SUPPLEMENTARY INSTRUCTION SHEET
補足説明書
V-ONESROS12TG-Pエンジン付
取扱説明書に変更があります。組立てる前に必ずこの補足説明書をお読みください。
Please use these supplementary instructions in conjunction with the manual included in your kit.
V-ONE SR w/OS 12TG-P
No.31598TG
Page 31
31598TG-HT01
No.10
41
Engine
Page 31
42
Engine
3x8mm
3x10mm
3x10mm
3x8mm
4
3 x 8mm
Screw
Engine Assembly
174
165
161
162
160
159
183
164
167
166
181
158
175
185
157
Washer
3x8mm
7mm
Washer
5mm
1
Tighten the screws with
one sheet of paper inserted
between both gears.
A
"OS" Inscription
A
A
A
Part bags used. Must be purchased separately!
エンジン
ビス
エンジンアッセンブリー
31ページ
エンジン
31ページ
ワッシャー
ワッシャー
紙1枚分のすき間をつくって
固定する。
OSの刻印
使用する袋詰。 別購入品。

191 190188
191
191
191
187
188
190
189
189
2
180
Bend the wire to adjust the muffler.
Muffler
3x3mm
1
3 x 3mm
Set Screw
Rear Stiffener
3x10mm
3x10mm
156
2
3 x 10mm
Screw
No.9
Page 32
No.9
43
A
A
Part bags used. Must be purchased separately! Cut off excess.
192
使用するマフラーに合わせて曲げる。
マフラー
セットビス
リヤスティフナー
ビス
32ページ
使用する袋詰。 別購入品。 余分をカットする。

3
Fuel Tube
Page 32
44
Air Cleaner
143
Silicone Tube
143
Silicone Tube
Must be purchased separately!
燃料チューブ
エアークリーナー
32ページ
シリコンチューブ
シリコンチューブ
別購入品。

PRINTED IN JAPAN61921005-1© Copyright 2010 KYOSHO CORPORATION
4
Tires and wheels are not included with this kit.
Refer to dimensions shown and fit your choice of tires & wheels.
Use body pins to fix on
to body mounts.
Tire & Wheel
Page 34
47
A
Body is not inclued with this kit.
Fit your preferred 200mm wide touring car body.
A
Remove to adjust, then reattach.
B
Body Shell
Body Pin
4
Body Pin
4
Must be purchased separately!
< >Front
< >Rear
24 ~ 26mm
200mm
Assemble left and right sides the same way.
B
A
A
24 ~ 26mm
A
このキットにはタイヤ、ホイールが付属されておりません。
図の寸法をご参考に、お好みのものをお選びください。
このキットにはボディが付属されておりません。
市販の200mm幅ツーリングカーボディをお選びください。
いったんはずして取付け直します。
ボディピンは、ボディの取付けに
使用します。
※
タイヤ&ホイール
34ページ
/ 禁無断転載複製
ボディ
ボディピン
ボディピン
別購入品。
< >
< >
左右同じように組立てる。
フロント
リヤ
