Micro Kjeldahl Digestors
MODELS 6030000 & 6030001
INSTRUCTION MANUAL
Product designs are subject to change without notice
© 2002 Labconco Corporation
60352 REV. H / ECO 8842
Printed in U.S.A.
TABLE OF CONTENTS
Preface
Introduction
Components Shipped 1
General Description 2
Labeled Diagram of Unit 3
Installation 4
Dimensional Drawing 5
Normal Operation 6
Replacement Parts 7
Wiring Diagrams 10
Warranty 11
Shipping Claims 12
Contacting Labconco 13
PREFACE
Thank you for displaying confidence in us by selecting a Labconco Micro Kjeldahl Digestor. Our
design engineers, assemblers and inspectors have utilized their skills and years of experience to
ensure that the new Labconco Micro Kjeldahl Digestor meets our high standards of quality and
performance.
IMPORTANT NOTICE
This manual should be read carefully by all the end users in order to become familiar with the
operation of the Micro Kjeldahl Digestor. Recommendations are made within the manual to help
you obtain maximum performance and life from your product.
We have included sections on initial set up, operation, maintenance and troubleshooting to provide
you with all the tools necessary to achieve maximum performance.
If you have questions or concerns, do not hesitate to call us at 1-800-821-5525 for assistance.
INTRODUCTION
Components Shipped
Carefully check the contents of the carton for damage that might have occurred in transit. Do not
discard the carton or packing material until all components have been checked against the
following component list and the equipment has been installed and tested.
As shipped, the carton should contain the following:
Catalog # Description Ship Wt.
6030000 With Glass Manifold, 115 Volt AC 17 pounds
6030001 With Glass Manifold, 230 Volt AC 17 pounds
6035200 Instruction Manual
1
INTRODUCTION
General Description
Micro Kejeldahl Digestors are designed for the digestion of material containing nitrogen from
micro samples.
All Micro Digestors will accommodate six Micro Kjeldahl flasks (30 ml or 100 ml sizes). This is
accomplished by an adjustable glass manifold support and heaters that are recessed into the top of
the unit.
Heaters are controlled by infinite heat thermostats, with individual pilot lamps to indicate
“HEATER ON.” A chemically resistant finish is applied to the main housing exterior.
Detailed Function of Components
Heater Element. Each flask station has an individual 200 watt heater assembly which
consists of a tubular heater element and a stainless steel cup. The concave design holds the
flask securely and ensures even, well distributed heat.
Variable Heat Control Switch. Each heater element has an individual heat control pilot
light. The infinite heat controls have variable input from 20-100% of capacity.
Heat and Chemical Resistant Cabinet. The cabinet is epoxy coated. The top is 1-1/2
inch thick Maronite I insulating board to protect wiring and controls from heat and
chemicals.
Wiring. The Micro Digestion Unit is completely factory wired including a 5', 3-wire cord
and plug. An electrical receptacle is all that is needed for installation.
2
Labeled Diagram of Unit
INTRODUCTION
3
INSTALLATION
Specifications
(1) Electrical
Operating Volts: 115 or 230
Current (Max): 12 amp at 115 volts; 6 amp at 230 volt
Frequency: 50 or 60 Hz
(2) Remove all “fillers” CAREFULLY and check for separate parts packed inside. Catalog
#6030000 and 6030001 Digestors will have a glass manifold, 2 support brackets and
related hardware packed in their cartons.
(3) Place unit in a location having a convenient 120V, AC 3-wire receptacle.
NOTE: 230V AC models require permanent wiring connections – contact your electrician
for initial electrical hook-up in all cases!
(4) Mount the glass manifold support brackets into the glide rod clamps located on each side
panel. Loosen the thumb screw on the bottom glide clamp. Slide the support rods in place
and secure by tightening the thumb screw.
(5) Mount the glass manifold. Connect manifold outlet to a suitable water aspirator. Manifold
should be adjusted to provide a minimum 1/2" of the flask neck within the manifold.
4
Dimensional Drawing
DIMENSIONAL DRAWING
5
NORMAL OPERATION
Use of the Micro Kjeldahl
Applicable methods for nitrogen determination as outlined by the A.O.A.C. or other technical
procedures involved with Protein (Nitrogen) determination by the Kjeldahl method, are to be
referred to in all cases.
The infinite heat control in the digestor uses a bi-metallic element to proportion the on and off time
of the heating element. In the “high” position, the heater is on 100% of the time and in the “low”
position the heater is on 20% of the time.
A digestion of extremely small samples may require less heat than available from the lowest
control setting. In that event, a voltage reducing device should be used to reduce the power input
to the apparatus.
CAUTION: DO NOT boil flasks dry. Breakage of the flask may occur.
Maintenance
If a problem should arise, please contact Labconco Customer Service Department at 800-821-5525
or 816-333-8811 between the hours of 7:00 a.m. to 6:00 p.m. Central Standard Time.
Please include Labconco Catalog and Serial Numbers on all phone or letter inquiries to obtain
prompt action on your particular unit.
6
Manufactured before 1968
Models 1200 & 1200-A, 1250 & 1250-A
MICRO KJELDAHL DIGESTOR (OLD STYLE)
Cat. No. Description
60011 Glass Manifold
60018 Support Rod Assembly for Glass Manifold, Pr.
13154 Infinite Control, 120 Volt, 15 Amp
13155 Infinite Control, 240 Volt, 15 Amp
18702 Knob for Infinite Control
60132 Chromalox Heating Element, 115 Volt, 150 Watt
60133 Chromalox Heating Element, 115 Volt, 200 Watt
60205 Chromalox Heating Element, 230 volt, 250 watt
60119 Pilot Light Assembly, 115 Volt
60203 Pilot Light Assembly, 230 Volt
60110 Flask Support Cone 30 ml
60007 Flask Support Cone 100 ml
60079 Flask Support Rod with two uprights
60015 Bracket Assembly for #60079, Pr.
60103 Power Cord Set Assembly
REPLACEMENT PARTS
7
REPLACEMENT PARTS
Manufactured from 1968 to 1972
Serial Numbers 1001 to 21858
MICRO KJELDAHL DIGESTOR (OLD STYLE)
Cat. No. Description
60011 Glass Manifold
60317 Upright Bracket Assembly (for #60011), Pr.
60027 Horizontal Flask Support Assembly
60318 Upright Supports (for #60027), Pr.
60307 Heater Assembly – 115 Volt, 200 Watt
60307-01 Heater Assembly – 230 Volt, 200 Watt
13154 Infinite Control, 115 Volt, 15 Amp
13155 Infinite Control, 230 Volt, 15 Amp
60119 Pilot Lamp, 115 Volt
60203 Pilot Lamp, 230 Volt
18702 Knob for Infinite Control
60311 Heater Housing, Ceramic
60321 Guide Rod Clamp (with thumb screw)
60103 Power Cord Set, 115 Volt
60207 Power Cord Set, 230 Volt
60309 Top Plate, only (Marinite #23)
19253 Aluminum Vent Louvers
60357 Heater Conversion Kit, 115 Volt
60358 Heater Conversion Kit, 230 Volt
60375 Flask Kit, 6 @ 100 ml each
8
REPLACEMENT PARTS
Manufactured from January 1972 and September 1972
MICRO KJELDAHL DIGESTOR (NEW STYLE)
Cat. No. Description
60011 Glass Manifold
13154 Infinite Control, 115 Volt, 15 Amp
13155 Infinite Control, 230 Volt, 15 Amp
60119 Pilot Lamp, 115 Volt
60203 Pilot Lamp, 230 Volt
18702 Knob for Infinite Control
60321 Guide Rod Clamp (with thumb screw)
60027 Horizontal Flask Support Assembly
60336 Top Plate, only (Marinite I)
60350 Heater Assembly, 115 Volt, 200 Watt
60351 Heater Assembly, 230 Volt, 200 Watt
60342 Upright Supports (for #60011), Pr.
60343 Upright Supports (for #60027), Pr.
60103 Power Cord Set, 115 Volt
60207 Power Cord Set, 230 Volt
60375 Flask Kit, 6 @ 100 ml each
Manufactured January 1972 to Present
Models 60300C, 60300-01C, 60301C & 60301-01C, Same as above except:
Cat. No. Description
60346 Heater Assembly – 115 Volt, 200 Watt (with Heater Cup)
60347 Heater Assembly – 230 Volt, 200 Watt (with Heater Cup)
9
WIRING DIAGRAMS
Catalog No. 60300 & 60301 Models
Catalog No. 6030001 & 6030101 Models
10
WARRANTY
We are committed to providing our customers with quality equipment and service after the sale.
Part of this objective involves keeping you informed of changes and new product additions. We,
therefore, request that you take a moment to fill out the product registration card so we many know
your location as well as some of the reasons that prompted you to purchase our product.
Labconco provides a warranty on all parts and factory workmanship. The warranty includes areas
of defective material and workmanship, provided such defect results from normal and proper use
of the equipment.
The warranty for all Labconco products will expire one year from date of installation or two years
from date of shipment from Labconco, whichever is sooner, except the following:
• Purifier® Delta® Series Biological Safety Cabinets carry a three-year warranty from date
of installation or four years from date of shipment from Labconco, whichever is sooner.
• Carts carry a lifetime warranty.
• Glassware is not warranted from breakage when dropped or mishandled.
This limited warranty covers parts and labor, but not transportation and insurance charges. In the
event of a warranty claim, contact Labconco Corporation or the dealer who sold you the product.
If the cause is determined to be a manufacturing fault, the dealer or Labconco Corporation will
repair or replace all defective parts to restore the unit to operation. Under no circumstances shall
Labconco Corporation be liable for indirect, consequential, or special damages of any kind. This
statement may be altered by a specific published amendment. No individual has authorization to
alter the provisions of this warranty policy or its amendments. Lamps and filters are not covered
by this warranty. Damage due to corrosion or accidental breakage is also not covered.
WARNING: The disposal and/or emission of substances used in connection with this equipment
may be governed by various federal, state or local regulations. All users of this equipment are
urged to become familiar with any regulations that apply in the user’s area concerning the
dumping of waste materials in or upon water, land or air and to comply with such regulations.
11
SHIPPING CLAIMS
If shipment is received in visibly damaged condition, be certain to make a notation on the
delivering carrier’s receipt and have his agent confirm the damage on your receipt. Otherwise, the
damage claim may be refused.
If concealed damage or pilferage is discovered, notify the carrier immediately and retain the entire
shipment intact for inspection. Interstate Commerce Commission rules require that the claim be
filed with the carrier within 15 days after delivery.
NOTE: Do not return goods. Goods returned without prior authorization will not be accepted.
Labconco Corporation and its dealers are not responsible for shipping damage. Claims must be
filed directly with the freight carrier by the recipient. If authorization has been received to return
this product, by accepting this approval, the user assumes all responsibility and liability for
biological and chemical decontamination and cleansing. Labconco reserves the right to refuse
delivery of any products which do not appear to have been properly cleaned and/or
decontaminated prior to return.
12
CONTACTING LABCONCO
If you have any questions that are not addressed in this manual or if you need technical assistance,
please contact Labconco’s Customer Service Department at 1-800-821-5525, Labconco’s Product
Service Department at 1-800-522-7658 or either department at 1-816-333-8811, between the hours
of 7:00 a.m. and 6:00 p.m. Central Standard Time.
Labconco’s mailing address is:
Labconco Corporation
8811 Prospect Avenue
Kansas City, Missouri 64132-2696
Visit Labconco through the Internet at:
http://www.labconco.com
or
e-mail: labconco@labconco.com
13
