Kramer VA-1VGAN User manual
Kramer Electronics, Ltd.
Preliminary
USER MANUAL
Model:
VA-1VGAN
EDID Capture
Introduction
Contents
1
Introduction 1
2
Getting Started 1
2.1 Quick Start 2
3
Overview 3
3.1 Defining EDID 4
4
Your VA-1VGAN EDID Capture 4
5
Connecting the VA-1VGAN EDID Capture 5
5.1 Acquiring the EDID 5
5.2 Reconnecting the Projector 6
6
Technical Specifications 7
Figures
Figure 1: VA-1VGAN EDID Capture 4
Figure 2: VA-1VGAN – Acquiring the EDID from the Display Device 6
Figure 3: Connecting the VA-1VGAN EDID Capture 7
Tables
Table 1: VA-1VGAN EDID Capture Functions 4
Table 2: VA-1VGAN EDID Capture Technical Specifications 7
i
Introduction
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1 that are clearly
defined by function.
Thank you for purchasing the Kramer PicoTOOLS™ VA-1VGAN EDID
Capture, which is ideal for:
Distributing presentation graphics
Using a display at a distance from the computer
Using in graphics production studios
Each package includes the following items:
The VA-1VGAN EDID Capture
This user manual2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high-resolution cables3. Be sure
that the VGA cable passes the signals on pins 12 and 15
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com
1
Getting Started
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
2
