PS-1202-5 Quick Start
P/N:
2900- 301629QS
Rev:
1
Scan for full manual
PS-1202-5 Quick Start Guide
This guide helps you install and use your PS-1202-5 for the first time.
Go to www.kramerav.com/downloads/PS-1202-5 to download the latest user manual and check if firmware
upgrades are available.
Step 1: Check what’s in the box
PS-1202-5 12V DC/2A Right-Angle Power Supply
1 Power cord
1 Quick start guide
Step 2: Get to know your PS-1202-5
PS-1202-5 is a desktop right-angle power supply with standard size DC output plug that provides 12V DC/2A to any device
that requires this type of power input.
Step 3: Technical Specifications
Input
100-240V AC
Output
12V DC, 2A max.
Maximum Power
25W
Operating Temperature
0°C to +40°C (32° to 104°F)
Storage Temperature
-20°C to +80°C (-4° to 140°F)
Operating Humidity
20% to 80%, RH (non-condensing)
Storage Humidity
10% to 90%, RH (non-condensing)
Net Dimensions
9.8cm x 3.7cm x 2.9cm (3.9" x 1.5"x 1.1") W, D, H
DC cable 150cm ±2 (59"±0.9)
Shipping Dimensions
17.2cm x 13cm x 6.5cm (6.8" x 5.1"x 2.6") W, D, H
Net Weight
0.13kg (0.29lbs) approx.
Shipping Weight
0.28kg (0.62lbs) approx.
