Krom Khensu User Manual

QuickGuide Installation

FEATURES

EN

1) Left joystick / push switch

2) Directional pad

3) Turbo mode button

4) Right joystick / push switch

5) Action buttons

6) Right trigger

7) Right button

8) Start button

9) Mini USB port

10) Mode button

11) Back button

12) Left trigger

13) Left button

14) Reset button

13 7

10

11 8

1

3

2

6 12

4

9

14

5

INSTALLATION

1) Plug Krom Khensu’s receiver into one of your device’s USB ports.

2) Turn on your device.

3) Press MODE button during 15 seconds, the 4 LEDs will rapidly flash.

4) When one of the four LEDs stays lit, the gamepad is paired successfully.

CONFIGURATION MODES (X-INPUT / D-INPUT

1) Default mode is X-input (LED under TURBO button is off and 1ST LED is lit)

2) To turn it to D-input mode: Hold the MODE button for 5 seconds, LED under TURBO button

will turn on.
Be sure to set the game controller to the correct mode before starting the game. If you
switch during game play it could lead to the game not identifying the controller. If this
happens, restart the game.

FUNCTIONS
¬ The controller switch to sleep mode after 5 minutes in standby.

Press MODE button to switch from standby to working mode.

¬ When the battery controller is low, LED indicator will flash, you should connect

the USB cable to continue enjoying your game.

¬ To change the function between the left joystick and D-pad, press MODE button:

1ST LED will turn off and the change will take place.

¬ TURBO SETTING: Hold down the button which you want to set into turbo mode, then press

TURBO key one time. Turbo function is now set. Hold the key which you have set as turbo
function, then press TURBO button to clear the turbo mode.

¬ RESET: To return to the factory settings, press the RESET button located on the back of

the gamepad.

)

CHARGING THE BATTERY

Plug the cable into a free USB port on your device. The gamepad’s LED ring will flash during
charging, which can take up to 3 hours. When the gamepad is completely charged the
gamepad’s LED ring will stay lit. Be aware that the first charge may take a little longer.

EU DIRECTIVES

¬ STATEMENT OF COMPLIANCE WITH EUROPEAN UNION DIRECTIVES

Krom declares that this product is in compliance with the essential requirements and
other relevant provisions from the following Directives: 1999/5/EC; 2004/108/EC;
2011/65/EC, as applicable. The technical documentation required by the Conformity
Evaluation process is in Krom´s possession and can be requested through
[e-mail].

¬ DISPOSAL OF BATTERIES AND ELECTRICAL OR ELECTRONIC EQUIPMENT WASTE

The existence of this symbol on the product, batteries or respective packaging, signifies
that this product and the contained batteries can not be disposed as domestic waste.
It is the user´s responsibility to deliver this product at a batteries, electrical or electronic
recycling pick-up point. The pick-up and separate recycling contributes for the
preservation of natural resources and suppresses potential negative consequences for
the human health and the environment resultant of inadequate disposal of dangerous
substances contained in batteries and electrical or electronic equipment. For additional
information regarding batteries, electrical or electronic recycling pick-up points, please
contact your local municipal services.
