FCC Notice:
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Caution:
The user is cautioned that changes or modifications
not expressly approved by the party responsible for
compliance could void the warranty and users’
authority to operate the equipment.
Note:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC Radiation Exposure Statement:
To comply with the FCC RF exposure compliance
requirements, this device must not be co-located
or operating in conjunction with any other antenna
or transmitter.
Industry Canada Notice
Operation is subject to the following two conditions:(1)
this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of the
device. The term “IC:” before the radio certification
number only signifies that Industry Canada technical
specifications were met. This product meets the
applicable Industry Canada technical specifications of
the RSS210.
Kyocera is a registered trademark of Kyocera
Corporation. The Bluetooth word mark and logos are
owned by the Bluetooth SIG, Inc. and any use of such
marks by Kyocera Wireless Corp. is under license. All
other marks are held by their respective owners.
Copyright © 2007 Kyocera Wireless Corp.
All rights reserved.
Page 3
Wireless Stereo Headset with Pendant Controller iii
CONTENTS
Wireless Stereo Headset
with Pendant Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Using the toggle key. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Powering the headset on and off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Pairing the headset to your mobile phone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Playing music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Making calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Receiving calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Rejecting calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Call transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Page 4
Page 5
Wireless Stereo Headset with Pendant Controller 1
Wireless Stereo Headset
with Pendant Controller
Your new stereo audio quality Wireless Stereo
Headset with Pendant Controller provides hours of
comfortable music listening or for making mobile
phone calls.
Noise reducing software technology lets you enjoy
outstanding voice call quality. The Wireless Stereo
Headset with Pendant Controller can be used in
noisy environments and still deliver sharp voice
quality and receive the best, clearest audio clarity.
Bluetooth Wireless Technology
Bluetooth wireless technology is a short-distance
wireless communication technology. The range of
operation between Bluetooth wireless technology
enabled devices is about 10 meters (33 ft.).
Bluetooth wireless technology enabled devices do
not require line of sight and can transmit through
walls and other non-metal obstacles. Thick or
reinforced concrete can limit the range.
1. Ear jack connector
2. Navigation points
(toggle
up +, down -,
right >>| or left |<<)
3. Hold switch
4. USB charging jack
5. Microphone
6. Toggle key
7. LED
Using the toggle key
The toggle key controls the following functions:
To do this...
Do this with
the
toggle key...
Power on and off Press IN for approximately
1.5 seconds.
Volume control Press
up + or down -.
Music play Press
IN briefly. Press IN briefly
again to resume.
Pairing Press
up + or down - for 4 to
5 seconds.
Receiving a call When the phone rings, press
IN briefly.
Initiating a
voice-activated call
Press
right >>| or
left |<< for approximately 1.5
seconds and follow the voice
prompts.
Redialing Press
right >>| or
left |<< twice briefly.
Call Switching Press
IN for approximately
one and a half seconds.
End a call While in a call press
IN
Reject a call Press and hold IN
Page 6
2 82-G1653-1EN, Rev. 002
Getting started
Remove all components from the package:
1. Wireless Stereo Headset with Pendant Controller
2. USB connector for charging
3. Lanyard w/earbuds
4. User Guide
Charging the headset
This headset is equipped with the latest Li-Polymer
battery which can be charged at any time without
degrading the battery life, regardless of the amount
of charge remaining.
The battery must be fully charged before initial use.
It takes approximately 1 hour to charge the battery
when fully discharged; less time if it has a partial
charge.
A single charge will provide approximately 200
hours of stand-by time. You can call or listen to
music continuously for up to five hours.
1. Ensure the headset is turned off.
2. Connect the pendant to your computer’s USB
port using the provided USB adapter.
Note: If using a charger other than the one
provided with your device, ensure that it is
approved for use with this product.
3. While the pendant is charging the red LED is lit.
4. When the device is fully charged the red LED
blinks and then turns off.
Important: The rechargeable battery in the headset
must be disposed or recycled according to local
ordinance regulations.
Checking the battery level
• With the headset turned on, press the toggle
key
down - for approximately one and a half
seconds. The LED blinks in the following
patterns (the more blinks, the fuller the battery):
– 5 consecutive blinks: fully charged/over 4.0V
– 4 consecutive blinks: 3.8V
– 3 consecutive blinks: 3.6V
– 2 consecutive blinks: 3.4V
– 1 blink: nearly dead/under 3.4V
Powering the headset on and off
Power on
• Press the toggle key IN for approximately
one and a half seconds. The LED lights up, and if
the earpiece is in place, you can hear the tones
of the scale play from low to high.
Power off
• Press the toggle key IN for four to five
seconds to power the pendant off. If the
earpiece is in place, you can hear the tones of
the scale play from high to low, and the LED
turns off.
Pairing the headset to your
mobile phone
Before you can use the headset to make calls, you
must pair the headset with your phone. Pairing
creates a secure link between your phone and the
unique ID of the headset. You only have to pair
devices once.
Page 7
Wireless Stereo Headset with Pendant Controller 3
When the device is initially powered on, it is
automatically in pairing mode. The LED blinks
rapidly for approximately eight seconds and then
stops. The LED will then continue blinking at five
second intervals.
If you did not pair the headset with your mobile
phone when you initially turned it on, you can do so
at any time.
1. After power-on, press the toggle key up + or
down - for four to five seconds
Note: The blue LED will blink rapidly indicating
that it is in pairing stand-by status.
2. Prepare your mobile phone for pairing according
to the instructions provided with the phone.
3. Begin pairing the headset and the phone
according to the instructions provided with
the phone.
4. Select ED-8800.
Note: The password is 0000.
5. Once the devices have been successfully
paired, the blue LED starts to blink twice at
five-second intervals. When the Bluetooth icon
displays on the mobile phone LCD, the
registration is complete.
Note: If the LED blinks rapidly for several
seconds, the pairing was unsuccessful. In this
case, power off both the phone and the headset
and begin the paring process again.
6. The connection between the headset and
phone terminates when the distance exceeds
10M (33 ft.).
If this happens, press the toggle key to the
right >>| or left |<<, and the connection will be
recovered. The stereo profile is connected if you
press the toggle key
IN or will automatically
reconnect after about four minutes.
Playing music
Make sure you are within 10M (33 ft.) of the music
player. (This distance may vary depending the other
device’s specifications.)
Note: Ensure that the headset is paired with the
mobile phone.
Adjusting the volume
• While listening to music or making a call, press
the toggle key
up + or down -.
Controls
• Press the toggle key IN to start the MP3
player. Press
IN again to stop the music.
• While music is playing, a toggle to the or
left |<< returns to the beginning of the
current song.
• To gg l e to the right >>| to jump to the
next music selection.
• Press and hold the toggle key IN to stop
the music.
Page 8
4 82-G1653-1EN, Rev. 002
Making calls
Direct dial from phone
1. Dial the number on your mobile phone.
2. Touch toggle key slightly to the right >>|
or left |<<.
Note: If your mobile phone supports auto-
transfer and is set to do so, the call transfers to the
headset automatically.
Redial
• Press the toggle key briefly twice
towards the
right >>| or left |<< to redial the
last number.
Note: This only functions if you are not in music
play mode.
Voice activated call
Note: The phone must support hands-free and
voice recognition functions and voice dial must
already be set up for this number.
1. Press the toggle key right >>| or left |<< for
approximately one and half seconds.
2. When the mobile phone tells you to speak the
name, you will hear a beep at which time you
should say the name.
Receiving calls
• When you receive the call, press the toggle key
briefly to the right >>| or left |<< to answer.
Rejecting calls
• Press and hold the toggle key IN.
Note: This function may not be supported on
all devices.
Call transfer
Using the mobile phone
To transfer a call from the mobile phone to the
headset, press the transfer key on the mobile
phone according to the device’s instructions.
Repeat this process to transfer the call back to the
mobile phone.
Using the headset pendant
To transfer a call from mobile phone to the
headset, press and hold the toggle key
IN for
approximately one and a half seconds. Repeat
this process to transfer the call back to the
mobile phone.
Note: The call may be dropped if the transfer
process is mishandled.
Ending a call
To hang up the phone, press the toggle key IN.
If the other party hangs up before you do, the call is
automatically ended.
Safety Information
• Please do not connect the plug of the headset
charger with wet hands.
• Please do not let children or pets bite or suck on
the headset.
• Please ensure the headset is powered off when
entering construction or other areas that may be
susceptible to explosions.
• Please do not use the headset while driving
your car.
Page 9
Wireless Stereo Headset with Pendant Controller 5
•
To protect your hearing, and prevent
hearing loss, ensure volume is kept within
reasonable levels.
Notes
Some features or functions may not be supported
by your mobile phone. Please check with your
service provider for specific feature information.
To ensure correct operation, please read the
following safety information carefully.
• Take care not to drop the headset. This may
shorten product life and void the warranty.
• Do not disassemble the headset. This will void
the product support agreement.
• If the headset has not been used for several
hours, charge it completely before its next use.
This will help ensure proper operation.
• Take care not to press the toggle key by
mistake. This may activate the redial function,
and initiate a call.
• To prevent possible disruptions or noise, please
do not use the headset near a microwave.
• While charging the headset, please ensure the
power is off, and use the charger included with
the kit. Using an incorrect charger may result in
product failure.
• Please do not leave your headset in high
temperature settings, such as a sauna or in the
car during the summer.
Page 10
6 82-G1653-1EN, Rev. 002
Kyocera Wireless Corp. (“KYOCERA”) offers you a
limited warranty that the enclosed product or
products (the “Product”) will be free from defects in
material and workmanship for a period that expires
one year from the date of sale of the Product to you,
provided that you are the original end-user purchaser
of the Product and provided that your purchase was
made from an authorized supplier. Transfer or resale
of a Product will automatically terminate warranty
coverage with respect to that Product. This limited
warranty is not transferable to any third party,
including but not limited to any subsequent purchaser
or owner of the Product. This limited warranty is
applicable only to end users in the United States and
Canada.
KYOCERA shall, at its sole and absolute discretion,
either repair or replace a Product (which unit may use
refurbished parts of similar quality and functionality) if
found by KYOCERA to be defective in material or
workmanship, or if KYOCERA determines that it is
unable to repair or replace such Product, KYOCERA
shall refund the purchase price for such Product,
provided that the subject Product (i) is returned, with
transportation prepaid, to a KYOCERA authorized
service center within the one year warranty period,
and (ii) is accompanied by a proof of purchase in the
form of a bill of sale or receipted invoice which
evidences that the subject Product is within the one
year warranty period (“Proof of Purchase”). After the
one year warranty period, you must pay all shipping,
parts and labor charges.
This limited warranty does not cover and is void with
respect to the following: (i) any Product which has
been improperly installed, repaired, maintained or
modified; (ii) any Product which has been subjected to
misuse (including any Product used in conjunction
with hardware electrically or mechanically
incompatible or used with accessories not approved
by KYOCERA), abuse, accident, physical damage,
abnormal operation, improper handling, neglect,
exposure to fire, water or excessive moisture or
dampness or extreme changes in climate or
temperature; (iii) any Product operated outside
published maximum ratings; (iv) cosmetic damage; (v)
any Product on which warranty stickers or Product
serial numbers have been removed, altered, or
rendered illegible; (vi) cost of installation, removal or
reinstallation; (vii) signal reception problems (unless
caused by defects in material and workmanship); (viii)
damage the result of fire, flood, acts of God or other
acts which are not the fault of KYOCERA and which
the Product is not specified to tolerate, including
damage caused by mishandling, shipping and blown
fuses; (ix) consumables (such as fuses); or (x) any
Product which has been opened, repaired, modified
or altered by anyone other than KYOCERA or a
KYOCERA authorized service center.
USE ONLY KYOCERA APPROVED ACCESSORIES WITH
KYOCERA PHONES. USE OF ANY UNAUTHORIZED
ACCESSORIES MAY BE DANGEROUS AND WILL
INVALIDATE THE PHONE WARRANTY IF SAID
ACCESSORIES CAUSE DAMAGE OR A DEFECT TO
THE PHONE.
CONSUMER LIMITED WARRANTY
Page 11
Wireless Stereo Headset with Pendant Controller 7
KYOCERA SPECIFICALLY DISCLAIMS LIABILITY FOR
ANY AND ALL DIRECT, INDIRECT, SPECIAL, GENERAL,
PUNITIVE, EXEMPLARY, AGGRAVATED, INCIDENTAL
OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED
OF THE POSSIBILITY THEREOF, WHETHER
FORESEEABLE OR UNFORESEEABLE OF ANY KIND
WHATSOEVER, INCLUDING BUT NOT LIMITED TO
LOSS OF PROFITS, UNANTICIPATED BENEFITS OR
REVENUE, ANTICIPATED PROFITS ARISING OUT OF
USE OF OR INABILITY TO USE ANY PRODUCT (FOR
EXAMPLE, WASTED AIRTIME CHARGES DUE TO THE
MALFUNCTION OF A PRODUCT) OR CONTRIBUTION
OR INDEMNITY IN RESPECT OF ANY CLAIM RELATED
TO A PRODUCT.
REPAIR OR REPLACEMENT OF A DEFECTIVE PRODUCT
OR REFUND OF THE PURCHASE PRICE RELATING TO A
DEFECTIVE PRODUCT, AS PROVIDED UNDER THIS
WARRANTY, ARE YOUR SOLE AND EXCLUSIVE
REMEDIES FOR BREACH OF THE LIMITED WARRANTY,
AND SUBJECT TO THIS WARRANTY, THE PRODUCTS
ARE APPROVED AND ACCEPTED BY YOU “AS IS”.
KYOCERA MAKES NO OTHER WARRANTIES,
REPRESENTATIONS OR CONDITIONS OF ANY KIND,
ORAL OR VERBAL, EXPRESS OR IMPLIED, STATUTORY
OR OTHERWISE, WITH RESPECT TO THE PRODUCTS,
INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTY OR CONDITION OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE OR
AGAINST INFRINGEMENT OR ANY IMPLIED
WARRANTY OR CONDITION ARISING OUT OF TRADE
USAGE OR OUT OF A COURSE OF DEALING OR
COURSE OF PERFORMANCE. NO DEALER,
DISTRIBUTOR, AGENT OR EMPLOYEE IS AUTHORIZED
TO MAKE ANY MODIFICATION OR ADDITION TO THIS
WARRANTY.
Some jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages, or
allow limitations on how long an implied warranty
lasts, so the above limitations or exclusions may not
apply to you. This limited warranty gives you specific
legal rights, and you may also have other rights which
vary from jurisdiction to jurisdiction.
For warranty service information, please call the
following telephone number from anywhere in the
continental United States and Canada:
1-800-349-4478 or 858-882-1401; or contact
KYOCERA at the following address:
10300 Campus Point Drive, San Diego, California,
92121-1582, USA, Attention: Technical Support.
DO NOT RETURN YOUR PRODUCTS TO THE
ABOVE ADDRESS. Please call or write for the
location of the Kyocera Wireless Corp. authorized
service center nearest you and for procedures for
obtaining warranty service.
Loading...
