PRINTER OPTIONS
HS-3
PARTS CATALOGUE
PRINTER OPTIONS - Parts Catalogue KYOCERA HS-3 Page 1
HS-3 Parts Catalogue
Table of Contents
Introduction
The figures which follow depict the major assemblies of the printer or option,
broken down into components. Following each figure are the list giving the
following information:
Reference number which corresponds to the parts in the figure’Ref No.’
Part code which identifies the part’Part code’
A brief description of the part’Part description’
Quantity of the part used in the printer or option’Quantity’
Only the parts highlighted in BOLD should be ordered. All other parts are for
reference only and are not stocked.
3Exploded view (Fig.1)
PRINTER OPTIONS - Parts Catalogue KYOCERA HS-3 Page 2
PRINTER OPTIONS - Parts Catalogue KYOCERA HS-3 Page 3
Fig.1 - Exploded view
02-008
02-025
02-023
02-027
02-003
KP395B
02-004
02-025
01-002
02-025
02-010
02-024
02-002
02-005
02-026
01-014
02-015
01-011
01-020
02-001
02-006
03-009
02-011
02-016
02-017
03-013
02-019
03-034
03-006
03-002
03-009
01-015
02-018
02-009
01-016
02-021
01-013
02-007
01-012
03-012
01-018
KP396B
02-020
03-005
03-032
03-010
03-024
02-025
01-017
03-004
03-021
03-006
03-003
03-035
03-020
03-034
03-019
03-005
01-007
03-017
01-019
03-022
01-019
03-026
03-033
03-025
03-007
03-011
03-028
03-001
03-009
03-029
03-027
01-008
03-009
03-028
03-030
03-013
KP396B
03-015
03-014
03-031
01-004
03-016
01-009
03-008
01-003
03-018
01-006
01-010
01-005
01-001
QuantityDescriptionPart CodeRef No. QuantityDescriptionPart CodeRef No.
1500 SHEET HANDLER STACKERHS-301-000
1COVER RIGHT5MVB885SW00201-001
1COVER LEFT5MVB885SW00301-002
1LID TOP5MVX874SW00201-003
2SHAFT EXIT5MMT733SN00101-004
4SPRING PULLEY5MMW251LD00501-005
4PULLEY EXIT5MVM174DB00201-006
1COVER TOP5MVX863SW00501-007
1PUSH SWITCH ASSY5AAYHS3***0301-008
1TRAY BACK5MVB872SW02901-009
1BKT HS5MVB876SW00801-010
1COVER JOINT5MVS432SW00101-011
1COVER GEAR5MVX332SB01601-012
1SPRING COVER5MMW162LJ01201-013
1BELT MXL109-325MVM150RB00901-014
1GEAR FUX Z32-P195MVG048DB00701-015
1GEAR ED Z305MVG138DB02001-016
1LABEL SERIAL J5MVVSH3J**101-017
1LABEL SERIAL5MVVSHS3***101-017
2SHEET STACK5MVS631KN00101-018
2SEAL PWB5MVS111KN00201-019
1POLY WASHER5MBWN92135NB01-020
1PLATE ENCODER5MVM196DB00301-022
1FRAME LOW5MMZ866SL00202-001
1BOX PWB5MVB764SW00502-002
1CONN. CORD S008445AACCNNB3GEA02-003
1GUIDE PAPER F5MMS866SL01702-004
1ROLLER TRANS A5MMT875SN00502-005
1ROLLER EXIT5MMT875SN00602-006
2GEAR Z145MVG127DB02902-007
1PULLEY P175MVG327DB00302-008
2BUSHING SBK5MMM176CJ00502-009
2BUSHING POM5MVM176DB00602-010
1GUIDE PAPER R5MVL866SW00102-011
2SPACING CLIP5MVX431NN00102-015
1FRAME RIGHT5MMX777SL00102-016
1TRNS MOTOR ASSY5AAYHS3***0202-017
1GEAR Z28-P565MVG368DB00102-018
2GEAR FEED Z145MVG127DB03002-019
1GEAR Z28-P565MVG148DB01802-020
1BELT MOTOR Z705MVM150RB00702-021
1FRAME LEFT5MMX777SL00202-023
1MICRO SWITCH5ESM010234***0102-024
1CONN CORD S008455AACCNNB4GEA02-025
1PULLEY MXL145MVG326DB00102-025
PRINTER OPTIONS - Parts Catalogue KYOCERA HS-3 Page 4
QuantityDescriptionPart CodeRef No.
1SHEET TRANSFER5MVS862KN00202-025
2SHEET A5MVS421KN00202-026
1SPACER BOX5MVS217SF00102-027
1FRAME ELEVATOR R5MMX876SL02003-001
1FRAME ELEVATOR L5MMX876SL00703-002
1FRAME STACK5MMS886SL00703-003
1SHAFT FOOT5MMT865SN00203-004
2FOOT5MVX643SW00203-005
1SHAFT ELEVATOR5MMT866SN01803-006
1METAL BUSH KD5MMM176CJ00303-007
2BUSH POW5MVM122DB00303-008
4PULLEY XL145MVG318DN00103-009
1TRAY ELEVATOR5MVB882SW00303-010
1GUIDE ELEVATOR R5MVX665DN00103-011
1GUIDE ELEVATOR L5MVX665DN00203-012
2BELT XL280 9.65MVM190RB01603-013
1GEAR WHEEL H305MVG138DN01803-014
1GEAR MOTOR5MVG127DN03103-015
1BKT SENSOR BOTTLE5MVX532DN00103-016
1PAN HEAD RIVET5MBRP3045QNB03-017
1MICRO SWITCH5ESM010235***0103-018
2LOCKING CARD SPACER5MVX211NN01903-019
1SHAFT STAY5MMT865SN00403-020
1PAPER SIZE R ASSY5AAYHS3***1403-021
1PAPER SIZE L ASSY5AAYHS3***1503-022
1PT. SENSOR ASSY5AAXPS022GEA03-024
1BKT WORM5MMU654SL00103-025
1PLATE WORM5MMS336SL00803-026
1GEAR WORM5MVG117DN00103-027
2BUSH POW5MVM122DB00303-028
1GEAR CLUTCH Z225MVG137DB02403-029
1ELEV MOTOR ASSY5AAYHS3***0103-030
1BKT DC MOTOR5MML654SL00203-031
1GUIDE CHANGE5MVX832CB00603-032
1SPRING GUIDE5MMW162LJ01103-033
2PIN STUD5MMT263SZ01603-034
1DISCHARGER HS5MVS824XF00103-035
2SEAL TRAY5MVS643KN00103-036
1PWB ASSY5AAPRIFC2004AHKP395B
1PWB ASSY5AAPRDVC2004AHKP396B
1PWB ASSY5AAPRSSC2002AHKP398B
PRINTER OPTIONS - Parts Catalogue KYOCERA HS-3 Page 5
