P/N:
2900-300227
Rev:
1
Black Front Panel Replacement kit
for SID-X1:
Congratulations on purchasing your Kramer SID-X1BP Black Front Panel Replacement kit
which is used to replace the gray colored front panel with a black one so it can blend into
the T10-22M inner frame of the TBUS-10XL.
The kit includes a black SID-X1 front panel and an Allen L shaped key.
To replace the front panel of the SID-X1:
1. Remove the two front panel screws on the
SID-X1 with the Allen L-shaped key (supplied).
2. Remove all the hexagonal spacers using a 5mm
socket spanner wrench (not supplied).
3. Remove the original front panel and replace with
the new SID-X1BP black front panel.
4. Replace the hexagonal spacers and tighten with
the socket spanner wrench.
5. Replace the two front panel screws and tighten
with the Allen L shaped key.
6. Keep the original SID-X1 gray front panel (for
future use) in case you choose not to use with
the TBUS-10XL.
For the latest information on our products and a list of Kramer distributors, visit our Web
SID- X1BP
site where updates to this sheet may be found.
We welcome your questions, comments, and feedback.
Web site:
www.kramerelectronics.com
E-mail:
info@kramerel.com
KRAMER ELECTRONICS LTD.
P/N: 2900-300227 REV 1
