KDock-2 USB-C Hub Multiport Adapter
KDock-2 USB-C Hub Multiport Adapter
Introduction
Congratulations on purchasing your Kramer KDock-2 USB-C Hub Multiport Adapter.
KDock-2 USB-C Hub Multiport Adapter supports HDMI™ video output, 2 USB ports, 1
USB-C port, and an SD card reader. It is specially designed to support mobile devices. it is
an ideal accessory for MacBook, laptops equipped with USB Type-C, mobile phones, and
tablets.
Get to Know Your KDock-2
#
Feature
Function
1
Ethernet RJ-45
Connector
Ethernet RJ-45 Connector - To directly connect your mobile
device or laptop to the Ethernet with an RJ-45 1000M
(Gigabit)/100M/10M cable.
2
USB-C Female
Connect with adapter power 5V/1A---20V/5A.
3
SD
SD support read/write transmission speed up to 480Mbps
(60MB/s).
Version: 2.0.
4
2 USB-A 3.0/2.0
Connector
Connect with U disk, mouse, keyboard, or SSD.
Speed: 5.0Gbps (640MB/s).
5
4K HDMI Connector
Connect to an HDMI acceptor.
6
USB-C Male
Connect to host (PC, phone, or tablet).
1
2
3 5 64
Page 3
Installation Instructions
3
Technical Specifications
Inputs
1 USB
On a male USB-C connector.
Outputs
1 HDMI
On a female HDMI connector.
3840x2160P@30Hz.
Ports
3 USB
2 female USB-A 3.0 connectors for USB link
extension.
• Backward compatible with USB 2.0 data
transmission up to 480Mbps(60MB/s).
• When connected with powered device, the
limited current is 1.9A from the USB 3.0 port.
• When unconnected with powered device, the
limited current is 1A from the USB 3.0 port.
• Charging: BC1.2 (5V 1.5A).
• Speed: 5.0Gbps (640MB/s).
1 female USB-C connector for USB link
extension.
Support 5GB/s data transmission (when powered
device charge is not in use).
1 Ethernet
On an RJ-45 connector.
1 SD
On an SD card port.
Video
Max Bandwidth
10.2Gbps (3.4Gbps per graphic channel).
Max Resolution
3840x2160P@30Hz resolution.
Compliance
HDMI and HDCP 1.4.
Extended
Ethernet
Max Transmission
Bandwidth
1000M (Gigabit)/100M/10M.
Power
Consumption
100W.
Environmental
Conditions
Operating
Temperature
0° to +40°C (32° to 104°F).
Storage
Temperature
-10° to +70°C (14° to 158°F).
Humidity
5% to 90%, RHL non-condensing.
Regulatory
Compliance
Safety
CE.
Environmental
RoHs, FCC.
Enclosure
Type
Aluminum with built-in 16cm/6.3" flexible USB-C
cable.
General
Net Dimensions
11.65cm x 4.68cm x 1.60cm (4.6" x 1.8" x 0.6").
Net Weight
99g (0.22lbs) approx.
Specifications are subject to change without notice at www.kramerav.com
The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
