Kramer Electronics VP-501N User Manual
KRAMER ELECTRONIC S LTD.
USER MANUAL
MODEL:
VP-5 01 N
UXGA Scan Converter
P/N: 2900-300183 Rev 5
VP-501N – Contents
i
Contents
1 Introduction 1
2 Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3 Overview 4
3.1 Defining the VP-501N UXGA Scan Converter 5
3.2 Input Resolutions 6
4 Connecting the VP-501N UXGA Scan Converter 7
5 Operating the VP-501N UXGA Scan Converter 9
5.1 Using the Quick-Set Buttons 9
5.2 Adjusting the Display via the Menu Buttons 10
5.3 Using the Menu 11
5.4 Using the Test Patterns 11
5.5 Saving and Recalling 12
5.6 Setting the DIP-Switches 13
6 Technical Specifications 14
Figures
Figure 1: VP-501N UXGA Scan Converter 5
Figure 2: Connecting a Computer Graphics Source to the VP-501N 8
Figure 3: Connecting a High-Definition Source to the VP-501N 8
Figure 4: Over-scanned and Under-scanned images 10
Figure 5: Test Pattern Example 12
Figure 6: VP-501N DIP-Switches 13
VP-501N - Introduction
1
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Video Products.
Congratulations on purchasing your Kramer TOOLS® VP-501N UXGA Scan
Converter. The VP-501N is ideal for:
Multimedia, board rooms, and video-conferencing
Any application where high-quality conversion of graphical data signals to
video signals is required
2
VP-501N - Getting Started
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VP-501N away from moisture, excessive sunlight and
dust
VP-501N - Getting Started
3
3
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
!
2.2 Safety Instructions
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
