Kramer Electronics, Ltd.
USER MANUAL
Models:
TR-1YC,
s-Video Isolation Transformer
TR-2YC,
s-Video Dual Isolation Transformers
Contents
i
Contents
1
Introduction 1
2
Getting Started 1
2.1
Quick Start 1
3
Overview 3
4
Your Isolation Transformers 4
5
Using the Isolation Transformer 7
5.1
Connecting the Isolation Transformer 7
6
Technical Specifications 8
Figures
Figure 1: TR-1YC s-Video Isolation Transformer 4
Figure 2: TR-2YC s-Video Dual Isolation Transformers 5
Figure 3: The s-Video Isolation Transformers Underside 6
Figure 4: Dipswitch Definitions 6
Figure 5: Connecting the TR-2YC s-Video Dual Isolation Transformers 8
Tables
Table 1: Features and Functions of the TR-1YC s-Video Isolation Transformer 4
Table 2: Features and Functions of the TR-2YC s-Video Dual Isolation Transformers 5
Table 3: Features and Functions of the s-Video Isolation Transformers Underside 6
Table 4: Technical Specifications of the TR-1YC and TR-2YC 8
Introduction
1
1 Introduction
Welcome to Kramer Electronics (since 1981): a world of unique, creative and
affordable solutions to the infinite range of problems that confront the video, audio
and presentation professional on a daily basis. In recent years, we have redesigned
and upgraded most of our line, making the best even better! Our 500-plus different
models now appear in 8 Groups1, which are clearly defined by function.
Congratulations on purchasing your Kramer TR-1YC s-Video Isolation
Transformer and/or TR-2YC s-Video Dual Isolation Transformers.
This product is ideal for:
Broadcast and production video studios
Staging and fieldwork
The package includes the following items:
TR-1YC or TR-2YC
This user manual2
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:
Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;
GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2
1
1
2
s-Video Player
s-Video Display
