Multiviewer Configuration
and card selection guide
SMP-xx/SMP-xx-R
1 RU Modular Multiviewer Platform
MP-xx
3 RU Modular Multiviewer Platform
Version 0.5
Introduction
The video and audio architecture is the same for the SMP-xx,SMP-xx-R and MP-xx frames.
SMP-xx frame - up to 4 video processing cards supporting up to 32 inputs and up to 2 independent multi-viewers.
Rear View of a 2 x 4k quad input multiviewer
SMP-xx-R frame - up to 4 video processing cards supporting 32 inputs and 32 routing inputs.
Rear View of a 4k 32 input multiviewer with 32 routing outputs
MP-xx frame – up to 18 video processing cards supporting 144 inputs and up to 9 independent multiviewers.
Rear View of a 6 x 4k 16 input multiviewer
Version 0.5
The following processing cards are available for ALL FRAMES
Video input cards:
VIP4 with 8 input channels/card.
VIP3 with 4 input channels/card
Multiviewer Output cards
MVC two head video output card
MVC2 two head 4K video output card
Audio input cards:
AIPxxA up to 32 channel analogue input cards ( where xx is either 08 16 or 32)
AIPxxD up to 32 channel digital input cards ( where xx is either 08 16 or 32)
AIP32AD up to 32 channel analogue and digital input cards.
Audio output cards:
AOPxxA up to 32 channel analogue audio output cards ( where xx is either 08 16 or 32)
AOPxxD up to 32 channel digital audio output cards ( where xx is either 08 16 or 32)
The following table shows what video inputs are supported by each VIP video processing card along with which of the three
video output cards can be used with that VIP and the output resolutions they can support:
VIP
Options
Number of Input
signal types supported
MVC Card Output signal types supported
2K60 4K30 4K60 2K60 4K30 4K60
VIP3 4
MVC 2
MVC2-LV 2 2
MVC2-SD
VIP4 8 4 2
MVC
MVC2-LV
MVC2-SD 2 2 2
Version 0.5
SMP-xx examples of common configurations
The SMP-xx 1U frame has six card slots at the front and rear of the unit. One of the slots is always reserved for the
network card (NET), leaving five slots that can be populated with a variety of video and and audio processing cards
tailored to any broadcast requirements:
4K Capable 32 input multi-viewer
Front View (Processing Cards)
Rear View(Input and Output Cards)
4K Capable 2x independent 8 input multiviewers
Front View (Processing Cards)
Rear View (Input-Output Cards)
16 Channel HDMI input multiviewer
Front View (Processing Cards)
Rear View (Input-Output Cards)
Version 0.5
PSU
VIP4 (Slot 5)
Net (Slot 0)
VIP4 (Slot 4)
MVC2 (Slot1)VIP4 (Slot 2)
VIP4 (Slot 3)
PSU
Net (Slot 0)
MVC2 (Slot1)
VIP4 (Slot 2)
MVC2 (Slot 3)
VIP4 (Slot 4)
Empty (Slot 5)
PSU
Net (Slot 0)
MVC (Slot1)
VIP3 (Slot 2)
VIP3 (Slot 3)
VIP3 (Slot 4)
VIP3 (Slot 5)
PSU
RMP-SD8 (Slot 5)
MPX-RNG (Slot 0)
RMP-SD8 (Slot 4)
RMP-MVCS8 (Slot1) RMP-SD8 (Slot 2)
RMP-SD8 (Slot 3)
PSU
RMP-SD8 (Slot 5)
MPX-RNG (Slot 0)
RMP-SD8 (Slot 4)
RMP-MVCS8 (Slot1) RMP-SD8 (Slot 2)
RMP-MVCS8 (Slot3)
PSU
RMP-HM4 (Slot 5)
MPX-RNG (Slot 0)
RMP-HM4 (Slot 4)
RMP-MVC (Slot1)
RMP-HM4 (Slot3)
RMP-HM4 (Slot 2)
AM-xx Audio monitoring
Audio processing cards can be fitted exclusively in a SMP-xx chassis to create the AM-xx range of audio monitoring racks.
64 channel input and output AM-xx.
Front View (Processing Cards)
Rear View (Input-Output Cards)
128 channel input AM-xx.
Front View (Processing Cards)
Rear View (Input-Output Cards)
The AM-xx can notify users via mobile platforms such as cellphones, tablets etc, as well as via PC, to any pre-configured
alarm events such as loudness excursions, loss of signal etc.
Version 0.5
Audio OUT (Slot1)
Net (Slot 0)
PSU
Audio OUT (Slot 2)
MVC (Slot 3)
Audio IN (Slot 4)
Audio IN (Slot 5)
PSU
MVC (Slot1)
Audio IN (Slot 2)
Audio IN (Slot 3) Audio IN (Slot 4)
Audio IN (Slot 5)
Net (Slot 0)
PSU
RMP-A32 (Slot 5)
MPX-RNG (Slot 0)
RMP-A32 (Slot 4)
RMP-A32 (Slot1)
RMP-MVC (Slot3)
RMP-A32 (Slot 2)
PSU
RMP-A32 (Slot 5)
MPX-RNG (Slot 0)
RMP-A32 (Slot 4)
RMP-MVC (Slot1)
RMP-A32(Slot3)
RMP-A32 (Slot 2)
SMP-xx-R (Integrated routers)
The SMP-xx-R frame has two integrated 32x32 non-blocking routers.
MV input router; offers a 32x32 non-blocking multi-viewer input capability which allows any SDI input to be routed to
any of the input channels on any VIP4.
SDI router; this is independent of the MV input router and functions as a stand-alone 32x32 non-blocking SDI router.
SMP-32-R, 32 channel input and output multi-viewer and SDI router:
Front View (Processing Cards)
Rear View (Input-Output Cards)
The router architecture also allows asymmetric routing for more cost effective solutions.
SMP-32-R, 32 x 8 asymmetric input multi-viewer
Front View (Processing Cards)
Rear View (Input-Output Cards)
SMP-32-R, 32 x 32 non-blocking SDI router
Front View (Processing Cards)
Rear View (Input-Output Cards)
Version 0.5
VIP4 (Slot 5)
Net (Slot 0)
VIP4 (Slot 4)
MVC2 (Slot1)
VIP4 (Slot 3)
PSU
VIP4 (Slot 2)
PSU
PSU
RMP-SD8R (Slot 5)
MPX-RNG (Slot 0)
RMP-SD8R (Slot 4)
RMP-MVCS8 (Slot1) RMP-SD8R (Slot 2)
RMP-SD8R (Slot3)
PSU
RMP-SD8R (Slot 5)
MPX-RNG (Slot 0)
RMP-SD8R (Slot 4)
RMP-MVCS8 (Slot1) RMP-SD8 (Slot 2)
RMP-SD8R (Slot3)
Net (Slot 0)
MVC2 (Slot1)
VIP4 (Slot 2)
Empty (Slot 3)
Empty (Slot 5)Empty (Slot 4)
PSU
Net (Slot 0)
MVC2 (Slot1)
Empty (Slot 2)
Empty (Slot 3)
Empty (Slot 5)Empty (Slot 4)
PSU
PSU
RMP-SD8R (Slot 5)
MPX-RNG (Slot 0)
RMP-SD8R (Slot 4)
RMP-MVCS8 (Slot1) RMP-SD8R (Slot 2)
RMP-SD8R (Slot3)
MP-xx
The MP-xx 3U frame has a total of twenty slots at the front and rear of the unit allowing up to144 inputs.Any multi-viewer instance simply requires an MVC output card and at least one VIP video processing card.
4K Capable 64 input multi-viewer
Front View (Processing cards)
Rear View (Input/Output Cards)
4K Capable 2x independent 64 input multi-viewer
Front View (Processing Cards)
Version 0.5
P
S
U
N
e
t
(
S
l
o
t
0
)
M
V
C
2
(
S
l
o
t
1
)
V
I
P
4
(
S
l
o
t
2
)
V
I
P
4
(
S
l
o
t
3
)
V
I
P
4
(
S
l
o
t
4
)
V
I
P
4
(
S
l
o
t
5
)
V
I
P
4
(
S
l
o
t
6
)
V
I
P
4
(
S
l
o
t
8
)
E
m
p
t
y
(
S
l
o
t
1
1
)
E
m
p
t
y
(
S
l
o
t
1
2
)
E
m
p
t
y
(
S
l
o
t
1
4
)
E
m
p
t
y
(
S
l
o
t
1
5
)
E
m
p
t
y
(
S
l
o
t
1
6
)
E
m
p
t
y
(
S
l
o
t
1
9
)
E
m
p
t
y
(
S
l
o
t
1
3
)
E
m
p
t
y
(
S
l
o
t
1
7
)
E
m
p
t
y
(
S
l
o
t
1
8
)
V
I
P
4
(
S
l
o
t
7
)
V
I
P
4
(
S
l
o
t
9
)
E
m
p
t
y
(
S
l
o
t
1
0
)
P
S
U
V
I
P
4
(
S
l
o
t
3
)
V
I
P
4
(
S
l
o
t
4
)
V
I
P
4
(
S
l
o
t
5
)
V
I
P
4
(
S
l
o
t
6
)
V
I
P
4
(
S
l
o
t
8
)
V
I
P
4
(
S
l
o
t
1
1
)
V
I
P
4
(
S
l
o
t
1
2
)
V
I
P
4
(
S
l
o
t
1
4
)
V
I
P
4
(
S
l
o
t
1
5
)
V
I
P
4
(
S
l
o
t
1
6
)
E
m
p
t
y
(
S
l
o
t
1
9
)
V
I
P
4
(
S
l
o
t
1
3
)
V
I
P
4
(
S
l
o
t
1
7
)
V
I
P
4
(
S
l
o
t
1
8
)
V
I
P
4
(
S
l
o
t
7
)
V
I
P
4
(
S
l
o
t
9
)
M
V
C
2
(
S
l
o
t
1
0
)
N
e
t
(
S
l
o
t
0
)
M
V
C
2
(
S
l
o
t
1
)
V
I
P
4
(
S
l
o
t
2
)
PSU
MPX-RNG (Slot 0)
RMP-MVCS8 (Slot 1)
RMP-SD8 (Slot 2)
RMP-SD8 (Slot 5)
RMP-SD8 (Slot 6)
RMP-SD8 (Slot 8)
Empty(Slot 11)
Empty(Slot 12)
Empty(Slot 14)
Empty(Slot 15)
Empty(Slot 16)
Empty(Slot 19)
Empty(Slot 13)
Empty(Slot 17)
Empty(Slot 18)
Empty(Slot 10)
RMP-SD8 (Slot 3)
RMP-SD8 (Slot 7)
RMP-SD8 (Slot 9)
RMP-SD8 (Slot 4)
Empty(Slot 19)
PSU
Net (Slot 0)
RMP-MVCS8 (Slot 1)
RMP-SD8 (Slot 2)
RMP-SD8 (Slot 3)
RMP-SD8 (Slot 4)
RMP-SD8 (Slot 5)
RMP-SD8 (Slot 6)
RMP-SD8 (Slot 7)
RMP-SD8 (Slot 8)
RMP-SD8 (Slot 9)
RMP-MVCS8 (Slot 10)
RMP-SD8 (Slot 11)
RMP-SD8 (Slot 12)
RMP-SD8 (Slot 13)
RMP-SD8 (Slot 15)
RMP-SD8 (Slot 16)
RMP-SD8 (Slot 17)
RMP-SD8 (Slot 18)
RMP-SD8 (Slot 14)
Rear View (Input/Output cards)
4K Capable 9x independent 8 input multi-viewer
Front View (Processing cards)
Rear View (Input/Output cards)
Any input combination between these extremes can be adopted along with the use of the audio IO cards to allow tailor made
solutions for any broadcast application.
Audio Handling
MP-xx frame – up to 8 audio input cards and up to 3 audio output cards are supported. Each analogue audio input card can
accept up to 32 channels with the digital input cards handling up to 32 AES pairs (64 digital channels). The maximum
number of audio input channels (from any source) supported is 1152.
Front view showing 544 analogue or 1088 digital channels to be monitored on up to 4 screens
Version 0.5
P
S
U
N
e
t
(
S
l
o
t
0
)
A
I
P
3
2
A
D
(
S
l
o
t
2
)
M
V
C
(
S
l
o
t
1
)
A
I
P
3
2
A
D
(
S
l
o
t
3
)
A
I
P
3
2
A
D
(
S
l
o
t
4
)
A
I
P
3
2
A
D
(
S
l
o
t
5
)
A
I
P
3
2
A
D
(
S
l
o
t
7
)
A
I
P
3
2
A
D
(
S
l
o
t
6
)
M
V
C
(
S
l
o
t
1
0
)
A
I
P
3
2
A
D
(
S
l
o
t
8
)
A
I
P
3
2
A
D
(
S
l
o
t
9
)
A
I
P
3
2
A
D
(
S
l
o
t
1
3
)
A
I
P
3
2
A
D
(
S
l
o
t
1
4
)
A
I
P
3
2
A
D
(
S
l
o
t
1
5
)
A
I
P
3
2
A
D
(
S
l
o
t
1
6
)
A
I
P
3
2
A
D
(
S
l
o
t
1
7
)
A
I
P
3
2
A
D
(
S
l
o
t
1
9
)
A
I
P
3
2
A
D
(
S
l
o
t
1
8
)
A
I
P
3
2
A
D
(
S
l
o
t
1
1
)
A
I
P
3
2
A
D
(
S
l
o
t
1
2
)
P
S
U
V
I
P
4
(
S
l
o
t
4
)
V
I
P
4
(
S
l
o
t
6
)
V
I
P
4
(
S
l
o
t
8
)
V
I
P
4
(
S
l
o
t
1
2
)
V
I
P
4
(
S
l
o
t
1
6
)
E
m
p
t
y
(
S
l
o
t
1
9
)
V
I
P
4
(
S
l
o
t
1
8
)
V
I
P
4
(
S
l
o
t
1
0
)
N
e
t
(
S
l
o
t
0
)
V
I
P
4
(
S
l
o
t
2
)
M
V
C
2
(
S
l
o
t
3
)
M
V
C
2
(
S
l
o
t
5
)
M
V
C
2
(
S
l
o
t
7
)
M
V
C
2
(
S
l
o
t
9
)
M
V
C
2
(
S
l
o
t
1
1
)
M
V
C
2
(
S
l
o
t
1
5
)
M
V
C
2
(
S
l
o
t
1
7
)
V
I
P
4
(
S
l
o
t
1
4
)
M
V
C
2
(
S
l
o
t
1
3
)
M
V
C
2
(
S
l
o
t
1
)
PSU
RMP SD8 (Slot 4)
RMP SD8 (Slot 6)
RMP SD8 (Slot 8)
RMP SD8 (Slot 12)
RMP SD8 (Slot 16)
Empty(Slot 19)
RMP SD8 (Slot 18)
Net (Slot 0)
RMP SD8 (Slot 2)
RMP SD8 (Slot 14)
RMP-MVCS8 (Slot 1)
RMP-MVCS8 (Slot 3)
RMP-MVCS8 (Slot 5)
RMP-MVCS8 (Slot 9)
RMP-MVCS8 (Slot 15)
RMP-MVCS8 (Slot 17)
RMP SD8 (Slot 10)
RMP-MVCS8 (Slot 7)
RMP-MVCS8 (Slot 11)
RMP-MVCS8 (Slot 13)
PSU
RMP A32 (Slot 4)
RMP A32 (Slot 6)
RMP A32 (Slot 8)
RMP A32 (Slot 12)
RMP A32 (Slot 16)
RMP-A32(Slot 19)
RMP A32 (Slot 18)
Net (Slot 0)
(RMP A32 Slot 2)
RMP A32 (Slot 14)
RMP-MVC (Slot 1)
RMP-A32 (Slot 3)
RMP-A32 (Slot 5)
RMP-A32 (Slot 9)
RMP-A32(Slot 15)
RMP-A32 (Slot 17)
RMP MVC (Slot 10)
RMP-A32 (Slot 7)
RMP-A32 (Slot 11)
RMP-A32 (Slot 13)
SMP-xx and MP-xx Key Features
• Modular multi-viewer family available in a 1U and 3U chassis
• SMP-xx frame has a maximum capacity of 32 input channels when used as a single multi-viewer or it
can be configured to support two independent multi-viewers within the same chassis
• MP-xx frame has a maximum capacity of 144 input channels when used as a single multi-viewer or it
can be configured to support multiple independent multi-viewers within the same chassis
• Two independently configurable HDMI (or DVI) outputs with paired SDI outputs up to 4K60 per
multi-viewer instance
• Support for 4K60 inputs via quad-link, dual 6G or direct 12G SDI
• Dedicated analogue and digital audio input/output cards available
• SMP-xx-R frame has two router matrices offering non-blocking routing for multi-viewer inputs AND a
stand-alone SDI router
• Genlocked inputs for flicker-free and full frame operation
• Teletext subtitles display (WST on SD-SDI or OP-47 on HD-SDI)
• AFD decoding for adjusting aspect ratio
• D-VITC and ancillary time code decoding and display (SDI/HD-SDI sources only)
• Audio metering is supported for up to 32 channels per video tile
• Audio metering may be sourced from SDI / HD-SDI embedded audio groups (PCM or Dolby E metadata
meter segment), or externally via optional analogue and AES/EBU (with SRC) interfaces
• Front panel mounted stereo audio socket for use as an assignable analogue audio monitor output
• Front panel mounted OLED display offering chassis and card status updates
• Alarms for video, audio and metadata, with outputs to, GPI O/Ps, LAN and/or SNMP traps
• Daily log files in CSV format accessible via LAN
• Input standard decode available as on-screen caption
• Assignable tallies
• Under Monitor Displays (UMD) entered via keyboard, LAN or serial cable, supporting Open, TSL and SAM
protocols
• Clock display receiving time information via NTP network protocol or LTC
• SMP-xx(-R) and MP-xx lightweight compact designs are both ideal for OB-vans and other space
restricted installations
• Low noise - temperature controlled fan speed
• Optional external backup power supply
• User-friendly set-up via browser software
Version 0.5
Rear Input/Output cards
MPX-RNG (network) rear
This is the only rear that has a different mechanical format between the 1U and 3U Frames. The signal connectivity is
identical, the only difference is the 3U version has a wider rear plate. All other rears are identical in form and functionality and
can be used in either sized frame.
MPX-RNG rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
SMP-xx SMP-xx-R MP-xx NET
√ √ √ √
Version 0.5
REF
TIME
CODE
RS422
LAN
GPIO
RMP-MVC rear
This is a 2K output rear Two independent video outputs are provided via each HDMI connector, each of which is paired
with a BNC providing a slaved SDI output. HDMI and SDI outputs contain embedded audio. A standard RJ45 connector is
provided as a LAN connection from which the multi-viewer browser control application is accessed.
RMP-MVC rear (connectors and pcb, shown here with H-Lok HDMI
retention brackets)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME
WITH THIS REAR
SMP-XX SMP-XX-R MP-XX MVC NET VIP3 VIP4 AIP/AOP
√ √ √ √ √ √ X √
Version 0.5
LAN
OUT 2
OUT 1
RMP-MVCS8-MBNC rear
This is a 4K capable output rear fitted with two Type A HDMI connectors Two independent 4K video outputs are
provided via each HDMI connector, each of which is paired with four of the micro-BNC coax connectors providing quadlink 12G SDI outputs. HDMI and SDI outputs contain embedded audio. A standard RJ45 connector is provided as a LAN
connection from which the multiviewer browser control application is accessed.
RMP-MVCS8-MBNC rear (connectors and pcb, shown here with H-Lok HDMI retention
brackets)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX MVC2 NET VIP3 VIP4SD AIP/AOP
√ √ √ √ √ X √ √
Version 0.5
LAN
HDMI 1
HDMI 2
SDI1-1
SDI1-2
SDI1-3
SDI1-4
SDI2-1
SDI2-2
SDI2-3
SDI2-4
RMP-SD4 rear
With four BNC connectors capable of accepting up to 3G SDI inputs and a 15 way D-type GPIO connector.
RMP-SD4 rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP3 NET MVC2 MVC VIP4 AIP/AOP
√ X √ √ √ X √ X √
INPUTS SUPPORTED
VIDEO CARD SD-60
HD-60/
FHD-30
FHD-60
VIP 3 √ √ √
NOTES:
Primarily designed to work with the four channel VIP3 processing cards either for use in SDI only architectures or in mixed
signal environments alongside the RMP-HM4 and RMP-CV4.
Version 0.5
SDI 4
SDI 3
SDI 2
SDI 1
GPIO
RMP-SD4R rear
Designed for the SMP-xx-R, the SD4R, is available fitted with eight miniature bncs offering four 3G SDI inputs and four 3G
SDI outputs. A 15 way GPI/O connector is also included.
RMP-SD4R rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP3 NET MVC2 MVC VIP4 AIP/AOP
X √ X √ √ X √ X √
INPUTS SUPPORTED OUTPUTS SUPPORTED
VIDEO CARD SD-60 HD-60/ FHD-30 FHD-60 SD-60 HD-60/ FHD-30 FHD-60
VIP 3 √ √ √ √ √ √
Version 0.5
OUT 4
OUT 3
OUT 2
OUT 1
IN 4
IN 3
IN 2
IN 1
GPIO
RMP-HM4 rear
Where source equipment is fitted with HDMI outputs, the HM4 offers four Type A HDMI inputs along with a 15 way GPI/O
connector.
RMP-HM4 rear (connectors and pcb, shown here with H-Lok HDMI retention
brackets)
FRAME
COMPATIBILITY
ASSOCI
ATED
CARD
OTHER CARDS THAT CAN BE USED IN
THE FRAME WITH THIS REAR
SMP-XXSMP-
XX-R
MP-
XX
VIP3 NET MVC2 MVC VIP4
AIP/A
OP
√ X √ √ √ X √ X √
VIDEO CARD HDMI STANDARDS
VIP3 SVGA (800x600 @ 60Hz) √ VIP3 1280x720 @ 60Hz √
VIP3 XGA (1024x768 @ 60Hz) √ VIP3 1366x768 @ 60Hz √
VIP3 SXGA (1280x1024 @ 60Hz) √ VIP3 960x540 @ 60Hz √
VIP3 UXGA (1600x1200 @ 60Hz) √ VIP3 720x480 @ 60Hz √
VIP3 1400x1050 @ 60Hz √ VIP3 1920x1080 @ 60Hz √
VIP3 852x480 @ 60Hz √ VIP3
1920x1080 @ 25,30Hz
(interlaced)
√
Version 0.5
HDMI 4
HDMI 3
HDMI 2
HDMI 1
GPIO
RMP-CV4 rear
For use with with composite inputs only, the CV4 is designed for cvbs applications providing four independent inputs via BNC
connectors. State of the art CVBS decoders use frame comb decoding techniques to provide optimum separation of
luminance and chrominance components and is ideally suited to CCTV applications or where the input source requires time
base correction.
RMP-CV4 rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP3 NET MVC2 MVC VIP4 AIP/AOP
√ X √ √ √ X √ X √
INPUTS SUPPORTED
VIDEO CARD CVBS
VIP 3 √
Version 0.5
CVBS 4
CVBS 3
CVBS 2
CVBS 1
RMP-SD4L rear
Utilising eight 3G SDI micro-BNC coax connectors, this rear has a loop-through output on each of its four video inputs in
order to ease connectivity issues where space is at a premium. A 15 way GPI/O connector is also included.
RMP-SD4L rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP3 NET MVC2 MVC VIP4 AIP/AOP
√ NO √ √ √ X √ X √
INPUTS SUPPORTED OUTPUTS SUPPORTED
VIDEO CARD SD-60 HD-60/ FHD-30 FHD-60 SD-60 HD-60/ FHD-30 FHD-60
VIP 3 √ √ √ √ √ √
Version 0.5
GPIO
SDI4
LOOP4
LOOP3
LOOP2
LOOP1
SDI3
SDI2
SDI1
RMP-SD8 rear
Paired with VIP4 processing cards, this rear allows up to eight 3G SDI inputs via micro-BNC coax connectors. This signal
architecture allows up to eight single 3G inputs, or up to four dual-link 6G inputs or two two quad-link 12G inputs – or a
combination of all three input types.
RMP-SD8 rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME
WITH THIS REAR
SMP-XX SMP-XX-R MP-XX VIP4 NET MVC MVC2 VIP3 AIP/AOP
√ X √ √ √ X √ X √
INPUTS SUPPORTED
VIDEO
CARD
SD-60 HD-60/
FHD-30
FHD-60 UHD-30 UHD-60
VIP 4
√ √ √ √ √
Version 0.5
SDI 8
SDI 7
SDI 6
SDI 5
SDI 4
SDI 3
SDI 2
SDI 1
RMP-SD8R rear
Paired with VIP4 processing cards, this rear allows up to eight 3G SDI inputs via micro-BNC coax connectors. This signal
architecture allows up to eight single 3G inputs, or four dual-link 6G inputs or two two quad-link 12G inputs – or a
combination of all three input types.
The SD8R is designed to be used with the router based SMP-xx-R family.
RMP-SD8R
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX VIP4 NET MVC MVC2 VIP3 AIP/AOP
X √ X √ √ X √ X √
INPUTS SUPPORTED ROUTER INPUTS SUPPORTED
VIDEO
CARD
SD-60 HD-60/
FHD-30
FHD-60 UHD-30 UHD-60 SD-60 HD-60/ FHD-30 FHD-60 UHD-30 UHD-60
VIP 4
√ √ √ √ √ √ √ √ √ √
Version 0.5
R IN 1
R IN 2
R IN 3
R IN 4
R IN 5
R IN 6
R IN 7
R IN 8
SDI 8
SDI 7
SDI 6
SDI 5
SDI 4
SDI 3
SDI 2
SDI 1
RMP-A32 rear
Audio input or output rears are fitted with two high density 44 way female ‘D’ connectors supporting a total of 32 audio input
channels (16 channels/connector). With the appropriate interface cable, the audio rear is capable of accepting analogue or
digital audio signals.
RMP-A32 rear (connectors and pcb)
FRAME COMPATIBILITY ASSOCIATED
CARD
OTHER CARDS THAT CAN BE USED IN THE FRAME WITH
THIS REAR
SMP-XX SMP-XX-R MP-XX AIP/AOP NET MVC MVC2 VIP4 VIP3
√ X √ √ √ √ √ √ √
Version 0.5
Audio
Channels:
1-16
Audio
Channels:
17-32
Processing cards
The VIP3 video processing card provides 4 video inputs. With the appropriate rears fitted, the combinations of video input
types supported are:
Input Supported RMP-SD4 RMP-SD4R RMP-SD4L RMP-HM4 RMP-CV4
4x SD/HD/3G-SDI √ √ √ X X
4x HDMI up to 1920x1200 @
60Hz
X X X √ X
4x composite video X X X X √
MV-VIP3 pcb
Version 0.5
The VIP4 video processing card utilises the latest generation of scaling technology in order to be able to process inputs up to
4K60. With the appropriate rears fitted, the combinations of video input types supported are:
Input Supported RMP-SD8 RMP-SD8R
Up to 8x SD/HD/3G-SDI √ √
2x 4K60 quad-link (12G) SDI digital video √ √
Up to 4x 4K30 dual-link (6G) SDI √ √
4x 6G-SDI direct √ √
2x 12G-SDI direct √ √
MV-VIP4 pcb
VIP4- designed to work with the new 4K capable output rear MPX-RMV2 and video output card MPX-MVC2-SD in order to
provide the highest resolution 4K I/O solution.
Version 0.5
MPX-MVC can be combined with VIP3 video processing cards to produce up to 2K60 outputs.
MV-MVC pcb
MPX-MVC2-LV can be combined with VIP3 or VIP4-LV video processing cards to produce up to 4K30 outputs.
MPX-MVC2-SD can be combined with VIP4-SD video processing cards to produce up to 4K60 outputs.
MV-MVC2-LV/SD pcb
Version 0.5
• AIPxxA analogue only audio input cards (up to 32 channels)
• AIPxxD digital only audio input cards (up to 32 AES/EBU pairs) with sample rate conversion for maximum flexibility
• AIP32AD analogue and digital audio input cards (up to 32 channels/AES/EBU pairs)
AIP32AD
The analogue and digital audio input cards are available in the following input configurations:
Analogue audio input
card
Max. no. of channels
supported
Digital audio input
card
Max. no. of AES pairs supported
(Channels)
AIP08A 8 AIP08D 8 (16)
AIP16A 16 AIP16D 16(32)
AIP32A 32 AIP32D 32(64)
• AOPxxA analogue audio output card capable of supporting up to 32 analogue channels
• AOPxxD digital output card that can support up to 32 AES/EBU pairs.
AOP-32D pcb
The analogue and digital audio output cards are available in the following input configurations:
Analogue audio output
card
Max. no. of channels
supported
Digital audio output
card
Max. no. of AES pairs
supported (Channels)
AOP08A 8 AOP08D 8 (16)
AOP16A 16 AOP16D 16(32)
AOP32A 32 AOP32D 32(64)
Version 0.5
Specifications
Main Frame SMP-xx and SMP-xx-R
Mechanical SMP-xx(-R) frame – 1U high 19” Rack Mounting Frame with removable front panel,
temperature controlled fan assisted ventilation, 6 card slots, separate rear connector
modules and power supply / fan status indicators.
The SMP-xx-R version is equipped with two SDI routers, one providing non-blocking
multiviewer inputs, the other, when used with the appropriate rears, acts as an
indpendeant non-blocking SDI router.
Outline Dimensions~: 445mm(W) x 511mm(D) x 44mm(H)
Weight: 6kg (full frame)
Power Connectors: AC - Single IEC Mains Socket
DC – Single 2-pole DC power socket
Consumption: Maximum power consumption 204W
Input current rating 2.5A AC, 8.5A DC
Fuses 1x 3.15A Fuse; 5x20mm ceramic body, Anti-
surge/Time delay inside IEC socket
Environmental Operating Temperature 0°C to 40°C
Relative Humidity 70% max, non-condensing
Ventilation Fan assisted. Front Inlet, rear exhaust
Compliance EMC – Emissions EU: EN55103-1
USA: 47 CFR: 2009, Part 15, Sub-part B (Class A)
EMC – Immunity EU: EN55103-1
Safety EN: EN60950-1
USA: Tested to UL1419 (3rd Edition)
Hazardous Material UK: RoHS-6 – Complies with EU Directive
Front panel Power supply and fan failure LED indicators on front panel
1 x OLED display and control knob
1 x USB type A port
1 x 6.35mm stereo audio socket
Version 0.5
Main Frame MP-xx
Mechanical MP-xx frame – 3U high 19” Rack Mounting Frame with removable front panel,
temperature controlled fan assisted ventilation, 20 card slots, separate rear connector
modules and power supply / fan status indicators.
Outline Dimensions~: 440mm(W) x 455mm(D) x 132mm(H)
Weight: 10.5kg (full frame)
Power Connectors: AC - Single IEC Mains Socket
DC – Single 2-pole DC power socket
Consumption: Maximum power consumption 576W
Input current rating 7A AC, 24A DC
Fuses 1x 3.15A Fuse; 5x20mm ceramic body, Anti-
surge/Time delay inside IEC socket
Environmental Operating Temperature 0°C to 40°C
Relative Humidity 70% max, non-condensing
Ventilation Fan assisted. Front Inlet, rear exhaust
Compliance EMC – Emissions EU: EN55103-1
USA: 47 CFR: 2009, Part 15, Sub-part B (Class A)
EMC – Immunity EU: EN55103-1
Safety EN: EN60950-1
USA: Tested to UL1419 (3rd Edition)
Hazardous Material UK: RoHS-6 – Complies with EU Directive
Front panel Power supply and fan failure LED indicators on front panel
1 x OLED display and control knob
1 x USB type A port
1 x 6.35mm stereo audio socket
Version 0.5
VIDEO INPUT CARDS
VIP4
8 video inputs per card:
SDI input standards
supported:
SD-SDI (SMPTE259M 270Mb): 525/60, 625/60
HD-SDI (SMPTE292M 1.5Gbs)
3G-SDI (SMPTE424M Level A Mapping 3Gbs)
6G-SDI (SMPTE ST-2081 6Gbs). Inputs 1, 3, 5 and 7.
12G-SDI (SMPTE ST-2082 12Gbs) using quad-link or 12G direct using specific rears .
Up to two 12G inputs/VIP4.
SD-Analogue: Composite (CBVS 1V P-P) available on certain rears
Embedded audio
Embedded audio derived from SDI (up to 16 channels per source)
HDMI
Dolby E meter segment metadata level metering (optional)
Video Processing Processing delay varies from 2-3 fields for interlaced video inputs, 2-3 frames for
progressive video inputs, depending on timing relationship between the input and
output.
Alarms Video inputs Loss of sync, loss of luminance, freeze frame
Audio inputs Loss of embedded or external audio, over-level, out of phase
channel pairs
Metadata
inputs
Loss of VITC (SDI only), loss of V-Chip (composite only), teletext
(analogue only), subtitles, video non-sync detection
Alarm
indication
Visual (in display), GPI, LAN, SNMP traps
Metadata Decoding
/monitoring
Teletext (WST) subtitles (ITU-R BT.653-3) SD-SDI only
OP-47 subtitles, SD- HD- 3G-SDI
AFD driving aspect ratio (SMPTE 2016-2007), SD- HD- 3G-SDI
WSS driving aspect ratio (ETSI EN 300 294), composite only
D-VITC timecode display (SMPTE-12M-2008 VITC), SD-SDI only
ATC timecode display (SMPTE-12M-2008 ATC), SD- HD- 3G-SDI
Version 0.5
VIP 3
4 video inputs per card
SDI input
standards
supported:
SD-SDI (SMPTE259M 270Mb): 525/60, 625/60
HD-SDI (SMPTE292M 1.5Gbs).
3G-SDI (SMPTE424M Level A Mapping 3Gbs)
SD-Analogue: Composite (CBVS 1V P-P) available on certain rears (please see the Summary
of rear connector modules table): PAL, PAL-M, NTSC, NTSC-4.43, SECAM
HDMI input
standards
supported:
SVGA (800x600 @ 60Hz)
XGA (1024x768 @ 60Hz)
SXGA (1280x1024 @ 60Hz)
UXGA (1600x1200 @ 60Hz)
1400x1050 @ 60Hz
852x480 @ 60Hz
1280x720 @ 60Hz
1366x768 @ 60Hz
960x540 @ 60Hz
720x480 @ 60Hz
1920x1080 @ 60Hz
1920x1080 @ 25,30Hz (interlaced)
In addition to the above, the HDMI receivers will handle any resolution with a clock frequency in the
range of 25MHz to 165MHz.
Embedded
audio
Embedded audio derived from SDI (up to 16 channels per source)
HDMI
Dolby E meter segment metadata level metering (optional)
Video
Processing
Processing delay varies from 2-3 fields for interlaced video inputs, 2-3 frames for progressive
video inputs, depending on timing relationship between the input & output.
Alarms Video inputs Loss of sync, loss of luminance, freeze frame
Audio inputs Loss of embedded or external audio, over-level, out of phase channel pairs
Metadata
inputs
Loss of VITC (SDI only), loss of V-Chip (composite only), teletext (analogue
only), subtitles, video non-sync detection
Alarm
indication
Visual (in display), GPI, LAN, SNMP traps
Metadata Decoding
/monitoring
Teletext (WST) subtitles (ITU-R BT.653-3) SD-SDI only
OP-47 subtitles, SD- HD- 3G-SDI
AFD driving aspect ratio (SMPTE 2016-2007), SD- HD- 3G-SDI
WSS driving aspect ratio (ETSI EN 300 294), composite only
D-VITC timecode display (SMPTE-12M-2008 VITC), SD-SDI only
ATC timecode display (SMPTE-12M-2008 ATC), SD- HD- 3G-SDI
Version 0.5
AUDIO INPUT CARDS
Up to 64 audio Channels per card
Analogue Up to 32 Channels per card.
Digital AES/EBU (up to 32 pairs (64 channels)/card with SRC (32kHz-192kHz re-
sampled to 48kHz)
Analogue and
Digital
Combined card that supports a combination of up to 64 channels
NETWORK CARDS
GPIO Global port 8 inputs / 4 outputs per multiviewer (assignable).
LTC SMPTE-12M unbalanced. >0.5Vpp
Version 0.5
Signal Output Cards
MPX-MVC-SD
FOR USE WITH THE VIP4 ONLY
2 x independent HDMI/DVI each with slaved SDI outputs
Video Standards
supported
HDMI output With embedded
audio
Slaved SDI output With embedded
audio
UHD 4K25 RGB 4:4:4
(3840x2160@25Hz)
✓ ✓
✓
1
✓
UHD 4K30 RGB 4:4:4
(3840x2160@30Hz)
✓ ✓
✓
1
✓
UHD 4K50 YCbCr 4:2:0
(3840x2160@50Hz)
✓ ✓
✓
2
✓
UHD 4K60 YCbCr 4:2:0
(3840x2160@60Hz)
✓ ✓
✓
2
✓
Notes:
1. SMPTE ST 2081-10 6Gbps supported
2. Depending on rear selected quad-link or SMPTE ST 2082-10 12Gbs supported
Audio Meter Scales and Ballistics
Overall dynamic range: Attack time: Decay time:
NORDIC:
54dB (+12 to -42dB) 10mSec 1.7Sec per 20dB decay
DIN PPM:
55dB (+5 to -50dB) 10mSec 2.8Sec per 24dB decay (from "Mark 7" to
"Mark 1")
BBC PPM:
24dB +3dB down "Mark 1"
(+12 to-12dB)
10mSec 2.8Sec per 24dB decay (from "Mark 7" to
"Mark 1")
VU:
23dB (+3 to -20dB) 300mSec 300mSec per 20dB decay
VU EXT:
60dB (+10 to -50dB) 300mSec 300mSec per 20dB decay
AES/EBU:
60dB (0 to -60dB) < 5ms 1.5Sec per 20dB decay
Version 0.5
Signal Output Cards
MPX-MVC
FOR USE WITH THE VIP3 ONLY
2 x independent HDMI/DVI each with slaved SDI outputs
Video Standards supported HDMI output With embedded
audio
Slaved SDI
output
With embedded
audio
720p50 (1280x720@50Hz)
✓ ✓ ✓ ✓
720p59.94 (1280x720@59.94Hz)
✓ ✓ ✓ ✓
720p60 (1280x720@60Hz)
✓ ✓ ✓ ✓
1080p50 (1920x1080@50Hz)
✓ ✓ ✓ ✓
1080p59.94 (1920x1080@59.94Hz)
✓ ✓ ✓ ✓
1080p60 (1920x1080@60Hz)
✓ ✓ ✓ ✓
XGA
(1024x768@60Hz)
✓
SXGA+ (1400x1050@60Hz)
✓
1600x1200@60Hz
✓
Audio Meter Scales and Ballistics
Overall dynamic range: Attack time: Decay time:
NORDIC:
54dB (+12 to -42dB) 10mSec 1.7Sec per 20dB decay
DIN PPM:
55dB (+5 to -50dB) 10mSec 2.8Sec per 24dB decay (from "Mark 7" to "Mark 1")
BBC PPM:
24dB +3dB down "Mark 1"
(+12 to-12dB)
10mSec 2.8Sec per 24dB decay (from "Mark 7" to "Mark 1")
VU:
23dB (+3 to -20dB) 300mSec 300mSec per 20dB decay
VU EXT:
60dB (+10 to -50dB) 300mSec 300mSec per 20dB decay
AES/EBU:
60dB (0 to -60dB) < 5ms 1.5Sec per 20dB decay
Version 0.5
MV HDMI and SDI video output standards
The following table summarises the video standards available from the two independent HDMI (or DVI) output connectors on
the RMP-MVC, RMP-DV2SD2 or RMP-MVC2 rears along with the corresponding outputs on each of their slaved SDI
connections.
Video outputs: 2 x
independent HDMI each with
slaved SDI outputs
HDMI
output
With embedded
audio
Slaved SDI output With embedded audio
Using the MPX-MVC output card with the VIP3 (please see the Video outputs up to 4K section for more details on
card/rear combinations available)
720p50 (1280x720@50Hz)
✓ ✓ ✓ ✓
720p59.94
(1280x720@59.94Hz)
✓ ✓ ✓ ✓
720p60 (1280x720@60Hz)
✓ ✓ ✓ ✓
1080p50
(1920x1080@50Hz)
✓ ✓ ✓ ✓
1080p59.94
(1920x1080@59.94Hz)
✓ ✓ ✓ ✓
1080p60
(1920x1080@60Hz)
✓ ✓ ✓ ✓
XGA
(1024x768@60Hz)
✓
SXGA+ (1400x1050@60Hz)
✓
1600x1200@60Hz
✓
Using the MPX-MVC-LC/SD output card with the VIP3 or VIP4 (please see the Video outputs up to 4K section for
more details on card/rear combinations available)
UHD 4K25 RGB 4:4:4
(3840x2160@25Hz)
✓ ✓
✓
1
✓
UHD 4K30 RGB 4:4:4
(3840x2160@30Hz)
✓ ✓
✓
1
✓
UHD 4K50 YCbCr 4:2:0
(3840x2160@50Hz)
✓ ✓
✓
2
✓
UHD 4K60 YCbCr 4:2:0
(3840x2160@60Hz)
✓ ✓
✓
2
✓
Notes:1. SMPTE ST 2081-10 6Gbps supported
2. Depending on rear selected quad-link or SMPTE ST 2082-10 12Gbs supported
Processing delay varies from 2-3 fields for interlaced video inputs, 2-3 frames for progressive video inputs,
depending on timing relationship between the input and output.
Version 0.5
Version 0.5
Loading...
