MODEL:

KDS-EN6, KDS-DEC6

P/N: 2900-300839 Rev 1 www.KramerAV.com

KDS-EN6, KDS-DEC6 - Overview

Contents

Overview 1

Terms 1 How to Access the Console 2

Astparam Configuration API 3

Overview 3 How to Access astparam 4 List of astparams 5 Getting KDS-6 Board's IP Address 24

Application Scenario: 25 FAQs: 26

Generic Configuration: 26 Unicast (KVM over IP) 32 Multicast (M to 1 group) 32 Mult icas t (M t o N group) 33 IIC 33 UART 34

Console APIs 36

Debug Console APIs 36 Link Manager APIs 37 Video Over IP Driver Statistic/Control APIs 37 Display Driver Statis tic/Control APIs 38 OSD APIs 38

Configurations APIs 40

IIC APIs 41 UART Port 1 APIs 41

Configuration Option List 42

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Overview

Kramer KDS Default is Telnet port 24 Use "root" to log in.

Overview

This document describes the commands that can be used for KDS-6 console. KDS-6 uses Linux OS and the console is operated by BusyBox shell. Using console APIs, developers can control KDS-6 firmware and extend the product's features and capabilities.

-6 is based on Aspeed A6.4.3 firmware.

Terms

No password is required.

• Commands starting with "$" – Console commands executed under the Linux shell console.

The default value of multicast IP (multicast_ip) is 225.0.10x.xxx. Please use this multicast_ip value.

• The ‘ast_send_event -1 xxx’ command has a new shortcut named ‘e’. All of the following

‘ast_send_evnt -1 xxx’ commands can be replaced with the shortcut command like ‘e xxx’. They are exactly the same.

KDS-EN6, KDS-DEC6 - Overview

Default is Telnet port 24 Use "root" to log in.

How to Access the Console

• Telnet

Every KDS-6 host/c lient FW has Telnet and a Telnet client built in. a developer can use one KDS-6's Telnet client to connect to any other KDS-6 board. Or write their own program using Telnet protocol to connect to any KDS-6 board through the Ethernet network.

• Web UI

Use this approach when you need to modify astparam and prefer to enter commands via a web interface instead of a console. To modify astparam via a web interface:

1. Connect to the device’s Web UI

2. Enter astparam commands in “System->Utilities->Console API command:”

Note: You can enter multiple commands in a single line, separated by a semicolon (;).

No password is required.

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Astparam Configuration API

Overview

KDS-6 firmware includes many configurable features. Most of the configuration are done using the “Configuration API” called astparam. astparam is the console command to access these system configurations.

astparam can be saved in flash ROM, so that system configuration is not lost when the system loses power. Typical applications of astparam are:

• Enable/disable firmware features like serial over IP or video wall.

• Configure factory default firmware features

• Prepare an SPI flash image for production, including default astparam settings.

• Enable/Disable firmware features on end customer side.

The format of astparam is a key=value string pair. For example, a astparam: “en_video_wall=y” means astparam key “en_video_wall”’s value is “y”. Both “key” and “value” are ANSI string and case sensitive. The firmware decides how to use it.

Note: The firmware does not validate the astparam. So, any type error could cause unexpected results. The advantage is that a user can add any astparam key/value pair, even if KDS-6’s reference firmware doesn’t need it. Both RO and RW astparams can be modified or even removed.

The firmware reserves two flash partitions for system configuration. One is read only (RO) the other is read-write (RW).

Note: BOTH ‘RO’ and ‘RW’ partitions are actually read/writable. Their usage is just defined differently.

The firmware treats the setting in the RO partition as the system’s factory default settings. It is recommended to save non-factory default changes in the RW partition (including the random ethaddr). When firmware boots up, it takes astparam in the following priority order: RW > RO > firmware default. Firmware uses the value in RW if the astparam exists. If the astparam is not available in RW partition, then the value in RO partition is used. Firmware hard coded value is used only when the astparam doesn’t exist in both RO and RW partition.

on a production line.

When the firmware starts up, both RO and RW configurations are read from flash and saved in RAM.

Note: All configuration modifications are saved in RAM until the "astparam save [ro]" command is called.

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

The process of "reset_to_default.sh" erases the RW partition but keeps the 'ethaddr' value (by rewriting it after partition erase.). Since everything in the RW is gone, the firmware takes values from the RO partition, which is the 'factory default'.

How to Access astparam

The most fundamental and powerful way to access astparam is through the “astparam” Console API command. Most of alternative approaches are just a wrap of the “astparam” command.

$ astparam OPTIONS [KEY] [VALUE]

OPTIONS

• r : read from RO partition cache file. [KEY] is required.

• w: write to RO partition cache file (not save to flash ROM yet). [KEY] and [VALUE] are

required. If [VALUE] is empty the [KEY] will be removed.

• g : read from RW partition cache file. [KEY] is required.

• s : write to RW partition cache file (not save to flash ROM yet). [KEY] and [VALUE] are

required. If [VALUE] is empty the [KEY] will be removed.

• flush : clear all settings in RW partition cache file including random generated MAC

address. "./astparam save" is needed to clear all settings in flash ROM.

• dump: dump all parameters in RW partition cache file.

• dump ro: dump all parameters in RO partition cache file.

• dd: dump all parameters in RW partition directly from flash ROM.

• dd ro: dump all parameters in RO partition directly from flash ROM.

• save: save all parameters in RW partition cache file into flash ROM.

• save ro: save all parameters in RO partition cache file into flash ROM.

Examples:

• Read "ip_mode" setting from RO partition cache file:

$./astparam r ip_mode

• Read "ip_mode" setting from RW partition cache file:

$./astparam g ip_mode

• Write "ip_mode" setting as "autoip" to RW partition cache file:

$./astparam s ip_mode autoip

• Clear all settings in RW partition cache file:

$./astparam flush

• Clear ip_mode setting in RW partition cache file:

$./astparam s ip_mode

• Write RW partition cache file back to SPI flash ROM’s RW partition:

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

scenario

pc2tv:

H/C

astaccess

Host: ‘y’ boot up default accept connection

H/C

multicast_on

Configure casting mode

y: Multicast mode

H/C

ui_feature

ignore_e_button_link

H/C

ignore_e_button_link

H/C

pwr_led_type

default:

H/C

en_log

‘y’ show debug message on debug

H/C

stop_on_boot_test_fa

H/C telnetd_param

‘-p 24’: use IP port 24.

-p 24

H/C

lm_link_off_timeout

15: 15 seconds

$./astparam save

• Write RO partition cache file back to SPI flash ROM’s RO partition:

$./astparam save ro

List of astparams

Generic Settings

Kramer Electronics Ltd.

from client. Client: ‘y’ boot up default auto connect to

host.

(bold is default)

usb_only:

n: Unicast mode

Client

console.

share_usb:

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

cs_gpio_inv

[>= A5.3.3] Invert 4-bits DIP switch value.

0000

H/C

soc_op_mode

[>= AST1520][>= A6.2.0] Config backward

0: as it is

H/C

web_ui_cfg

Used to customize Web UI. The default

board_revision

[>= AST1520] Used to indicate firmware

300:

Default value is '0000', means all 4bits (CH0,CH1,CH2,CH3) no invert. To invert CH1, for example, set the value to '0100'.

compatibility mode.

value is automatically generated based on enabled functions during first time boot up.

The value is a series of characters: e: essential functions (can’t be disabled) n: network v: video w: video wall a: audio (i2s) u: usb s: serial over ip r: IR

Character order does not matter.

Example 1: To enable all UI elements, set the value to ‘envwausr’.

Example 2: 'envas' means show ‘essential functions’, 'network', 'video', 'audio', and 'serial over ip' modules.

(bold is default)

1: AST1500 compatible

2: AST1510 compatible

Client

different kind of HW board design. 300: [Host] AST152x v1.x reference board. 301: [Host] AST1520 v2.x splitter loopback

design with HDCP 2.2 support

301:

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

ui_default_res

[>= A6.1.0] Change the bootup and GUI

640x480@60

ui_show_text

‘y’ to display diagnostic information on the

y: Display

(bold is default)

Client

default resolution. Default resolution is 640x480@60Hz. Note: System reboot is required for ui_default_res to be applied.

bottom of the GUI. ‘n’ to hide it.

n: Hide

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

ip_mode

static:

H/C

netmask

H/C

gatewayip

[> A 1.38]

H/C

hostname_prefix

ast: For AST1500

H/C

hostnamebydipswitch

Use default hostname_id based on 4-bits

H/C

hostname_id

Overwrite “hostnamebydipswitch”

H/C

ch_select

H/C

reset_ch_on_boot

Resets link related astparam on boot, to

y: enable

H/C

jumbo_mtu

[>= AST1510]

1500:

H/C

IP Network Setting

Kramer Electronics Ltd.

(bold is default)

Client

dhcp: autoip:

ipaddr H/C

ast2: For AST1510 ast3: For AST1520

DIP switch.

Host default is ‘y’ Client default is ‘n’

multicast_ip H/C

prevent the user from entering the wrong channel setting. The following astparam is cleared to the default value: ch_select multicast_ip hostname_id

multicast_ip_prefix Uses a different multicast IP prefix.

Default value is ‘225.0.10’ which means multicast IP is ‘225.0.10x.xxx’ where x’s value depends on 4-bits DIP switch.

n: disable

8000:

225.0.10 H/C

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

btn1_short

H/C

btn1_long

H/C

btn1_short_on_boot

H/C

btn1_short_on_eth_of

H/C btn1_long_on_eth_off

H/C

btn2_short

H/C

btn2_long

H/C

btn2_short_on_boot

H/C

btn2_long_on_boot

H/C

btn2_short_on_eth_of

H/C btn2_long_on_eth_off

H/C

btn_init

H/C

btn1_delay

H/C

btn2_delay

H/C

Button: (> A3.2)

Kramer Electronics Ltd.

(bold is default)

Client

btn1_long_on_boot H/C

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

no_video

y: disable VideoIP

H/C

ast_video_quality_mo

-1: Video mode

v_bcd_threshold

0: anti-dither off

v_1080i_to_720p

H/C

en_video_wall

H/C

profile

[< A6.0.0] Select ‘giga’ or ‘analog’.

auto:

v_chunk_size

[OP_MODE < 3] Used to control video

64512

v_type

[>= AST1520] Overwrite “video type”

0: VGA

H/C

Video over IP

Kramer Electronics Ltd.

[>= A6.x.x] Revised the naming to: auto, 10M, 50M, 100M, 150M, 200M. SoC V1 and V2 only support ‘auto’.

(bold is default)

n: enable VideoIP

0: Graphic mode

1: anti-dither 1 2: anti-dither 2

10M: 50M: 100M: 150M: 200M:

Client

network stream’s burst size. A smaller value smooths the Ethernet switch’s loading, but may causes video streaming performance issues.

Default value is ‘64512’. Use ‘7376’ when you want to smooth the video stream packets. Don’t touch this setting unless you know what you are doing.

v_ignore_cts7_33 HDMI compliant test (CTS 7-33) requires

the HDMI source to always output a DVI signal when the downstream sink is not an HDMI sink (EDID is not HDMI device). Set this option to ‘y’ to ignore this requirement.

setting. Default value is received from the GPIO pin (HDMI or VGA).

n: follow CTS y: ignore CTS

1: disable 2: HDMI 3: DVI

H/C

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

v_loopback_type

[>= AST1520] Set video loopback port

0: VGA

H v_output_timing_conv

[>= AST1520] Force specific video output

0: Pass-Through

v_eng_drv_option

[>= AST1520] 32bits bitmap VE driver

0: Default value

H/C

type. Overwrite HW GPIO setting. Default value is gotten from GPIO pin.

Default value when GPIO pin is set to enable:

AST1525: the same as v_type setting. AST1520: ‘board_revision’ == 301, default 2 (HDMI). If the board is ‘301’ type and has VGA loopback, please set v_loopback_type to ‘0’. v_dual_port to ‘1’. Otherwise [<= A6.2.6] Default as v_type setting. [> A6.2.6] Default as 0 (VGA).

(bold is default)

1: disable 2: HDMI 3: DVI

Client

ert

timing.

Examples: 00000000: Pass-Through 80000010: Full HD 1080p60 8000001F: Full HD 1080p50 8000005F: Ultra HD 2160p30 8000005E: Ultra HD 2160p25 80000004: HD 720p60 81000061: WXGA 1366x768@60 81000040: WXGA+ 1440x900@60 81000051: WUXGA 1920x1200@60 8100003C: SXGA+ 1400x1050@60

options to tweak driver behavior. Default value is 0.

0x00000001: [>=A6.0.0][Host] Convert 2160p30Hz to 1080p

0x00000002: [>=A6.0.0][Host] Convert 2160p60Hz (YUV420) to 1080p60Hz

0x00010000: [>=A6.1.0][Client] Do not black out after switching to new video source

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

v_dual_port

[>= AST1520] Dual output mode. Client

1: enable

H/C

v_rx_drv

[>= A6.0.0] Used to specify HDMI

cat6023: for

v_src_unavailable_tim

Wait for a v_src_unavailable_timeout ms

10000: 10 seconds

v_turn_off_screen_on

Turn off video output sync after

y: Turn off

v_analog_edge_

[>= A6.1.12] For VGA analog video input

37: default value

loopback_edid_patch

Copy EDID patch option for local

00000000

eout

set to ‘1’ to output video signal to both VGA and HDMI port. Host set to ‘1’ to output HDMI input to VGA loopback port. Default value:

Host: 0 Client: 1

receiver driver used. Default value for different SoC version:

AST1500: cat6023 AST1510: cat6023 AST1520: it6802 AST1525: it6802

before entering power save. Set to ‘-1’ means never timeout.

(bold is default)

0: disable

IT6604, IT6605 chip

it6802: for IT6802 chip

-1: never timeout

Client

_pwr_save

connected host stops streaming video to client.

v_rx_drv_option Special bitmap options for HDMI receiver

driver. (IT6604, IT6802…) 0x00000002: Always report HDMI audio as 2Ch 48KHz 0x00000004: Always report HDMI audio is ON

detect

only. Used to adjust edge detection threshold value. Default value should be fine in most of cases. Increase the value when edge detection is not accurate. Valid range is 0~255. Good value range: 15~64. Set the value too high or too low may cause bad result.

n: Do not turn off. Will switch back to GUI screen

0: default

loopback video port.

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

remote_edid_patch

Copy EDID patch option for remote client.

v_input_select

[>=AST1520][>=A6.3.0]

auto

H v_dual_input

[>=AST1520][>=A6.3.0]

y: has

Default values: AST1500: 00230017 AST1510: 00000005 AST1520/AST1525: [FW < A6.3.0] 00000000 [FW >= A6.3.0] 00000001

Configure different types of input select mode: auto: auto detect. always controlled by GPIO. detect_sync: auto switch after video lost fixed: fixed selection

Specify if the HW board has dual input port or not. This astparam is optional. The FW will automatically detect the HW configuration based on the availability of EDID ROM of both ports.

(bold is default)

detect_sync fixed

n: doesn’t have

Client

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

edid_use

By design, all connected client and host

primary:

H/C

v_hdmi_hdr_mode

[FW >= A6.3.0]

0: HDR

loopback video port’s EDID is received by host’s VE driver. All EDID info rm a tion also contains the ‘edid_use’ flag. The host VE driver will ONLY write the received EDID into EEPROM when the ‘edid_use’ is set to ‘primary’. So, ‘edid_use’ flag is used to control whether a host should write a received EDID into EEPROM or not. Different casting mode has different ‘edid_use’ default value.

By default: Unicast Mode: All client’s ‘edid_use’ will ALWAYS be ‘primary’. host loopback’s ‘edid_use’ default is ‘primary’. Multicast Mode: All host and client ‘edid_use’ default is ‘secondary’. And “press and hold Button 2 on device reboot” can force the device to be ‘primary’. In most of cases, leaving ‘edid_use’ as default is fine.

(bold is default)

secondary:

Client

passthrough 1: Force HDR off

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

en_video_wall

Enable video wall feature. Please also

y: enable

H/C

vw_rotate

[>= AST1520] Clock-wise rotate output

0: No rotate

hdcp_always_on

[Host >=A5.3.1]

y: enable

H/C

hdcp_always_on_22

[Host >=A6.0.0]

y: enable

H/C v_reject_hdcp

Don’t accept HDCP video source.

y: enable

hdcp_cts_option

[FW >= A6.2.0] 32bits bitmap options for

0x00000000:

H/C

Video Wall

Kramer Electronics Ltd.

(bold is default)

check the value of astparam ,web_ui_cfg,

n: disable

for the video wall Web UI.

picture.

Console API:

3: 180 degree 6: 270 degree

echo 3 > /sys/devices/platform/display/vw_rotate

HDCP

Key Description Value

(bold is default)

Client

Host/ Client

[Client >=A6.1.0]

n: disable

Always enable HDCP 1.4

[Client >=A6.1.0]

n: disable

Always enable HDCP 2.2.

n: disable

HDCP CTS test. 0x80000000: Disable auto SiI9678/9679 firmware update. 0x00000001: HDCP 2.2 Only firmware 0x00000002: HDCP 1.x Only firmware

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

no_usb

H/C

share_usb

Default value: (when

H/C

share_usb_auto_mod

When ‘share_usb_auto_mode == y’,

H/C

share_usb_on_first_

[>A6.1.8] Applied to ‘share_usb == y’

y: auto connect first

usb_set_addr_hack

It is a hack for some buggy BIOS to be

0: disable

usb_hid_urb_interval

Set to 35 to resolve some USB HID long

0: ASAP

usb_quirk

[>=A5.3.3] 32bits bitmap options for

H usb_fast_switch

Set to ‘y’ to enable ‘usb fast switch’

n: Disable

USB over IP

Kramer Electronics Ltd.

peer

‘share_usb_auto_mode’ is ‘n’) Multicast mode: ‘share_usb = y’. Unicast mode: ‘share_usb = n’.

‘share_usb’ setting will automatically change depends on the setting of casting mode (‘multicast_on’).

mode. When value is ‘y’, the first connected

client automatically requests USBoIP function. By enabling this feature, USBoIP automatically enabled when there is only one client connected to host under multicast mode.

(bold is default)

peer n:

Client

able to recognize USBoIP devices. The problem is rarely seen.

latency issue. Applies to both KMoIP and USBoIP.

resolving some vhub compatibility issues. VHUB_QUIRK_BULK_SSPLIT (0x1UL << 0)

mode. This enhances about 2 seconds of USB switching time, but sac r ifices video switching time from 2 to 5 seconds.

1: enable

35: 35ms

y: Enable

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

usb_default_policy

The default/global exporting policy used

auto_export

usb_conflict_policy

Policy used when a device has different

auto_export

usb_disable_classes

Policy setup to disable per USB classes.

per_interface

usb_enable_classes

Policy setup to enable per USB classes.

same as

usb_disable_devices

Policy setup to disable per USB’s PnP ID.

usb_enable_devices

Policy setup to enable per USB’s PnP ID.

USB over IP Exporting Policy: (> A 5.2.2)

Kramer Electronics Ltd.

when a specific policy is not available.

interfaces with conflict exporting policy.

(>A5.1.0 b1701)

There is no default value. Each class should be separated by a space. For example, usb_disable_classes=audio video printer.

(bold is default)

no_auto_export

audio comm hid physical still_image printer mass_storage cdc_data cscid content_sec video personal_healthcar e audio_video diagnostic wireless_controller misc app_spec vendor_spec

Client

There is no default value. Each class should be separated by a space. For example, usb_enable_classes=audio video printer.

There is no default value. Each device should be separated by a space. For example, usb_disable_devices=0781:000c 0770:1234.

“usb_disable_class es”

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

There is no default value. Each device

should be separated by a space. For example, usb_enable_devices=0781:000c 0770:1234.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

no_kmoip

Enable/disable KMoIP function.

y: disable KMoIP

H/C

kmoip_ports

Specify which client USB port can use

all: all USB ports

kmoip_hotkeys

Specify 8 set of hotkeys.

kmoip_token_interval

This is a per client setting. Set the idle

100

usb_busid_map

A mapping list to map USB busid to USB

kmoip_poll_interval

[FW >= A6.3.0] Used to set KMoIP’s USB

H/C

KMoIP: (> A 5.1.0)

Kramer Electronics Ltd.

KMoIP function when USBoIP session is running. The value can be ‘all’ or a list of port numbers, Ex: ‘1 2’. USB port number can be re-mapped by ‘usb_busid_map’ astparam.

(bold is default)

n: enable KMoIP

1: USB port 1 2: USB port 2 3: USB port 3 4: USB port 4 5: USB port 5

Note: Firmware version A5.1.0 ~ A5.1.4 uses ‘all’ as default value. The value was changed to ‘1 2’ starting from A5.2.1.

Client

timeout value (in milliseconds) for holding an access token. For example, the default value is 100ms, which means once client A acquires keyboard/mouse access, other clients can only successfully acquire the access (token) after client A is idle longer than 100ms. Normally, you don’t need to set this value (leave it as default). It is used to work around a bad mouse, which keeps reporting pointer activities and hence blocks all other client keyboard/mouse input.

port. Use default value unless you have a different hardware layout.

poll interval. Both host and client must be set to the same value. Unit is in ms.

Default value should be good for most

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

cases:

AST1500: 35 AST1510: 35 AST1520: 10 [FW >=A6.3.0], 35 [FW <

A6.3.0]

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

no_i2s

y: disable I2SoIP

H/C

a_io_select

[FW >= b1733] Used to select audio input

auto:

H/C

Audio over IP (I2S over IP)

Kramer Electronics Ltd.

source. Host: auto: auto select analog when host’s

analog line in plugged hdmi: fixed hdmi audio analog: fixed analog audio/in Client: auto: auto dual output. hdmi: fixed hdmi audio out analog: fixed analog audio out/in

[FW >= A6.1.1][>=AST152x] Set this on client to select audio output port. Default is ‘auto’ which means dual output.

[FW >= A6.3.0] [>=AST151 0][Host Only ] Host add extra ‘auto_1’ and ‘auto_2’ mode and redefined ‘auto’. auto: When HDMI/DVI video port is used, auto select audio port per analog line in plug. When VGA video port is used, ALWAYS use analog audio port. auto_1: Always select audio port per analog line in plug. auto_2: Always select audio port per video port used. When HDMI/DVI video port is used, HDMI always use HDMI audio port. When VGA video port is used, always use analog audio port.

(bold is default)

n: enable I2SoIP

hdmi: analog:

[FW>= A6.3.0][Host Only] auto_1: auto_2:

Client

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

a_analog_in_vol

[>=AST1510][FW >= A6.3.0]

echo [value] >

-1,0,1,2 ~,100

H/C

a_analog_out_vol

[>=AST1510][FW >= A6.3.0]

-1,0,1,2 ~,100

H/C

Key

Description

Value

Host/

no_ir

H/C

Set analog audio’s input volume. Range from 0 to 100 %.

Default value ‘-1’ means use driver builtin default value.

This setting requires system reset to take effect. To runtime change the volume, please use following command:

/sys/devices/platform/150 0_i2s/analog_in_vol

Set analog audio’s output volume. Range from 0 to 100 %. Default value ‘-1’ means use driver builtin default value.

This setting requires system reset to take effect. To runtime change the volume, please use following command:

(bold is default)

Client

IR over IP

echo [value] > /sys/devices/platform/150 0_i2s/analog_out_vol

(bold is default)

Client

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Key

Description

Value

Host/

no_soip

y: Disable SoIP

H/C

soip_type2

H/C

soip_guest_on

H/C s0_baudrate

115200-8n1

H/C

soip_type2_token_tim

[>=A1.38]

1,2,3... seconds

H/C ch_select_soip2

[>=A5.3.0]

N/A

Key

Description

Value

Host/

no_pwrbtn

H/C

Serial over IP

Kramer Electronics Ltd.

eout

(bold is default)

Client

n: Enable SoIP

GPIO over IP (Push Button over IP)

(bold is default)

Client

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Astparam Configuration API

Getting KDS-6 Board's IP Address

Kramer KDS-6 FW default runs "static ip" and uses the following address: 192.168.1.39. If the device is set to "autoip" and uses 169.254.xxx.xxx private IP domain, the IP of the target

KDS-6 board can be resolved by its hostname using mDNS protocol.. The following are the methods of resolving the IP address using "autoip" mode:

• Client's GUI – The client's GUI displays the client's IP address and the connected host's IP

address.

• Console APIs – Two console APIs are provided:

• astresname: use this command to resolve a target's IP address by providing target's

hostname.

• node_list: use this command to list all KDS-6 boards' hostname and IP address.

• From PC – Use the mDNS libraries, such as:

• Bonjour

• pyZeroConfig

• From PC: Developer can reference to "node_list" sample code to implement PC version of

node_list.

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Application Scenario:

Application Scenario:

With Console APIs, developers have more controls over KDS-6 FW, enabling development of new application scenarios. Console APIs are designed to support following application scenarios:

• KVM over IP: Extension of built-in 1 to 1 unicast mode. The client is able to choose which

host to connect to. Console APIs provide APIs for developers to enable a client to connect to a specific host.

• Multicast M to 1 group: Extension of built-in multicast mode. In this mode, there are

multiple video sources but a single group of monitors. This group of clients always displays the same video source from one of the hosts. Console APIs provide APIs to enable a host to change video source for display.

• Multicast M to N group: Extension of built-in multicast M to N mode. In this mode, there are

multiple video sources and multiple groups of monitors. Console APIs provide APIs to enable clients to join different multicast groups.

• Extra IIC remote communication:

• Extra UART port remote communication:

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

FAQs

Generic Configuration:

How do I discover all KDS-6 boards in the same LAN?

1. Use Telnet or the debug console to connect to the target board.

2. Start discover all: $./node_list

3. Start discover hosts: $./node_list -t host

4. Start discover clients: $./node_list -t client

The results appear on the console.

How do I use the node_list feature without going through KDS-6 board? For example, using a PC.

Request a "node_list" sample code.

How do I find the target client board's current multicast group?

1. Use Telnet or the debug console to connect to the target board.

2. Get the current multicast ip: $./astparam g multicast_ip.

3. To read the default value from the DIP switch: $./astconfig channel

The result is a four bits value (B0B1B2B3). that maps to multicast ip 225.0.B0.B1B2B3.

How do I turn on/off the debug console's debug message?

• To turn off: $dmesg -n 1 && setconsole /dev/ttyS1

• To turn on: $dmesg -n 8 && setconsole -r

How do I configure IP settings?

KDS-6 firmware supports three kinds of ip mode settings:

• autoip: 169.254.xxx.xxx private IP domain is used and auto-generated on boot.

• dhcp client: Use DHCP client to get an IP address. A DHCP server is required to use this

mode.

• static ip: Use a static IP address, th at can be configured through th e Console API.

KDS-EN6, KDS-DEC6 - FAQs

1. To configure the IP mode: $./ astparam s ip_mode mode (where "mode" can be: autoip,

dhcp, static)

2. To configure a static IP address:

• IP: $./astpara m s i paddr xxx.xxx.x xx.xxx

• Netmask: $./astparam s netmask xxx.xxx.xxx.xxx

• Default gateway: $./astparam s gatewayip xxx.xxx.xxx.xxx

3. Reboot the system to apply the above IP configuration changes.

How do I configure hostname_id?

Host:

1. hostname_id will overwrite “hostnamebydipswitch” setting.

Kramer Electronics Ltd.

2. Set hostname_id by: $./astparam s hostname_id XXXX

3. If you want to save the setting into flash and keeps the setting after reboot:

• $./astparam s reset_ch_on_boot n

• $./astparam save

4. Trigger hostname change: $./ast_send_event -1 e_chg_hostname

Client:

1. Set hostname_id by: $./astparam s hostname_id XXXX

2. If you want to save the setting to flash and keep the setting after reboot:

• $./astparam s reset_ch_on_boot n

• $./astparam save

3. Trigger hostname change: $./ast_send_event -1 e_chg_hostname

Note: See hostname_id in the Configuration Option List section on page 42

for details

What is the relationship between hostname and hostname_id?

KDS-6 board's "hostname" is constructed by "hostname_id". For example:

• For a host board with "hostname_id" as "ABCD", the board's "hostname" is "ast-

gatewayABCD". The board's IP can by resolved by $./astresname ast-gatewayABCD.local

• For client board with "hostname_id" as "1234", the board's "hostname" is "ast-client1234".

The board's IP can be resolved by $./astresname ast-client1234.local

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

How do I dynamically toggle between Graphic Mode and Video Mode?

1. Use Telnet or the debug console to connect to the host board.

2. Current quality mode can be get by: $cat /sys/devices/platform/videoip/QualityMode

3. Toggle quality mode by sending a "button 2" press event:

$./ast_send_event -1 e_button_pairing

How do I dynamically change Anti-Dithering mode?

1. Use Telnet or the debug console to connect to the host board.

2. Get the current quality mode: $cat /sys/devices/platform/videoip/bcd_threshold

3. Toggle anti-dithering mode by sending a "button 2 long press" event:

$./ast_send_event -1 e_button_pairing_1

How do I dynamically change snoop mode?

1. Use Telnet or the debug console to connect to the host board.

2. Get the current video loopback state:

$cat /sys/devices/platform/videoip/LoopbackEnable

• 0: currently not enabled

• 1: enabled

3. Toggle "snoop" mode by sending a "button 2" long press event:

$./ast_send_event -1 e_button_pairing_1

How do I dynamically connect/disconnect a client?

1. Use Telnet or the debug console to connect to the client board.

2. Get the current link manag er stat e: $cat /var/ast_device_status

See Link Manager APIs on page 37

3. Toggle the "link" mode by sending a "button 1" event UNDER stable state:

Wait state "s_idle" or "s_srv_on" $./ast_send_event -1 e_button_link

for details.

How do I dynamically enable/disable remote access (host)?

1. Use Telnet or the debug console to connect to the host board.

2. Get the curr ent link manager state: $cat /var/ast_device_status

See Link Manager APIs on page 37

for details

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

3. Toggle the "link" mode by sending a "button 1" event UNDER stable state:

Wait state "s_idle" or "s_srv_on" or "s_attaching" $./ast_send_event -1 e_button_link

How do I force update EDID of a target client?

1. Use Telnet or the debug console to connect to the client board.

2. Wait for link manager state "s_srv_on"

$echo primary > /sys/devices/platform/videoip/edid_use

How do I force update EDID of the video loopback port (host)?

1. Use Telnet or the debug console to connect to the host board.

2. Wait for link manager state "s_srv_on" or "s_attaching"

$echo primary > /sys/devices/platform/videoip/edid_use

Under multicast USB mode, how do I know the current USB state of a client?

1. Use Telnet or the debug console to connect to the client board.

2. Dump the link manager state by:

$./ast_send_event -1 e_debug /usr/local/bin$ cat lm_params [FW >= A3.20] lmparam g SHARE_USB_STATE

3. The "SHARE_USB_STATE" is the current USB state.

s_idle: Stopped USB redirection s_srv_on: Using USB redirection others states: Not stable state

How do I find the status of the video source?

• When video source is not available:

• Host: $cat /sys/devices/platform/videoip/State will be DETECTING_MODE

• Client: $cat /sys/devices/platform/videoip/State will be WAITING_HOST_MODE

• When video is streaming

• Host: $cat /sys/devices/platform/videoip/State will be OPERATING

• Client: $cat /sys/devices/platform/videoip/State will be OPERATING

How do I check if the Ethernet cable is connected and works?

$cat /sys/devices/platform/ftgmac/link_state

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

How do I know which client (IP) is using the host's USB redirection under multicast mode?

1. Use Telnet or the debug console to connect to the host board.

2. Request link manager's status by: $./ast_send_event -1 e_debug

3. Get the client's IP address by: /usr/local/bin$ cat lm_params | grep USB_CLIENT_IP

How do I know whether a monitor is connected?

1. Use Telnet or the debug console to connect to the host or client board in interests.

2. $cat /sys/devices/platform/display/monitor_info | grep "attached="

How do I dump the attached monitor's EDID?

1. Use Telnet or the debug console to connect to the host or client board in interests.

2. $cat /sys/devices/platform/display/monitor_info

How do I know if the video timing (resolution...) is in use?

1. Use Telnet or the debug console to connect to the client board.

2. $cat /sys/devices/platform/display/timing_info

How do I get the device’s hostname?

1. Use Telnet or the debug console to connect to the device.

2. For the short version of hostname: $lmparam g HOSTNAME_ID

3. For the long version of hostname: $hostname

How do I get the device’s IP address?

1. Use Telnet or the debug console to connect to the device.

2. $lmparam g MY_IP

How do I get the device’s MAC address?

1. Use Telnet or the debug console to connect to the device.

2. $lmparam g MY_MAC

3. [A3.50] Query current connected host IP on client:

4. Use Telnet or the debug console to connect to the client.

5. $lmparam g GWIP

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

How do I stop a client’s connection?

1. Use Telnet or the debug console to connect to the client.

2. $e e_stop_link

How can a client request USB redirection access under multicast mode?

1. Use Telnet or the debug console to connect to the client.

2. $e msg_e_request_usb

Note: If the client currently has USB redirection access, the above command stops the redirection session. You can query the current USB redirection status to avoid this condition.

How do I configure as multicast mode?

1. Use Telnet or the debug console to connect to the target device.

2. $astparam s multicast_on y

3. Config USB over IP mode:

• $astparam s share_usb_auto_mode y

4. $astparam save

5. $reboot

How do I configure as unicast mode?

1. Use Telnet or the debug console to connect to the target device.

2. #astparam s multicast_on n

3. Config USB over IP mode:

• [>= A3.54]: $astparam s share_usb_auto_mode y

• [< A3.54]: $astparam s share_usb n

4. $astparam save

5. $reboot

Can I overwrite multicast IP?

There are 2 ways to overwrite the multicast IP:

• astparam "multicast_ip" – you must set "reset_ch_on_boot" to "n" and do the "astparam

save" command to save it into flash ROM, so that the setting won't disappear after box reset.

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

• astparam "multicast_ip_prefix" – used to construct the default multicast ip value's prefix.

When "multicast_ip" is not set, firmware is construct default multicast ip as ${MULTICAST_IP_PREFIX}${ch0}.${ch1}${ch2}${ch3}. For example, the default value of "multicast_ip_prefix" is "225.0.10". So, for a DIP switch setting of 0110, the default multicast ip is 225.0.100.110.

Unicast (KVM over IP)

How can a client connect to a specified host under unicast mode?

1. Use Telnet or the debug console to connect to the client board.

2. [>= A5.1.0] Change multicast ip: $./astparam s multicast_ip 225.0.B0.B1B2B3 =>

where B0,B1,B2,B3 are mapped to the 4-bits DIP switch

3. Set target ch_select as target host's hostname_id or IP:

hostname_id: $./astparam s ch_select hostname_id IP: $./astpara m s ch_selec t xxx.xxx.xxx.xx x

4. Trigger client to re-connect: $./ast_send_event -1 e_reconnect

Multicast (M to 1 group)

How to change Host's multicast group from XXXX to 1001?

1. Use Telnet or the debug console to connect to the host board.

2. Stop Link: $./ast_send_event -1 e_stop_link

3. Change multicast ip: $./astparam s multicast_ip 225.0.1.001

4. Change the hostname_id: $./astparam s hostname_id 1001

5. Trigger hostname change: $./ast_send_event -1 e_chg_hostname

6. If you want to save the setting into flash and keep the setting after reboot:

$./astparam s reset_ch_on_boot n $./astparam save

7. Restart Link: $./ast_send_event -1 e_reconnect

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

Multicast (M to N group)

How to change the target client board's multicast group?

1. Use Telnet or the debug console to connect to the target board.

2. Change multicast ip: $./astparam s multicast_ip 225.0.B0.B1B2B3 => where

B0,B1,B2,B3 are mapped to the 4-bits DIP switch

3. Change the ch_select to connect to: $./astparam s ch_select B0B1B2B3

4. If you want to save the setting into flash and keep the setting after reboot:

$./astparam s reset_ch_on_boot n $./astparam save

5. Trigger client to re-connect: $./ast_send_event -1 e_reconnect

IIC

How to read/write target board's IIC channel?

1. Use Telnet or the debug console to connect to the target board.

2. All following values are treated as hex number

3. [>=A3.0] Initial IIC bus: $echo BusNum BusSpeed > /sys/devices/platform/i2c/bus_init

4. Setup the IIC slave's address: $echo BusNum DevAddr >

/sys/devices/platform/i2c/io_select

5. To read offs et X:

$echo X 1 > /sys/devices/platform/i2c/i_range $cat /sys/devices/platform/i2c/io_value

6. To write offset X to value Y: $echo X Y > /sys/devices/platform/i2c/io_value

Why is the sysfs approach used for IIC access?

IIC access consumes a very high percentage of the CPU resources. Using the sysfs approach, we ensure that developers' IIC access won't impact system performance.

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

UART

How to read/write the target board's UART port 1 (/dev/ttyS0)?

1. Make sure "Serial over IP" feature is disabled. (Reboot is needed for taking effect.)

2. Use telnet or debug console to attach to target board.

3. [~A1.32]

• Use stty to configure the UART port 1. Ex: $stty 115200 -F /dev/ttyS0 => set UART

port 1's baud rate to 115200.

• To start read: $cat /dev/ttyS0 & => UART data will be redirected to console

• To sto p read: $ pkill c at

• To start write: $cat > /dev/ttyS0 => console input will be redirected to UART

• To stop write: press "ctrl+c" (0x03)

4. [A1.33~]

• Use "microcom" to direct access /dev/ttyS0.

ex: microcom -t 10000 -s 115200 -X /dev /ttyS0 Please google "busybox microcom" for usage details

How to configure UART port 1 (/dev/ttyS0) for non-Serial over IP usage?

• UART port 1 is used for "Serial over IP" feature. Developers who want to manually control

UART port 1 need to disable "Serial over IP" feature.

• To configure UART port 1, please use "stty" command. See Console APIs on page 36 for

details.

How to enable debug console repeater mode?

1. Use the host debug console to Telnet to client.

2. Create pipe: $mknod p1 p && mknod p2 p

3. Enable bi-directional repeater mode by:

Host:

• Start read: $cat p1 &

• Start write: $cat > p2

Client:

• Start read: $cat p2 &

• Start write: $cat > p1

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - FAQs

[A1.2 Firmware] How to have functions like Serial over IP without going through the host board's UART port 1? For example, controlling all host/client boards through a network attached PC.

We call it "Serial over IP guest mode". Please request sample code if you need this feature.

KDS-EN6, KDS-DEC6 - Console APIs

Console APIs

Debug Console APIs

● Turn on/off application debug message

○ NA ME: setconsole ○ EXAMPLE:

■ Turn off: $setconsole /dev/ttyS1

■ Turn on: $setconsole -r

● Turn on/off kernel debug message

○ NA ME: dmesg ○ EXAMPLE:

■ Turn off: $dmesg -n 1

■ Turn on: $dmesg -n 8

Kramer Electronics Ltd.

● Reboot system

○ NA ME: reboot ○ EX AMPLE: $reboot

● Telnet client

○ NAME: telnet ○ EXAMPLE:

■ t elnet to IP 169.254.0.101 port 24

■ $t elnet 169.254. 0.101 24

■ telnet to ast-client0000.local port 24

■ $telnet ast-client0000.local 24

● List all KDS-6 devices:

○ NA ME: node_list ○ OPTIONS

■ t : specif y the device type to list

○ EXAMPLE

■ Lis t all clients:

■ $./node_list -t client

■ List all hosts:

■ $./node_list -t host

● Get IP from hostname:

○ NA ME: astr esname ○ EXAMPLE:

■ G et "ast-gateway0001.local"'s IP address:

KDS-EN6, KDS-DEC6 - Console APIs

■ $./astresname ast-gateway0001.local

● To kill a running process by process name:

○ NAME: pkill ○ EXAMPLE:

■ kill a process named "abc"

■ pkill -9 abc

Link Manager APIs

● Send event to link manager

○ NA ME: ast_send_event ○ OPTIONS:

■ e_stop_link: stop link

■ e_reconnect: restart link

■ e_chg_hostname: notify hostname change

■ e_but t on_link: trigg er a "button 1" press event

■ e_button_link_1: trigger a "button 1" long press event

■ e_but t on_pair ing: trigger a "button 2" press event

■ e_but t on_pair ing_1: trigger a "button 2" long press event

■ e_debug: s ave current link manager states into ./lm_params

○ EXAMPLE:

■ $./ast_send_event -1 e_chg_hostname

Kramer Electronics Ltd.

● Get current link manager state

○ CO MMAND: $cat /var/ast_device_status ○ RESULT: (Host)

■ s_idle: Client connection is not allowed. (loopback mode)

■ s_attaching: Client is connecting or video source is not available.

■ s_s r v_on: All functions are ready to work or working.

■ ot her st ates: non-stable states

○ RESULT: (CLIENT)

■ s_idle: Client is not connected to Host

■ s_s r v_on: Client is connected to Host

■ ot her st ates: non-stable states

Video Over IP Driver Statistic/Control APIs

The interface is presented as files and located under /sys/devices/platform/videoip/.

● Connect ed client list: ○ FI LE: unlink ○ USAGE: cat /sys/devices/platform/videoip/unlink

KDS-EN6, KDS-DEC6 - Console APIs

Display Driver Statistic/Control APIs

The interface is presented as files and located under /sys/devices/platform/display/.

● Attached monitor information: ○ FILE: monitor_info

○ USAGE: cat /sys/devices/platform/display/monitor_info

● Video timing informat ion : ○ FILE: timing_info

○ USAGE: cat /sys/devices/platform/display/timing_info

● [>=A3.54]Turn on/off display: ○ FILE: screen_off

○ USAGE:

Kramer Electronics Ltd.

■ Turn off screen: echo 1 > /sys/devices/platform/display/screen_off

■ Turn on screen: echo 0 > /sys/devices/platform/display/screen_off

■ Show status: cat > /sys/devices/platf orm/display/scr een_off

■ enable: m eans screen is off

■ disable: m eans screen is on

OSD APIs

By using the following script, the user can dynamically show OSD messages.

● Turn ON:

○ ./osd_on.sh ○ USAGE:

■ To show "This is OSD string":

■ ./osd_on.sh “This is OSD string”

■ The OSD string takes ‘printf’ like special character input, for example:

■ Use f ollowing code for reserved characters:

○ Environment Var iables: Please see the comments in osd_on.sh

■ OSD_STR

■ . / os d_on.sh “Line 1 \n Line 2”

■ \x3A: ‘:’

■ \n: CR

■ \t: tab

KDS-EN6, KDS-DEC6 - Console APIs

● Turn OFF:

Kramer Electronics Ltd.

■ OSD_FONT_SIZE

■ OSD_FONT_COLOR

■ OSD_TRANSPARENT

■ OSD_MAX_Y_SIZE

○ ./osd_off.sh ○ USAG E: To disable OSD message after 5 seconds:

■ . / os d_off.sh 5 &

Note: The maximum number of characters an OSD string can show is software limited to 128 characters.

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Configurations APIs

Configurat i ons API s

Current firmware reserved two flash sections for system configuration. One is read only (RO) the other is read-write (RW). By factory default, there are configurations saved in the flash read only (RO) section. When the firmware starts up, both RO and RW configurations are read from flash and saved in RAM. All configuration modif ic at io ns are saved in RAM until "./astparam save" is called.

● Access configurations from RO/RW section: ○ NA ME: astpar am

○ OPTIONS

■ r : read from RO section

■ g : read from RW section

■ s : write to RW section

■ flush : clear all settings in RW section including randomly generated MAC

address. "./astparam save" is needed to clear all settings in flash memory.

■ dum p: dump all parameters in RW section

■ dum p ro: dump all parameters in RO section

■ dd: dump all parameters in RW section directly from flash

■ dd r o: dump all parameters in RO section directly from flash

■ save: save all parameters in RW section into flash

○ EXAMPLE:

■ r ead "ip_mode" setting from RO section:

■ $./astparam r ip_mode

■ read "ip_mode" setting from RW section:

■ $./astparam g ip_mode

■ write "ip_m ode" setting as "autoip" to RW section:

■ $. / astpar am s ip_mode autoip

■ clear all settings in RW section:

■ $./astparam flush

■ clear ip_m ode setting in RW section:

■ $./astparam s ip_mode

● Reset setting to factory default: ○ NA ME: reset _to_default.sh

○ DESCRIPTION:

■ r eset RW section but keeps the random generated MAC address. A system

reboot is required to take effect.

○ EXAMPLE:

■ $./reset_to_default.sh

KDS-EN6, KDS-DEC6 - Configurations APIs

IIC APIs

● [>= A3.0] Initial IIC bus: ○ NA ME: bus_init

○ DESCRIPT ION: Used to initial IIC bus speed. Must be set at least once in order to

○ EX AMPLE: Set bus number 1 using 40000Hz

● Select IIC bus and device: ○ NA ME: io_select ○ DESCRIPT ION: Used to set IIC slave device's bus number and device address

○ EX AMPLE: choose bus number 1 and device address 9a

Kramer Electronics Ltd.

work.

■ $echo 1 40000 > /sys/devices/platf orm/i2c/bus_init

■ $echo 1 9a > /sys/devices/platform/i2c/io_select

● Read/Write IIC slave: ○ NA ME: io_value

○ DESCRIPT ION: Used to read or write value. Set "i_range" for read range. ○ EXAMPLE:

■ To write 0xaa to IIC device offset 0xbb:

■ $echo 0xbb 0xaa > /sys/devices/platform/i2c/io_value

■ To read 5 bytes from offset 0xbb:

■ $echo 0xbb 0x5 > /sys/devices/platform/i2c/i_range

■ $cat /sys/devices/platform/i2c/io_value

● Setting range of IIC read: ○ NA ME: i_rang e

○ DESCRIPTION: Used to set the range for read. See "io_value" for example.

UART Port 1 APIs

● Setup /dev/ttyS0: ○ NAME: stty

○ DESCRIPTION: http://linux.about.com/od/lna_guide/a/gdelna38t01.htm ○ Example: set baudrate to 115200

■ $stty 115200 -F /dev/ttyS0

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Configuration Option List

Configuration Option Li st

Configuration options are settings saved in flash. These settings are used by KDS-6 FW. The KDS-6 FW reserves two flash partitions for this purpose, one is read only (RO) and the other is read-write (RW). Factory default settings are saved in the RO partition. Changes are saved in the RW partition. When the same configuration name is defined in both partitions, the setting in the RW partition is used (unless specially noted).

● ch_select ○ DESCRIPT ION: Used by client FW only. If defined, client FW uses it to resolve target

host's IP address, otherwise 4-bits DIP s witch will be used as ch_select.

○ O PTIONS: IP or host's hostname_id ○ DEF AULT: 4-bits DIP switch ○ PARTITION: [A1.32]RO, RW

● hostname_id ○ DESCRIPT ION: If defined, FW will use hostname_id to create the board's hostname

(See FAQ: What is the relationship between hostname and hostname_id? defined, default value will be used.

○ OPTIONS: any string without '.' ○ DEFAULT:

■ When hostnamebydipswitch == y: 4-bits DIP swit ch

■ When hostnamebydipswitch == n: mac address

○ PARTITION: [A1.32]RO, RW

● ip_mode ○ DESCRIPTION: Used to configure how FW allocates it's IP address.

○ OPTIONS:

■ aut oip: Auto-generated. Use 169.254.xxx.xxx private IP domain.

■ dh c p : Use DHCP client. A DHCP server is required.

■ static: Use static assigned IP address. The flash configurations "ipaddr" and

"netmask" are used.

○ DEFAULT: autoip ○ PARTITION: RO, RW

). If not

● ipaddr ○ DESCRIPT ION: Used when "ip_mode" is "static". If not defined, default value is used.

○ DEFAULT:

■ Host : 169. 254.0.222

■ Cllien t: 169.254.0.111

○ PARTITION: RO, RW

● netmask ○ DESCRIPT ION: Used when "ip_mode" is "static". If not defined, default value is used.

KDS-EN6, KDS-DEC6 - Configuration Option List

● gatewayip

● s0_baudrate

Kramer Electronics Ltd.

○ DEFAULT: 255.255.0.0 ○ PARTITION: RO, RW

○ DESCRIPT ION: Used when “ip_mode” is “static”. If not defined, default value is used. ○ DEFAULT: 169.254.0.254 ○ PARTITION: RO, RW

○ DESCRIPT ION: The static baud rate used under RS-232 over IP Type 2 mode. For

example: "115200-8n1" means using "115200" baud rate with data bits "8", parity "None" and stop bits "1".

○ DEFAULT: 115200-8n1 ○ PARTITION: RO, RW

● multicast_ip ○ DESCRIPTION: Multicast group used under multicast mode. Always map the

multicast_ip to 225.0.B0.B1B2B3 format where B0, B1, B2 and B3 are originally mapped from 4-bits DIP switch. Do not use a different multicast_ip, unless you know what you are doing.

[A3.50] Starting from firmware A3.50, the default value of multicast IP (multicast_ip) changes from 225.0.x.xxx to 225.0.10x.xxx. Please use the new multicast_ip value when using fw version A3.50 and up.

○ OPTIONS: any valid multicast IP ○ DEFAULT: mapping from 4-bits DIP switch:

■ [<A3.50] 225.0.B0.B1B2B3

■ [ > = A3.50] 225.0.10B0.B1B2B3

○ PARTITION: [A1.32]RO, RW

● hostnamebydipswitch ○ DESCRIPT ION: If "hostname_id" is not defined, the KDS-6 FW selects the

"hostname_id" according to the definition of "hostnamebydipswitch". If 'y' the value of the 4-bits DIP switc h is used. Otherwise, the MAC address is used.

○ OPTIONS: y , n ○ DEFAULT:

■ Ho s t: y

■ Clie nt: n

■ Clie nt for USB only FW: y

○ PARTITION: RO, RW

● reset_ch_on_boot ○ DESCRIPTION: Set to 'y' to reset channel related settings to the setting of the 4-bits

DIP switch after board reset. By using this feature, the modification of multicast group or unicast target disappears after board reset. The following settings are reset:

KDS-EN6, KDS-DEC6 - Configuration Option List

■ multicast_ip

■ ch_select

■ hostname_id ○ OPTIONS: y , n ○ DEF AULT: y ○ PARTITION: RO, RW

● ast_video_quality_mode ○ DESCRIPT ION: Used to configure "Graphic Mode" or "Video Mode". This setting only

takes effect each time video capturing starts. This setting only applies to the host board. Pressing "button 2" changes this setting. The recommended way of dynamically changing the quality mode is to use "button 2 event".

○ OPTIONS:

■ 0: graphic mode

■ -1: video mode ○ DEFAULT: -1 ○ PARTITION: RO, RW

Kramer Electronics Ltd.

● v_bcd_threshold ○ DESCRIPTION: Used to configure "Anti-Dithering Mode". This setting only takes

effect each time video capturing starts. This setting only applies on the host board. Pressing and holding "button 2" changes this setting. The recommended way of dynamically changing this setting is to use "button 2 event".

○ OPTIONS:

■ 0: Off

■ 1: Ant i-dithering 1

■ 2: Ant i-dithering 2 ○ DEF AULT: 0 ○ PARTITION: RO, RW

● no_soip ○ DESCRIPTION: Used to turn ON/OFF "Serial Over IP" feature. This setting only takes

effect on system reboot.

○ OPTIONS:

■ y: Disable "Serial Over IP" feature

■ n: Enable "Serial Over IP" feature ○ DEFAULT: Default value is configured by manufacturer using "autoterm". ○ PARTITION: RO, RW

● soip_type2 ○ DESCRIPT ION: Used to configure "Serial Over IP" operating mode when "Serial Over

IP" feature is enabled. This setting only takes effect on system reboot and "Serial Over IP" feature is enabled.

○ OPTIONS:

■ n: Use "Serial over IP type 1"

■ y: Use "Serial over IP type 2"

○ DEFAULT: Default value is configured by manufacturer using "autoterm"

KDS-EN6, KDS-DEC6 - Configuration Option List

○ PARTITION: RO, RW

● [A1.2 Firmware] soip_guest_on ○ DESCRIPTION: Used to configure "Serial Over IP" operating mode to "guest mode".

This setting only takes effect on system reboot and "Serial Over IP" feature is enabled.

○ OPTIONS:

■ n: Use typical "Serial Over IP" mode, in which host and client are paired

together.

■ y: Use "guest mode", in which both host and client boards' UART port 1 are controlled by an external network controller (for example a PC).

○ DEFAULT: n. Can be configured by manufacturer using "autoterm" ○ PARTITION: RO, RW

● multicast_on ○ DESCRIPTION: Used to configure unicast/multicast operation mode. Since the

operation mode of “USB over IP” will be different between multicast and unicast mode. So, when you change ‘multicast_on’, remember to config ‘USB over IP’ mode as well. See ‘share_usb’ and ‘share_usb_auto_mode’ below.

○ OPTIONS:

Kramer Electronics Ltd.

■ n: unicast mode

■ y: multicast mode

○ DEF AULT: n ○ PARTITION: RO, RW

● share_usb ○ DESCRIPTION: Used to configure USB over IP’s operation mode. There are two USB

over IP operation modes. ‘share USB’ mode is typically used in multicast mode. In this mode, only one client can request the USB over IP access at a time.

○ OPTIONS:

■ n: default mode for unicast mode

■ y: share USB mode. default mode for multicast mode

○ DEFAULT:

■ n

○ PARTITION: RO, RW

● [>=A3.54] share_usb_auto_mode ○ DESCRIPTION: A new setting used to overwrite the setting of ‘share_usb’ depending

on the setting of ‘multicast_on’.

○ OPTIONS:

■ y: enable. The value of ‘share_usb’ is always:

■ shar e_us b will be ‘n’ under unicast mode

Kramer Electronics Ltd.

KDS-EN6, KDS-DEC6 - Configuration Option List

■ shar e_us b will be ‘y’ under multicast mode

■ n: disable.

○ DEFAULT:

■ n: For backward compatibility. The default value is ‘n’.

○ PARTITION: RO, RW

P/N:

2900-300839

Rev:

SAFETY WARNING

Disconnect the unit from the power supply before opening and servicing

For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found.

We welcome your questions, comments, and feedback.

www.KramerAV.com info@KramerAV.com

Kramer KDS-EN6 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Terms

How to Access the Console

Astparam Configuration API

Overview

How to Access astparam

OPTIONS

List of astparams

Generic Settings

IP Network Setting

Button: (> A3.2)

Video over IP

Video Wall

HDCP

USB over IP

USB over IP Exporting Policy: (> A 5.2.2)

KMoIP: (> A 5.1.0)

Audio over IP (I2S over IP)

IR over IP

Serial over IP

GPIO over IP (Push Button over IP)

Getting KDS-6 Board's IP Address

Application Scenario:

FAQs

Generic Configuration:

How do I discover all KDS-6 boards in the same LAN?

How do I use the node_list feature without going through KDS-6 board? For example, using a PC.

How do I find the target client board's current multicast group?

How do I turn on/off the debug console's debug message?

How do I configure IP settings?

How do I configure hostname_id?

What is the relationship between hostname and hostname_id?

How do I dynamically toggle between Graphic Mode and Video Mode?

How do I dynamically change Anti-Dithering mode?

How do I dynamically change snoop mode?

How do I dynamically connect/disconnect a client?

How do I dynamically enable/disable remote access (host)?

How do I force update EDID of a target client?

How do I force update EDID of the video loopback port (host)?

Under multicast USB mode, how do I know the current USB state of a client?

How do I find the status of the video source?

How do I check if the Ethernet cable is connected and works?

How do I know which client (IP) is using the host's USB redirection under multicast mode?

How do I know whether a monitor is connected?

How do I dump the attached monitor's EDID?

How do I know if the video timing (resolution...) is in use?

How do I get the device’s hostname?

How do I get the device’s IP address?

How do I get the device’s MAC address?

How do I stop a client’s connection?

How can a client request USB redirection access under multicast mode?

How do I configure as multicast mode?

How do I configure as unicast mode?

Can I overwrite multicast IP?

Unicast (KVM over IP)

How can a client connect to a specified host under unicast mode?

Multicast (M to 1 group)

How to change Host's multicast group from XXXX to 1001?

Multicast (M to N group)

How to change the target client board's multicast group?

How to read/write target board's IIC channel?

Why is the sysfs approach used for IIC access?

UART

How to read/write the target board's UART port 1 (/dev/ttyS0)?

How to configure UART port 1 (/dev/ttyS0) for non-Serial over IP usage?

How to enable debug console repeater mode?

[A1.2 Firmware] How to have functions like Serial over IP without going through the host board's UART port 1? For example, controlling all host/client boards through a network attached PC.

Console APIs

Debug Console APIs

Link Manager APIs

Video Over IP Driver Statistic/Control APIs

Display Driver Statistic/Control APIs

OSD APIs

Configurat i ons API s

IIC APIs

UART Port 1 APIs
