KRAMER ELECTRONIC S LTD.
USER MANUAL
MODEL:
VS-8 1HDx l
8x1 HD/SD‑ SDI S witcher
P/N: 2900-000418 Rev 4
VS-81HDxl – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Defining the VS-81HDxl 8x1 HD/SD‑SDI Switcher 5
3.2 Using the IR Transmitter 8
4 Installing in a Rack 9
5 Connecting the VS-81HDxl 10
5.1 DIP-Switch Settings 11
5.2 Connecting to the VS-81HDxl via RS-232 12
5.3 Connecting a PC or Controller to the RS-485 Port 13
5.4 Switching Genlocked Video Signals 14
5.5 Operating via Ethernet 14
5.6 Controlling via the REMOTE Connector 19
6 Operating the VS-81HDxl 20
6.1 Locking the Front Panel 20
7 Technical Specifications 21
8 Protocol 2000 22
8.1 Syntax 22
8.2 Instruction Codes 23
Figures
Figure 1: VS-81HDxl 8x1 HD/SD‑SDI Switcher Front Panel 6
Figure 2: VS-81HDxl 8x1 HD/SD‑SDI Switcher Rear Panel 7
Figure 3: Connecting the VS-81HDxl 8x1 HD/SD‑SDI Switcher 11
Figure 4: VS-81HDxl MACHINE ID DIP-switches 11
Figure 5: Crossed Cable RS-232 Connection 12
Figure 6: Straight Cable RS-232 Connection with a Null Modem Adapter 13
Figure 7: Local Area Connection Properties Window 16
Figure 8: Internet Protocol Version 4 Properties Window 17
Figure 9: Internet Protocol Version 6 Properties Window 17
Figure 10: Internet Protocol Properties Window 18
Figure 11: Using the REMOTE Connector 19
VS-81HDxl - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer VS-81HDxl 8x1 HD/SD‑SDI Switcher,
which is ideal for the following typical applications:
Professional broadcasting and production studios
Post production
2
VS-81HDxl - Getting Started
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VS-81HDxl away from moisture, excessive sunlight
and dust
VS-81HDxl - Getting Started
3
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the power cord that is supplied with the unit
Warning:
Do not open the unit. High voltages can cause
electrical shock! Servicing by qualified personnel only
Warning:
Disconnect the power and unplug the unit from the wall
before installing
!
2.2 Safety Instructions
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
4
VS-81HDxl - Overview
3 Overview
The Kramer VS-81HDxl is a true 8x1 switcher for SD/HD/3G HD-SDI signals that
lets you switch any one of the eight inputs to two identical outputs.
The VS-81HDxl features:
A maximum data rate of 3Gbps
HDTV compatibility
Multi-standard operation: SDI (SMPTE 259M/344M) & HD−SDI (SMPTE
292M) & 3G HD−SDI (SMPTE 424M)
Kramer Equalization & re-Klocking™ Technology that rebuilds the digital
signal to travel longer distances
Cable equalization of up to 350m for SD signals, 140m for 1.5GHz HD
signals, and 120m for 3GHz HD signals
Standard Definition (SD) means an NTSC or PAL compatible video format, consisting of
480 (for NTSC) or 576 (for PAL) lines of interlaced video.
High Definition (HD) means a video format, consisting of 720 active lines of progressive
video or 1080 lines of progressive or interlaced video.
Active Input Indication™ reporting where each input button on the front
panel automatically lights up when the unit detects a video signal on that
input. Green indicates a standard definition (SDI) input signal and blue
indicates a high definition (HD−SDI) input signal
ANC data support (embedded audio, Teletext, time code and so on)
Bi−level, tri−level analog sync
Front panel control lockout
Output disconnect
SMPTE RP−168 vertical interval switching
A 100−240V AC worldwide power supply
Standard 19” rack mount size - 1U, rack “ears” included
VS-81HDxl - Overview
5
The VS-81HDxl can be controlled via the:
Front panel buttons
Infrared remote control transmitter
Infrared remote extension cable transmitter
Remotely, by RS-232 or RS-485 serial commands transmitted by a touch
screen system, PC, or other serial controller
Ethernet
Remote contact closure for forced operation
3.1 Defining the VS-81HDxl 8x1 HD/SD‑SDI Switcher
This section defines the VS-81HDxl.
6
VS-81HDxl - Overview
#
Feature
Function
1
IR Receiver
The red LED is illuminated when receiving signals from the infrared remote control transmitter
2
POWER Switch
Illuminated switch for turning the unit ON or OFF
3
OFF Button
Press to disconnect the outputs
4
INPUT SELECTOR Buttons
Select the input to switch to the output (from 1 to 8)
Use to set the resolution when switching genlocked video signals (see Section 5.4)
5
PANEL LOCK Button
Disengages the front panel buttons
6
VS-81HD – Overview
Figure 1: VS-81HDxl 8x1 HD/SD‑SDI Switcher Front Panel
VS-81HDxl - Overview
7
VS-81HD – Overview
7
#
Feature
Function
6
GENLOCK IN BNC Connector
Connect to the genlock source
7
GENLOCK TERM Button
Press to terminate the genlock source (75) or release for looping to another unit
8
GENLOCK LOOP BNC Connector
Connect to the GENLOCK connector of the next unit in the line
9
INPUTS BNC Connectors
Connect to the serial digital video sources (from 1 to 8)
10
OUTPUTS SDI BNC Connectors
Connect the two identical SDI outputs to serial digital video acceptors (1 and 2)
11
RS-485 Detachable Terminal Block Port
PIN G is for the ground connection; PINs B (-) and A (+) are for RS-485
12
RS-232 9-pin D-sub Port
Connects to the PC or the Remote Controller via a null-modem
13
REMOTE Terminal Block Connector
Connect to contact closure switches (see Section 5.5)
14
MACHINE ID DIP-switches
DIP-switches for setting the machine ID number
15
REMOTE IR Opening
Connects to an optional external IR receiver unit for controlling the machine via an IR
remote controller (instead of using the front panel IR receiver)
16
ETH RESET Button
Press to reset to factory default definitions:
First disconnect the power cord and then connect it again while pressing the ETH Factory
Reset button. The unit will power up and load its memory with the factory default definitions
IP number 192.168.1.39
Mask – 255.255.255.0
Gateway – 192.168.1.1
17
ETHERNET Connector
Connects to the PC or other Serial Controller through computer networking
18
Power Connector with Fuse
AC connector enabling power supply to the unit
Figure 2: VS-81HDxl 8x1 HD/SD‑SDI Switcher Rear Panel
8
VS-81HDxl - Overview
3.2 Using the IR Transmitter
You can use the RC-IR3 IR transmitter to control the machine via the built-in IR
receiver on the front panel or, instead, via an optional external IR receiver (Model:
C-A35M/IRR-50). The external IR receiver can be located up to 15m (50ft) away
from the machine. This distance can be extended to up to 60m (200ft) when used
with three extension cables (Model: C-A35M/A35F-50).
Before using the external IR receiver, be sure to arrange for your Kramer dealer to
insert the internal IR connection cable (P/N: 505-70434010-S) with the 3.5mm
connector that fits into the REMOTE IR opening on the rear panel. Connect the
external IR receiver to the REMOTE IR 3.5mm connector.
VS-81HDxl - Installing in a Rack
9
4 Installing in a Rack
This section provides instructions for rack mounting the unit.
10
VS-81HDxl - Connecting the VS-81HDxl
Always switch off the power to each device before connecting it to your
VS-81HDxl. After connecting your VS-81HDxl, connect its power and
then switch on the power to each device.
i
5 Connecting the VS-81HDxl
You can use your VS-81HDxl to switch one of the eight HD/SD SDI inputs to the
two identical HD/SD SDI outputs, as the example illustrated in Figure 3 shows.
To connect the VS-81HDxl as illustrated in the example in Figure 3:
1. Connect up to eight SDI sources to the INPUTS BNC connectors, for
example an:
HD/SD SDI camera to INPUT 1
HD/SD SDI camera to INPUT 2
HD/SD SDI camera to INPUT 7
SDI VTR to INPUT 8
2. Connect the SDI OUTPUT BNC connectors to up to two SDI acceptors (for
example, two HD/SD SDI displays).
3. Set the DIP-switches (see Section 5.1).
4. As an option (not illustrated in Figure 3), you can connect:
A genlock source to the GENLOCK IN BNC connector
The LOOP BNC connector to the GENLOCK connector of the next unit
in the line, and release the TERM button for looping
Push in to terminate the input. Release when the input extends to another unit.
5. If required, connect a PC and/or controller to the:
RS-232 port (see Section 5.2), and/or
RS-485 port (see Section 5.3), and/or
ETHERNET connector (see Section 5.5)
VS-81HDxl - Connecting the VS-81HDxl
11
ON
1 2 3 4
6. If required, connect a remote contact closure switch (see Section 5.5).
7. Connect the power cord.
Figure 3: Connecting the VS-81HDxl 8x1 HD/SD‑SDI Switcher
5.1 DIP-Switch Settings
By default, all the DIP-switches are set to OFF.
Figure 4 illustrates the VS-81HDxl DIP-switches:
Figure 4: VS-81HDxl MACHINE ID DIP-switches
12
VS-81HDxl - Connecting the VS-81HDxl
Mach.
#
DIP 1
DIP 2
DIP 3
DIP 4
Mach. #
DIP 1
DIP 2
DIP 3
DIP 4
1
OFF
OFF
OFF
OFF 9
OFF
OFF
OFF
ON 2 ON
OFF
OFF
OFF 10
ON
OFF
OFF
ON 3 OFF
ON
OFF
OFF 11
OFF
ON
OFF
ON 4 ON
ON
OFF
OFF 12
ON
ON
OFF
ON 5 OFF
OFF
ON
OFF 13
OFF
OFF
ON
ON 6 ON
OFF
ON
OFF 14
ON
OFF
ON
ON
7
OFF
ON
ON
OFF 15
OFF
ON
ON
ON
8
ON
ON
ON
OFF 16
ON
ON
ON
ON
1
2
6
3
7
4
8
5
9
1
2
6
3
7
4
8
5
9
PC
5.1.1 Setting the Machine ID DIP-switches
The MACHINE ID determines the position of a VS-81HDxl unit, specifying which
VS-81HDxl unit is being controlled when several VS-81HDxl units connect to a PC
or serial controller. Set the Machine number on a VS-81HDxl unit via MACHINE ID
DIPs 1, 2, 3 and 4, according to the following table.
When using a standalone VS-81HDxl unit, set the Machine ID to 1. When
connecting more than one VS-81HDxl unit, set the first machine (the Master) that
is closest to the PC, as Machine ID 1 (the DIP-switches are set to OFF).
5.2 Connecting to the VS-81HDxl via RS-232
You can connect to the unit via a crossed RS-232 connection, using for example,
a PC. A crossed cable or null-modem is required as shown in method A and B
respectively. If a shielded cable is used, connect the shield to pin 5.
Method A (Figure 5)—Connect the RS-232 9-pin D-sub port on the unit via a
crossed cable (only pin 2 to pin 3, pin 3 to pin 2, and pin 5 to pin 5 need be
connected) to the RS-232 9-pin D-sub port on the PC.
Note: There is no need to connect any other pins.
Figure 5: Crossed Cable RS-232 Connection
VS-81HDxl - Connecting the VS-81HDxl
13
1
2
6
3
7
4
8
5
9
to PC
Null-Modem
Adapter
Hardware flow control is not required for this unit. In the rare case where a
controller requires hardware flow control, short pin 1 to 7 and 8, and pin 4 to 6 on
the controller side.
Method B (Figure 6)—Connect the RS-232 9-pin D-sub port on the unit via a
straight (flat) cable to the null-modem adapter, and connect the null-modem
adapter to the RS-232 9-pin D-sub port on the PC. The straight cable usually
contains all nine wires for a full connection of the D-sub connector. Because the
null-modem adapter (which already includes the flow control jumpering described
in Method A above) only requires pins 2, 3 and 5 to be connected, you are free to
decide whether to connect only these 3 pins or all 9 pins.
Figure 6: Straight Cable RS-232 Connection with a Null Modem Adapter
5.3 Connecting a PC or Controller to the RS-485 Port
You can operate the VS-81HDxl via the RS-485 port from a distance of up to
1200m (3900ft) using any device equipped with an RS-485 port (for example, a
PC). For successful communication, you must set the RS-485 machine number
and bus termination.
To connect a device with a RS-485 port to the VS-81HDxl:
Connect the A (+) pin on the RS-485 port of the PC to the A (+) pin on the
RS-485 port on the rear panel of the VS-81HDxl
Connect the B (–) pin on the RS-485 port of the PC to the B (–) pin on the
RS-485 port on the rear panel of the VS-81HDxl
Connect the G pin on the RS-485 port of the PC to the G pin on the RS-485
port on the rear panel of the VS-81HDxl
14
VS-81HDxl - Connecting the VS-81HDxl
5.4 Switching Genlocked Video Signals
The genlock feature lets you switch genlocked video signals according to timing of
the GENLOCK reference input.
According to SMPTE RP-168. The sources must be genlocked to the GENLOCK input in order
to switch cleanly.
Connect the GENLOCK cable.
If the HD or SD input signal (the unit detects automatically when SD-SDI inputs
are used) that is connected is one of the following, it is necessary to set it up as
follows:
1080i@60Hz: press and hold INPUT 1 button for 3 seconds. The button
flashes to indicate that the set up was completed
1080i@50Hz or 720p@50Hz: press and hold INPUT 2 button for 3 seconds
The button flashes to indicate that the set up was completed
720p@60Hz: press and hold INPUT 3 button for 3 seconds.
The button flashes to indicate that the set up was completed
NTSC: press and hold INPUT 7 button for 3 seconds.
The button flashes to indicate that the set up was completed
PAL: press and hold INPUT 8 button for 3 seconds.
The button flashes to indicate that the set up was completed
If a change is made to the resolution or refresh rate. The button does not flash if the
new timing is the same as that previously selected.
This feature is available in the devices upgraded to the latest firmware version 1.9 or
higher. Contact your Kramer dealer for details.
When turning the machine ON, the appropriate button will flash to indicate the
latest setup (last setup is saved).
5.5 Operating via Ethernet
You can connect to the VS-81HDxl via Ethernet using either of the following
methods:
Directly to the PC using a crossover cable (see Section 5.5.1)
Via a network hub, switch, or router, using a straight-through cable (see
Section 5.5.2)
VS-81HDxl - Connecting the VS-81HDxl
15
This type of connection is recommended for identifying the VS-81HDxl
with the factory configured default IP address.
i
Note: If you want to connect via a router and your IT system is based on IPv6,
speak to your IT department for specific installation instructions.
5.5.1 Connecting the Ethernet Port Directly to a PC
You can connect the Ethernet port of the VS-81HDxl directly to the Ethernet port
on your PC using a crossover cable with RJ-45 connectors.
After connecting the VS-81HDxl to the Ethernet port, configure your PC as follows:
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
3. Highlight the network adapter you want to use to connect to the device and
click Change settings of this connection.
The Local Area Connection Properties window for the selected network
adapter appears as shown in Figure 7.
16
VS-81HDxl - Connecting the VS-81HDxl
Figure 7: Local Area Connection Properties Window
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet
Protocol Version 4 (TCP/IPv4) depending on the requirements of your IT
system.
5. Click Properties.
The Internet Protocol Properties window relevant to your IT system appears
as shown in Figure 8 or Figure 9.
VS-81HDxl - Connecting the VS-81HDxl
17
Figure 8: Internet Protocol Version 4 Properties Window
Figure 9: Internet Protocol Version 6 Properties Window
18
VS-81HDxl - Connecting the VS-81HDxl
6. Select Use the following IP Address for static IP addressing and fill in the
details as shown in Figure 10.
For TCP/IPv4 you can use any IP address in the range 192.168.1.1 to
192.168.1.255 (excluding 192.168.1.39) that is provided by your IT
department.
Figure 10: Internet Protocol Properties Window
7. Click OK.
8. Click Close.
5.5.2 Connecting the Ethernet Port via a Network Hub or Switch
You can connect the Ethernet port of the VS-81HDxl to the Ethernet port on a
network hub or using a straight-through cable with RJ-45 connectors.
5.5.3 Control Configuration via the Ethernet Port
To control several units via Ethernet, connect the Master unit (Device 1) via the
Ethernet port to the Ethernet port of your PC. Use your PC provide initial
configuration of the settings (see Section 5.5).
VS-81HDxl - Connecting the VS-81HDxl
19
DO NOT connect more than one PIN to the GND PIN at the same
time.
!
5.6 Controlling via the REMOTE Connector
The contact closure remote control pins operate in a similar way to the input
selector button. Using the contact closure remote control lets you route an input to
the outputs by remote control. To do so, temporarily connect the required input
(from 1 to 8) pin on the REMOTE terminal block connector to the GND (ground) pin.
You can also disconnect the outputs by temporarily connecting the OFF pin to the GND
pin.
For example, to route input 5 to the outputs, as the example in Figure 11 illustrates,
momentarily touch input # 5 to the GND (ground) pin.
Figure 11: Using the REMOTE Connector
20
VS-81HDxl - Operating the VS-81HDxl
6 Operating the VS-81HDxl
You can operate your VS-81HDxl via:
The front panel buttons
RS-232/RS-485 serial commands transmitted by a PC, touch screen system,
or other serial controller
The Kramer infrared remote control transmitter
Infrared remote extension cable transmitter
The Ethernet
To switch an input to the outputs via the front panel buttons, press the desired
input button. (For details of how to route an input to an output using the REMOTE
connector, see Section 5.5).
When selecting an input that is not connected, that input button blinks.
6.1 Locking the Front Panel
To prevent changing the settings accidentally or tampering with the unit via the
front panel buttons, lock your VS-81HDxl. Unlocking releases the protection
mechanism.
Nevertheless, even though the front panel is locked you can still operate via RS-232 or
RS-485, as well as via the Kramer IR Remote Control Transmitter.
To lock the VS-81HDxl:
Press the LOCK button for three seconds, until the LOCK button is
illuminated
The front panel is locked. Pressing a button will have no effect
To unlock the VS-81HDxl:
Press the illuminated LOCK button until the LOCK button is no longer
illuminated
The front panel unlocks
VS-81HDxl - Technical Specifications
21
INPUTS:
8 SDI SMPTE-259M, 292M, 344M, 424M serial video,
75 on BNC connectors
1 GENLOCK 75 / Hi-Z on looping BNC connectors,
bi-level, Tri-level inputs
OUTPUTS:
2 identical equalized and reclocked SMPTE-259M, 292M,
344M, 424M outputs 75 on BNC connectors
1 GENLOCK 75 / Hi-Z on looping BNC connectors,
bi-level, Tri-level inputs
MAX. OUTPUT LEVEL:
800mVpp /75
JITTER:
Better than 0.2UI
DATA RATE:
Up to 2.97Gbps
CONTROLS:
Front-panel, RS-232; RS-485, Ethernet, infrared remote,
dry contact, and panel lock
POWER CONSUMPTION:
Universal, 100-240VAC, 50/60Hz 22VA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
19” x 7” x 1U (W, D, H) rack mountable
WEIGHT:
1.5kg (3.3lbs) approx.
INCLUDED ACCESSORIES:
Power cord, null-modem adapter, external remote IR
receiver cable P/N: C-A35M/IRR-50
Specifications are subject to change without notice at http://www.kramerelectronics.com
7 Technical Specifications
22
VS-81HDxl - Protocol 2000
MSB
LSB
1st Byte
DESTINATION
INSTRUCTION
0 D N5
N4
N3
N2
N1
N0 7 6 5 4 3 2 1 0
2nd Byte
INPUT
1
I6
I5
I4
I3
I2
I1
I0 7 6 5 4 3 2 1 0
3rd Byte
OUTPUT
1
O6
O5
O4
O3
O2
O1
O0 7 6 5 4 3 2 1 0
4th Byte
MACHINE NUMBER
1
OVR X M4
M3
M2
M1
M0 7 6 5 4 3 2 1 0
8 Protocol 2000
This RS-232/RS-485 communication protocol uses four bytes of information as
defined below.
For RS-232, a null-modem connection between the machine and controller is
used. The default data rate is 9600 baud, with no parity, 8 data bits and 1 stop bit.
8.1 Syntax
1st Byte: Bit 7 – Defined as 0
The 6-bit INSTRUCTION defines the function performed by the switcher(s). If a function is performed using the
machine’s keyboard, these bits are set with the INSTRUCTION NO. performed. The instruction codes are defined
according to the table below (INSTRUCTION NO. is the value set in N5…N0).
2nd Byte: Bit 7 – Defined as 1
I6…I0 – INPUT
When switching (i.e. instruction codes 1 and 2), the 7-bit INPUT is set as the input number to be switched. If switching is
done using the machine’s front panel, these bits are set with the INPUT NUMBER switched. For other operations, these
bits are defined according to the table.
3rd Byte: Bit 7 – Defined as 1
O6…O0 – OUTPUT
When switching (i.e. instruction codes 1 and 2), the 7-bit OUTPUT is set as the output number to be switched. If
switching is done using the machine’s front panel, these bits are set with the OUTPUT NUMBER switched. For other
operations, these bits are defined according to the table.
4th Byte: Bit 7 – Defined as 1
Bit 5 – Don’t care
OVR – Machine number override
M4…M0 – MACHINE NUMBER
This byte is used to address machines in a system by their machine numbers. When several machines are controlled
from a single serial port, they are usually configured together and each machine has an individual machine number. If
the OVR bit is set, then all machine numbers accept (implement) the command and the addressed machine replies.
When a single machine is controlled over the serial port, always set M4…M0 to 1, and make sure that the machine itself
is configured as MACHINE NUMBER = 1.
D – DESTINATION:
N5…N0 – INSTRUCTION
0 – Sends information to the switchers (from the PC)
1 – Sends information to the PC (from the switcher)
VS-81HDxl - Protocol 2000
23
Instruction Codes for Protocol 2000
Instruction
Definition for Specific Instruction
Notes # Description
Input
Output
0
RESET VIDEO
0 0 1
1
SWITCH VIDEO
Set equal to video input that is
switched
(0 = disconnect)
Set equal to video output that is
switched
(0 = to all the outputs)
2, 15
5
REQUEST STATUS OF
A VIDEO OUTPUT
Set as SETUP #
Equal to output number whose
status is required
4, 3
16
ERROR / BUSY
For invalid / valid input (i.e.
OUTPUT byte = 4 or OUTPUT byte
= 5),
this byte is set as the input #;
For invalid / valid output (i.e.
OUTPUT byte=7 or OUTPUT
byte=8), this byte is set as the
output#
0 – Error
1 – Invalid instruction
2 – Out of range
3 – Machine busy
4 – Invalid input
5 – Valid input
6 – RX buffer overflow
7 – Invalid output
8 – Valid output
9 – Valid EDID
9, 25
30
LOCK FRONT PANEL
Unlock panel
Lock panel
0
2
31
REQUEST WHETHER
PANEL IS LOCKED
0 0 16
61
IDENTIFY MACHINE
1 – Video machine name
2 – Audio machine name
3 – Video software version
4 – Audio software version
5 – RS-422 controller name
6 – RS-422 controller version
7 – Remote control name
8 – Remote software version
9 – Protocol 2000 revision
10 – Control data machine name
11 – Control data software version
For names:
0 – Request first 4 digits
1 – Request first suffix
2 – Request second suffix
3 – Request third suffix
10 – Request first prefix
11 – Request second prefix
12 – Request third prefix
For versions:
0 – main board
or the number of external board
13
62
DEFINE MACHINE
1 – Number of inputs
2 – Number of outputs
3 – Number of setups
1 – For video
2 – For audio
3 – For SDI
4 – For remote panel
5 – For RS-422 controller
6 – For control data
14
8.2 Instruction Codes
All the values in the table are decimal, unless otherwise stated
NOTES on the above table:
NOTE 1 – When the master switcher is reset, (e.g. when it is turned on), the reset code is sent to the PC. If this code is
sent to a switcher, it resets according to the present power-down settings.
NOTE 2 – These are bi-directional definitions. If the switcher receives the code, it performs the instruction. If the
instruction is performed (due to a keystroke operation on the front panel), then these codes are sent.
For example, if the PC sends HEX code:
01 85 88 83
then the switcher (machine 3) switches input 5 to output 8.
If the user switches input 1 to output 7 using the front panel buttons, the switcher sends HEX code:
41 81 87 83
to the PC.
When the PC sends one of the commands in this group to the switcher, if the instruction is valid, the switcher replies by
sending the same four bytes to the PC that it received (except for the first byte, where the DESTINATION bit is set high).
NOTE 3 – SETUP # 0 is the present setting. SETUP # 1 and higher are the settings saved in the switcher's memory,
(i.e. those used for Store and Recall).
NOTE 4 – The reply to a REQUEST instruction is as follows: the same instruction and INPUT codes that were sent are
returned, and the OUTPUT is assigned the value of the requested parameter. The replies to instructions 10 and 11 are
according to the definitions in instructions 7 and 8 respectively.
For example, if the present status of machine number 5 is breakaway setting, then the reply to HEX code:
0B 80 80 85
is HEX code:
4B 80 81 85
24
VS-81HDxl - Protocol 2000
NOTE 13 – This is a request to identify the switcher/s in the system. If the OUTPUT is set as 0, and the INPUT is set as
1, 2, 5 or 7, the machine sends its name. The reply is the decimal value of the INPUT and OUTPUT.
For example, for a 2216, the reply to the request to send the audio machine name is HEX code:
7D 96 90 81 (i.e. 128
If the request for identification is sent with the INPUT set as 3 or 4, the appropriate machine sends its software version
number. Again, the reply would be the decimal value of the INPUT and OUTPUT - the INPUT representing the number
in front of the decimal point, and the OUTPUT representing the number after it.
For example, for version 3.5, the reply to the request to send the version number would be HEX code:
7D 83 85 81 (i.e. 128
If the OUTPUT is set as 1, then the ASCII coding of the lettering following the machine’s name is sent.
For example, for the VS-7588YC, the reply to the request to send the first suffix would be HEX code:
7D D9 C3 81 (i.e. 128
NOTE 14 – The number of inputs and outputs refers to the specific machine being addressed, not to the system.
For example, if six 16x16 matrices are configured to make a 48x32 system (48 inputs, 32 outputs), the reply to the HEX
code:
3E 82 81 82 (i.e. request the number of outputs)
would be HEX code:
7E 82 90 82 (i.e. 16 outputs).
NOTE 15 – When the OVR bit (4th byte) is set, then the video commands have universal meaning.
For example, instruction 1 (SWITCH VIDEO) causes all units (including audio, data, etc.) to switch. Similarly, if a
machine is in FOLLOW mode, it performs any video instruction.
NOTE 25 – For units that detect the validity of the video inputs, instruction 16 is sent whenever the unit detects a change
in the state of an input (in real-time).
For example, if input 3 is detected as invalid, the unit sends HEX code:
10 83 84 81
If input 7 is detected as valid, then the unit sends HEX code:
10 87 85 81.
+ 22
for 2nd byte, and 128
dec
dec
+ 3
for 2nd byte, 128
dec
dec
+ ASCII for “Y”; 128
dec
+ 16
dec
+ 5
for 3rd byte).
dec
dec
+ ASCII for “C”).
dec
for 3rd byte).
dec
For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: info@kramerel.com
P/N:
2900-000418
Rev:
4
!
SAFETY WARNIN G
Disconnect the unit from the power
supply before opening and servicing
Loading...
