Kramer TP-600TR, TP-600TRxr User Manual

P/N: 2900-301503 Rev 1 www.kramerAV.com

USER MANUAL

MODELS:

TP-600TRxr
TP-600TR
4K60 HDMI/USB Extender

Kramer Electronics Ltd.

TP-600TRxr – Contents

i

Contents

Introduction 1

Getting Started 1
Overview 2
Typical Applications 3

Defining TP-600TRxr 4K60 HDMI/USB Extender 4
Mounting TP-600TRxr 6
Connecting the 4K60 HDMI/USB Extender 7

Connecting TP-600TRxr 7
Connecting TP-600TR 9
Connecting to TP-600TRxr via RS-232 11
Setting the DIP-Switches 11

Technical Specifications 12

TP-600TRxr Specifications 12
TP-600TR Specifications 13

Kramer Electronics Ltd.

TP-600TRxr – Introduction

1

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.

• Review the contents of this user manual.

Go to www.kramerav.com/downloads/TP-600TRxr or www.kramerav.com/downloads/TP-

600TRto check for up-to-date user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

Achieving Best Performance

• Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).

• Do not secure the cables in tight bundles or roll the slack into tight coils.

• Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

• Position your Kramer TP-600TRxr / TP-600TR away from moisture, excessive sunlight
and dust.

Safety Instructions

Caution:

• This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.

• For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.

• There are no operator serviceable parts inside the unit.

Warning:

• Use only the power cord that is supplied with the unit.

• To ensure continuous risk protection, replace fuses only according to the rating

specified on the product label which is located on the bottom of the unit.

Kramer Electronics Ltd.

TP-600TRxr – Introduction

2

Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected
and recycled. To comply with the WEEE Directive, Kramer Electronics has made
arrangements with the European Advanced Recycling Network (EARN) and will cover any
costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on
arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular
country go to our recycling pages at www.kramerav.com/il/quality/environment.

Overview

Congratulations on purchasing your Kramer TP-600TRxr/TP-600TR 4K60 HDMI/USB

Extender.

TP-600TR is identical to TP-600TRxr except for ETH extension. TP-600TRxr, in this User

Manual, refers to both devices, unless specified otherwise.

TP-600TRxr is a high-performance, long-reach HDBaseT 3.0 extender for 4K60Hz (4:4:4)

HDMI, USB, Ethernet (TP-600TRxr only), RS-232, and IR signals over twisted pair, flexibly
set as transmitter-side or receiver-side device. TP-600TRxr transmitter-side converts all input
signals into the transmitted HDBaseT 3.0 signal. TP-600TRxr receiver-side receives the
HDBaseT 3.0 signal and converts it back into the original input signals.

TP-600TRxr extends video signals up to 100m (330ft) over CAT copper cables at 4K@60Hz

(4:4:4) video resolution.

TP-600TR extends video signals up to 40m (130ft) over CAT copper cables at 4K@60Hz

(4:4:4) video resolution and up to 70m (230ft) at 4K@30Hz (4:4:4).

TP-600TRxr provides exceptional quality, advanced and user-friendly operation, and flexible

control.

Exceptional Quality

• High Performance Standard Extender – Professional HDBaseT extender for providing
extended-reach signals over twisted-pair copper infrastructures. TP-600TRxr is a
standard extender that can be connected to any market-available HDBaseT-compliant
extension product. For optimum extension reach and performance, use recommended
Kramer cables.

• HDMI Signal Extension – HDCP 2.3, EDID and CEC signals are passed through from

the source to the display. Supports HDR10, deep color, x.v.Color™, lip sync, HDMI

uncompressed audio channels, Dolby TrueHD, DTS-HD, 2K, 4K, and 3D as specified in
HDMI 2.0.

• HDMI extension – Uncompressed 4K@60Hz (4:4:4).

• I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID handling,

processing, and pass-through algorithm that ensures Plug and Play operation for HDMI
source and display systems.

Kramer Electronics Ltd.

TP-600TRxr – Introduction

3

Advanced and User-friendly Operation

• HDMI Mirroring – Transmitter-side extender mirrors input HDMI signal to loop output port
for connecting a local monitor or an additional unit in a daisy chain.

• Flexible USB 2.0 Extension – An active USB host is connected to the extender at either
the transmitter or receiver sides. USB 2.0 signals are extended between the extender
transmitter and receiver sides, enabling connection of the active USB host to both local
and remote USB devices, such as camera and audio devices, or HID (Human Interface
Devices) mouse or keyboard devices.

• Cost-effective Maintenance – Status LED indicators for HDMI, Loop, HDBT, and USB
active host ports, facilitate easy local maintenance and troubleshooting.

• Easy and Elegant Installation – MegaTOOLS™ fan-less enclosure for dropped-ceiling
mounting, or side-by-side mounting of 2 units in a 1U rack space with the recommended
rack adapter.

Flexible Connectivity

• Multi-channel Audio Transmission – Up to 32 channels of digital stereo uncompressed
signals for supporting studio-grade surround sound.

• Flexible USB 2.0 host and devices extension.

• Ethernet Extension (TP-600TRxr only) – Ethernet interface data flows in both directions,

allowing extension of up to 1 Gbps Ethernet connectivity for LAN communication and
device control.

• Bidirectional RS-232 Extension – Serial interface data flows in both directions, allowing
data transmission and device control.

• Bidirectional Infrared Extension – IR interface data flows in both directions, allowing
remote control of peripheral devices located at either end of the extended line.

Typical Applications

TP-600TRxr is ideal for the following typical applications:

• Corporate – Hybrid and online meetings.

• Education – Hybrid and online learning and training.

• Any AV, Ethernet (TP-600TRxr only) and USB room extension applications such as

conference rooms, boardrooms, and training facilities.

Kramer Electronics Ltd.

TP-600TRxr – Defining TP-600TRxr 4K60 HDMI/USB Extender

4

Defining TP-600TRxr 4K60 HDMI/USB Extender

This section defines TP-600TRxr and TP-600TR.

The extender device functions as a transmitter or receiver as defined by the SETUP
DIP-switch 1 setting on the rear panel (see Setting the DIP-Switches on page 11).

Figure 1: TP-600TRxr 4K60 HDMI/USB Extender Front Panel

Figure 2: TP-600TR 4K60 HDMI/USB Extender Front Panel

#

Feature

Function

HOST USB B 2.0
Connector

Connect to the USB host (for example, a laptop) to communicate with the USB
peripheral devices (for example, a smart board) connected to USB device ports
on either the transmitter or the receiver sides of the extender (see Connecting

the 4K60 HDMI/USB Extender on page 7).

ACTIVE HOST
LED

Lights orange when the USB host side is active
ACTIVE Rx LED

Lights green when the extender receiver function is active

IN LED

Lights blue when an active HDMI input signal is detected on HDMI IN.

OUT LED

Lights blue when an output acceptor device is connected.

TX LOOP

Transmitter mode

Lights blue an active signal is transmitted on the Tx LOOP
port.

Receiver mode

N/A

LINK LED

Lights green when the HDBT active link connection is established.

ON LED

Lights green when the device receives power.

1 2 3

4 5 6

7

8

Kramer Electronics Ltd.

TP-600TRxr – Defining TP-600TRxr 4K60 HDMI/USB Extender

5

Figure 3: TP-600TRxr 4K60 HDMI/USB Extender Rear Panel

Figure 4: TP-600TR 4K60 HDMI/USB Extender Rear Panel

#

Feature

Function

ENTER Button

Press to move to the next level in the OSD screen or to accept a new
parameter.

HDMI TX IN
Connector

Transmitter mode

Connect to an HDMI source.

Receiver Mode

N/A

HDMI Rx
OUT/Tx LOOP
Connector

Transmitter mode

Connect to a local acceptor.
Receiver mode

Connect to an HDMI acceptor.

USB A 2.0 Fast­Charging
Connectors (3)

Connect to the USB local peripheral devices (for example, a USB camera, a
soundbar, microphone and so on).

IR 3.5mm Mini
Jack Connector

Connect to an external IR emitter to control a local IR-controlled device from the
remote extender (for example, TP-600TRxr).
Connect to an IR sensor to control a remote IR-controlled device connected to
the remote extender side (for example, TP-600TRxr).

RS-232 3-pin
Terminal Block

Connect to a controller device (for example, SL240C) to control a remote device
via serial connection (for example, the remotely connected PTZ USB camera).

ETHERNET
RJ-45 Connector

Connect to LAN.

SETUP 4-way
DIP-switch

Sets the device behavior (see Setting the DIP-Switches on page 11).

12V DC Power
Connector

Connect to the power supply.

9

10

11

12

13

14

15

16

17

Kramer Electronics Ltd.

TP-600TRxr – Mounting TP-600TRxr

6

Mounting TP-600TRxr

This section provides instructions for mounting TP-600TRxr. Before installing, verify that the
environment is within the recommended range:

• Operation temperature – 0 to 40C (32 to 104F).

• Storage temperature – -40 to +70C (-40 to +158F).

• Humidity – 10% to 90%, RHL non-condensing.

Caution:

• Mount TP-600TRxr before connecting any cables or power.

Warning:

• Ensure that the environment (e.g., maximum ambient temperature & air flow) is
compatible for the device.

• Avoid uneven mechanical loading.

• Appropriate consideration of equipment nameplate ratings should be used for avoiding

overloading of the circuits.

• Reliable earthing of rack-mounted equipment should be maintained.

• Maximum mounting height for the device is 2 meters.

Mount TP-600TRxr in a rack:

• Use the recommended rack adapter
(see www.kramerav.com/product/TP-600TRxr).

Mount TP-600TRxr on a surface using one of the following
methods:

• Attach the rubber feet and place the unit on a flat surface.

• Fasten a bracket (included) on each side of the unit and attach it to

a flat surface. For more information go to

www.kramerav.com/downloads/TP-600TRxr.

Kramer Electronics Ltd.

TP-600TRxr – Connecting the 4K60 HDMI/USB Extender

7

Connecting the 4K60 HDMI/USB Extender

You can use two TP-600TRxr units, define them as transmitter and receiver and then connect
the transmitter to the receiver (as described in this section). You can also connect the device
to a different unit. For example:

• Connecting TP-600TRxr that is set as a transmitter to the Kramer TP-590R receiver.

• Connecting a transmitter (for example, the Kramer TP-590T transmitter) to a

TP-600TRxr that is set as a receiver.

• Connecting the TP-600TRxr (defined as a transmitter or receiver to a switcher or other
system, for example, the VS-84UT).

This section describes the following actions:

• Connecting TP-600TRxr on page 7.

• Connecting TP-600TR on page 9.

• Connecting to TP-600TRxr via RS-232 on page 11.

• Error! Reference source not found. on page Error! Bookmark not defined..

• Setting the DIP-Switches on page 11.

Always switch off the power to each device before connecting it to your TP-600TRxr. After
connecting your TP-600TRxr, connect its power and then switch on the power to each
device.

Connecting TP-600TRxr

Figure 5: Connecting to TP-600TRxr

Kramer Electronics Ltd.

TP-600TRxr – Connecting the 4K60 HDMI/USB Extender

8

To connect TP-600TRxr as illustrated in the example in Figure 5:

1. Use the DIP-switches to define one device as a transmitter and the other as a
receiver (see Setting the DIP-Switches on page 11).

2. Connect the HDBT port on the TP-600TRxr transmitter side to the HDBT port on
the TP-600TRxr receiver side.

3. On the TP-600TRxr transmitter side, connect an HDMI source (for example, a laptop) to
the HDMI Tx IN connector .

4. On the TP-600TRxr transmitter side, connect the HDMI Rx OUT/Tx LOOP connector
to an HDMI acceptor.

5. On the TP-600TRxr receiver side, connect the HDMI Rx OUT/Tx LOOP connector to
an HDMI acceptor (for example, a smart TV).

6. Connect the USB ports:

▪ Connect the HOST USB port to a laptop or room PC.

The HOST USB port can be connected to either the transmitter or the receiver
side, as necessary.

▪ Connect the USB DEVICE ports on the transmitter side to USB devices (for example,

the room microphone, mouse, and keyboard).

▪ Connect the USB DEVICE ports on the receiver side to USB devices (for example, a

smart board, soundbar and camera).

USB devices can be connected to both the transmitter and receiver sides, as
necessary.

7. To control the smart TV via IR, connect the following:

▪ On the TP-600TRxr transmitter side, connect an IR sensor cable to the IR 3.5mm

mini jack

.

▪ On the TP-600TRxr receiver side, connect the IR 3.5mm mini jack to an emitter

cable and attach the emitter side to the IR sensor of the smart TV.

Point the smart TV IR remote controller to the IR sensor to pass an IR command via
HDBT to the smart TV.

8. To Control the smart TV via Ethernet, connect the following:

▪ On the TP-600TRxr transmitter side, connect a room controller (for example, the

Kramer SL-240C with Kramer Control) to the Ethernet RJ-45 port .

▪ On the TP-600TRxr receiver side, connect the Ethernet RJ-45 port to the smart

TV.

Send IP commands via the room controller to the smart TV via LAN.

9. To control the PTZ camera, connect the following:

▪ On TP-600TRxr transmitter side connect a controller (for example, SL-240C room

controller) to the RS-232 port (and also to the ETHERNET RJ-45 port ).

▪ On TP-600TRxr receiver side connect the RS-232 port to a PTZ camera.

14 9 9

10

11

11

13

13

15

15

14

15

14

Kramer Electronics Ltd.

TP-600TRxr – Connecting the 4K60 HDMI/USB Extender

9

Send serial commands from SL-240C to the camera via RS-232.

10. Connect the power adapter to TP-600TRxr and to the mains electricity (not shown in

Figure 5).

TP-600TRxr is connected.

Connecting TP-600TR

Figure 6: Connecting to TP-600TR

To connect TP-600TR as illustrated in the example in Figure 5:

1. Use the DIP-switches to define one device as a transmitter and the other as a
receiver (see Setting the DIP-Switches on page 11).

2. Connect the HDBT port on the TP-600TR transmitter side to the HDBT port on
the TP-600TR receiver side.

3. On the TP-600TR transmitter side, connect an HDMI source (for example, a laptop) to
the HDMI Tx IN connector .

4. On the TP-600TR transmitter side, connect the HDMI Rx OUT/Tx LOOP connector
to an HDMI acceptor.

5. On the TP-600TR receiver side, connect the HDMI Rx OUT/Tx LOOP connector to
an HDMI acceptor (for example, a smart TV).

6. Connect the USB ports:

▪ Connect the HOST USB port to a laptop or room PC.

The HOST USB port can be connected to either the transmitter or the receiver
side, as necessary.

▪ Connect the USB DEVICE ports on the transmitter side to USB devices (for example,

the room microphone, mouse, and keyboard).

▪ Connect the USB DEVICE ports on the receiver side to USB devices (for example, a

smart board, soundbar and camera).

14 9 9

10

11

11

Kramer Electronics Ltd.

TP-600TRxr – Connecting the 4K60 HDMI/USB Extender

10

USB devices can be connected to both the transmitter and receiver sides, as
necessary.

7. To control the smart TV via IR, connect the following:

▪ On the TP-600TR transmitter side, connect an IR sensor cable to the IR 3.5mm mini

jack

.

▪ On the TP-600TR receiver side, connect the IR 3.5mm mini jack to an emitter

cable and attach the emitter sidea to the IR sensor of the smart TV.

Point the smart TV IR remote controller to the IR sensor to pass an IR command via
HDBT to the smart TV.

8. To control the PTZ camera, connect the following:

▪ On TP-600TR transmitter side connect a controller (for example, SL-240C room

controller) to the RS-232 port (and also to the ETHERNET RJ-45 port ).

▪ On TP-600TR receiver side connect the RS-232 port to a PTZ camera.

Send serial commands from SL-240C to the camera via RS-232.

9. Connect the power adapter to TP-600TR and to the mains electricity (not shown in

Figure 5).

TP-600TR is connected.

13

13

14

15

14

Kramer Electronics Ltd.

TP-600TRxr – Connecting the 4K60 HDMI/USB Extender

11

Connecting to TP-600TRxr via RS-232

You can connect to TP-600TRxr via an RS-232 connection using, for example, a PC.

TP-600TRxr features an RS-232 3-pin terminal block connector to extend RS-232 signals via
TP-600TRxr transmitter and receiver.

Connect the RS-232 terminal block on the rear panel of TP-600TRxr to a device, as follows:
From the RS-232 9-pin D-sub serial port connect:

• Pin 2 to the TX pin on the TP-600TRxr RS-232 terminal
block

• Pin 3 to the RX pin on the TP-600TRxr RS-232 terminal
block

• Pin 5 to the G pin on the TP-600TRxr RS-232 terminal

block

RS-232 Device TP-600TRxr

EIA /TIA 568B

PIN

Wire Color

1

Orange / White

2

Orange

3

Green / White

4

Blue

5

Blue / White

6

Green

7

Brown / White

8

Brown

Setting the DIP-Switches

All changes in DIP-Switches apply immediately, on-the-fly (no need to power cycle the
device), except for DIP-switches 1 and 2.

All DIP-switches are set to OFF (up) by default.

#

Feature

DIP-switch Settings

1

Device Operation Mode

OFF (up) – Receiver mode is active.
ON (down) – Transmitter mode is active.

2

Active USB Host port

OFF (up) – Host is active.
ON (down) – Host is inactive (active on remote paired device).

3

Define IR Pass-through

OFF (up) – Pass-through the IR signal to or from the IR cable.
ON (down) – Add IR modulation (38kHz) to the IR output signal (applies only when the IR port is
connected to an IR emitter cable).

4

Programing RS-232

Off (up) – Normal operation mode is enabled (FW programming RS-232 is inactive).
On (down) – FW programming RS-232 is active.

13

Kramer Electronics Ltd.

TP-600TRxr – Technical Specifications

12

Technical Specifications

TP-600TRxr Specifications

Inputs

Transmitter Side

1 HDMI

On a female HDMI connector

Receiver Side

1 HDBT

On a female RJ-45 connector

Outputs

Transmitter Side

1 HDBT

On a female RJ-45 connector

1 LOOP

On a female HDMI connector

Receiver Side

1 HDMI

On a female HDMI connector

Ports

1 USB 2.0 Host

On a USB-B female connector

3 USB 2.0 Device

On USB type-A female connectors

1 1000BaseT Ethernet

On an RJ-45 female connector for LAN extension

1 IR

On a 3.5mm mini jack for IR link extension

1 RS-232

On a 3-pin terminal block for serial link extension

Extension Line

Reach

Up to 100m (330ft), when using Kramer HDBaseT
cables

Standards Compliance

HDBaseT 3.0

Video

Max Data Rate

18Gbps bandwidth (6Gbps per graphic channel)

Max Resolution

4K@60Hz (4:4:4) 24bpp resolution

Content Protection

HDCP 2.3

HDMI Support

4K as specified in HDMI 2.0b

Extended USB

Data Rate

Up to 480Mbps

Transmitted Data Bandwidth

Up to 300Mbps

Standards Compliance

1.1 and 2.0 USB

Extended Ethernet

Max Data Rate

1Gbps

Extended RS-232

Baud Rate

300 to 115200

Power
Consumption

12V DC, 3200mA

Source

12V DC, 5A

Environmental
Conditions

Operating Temperature

0° to +40°C (32° to 104°F)

Storage Temperature

-40° to +70°C (-40° to 158°F)

Humidity

10% to 90%, RHL non-condensing

Regulatory
Compliance

Safety

CE

Environmental

RoHs, WEEE

Enclosure

Size

Mega Tool

Material

Aluminum

Cooling

Convection Ventilation

General

Net Dimensions (W, D, H)

19cm x 11.6cm x 2.7cm
(7.5" x 4.6" x 1.1")

Shipping Dimensions (W, D,
H)

34.5cm x 16.5cm x 5.2cm
(13.6" x 6.5" x 2")

Net Weight

0.56kg (1.2lbs)

Shipping Weight

1.15kg (2.5lbs) approx.

Accessories

Included

Power adapter and cord

Specifications are subject to change without notice at www.kramerav.com

Kramer Electronics Ltd.

TP-600TRxr – Technical Specifications

13

TP-600TR Specifications

Inputs

Transmitter Side

1 HDMI

On a female HDMI connector

Receiver Side

1 HDBT

On a female RJ-45 connector

Outputs

Transmitter Side

1 HDBT

On a female RJ-45 connector

1 LOOP

On a female HDMI connector

Receiver Side

1 HDMI

On a female HDMI connector

Ports

1 USB 2.0 Host

On a USB-B female connector

3 USB 2.0 Device

On USB type-A female connectors

1 IR

On a 3.5mm mini jack for IR link extension

1 RS-232

On a 3-pin terminal block for serial link extension

Extension Line

Reach

Up to 40m (130ft) at 4K@60Hz (4:4:4), when
using Kramer HDBaseT cables

Up to 70m (230ft) at up to 4K@30Hz (4:4:4),
when using Kramer HDBaseT cables

Standards Compliance

HDBaseT 3.0

Video

Max Data Rate

18Gbps bandwidth (6Gbps per graphic channel)

Max Resolution

4K@60Hz (4:4:4) 24bpp resolution

Content Protection

HDCP 2.3

HDMI Support

4K as specified in HDMI 2.0b

Extended USB

Data Rate

Up to 480Mbps

Transmitted Data Bandwidth

Up to 300Mbps

Standards Compliance

1.1 and 2.0 USB

Extended Ethernet

Max Data Rate

1Gbps

Extended RS-232

Baud Rate

300 to 115200

Power
Consumption

12V DC, 600mA

Source

12V DC, 2A

Environmental
Conditions

Operating Temperature

0° to +40°C (32° to 104°F)

Storage Temperature

-40° to +70°C (-40° to 158°F)

Humidity

10% to 90%, RHL non-condensing

Regulatory
Compliance

Safety

CE

Environmental

RoHs, WEEE

Enclosure

Size

Mega Tool

Material

Aluminum

Cooling

Convection Ventilation

General

Net Dimensions (W, D, H)

19cm x 11.6cm x 2.7cm
(7.5" x 4.6" x 1.1")

Shipping Dimensions (W, D,
H)

34.5cm x 16.5cm x 5.2cm
(13.6" x 6.5" x 2")

Net Weight

0.55kg (1.2lbs)

Shipping Weight

1.12kg (2.5lbs) approx.

Accessories

Included

Power adapter and cord

Specifications are subject to change without notice at www.kramerav.com

The warranty obligations of Kramer Electronics Inc. (“Kramer Electronics”) for this product are limited to the terms set forth below:

What is Covered

This limited warranty covers defects in materials and workmanship in this product.

What is Not Covered

This limited warranty does not cover any damage, deterioration or malfunction resulting from any alteration, modification, improper or unreasonable use or
maintenance, misuse, abuse, accident, neglect, exposure to excess moisture, fire, improper packing and shipping (such claims must be presented to the carrier),
lightning, power surges, or other acts of nature. This limited warranty does not cover any damage, deterioration or malfunction resulting from the installation or
removal of this product from any installation, any unauthorized tampering with this product, any repairs attempted by anyone unauthorized by Kramer Electronics
to make such repairs, or any other cause which does not relate directly to a defect in materials and/or workmanship of this product. This limited warranty does not
cover cartons, equipment enclosures, cables or accessories used in conjunction with this product.
Without limiting any other exclusion herein, Kramer Electronics does not warrant that the product covered hereby, including, without limitation, the technology
and/or integrated circuit(s) included in the product, will not become obsolete or that such items are or will remain compatible with any other product or technology
with which the product may be used.

How Long this Coverage Lasts

The standard limited warranty for Kramer products is seven (7) years from the date of original purchase, with the following exceptions:

1. All Kramer VIA hardware products are covered by a standard three (3) year warranty for the VIA hardware and a standard three (3) year
warranty for firmware and software updates; all Kramer VIA accessories, adapters, tags, and dongles are covered by a standard one (1) year
warranty.

2. Kramer fiber optic cables, adapter-size fiber optic extenders, pluggable optical modules, active cables, cable retractors, ring mounted
adapters, portable power chargers, Kramer speakers, and Kramer touch panels are covered by a standard one (1) year warranty. Kramer
7-inch touch panels purchased on or after April 1st, 2020 are covered by a standard two (2) year warranty.

3. All Kramer Calibre products, all Kramer Minicom digital signage products, all HighSecLabs products, all streaming, and all wireless products
are covered by a standard three (3) year warranty.

4. All Sierra Video MultiViewers are covered by a standard five (5) year warranty.

5. Sierra switchers & control panels are covered by a standard seven (7) year warranty (excluding power supplies and fans that are covered for
three (3) years).

6. K-Touch software is covered by a standard one (1) year warranty for software updates.

7. All Kramer passive cables are covered by a lifetime warranty.

Who is Covered

Only the original purchaser of this product is covered under this limited warranty. This limited warranty is not transferable to subsequent purchasers or owners of
this product.

What Kramer Electronics Will Do

Kramer Electronics will, at its sole option, provide one of the following three remedies to whatever extent it shall deem necessary to satisfy a proper claim under
this limited warranty:

1. Elect to repair or facilitate the repair of any defective parts within a reasonable period of time, free of any charge for the necessary parts and
labor to complete the repair and restore this product to its proper operating condition. Kramer Electronics will also pay the shipping costs
necessary to return this product once the repair is complete.

2. Replace this product with a direct replacement or with a similar product deemed by Kramer Electronics to perform substantially the same
function as the original product. If a direct or similar replacement product is supplied, the original product’s end warranty date remains
unchanged and is transferred to the replacement product.

3. Issue a refund of the original purchase price less depreciation to be determined based on the age of the product at the time remedy is sought
under this limited warranty.

What Kramer Electronics Will Not Do Under This Limited Warranty

If this product is returned to Kramer Electronics or the authorized dealer from which it was purchased or any other party authorized to repair Kramer Electronics
products, this product must be insured during shipment, with the insurance and shipping charges prepaid by you. If this product is returned uninsured, you assume
all risks of loss or damage during shipment. Kramer Electronics will not be responsible for any costs related to the removal or re-installation of this product from or
into any installation. Kramer Electronics will not be responsible for any costs related to any setting up this product, any adjustment of user controls or any
programming required for a specific installation of this product.

How to Obtain a Remedy Under This Limited Warranty

To obtain a remedy under this limited warranty, you must contact either the authorized Kramer Electronics reseller from whom you purchased this product or the
Kramer Electronics office nearest you. For a list of authorized Kramer Electronics resellers and/or Kramer Electronics authorized service providers, visit our web
site at www.kramerav.com or contact the Kramer Electronics office nearest you.
In order to pursue any remedy under this limited warranty, you must possess an original, dated receipt as proof of purchase from an authorized Kramer Electronics
reseller. If this product is returned under this limited warranty, a return authorization number, obtained from Kramer Electronics, will be required (RMA number).
You may also be directed to an authorized reseller or a person authorized by Kramer Electronics to repair the product.
If it is decided that this product should be returned directly to Kramer Electronics, this product should be properly packed, preferably in the original carton, for
shipping. Cartons not bearing a return authorization number will be refused.

Limitation of Liability

THE MAXIMUM LIABILITY OF KRAMER ELECTRONICS UNDER THIS LIMITED WARRANTY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID
FOR THE PRODUCT. TO THE MAXIMUM EXTENT PERMITTED BY LAW, KRAMER ELECTRONICS IS NOT RESPONSIBLE FOR DIRECT, SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL
THEORY. Some countries, districts or states do not allow the exclusion or limitation of relief, special, incidental, consequential or indirect damages, or the limitation
of liability to specified amounts, so the above limitations or exclusions may not apply to you.

Exclusive Remedy

TO THE MAXIMUM EXTENT PERMITTED BY LAW, THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN LIEU OF
ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. TO THE MAXIMUM EXTENT
PERMITTED BY LAW, KRAMER ELECTRONICS SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IF KRAMER ELECTRONICS CANNOT LAWFULLY DISCLAIM OR
EXCLUDE IMPLIED WARRANTIES UNDER APPLICABLE LAW, THEN ALL IMPLIED WARRANTIES COVERING THIS PRODUCT, INCLUDING WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY TO THIS PRODUCT AS PROVIDED UNDER APPLICABLE LAW.
IF ANY PRODUCT TO WHICH THIS LIMITED WARRANTY APPLIES IS A “CONSUMER PRODUCT” UNDER THE MAGNUSON-MOSS WARRANTY ACT (15
U.S.C.A. §2301, ET SEQ.) OR OTHER APPLICABLE LAW, THE FOREGOING DISCLAIMER OF IMPLIED WARRANTIES SHALL NOT APPLY TO YOU, AND
ALL IMPLIED WARRANTIES ON THIS PRODUCT, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR THE PARTICULAR PURPOSE,
SHALL APPLY AS PROVIDED UNDER APPLICABLE LAW.

Other Conditions

This limited warranty gives you specific legal rights, and you may have other rights which vary from country to country or state to state.
This limited warranty is void if (i) the label bearing the serial number of this product has been removed or defaced, (ii) the product is not distributed by Kramer
Electronics or (iii) this product is not purchased from an authorized Kramer Electronics reseller. If you are unsure whether a reseller is an authorized Kramer
Electronics reseller, visit our web site at www.kramerav.com or contact a Kramer Electronics office from the list at the end of this document.
Your rights under this limited warranty are not diminished if you do not complete and return the product registration form or complete and submit the online product
registration form. Kramer Electronics thanks you for purchasing a Kramer Electronics product. We hope it will give you years of satisfaction.

www.KramerAV.com
[e-mail]

P/N:

2900-301503

Rev:

1

SAFETY WARNING

Disconnect the unit from the power supply before opening and servicing

For the latest information on our products and a list of Kramer distributors, visit our website where
updates to this user manual may be found.

We welcome your questions, comments, and feedback.

The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
All brand names, product names, and trademarks are the property of their respective owners.
