VS-3232DN VGA & Analog Audio Card Installation Sheet
2900- 300402
5
The VS-3232DN VGA and Analog Audio card mounts in one of the 16 slots on the rear of
the VS-3232DN chassis. Slots are numbered from left to right. Audio output is accessed by
connecting the four supplied Kramer C-GF/GMAF-30 cables to each VGA port.
WARNING: An input card must only be mounted in a slot designated for input cards (slots
1 to 4 and 9 to 12) and an output card must only be mounted in a slot designated for
output cards (slots 5 to 8 and 13 to 16).
P
O
To install an I/O card:
1. Power off the VS-3232DN and all devices
connected to it.
2. Using a Phillips screwdriver, loosen the
screws at the top and bottom of the
blanking plate.
3. Remove the blanking plate from the slot
and store it for possible future use.
4. Remove the new card from its shipping box
and anti-ESD bag.
WE
R
C
TR
L
D
VI
DV
I
DV
I
DV
I
DV
I
DVI
DV
I
D
VI
D
VI
D
V
I
D
V
I
D
V
P
O
W
E
R
C
T
R
L
I
N
1~4
I
N
5~8
I
N
9~12
I
N
13~16
OU
T
1~4
OU
T
5~8
OU
T
9~12
I
N
OU
13~16
I
D
V
I
DV
I
DVI
T
I
N
17~20
I
N
21~24
I
N
25~28
I
N
29~32
O
U
17~20
T
PATTERN RESOLUTION
O
U
21~24
T
O
U
25~28
T
OU
29~32
T
T
E
S
T
P
C
-
A
5. Holding the card by the upper and lower
handles, align the card with the plastic guide
rails.
6. Slide the card into the chassis until the front of
the card makes contact with the connector
I
N
inside the chassis.
7. Press the card firmly into the slot until the
connector is fully seated and the connector
plate is flush with the rear panel of the chassis.
8. Using a Phillips screwdriver, tighten the
retaining screws at the top and bottom of the
card to secure it to the chassis.
P
C-
A
Kramer Electronics Ltd.
9. Power on the VS-3232DN and follow the
procedure in the
VS-3232DN User Manual (see Section 9) to
configure the new card.
10. Power on the peripheral devices.
VS-3232DN VGA & Analog Audio Card Installation Sheet
( )P/N: 2900-300402 REV 5
