Kyosho V-ONE S User Manual

V-ONE S SERIES　Parts acceptable List

○ NOMAL ● OPTION

№ ENGLISH JAN V-ONE SⅢ V-ONE SⅡ V-ONE S

1180 Flanged Nylon Nut(M4) 4955439652947 ○ ○

1284 Pillow Ball(5.8) 4955439654972 ○ ○

1705 Color Antenna(white) 4955439666296 ○ ○

1706 Color Antenna (KP) 4955439666302 ● ●

1707 Color Antenna (KY) 4955439666319 ● ●

1708 Color Antenna(Black) 4955439740880 ● ●

1709KG Fluorescent Velcro(Green/25x100/4pcs) 4955439858813 ● ●

1709KY Fluorescent Velcro(Yelow/25x100/4pcs) 4955439858998 ● ●

1776-01 Pitbox(Catch) 4955439790946 ○ ○

1790 Color Silicone Tube 4955439655139 ○ ○

1790BL Color Silicone Tube(2.3x1000 Blue) 4955439789858 ● ●

1790SG Color Silicone Tube(2.3x1000 Smoke Grey) 4955439789872 ● ●

1790R Color Silicone Tube(2.3x1000 Red) 4955439789865 ● ●

1808 Rod Stopper 4955439673508 ○ ○

1879 Grease 4955439655375 ○ ○

39057 Manifold(V-One S) 4955439741542 ○ ○

39064 Tuned Muffler(Nipple) 4955439752579 ● ●

39068 Tuned Muffler(5.2) 4955439758915 ●

39069 Tuned Muffler Set(For V-One S/Side Exhau 4955439763902 ● ●

39070 Manifold(For V-One S/Side Exhast) 4955439763933 ● ●

39071 Tuned Muffler(For V-One S) 4955439763896 ● ●

39173 Body Set Chivolet Corvette C5-R 4955439743379 ● ● ●

39173-1V Decal Set(Chivolet Corvette C5-R 2002)fo 4955439765883 ● ● ●

39174 Body Set(ZERO McLaren) 4955439743126 ● ● ●

39174-1 Sponsor Decal(ZERO McLare 4955439743096 ● ● ●

39179 Body Set(SKYLINE GT-R) 4955439748237 ● ● ●

39179-1 Sponsor Decal(Calsonic Skyline) 4955439747490 ● ● ●

39184 Body Sell(Castrol TOM'S SUPRA) 4955439752197 ● ● ●

39184-1 Sponsor Decal(Castrol TOM'S SUPRA) 4955439752180 ● ● ●

39186 Body(Lora/1.0mm/For V-One S) 4955439762769 ● ●

39186-1 Decal(V-One S) 4955439762783 ● ●

39241 Body(VAUXHALL ASTRA) 4955439043561 ● ● ●

39241-1B Sponsor Decal(VAUXHALL ASTRA) 4955439755495 ● ● ●

39243-1 Sponsor Decal(au Cerumo SUPRA 2002) 4955439757345 ● ● ●

39247 Body(PLUS e TAISAN ADVAN PORSCHE911 GT3R 4955439759431 ● ● ●

39247-1B Sponsor Decal(PLUS e TAISAN ADVAN GT3R) 4955439759387 ● ● ●

39248-1 Sponsor Decal(XANAVI NISMO GT-R) 4955439760567 ● ● ●

39249 Body(CLK DTM 2002 AMG Mercedes) 4955439762738 ● ● ●

39249-1 Sponsor Decal(CLK DTM 2002 AMG Mercedes) 4955439762745 ● ● ●

39250-1 Decal Set(ESSO Ultraflo Supra)for PureTe 4955439765890 ● ● ●

39251-1 Sponsor Decal(G'ZOX MUGEN NSX 2003) 4955439766798 ● ● ●

39252 Body Shell (NISMO FAIRLADY 350Z) 4955439766989 ● ● ●

39252-1 Sponsor Decal(NISMO FAIRLADY 350Z) 4955439766996 ● ● ●

39253-1 Sponsor Decal(Mobil 1 NSX) 4955439769775 ● ● ●

39254-1 Sponsor Decal(WOODONE SUPRA) 4955439769768 ● ● ●

39255 Body Set(ALFA 156 GTA) 4955439769829 ● ● ●

39255-1B Sponsor Decal(for ALFA 156 GTA Super2000 4955439771792 ● ● ●

1/11 【2006.3.22改定】

V-ONE S SERIES　Parts acceptable List

○ NOMAL ● OPTION

№ ENGLISH JAN V-ONE SⅢ V-ONE SⅡ V-ONE S

39256 Body Set(MOTUL PITWORK GT-R) 4955439773581 ● ● ●

39256-1 Sponsor Decal(MOTUL PITWARK GT-R) 4955439773635 ● ● ●

39257 Body Set(BMW M3 GTR/PureTen Size) 4955439775691 ● ● ●

39257-1 Sponsor Decal(BMW M3 GTR) 4955439775684 ● ● ●

39258 Body Set(NSX 2004)PureTen Size 4955439794203 ● ● ●

39258-1 Sponsor Decal(EPSON NSX 2004) 4955439794197 ● ● ●

39259 Body Set(CALSONIC IMPUL Z)PureTen Size 4955439793978 ● ● ●

39259-1 Sponsor Decal(CALSONIC INPUL Z) 4955439793985 ● ● ●

39260 Porsche 911 GT2 Body Set 4955439859049 ● ● ●

39260-1 Decal(Porsche 911 GT2) 4955439858981 ● ● ●

39262-1 Sponsor Decal(Vauxhall BTCC Astra Coupe 4955439793046 ● ● ●

39263 Body Set(SUBARU Impreza WRC 2004) 4955439865736 ● ● ●

39263-1 Decal(SUBARU Impreza WRC 2004) 4955439865743 ● ● ●

39264 Ferrari 360GTC Body Set 4955439861578 ● ● ●

39265 Ferrari 575GTC Body Set 4955439865101 ● ● ●

39266 Ford Mustang GTR Body Set 4955439865118 ● ● ●

39267-1 Sponsor Decal(MOTUL PITWORK Z) 4955439859322 ● ● ●

39268-1 Sponsor Decal(TAKATA DOME NSX) 4955439859315 ● ● ●

39269 Body Set (SUPRA 2005) P-Ten Size 4955439865842 ● ● ●

39269-1 Decal (DYNACITY SUPRA) 4955439865835 ● ● ●

39270-1 Sponsor Decal(G'ZOX HASEMI Z) 4955439867372 ● ● ●

39305-03 Spur Gear (L) 43T 4955439660584 ● ●

39305-04 Spur Gear (H) 40T 4955439660591 ● ●

39305-07 Shift Cam Set 4955439660621 ● ●

39305-08 Spur Gear (H) 37T 4955439660638 ● ●

39305-09 Spur Gear (H) 38T 4955439660645 ● ●

39305-10 Spur Gear (H) 39T 4955439660652 ● ●

39305-11 Spur Gear (H) 41T 4955439660669 ● ●

39308 Fuel Filter (M) 4955439654651 ● ●

39648 Special Engine Mount 4955439695852 ● ●

39673 VESPEL Clutch Shoe(KC45) 4955439698082 ● ●

39721-1 Spur Gear(L)43T-48 4955439703663 ● ●

39724 PC Clutch Bell 4955439710685 ● ●

39724-13 PC Pinion Gear13T 2Speed 4955439710692 ● ●

39724-14 PC Pinion Gear14T 2Speed 4955439710708 ● ●

39724-15 PC Pinion Gear15T 2Speed 4955439710715 ● ●

39724-16 PC Pinion Gear16T 2Speed 4955439710722 ● ●

39724-17 PC Pinion Gear17T 2Speed 4955439710739 ● ●

39724-18 PC Pinion Gear18T 2Speed 4955439710746 ● ●

39724-19 PC Pinion Gear19T 2Speed 4955439710753 ● ●

39724-20 PC Pinion Gear20T 2Speed 4955439710654 ● ●

39724-21 PC Pinion Gear21T 2Speed 4955439710661 ● ●

39724-22 PC Pinion Gear22T 2Speed 4955439710678 ● ●

39724-23 PC Pinion Gear 23T 2Speed 4955439719183 ● ●

39724-24 PC Pinion Gear 24T 2Speed 4955439719190 ● ●

39724-25 PC Pinion Gear 25T 2Speed 4955439719206 ● ●

39724-26 PC Pinion Gear 26T 2Speed 4955439719213 ● ●

2/11 【2006.3.22改定】

V-ONE S SERIES　Parts acceptable List

○ NOMAL ● OPTION

№ ENGLISH JAN V-ONE SⅢ V-ONE SⅡ V-ONE S

6510-05 Flywheel Spacer 4955439650196 ○ ○

6510-15 Screw Set 4955439650295 ○ ○

6510-24BL Cylinder Head(GS-11R/Blue) 4955439759349 ● ●

6510-27 Needle Set 4955439724323 ○ ○

6591 Gasket Muffler 4955439655771 ○ ○ ○

695030 Aluminum Drive Pulley 18T 4955439748459 ● ●

695031 Aluminum Drive Pulley 19T 4955439748466 ● ●

695032 Aluminum Drive Pulley 27T 4955439748473 ● ●

695033 Aluminium Drive Pulley 25T 4955439752425 ● ●

695034 Aluminum Drive Puller 32T 4955439748893 ● ●

695035 V-One Brake Bracket & Stiffener 4955439755242 ● ●

695036 Front Upper Sus.Arm 4955439757468 ● ●

695037 Rear Upper Sus.Arm 4955439757475 ● ●

74001B EP Starter Unit(GS15R/PR) 4955439791684 ○ ○ ○

74001-1B Starter Case(GS15R/PR) 4955439791691 ○ ○ ○

74001-3 Starter Motor 4955439739587 ○ ○ ○

74001-4 One Way Shaft 4955439739594 ○ ○

74001-5C Gears/Shaft(for EP Starter Unit) 4955439777169 ○ ○ ○

74001-6 One Way Bearing 4955439746639 ○ ○ ○

74001-7 One-Way Shaft(GXR15) 4955439862049 ○

74002 Starter Wiring Unit 4955439739600 ○ ○ ○

74003 Connector Unit 4955439739617 ○ ○ ○

74016B GXR15 Engine 4955439863831 ○

74016-01 Cylinder Head(GXR15) 4955439793930 ○

74016-02 Head Gasket(GXR15) 4955439793923 ○

74016-03 Crankcase(GXR15) 4955439793916 ○

74016-03-1 Front Bearing(GXR15) 4955439795248 ○

74016-03-2 Rear Bearing(GXR15) 4955439795255 ○

74016-04 Crankshaft(GXR15) 4955439793909 ○

74016-05 Piston & Cylinder(GXR15) 4955439793893 ○

74016-06 Piston Pin(GXR15) 4955439793886 ○

74016-07 Connecting Rod(GXR15) 4955439793879 ○

74016-08 Recoil Starter Assembly(GXR15) 4955439793862 ○

74016-08-1 Recoil Starter Unit(GXR15) 4955439795231 ○

74016-08-2 Starter Shaft(GXR15) 4955439795224 ○

74016-08-3 Starter Holder(GXR15) 4955439795217 ○

74016-09 Carburetor Assembly(GXR15) 4955439793855 ○

74016-09-1 Carburetor Case(GXR15) 4955439795279 ○

74016-09-2 Needle Set(GXR15) 4955439795286 ○

74016-09-3 Slide Valve Set(GXR15) 4955439795262 ○

74016-10 Ball Joint(GXR15) 4955439794043 ○

74016-11 Screw Set(GXR15) 4955439794050 ○

74016-12 Throttle Return Spring(GXR15) 4955439794067 ○

74016-13 Crankcase(GXR15 for Touch Starter) 4955439862094 ○

74901 GS15R Engine 4955439729441 ○ ○

74901ES GS15R Engine(EP Unit) 4955439739624 ○ ○

74901SP GS15R Engine(With SP Cylinder Head/Blue) 4955439790892 ● ●

3/11 【2006.3.22改定】

V-ONE S SERIES　Parts acceptable List

○ NOMAL ● OPTION

№ ENGLISH JAN V-ONE SⅢ V-ONE SⅡ V-ONE S

74901-01 Carburetor Drum Set 4955439727485 ○ ○

74901-02 Head Gasket 4955439727492 ○ ○

74901-03 Piston Pin 4955439727508 ○ ○

74901-04 Crank Case(GS15R) 4955439727515 ○ ○

74901-05B Crank Shaft(GS15R) 4955439752609 ○ ○

74901-06 Piston Cylinder 4955439727539 ○ ○

74901-07 Head(GS15R) 4955439727546 ● ○

74901-07GM Head(GS15R/Gun Metallic) 4955439762462 ○ ●

74901-08 Connecting Rod 4955439727553 ○ ○

74901-09 Starter Assembly 4955439727560 ○ ○

74901-10 One Way Shaft 4955439727577 ○ ○

74901-11 Starter Holder 4955439727584 ○ ○

74901-12 Engine Plate 4955439727591 ○ ○

74901-13 Carburetor Set 4955439727607 ○ ○

74901-14BL SP Cylinder Head(GS-15R) 4955439747643 ● ●

74901-14GM SP Cylinder Head(GS-15R/Gunmetallic) 4955439766552 ● ●

74902 GS Glow Plug 4955439766095 ○ ○

80151 Tire Fitting Tool 4955439749159 ● ●

80152 Toe Angle Gauge(200mm) 4955439752012 ● ●

92001 On-Road Spring (Hard) 4955439738085 ● ●

92011 Wheel(Mesh/White)PureTen Size 4955439763377 ● ●

92011S Wheel(Mesh) 4955439748268 ● ●

92012-8BK Aero 24 Wheel(15-Spoke/Bluck)8pcs 4955439772270 ● ● ●

92012-8KG Aero 24 Wheel(15-Spoke/Fluorescence Gree 4955439859353 ● ●●

92012-8KP Aero 24 Wheel(15-Spoke/Fluorescence Pink 4955439859346 ● ●●

92012-8KY Aero 24 Wheel(15-Spoke/Fluorescence Yell 4955439859339 ● ●●

92012-8W Aero 24 Wheel(15-Spork)8p 4955439741474 ● ● ●

92012BK Aero 24 Wheel(15-Spork)Bl 4955439741467 ● ● ●

92012W Aero 24 Wheel(15-Spork)Wh 4955439741450 ● ● ●

92013 Inner Sponge 4955439742242 ○ ● ●

92014-25B V-Slicks Tire M-25MN 4955439759370 ● ● ●

92014-30B V-Slicks Tire M-30MN 4955439759363 ○ ● ●

92014-35B V-Slicks Tire M-35MN 4955439759356 ● ● ●

92014-40 V-Slicks Tire 4955439746110 ● ● ●

92022 Multi Gauge for Ground Cl 4955439736746 ● ●

92023 Air Cleaner(10/15) 4955439793800 ○

92023-1 Air Cleaner Sponge(3pcs) 4955439793794 ○

92023-2 Air Cleaner Cover 4955439859308 ○

92032 Adjust Rod(45) 4955439741511 ○ ○ ○

92050B 75cc Fuel Tank 4955439770078 ● ● ●

92050-01 Sponge Packing for Fuel Tank 4955439742211 ● ● ●

92051 2x11 Pin 4955439741528 ○ ○ ○

92060 Muffler Joining Pipe 4955439741337 ●

92070 Fly Wheel 4955439742877 ○ ○

92071 Clutch Bell(16T) 4955439742884 ○ ○

92201 TCD Gear Oil 4955439752463 ● ●

92211 Shock Spring Dial Adjuster 4955439752432 ● ●

4/11 【2006.3.22改定】
