MIDI Implementaion

1

KORG RADIAS MIDI Implementation

Revision 1.0 (2005.09.22)

1.TRANSMITTED DATA

1-1 CHANNEL MESSAGES [H]:Hex, [D]:Decimal +--------+---------+-------------+------------------------------------------------------------+---+ | Status | Second | Third | Description (Transmitted by ... ) |ENA| | [Hex] | [H] [D] | [H] [D] | | | +--------+---------+-------------+------------------------------------------------------------+---+ | 8n | kk (kk) | 40 (64) | Note Off *1| A | | 9n | kk (kk) | vv (vv) | Note On vv=1~127 *1| A | | Bn | 00 (00) | mm (mm) | Bank Select(MSB) (Program Change) *2| K | | Bn | 01 (01) | vv (vv) | Modulation1 (Mod Wheel,A.P=ModWheel) | C | | Bn | 02 (02) | vv (vv) | Modulation2 (A.P=BrthCtrl) | C | | Bn | 04 (04) | vv (vv) | Foot Control (A.P=FootPedal) | C | | Bn | 06 (06) | vv (vv) | Data Entry (MSB) (Panel Control) *3| C | | Bn | 07 (07) | vv (vv) | Volume (A.P=Volume) | C | | Bn | 0A (10) | vv (vv) | Panpot (A.P=Pan) | C | | Bn | 0B (11) | vv (vv) | Expression (A.P=ExpPedal) | C | | Bn | 20 (32) | bb (bb) | Bank Select(LSB) (Timbre/DrumKit Change) *2| K | | Bn | 40 (64) |00/7F (0/127)| Sustain Off/On (A.S=Damper) | C | | Bn | 41 (65) |00/7F (0/127)| Portamento Off/On (A.S=PortSw) | C | | Bn | 52 (82) |00/7F (0/127)| Multi Purpose Ctrl17(as Foot Sw) (A.S=FootSw) | C | | Bn | 62 (98) | vv (vv) | NRPN (LSB) (P.C) *3| C | | Bn | 63 (99) | vv (vv) | NRPN (MSB) (P.C) *3| C | | Bn | cc (cc) | vv (vv) | Control Change cc=00~95,102~119 (P.C) *4| C | | Cn | pp (pp) | -- -- | Program Change (Prog Change) | P | | Dn | vv (vv) | -- -- | Channel Pressure (A.P=AftTouch) | C | | En | bb (bb) | bb (bb) | Pitch Bender Change (Bend Wheel) | B | +--------+---------+-------------+------------------------------------------------------------+---+

n : MIDI Channel = 0 ~ F vv : Value

A.P: Assignable Pedal A.S: Assignable Switch P.C: Panel Control

ENA = A : Always Enable C : Enabled when Global CtrlChg is enabled. P : Enabled when Global PROG Chg is enabled. K : Enabled when Global BANK Chg is enabled. B : Enabled when Global PitchBend is enabled.

*1 : kk = 5 ~ 108 : RADIAS(with Keyboard) (49Keys + OCT + Transpose) = 21 ~ 108 : RADIAS(no Keyboard) (16Keys + OCT + Transpose)

*2 : Program MIDI Out [Hex] [Dec] Program A01 - H16 mm,bb,pp = 00,00,00~7F / 00,00,000~127 I01 - P16 00,01,00~7F / 00,01,000~127 Timbre1 A01 - H16 20,20,00~7F / 32,32,000~127 (only Receive) I01 - P16 20,21,00~7F / 32,33,000~127 (only Receive) Timbre2 A01 - H16 20,22,00~7F / 32,34,000~127 (only Receive) I01 - P16 20,23,00~7F / 32,35,000~127 (only Receive) Timbre3 A01 - H16 20,24,00~7F / 32,36,000~127 (only Receive) I01 - P16 20,25,00~7F / 32,37,000~127 (only Receive) Timbre4 A01 - H16 20,26,00~7F / 32,38,000~127 (only Receive) I01 - P16 20,27,00~7F / 32,39,000~127 (only Receive) Drum Kit 01 - 32 20,40,00~1F / 32,64,000~031 (only Receive)

2

*3 : Non Registered Parameter Number (NRPN) +---------+-----------------------------+------------------------+ | MSB LSB | Parameter | Data Entry(MSB) Value | | [H] [H] | | | +---------+-----------------------------+------------------------+ | 00 02 | Arpeggio On/Off | 00/7F:OFF/ON | | 00 04 | Arpeggio Latch On/Off | 00/7F:OFF/ON | | 00 07 | Arpeggio Type | *3-1 | | 00 0A | Arpeggio Gate | *3-2 | | 00 0B | Arpeggio Select SW | *3-3 | | | | | | 00 14 | StepSeq1 Latch | 00/7F:OFF/ON | | 00 1A | StepSeq1 Gate | *3-2 | | | | | | 00 24 | StepSeq2 Latch | 00/7F:OFF/ON | | 00 2A | StepSeq2 Gate | *3-2 | | | | | | 04 00 | Patch1 Source | *3-4 | | 04 01 | Patch2 Source | *3-4 | | 04 02 | Patch3 Source | *3-4 | | 04 03 | Patch4 Source | *3-4 | | 04 04 | Patch5 Source | *3-4 | | 04 05 | Patch6 Source | *3-4 | | 04 08 | Patch1 Destination | *3-5 | | 04 09 | Patch2 Destination | *3-5 | | 04 0A | Patch3 Destination | *3-5 | | 04 0B | Patch4 Destination | *3-5 | | 04 0C | Patch5 Destination | *3-5 | | 04 0D | Patch6 Destination | *3-5 | | | | | | 04 10 | Mod.SEQ1 Step[01] VALUE | *3-6 | | 04 11 | Mod.SEQ1 Step[02] VALUE | *3-6 | | 04 12 | Mod.SEQ1 Step[03] VALUE | *3-6 | | 04 13 | Mod.SEQ1 Step[04] VALUE | *3-6 | | 04 14 | Mod.SEQ1 Step[05] VALUE | *3-6 | | 04 15 | Mod.SEQ1 Step[06] VALUE | *3-6 | | 04 16 | Mod.SEQ1 Step[07] VALUE | *3-6 | | 04 17 | Mod.SEQ1 Step[08] VALUE | *3-6 | | 04 18 | Mod.SEQ1 Step[09] VALUE | *3-6 | | 04 19 | Mod.SEQ1 Step[10] VALUE | *3-6 | | 04 1A | Mod.SEQ1 Step[11] VALUE | *3-6 | | 04 1B | Mod.SEQ1 Step[12] VALUE | *3-6 | | 04 1C | Mod.SEQ1 Step[13] VALUE | *3-6 | | 04 1D | Mod.SEQ1 Step[14] VALUE | *3-6 | | 04 1E | Mod.SEQ1 Step[15] VALUE | *3-6 | | 04 1F | Mod.SEQ1 Step[16] VALUE | *3-6 | | | | | | 04 20 | Mod.SEQ2 Step[01] VALUE | *3-6 | | 04 21 | Mod.SEQ2 Step[02] VALUE | *3-6 | | 04 22 | Mod.SEQ2 Step[03] VALUE | *3-6 | | 04 23 | Mod.SEQ2 Step[04] VALUE | *3-6 | | 04 24 | Mod.SEQ2 Step[05] VALUE | *3-6 | | 04 25 | Mod.SEQ2 Step[06] VALUE | *3-6 | | 04 26 | Mod.SEQ2 Step[07] VALUE | *3-6 | | 04 27 | Mod.SEQ2 Step[08] VALUE | *3-6 | | 04 28 | Mod.SEQ2 Step[09] VALUE | *3-6 | | 04 29 | Mod.SEQ2 Step[10] VALUE | *3-6 | | 04 2A | Mod.SEQ2 Step[11] VALUE | *3-6 | | 04 2B | Mod.SEQ2 Step[12] VALUE | *3-6 | | 04 2C | Mod.SEQ2 Step[13] VALUE | *3-6 | | 04 2D | Mod.SEQ2 Step[14] VALUE | *3-6 | | 04 2E | Mod.SEQ2 Step[15] VALUE | *3-6 | | 04 2F | Mod.SEQ2 Step[16] VALUE | *3-6 | | | | | | 04 30 | Mod.SEQ3 Step[01] VALUE | *3-6 | | 04 31 | Mod.SEQ3 Step[02] VALUE | *3-6 | | 04 32 | Mod.SEQ3 Step[03] VALUE | *3-6 | | 04 33 | Mod.SEQ3 Step[04] VALUE | *3-6 | | 04 34 | Mod.SEQ3 Step[05] VALUE | *3-6 | | 04 35 | Mod.SEQ3 Step[06] VALUE | *3-6 | | 04 36 | Mod.SEQ3 Step[07] VALUE | *3-6 | | 04 37 | Mod.SEQ3 Step[08] VALUE | *3-6 | | 04 38 | Mod.SEQ3 Step[09] VALUE | *3-6 | | 04 39 | Mod.SEQ3 Step[10] VALUE | *3-6 | | 04 3A | Mod.SEQ3 Step[11] VALUE | *3-6 | | 04 3B | Mod.SEQ3 Step[12] VALUE | *3-6 | | 04 3C | Mod.SEQ3 Step[13] VALUE | *3-6 | | 04 3D | Mod.SEQ3 Step[14] VALUE | *3-6 | | 04 3E | Mod.SEQ3 Step[15] VALUE | *3-6 | | 04 3F | Mod.SEQ3 Step[16] VALUE | *3-6 | | | | | | 04 40 | Vocoder Band01 Level | 00~7F:0~127 | | 04 41 | Vocoder Band02 Level | 00~7F:0~127 | | 04 42 | Vocoder Band03 Level | 00~7F:0~127 | | 04 43 | Vocoder Band04 Level | 00~7F:0~127 | | 04 44 | Vocoder Band05 Level | 00~7F:0~127 | | 04 45 | Vocoder Band06 Level | 00~7F:0~127 | | 04 46 | Vocoder Band07 Level | 00~7F:0~127 | | 04 47 | Vocoder Band08 Level | 00~7F:0~127 | | 04 48 | Vocoder Band09 Level | 00~7F:0~127 | | 04 49 | Vocoder Band10 Level | 00~7F:0~127 | | 04 4A | Vocoder Band11 Level | 00~7F:0~127 | | 04 4B | Vocoder Band12 Level | 00~7F:0~127 | | 04 4C | Vocoder Band13 Level | 00~7F:0~127 | | 04 4D | Vocoder Band14 Level | 00~7F:0~127 | | 04 4E | Vocoder Band15 Level | 00~7F:0~127 | | 04 4F | Vocoder Band16 Level | 00~7F:0~127 | | | | |

1.TRANSMITTED DATA

3

KORG RADIAS MIDI Implementation

| 04 50 | Vocoder Band01 Panpot | *3-8 | | 04 51 | Vocoder Band02 Panpot | *3-8 | | 04 52 | Vocoder Band03 Panpot | *3-8 | | 04 53 | Vocoder Band04 Panpot | *3-8 | | 04 54 | Vocoder Band05 Panpot | *3-8 | | 04 55 | Vocoder Band06 Panpot | *3-8 | | 04 56 | Vocoder Band07 Panpot | *3-8 | | 04 57 | Vocoder Band08 Panpot | *3-8 | | 04 58 | Vocoder Band09 Panpot | *3-8 | | 04 59 | Vocoder Band10 Panpot | *3-8 | | 04 5A | Vocoder Band11 Panpot | *3-8 | | 04 5B | Vocoder Band12 Panpot | *3-8 | | 04 5C | Vocoder Band13 Panpot | *3-8 | | 04 5D | Vocoder Band14 Panpot | *3-8 | | 04 5E | Vocoder Band15 Panpot | *3-8 | | 04 5F | Vocoder Band16 Panpot | *3-8 | | | | | | 04 60 | Vocoder Fc Mod.Source | *3-4 | | | | | | 05 00 | Timbre1 SW | 00/7F:OFF/ON | | 05 01 | Timbre2 SW | 00/7F:OFF/ON | | 05 02 | Timbre3 SW | 00/7F:OFF/ON | | 05 03 | Timbre4 SW | 00/7F:OFF/ON | | 05 04 | Vocoder SW | 00/7F:OFF/ON | +---------+-----------------------------+------------------------+

*3-1 : 00~14 : Up 15~29 : Down 2A~3E : Alt1 3F~53 : Alt2 54~68 : Random 69~7F : Trigger

*3-2 : 00~07 :-100, -98, -96, -94, -92, -90, -88, -86, 08~0F : -84, -82, -80, -78, -76, -74, -72, -70, 10~17 : -68, -66, -64, -62, -60, -58, -56, -54, 18~1F : -52, -50, -48, -46, -44, -42, -40, -38, 20~27 : -36, -34, -32, -30, -28, -27, -26, -25, 28~2F : -24, -23, -22, -21, -20, -19, -18, -17, 30~37 : -16, -15, -14, -13, -12, -11, -10, -9, 38~3F : -8, -7, -6, -5, -4, -3, -2, -1, 40~47 : 0, 1, 2, 3, 4, 5, 6, 7, 48~4F : 8, 9, 10, 11, 12, 13, 14, 15, 50~57 : 16, 17, 18, 19, 20, 21, 22, 23, 58~5F : 24, 25, 26, 28, 30, 32, 34, 36, 60~67 : 38, 40, 42, 44, 46, 48, 50, 52, 68~6F : 54, 56, 58, 60, 62, 64, 66, 68, 70~77 : 70, 72, 74, 76, 78, 80, 82, 84, 78~7F : 86, 88, 90, 92, 94, 96, 98, 100

*3-3 : 00 : OFF 01 : Arpeggiator 02 : Step Seq1 03~7F : Step Seq2

*3-4 : 00~07 : EG1 08~10 : EG2 11~18 : EG3 19~21 : LFO 22~29 : LFO2 2A~32 : VELOCITY 33~3A : PITCH BEND 3B~43 : MOD WHEEL 44~4B : KBD TRACK 4C~54 : ENVELOPE FOLLOWER 55~5C : MIDI1 5D~65 : MIDI2 66~6D : MIDI3 6E~76 : MIDI4 77~7F : MIDI5

*3-5 : 00~07 :PITCH 08~0F :OSC2 PITCH 10~17 :OSC1 CTRL 18~1F :OSC1 LEVEL 20~27 :OSC2 LEVEL 28~2F :NOISE LEVEL 30~37 :FILTER1 TYPE 38~3F :FILTER1 CUTOFF 40~47 :FILTER1 RESONANCE 48~4F :FILTER2 CUTOFF 50~57 :DRV/WS DEPTH 58~5F :AMP LEVEL 60~67 :PANPOT 68~6F :LFO1 FREQ. 70~7F :LFO2 FREQ.

*3-6 : When Knob is "Pitch" or "OSC2 Semi" 00~7F : -24~0~+24 (*3-7) When Knob is others 00~7F : -63~0~+63 (*3-8)

4

*3-7 : 00~07 : -24,-24,-24,-23,-23,-23,-22,-22 08~0F : -21,-21,-21,-20,-20,-20,-19,-19 10~17 : -18,-18,-18,-17,-17,-16,-16,-16 18~1F : -15,-15,-15,-14,-14,-13,-13,-13 20~27 : -12,-12,-11,-11,-11,-10,-10,-10 28~2F : - 9,- 9,- 8,- 8,- 8,- 7,- 7,- 7 30~37 : - 6,- 6,- 5,- 5,- 5,- 4,- 4,- 3 38~3F : - 3,- 3,- 2,- 2,- 2,- 1,- 1, 0 40~47 : 0, 0,+ 1,+ 1,+ 2,+ 2,+ 2,+ 3 48~4F : + 3,+ 3,+ 4,+ 4,+ 5,+ 5,+ 5,+ 6 50~57 : + 6,+ 7,+ 7,+ 7,+ 8,+ 8,+ 8,+ 9 58~5F : + 9,+10,+10,+10,+11,+11,+11,+12 60~67 : +12,+13,+13,+13,+14,+14,+15,+15 68~6F : +15,+16,+16,+16,+17,+17,+18,+18 70~77 : +18,+19,+19,+20,+20,+20,+21,+21 78~7F : +21,+22,+22,+23,+23,+23,+24,+24

*3-8 : 00,01~7F = -63,-63~+63 00~07 : -63,-63,-62,-61,-60,-59,-58,-57 08~0F : -56,-55,-54,-53,-52,-51,-50,-49 10~17 : -48,-47,-46,-45,-44,-43,-42,-41 18~1F : -40,-39,-38,-37,-36,-35,-34,-33 20~27 : -32,-31,-30,-29,-28,-27,-26,-25 28~2F : -24,-23,-22,-21,-20,-19,-18,-17 30~37 : -16,-15,-14,-13,-12,-11,-10,- 9 38~3F : - 8,- 7,- 6,- 5,- 4,- 3,- 2,- 1 40~47 : 0,+ 1,+ 2,+ 3,+ 4,+ 5,+ 6,+ 7 48~4F : + 8,+ 9,+10,+11,+12,+13,+14,+15 50~57 : +16,+17,+18,+19,+20,+21,+22,+23 58~5F : +24,+25,+26,+27,+28,+29,+30,+31 60~67 : +32,+33,+34,+35,+36,+37,+38,+39 68~6F : +40,+41,+42,+43,+44,+45,+46,+47 70~77 : +48,+49,+50,+51,+52,+53,+54,+55 78~7F : +56,+57,+58,+59,+60,+61,+62,+63

*3-9 : 00,01~40~7F = L63,L63~CNT~R63 00~07 : L63,L63,L62,L61,L60,L59,L58,L57 08~0F : L56,L55,L54,L53,L52,L51,L50,L49 10~17 : L48,L47,L46,L45,L44,L43,L42,L41 18~1F : L40,L39,L38,L37,L36,L35,L34,L33 20~27 : L32,L31,L30,L29,L28,L27,L26,L25 28~2F : L24,L23,L22,L21,L20,L19,L18,L17 30~37 : L16,L15,L14,L13,L12,L11,L10,L09 38~3F : L08,L07,L06,L05,L04,L03,L02,L01 40~47 : CNT,R01,R02,R03,R04,R05,R06,R07 48~4F : R08,R09,R10,R11,R12,R13,R14,R15 50~57 : R16,R17,R18,R19,R20,R21,R22,R23 58~5F : R24,R25,R26,R27,R28,R29,R30,R31 60~67 : R32,R33,R34,R35,R36,R37,R38,R39 68~6F : R40,R41,R42,R43,R44,R45,R46,R47 70~77 : R48,R49,R50,R51,R52,R53,R54,R55 78~7F : R56,R57,R58,R59,R60,R61,R62,R63

*3-10: 00,01~40~7F = -2.00~0.00~+2.00 00~07 : -2.00,-2.00,-1.93,-1.86,-1.80,-1.73,-1.66,-1.60, 08~0F : -1.53,-1.46,-1.40,-1.33,-1.26,-1.20,-1.13,-1.06, 10~17 : -1.00,-0.97,-0.95,-0.93,-0.91,-0.89,-0.87,-0.85, 18~1F : -0.83,-0.81,-0.79,-0.77,-0.75,-0.72,-0.70,-0.68, 20~27 : -0.66,-0.64,-0.62,-0.60,-0.58,-0.56,-0.54,-0.52, 28~2F : -0.50,-0.47,-0.45,-0.43,-0.41,-0.39,-0.37,-0.35, 30~37 : -0.33,-0.31,-0.29,-0.27,-0.25,-0.22,-0.20,-0.18, 38~3F : -0.16,-0.14,-0.12,-0.10,-0.08,-0.06,-0.04,-0.02, 40~47 : 0.00, 0.02, 0.04, 0.06, 0.08, 0.10, 0.12, 0.14, 48~4F : 0.16, 0.18, 0.20, 0.22, 0.25, 0.27, 0.29, 0.31, 50~57 : 0.33, 0.35, 0.37, 0.39, 0.41, 0.43, 0.45, 0.47, 58~5F : 0.50, 0.52, 0.54, 0.56, 0.58, 0.60, 0.62, 0.64, 60~67 : 0.66, 0.68, 0.70, 0.72, 0.75, 0.77, 0.79, 0.81, 68~6F : 0.83, 0.85, 0.87, 0.89, 0.91, 0.93, 0.95, 0.97, 70~77 : 1.00, 1.06, 1.13, 1.20, 1.26, 1.33, 1.40, 1.46, 78~7F : 1.53, 1.60, 1.66, 1.73, 1.80, 1.86, 1.93, 2.00

*3-11: 00~07 : -15.0, -15.0, -15.0, -14.5, -14.5, -14.0, -14.0, -13.5, 08~0F : -13.5, -13.0, -13.0, -12.5, -12.5, -12.0, -12.0, -11.5, 10~17 : -11.5, -11.0, -11.0, -10.5, -10.5, -10.0, -10.0, -10.0, 18~1F : -09.5, -09.5, -09.0, -09.0, -08.5, -08.5, -08.0, -08.0, 20~27 : -07.5, -07.5, -07.0, -07.0, -06.5, -06.5, -06.0, -06.0, 28~2F : -05.5, -05.5, -05.0, -05.0, -05.0, -04.5, -04.5, -04.0, 30~37 : -04.0, -03.5, -03.5, -03.0, -03.0, -02.5, -02.5, -02.0, 38~3F : -02.0, -01.5, -01.5, -01.0, -01.0, -00.5, -00.5, +00.0, 40~47 : +00.0, +00.0, +00.5, +00.5, +01.0, +01.0, +01.5, +01.5, 48~4F : +02.0, +02.0, +02.5, +02.5, +03.0, +03.0, +03.5, +03.5, 50~57 : +04.0, +04.0, +04.5, +04.5, +05.0, +05.0, +05.0, +05.5, 58~5F : +05.5, +06.0, +06.0, +06.5, +06.5, +07.0, +07.0, +07.5, 60~67 : +07.5, +08.0, +08.0, +08.5, +08.5, +09.0, +09.0, +09.5, 68~6F : +09.5, +10.0, +10.0, +10.0, +10.5, +10.5, +11.0, +11.0, 70~77 : +11.5, +11.5, +12.0, +12.0, +12.5, +12.5, +13.0, +13.0, 78~7F : +13.5, +13.5, +14.0, +14.0, +14.5, +14.5, +15.0, +15.0

1.TRANSMITTED DATA

5

KORG RADIAS MIDI Implementation

*4 :Panel Knob & Switch Control (assignable) +----------+--------------------+--------------------+---------------------------+ | | Synth | Vocoder | Value Synth/Vocoder | +----------+--------------------+--------------------+---------------------------+ | PITCH | Portamento | | 00~7F:0~127 | | UNISON | Unison SW | | 0,40 | | OSC1 | Wave | | *4-1 | | | OSC Mod. | | *4-2 | | | Control1 | | *4-3 | | | Control2 | | *4-4 | | OSC2 | Wave | | *4-5 | | | OSC Mod. | | *4-6 | | | Semitone | | *3-7 | | | Tune | | *3-8 | | MIXER | OSC1 Level | In Source1 | 00~7F:0~127 / 00~7F:0~127 | | | OSC2 Level | In Source2 | 00~7F:0~127 / 00~7F:0~127 | | | Noise Level | | 00~7F:0~127 | | FILTER1 | Routing | Mod.Select | *4-7 / *4-8 | | | Type Balance | | *4-9 | | | Cutoff | FC Offset | 00~7F:0~127 / *3-8 | | | Resonance | Resonance | 00~7F:0~127 | | | EG1 Int | FC Mod.Int | *3-8 | | | KBD Track | E.F.Sens | *3-10 / 00~7F:0~127 | | FILTER2 | Type | Formant Shift | *4-10 / *4-11 | | | Cutoff | Threshold | 00~7F:0~127 | | | Resonance | HPF Level | 00~7F:0~127 | | | EG1 Int | FC Mod Int | *3-8 | | | KBD Track | E.F.Sens | *3-8 / 00~7F:0~127 | | AMP | Level | Vocoder Level | 00~7F:0~127 | | | Pan | Direct Level | *3-9 / 00~7F:0~127 | | | Drive/WS Depth | | 00~7F:0~127 | | | Drive/WS SW | HPF Gate | *4-12 / *4-13 | | EG1 | Attack | | 00~7F:0~127 | | | Decay | | 00~7F:0~127 | | | Sustain | | 00~7F:0~127 | | | Release | | 00~7F:0~127 | | EG2 | Attack | | 00~7F:0~127 | | | Decay | | 00~7F:0~127 | | | Sustain | | 00~7F:0~127 | | | Release | | 00~7F:0~127 | | LFO1 | Wave | | *4-14 | | | Frequency | | *4-15 | | LFO2 | Wave | | *4-14 | | | Frequency | | *4-15 | | PATCH1 | Intensity | | *3-8 | | PATCH2 | Intensity | | *3-8 | | PATCH3 | Intensity | | *3-8 | | PATCH4 | Intensity | | *3-8 | | PATCH5 | Intensity | | *3-8 | | PATCH6 | Intensity | | *3-8 | | EQ | Hi.Gain | | *3-11 | | | Low.Gain | | *3-11 | | MOD SEQ. | Mod.Seq. SW | | 00~3F,40~7F:OFF,ON | | IFX1 | SW | | 00~3F,40~7F:OFF,ON | | | Edit1 | | refer midi_imp_fx | | | Edit2 | | refer midi_imp_fx | | IFX2 | SW | | 00~3F,40~7F:OFF,ON | | | Edit1 | | refer midi_imp_fx | | | Edit2 | | refer midi_imp_fx | | MFX | SW | | 00~3F,40~7F:OFF,ON | | | Edit | | refer midi_imp_fx | +----------+--------------------+--------------------+---------------------------+

*4-1 : 00~0D : Saw 0E~1B : Square 1C~29 : Tri 2A~37 : Sin 38~45 : Formant 46~53 : Noise 54~61 : Synth PCM 62~6F : Drum PCM 70~7F : Audio In

*4-2 : 00~1F : Waveform 20~3F : Cross 40~5F : Unison 60~7F : VPM

*4-3 : When OSC1Wave is "Saw,Tri,Sin" and OSC1Mod.Type is Waveform 00~7F : Waveform When OSC1Wave is "Squ" and OSC1Mod.Type is Waveform 00~7F : PulthWidth When OSC1Wave is "Saw,Squ,Tri,Sin" and OSC1Mod.Type is Cross 00~7F : Mod.Depth When OSC1Wave is "Saw,Squ,Tri,Sin" and OSC1Mod.Type is Unison 00~7F : Detune When OSC1Wave is "Saw,Squ,Tri,Sin" and OSC1Mod.Type is VPM 00~7F : Mod.Depth

When OSC1Wave is "FORMNAT" 00~7F : Formant Width When OSC1Wave is "NOISE" 00~7F : Resonance When OSC1Wave is "SynthPCM,DrumPCM" none When OSC1Wave is "Audio In" 00~7F : Gain

*4-4 : When OSC1Wave is "Saw,Tri,Sin" and OSC1Mod.Type is Waveform 00~7F : WFM LFO1 Mod. Int. When OSC1Wave is "Squ" and OSC1Mod.Type is Waveform 00~7F : PWM LFO1 Mod. Int. When OSC1Wave is "Saw,Squ,Tri,Sin" and OSC1Mod.Type is Cross 00~7F : Mod. Depth LFO1 Mod. Int. When OSC1Wave is "Saw,Squ,Tri,Sin" and OSC1Mod.Type is Unison 00~7F : Unison Phase When OSC1Wave is "Saw,Squ,Tri,Sin" and OSC1Mod.Type is VPM 00~7F : Carrier Harmonics

When OSC1Wave is "FORMNAT" 00~7F : Formant Shift When OSC1Wave is "NOISE" 00~7F : LPF/HPF Balance When OSC1Wave is "SynthPCM,DrumPCM" 00~7F : Wave Select When OSC1Wave is "Audio In" 00~7F : none

6

*4-5 : 00~1F : Saw 20~3F : Squ 40~5F : Tri 60~7F : Sin

*4-6 : 00~1F : OFF 20~3F : RING 40~5F : SYNC 60~7F : RING+SYNC

*4-7 : 00~1F : SINGLE 20~3F : SERIAL 40~5F : PARALLEL 60~7F : INDIVIDUAL

*4-8 : 00~3F : Audio 40~7F : Formant Play

*4-9 00 : LPF24 01~1E : LPF24~LPF12 1F~21 : LPF12 22~3E : LPF12~HPF 3F~41 : HPF 42~5E : HPF~BPF 5F~61 : BPF 62~7E : BPF~THRU 7F : THRU

*4-10: 00~1F : LPF 20~3F : HPF 40~5F : BPF 60~7F : COMB

*4-11: 00~1F : +1 20~3F : +2 40~5F : -1 60~7F : -2

*4-12: 00~29 : OFF 2A~54 : Drive 55~7F : WaveShape

*4-13: 00~3F : Disable 40~7F : Enable

*4-14: 00~1F : Saw 20~3F : Squ 40~5F : Tri 60~7F : S/H

*4-15: When Tempo Sync is "OFF". 00~07 : 0.01, 0.02, 0.03, 0.04, 0.05, 0.06, 0.07, 0.08, 08~0F : 0.09, 0.10, 0.11, 0.12, 0.13, 0.14, 0.15, 0.16, 10~17 : 0.17, 0.18, 0.19, 0.20, 0.21, 0.22, 0.23, 0.24, 18~1F : 0.25, 0.29, 0.33, 0.42, 0.50, 0.58, 0.67, 0.75, 20~27 : 0.83, 0.92, 1.00, 1.13, 1.25, 1.38, 1.50, 1.63, 28~2F : 1.75, 1.88, 2.00, 2.13, 2.25, 2.38, 2.50, 2.63, 30~37 : 2.75, 2.88, 3.00, 3.13, 3.25, 3.38, 3.50, 3.63, 38~3F : 3.75, 3.88, 4.00, 4.13, 4.25, 4.38, 4.50, 4.63, 40~47 : 4.75, 4.88, 5.00, 5.25, 5.50, 5.75, 6.00, 6.25, 48~4F : 6.50, 6.75, 7.00, 7.25, 7.50, 7.75, 8.00, 8.25, 50~57 : 8.50, 8.75, 9.00, 9.25, 9.50, 9.75, 10.0, 10.5, 58~5F : 11.0, 11.5, 12.0, 12.5, 13.0, 13.5, 14.0, 14.5, 60~67 : 15.0, 16.0, 17.0, 18.0, 19.0, 20.0, 21.5, 23.0, 68~6F : 24.5, 26.0, 27.5, 29.0, 31.0, 33.0, 35.0, 37.0, 70~77 : 39.0, 41.0, 44.0, 47.0, 50.0, 53.0, 57.0, 61.0, 78~7F : 65.0, 70.0, 75.0, 80.0, 85.0, 90.0, 95.0, 100.0

When Tempo Sync is "ON". 00~03 : 8/1 24~2B : 1/2 4C~53 : 1/6 74~7B : 1/32 04~0B : 4/1 2C~33 : 3/8 54~5B : 1/8 7C~7F : 1/64 0C~13 : 2/1 34~3B : 1/3 5C~63 : 1/12 14~1B : 1/1 3C~43 : 1/4 64~6B : 1/16 1C~23 : 3/4 44~4B : 3/16 6C~73 : 1/24

1.TRANSMITTED DATA

7

KORG RADIAS MIDI Implementation

1-3 UNIVERSAL SYSTEM EXCLUSIVE MESSAGES

DEVICE INQUIRY REPLY +---------+------------------------------------------------+ | Byte[H] | Description | +---------+------------------------------------------------+ | F0 | Exclusive Status | | 7E | Non Realtime Message | | 0g | MIDI Global Channel ( Device ID ) | | 06 | General Information | | 02 | Identity Reply | | 42 | KORG ID ( Manufacturers ID ) | | 72 | RADIAS Series ID ( Family ID (LSB)) | | 00 | ( Family ID (MSB)) | | 00 | ( Member ID (LSB)) | | 00 | ( Member ID (MSB)) | | xx | ( Minor Ver. (LSB)) | | xx | ( Minor Ver. (MSB)) | | xx | ( Major Ver. (LSB)) | | xx | ( Major Ver. (MSB)) | | F7 | END OF EXCLUSIVE | +---------+------------------------------------------------+ This message is transmitted whenever a INQUIRY MESSAGE REQUEST is received.

1-4 SYSTEM EXCLUSIVE MESSAGES +-------------+-------------------------------------+--------+ | Function ID | Description/Function | | | [Hex] | | *5 | +-------------+-------------------------------------+--------+ | 40 | CURRENT PROGRAM DATA DUMP | R,D,Me | | 4C | PROGRAM DATA DUMP (1 PROG) | R | | 43 | CURRENT FORMANT MOTION DATA DUMP | R | | 48 | FORMANT MOTION DATA DUMP | R | | 51 | GLOBAL DATA DUMP | R,D | | 31 | CURRENT DRUMKIT DATA DUMP | R,D | | 52 | DRUMKIT DATA DUMP (1 DRUMKIT) | R | | 7B | TEMPLATE DATA DUMP | R,D | | | | | | 41 | PROGRAM PARAMETER CHANGE | C | | 53 | DRUMKIT PARAMETER CHANGE | C | | 42 | MODE DATA | M | | | | | | 26 | DATA FORMAT ERROR | E | | 23 | DATA LOAD COMPLETED | E | | 24 | DATA LOAD ERROR | E | | 21 | WRITE COMPLETED | E | | 22 | WRITE ERROR | E | +-------------+-------------------------------------+--------+ *5 : Transmitted when R : Request message is received. D : Data dump from MIDI dump page. (Doesn't respond to MIDI FILTER "SystemEx" parameter.) E : Exclusive message is received. C : Parameter is changed by -/+ Switch or Rotary Encoder. M : Mode is changed. Me : Mode is changed to "LCD Edit".

8

2.RECOGNIZED RECEIVE DATA

2-1 CHANNEL MESSAGES +--------+---------+-------------+--------------------------------------+ | Status | Second | Third | Description | | [Hex] | [H] [D] | [H] [D] | | +--------+---------+-------------+--------------------------------------+ | 8n | kk (kk) | vv (vv) | Note Off vv=0~127 | | 9n | kk (kk) | 00 (00) | Note Off | | 9n | kk (kk) | vv (vv) | Note On vv=1~127 | | Bn | 00 (00) | mm (mm) | Bank Select(MSB) *2 | | Bn | 01 (01) | vv (vv) | Pitch Modulation Depth | | Bn | 02 (02) | vv (vv) | Breath Control Depth | | Bn | 06 (06) | vv (vv) | Data Entry(MSB) *6 | | Bn | 0B (11) | vv (vv) | Expression | | Bn | 20 (32) | bb (bb) | Bank Select(LSB) *2 | | Bn | 40 (64) | vv (vv) | Sustain Off/On | | Bn | 41 (65) | vv (vv) | Portamento Off/On | | Bn | 62 (98) | nl (nl) | NRPN LSB *6 | | Bn | 63 (99) | nm (nm) | NRPN MSB *6 | | Bn | 78(120) | 00 (0) | All Sound Off | | Bn | 79(121) | 00 (0) | Reset All Controllers | | Bn | 7B(123) | 00 (0) | All Note Off | | Bn | 7C(124) | 00 (0) | Omni Mode Off | | Bn | 7D(125) | 00 (0) | Omni Mode On | | Bn | cc (cc) | vv (vv) | Control Data cc=00~95 | | Cn | pp (pp) | -- -- | Program Change | | Dn | vv (vv) | -- -- | Channel Pressure (After Touch) | | En | bb (bb) | bb (bb) | Pitch Bender Change | +--------+---------+-------------+--------------------------------------+ n : MIDI Channel = 0 ~ F vv : Value

*6 : Non Registered Parameter Number (NRPN) +---------+-----------------------------+------------------------+ | MSB LSB | Parameter | Data Entry(MSB) Value | | [H] [H] | | | +---------+-----------------------------+------------------------+ | 00 02 | Arpeggio On/Off | 00~3F/40~7F:OFF/ON | | 00 03 | Arpeggio Octaves | 00~03:1~4 Octave | | 00 04 | Arpeggio Latch On/Off | 00~3F/40~7F:OFF/ON | | 00 07 | Arpeggio Type | *3-1 | | 00 0A | Arpeggio Gate | *3-2 | | 00 0B | Arpeggio Select SW | *3-3 | | | | | | 00 14 | StepSeq1 Latch | 00~3F/40~7F:OFF/ON | | 00 1A | StepSeq1 Gate | *3-2 | | | | | | 00 24 | StepSeq2 Latch | 00~3F/40~7F:OFF/ON | | 00 2A | StepSeq2 Gate | *3-2 | | | | | | 04 00 | Patch1 Source | *3-4 | | 04 01 | Patch2 Source | *3-4 | | 04 02 | Patch3 Source | *3-4 | | 04 03 | Patch4 Source | *3-4 | | 04 04 | Patch5 Source | *3-4 | | 04 05 | Patch6 Source | *3-4 | | 04 08 | Patch1 Destination | *3-5 | | 04 09 | Patch2 Destination | *3-5 | | 04 0A | Patch3 Destination | *3-5 | | 04 0B | Patch4 Destination | *3-5 | | 04 0C | Patch5 Destination | *3-5 | | 04 0D | Patch6 Destination | *3-5 | | | | | | 04 10 | Mod.SEQ1 Step[01] VALUE | *3-6 | | 04 11 | Mod.SEQ1 Step[02] VALUE | *3-6 | | 04 12 | Mod.SEQ1 Step[03] VALUE | *3-6 | | 04 13 | Mod.SEQ1 Step[04] VALUE | *3-6 | | 04 14 | Mod.SEQ1 Step[05] VALUE | *3-6 | | 04 15 | Mod.SEQ1 Step[06] VALUE | *3-6 | | 04 16 | Mod.SEQ1 Step[07] VALUE | *3-6 | | 04 17 | Mod.SEQ1 Step[08] VALUE | *3-6 | | 04 18 | Mod.SEQ1 Step[09] VALUE | *3-6 | | 04 19 | Mod.SEQ1 Step[10] VALUE | *3-6 | | 04 1A | Mod.SEQ1 Step[11] VALUE | *3-6 | | 04 1B | Mod.SEQ1 Step[12] VALUE | *3-6 | | 04 1C | Mod.SEQ1 Step[13] VALUE | *3-6 | | 04 1D | Mod.SEQ1 Step[14] VALUE | *3-6 | | 04 1E | Mod.SEQ1 Step[15] VALUE | *3-6 | | 04 1F | Mod.SEQ1 Step[16] VALUE | *3-6 | | | | | | 04 20 | Mod.SEQ2 Step[01] VALUE | *3-6 | | 04 21 | Mod.SEQ2 Step[02] VALUE | *3-6 | | 04 22 | Mod.SEQ2 Step[03] VALUE | *3-6 | | 04 23 | Mod.SEQ2 Step[04] VALUE | *3-6 | | 04 24 | Mod.SEQ2 Step[05] VALUE | *3-6 | | 04 25 | Mod.SEQ2 Step[06] VALUE | *3-6 | | 04 26 | Mod.SEQ2 Step[07] VALUE | *3-6 | | 04 27 | Mod.SEQ2 Step[08] VALUE | *3-6 | | 04 28 | Mod.SEQ2 Step[09] VALUE | *3-6 | | 04 29 | Mod.SEQ2 Step[10] VALUE | *3-6 | | 04 2A | Mod.SEQ2 Step[11] VALUE | *3-6 | | 04 2B | Mod.SEQ2 Step[12] VALUE | *3-6 | | 04 2C | Mod.SEQ2 Step[13] VALUE | *3-6 | | 04 2D | Mod.SEQ2 Step[14] VALUE | *3-6 | | 04 2E | Mod.SEQ2 Step[15] VALUE | *3-6 | | 04 2F | Mod.SEQ2 Step[16] VALUE | *3-6 | | | | |

2.RECOGNIZED RECEIVE DATA

9

KORG RADIAS MIDI Implementation

| 04 30 | Mod.SEQ3 Step[01] VALUE | *3-6 | | 04 31 | Mod.SEQ3 Step[02] VALUE | *3-6 | | 04 32 | Mod.SEQ3 Step[03] VALUE | *3-6 | | 04 33 | Mod.SEQ3 Step[04] VALUE | *3-6 | | 04 34 | Mod.SEQ3 Step[05] VALUE | *3-6 | | 04 35 | Mod.SEQ3 Step[06] VALUE | *3-6 | | 04 36 | Mod.SEQ3 Step[07] VALUE | *3-6 | | 04 37 | Mod.SEQ3 Step[08] VALUE | *3-6 | | 04 38 | Mod.SEQ3 Step[09] VALUE | *3-6 | | 04 39 | Mod.SEQ3 Step[10] VALUE | *3-6 | | 04 3A | Mod.SEQ3 Step[11] VALUE | *3-6 | | 04 3B | Mod.SEQ3 Step[12] VALUE | *3-6 | | 04 3C | Mod.SEQ3 Step[13] VALUE | *3-6 | | 04 3D | Mod.SEQ3 Step[14] VALUE | *3-6 | | 04 3E | Mod.SEQ3 Step[15] VALUE | *3-6 | | 04 3F | Mod.SEQ3 Step[16] VALUE | *3-6 | | | | | | 04 40 | Vocoder Band01 Level | 00~7F:0~127 | | 04 41 | Vocoder Band02 Level | 00~7F:0~127 | | 04 42 | Vocoder Band03 Level | 00~7F:0~127 | | 04 43 | Vocoder Band04 Level | 00~7F:0~127 | | 04 44 | Vocoder Band05 Level | 00~7F:0~127 | | 04 45 | Vocoder Band06 Level | 00~7F:0~127 | | 04 46 | Vocoder Band07 Level | 00~7F:0~127 | | 04 47 | Vocoder Band08 Level | 00~7F:0~127 | | 04 48 | Vocoder Band09 Level | 00~7F:0~127 | | 04 49 | Vocoder Band10 Level | 00~7F:0~127 | | 04 4A | Vocoder Band11 Level | 00~7F:0~127 | | 04 4B | Vocoder Band12 Level | 00~7F:0~127 | | 04 4C | Vocoder Band13 Level | 00~7F:0~127 | | 04 4D | Vocoder Band14 Level | 00~7F:0~127 | | 04 4E | Vocoder Band15 Level | 00~7F:0~127 | | 04 4F | Vocoder Band16 Level | 00~7F:0~127 | | | | | | 04 50 | Vocoder Band01 Panpot | *3-8 | | 04 51 | Vocoder Band02 Panpot | *3-8 | | 04 52 | Vocoder Band03 Panpot | *3-8 | | 04 53 | Vocoder Band04 Panpot | *3-8 | | 04 54 | Vocoder Band05 Panpot | *3-8 | | 04 55 | Vocoder Band06 Panpot | *3-8 | | 04 56 | Vocoder Band07 Panpot | *3-8 | | 04 57 | Vocoder Band08 Panpot | *3-8 | | 04 58 | Vocoder Band09 Panpot | *3-8 | | 04 59 | Vocoder Band10 Panpot | *3-8 | | 04 5A | Vocoder Band11 Panpot | *3-8 | | 04 5B | Vocoder Band12 Panpot | *3-8 | | 04 5C | Vocoder Band13 Panpot | *3-8 | | 04 5D | Vocoder Band14 Panpot | *3-8 | | 04 5E | Vocoder Band15 Panpot | *3-8 | | 04 5F | Vocoder Band16 Panpot | *3-8 | | | | | | 04 60 | Vocoder Fc Mod.Source | *3-4 | | | | | | 05 00 | Timbre1 SW | 00~3F/40~7F:OFF/ON | | 05 01 | Timbre2 SW | 00~3F/40~7F:OFF/ON | | 05 02 | Timbre3 SW | 00~3F/40~7F:OFF/ON | | 05 03 | Timbre4 SW | 00~3F/40~7F:OFF/ON | | 05 04 | Vocoder SW | 00~3F/40~7F:OFF/ON | +---------+-----------------------------+------------------------+ All these parameters can be changed by "Data Entry(MSB)".

2-3 UNIVERSAL SYSTEM EXCLUSIVE MESSAGE ( NON REALTIME )

DEVICE INQUIRY MESSAGE REQUEST +---------+------------------------------------------------+ | Byte[H] | Description | +---------+------------------------------------------------+ | F0 | Exclusive Status | | 7E | Non Realtime Message | | nn | MIDI Channel (Device ID) | | 06 | General Information | | 01 | Identity Request | | F7 | END OF EXCLUSIVE | +---------+------------------------------------------------+ nn : MIDI Channel = 0 ~ F :Global Channel = 7F :Any Channel

10

2-4 UNIVERSAL SYSTEM EXCLUSIVE MESSAGE ( REALTIME )

(1) MASTER VOLUME +---------+------------------------------------------------+ | Byte[H] | Description | +---------+------------------------------------------------+ | F0 | Exclusive Status | | 7F | Realtime Message | | nn | MIDI Channel (Device ID) | | 04 | Device Control | | 01 | Master Volume | | vv | Value (LSB) | | mm | Value (MSB) | | F7 | END OF EXCLUSIVE | +---------+------------------------------------------------+ nn : MIDI Channel = 0~F : Global Channel = 7F : Any Channel mm,vv : 00,00~7F,7F : Min~Max

(2) MASTER FINE TUNE +---------+------------------------------------------------+ | Byte[H] | Description | +---------+------------------------------------------------+ | F0 | Exclusive Status | | 7F | Realtime Message | | nn | MIDI Channel (Device ID) | | 04 | Device Control | | 03 | Master Fine Tune | | vv | Value (LSB) | | mm | Value (MSB) | | F7 | END OF EXCLUSIVE | +---------+------------------------------------------------+ nn : MIDI Channel = 0~F : Global Channel = 7F : Any Channel mm,vv : 00,00~40,00~7F,7F : -100~0~+100

2.RECOGNIZED RECEIVE DATA

2-5 SYSTEM EXCLUSIVE MESSAGE +-------------+--------------------------------------------+ | Function ID | Function | | [Hex] | | +-------------+--------------------------------------------+ | 12 | MODE REQUEST | | 10 | CURRENT PROGRAM DATA DUMP REQUEST | | 1C | PROGRAM DATA DUMP REQUEST (1 PROG) | | 13 | CURRENT FORMANT MOTION DATA DUMP REQUEST | | 18 | FORMANT MOTION DATA DUMP REQUEST | | 0E | GLOBAL DATA DUMP REQUEST | | 01 | CURRENT DRUMKIT DATA DUMP REQUEST | | 0D | DRUMKIT DATA DUMP REQUEST (1 DRUMKIT) | | 11 | PROGRAM WRITE REQUEST | | 02 | DRUMKIT WRITE REQUEST | | 03 | FORMANT MOTION DATA WRITE REQUEST | | 7A | TEMPLATE DATA DUMP | | | | | 40 | CURRENT PROGRAM DATA DUMP | | 4C | PROGRAM DATA DUMP (1 PROG) | | 43 | CURRENT FORMANT MOTION DATA DUMP | | 48 | FORMANT MOTION DATA DUMP | | 51 | GLOBAL DATA DUMP | | 31 | CURRENT DRUMKIT DATA DUMP | | 52 | DRUMKIT DATA DUMP (1 DRUMKIT) | | | | | 4E | MODE CHANGE | | 41 | PARAMETER CHANGE | | 53 | DRUMKIT PARAMETER CHANGE | +-------------+--------------------------------------------+ When the "SystemEx" parameter is set to "ENA", these messages are recognized.

MIDI EXCLUSIVE FORMAT (R:Receive, T:Transmit)

(1) MODE REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0001 0010 (12) | MODE REQUEST 12H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=42 message.

(2) CURRENT PROGRAM DATA DUMP REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0001 0000 (10) | CURRENT PROGRAM DATA DUMP REQUEST 10H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=40 or Func=24 message.

11

KORG RADIAS MIDI Implementation

(4) CURRENT FORMANT MOTION DATA DUMP REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0001 0011 (13) | MOTION DATA DUMP REQUEST 13H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=43 or Func=13 message.

(5) FORMANT MOTION DATA DUMP REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0001 1000 (18) | MOTION DATA DUMP REQUEST 18H | | 0000 ffff (0f) | FORMANT MOTION No.(0~15) | | 0000 0000 (00) | | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=48 or Func=24 message.

(6) GLOBAL DATA DUMP REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0000 1110 (0E) | GLOBAL DATA DUMP REQUEST 0EH | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=51 or Func=24 message.

(7) CURRENT DRUMKIT DATA DUMP REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0000 0001 (01) | CURRENT DRUMKIT DATA DUMP REQUEST 01H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=31 or Func=24 message.

(8) DRUMKIT DATA DUMP REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0000 1100 (0D) | PROGRAM DATA DUMP REQUEST 0DH | | 000k kkkk (kk) | Source DrumKit No.(0~31) | | 0000 0000 (00) | | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=52 or Func=24 message.

(10) DRUMKIT WRITE REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0000 0010 (02) | DRUMKIT WRITE REQUEST 02H | | 000k kkkk (kk) | Destination DrumKit No.(0~31) | | 0000 0000 (00) | | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=21 or Func=22 message.

12

2.RECOGNIZED RECEIVE DATA

(11) FORMANT MOTION DATA WRITE REQUEST R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0000 0011 (03) | DRUMKIT WRITE REQUEST 03H | | 0000 ffff (ff) | Destination Formant Motion No.(0~15) | | 0000 0000 (00) | | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message, and transmits Func=21 or Func=22 message.

(13) CURRENT PROGRAM DATA DUMP R/T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0100 0000 (40) | CURRENT PROGRAM DATA DUMP 40H | | 0ddd dddd (dd) | Data (NOTE 1,6) | | : | : | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message & data, save them to Edit Buffer and transmits Func=23 or Func=24 message. Receive Func=10 message, and transmits this message & data from Edit Buffer. When Enter the LCD Edit Mode, transmit this message & data from Edit Buffer.

(14) PROGRAM DATA DUMP (1 PROG) R/T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0100 1100 (4C) | PROGRAM DATA DUMP 4CH | | 0ppp pppp (pp) | Program No.(LBS bit 6~0) | | 0000 000p (0p) | Program No.(MSB bit 13~7) | | 0ddd dddd (dd) | Data (NOTE 1,6) | | : | : | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message & data, save them to Internal Memory and transmits Func=23 or Func=24 message. Receive Func=1C message, and transmits this message & data from Internal Memory. When DATA DUMP is executed, transmit this message & data from Internal Memory.

(15) CURRENT FORMANT MOTION DATA DUMP R/T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0100 0011 (43) | CURRENT FORMANT MOTION DATA DUMP 43H | | 0000 0000 (00) | | | 0sss ssss (ss) | FORMANT MOTION DATA SIZE (bit 6~ 0) | | 0sss ssss (ss) | FORMANT MOTION DATA SIZE (bit 13~ 7) | | 0000 0000 (00) | | | 0ddd dddd (dd) | Data (NOTE 4,6) | | : | : | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message & data, save them to Internal Memory and transmits Func=23 or Func=24 message. Receive Func=13 message, and transmits this message & data from Internal Memeory. When DATA DUMP is executed, transmit this message & data from Internal Memory.

13

KORG RADIAS MIDI Implementation

(17) GLOBAL DATA DUMP R/T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0101 0001 (51) | GLOBAL DATA DUMP 51H | | 0ddd dddd (dd) | Data (NOTE 3,6) | | : | : | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message & data, save them to Internal Memory and transmits Func=23 or Func=24 message. Receive Func=0E message, and transmits this message & data from Edit Buffer. When DATA DUMP is executed, transmit this message & data from Edit Buffer.

(18) CURRENT DRUMKIT DATA DUMP R/T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0011 0001 (31) | CURRENT DRUMKIT DATA DUMP 31H | | 0ddd dddd (dd) | Data (NOTE 2,6) | | : | : | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message & data, save them to Edit Buffer and transmits Func=23 or Func=24 message. Receive Func=01 message, and transmits this message & data from Edit Buffer. When Enter the LCD Edit Mode, transmit this message & data from Edit Buffer.

(19) DRUMKIT DATA DUMP (1 DRUMKIT) R/T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0101 0010 (52) | DRUMKIT DATA DUMP 52H | | 000k kkkk (kk) | DrumKit No.(0~31) | | 0000 0000 (00) | | | 0ddd dddd (dd) | Data (NOTE 2,6) | | : | : | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message & data, save them to Internal Memory and transmits Func=23 or Func=24 message. Receive Func=0D message, and transmits this message & data from Edit Buffer. When DATA DUMP is executed, transmit this message & data from Edit Buffer.

(20) TEMPLATE DATA DUMP R +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0111 1011 (7B) | TEMPLATE DATA DUMP 7BH | | 0000 00kk (kk) | Template kind (NOTE 8) | | 0ddd dddd (dd) | Data (NOTE 9,6) | | : | : | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message & data, save them to Internal Memory and transmits Func=23 or Func=24 message. Receive Func=7A,kk message, and transmits this message & data from Internal Memeory. When DATA DUMP is executed, transmit this message & data from Internal Memory.

(21) MODE CHANGE R/T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0100 1110 (4E) | MODE CHANGE 4EH | | 0000 00mm (0m) | Mode Data (NOTE 5) | | 0000 0000 (00) | | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive this message & data, changes the Mode. and transmits Func=23 or Func=24 message. When the Mode is changed by Switch, transmit this message & data.

14

2.RECOGNIZED RECEIVE DATA

(24) MODE DATA T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0100 0010 (42) | MODE DATA 42H | | 0000 00mm (0m) | Mode Data (NOTE 5) | | 0000 0000 (00) | | | 0000 0000 (00) | | | 0000 0100 (04) | | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ Receive Func=12 message, and transmits this message & data .

(25) RECEIVE DATA FORMAT ERROR T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0010 0110 (26) | DATA FORMAT ERROR 26H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ When found an error in the received message (ex.data length), transmits this message.

(26) DATA LOAD COMPLETED (ACK) T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0010 0011 (23) | DATA LOAD COMPLETED 23H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ When DATA LOAD,PROCESSING have been completed, transmits this message.

(27) DATA LOAD ERROR (NAK) T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0010 0100 (24) | DATA LOAD ERROR 24H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ When DATA LOAD,PROCESSING have not been completed (ex.protect), transmits this message.

(28) WRITE COMPLETED T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0010 0001 (21) | WRITE COMPLETED 21H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ When DATA WRITE MIDI has been completed, transmits this message.

(29) WRITE ERROR T +----------------+--------------------------------------------------+ | Byte | Description | +----------------+--------------------------------------------------+ | F0,42,3g,72 | EXCLUSIVE HEADER | | 0010 0010 (22) | WRITE ERROR 22H | | 1111 0111 (F7) | EOX | +----------------+--------------------------------------------------+ When DATA WRITE MIDI has not been completed, transmits this message.

NOTE 1: CURRENT PROGRAM DATA (IN CURRENT BUFFER) DUMP FORMAT & PROGRAM DATA (IN INTERNAL MEMORY) DUMP FORMAT 1782Bytes = 7*254+4 -> 8*254+(4+1) => 2037Bytes (TABLE 1)

NOTE 2: CURRENT DRUMKIT DATA (IN CURRENT BUFFER) DUMP FORMAT & DRUMKIT DATA (IN INTERNAL MEMORY) DUMP FORMAT 1716Bytes = 7*245+1 -> 8*245+(1+1) => 1962Bytes (TABLE 11)

NOTE 3: GLOBAL DATA (IN INTERNAL MEMORY) DUMP FORMAT 656Bytes = 7*93+5 -> 8*93+(5+1) => 750Bytes (TABLE 12)

15

KORG RADIAS MIDI Implementation

NOTE 4: FORMANT MOTION DATA (IN INTERNAL MEMORY) DUMP FORMAT (FORMANT MOTION DATA SIZE)*16Bytes = 7*X+Y -> 8*X+(1+Y) Bytes (TABLE 13)

NOTE 5: m = 0 : PROGRAM PLAY 1 : PROGRAM EDIT 2 : DRUM PLAY 3 : DRUM EDIT 4 : GLOBAL

NOTE 6: The dump data conversion

DATA ( 1set = 8bit x 7Byte ) b7 ~ b0 b7 ~ b0 b7 ~~ b0 b7 ~ b0 +-+-+-+-+-+-+-+-+ +-+-+-+-+-+-+-+-+ +-+-+-~~-+-+-+ +-+-+-+-+-+-+-+-+ | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | +-+-+-+-+-+-+-+-+ +-+-+-+-+-+-+-+-+ +-+-+-~~-+-+-+ +-+-+-+-+-+-+-+-+ 7n+0 7n+1 7n+2 ~~ 7n+5 7n+6

MIDI DATA ( 1set = 7bit x 8Byte ) b7b7b7b7b7b7b7 b6 ~ b0 b6 ~~ b0 b6 ~ b0 +-+-+-+-+-+-+-+-+ +-+-+-+-+-+-+-+-+ +-+-+-~~-+-+-+ +-+-+-+-+-+-+-+-+ |0| | | | | | | | |0| | | | | | | | |0| | | | | |0| | | | | | | | +-+-+-+-+-+-+-+-+ +-+-+-+-+-+-+-+-+ +-+-+-~~-+-+-+ +-+-+-+-+-+-+-+-+ 7n+6,5,4,3,2,1,0 7n+0 7n+1 ~~ 7n+5 7n+6

NOTE 7: MIDI Parameter Change Message Format F0,42,3n,72,41,PP,pp,QQ,qq,vv,VV,F7 n :Global MIDI Ch. 72 :RADIAS ID

parameter ID :PPpp = 0~3FFF parameter sub ID :QQpp = 0~3FFF parameter value :VVvv = signed value

VV(PP)(QQ):0MMMMMMMvv(pp)(qq):0LLLLLLL value(No.):MMMMMM MLLLLLLL

(See the parameter lists. : TABLE ?)

NOTE 8: k = 0 : ALL TIMBRE PROGRAM 1 : ALL INSERT FX 2 : ALL MASTER FX

NOTE 9: TEMPLATE DATA (IN INTERNAL MEMORY) DUMP FORMAT ALL TIMBRE PROGRAM (TIMB PROG DATA SIZE)*128Bytes = 7*4681+1 -> 8*4681+(1+1) => 37450Bytes (TABLE 14) ALL INSERT FX (INSERT FX DATA SIZE)*128Bytes = 7*1170+2 -> 8*1170+(2+1) => 9363Bytes (TABLE 15) ALL MASTER FX (INSERT FX DATA SIZE)*128Bytes = 7*877+5 -> 8*877+(5+1) => 7022Bytes (TABLE 16)

16

TABLE 1 : PROGRAM PARAMETER ( 1 PROG, CURRENT PROG ) No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | 0~11 | program name | ASCII code [0]~[11]=Head~Tail | 00:00~0B | +-----------+-------------------+-----------------------------------+----------+ | 12~15 | (dummy bytes) | 00:-- | +-----------+-------------------+-----------------------------------+----------+ | 16 | category no. | 0~15 | 00:10 | +-----------+-------------------+-----------------------------------+----------+ | 17 | (dummy byte) | 00:-- | +-----------+-------------------+-----------------------------------+----------+ | 18 B5~7 | not use | (0,0,0) | 00:-- | | -------+-------------------+-----------------------------------+----------+ | B4 | Vocoder select | 0,1=Off,On | 00:16 | | -------+-------------------+-----------------------------------+----------+ | B3 | Timb4 select | 0,1=Off,On | 00:15 | | B2 | Timb3 select | 0,1=Off,On | 00:14 | | B1 | Timb2 select | 0,1=Off,On | 00:13 | | B0 | Timb1 select | 0,1=Off,On | 00:12 | +-----------+-------------------+-----------------------------------+----------+ | 19 B4~7 | Scale Key | 0~11=C,C#,D,D#,E,F,F#,G,G#,A,A#,B | 00:18 | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Scale Type | 0~9=Equal Temp~User Scale *T01-1 | 00:17 | +-----------+-------------------+-----------------------------------+----------+ | 20,21 | (dummy byte) | 00:-- | +-----------+-------------------+-----------------------------------+----------+ | 22 | Illumination Mode | 0~3=OFF~Arp/S.Seq *T01-2 | 00:1F | +-----------+-------------------+-----------------------------------+----------+ | 23 B6,7 | not use | (0,0) | 00:-- | | -------+-------------------+-----------------------------------+----------+ | B5 | Vocoder panel sel | 0,1=Off,On | 00:25 | | -------+-------------------+-----------------------------------+----------+ | B4 | Timb4 panel sel | 0,1=Off,On | 00:24 | | B3 | Timb3 panel sel | 0,1=Off,On | 00:23 | | B2 | Timb2 panel sel | 0,1=Off,On | 00:22 | | B1 | Timb1 panel sel | 0,1=Off,On | 00:21 | | -------+-------------------+-----------------------------------+----------+ | B0 | Link panel edit | 0,1=Off,On | 00:20 | +-----------+-------------------+-----------------------------------+----------+ | 24 B5~7 | Drum Timb select | 0,1~4~=off,T1~4 | 00:29 | | -------+-------------------+-----------------------------------+----------+ | B0~4 | Drum Bank select | 0~31=Drum-1~32 | 00:28 | +-----------+-------------------+-----------------------------------+----------+ | 25 | Drum Level | 0~127 | 00:2A | +-----------+-------------------+-----------------------------------+----------+ | 26 | Drum Panpot | 0~127 | 00:2B | +-----------+-------------------+-----------------------------------+----------+ | 27 | Drum note shift | 64+/-48=0+/-48 | 00:2C | +-----------+-------------------+-----------------------------------+----------+ | 28~31 | (dummy bytes) | 00:-- | +-----------+-------------------+-----------------------------------+----------+ | E.F parameter | +-----------+-------------------+-----------------------------------+----------+ | 32 B3~7 | not use | (0,0,0,0,0) | 00:-- | | -------+-------------------+-----------------------------------+----------+ | B0~2 | Input Source | 0~4=Off,ExtIn1,2,1+2,Int | 00:30 | +-----------+-------------------+-----------------------------------+----------+ | 33 | Sensitivity | 0~127 | 00:31 | +-----------+-------------------+-----------------------------------+----------+ | 34 | Response | 0~127 | 00:32 | +-----------+-------------------+-----------------------------------+----------+ | 35 | Trigger Threshold | 0~127,128~=0~127,Off | 00:33 | +-----------+-------------------+-----------------------------------+----------+ | 36~39 | (dummy bytes) | 00:-- | +-----------+-------------------+-----------------------------------+----------+ | 40 | Trigger note1 | 0~127,128~=C-1~G9,Off | 00:38 + +-----------+-------------------+-----------------------------------+----------+ | 41 | Trigger note2 | 0~127,128~=C-1~G9,Off | 00:39 + +-----------+-------------------+-----------------------------------+----------+ | 42 | Trigger note3 | 0~127,128~=C-1~G9,Off | 00:3A + +-----------+-------------------+-----------------------------------+----------+ | 43 | Trigger note4 | 0~127,128~=C-1~G9,Off | 00:3B + +-----------+-------------------+-----------------------------------+----------+ | 44 | Trigger note5 | 0~127,128~=C-1~G9,Off | 00:3C + +-----------+-------------------+-----------------------------------+----------+ | 45 | Trigger note6 | 0~127,128~=C-1~G9,Off | 00:3D + +-----------+-------------------+-----------------------------------+----------+ | 46 | Trigger note7 | 0~127,128~=C-1~G9,Off | 00:3E + +-----------+-------------------+-----------------------------------+----------+ | 47 | Trigger note8 | 0~127,128~=C-1~G9,Off | 00:3F + +-----------+-------------------+-----------------------------------+----------+ | Timbre parameter | +-----------+-------------------+-----------------------------------+----------+ | 48~273 | TIMBRE1 DATA | Timbre parameter [226] (TABLE 2) | 1x:00~ | +-----------+-------------------+-----------------------------------+----------+ | 274~499 | TIMBRE2 DATA | Timbre parameter [226] (TABLE 2) | 2x:00~ | +-----------+-------------------+-----------------------------------+----------+ | 500~725 | TIMBRE3 DATA | Timbre parameter [226] (TABLE 2) | 3x:00~ | +-----------+-------------------+-----------------------------------+----------+ | 726~951 | TIMBRE4 DATA | Timbre parameter [226] (TABLE 2) | 4x:00~ | +-----------+-------------------+-----------------------------------+----------+ | Vocoder parameter | +-----------+-------------------+-----------------------------------+----------+ | 952~1029 | VOCODER DATA | Vocoder parameter [78] (TABLE 3) | 5x:00~ | +-----------+-------------------+-----------------------------------+----------+ | Master FX parameter | +-----------+-------------------+-----------------------------------+----------+ | 1030~1051 | MASTER FX DATA | Master Ex parameter[22] (TABLE 4) | 6x:00~ |

2.RECOGNIZED RECEIVE DATA

17

KORG RADIAS MIDI Implementation

+-----------+-------------------+-----------------------------------+----------+ | Arpeggio/Step SEQ common parameter | +-----------+-------------------+-----------------------------------+----------+ | 1052 | tempo (LSB) | 200~3000 | 70:00 + | 1053 | (MSB) | | + +-----------+-------------------+-----------------------------------+----------+ | 1054 B7 | Arpg/SSeq On/Off | 0,1=Off,On | 70:01 + | -------+-------------------+-----------------------------------+----------+ | B6 | Key Sync | 0,1=Off,On | 70:02 + | -------+-------------------+-----------------------------------+----------+ | B5 | not use | (0) | 70:-- + | -------+-------------------+-----------------------------------+----------+ | B4 | Step SEQ Link | 0,1=Off,On | 70:03 + | -------+-------------------+-----------------------------------+----------+ | B0~3 | not use | (0,0,0,0) | 70:-- + +-----------+-------------------+-----------------------------------+----------+ | 1055 B6,7 | not use | (0,0,0) | 70:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4 | Link Last step | 0~31=1~32 | 70:04 + +-----------+-------------------+-----------------------------------+----------+ | Arpeggio parameter | +-----------+-------------------+-----------------------------------+----------+ | 1056~1125 | ARPEGGIO DATA | Arpeggio parameter [70] (TABLE 5) | 71:00~4F | +-----------+-------------------+-----------------------------------+----------+ | Step SEQ parameter | +-----------+-------------------+-----------------------------------+----------+ | 1126~1453 | StepSEQ1 DATA | Step SEQ parameter [328](TABLE 6) | 78~79:00~| +-----------+-------------------+-----------------------------------+----------+ | 1454~1781 | StepSEQ2 DATA | Step SEQ parameter [328](TABLE 6) | 7C~7D:00~| +-----------+-------------------+-----------------------------------+----------+

TABLE 2 : TIMBRE PARAMETER ( 1 TIMBRE ) No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0 B7 | Timbre SW | 0,1=Off,On | x0:00 | | -------+-------------------+-----------------------------------+----------+ | B5,6 | not use | (0,0) | x0:-- | | -------+-------------------+-----------------------------------+----------+ | B4 | Sub Output select | 0,1=IndL/R,IntBus | x0:02 | | -------+-------------------+-----------------------------------+----------+ | B2,3 | Arpg/Sseq Assign | 0~3=Off,Arpg,Sseq-A,Sseq-B | x0:01 | | -------+-------------------+-----------------------------------+----------+ | B0,1 | not use | (0,0) | x0:-- | +-----------+-------------------+-----------------------------------+----------+ | +1 | (dummy byte) | +-----------+-------------------+-----------------------------------+----------+ | +2 | Out Balance | 0~127 | x0:04 | +-----------+-------------------+-----------------------------------+----------+ | +3 | (dummy byte) | x0:-- | +-----------+-------------------+-----------------------------------+----------+ | MIDI parameter | +-----------+-------------------+-----------------------------------+----------+ | +4 | MIDI ch. | 0~15,16~=1~16ch,GLOBAL | x1:00 | +-----------+-------------------+-----------------------------------+----------+ | +5 B7 | Pitch Bend filter| 0,1=Dis,Ena | x1:0F | | -------+-------------------+-----------------------------------+----------+ | B6 | ControlChg filter| 0,1=Dis,Ens | x1:0E | | -------+-------------------+-----------------------------------+----------+ | B5 | Foot Pdl&Sw filter| 0,1=Dis,Ena | x1:0D | | -------+-------------------+-----------------------------------+----------+ | B4 | Mod wheel filter| 0,1=Dis,Ena | x1:0C | | -------+-------------------+-----------------------------------+----------+ | B3 | PortamentSW filter| 0,1=Dis,Ena | x1:0B | | -------+-------------------+-----------------------------------+----------+ | B2 | Damper Pdl filter| 0,1=Dis,Ena | x1:0A | | -------+-------------------+-----------------------------------+----------+ | B1 | After Touch filter| 0,1=Dis,Ena | x1:09 | | -------+-------------------+-----------------------------------+----------+ | B0 | Program.Chg filter| 0,1=Dis,Ena | x1:08 | +-----------+-------------------+-----------------------------------+----------+ | Key Window parameter | +-----------+-------------------+-----------------------------------+----------+ | +6 | Key Window Bottom | 0~127=C-1~G9 | x2:00 | +-----------+-------------------+-----------------------------------+----------+ | +7 | Key Window Top | 0~127=C-1~G9 | x2:01 | +-----------+-------------------+-----------------------------------+----------+ | +8 B7 | Unision SW | 0,1=Off,On | x3:00 | | -------+-------------------+-----------------------------------+----------+ | B4~6 | not use | (0,0,0) | x3:-- | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Unison Voice | 0~4,5~=2Voice~6Voice | x3:01 | +-----------+-------------------+-----------------------------------+----------+ | +9 | Unison Detune | 0~99=0~99[cent] | x3:02 | +-----------+-------------------+-----------------------------------+----------+ | +10 | Unison Spread | 0~127= | x3:03 | +-----------+-------------------+-----------------------------------+----------+ | +11 | Bend Range | 64+/-12=0+/-12[note] | x4:00 | +-----------+-------------------+-----------------------------------+----------+ | +12 | Portamento Time | 0~127 | x4:01 | +-----------+-------------------+-----------------------------------+----------+ | +13 B4~6 | not use | (0,0,0) | x4:-- | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Portamento Curve | 0~4=LogHard~Exp *T02-1 | x4:02 | +-----------+-------------------+-----------------------------------+----------+ | +14~15 | (dummy bytes) | x4:-- |

18

+-----------+-------------------+-----------------------------------+----------+ | Timbre Program parameter | +-----------+-------------------+-----------------------------------+----------+ | +16~119 | PROGRAM DATA | Program Parameter [104](TABLE 7) | x5~x6:00~| +-----------+-------------------+-----------------------------------+----------+ | Insert Fx parameter | +-----------+-------------------+-----------------------------------+----------+ | +120~171 | INSERT FX DATA | Insert Fx Parameter[52] (TABLE 8) | x9:00~ | +-----------+-------------------+-----------------------------------+----------+ | Motion Seq parameter | +-----------+-------------------+-----------------------------------+----------+ | +172~225 | MOTION SEQ DATA | MotionSeq Parameter[56] (TABLE 9) | xC:00~ | +-----------+-------------------+-----------------------------------+----------+

TABLE 3 : VOCODER PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0 B7 | SW | 0,1=Dis,Ena | 50:00 | | -------+-------------------+-----------------------------------+----------+ | B6 | Source | 0,1=Modulator,Formant Rec Data | 50:05 | | -------+-------------------+-----------------------------------+----------+ | B5 | HPF Gate | 0,1=Dis,Ena | 50:04 | | -------+-------------------+-----------------------------------+----------+ | B4 | FormantDataPlay | 0,1=FreeRun,Trig Reset | 50:03 | | -------+-------------------+-----------------------------------+----------+ | B2,3 | Input Source2 | 0~3=ExtIn1,IntBus(L+R),(L),(R) | 50:02 | | -------+-------------------+-----------------------------------+----------+ | B0,1 | Select | 0~3=ExtIn2,IntBus(L+R),(L),(R) | 50:01 | +-----------+-------------------+-----------------------------------+----------+ | +1 | Gate Sens | 0~127=0~127 | 50:06 | +-----------+-------------------+-----------------------------------+----------+ | +2 | Threshold | 0~127 | 50:07 | +-----------+-------------------+-----------------------------------+----------+ | +3 | HPF Level | 0~127 | 50:08 | +-----------+-------------------+-----------------------------------+----------+ | +4 | Direct Level | 0~127 | 50:09 | +-----------+-------------------+-----------------------------------+----------+ | +5 | Inst Bus Level | 0~127 | 50:0A | +-----------+-------------------+-----------------------------------+----------+ | +6 | Inst Synth Level | 0~127 | 50:0B | +-----------+-------------------+-----------------------------------+----------+ | +7 | Vocoder Level | 0~127 | 50:0C | +-----------+-------------------+-----------------------------------+----------+ | 16 Band parameter | +-----------+-------------------+-----------------------------------+----------+ | +8 | Band1 Panpot | 0,1~64~127=L63,L63~CNT~R63 | 52:00 | +-----------+-------------------+-----------------------------------+----------+ | +9 | Band1 Level | 0~127 | 52:01 | +-----------+-------------------+-----------------------------------+----------+ | +10,11 | Band2 parameter | same as Band1 | 52:02,03 | +-----------+-------------------+-----------------------------------+----------+ | +12,13 | Band3 parameter | same as Band1 | 52:04,05 | +-----------+-------------------+-----------------------------------+----------+ | +14,15 | Band4 parameter | same as Band1 | 52:06,07 | +-----------+-------------------+-----------------------------------+----------+ | +16,17 | Band5 parameter | same as Band1 | 52:08,09 | +-----------+-------------------+-----------------------------------+----------+ | +18,19 | Band6 parameter | same as Band1 | 52:0A,0B | +-----------+-------------------+-----------------------------------+----------+ | +20,21 | Band7 parameter | same as Band1 | 52:0C,0D | +-----------+-------------------+-----------------------------------+----------+ | +22,23 | Band8 parameter | same as Band1 | 52:0E,0F | +-----------+-------------------+-----------------------------------+----------+ | +24,25 | Band9 parameter | same as Band1 | 52:10,11 | +-----------+-------------------+-----------------------------------+----------+ | +26,27 | Band10 parameter | same as Band1 | 52:12,13 | +-----------+-------------------+-----------------------------------+----------+ | +28,29 | Band11 parameter | same as Band1 | 52:14,15 | +-----------+-------------------+-----------------------------------+----------+ | +30,31 | Band12 parameter | same as Band1 | 52:16,17 | +-----------+-------------------+-----------------------------------+----------+ | +32,33 | Band13 parameter | same as Band1 | 52:18,19 | +-----------+-------------------+-----------------------------------+----------+ | +34,35 | Band14 parameter | same as Band1 | 52:1A,1B | +-----------+-------------------+-----------------------------------+----------+ | +36,37 | Band15 parameter | same as Band1 | 52:1C,1D | +-----------+-------------------+-----------------------------------+----------+ | +38,39 | Band16 parameter | same as Band1 | 52:1E,1F | +-----------+-------------------+-----------------------------------+----------+ | | +-----------+-------------------+-----------------------------------+----------+ | +40 B7 | not use | (0) | 53:-- | | -------+-------------------+-----------------------------------+----------+ | B4~6 | Shift | 0~4=0,+1,+2,-1,-2 | 53:01 | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Fc Mod Source | 0~10=EG1~EnvF *T03-1 | 53:00 |

2.RECOGNIZED RECEIVE DATA

19

KORG RADIAS MIDI Implementation

+-----------+-------------------+-----------------------------------+----------+ | FILTER | +-----------+-------------------+-----------------------------------+----------+ | +41 | Cutoff offset | 64+/-63=0+/-63 | 53:10 | +-----------+-------------------+-----------------------------------+----------+ | +42 | Resonance | 0~127 | 53:11 | +-----------+-------------------+-----------------------------------+----------+ | +43 | Fc Mod Intencity | 64+/-63=0+/-63 | 53:12 | +-----------+-------------------+-----------------------------------+----------+ | +44 | E.F.Sens | 0~127 | 53:13 | +-----------+-------------------+-----------------------------------+----------+ | +45 B4~7 | FM Select | 0~15 | 53:18 | | -------+-------------------+-----------------------------------+----------+ | B3 | Timbre4 select | 0,1=Dis,Ena | 53:17 | | -------+-------------------+-----------------------------------+----------+ | B2 | Timbre3 select | 0,1=Dis,Ena | 53:16 | | -------+-------------------+-----------------------------------+----------+ | B1 | Timbre2 select | 0,1=Dis,Ena | 53:15 | | -------+-------------------+-----------------------------------+----------+ | B0 | Timbre1 select | 0,1=Dis,Ena | 53:14 | +-----------+-------------------+-----------------------------------+----------+ | Formant Hold Data | +-----------+-------------------+-----------------------------------+----------+ | +46 | Band1 (LSB) | 0~321767=0~321767 | 54:00 | | +47 | (MSB) | | | +-----------+-------------------+-----------------------------------+----------+ | +48,49 | Band2 parameter | same as Band1 | 54:01 | +-----------+-------------------+-----------------------------------+----------+ | +50,51 | Band3 parameter | same as Band1 | 54:02 | +-----------+-------------------+-----------------------------------+----------+ | +52,53 | Band4 parameter | same as Band1 | 54:03 | +-----------+-------------------+-----------------------------------+----------+ | +54,55 | Band5 parameter | same as Band1 | 54:04 | +-----------+-------------------+-----------------------------------+----------+ | +56,57 | Band6 parameter | same as Band1 | 54:05 | +-----------+-------------------+-----------------------------------+----------+ | +58,59 | Band7 parameter | same as Band1 | 54:06 | +-----------+-------------------+-----------------------------------+----------+ | +60,61 | Band8 parameter | same as Band1 | 54:07 | +-----------+-------------------+-----------------------------------+----------+ | +62,63 | Band9 parameter | same as Band1 | 54:08 | +-----------+-------------------+-----------------------------------+----------+ | +64,65 | Band10 parameter | same as Band1 | 54:09 | +-----------+-------------------+-----------------------------------+----------+ | +66,67 | Band11 parameter | same as Band1 | 54:0A | +-----------+-------------------+-----------------------------------+----------+ | +68,69 | Band12 parameter | same as Band1 | 54:0B | +-----------+-------------------+-----------------------------------+----------+ | +70,71 | Band13 parameter | same as Band1 | 54:0C | +-----------+-------------------+-----------------------------------+----------+ | +72,73 | Band14 parameter | same as Band1 | 54:0D | +-----------+-------------------+-----------------------------------+----------+ | +74,75 | Band15 parameter | same as Band1 | 54:0E | +-----------+-------------------+-----------------------------------+----------+ | +76,77 | Band16 parameter | same as Band1 | 54:0F | +-----------+-------------------+-----------------------------------+----------+

TABLE 4 : MASTER EFFECT PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0 B7 | SW | 0,1=Off,On | 60:00 + | -------+-------------------+-----------------------------------+----------+ | B0~6 | Fx Type | 0~30=NoEffect~TalkingMod *T04-1 | 60:01 + +-----------+-------------------+-----------------------------------+----------+ | +1 B5~7 | not use | (0,0,0,0) | 60:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4 | knob assign | 0~19=param1~20 | 60:02 + +-----------+-------------------+-----------------------------------+----------+ | +2 | parameter 1 | *T04-2 | 61:00 + +-----------+-------------------+-----------------------------------+----------+ | +3 | parameter 2 | *T04-2 | 61:01 + +-----------+-------------------+-----------------------------------+----------+ | +4 | parameter 3 | *T04-2 | 61:02 + +-----------+-------------------+-----------------------------------+----------+ | +5 | parameter 4 | *T04-2 | 61:03 + +-----------+-------------------+-----------------------------------+----------+ | +6 | parameter 5 | *T04-2 | 61:04 + +-----------+-------------------+-----------------------------------+----------+ | +7 | parameter 6 | *T04-2 | 61:05 + +-----------+-------------------+-----------------------------------+----------+ | +8 | parameter 7 | *T04-2 | 61:06 + +-----------+-------------------+-----------------------------------+----------+ | +9 | parameter 8 | *T04-2 | 61:07 + +-----------+-------------------+-----------------------------------+----------+ | +10 | parameter 9 | *T04-2 | 61:08 + +-----------+-------------------+-----------------------------------+----------+ | +11 | parameter 10 | *T04-2 | 61:09 + +-----------+-------------------+-----------------------------------+----------+ | +12 | parameter 11 | *T04-2 | 61:0A + +-----------+-------------------+-----------------------------------+----------+ | +13 | parameter 12 | *T04-2 | 61:0B + +-----------+-------------------+-----------------------------------+----------+ | +14 | parameter 13 | *T04-2 | 61:0C + +-----------+-------------------+-----------------------------------+----------+ | +15 | parameter 14 | *T04-2 | 61:0D + +-----------+-------------------+-----------------------------------+----------+ | +16 | parameter 15 | *T04-2 | 61:0E +

20

+-----------+-------------------+-----------------------------------+----------+ | +17 | parameter 16 | *T04-2 | 61:0F + +-----------+-------------------+-----------------------------------+----------+ | +18 | parameter 17 | *T04-2 | 61:10 + +-----------+-------------------+-----------------------------------+----------+ | +19 | parameter 18 | *T04-2 | 61:11 + +-----------+-------------------+-----------------------------------+----------+ | +20 | parameter 19 | *T04-2 | 61:12 + +-----------+-------------------+-----------------------------------+----------+ | +21 | parameter 20 | *T04-2 | 61:13 + +-----------+-------------------+-----------------------------------+----------+

TABLE 5 : ARPEGGIO PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0 B4~7 | Resolution | 0~8=1/32~1/1 *T05-1 | 71:01 + | -------+-------------------+-----------------------------------+----------+ | B3 | not use | (0) | 71:-- + | -------+-------------------+-----------------------------------+----------+ | B0~2 | Type | 0~5=Up~Trigger *T05-2 | 71:00 + +-----------+-------------------+-----------------------------------+----------+ | +1 B7 | Latch | 0,1=Off,On | 71:06 + | -------+-------------------+-----------------------------------+----------+ | B5,6 | Octave Range | 0~3=1~4 Octave | 71:02 + | -------+-------------------+-----------------------------------+----------+ | B0~4 | Last step | 0~31=1~32 step | 71:03 + +-----------+-------------------+-----------------------------------+----------+ | +2 | gate time offset | 0+/-100=0+/-100[%] | 71:04 + +-----------+-------------------+-----------------------------------+----------+ | +3 | Swing | 0+/-100=0+/-100[%] | 71:05 + +-----------+-------------------+-----------------------------------+----------+ | +4 | Scan zone Bottom | 0~127=C-1~G9 | 71:08 | +-----------+-------------------+-----------------------------------+----------+ | +5 | Scan zone Top | 0~127=C-1~G9 | 71:09 | +-----------+-------------------+-----------------------------------+----------+ | +6 B7 | Step1 SW | 0,1=Off,On | 71:10 + | -------+-------------------+-----------------------------------+----------+ | B0~6 | Step1 GateTime | 0,1~100=Off,1~100[%] | 71:30 + +-----------+-------------------+-----------------------------------+----------+ | +7~37 | Step2~32 SW | same as Step1 SW | 71:11~2F + | | GateTime | same as Step1 GateTime | 71:31~4F + +-----------+-------------------+-----------------------------------+----------+ | +38 | Step1 Velocity | 0,1~127,128~=KBD,1~127,KBD | 71:50 + +-----------+-------------------+-----------------------------------+----------+ | +39~69 | Step2~32 Velocity | same as Step1 Velocity | 71:51~6F + +-----------+-------------------+-----------------------------------+----------+

2.RECOGNIZED RECEIVE DATA

TABLE 6 : STEP SEQ PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0 B4~7 | Resolution | 0~8=1/32~1/1 *T05-1 | +0:01 + | -------+-------------------+-----------------------------------+----------+ | B2,3 | not use | (0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~1 | Run Mode | 0~2=1Shot,Loop,Step | +0:00 + +-----------+-------------------+-----------------------------------+----------+ | +1 B7 | Latch | 0,1=Off,On | +0:06 + | -------+-------------------+-----------------------------------+----------+ | B5~6 | not use | (0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4 | Last step | 0~31=1~32 | +0:03 + +-----------+-------------------+-----------------------------------+----------+ | +2 | gate time offset | 0+/-100=0+/-100[%] | +0:04 + +-----------+-------------------+-----------------------------------+----------+ | +3 | Swing | 0+/-100=0+/-100[%] | +0:05 + +-----------+-------------------+-----------------------------------+----------+ | +4 B7 | Transpose | 0,1=Off,On | +0:02 + | -------+-------------------+-----------------------------------+----------+ | B0~6 | Base Note | 0~127=C-1~G9 | +0:0A + +-----------+-------------------+-----------------------------------+----------+ | +5 | (dummy byte) | +0:-- + +-----------+-------------------+-----------------------------------+----------+ | +6 | Scan zone Bottom | 0~127=C-1~G9 | +0:08 + +-----------+-------------------+-----------------------------------+----------+ | +7 | Scan zone Top | 0~127=C-1~G9 | +0:09 + +-----------+-------------------+-----------------------------------+----------+ | Step SEQ Step parameter + +-----------+-------------------+-----------------------------------+----------+ | +8 B7 | STEP1 SW | 0,1=Off,On | +0:60 + | -------+-------------------+-----------------------------------+----------+ | B0~6 | STEP1 GateTime | 0,1~100=Off,1~100[%] | +0:20 + +-----------+-------------------+-----------------------------------+----------+ | +9~39 | STEP2~32 SW | same as STEP1 SW | +0:61~7F + | | GateTime | same as STEP1 GateTime | +0:21~3F + +-----------+-------------------+-----------------------------------+----------+ | +40~71 | STEP1~32 Velocity | [00]~[31]=STEP[1]~[32] | +0:40~5F + | | | 0,1~127,128~=Kbd,1~127,Kbd | + +-----------+-------------------+-----------------------------------+----------+

21

KORG RADIAS MIDI Implementation

+-----------+-------------------+-----------------------------------+----------+ | Step SEQ Step tone parameter + +-----------+-------------------+-----------------------------------+----------+ | +72 | STEP1 tone1 note | 0~127,128~=C-1~G9,Off | +1:00 + +-----------+-------------------+-----------------------------------+----------+ | +73 | STEP1 tone2 note | 0~127,128~=C-1~G9,Off | +1:01 + +-----------+-------------------+-----------------------------------+----------+ | +74 | STEP1 tone3 note | 0~127,128~=C-1~G9,Off | +1:02 + +-----------+-------------------+-----------------------------------+----------+ | +75 | STEP1 tone4 note | 0~127,128~=C-1~G9,Off | +1:03 + +-----------+-------------------+-----------------------------------+----------+ | +76 | STEP1 tone5 note | 0~127,128~=C-1~G9,Off | +1:04 + +-----------+-------------------+-----------------------------------+----------+ | +77 | STEP1 tone6 note | 0~127,128~=C-1~G9,Off | +1:05 + +-----------+-------------------+-----------------------------------+----------+ | +78 | STEP1 tone7 note | 0~127,128~=C-1~G9,Off | +1:06 + +-----------+-------------------+-----------------------------------+----------+ | +79 | STEP1 tone8 note | 0~127,128~=C-1~G9,Off | +1:07 + +-----------+-------------------+-----------------------------------+----------+ | +80~87 | STEP2 tone param | same as STEP1 tone | +1:08~0F + +-----------+-------------------+-----------------------------------+----------+ | +88~95 | STEP3 tone param | same as STEP1 tone | +1:10~17 + +-----------+-------------------+-----------------------------------+----------+ | +96~103 | STEP4 tone param | same as STEP1 tone | +1:18~1F + +-----------+-------------------+-----------------------------------+----------+ | +104~111 | STEP5 tone param | same as STEP1 tone | +1:20~27 + +-----------+-------------------+-----------------------------------+----------+ | +112~119 | STEP6 tone param | same as STEP1 tone | +1:28~2F + +-----------+-------------------+-----------------------------------+----------+ | +120~127 | STEP7 tone param | same as STEP1 tone | +1:30~37 + +-----------+-------------------+-----------------------------------+----------+ | +128~135 | STEP8 tone param | same as STEP1 tone | +1:38~3F + +-----------+-------------------+-----------------------------------+----------+ | +136~143 | STEP9 tone param | same as STEP1 tone | +1:40~47 + +-----------+-------------------+-----------------------------------+----------+ | +144~151 | STEP10 tone param | same as STEP1 tone | +1:48~4F + +-----------+-------------------+-----------------------------------+----------+ | +152~159 | STEP11 tone param | same as STEP1 tone | +1:50~57 + +-----------+-------------------+-----------------------------------+----------+ | +160~167 | STEP12 tone param | same as STEP1 tone | +1:58~5F + +-----------+-------------------+-----------------------------------+----------+ | +168~175 | STEP13 tone param | same as STEP1 tone | +1:60~67 + +-----------+-------------------+-----------------------------------+----------+ | +176~183 | STEP14 tone param | same as STEP1 tone | +1:68~6F + +-----------+-------------------+-----------------------------------+----------+ | +184~191 | STEP15 tone param | same as STEP1 tone | +1:70~77 + +-----------+-------------------+-----------------------------------+----------+ | +192~199 | STEP16 tone param | same as STEP1 tone | +1:78~7F + +-----------+-------------------+-----------------------------------+----------+ | +200~207 | STEP17 tone param | same as STEP1 tone | +1:80~87 + +-----------+-------------------+-----------------------------------+----------+ | +208~215 | STEP18 tone param | same as STEP1 tone | +1:88~8F + +-----------+-------------------+-----------------------------------+----------+ | +216~223 | STEP19 tone param | same as STEP1 tone | +1:90~97 + +-----------+-------------------+-----------------------------------+----------+ | +224~231 | STEP20 tone param | same as STEP1 tone | +1:98~9F + +-----------+-------------------+-----------------------------------+----------+ | +232~239 | STEP21 tone param | same as STEP1 tone | +1:A0~A7 + +-----------+-------------------+-----------------------------------+----------+ | +240~247 | STEP22 tone param | same as STEP1 tone | +1:A8~AF + +-----------+-------------------+-----------------------------------+----------+ | +248~255 | STEP23 tone param | same as STEP1 tone | +1:B0~B7 + +-----------+-------------------+-----------------------------------+----------+ | +256~263 | STEP24 tone param | same as STEP1 tone | +1:B8~BF + +-----------+-------------------+-----------------------------------+----------+ | +264~271 | STEP25 tone param | same as STEP1 tone | +1:C0~C7 + +-----------+-------------------+-----------------------------------+----------+ | +272~279 | STEP26 tone param | same as STEP1 tone | +1:C8~CF + +-----------+-------------------+-----------------------------------+----------+ | +280~287 | STEP27 tone param | same as STEP1 tone | +1:D0~D7 + +-----------+-------------------+-----------------------------------+----------+ | +288~295 | STEP28 tone param | same as STEP1 tone | +1:D8~DF + +-----------+-------------------+-----------------------------------+----------+ | +296~303 | STEP29 tone param | same as STEP1 tone | +1:E0~E7 + +-----------+-------------------+-----------------------------------+----------+ | +304~311 | STEP30 tone param | same as STEP1 tone | +1:E8~EF + +-----------+-------------------+-----------------------------------+----------+ | +312~319 | STEP31 tone param | same as STEP1 tone | +1:F0~F7 + +-----------+-------------------+-----------------------------------+----------+ | +320~327 | STEP32 tone param | same as STEP1 tone | +1:F8~FF + +-----------+-------------------+-----------------------------------+----------+

22

TABLE 7 : TIMBRE & DRUM PROGRAM PARAMETER No. : No. in the PROGRAM DUMP DATA or DRUMKIT DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0~11 | program name | ASCII code [0]~[11]=Head~Tail | +0:00~0B + +-----------+-------------------+-----------------------------------+----------+ | +12~15 | (dummy bytes) | +0:-- + +-----------+-------------------+-----------------------------------+----------+ | Voice + +-----------+-------------------+-----------------------------------+----------+ | +16 B7 | Assign Mode | 0,1=Mono,Poly | +0:10 + | -------+-------------------+-----------------------------------+----------+ | B6 | Trigger Mode | 0,1=Single,Multi | +0:11 + | -------+-------------------+-----------------------------------+----------+ | B2~5 | not use | (0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0,1 | Key Priority | 0~2=Last,Low,High | +0:12 + +-----------+-------------------+-----------------------------------+----------+ | +17 | (dummy byte) | +0:-- + +-----------+-------------------+-----------------------------------+----------+ | Pitch + +-----------+-------------------+-----------------------------------+----------+ | +18 | Analog Tuning | 0~127 | +0:13 + +-----------+-------------------+-----------------------------------+----------+ | +19 | Transpose | 64+/-48=0+/-48[note] | +0:14 + +-----------+-------------------+-----------------------------------+----------+ | +20 | DeTune | 64+/-50=0+/-50[cent] | +0:15 + +-----------+-------------------+-----------------------------------+----------+ | +21 | Vibrato Int | 64+/-63=0+/-63 | +0:16 + +-----------+-------------------+-----------------------------------+----------+ | Osc1 + +-----------+-------------------+-----------------------------------+----------+ | +22 B7 | not use | (0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B6 | Bus select | 0,1=Ext.In,Int bus | +0:1D | | -------+-------------------+-----------------------------------+----------+ | B4,5 | Osc Mod | 0~3=Waveform,Cross,Unison,VPM | +0:18 + | -------+-------------------+-----------------------------------+----------+ | B0~3 | Wave Type | 0~7=Saw~Audio In *T07-1 | +0:17 + +-----------+-------------------+-----------------------------------+----------+ | +23 | Waveform CTRL1 | 0~127 | +0:19 + +-----------+-------------------+-----------------------------------+----------+ | +24 | Waveform CTRL2 | 0~127 | +0:1A + +-----------+-------------------+-----------------------------------+----------+ | +25 | DWGS wave select | 0~63=EP-Stage~Endless | +0:1B + | | | (when Osc1 Wave is "DWGS") | + +-----------+-------------------+-----------------------------------+----------+ | +26 | PCM wave select | 0~127=BD-99~AT-"doo" | +0:1C + | | | (when Osc1 Wave is "PCM") | + +-----------+-------------------+-----------------------------------+----------+ | Osc2 + +-----------+-------------------+-----------------------------------+----------+ | +27 B6,7 | not use | (0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B4,5 | Mod Select | 0~3=Off,Ring,Sync,RingSync | +0:21 + | -------+-------------------+-----------------------------------+----------+ | B2,3 | not use | (0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0,1 | Wave Type | 0~3=Saw,Squ,Tri,Sin | +0:20 + +-----------+-------------------+-----------------------------------+----------+ | +28 | Semitone | 64+/-24=0+/-24[note] | +0:22 + +-----------+-------------------+-----------------------------------+----------+ | +29 | Tune | 64+/-63=0+/-24[note] | +0:23 + +-----------+-------------------+-----------------------------------+----------+ | Mixer + +-----------+-------------------+-----------------------------------+----------+ | +30 | Osc1 Level | 0~127 | +0:28 + +-----------+-------------------+-----------------------------------+----------+ | +31 | Osc2 Level | 0~127 | +0:29 + +-----------+-------------------+-----------------------------------+----------+ | +32 | Noise Level | 0~127 | +0:2A + +-----------+-------------------+-----------------------------------+----------+ | Filter + +-----------+-------------------+-----------------------------------+----------+ | +33 B7 | Filter Link SW | 0,1=Off,On | +0:37 + | -------+-------------------+-----------------------------------+----------+ | B6 | not use | (0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B4,5 | Filter2 Type | 0~3=LPF,HPF,BPF,COMBO | +0:40 + | -------+-------------------+-----------------------------------+----------+ | B2,3 | not use | (0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0,1 | Filter Routing | 0~3=Single,Serial,Prallel,Indiv | +0:30 + +-----------+-------------------+-----------------------------------+----------+ | +34 | Filter1 Balance | 0~127 | +0:31 + +-----------+-------------------+-----------------------------------+----------+ | +35 | Filter1 Cutoff | 0~127 | +0:32 + +-----------+-------------------+-----------------------------------+----------+ | +36 | Filter1 Resonance | 0~127 | +0:33 + +-----------+-------------------+-----------------------------------+----------+ | +37 | F1 EG1 Intensity | 64+/-63=0+/-63 | +0:34 + +-----------+-------------------+-----------------------------------+----------+ | +38 | F1 Keyboard Track | 64+/-63=0+/-63 | +0:35 + +-----------+-------------------+-----------------------------------+----------+ | +39 | F1 Velocity Sens | 64+/-63=0+/-63 | +0:36 + +-----------+-------------------+-----------------------------------+----------+ | +40 | Filter2 Cutoff | 0~127 | +0:42 + +-----------+-------------------+-----------------------------------+----------+ | +41 | Filter2 Resonance | 0~127 | +0:43 +

2.RECOGNIZED RECEIVE DATA

23

KORG RADIAS MIDI Implementation

+-----------+-------------------+-----------------------------------+----------+ | +42 | F2 EG1 Intensity | 64+/-63=0+/-63 | +0:44 + +-----------+-------------------+-----------------------------------+----------+ | +43 | F2 Keyboard Track | 64+/-63=0+/-63 | +0:45 + +-----------+-------------------+-----------------------------------+----------+ | +44 | F2 Velocity Sens | 64+/-63=0+/-63 | +0:46 + +-----------+-------------------+-----------------------------------+----------+ | Amp + +-----------+-------------------+-----------------------------------+----------+ | +45 | Level | 0~127 | +0:50 + +-----------+-------------------+-----------------------------------+----------+ | +46 B7 | not use | (0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B4~6 | Drive/WS position | 0~1=Pre Flt1,Pre Amp | +0:52 + | -------+-------------------+-----------------------------------+----------+ | B2,3 | not use | (0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0,1 | Mod Type | 0~3=Off/Driver,WaveShape | +0:53 + +-----------+-------------------+-----------------------------------+----------+ | +47 B4~7 | not use | (0,0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~3 | WaveShape Type | 0~10=Decimator~Lvl Boost *T07-2 | +0:51 + +-----------+-------------------+-----------------------------------+----------+ | +48 | Driver/Shaper | 0~127 | +0:54 + +-----------+-------------------+-----------------------------------+----------+ | +49 | Panpot | 0,1~64~127=L63,L63~CNT~R63 | +0:55 + +-----------+-------------------+-----------------------------------+----------+ | +50 | Key Track | 64+/-63=0+/-63 | +0:56 + +-----------+-------------------+-----------------------------------+----------+ | +51 | Punch Level | 0~127 | +0:57 + +-----------+-------------------+-----------------------------------+----------+ | EG1 + +-----------+-------------------+-----------------------------------+----------+ | +52 | Attack Time | 0~127 | +0:60 + +-----------+-------------------+-----------------------------------+----------+ | +53 | Decay Time | 0~127 | +0:61 + +-----------+-------------------+-----------------------------------+----------+ | +54 | Sustain Level | 0~127 | +0:62 + +-----------+-------------------+-----------------------------------+----------+ | +55 | Release Time | 0~127 | +0:63 + +-----------+-------------------+-----------------------------------+----------+ | +56 B3~7 | not use | (0,0,0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~2 | Curve | 0~4=LogHard~Exp *T02-1 | +0:64 + +-----------+-------------------+-----------------------------------+----------+ | +57 | LevelVelocitySens | 64+/-63=0+/-63 | +0:65 + +-----------+-------------------+-----------------------------------+----------+ | +58 | Time VelocitySens | 64+/-63=0+/-63 | +0:66 + +-----------+-------------------+-----------------------------------+----------+ | +59 | Time Key Track | 64+/-63=0+/-63 | +0:67 + +-----------+-------------------+-----------------------------------+----------+ | EG2 + +-----------+-------------------+-----------------------------------+----------+ | +60 | Attack Time | 0~127 | +0:70 + +-----------+-------------------+-----------------------------------+----------+ | +61 | Decay Time | 0~127 | +0:71 + +-----------+-------------------+-----------------------------------+----------+ | +62 | Sustain Level | 0~127 | +0:72 + +-----------+-------------------+-----------------------------------+----------+ | +63 | Release Time | 0~127 | +0:73 + +-----------+-------------------+-----------------------------------+----------+ | +64 B3~7 | not use | (0,0,0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~2 | Curve | 0~4=LogHard~Exp *T02-1 | +0:74 + +-----------+-------------------+-----------------------------------+----------+ | +65 | LevelVelocitySens | 64+/-63=0+/-63 | +0:75 + +-----------+-------------------+-----------------------------------+----------+ | +66 | Time VelocitySens | 64+/-63=0+/-63 | +0:76 + +-----------+-------------------+-----------------------------------+----------+ | +67 | Time Key Track | 64+/-63=0+/-63 | +0:77 + +-----------+-------------------+-----------------------------------+----------+ | EG3 + +-----------+-------------------+-----------------------------------+----------+ | +68 | Attack Time | 0~127 | +0:80 + +-----------+-------------------+-----------------------------------+----------+ | +69 | Decay Time | 0~127 | +0:81 + +-----------+-------------------+-----------------------------------+----------+ | +70 | Sustain Level | 0~127 | +0:82 + +-----------+-------------------+-----------------------------------+----------+ | +71 | Release Time | 0~127 | +0:83 + +-----------+-------------------+-----------------------------------+----------+ | +72 B3~7 | not use | (0,0,0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~2 | Curve | 0~4=LogHard~Exp *T02-1 | +0:84 + +-----------+-------------------+-----------------------------------+----------+ | +73 | LevelVelocitySens | 64+/-63=0+/-63 | +0:85 + +-----------+-------------------+-----------------------------------+----------+ | +74 | Time VelocitySens | 64+/-63=0+/-63 | +0:86 + +-----------+-------------------+-----------------------------------+----------+ | +75 | Time Key Track | 64+/-63=0+/-63 | +0:87 + +-----------+-------------------+-----------------------------------+----------+ | LFO1 + +-----------+-------------------+-----------------------------------+----------+ | +76 B4~7 | not use | (0,0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~3 | Wave | 0~3=Saw,Squ,Tri,S/H | +0:90 + +-----------+-------------------+-----------------------------------+----------+ | +77 | Shape | 64+/-63=0+/-63 | +0:91 + +-----------+-------------------+-----------------------------------+----------+ | +78 | Frequency | 0~127=0~127 *T07-4 | +0:92 + +-----------+-------------------+-----------------------------------+----------+

24

| +79 B7 | Tempo Sync | 0,1=Off,On | +0:93 + | -------+-------------------+-----------------------------------+----------+ | B5,6 | Key Sync | 0~2=Off,Timbre,Voice | +0:94 + | -------+-------------------+-----------------------------------+----------+ | B0~4 | Init Phase | 0~19=Free,0~180 | +0:95 + +-----------+-------------------+-----------------------------------+----------+ | +80 B5~7 | not use | (0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4 | Sync Note | 0~16=8/1~1/64 *T07-5 | +0:96 + +-----------+-------------------+-----------------------------------+----------+ | LFO2 + +-----------+-------------------+-----------------------------------+----------+ | +81 B4~7 | not use | (0,0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~3 | Wave | 0~3=Saw,Squ(+),Tri,S&H | +0:A0 + +-----------+-------------------+-----------------------------------+----------+ | +82 | Shape | 64+/-63=0+/-63 | +0:A1 + +-----------+-------------------+-----------------------------------+----------+ | +83 | Frequency | 0~127 | +0:A2 + +-----------+-------------------+-----------------------------------+----------+ | +84 B7 | Tempo Sync | 0,1=Off,On | +0:A3 + | -------+-------------------+-----------------------------------+----------+ | B5,6 | Key Sync | 0~2=Off,Timbre,Voice | +0:A4 + | -------+-------------------+-----------------------------------+----------+ | B0~4 | Init Phase | 0~19=Free,0~180 | +0:A5 + +-----------+-------------------+-----------------------------------+----------+ | +85 B5~7 | not use | (0,0,0) | +0:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4 | Sync Note | 0~16=8/1~1/64 *T07-5 | +0:A6 + +-----------+-------------------+-----------------------------------+----------+ | PATCH + +-----------+-------------------+-----------------------------------+----------+ | +86 | Patch1 Source | 0~10=EG1~EnvF *T03-1 | +1:00 + +-----------+-------------------+-----------------------------------+----------+ | +87 | Patch1 Destination| 0~14=PITCH~LFO2FREQ *T07-3 | +1:01 + +-----------+-------------------+-----------------------------------+----------+ | +88 | Patch1 Intensity | 64+/-63=0+/-63 | +1:02 + +-----------+-------------------+-----------------------------------+----------+ | +89 | Patch2 Source | 0~10=EG1~EnvF *T03-1 | +1:04 + +-----------+-------------------+-----------------------------------+----------+ | +90 | Patch2 Destination| 0~14=PITCH~LFO2FREQ *T07-3 | +1:05 + +-----------+-------------------+-----------------------------------+----------+ | +91 | Patch2 Intensity | 64+/-63=0+/-63 | +1:06 + +-----------+-------------------+-----------------------------------+----------+ | +92 | Patch3 Source | 0~10=EG1~EnvF *T03-1 | +1:08 + +-----------+-------------------+-----------------------------------+----------+ | +93 | Patch3 Destination| 0~14=PITCH~LFO2FREQ *T07-3 | +1:09 + +-----------+-------------------+-----------------------------------+----------+ | +94 | Patch3 Intensity | 64+/-63=0+/-63 | +1:0A + +-----------+-------------------+-----------------------------------+----------+ | +95 | Patch4 Source | 0~10=EG1~EnvF *T03-1 | +1:0C + +-----------+-------------------+-----------------------------------+----------+ | +96 | Patch4 Destination| 0~14=PITCH~LFO2FREQ *T07-3 | +1:0D + +-----------+-------------------+-----------------------------------+----------+ | +97 | Patch4 Intensity | 64+/-63=0+/-63 | +1:0E + +-----------+-------------------+-----------------------------------+----------+ | +98 | Patch5 Source | 0~10=EG1~EnvF *T03-1 | +1:10 + +-----------+-------------------+-----------------------------------+----------+ | +99 | Patch5 Destination| 0~14=PITCH~LFO2FREQ *T07-3 | +1:11 + +-----------+-------------------+-----------------------------------+----------+ | +100 | Patch5 Intensity | 64+/-63=0+/-63 | +1:12 + +-----------+-------------------+-----------------------------------+----------+ | +101 | Patch6 Source | 0~10=EG1~EnvF *T03-1 | +1:14 + +-----------+-------------------+-----------------------------------+----------+ | +102 | Patch6 Destination| 0~14=PITCH~LFO2FREQ *T07-3 | +1:15 + +-----------+-------------------+-----------------------------------+----------+ | +103 | Patch6 Intensity | 64+/-63=0+/-63 | +1:16 + +-----------+-------------------+-----------------------------------+----------+

2.RECOGNIZED RECEIVE DATA

25

KORG RADIAS MIDI Implementation

TABLE 8 : INSERT FX PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | Fx1 + +-----------+-------------------+-----------------------------------+----------+ | +0 B7 | Effect1 SW | 0,1=Off,On | x9:00 + | -------+-------------------+-----------------------------------+----------+ | B0~6| Effect1 Type | 0~30=NoEffect~TalkingMod *T04-1 | x9:01 + +-----------+-------------------+-----------------------------------+----------+ | +1 | (dummy byte) | x9:-- | +-----------+-------------------+-----------------------------------+----------+ | +2 B5~7| not use | (0,0,0) | x9:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4| Fx1 knob1 assign | 0~19=param1~20 | x9:02 + +-----------+-------------------+-----------------------------------+----------+ | +3 B5~7| not use | (0,0,0) | x9:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4| Fx1 knob2 assign | 0~19=param1~20 | x9:03 + +-----------+-------------------+-----------------------------------+----------+ | +4 | Fx1 Int param 1 | *T08-1 | x9:10 + +-----------+-------------------+-----------------------------------+----------+ | +5 | Fx1 Int param 2 | *T08-1 | x9:11 + +-----------+-------------------+-----------------------------------+----------+ | +6 | Fx1 Int param 3 | *T08-1 | x9:12 + +-----------+-------------------+-----------------------------------+----------+ | +7 | Fx1 Int param 4 | *T08-1 | x9:13 + +-----------+-------------------+-----------------------------------+----------+ | +8 | Fx1 Int param 5 | *T08-1 | x9:14 + +-----------+-------------------+-----------------------------------+----------+ | +9 | Fx1 Int param 6 | *T08-1 | x9:15 + +-----------+-------------------+-----------------------------------+----------+ | +10 | Fx1 Int param 7 | *T08-1 | x9:16 + +-----------+-------------------+-----------------------------------+----------+ | +11 | Fx1 Int param 8 | *T08-1 | x9:17 + +-----------+-------------------+-----------------------------------+----------+ | +12 | Fx1 Int param 9 | *T08-1 | x9:18 + +-----------+-------------------+-----------------------------------+----------+ | +13 | Fx1 Int param 10 | *T08-1 | x9:19 + +-----------+-------------------+-----------------------------------+----------+ | +14 | Fx1 Int param 11 | *T08-1 | x9:1A + +-----------+-------------------+-----------------------------------+----------+ | +15 | Fx1 Int param 12 | *T08-1 | x9:1B + +-----------+-------------------+-----------------------------------+----------+ | +16 | Fx1 Int param 13 | *T08-1 | x9:1C + +-----------+-------------------+-----------------------------------+----------+ | +17 | Fx1 Int param 14 | *T08-1 | x9:1D + +-----------+-------------------+-----------------------------------+----------+ | +18 | Fx1 Int param 15 | *T08-1 | x9:1E + +-----------+-------------------+-----------------------------------+----------+ | +19 | Fx1 Int param 16 | *T08-1 | x9:1F + +-----------+-------------------+-----------------------------------+----------+ | +20 | Fx1 Int param 17 | *T08-1 | x9:20 + +-----------+-------------------+-----------------------------------+----------+ | +21 | Fx1 Int param 18 | *T08-1 | x9:21 + +-----------+-------------------+-----------------------------------+----------+ | +22 | Fx1 Int param 19 | *T08-1 | x9:22 + +-----------+-------------------+-----------------------------------+----------+ | +23 | Fx1 Int param 20 | *T08-1 | x9:23 + +-----------+-------------------+-----------------------------------+----------+ | Fx2 + +-----------+-------------------+-----------------------------------+----------+ | +24~47 | Effect2 parameter | same as Effect1 | x9:30~53 + +-----------+-------------------+-----------------------------------+----------+ | EQ + +-----------+-------------------+-----------------------------------+----------+ | +48 | Low Freq | 0~29=40~1000 [Hz] *T08-2 | x9:60 + +-----------+-------------------+-----------------------------------+----------+ | +49 | Low Gain | 64+/-12=0+/-12 | x9:61 + +-----------+-------------------+-----------------------------------+----------+ | +50 | Hi Freq | 0~29=1.00~18.0 [KHz] *T08-3 | x9:62 + +-----------+-------------------+-----------------------------------+----------+ | +51 | Hi Gain | 64+/-12=0+/-12 | x9:63 + +-----------+-------------------+-----------------------------------+----------+

26

TABLE 9 : MOTION SEQ PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0 B7 | SEQ On/Off | 0,1=Off,On | xC:00 + | -------+-------------------+-----------------------------------+----------+ | B6 | not use | (0) | xC:-- + | -------+-------------------+-----------------------------------+----------+ | B4,5 | Seq Type | 0~3=Fowrd,Reverse,Alt1,Alt2 | xC:02 + | -------+-------------------+-----------------------------------+----------+ | B0~3 | Last Step | 0~15=1~16 | xC:01 + +-----------+-------------------+-----------------------------------+----------+ | +1 B7 | Run Mode | 0,1=1Shot,Loop | xC:03 + | | |(only Loop when KeySync is "OFF".) | + | -------+-------------------+-----------------------------------+----------+ | B6 | not use | (0) | xC:-- + | -------+-------------------+-----------------------------------+----------+ | B4,5 | Key Sync | 0~2=OFF,Timbre,Voice | xC:04 + | -------+-------------------+-----------------------------------+----------+ | B0~3 | Resolution | 0~15=1/48~1/1 *T09-1 | xC:05 + +-----------+-------------------+-----------------------------------+----------+ | +2 ~19 | SEQ1 parameter | SEQ parameter [18] (TABLE 10)| xD:00~ + +-----------+-------------------+-----------------------------------+----------+ | +20~37 | SEQ2 parameter | SEQ parameter [18] (TABLE 10)| xE:00~ + +-----------+-------------------+-----------------------------------+----------+ | +38~55 | SEQ3 parameter | SEQ parameter [18] (TABLE 10)| xF:00~ + +-----------+-------------------+-----------------------------------+----------+

2.RECOGNIZED RECEIVE DATA

TABLE 10: SEQ PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0 | Knob | 0~30=None~Patch4Int *T10-1 | xx:10 + +-----------+-------------------+-----------------------------------+----------+ | +1 B7 | Motion Type | 0,1=Smooth,Step | xx:11 + | -------+-------------------+-----------------------------------+----------+ | B0~6 | not use | (0,0,0,0,0,0,0) | xx:-- + +-----------+-------------------+-----------------------------------+----------+ | +2~17 | Step Value [0~15] | 64+/-63=0+/-63 | xx:00~0F + +-----------+-------------------+-----------------------------------+----------+

TABLE 11: DRUMKIT PARAMETER No. : No. in the DRUMKIT DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | 0~11 | Drum Bank name | ASCII code [0]~[11]=Head~Tail | 00:00~0B + +-----------+-------------------+-----------------------------------+----------+ | 12~15 | (dummy bytes) | 00:-- + +-----------+-------------------+-----------------------------------+----------+ | 16 B4~7 | not use | (0,0,0,0) | 00:-- + | -------+-------------------+-----------------------------------+----------+ | B0~3 | Drum Prog select | 0~15=DrumProg#01~16 | 00:10 + +-----------+-------------------+-----------------------------------+----------+ | 17 | (dummy byte) | 00:-- + +-----------+-------------------+-----------------------------------+----------+ | 18~33 | Excl.Assigne SW | 0,1,2=Off,Group1,2 | 00:20~2F + | | DrumProg#[01~16] | | + +-----------+-------------------+-----------------------------------+----------+ | 34 | Note Off SW | 0,1=Dis,Ena | 00:30~37 + | B0~7 | DrumProg#[01~08] | | + +-----------+-------------------+-----------------------------------+----------+ | 35 | Note Off SW | 0,1=Dis,Ena | 00:38~3F + | B0~7 | DrumProg#[09~16] | | + +-----------+-------------------+-----------------------------------+----------+ | 36~51 | Play Note no. | 0~127=C-1~G9 | 00:40~4F + | | DrumProg#[01~16] | | + +-----------+-------------------+-----------------------------------+----------+ | Drum Program parameter + +-----------+-------------------+-----------------------------------+----------+ | 52~155 | DRUM1 PROG DATA | Program Parameter [104] (TABLE 7) | 10,11:00~+ +-----------+-------------------+-----------------------------------+----------+ | 156~259 | DRUM2 PROG DATA | Program Parameter [104] (TABLE 7) | 12,13:00~+ +-----------+-------------------+-----------------------------------+----------+ | 260~363 | DRUM3 PROG DATA | Program Parameter [104] (TABLE 7) | 14,15:00~+ +-----------+-------------------+-----------------------------------+----------+ | 364~467 | DRUM4 PROG DATA | Program Parameter [104] (TABLE 7) | 16,17:00~+ +-----------+-------------------+-----------------------------------+----------+ | 468~571 | DRUM5 PROG DATA | Program Parameter [104] (TABLE 7) | 18,19:00~+ +-----------+-------------------+-----------------------------------+----------+ | 572~675 | DRUM6 PROG DATA | Program Parameter [104] (TABLE 7) | 1A,1B:00~+ +-----------+-------------------+-----------------------------------+----------+ | 676~779 | DRUM7 PROG DATA | Program Parameter [104] (TABLE 7) | 1C,1D:00~+ +-----------+-------------------+-----------------------------------+----------+ | 780~883 | DRUM8 PROG DATA | Program Parameter [104] (TABLE 7) | 1E,1F:00~+ +-----------+-------------------+-----------------------------------+----------+ | 884~987 | DRUM9 PROG DATA | Program Parameter [104] (TABLE 7) | 20,21:00~+ +-----------+-------------------+-----------------------------------+----------+ | 988~1091 | DRUM10 PROG DATA | Program Parameter [104] (TABLE 7) | 22,23:00~+ +-----------+-------------------+-----------------------------------+----------+ | 1092~1195 | DRUM11 PROG DATA | Program Parameter [104] (TABLE 7) | 24,25:00~+ +-----------+-------------------+-----------------------------------+----------+ | 1196~1299 | DRUM12 PROG DATA | Program Parameter [104] (TABLE 7) | 26,27:00~+ +-----------+-------------------+-----------------------------------+----------+

27

KORG RADIAS MIDI Implementation

| 1300~1403 | DRUM13 PROG DATA | Program Parameter [104] (TABLE 7) | 28,29:00~+ +-----------+-------------------+-----------------------------------+----------+ | 1404~1507 | DRUM14 PROG DATA | Program Parameter [104] (TABLE 7) | 2A,2B:00~+ +-----------+-------------------+-----------------------------------+----------+ | 1508~1611 | DRUM15 PROG DATA | Program Parameter [104] (TABLE 7) | 2C,2D:00~+ +-----------+-------------------+-----------------------------------+----------+ | 1612~1715 | DRUM16 PROG DATA | Program Parameter [104] (TABLE 7) | 2E,2F:00~+ +-----------+-------------------+-----------------------------------+----------+

TABLE 12: GLOBAL PARAMETER No. : No. in the GLOBAL DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | 0 | Master Tune | 0+/-100=430~440~450 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 1 | Transpose | 0+/-12 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 2 B7 | Memory Protect | 0,1=Off,On | --:-- | | -------+-------------------+-----------------------------------+----------+ | B6 | Panel Page Jump | 0,1=Off,On | --:-- | | -------+-------------------+-----------------------------------+----------+ | B5 | Page Memory | 0,1=Off,On | --:-- | | -------+-------------------+-----------------------------------+----------+ | B4 | not use | (0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B3 | Knob Mode | 0,1=JUMP,CATCH | --:-- | | -------+-------------------+-----------------------------------+----------+ | B2 | Position | 0,1=PostKBD,PreTG | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0,1 | Audio In Thru | 0~3=Off,Ext1+2,Ext1,Ext2 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 3 | Vel.Value | 1~127=1~127 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 4 B4~7 | not use | (0,0,0,0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Vel.Curve | 0~7,8=1~8,Const | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 5 | LCD contrast | 0~15=0~15 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 6 B4~7 | not use | (0,0,0,0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0~3 | MIDI Ch. | 0~15=1~16 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 7 B7 | Local Ctrl | 0,1=Off,On | --:-- | | -------+-------------------+-----------------------------------+----------+ | B6 | not use | (0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B4,5 | System routing | 0~2=Both,USB,MIDI | --:-- | | -------+-------------------+-----------------------------------+----------+ | B2,3 | Clock | 0~3=Auto,Internal,Ext(U),Ext(M) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0,1 | not use | (0,0) | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 8 | (dummy byte) | --:-- + +-----------+-------------------+-----------------------------------+----------+ | 9 | MIDI1 Ctrl No. | 0~115=P.Bend~CC#119 *T12-1 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 10 | MIDI2 Ctrl No. | 0~115=P.Bend~CC#119 *T12-1 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 11 | MIDI3 Ctrl No. | 0~115=P.Bend~CC#119 *T12-1 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 12 | MIDI2 Ctrl No. | 0~115=P.Bend~CC#119 *T12-1 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 13 | MIDI3 Ctrl No. | 0~115=P.Bend~CC#119 *T12-1 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 14 B6,7 | not use | (0,0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B5 | SystemEx Filter | 0,1=Dis,Ena | --:-- | | -------+-------------------+-----------------------------------+----------+ | B4 | P.Bend Filter | 0,1=Dis,Ena | --:-- | | -------+-------------------+-----------------------------------+----------+ | B3 | CtrlChg Filter | 0,1=Dis,Ena | --:-- | | -------+-------------------+-----------------------------------+----------+ | B2 | not use | (0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B1 | BankChg Filter | 0,1=Dis,Ena | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0 | ProgChg Filter | 0,1=Dis,Ena | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 15 B4~7 | not use | (0,0,0,0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Ass.Pedal | 0~6=Volume~FootPdl *T12-2 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 16 B7 | Ass.SW Polarity | 0,1= -,+ | --:-- | | -------+-------------------+-----------------------------------+----------+ | B6 | Ass.SW Mode | 0,1=Unlatch,Latch | --:-- | | -------+-------------------+-----------------------------------+----------+ | B4,5 | not use | (0,0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Ass.SW | 0~6=Damper~Arpegio Off/On *T12-3 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 17 | (dummy byte) | --:-- | +-----------+-------------------+-----------------------------------+----------+ | User Scale Parameter | +-----------+-------------------+-----------------------------------+----------+ | 18~29 | User Scale[C]~[B] | 0+/-100=+/-100cent | --:-- | +-----------+-------------------+-----------------------------------+----------+ | 30~317 | (dummy bytes) | --:-- +

28

+-----------+-------------------+-----------------------------------+----------+ | Knob & Switch Ctrl Change No. Map | +-----------+-------------------+-----------------------------------+----------+ | 318~387 | [0]~[69] | *T12-4 | --:-- | | | Ctrl Change No. | -1,0~95,102~119 | | | | | =OFF,CC#00~95,#102~119 | | +-----------+-------------------+-----------------------------------+----------+ | 388~399 | (dummy bytes) | --:-- + +-----------+-------------------+-----------------------------------+----------+ | category name list | +-----------+-------------------+-----------------------------------+----------+ | 400~415 | category 1 name | | --:-- | | | [0]~[15] | ASCII code [0]~[15]=Head~Tail | | | 416~431 | category 2 name | | --:-- | | 432~447 | category 3 name | | --:-- | | 448~463 | category 4 name | | --:-- | | 464~479 | category 5 name | | --:-- | | 480~495 | category 6 name | | --:-- | | 496~511 | category 7 name | | --:-- | | 512~527 | category 8 name | | --:-- | | 528~543 | category 9 name | | --:-- | | 544~559 | category 10 name | | --:-- | | 560~575 | category 11 name | | --:-- | | 576~591 | category 12 name | | --:-- | | 592~607 | category 13 name | | --:-- | | 608~623 | category 14 name | | --:-- | | 624~639 | category 15 name | | --:-- | | 640~655 | category 16 name | | --:-- | +-----------+-------------------+-----------------------------------+----------+

2.RECOGNIZED RECEIVE DATA

TABLE 13: FORMANT MOTION DATA No. : No. in the FORMANT MOTION DUMP DATA. +-----------+-------------------+-----------------------------------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | +-----------+-------------------+-----------------------------------+ | SEQ. STEP[1] Formant parameter (when SEQ. DATA SIZE > 0) | +-----------+-------------------+-----------------------------------+ | 0 | Band[1] Data | 0~FFh Formant data | +-----------+-------------------+-----------------------------------+ | 1 | Band[2] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 2 | Band[3] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 3 | Band[4] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 4 | Band[5] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 5 | Band[6] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 6 | Band[7] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 7 | Band[8] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 8 | Band[9] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 9 | Band[10] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 10 | Band[11] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 11 | Band[12] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 12 | Band[13] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 13 | Band[14] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 14 | Band[15] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | 15 | Band[16] Data | same as Band[1] | +-----------+-------------------+-----------------------------------+ | SEQ. STEP[2]~[16] Formant parameter | +-----------+-------------------+-----------------------------------+ | 16 ~ | SEQ. STEP [2] | same as SEQ. STEP[1] | | | Band[1]~ | (when SEQ. DATA SIZE > 1) | +-----------+-------------------+-----------------------------------+

TABLE 14: TIMBRE PROGRAM TEMPLATE DATA No. : No. in the ALL TIMBRE PROGRAM TEMPLATE DUMP DATA. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | +0~4 | (dummy byte) | --:-- | +-----------+-------------------+-----------------------------------+----------+ | Key Window parameter | +-----------+-------------------+-----------------------------------+----------+ | +6,7 | (dummy byte) | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +8 B7 | Unision SW | 0,1=Off,On | --:-- | | -------+-------------------+-----------------------------------+----------+ | B4~6 | not use | (0,0,0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Unison Voice | 0~4,5~=2Voice~6Voice | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +9 | Unison Detune | 0~99=0~99[cent] | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +10 | Unison Spread | 0~127 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +11 | Bend Range | 64+/-12=0+/-12[note] | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +12 | Portamento Time | 0~127 | --:-- |

29

KORG RADIAS MIDI Implementation

+-----------+-------------------+-----------------------------------+----------+ | +13 B4~6 | not use | (0,0,0) | --:-- | | -------+-------------------+-----------------------------------+----------+ | B0~3 | Portamento Curve | 0~4=LogHard~Exp *T02-1 | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +14~15 | (dummy bytes) | --:-- | +-----------+-------------------+-----------------------------------+----------+ | Timbre Program parameter | +-----------+-------------------+-----------------------------------+----------+ | +16~119 | PROGRAM DATA | Program Parameter [104](TABLE 7) | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +120~255 | (dummy bytes) | --:-- | +-----------+-------------------+-----------------------------------+----------+

TABLE 15: INSERT FX TEMPLATE DATA No. : No. in the ALL INSERT FX TEMPLATE DUMP DATA. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | Template Insert Fx + +-----------+-------------------+-----------------------------------+----------+ | +0~11 | Template name | | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +12 B7 | Effect SW | 0,1=Off,On | --:-- + | -------+-------------------+-----------------------------------+----------+ | B0~6| Effect Type | 0~30=NoEffect~TalkingMod *T04-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +13 | (dummy byte) | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +14 B5~7| not use | (0,0,0) | --:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4| Fx knob1 assign | 0~19=param1~20 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +15 B5~7| not use | (0,0,0) | --:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4| Fx knob2 assign | 0~19=param1~20 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +16 | Fx Int param 1 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +17 | Fx Int param 2 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +18 | Fx Int param 3 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +19 | Fx Int param 4 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +20 | Fx Int param 5 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +21 | Fx Int param 6 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +22 | Fx Int param 7 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +23 | Fx Int param 8 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +24 | Fx Int param 9 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +25 | Fx Int param 10 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +26 | Fx Int param 11 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +27 | Fx Int param 12 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +28 | Fx Int param 13 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +29 | Fx Int param 14 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +30 | Fx Int param 15 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +31 | Fx Int param 16 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +32 | Fx Int param 17 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +33 | Fx Int param 18 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +34 | Fx Int param 19 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +35 | Fx Int param 20 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +36~63 | (dummy bytes) | --:-- | +-----------+-------------------+-----------------------------------+----------+

30

TABLE 16: MASTER FX TEMPLATE DATA No. : No. in the ALL MASTER FX TEMPLATE DUMP DATA. +-----------+-------------------+-----------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+-----------------------------------+----------+ | Template Master Fx + +-----------+-------------------+-----------------------------------+----------+ | +0~11 | Template name | | --:-- | +-----------+-------------------+-----------------------------------+----------+ | +12 B7 | SW | 0,1=Off,On | --:-- + | -------+-------------------+-----------------------------------+----------+ | B0~6| Effect1 Type | 0~30=NoEffect~TalkingMod *T04-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +13 B5~7 | not use | (0,0,0,0) | --:-- + | -------+-------------------+-----------------------------------+----------+ | B0~4 | knob assign | 0~19=param1~20 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +14 | parameter 1 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +15 | parameter 2 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +16 | parameter 3 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +17 | parameter 4 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +18 | parameter 5 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +19 | parameter 6 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +20 | parameter 7 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +21 | parameter 8 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +22 | parameter 9 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +23 | parameter 10 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +24 | parameter 11 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +25 | parameter 12 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +26 | parameter 13 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +27 | parameter 14 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +28 | parameter 15 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +29 | parameter 16 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +30 | parameter 17 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +31 | parameter 18 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +32 | parameter 19 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +33 | parameter 20 | *T08-1 | --:-- + +-----------+-------------------+-----------------------------------+----------+ | +34~47 | (dummy bytes) | --:-- | +-----------+-------------------+-----------------------------------+----------+

2.RECOGNIZED RECEIVE DATA

*T01-1 : 0: Equal Temp 5: Werckmeist 1: Pure Major 6: Kirnberger 2: Pure Minor 7: Slendoro 3: Arabic 8: Pelog 4: Pythagorea 9: User Scale

*T01-2 : 0: OFF 1: Mod.Seq. 2: Mod.Seq.&D.Kit 3: Arp./Step Seq.

*T02-1 : 0:LogHard 1:LogMid 2:LogSoft 3:Lin 4:Exp

*T03-1 : Fc Mod Source, Patch1~6 Source 0: EG1 4: LFO2 8: Key Track 12: MIDI3 1: EG2 5: Velocity 9: EnvF 13: MIDI4 2: EG3 6: Pitch Bend 10: MIDI1 14: MIDI5 3: LFO1 7: Mod Wheel 11: MIDI2

31

KORG RADIAS MIDI Implementation

*T04-1 : Fx Type 0: No Effect 1: St.Compressor 2: St.Limiter 3: St.Gate 4: St.Filter 5: St.Wah 6: St.BandEQ 7: Distortion 8: CabinetSimltr 9: TubePreampSim(IFX) / St.TubePreamp(MFX) 10: St.Decimator 11: Reverb 12: Early Reflect 13: L/C/R Delay 14: St.Delay 15: AutoPanDelay 16: St.AutoPanDly 17: Mod Delay 18: St.Mod Delay 19: Tape Echo 20: St.Chorus 21: Ensemble 22: St.Flanger 23: St.Phaser 24: St.Tremolo 25: St.Ring Mod 26: Pitch Shifter(IFX) / St.PitchShift(MFX) 27: Grain Shifter(IFX) / St.GrainShift(MFX) 28: St.Vibrato 29: RotarySpeaker 30: Talking Mod

*T04-2 : (See midifx.txt.)

*T05-1 : 0: 1/32 3: 1/12 6: 1/4 1: 1/24 4: 1/8 7: 1/2 2: 1/16 5: 1/6 8: 1/1

*T05-2 : 0: Up 1: Down 2: Alt1 3: Alt2 4: Random 5: Trigger

*T07-1 : 0: Saw 4: Noise 8: Audio In 1: Pulse 5: Formant 2: Tri 6: DWGS 3: Sin(Cross) 7: PCM

*T07-2 : 0:Decimator 4:MultiSin 8:SubOSC Sin 1:Hard Clip 5:SubOSC Saw 9:Pickup 2:OctSaw 6:SubOSC Squ 10:Lvl Boost 3:MultiTri 7:SubOSC Tri

*T07-3 : Patch1~6 Destination 0: PITCH 5: NOISE LEVEL 10: DRIVE/WS DEPTH 1: OSC2 PITCH 6: FLT1 TYPE 11: AMP 2: OSC1 CNTL1 7: FLT1 CUTOFF 12: PAN 3: OSC1 LEVEL 8: FLT1 RESONANCE 13: LFO1 FREQ 4: OSC2 LEVEL 9: FLT2 CUTOFF 14: LFO2 FREQ

*T07-4 : [kHz] 0: 0.01 20: 0.21 40: 1.75 60: 4.25 80: 8.50 100: 19.0 120: 65.0 1: 0.02 21: 0.22 41: 1.88 61: 4.38 81: 8.75 101: 20.0 121: 70.0 2: 0.03 22: 0.23 42: 2.00 62: 4.50 82: 9.00 102: 21.5 122: 75.0 3: 0.04 23: 0.24 43: 2.13 63: 4.63 83: 9.25 103: 23.0 123: 80.0 4: 0.05 24: 0.25 44: 2.25 64: 4.75 84: 9.50 104: 24.5 124: 85.0 5: 0.06 25: 0.29 45: 2.38 65: 4.88 85: 9.75 105: 26.0 125: 90.0 6: 0.07 26: 0.33 46: 2.50 66: 5.00 86: 10.0 106: 27.5 126: 95.0 7: 0.08 27: 0.42 47: 2.63 67: 5.25 87: 10.5 107: 29.0 127: 100 8: 0.09 28: 0.50 48: 2.75 68: 5.50 88: 11.0 108: 31.0 9: 0.10 29: 0.58 49: 2.88 69: 5.75 89: 11.5 109: 33.0 10: 0.11 30: 0.67 50: 3.00 70: 6.00 90: 12.0 110: 35.0 11: 0.12 31: 0.75 51: 3.13 71: 6.25 91: 12.5 111: 37.0 12: 0.13 32: 0.83 52: 3.25 72: 6.50 92: 13.0 112: 39.0 13: 0.14 33: 0.92 53: 3.38 73: 6.75 93: 13.5 113: 41.0 14: 0.15 34: 1.00 54: 3.50 74: 7.00 94: 14.0 114: 44.0 15: 0.16 35: 1.13 55: 3.63 75: 7.25 95: 14.5 115: 47.0 16: 0.17 36: 1.25 56: 3.75 76: 7.50 96: 15.0 116: 50.0 17: 0.18 37: 1.38 57: 3.88 77: 7.75 97: 16.0 117: 53.0 18: 0.19 38: 1.50 58: 4.00 78: 8.00 98: 17.0 118: 57.0 19: 0.20 39: 1.63 59: 4.13 79: 8.25 99: 18.0 119: 61.0

*T07-5 : 0: 8/1 4: 3/4 8: 1/4 12: 1/12 16: 1/64 1: 4/1 5: 1/2 9: 3/16 13: 1/16 2: 2/1 6: 3/8 10: 1/6 14: 1/24 3: 1/1 7: 1/3 11: 1/8 15: 1/32

32

*T08-1 : (See midifx.txt.)

*T08-2 : 0: 40 10: 220 20: 420 1: 50 11: 240 21: 440 2: 60 12: 260 22: 460 3: 80 13: 280 23: 480 4: 100 14: 300 24: 500 5: 120 15: 320 25: 600 6: 140 16: 340 26: 700 7: 160 17: 360 27: 800 8: 180 18: 380 28: 900 9: 200 19: 400 29: 1000

*T08-3 : 0: 1.00 10: 3.50 20: 6.00 1: 1.25 11: 3.75 21: 7.00 2: 1.50 12: 4.00 22: 8.00 3: 1.75 13: 4.25 23: 9.00 4: 2.00 14: 4.50 24: 10.0 5: 2.25 15: 4.75 25: 11.0 6: 2.50 16: 5.00 26: 12.0 7: 2.75 17: 5.25 27: 14.0 8: 3.00 18: 5.50 28: 16.0 9: 3.25 19: 5.75 29: 18.0

*T09-1 : 0: 1/48 4: 1/12 8: 3/16 12: 1/2 1: 1/32 5: 3/32 9: 1/4 13: 2/3 2: 1/24 6: 1/8 10: 1/3 14: 3/4 3: 1/16 7: 1/6 11: 3/8 15: 1/1

2.RECOGNIZED RECEIVE DATA

*T10-1 : Motion SEQ1~3 Destination List 0: None 10: NoiseLevel 20: EG1Release 30: Patch4Int 1: Pitch 11: CutOff 21: EG2Attack 2: StepLength 12: Resonance 22: EG2Decay 3: Portamento 13: EG1 Int 23: EG2Sustain 4: OSC1CTRL1 14: KBD Track 24: EG2Release 5: OSC1CTRL2 15: AmpLevel 25: LFO1Freq 6: OSC2Semi 16: Panpot 26: LFO2Freq 7: OSC2Tune 17: EG1Attack 27: Patch1Int 8: OSC1Level 18: EG1Decay 28: Patch2Int 9: OSC2Level 19: EG1Sustain 29: Patch3Int

*T12-1 : 0: P.Bend 2~97: #CC 000~095 1: A.Touch 98~115: #CC 102~119

*T12-2 : 0: Volume 3: A.Touch 6: FootPdl 1: Exp Pdl 4: Mod Wheel 2: Panpot 5: BreathC

*T12-3 : 0: Damper 4: Oct 1: Prog + 5: Portmnt 2: Prog - 6: Arpegio Off/On 3: Oct +

*T12-4 : [+00]: Portamento [+30]: EG1 Sustain [+60]: Vcd Mod Select [+01]: Unison SW [+31]: EG1 Release [+61]: Vcd Direct Level [+02]: OSC1 Wave [+32]: EG2 Attack [+62]: Vcd In Src1 Level [+03]: OSC1 Mod. [+33]: EG2 Decay [+63]: Vcd In Src2 Level [+04]: OSC1 Ctrl1 [+34]: EG2 Sustain [+64]: Vcd Level [+05]: OSC1 Ctrl2 [+35]: EG2 Release [+65]: Vcd Formant Shift [+06]: OSC2 Wave [+36]: LFO1 Wave [+66]: Vcd FC Offset [+07]: OSC2 Mod. [+37]: LFO1 Frequency [+67]: Vcd Resonance [+08]: OSC2 Semitone [+38]: LFO2 Wave [+68]: Vcd Fc Mod.Int [+09]: OSC2 Tune [+39]: LFO2 Frequency [+69]: Vcd E.F. Sens [+10]: OSC1 Level [+40]: Patch1 Int. [+11]: OSC2 Level [+41]: Patch2 Int. [+12]: Noise Level [+42]: Patch3 Int. [+13]: Filter Routing [+43]: Patch4 Int. [+14]: Filter1 TypeBalance [+44]: Patch5 Int. [+15]: Filter1 Cutoff [+45]: Patch6 Int. [+16]: Filter1 Resonance [+46]: EQ Hi.Gain [+17]: Filter1 EG1 Int [+47]: EQ Low.Gain [+18]: Filter1 KeyTrack [+48]: Mod.Seq. SW [+19]: Filt2 Type [+49]: FX1 Edit1 [+20]: Filter2 Cutoff [+50]: FX1 Edit2 [+21]: Filter2 Resonance [+51]: FX2 Edit1 [+22]: Filter2 EG1 Int [+52]: FX2 Edit2 [+23]: Filter2 KeyTrack [+53]: MasterFX Edit [+24]: Amp Level [+54]: FX1 SW [+25]: Panpot [+55]: FX2 SW [+26]: Drive/WS Depth [+56]: MFX SW [+27]: Drive/WS SW [+57]: Vcd Threshold [+28]: EG1 Attack [+58]: Vcd HPF Level [+29]: EG1 Decay [+59]: Vcd HPF Gate

33

KORG RADIAS MIDI Implementation

RADIAS Effect Parameter Structure

TABLE 1 : INSERT EFFECT PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE.

1 St.Compressor +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~,99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +2 | Sensitivity | 1~127=1~127 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Attack | 0~127=0.1~500 msec *T01-01 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Output Level | 0~127=0~127 | x9:+04 | +-----------+-------------------+------------------------------------+----------+

2 St.Limiter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +2 | Ratio | 0~68,69=1.0:1~50.0:1,Inf:1 *T01-02 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Threshold | 24~64=-40~0 dB *T01-03 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Attack | 0~127=0.1~500 msec *T01-01 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Gain Adjust | 23,24~88=-Inf,-40~+24 dB *T01-04 | x9:+05 | +-----------+-------------------+------------------------------------+----------+

3 St.Gate +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +2 | Threshold | 0~127=0~127 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Attack | 0~127=0.1~500 msec *T01-01 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Release | 0~127=0.3~1500 msec *T01-05 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Gain Adjust | 23,24~88=-Inf,-40~+24 dB *T01-04 | x9:+05 | +-----------+-------------------+------------------------------------+----------+

4 St.Filter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Filter Type | 0~4=LPF24,LPF18,LPF12,HPF12,BPF12 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Cutoff | 0~127=0~127 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Resonance | 0~127=0~127 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Trim | 0~127=0~127 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Mod Source | 0,1=LFO,Ctrl | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Mod Intensity | 64+/-63=-63~+63 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Mod Response | 0~127=0~127 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Tempo Sync | 0,1=Off,On | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Shape | 64+/-63=-63~+63 | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO KeySync | 0,1=Off,Timbre | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | Control Source | 0~11=Off~MIDI3 *T04-01 | x9:+15 | +-----------+-------------------+------------------------------------+----------+

34

RADIAS Effect Parameter Structure

5 St.Wah +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Wah Type | 0~5=Y-CRY~M-VOX *T01-06 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Frequency | 64+/-63=-63~+63 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Resonance | 64+/-63=-63~+63 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Mod Source | 0~2=Auto,LFO,Ctrl | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Mod Intensity | 64+/-63=-63~+63 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Mod Response | 0~127=0~127 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Env.Sens | 0~127=0~127 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Env.Shape | 64+/-63=-63~+63 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Tempo Sync | 0,1=Off,On | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Shape | 64+/-63=-63~+63 | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO KeySync | 0,1=Off,Timbre | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+15 | +-----------+-------------------+------------------------------------+----------+ | +16 | Control Source | 0~11=Off~MIDI3 *T04-01 | x9:+16 | +-----------+-------------------+------------------------------------+----------+

6 St.Band EQ +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Trim | 0~127=0~127 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | B1 Type | 0,1=Peaking,Shelv Low | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | B2 Type | 0,1=Peaking,Shelv Hi | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | B1 Frequency | 0~58=20~20 kHz *T01-07 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | B1 Q | 0~95=0.5,0.6~9.9,10 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | B1 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | B2 Frequency | 0~58=20~20 kHz *T01-07 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | B2 Q | 0~95=0.5,0.6~9.9,10 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | B2 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | x9:+09 | +-----------+-------------------+------------------------------------+----------+

7 Distortion +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Gain | 0~127=0~127 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Pre EQ Frequency | 0~58=20~20 kHz *T01-07 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Pre EQ Q | 0~95=0.5,0.6~9.9,10 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Pre EQ Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | B1 Frequency | 0~58=20~20 kHz *T01-07 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | B1 Q | 0~95=0.5,0.6~9.9,10 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | B1 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | B2 Frequency | 0~58=20~20 kHz *T01-07 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | B2 Q | 0~95=0.5,0.6~9.9,10 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | B2 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | B3 Frequency | 0~58=20~20 kHz *T01-07 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | B3 Q | 0~95=0.5,0.6~9.9,10 | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | B3 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Output Level | 0~127=0~127 | x9:+14 | +-----------+-------------------+------------------------------------+----------+

35

KORG RADIAS MIDI Implementation

8 Cabinet Simulator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Cabinet Type | 0~10=Tweed1x8~US_V30 *T01-08 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Air | 0~127=0~127 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Trim | 0~127=0~127 | x9:+03 | +-----------+-------------------+------------------------------------+----------+

9 Tube Preamp Simulator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Tube1 Low Cut | 0~127=0~127 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Tube1 High Cut | 0~127=0~127 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Tube1 Gain | 23,24~64~88=-Inf,-40~0~+24 dB | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Tube1 Bias | 0~100=0~100 % | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Tube1 Satulation | 0~100=0~100 % | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Phase | 0,1=Normal,Inverted | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Tube2 Low Cut | 0~127=0~127 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Tube2 High Cut | 0~127=0~127 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | Tube2 Gain | 23,24~64~88=-Inf,-40~0~+24 dB | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | Tube2 Bias | 0~100=0~100 % | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Tube2 Satulation | 0~100=0~100 % | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | Output Level | 0~127=0~127 | x9:+12 | +-----------+-------------------+------------------------------------+----------+

10 St.Decimator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | PreLPF | 0,1=Off,On | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | HighDamp | 0~100=0~100 % | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Fs | 0~94=1.0,1.5,~47.5,48.0 kHz | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Bit | 0~20=4~24 bit | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Output Level | 0~127=0~127 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Fs Mod Intensity | 64+/-63=-63~+63 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Tempo Sync | 0,1=Off,On | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Shape | 64+/-63=-63~+63 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO KeySync | 0,1=Off,Timbre | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+13 | +-----------+-------------------+------------------------------------+----------+

11 Reverb +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0~2=Hall,Plate,Room | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Reverb Time | 0~127=0.1~10.0sec *T05-01,*T05-02 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | High Damp | 0~100=0~100 % | x9:+03 | +-----------+-------------------+------------------------------------+----------+

36

RADIAS Effect Parameter Structure

12 Early Reflections +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0~3=Sharp,Loose,Mod,Reverse | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | ER Time | 0~87=10~400 msec *T01-09 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Pre Delay | 0~127=0~200 msec *T02-01 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Pre EQ Trim | 0~127=0~127 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +6 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +7 | High Damp | 0~100=0~100 % | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Low Damp | 0~100=0~100 % | x9:+08 | +-----------+-------------------+------------------------------------+----------+

13 L/C/R Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay TempoSync | 0,1=Off,On | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | x9:+02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~1000 msec *T06-04 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | C Delay Time | 0~127=0~1000 msec *T06-04 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | R Delay Time | 0~127=0~1000 msec *T06-04 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | L Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | C Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | R Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | L Delay Level | 0~127=0~127 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | C Delay Level | 0~127=0~127 | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | R Delay Level | 0~127=0~127 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | C Feedback | 0~127=0~127 | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | High Damp | 0~100=0~100 % | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Low Damp | 0~100=0~100 % | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | Trim | 0~127=0~127 | x9:+15 | +-----------+-------------------+------------------------------------+----------+ | +16 | Spread | 0~127=0~127 | x9:+16 | +-----------+-------------------+------------------------------------+----------+

14 St.Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0,1=Stereo,Cross | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Delay TempoSync | 0,1=Off,On | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | x9:+03 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +4 | L Delay Time | 0~127=0~500 msec *T06-03 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | R Delay Time | 0~127=0~500 msec *T06-03 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | L Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | R Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Feedback | 0~127=0~127 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | High Damp | 0~100=0~100 % | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | Low Damp | 0~100=0~100 % | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Trim | 0~127=0~127 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | Spread | 0~127=0~127 | x9:+12 | +-----------+-------------------+------------------------------------+----------+

37

KORG RADIAS MIDI Implementation

15 Auto Panning Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay TempoSync | 0,1=Off,On | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +3 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | x9:+03 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~1000 msec *T06-04 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | R Delay Time | 0~127=0~1000 msec *T06-04 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | L Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | R Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FeedBack | 0~127=0~127 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Depth | 0~127=0~127 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Tempo Sync | 0,1=Off,On | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Shape | 64+/-63=-63~+63 | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO KeySync | 0,1=Off,Timbre | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+15 | +-----------+-------------------+------------------------------------+----------+ | +16 | High Damp | 0~100=0~100 % | x9:+16 | +-----------+-------------------+------------------------------------+----------+ | +17 | Low Damp | 0~100=0~100 % | x9:+17 | +-----------+-------------------+------------------------------------+----------+ | +18 | Trim | 0~127=0~127 | x9:+18 | +-----------+-------------------+------------------------------------+----------+

16 St.Auto Panning Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay Tempo Sync | 0,1=Off,On | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | x9:+02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~500 msec *T06-03 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | R Delay Time | 0~127=0~500 msec *T06-03 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | L Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | R Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FeedBack | 0~127=0~127 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Depth | 0~127=0~127 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Tempo Sync | 0,1=Off,On | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Frequency | 0~127=0.01~100.0Hz *T03-01 | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Shape | 64+/-63=-63~+63 | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO KeySync | 0,1=Off,Timbre | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+15 | +-----------+-------------------+------------------------------------+----------+ | +16 | LFO Spread | 64+/-18=-180~180 [degree] | x9:+16 | +-----------+-------------------+------------------------------------+----------+ | +17 | High Damp | 0~100=0~100 % | x9:+17 | +-----------+-------------------+------------------------------------+----------+ | +18 | Low Damp | 0~100=0~100 % | x9:+18 | +-----------+-------------------+------------------------------------+----------+ | +19 | Trim | 0~127=0~127 | x9:+19 | +-----------+-------------------+------------------------------------+----------+

38

RADIAS Effect Parameter Structure

17 Modulation Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay Tempo Sync | 0,1=Off,On | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | x9:+02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~980 msec *T06-09 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | R Delay Time | 0~127=0~980 msec *T06-09 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | L Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | R Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FeedBack | 0~127=0~127 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Depth | 0~127=0~127 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Spread | 64+/-18=-180~180 [degree] | x9:+10 | +-----------+-------------------+------------------------------------+----------+

18 St.Modulation Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay Tempo Sync | 0,1=Off,On | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | x9:+02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~480 msec *T06-08 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | R Delay Time | 0~127=0~480 msec *T06-08 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | L Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | R Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FeedBack | 0~127=0~127 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Depth | 0~127=0~127 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Spread | 64+/-18=-180~180 [degree] | x9:+10 | +-----------+-------------------+------------------------------------+----------+

19 Tape Echo +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay Tempo Sync | 0,1=Off,On | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | x9:+02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | Tap1 Delay Time | 0~127=0~980 msec *T06-09 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Tap2 Delay Time | 0~127=0~980 msec *T06-09 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Tap1 Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Tap2 Delay Time | 0~13=1/64~1/1 *T06-14 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Tap1 Level | 0~127=0~127 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Tap2 Level | 0~127=0~127 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | FeedBack | 0~127=0~127 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | High Damp | 0~100=0~100 % | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Low Damp | 0~100=0~100 % | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | Trim | 0~127=0~127 | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | Saturation | 0~127=0~127 | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Wah Flatter Freq | 0~127=0.01~100.0 Hz *T03-01 | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | Wah Flatter Depth | 0~127=0~127 | x9:+15 | +-----------+-------------------+------------------------------------+----------+ | +16 | Pre ToneÅ@ | 0~127=0~127 | x9:+16 | +-----------+-------------------+------------------------------------+----------+ | +17 | Spread | 0~127=0~127 | x9:+17 | +-----------+-------------------+------------------------------------+----------+

39

KORG RADIAS MIDI Implementation

20 St.Chorus +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mod Depth | 0~127=0~127 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | LFO Spread | 64+/-18=-180~180 [degree] | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | PreDelay L | 0~119=0~50 msec *T06-12 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | PreDelay R | 0~119=0~50 msec *T06-12 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Trim | 0~127=0~127 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Low EQ Gain | 64+/-30=-15~+15 dB | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | High EQ Gain | 64+/-30=-15~+15 dB | x9:+08 | +-----------+-------------------+------------------------------------+----------+

21 Ensemble +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mod Depth | 0~127=0~127 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Speed | 1~127=1~127 | x9:+02 | +-----------+-------------------+------------------------------------+----------+

22 St.Flanger/CombFilter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0,1=Flanger,Comb | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | [Flanger]Delay | 0~113=0~30 msec *T06-13 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | [Comb] CutOff | 0~127=0~127 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Mod Depth | 0~127=0~127 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Feedback | 0~127=0~127 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | [Flanger]Phase | 0,1=+,- | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Tempo Sync | 0,1=Off,On | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Shape | 64+/-63=-63~+63 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO KeySync | 0,1=Off,Timbre | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO Spread | 64+/-18=-180~180 [degree] | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | High Damp | 0~100=0~100 % | x9:+15 | +-----------+-------------------+------------------------------------+----------+

40

RADIAS Effect Parameter Structure

23 St.Phaser +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0,1=Blue,U-VB | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Manual | 0~127=0~127 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Mod Depth | 0~127=0~127 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Resonance | 0~127=0~127 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Phase | 0,1=+,- | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Tempo Sync | 0,1=Off,On | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Shape | 64+/-63=-63~+63 | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO KeySync | 0,1=Off,Timbre | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Spread | 64+/-18=-180~180 [degree] | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | High Damp | 0~100=0~100 % | x9:+14 | +-----------+-------------------+------------------------------------+----------+

24 St.Tremolo +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mod Depth | 0~127=0~127 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | LFO Tempo Sync | 0,1=Off,On | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Shape | 64+/-63=-63~+63 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO KeySync | 0,1=Off,Timbre | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Spread | 64+/-18=-180~180 [degree] | x9:+09 | +-----------+-------------------+------------------------------------+----------+

25 St.Ring Modulator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | OSC Mode | 0,1=Fixed,Note | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Frequency | 0~127=0~12.0kHz *T03-03 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Offset | 64+/-48=-48~+48 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Fine | 64+/-50=-100,-98~0~98,100 cent | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | OSC Waveform | 0~2=Saw,Tri,Sine | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Intensity | 64+/-63=-63~+63 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Tempo Sync | 0,1=Off,On | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Shape | 64+/-63=-63~+63 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO KeySync | 0,1=Off,Timbre | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Pre LPF | 0~127=0~127 | x9:+14 | +-----------+-------------------+------------------------------------+----------+

41

KORG RADIAS MIDI Implementation

26 Pitch Shifter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Pitch Shift | 64+/-24=-24~+24 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Fine | 64+/-50=-100,-98~0~98,100 cent | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +4 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +5 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +6 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +7 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +8 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +9 | Mode | 0~2=Slow,Medium,Fast | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | High Damp | 0~100=0~100 % | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Trim | 0~127=0~127 | x9:+11 | +-----------+-------------------+------------------------------------+----------+

27 Grain Shifter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Duration TempoSync| 0,1=Off,On | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | x9:+02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | Duration | 0~127=0~500 msec *T06-03 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | not use | | -- | +-----------+-------------------+------------------------------------+----------+ | +5 | LFO Tempo Sync | 0,1=Off,On | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO KeySync | 0,1=Off,Timbre | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Init PhaseÅ@ | 0~18=0,10,20~180 [degree] | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | not use | | -- | +-----------+-------------------+------------------------------------+----------+

28 St.Vibrato +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mod Depth | 0~127=0~127 | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | LFO Tempo Sync | 0,1=Off,On | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Shape | 64+/-63=-63~+63 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO KeySync | 0,1=Off,Timbre | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Spread | 64+/-18=-180~180 [degree] | x9:+09 | +-----------+-------------------+------------------------------------+----------+

42

RADIAS Effect Parameter Structure

29 Rotary Speaker +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mode Switch | 0,1=Rotate,Stop | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | ModeSw. Ctrl. Src | 0~11=Off~MIDI3 *T04-01 | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | ModeSw. Ctrl. Mode| 0,1=Toggle,Moment | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Speaker Ctrl. Type| 0,1=Switch,Manual | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | [Sw]Speed Switch | 0,1=Slow,Fast | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | [Sw]Sw. Ctrl. Src | 0~11=Off~MIDI3 *T04-01 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | [Sw]Sw. Ctrl. Mode| 0,1=Toggle,Moment | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | [Ml]Speed | 1~127=1~127 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | [Ml]Speed Ctrl.Src| 0~11=Off~MIDI3 *T04-01 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | [Ml]Speed Ctrl.Int| 64+/-63=-63~+63 | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Horn/Rotor Balance| 0,1~99,100=Rotor,1:99 ~ 99:1,Horn | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | Horn Acceleration | 0~127=0~127 | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | Horn Ratio | 0,1~76=stop,0.5~2.0 *T01-10 | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Rotor Acceleration| 0~127=0~127 | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | Rotor Ratio | 0,1~76=stop,0.5~2.0 *T01-10 | x9:+15 | +-----------+-------------------+------------------------------------+----------+ | +16 | Mic Distance | 0~127=0~127 | x9:+16 | +-----------+-------------------+------------------------------------+----------+ | +17 | Spread | 0~127=0~127 | x9:+17 | +-----------+-------------------+------------------------------------+----------+ | +18 | Trim | 0~127=0~127 | x9:+18 | +-----------+-------------------+------------------------------------+----------+

30 Talking Modulator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | x9:+00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Voice Control | 64+/-63=Bottom,-62~Center~+62,Top | x9:+01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Voice Top | 0~4=A,I,U,E,O | x9:+02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Voice Center | 0~4=A,I,U,E,O | x9:+03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Voice Bottom | 0~4=A,I,U,E,O | x9:+04 | +-----------+-------------------+------------------------------------+----------+ | +5 | ResonanceÅ@ | 0~127=0~127 | x9:+05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Drive | 0~127=0~127 | x9:+06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Mod Source | 0~2=Auto,LFO,Ctrl | x9:+07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Intensity | 64+/-63=-63~+63 | x9:+08 | +-----------+-------------------+------------------------------------+----------+ | +9 | Mod Response | 0~127=0~127 | x9:+09 | +-----------+-------------------+------------------------------------+----------+ | +10 | [Auto] Env.Sens | 0~127=0~127 | x9:+10 | +-----------+-------------------+------------------------------------+----------+ | +11 | [Auto] Env.Shape | 64+/-63=-63~+63 | x9:+11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Tempo Sync | 0,1=Off,On | x9:+12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | x9:+13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | x9:+14 | +-----------+-------------------+------------------------------------+----------+ | +15 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | x9:+15 | +-----------+-------------------+------------------------------------+----------+ | +16 | LFO Shape | 64+/-63=-63~+63 | x9:+16 | +-----------+-------------------+------------------------------------+----------+ | +17 | LFO KeySync | 0,1=Off,Timbre | x9:+17 | +-----------+-------------------+------------------------------------+----------+ | +18 | LFO Init Phase | 0~18=0,10,20~180 [degree] | x9:+18 | +-----------+-------------------+------------------------------------+----------+ | +19 | [Ctrl] Ctrl.l Src | 0~11=Off~MIDI3 *T04-01 | x9:+19 | +-----------+-------------------+------------------------------------+----------+

43

KORG RADIAS MIDI Implementation

TABLE 2 : MASTER EFFECT PARAMETER No. : No. in the PROGRAM DUMP DATA. Parameter ID & SUB ID [Hex]: for PARAMETER CHANGE.

1 St.Compressor +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Envelope Select | 0,1=LR Mix,LR Indv. | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Sensitivity | 1~127=1~127 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Attack | 0~127=0.1~500 msec *T01-01 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Output Level | 0~127=0~127 | 61:04 | +-----------+-------------------+------------------------------------+----------+

2 St.Limiter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Envelope Select | 0,1=LR Mix,LR Indv. | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Ratio | 0~68,69=1.0:1~50.0:1,Inf:1 *T01-02 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Threshold | 24~64=-40~0dB *T01-03 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Attack | 0~127=0.1~500 msec *T01-01 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Gain Adjust | 23,24~88=-Inf,-40~+24 dB *T01-04 | 61:05 | +-----------+-------------------+------------------------------------+----------+

3 St.Gate +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Envelope Select | 0,1=LR Mix,LR Indv. | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Threshold | 0~127=0~127 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Attack | 0.1~500 msec *T01-01 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Release | 0.3~1500 msec *T01-05 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Gain Adjust | 23,24~88=-Inf,-40~+24 dB *T01-04 | 61:05 | +-----------+-------------------+------------------------------------+----------+

4 St.Filter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Filter Type | 0~4=LPF24,LPF18,LPF12,HPF12,BPF12 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Cutoff | 0~127=0~127 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Resonance | 0~127=0~127 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Trim | 0~127=0~127 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Mod Source | 0,1=LFO,Ctrl | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Mod Intensity | 64+/-63=-63~+63 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Mod Response | 0~127=0~127 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Tempo Sync | 0,1=Off,On | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Shape | 64+/-63=-63~+63 | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO KeySync | 0,1=Off,Timbre | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | Control Source | 0~11=Off~MIDI3 *T04-01 | 61:15 | +-----------+-------------------+------------------------------------+----------+

44

RADIAS Effect Parameter Structure

5 St.Wah +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Wah Type | 0~4=Y-CRY~M-VOX *T01-06 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Frequency | 64+/-63=-63~+63 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Resonance | 64+/-63=-63~+63 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Mod Source | 0~2=Auto,LFO,Ctrl | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Mod Intensity | 64+/-63=-63~+63 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Mod Response | 0~127=0~127 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Env.Sens | 0~127=0~127 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Env.Shape | 64+/-63=-63~+63 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Tempo Sync | 0,1=Off,On | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Shape | 64+/-63=-63~+63 | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO KeySync | 0,1=Off,Timbre | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:15 | +-----------+-------------------+------------------------------------+----------+ | +16 | Control Source | 0~11=Off~MIDI3 *T04-01 | 61:16 | +-----------+-------------------+------------------------------------+----------+

6 4Band EQ +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Trim | 0~127=0~127 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | B1 Type | 0,1=Peaking,Shelv Low | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | B4 Type | 0,1=Peaking,Shelv Hi | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | B1 Frequency | 0~58=20~20 kHz *T01-07 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | B1 Q | 0~95=0.5,0.6~9.9,10 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | B1 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | B2 Frequency | 0~58=20~20 kHz *T01-07 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | B2 Q | 0~95=0.5,0.6~9.9,10 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | B2 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | B3 Frequency | 0~58=20~20 kHz *T01-07 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | B3 Q | 0~95=0.5,0.6~9.9,10 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | B3 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | B4 Frequency | 0~58=20~20 kHz *T01-07 | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | B4 Q | 0~95=0.5,0.6~9.9,10 | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | B4 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | 61:15 | +-----------+-------------------+------------------------------------+----------+

45

KORG RADIAS MIDI Implementation

7 Distortion +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Gain | 0~127=0~127 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Pre EQ Frequency | 0~58=20~20 kHz *T01-07 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Pre EQ Q | 0~95=0.5,0.6~9.9,10 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Pre EQ Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | B1 Frequency | 0~58=20~20 kHz *T01-07 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | B1 Q | 0~95=0.5,0.6~9.9,10 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | B1 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | B2 Frequency | 0~58=20~20 kHz *T01-07 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | B2 Q | 0~95=0.5,0.6~9.9,10 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | B2 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | B3 Frequency | 0~58=20~20 kHz *T01-07 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | B3 Q | 0~95=0.5,0.6~9.9,10 | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | B3 Gain | 64+/-36=-18,-17.5~0~17.5,18 dB | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Output Level | 0~127=0~127 | 61:14 | +-----------+-------------------+------------------------------------+----------+

8 Cabinet Simulator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Cabinet Type | 0~10=Tweed1x8~US_V30 *T01-08 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Air | 0~127=0~127 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Trim | 0~127=0~127 | 61:03 | +-----------+-------------------+------------------------------------+----------+

9 St.Tube Preamp Simulator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Tube1 Low Cut | 0~127=0~127 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Tube1 High Cut | 0~127=0~127 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Tube1 Gain | 23,24~64~88=-Inf,-40~0~+24dB | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Tube1 Bias | 0~100=0~100 % | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Tube1 Satulation | 0~100=0~100 % | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Phase | 0,1=Normal,Inverted | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Tube2 Low Cut | 0~127=0~127 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Tube2 High Cut | 0~127=0~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | Tube2 Gain | 23,24~64~88=-Inf,-40,~0~+24dB | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | Tube2 Bias | 0~100=0~100 % | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Tube2 Satulation | 0~100=0~100 % | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | Output Level | 0~127=0~127 | 61:12 | +-----------+-------------------+------------------------------------+----------+

46

RADIAS Effect Parameter Structure

10 St.Decimator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | PreLPF | 0,1=Off,On | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | HighDamp | 0~100=0~100 % | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Fs | 0~94=1.0,1.5,~47.5,48.0 kHz | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Bit | 0~20=4~24 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Output Level | 0~127=0~127 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Fs Mod Intensity | 64+/-63=-63~+63 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Tempo Sync | 0,1=Off,On | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Shape | 64+/-63=-63~+63 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO KeySync | 0,1=Off,Timbre | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:13 | +-----------+-------------------+------------------------------------+----------+

11 Reverb +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0~5=Hall~BrightRoom *T05-03 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Reverb Time | 0~127=0.1~10.0sec *T05-01,*T05-02 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | High Damp | 0~100=0~100 % | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Pre Delay | 0~127=0~200 msec *T02-01 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Pre Delay Thru | 0~127=0~127 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Pre EQ Trim | 0~127=0~127 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Low EQ Gain | 64+/-30=-15,-14.5~0~14.5,15 dB | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | High EQ Gain | 64+/-30=-15,-14.5~0~14.5,15 dB | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | ER Level | 0~127=0~127 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | Reverb Level | 0~127=0~127 | 61:10 | +-----------+-------------------+------------------------------------+----------+

12 Early Reflections +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0~3=Sharp,Loose,Mod,Reverse | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | ER Time | 0~127=10~800 msec *T01-09 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Pre Delay | 0~127=0~200 msec *T02-01 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Pre EQ Trim | 0~127=0~127 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Low EQ Gain | 64+/-30=-15,-14.5~0~14.5,15 dB | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | High EQ Gain | 64+/-30=-15,-14.5~0~14.5,15 dB | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | High Damp | 0~100=0~100 % | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Low Damp | 0~100=0~100 % | 61:08 | +-----------+-------------------+------------------------------------+----------+

47

KORG RADIAS MIDI Implementation

13 L/C/R Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay TempoSync | 0,1=Off,On | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~1400 msec *T06-06 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | C Delay Time | 0~127=0~1400 msec *T06-06 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | R Delay Time | 0~127=0~1400 msec *T06-06 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | L Delay Time | 0~13=1/64~1/1 *T06-14 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | C Delay Time | 0~13=1/64~1/1 *T06-14 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | R Delay Time | 0~13=1/64~1/1 *T06-14 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | L Delay Level | 0~127=0~127 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | C Delay Level | 0~127=0~127 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | R Delay Level | 0~127=0~127 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | C Feedback | 0~127=0~127 | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | High Damp | 0~100=0~100 % | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Low Damp | 0~100=0~100 % | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | Trim | 0~127=0~127 | 61:15 | +-----------+-------------------+------------------------------------+----------+ | +16 | Spread | 0~127=0~127 | 61:16 | +-----------+-------------------+------------------------------------+----------+

14 St.Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0,1=Stereo,Cross | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Delay TempoSync | 0,1=Off,On | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:03 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +4 | L Delay Time | 0~127=0~700 msec *T06-05 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | R Delay Time | 0~127=0~700 msec *T06-05 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | L Delay Time | 0~13=1/64~1/1 *T06-14 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | R Delay Time | 0~13=1/64~1/1 *T06-14 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Feedback | 0~127=0~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | High Damp | 0~100=0~100 % | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | Low Damp | 0~100=0~100 % | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Trim | 0~127=0~127 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | Spread | 0~127=0~127 | 61:12 | +-----------+-------------------+------------------------------------+----------+

48

RADIAS Effect Parameter Structure

15 Auto Panning Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay TempoSync | 0,1=Off,On | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~1400 msec *T06-06 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | R Delay Time | 0~127=0~1400 msec *T06-06 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | L Delay Time | 0~13=1/64~1/1 *T06-14 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | R Delay Time | 0~13=1/64~1/1 *T06-14 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FeedBack | 0~127=0~127 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Depth | 0~127=0~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Tempo Sync | 0,1=Off,On | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Shape | 64+/-63=-63~+63 | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO KeySync | 0,1=Off,Timbre | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:15 | +-----------+-------------------+------------------------------------+----------+ | +16 | High Damp | 0~100=0~100 % | 61:16 | +-----------+-------------------+------------------------------------+----------+ | +17 | Low Damp | 0~100=0~100 % | 61:17 | +-----------+-------------------+------------------------------------+----------+ | +18 | Trim | 0~127=0~127 | 61:18 | +-----------+-------------------+------------------------------------+----------+

16 St.Auto Panning Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay Tempo Sync | 0,1=Off,On | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~700 msec *T06-05 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | R Delay Time | 0~127=0~700 msec *T06-05 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | L Delay Time | 0~13=1/64~1/1 *T06-14 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | R Delay Time | 0~13=1/64~1/1 *T06-14 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FeedBack | 0~127=0~127 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Depth | 0~127=0~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Tempo Sync | 0,1=Off,On | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Shape | 64+/-63=-63~+63 | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO KeySync | 0,1=Off,Timbre | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:15 | +-----------+-------------------+------------------------------------+----------+ | +16 | LFO Spread | 64+/-18=-180~180 [degree] | 61:16 | +-----------+-------------------+------------------------------------+----------+ | +17 | High Damp | 0~100=0~100 % | 61:17 | +-----------+-------------------+------------------------------------+----------+ | +18 | Low Damp | 0~100=0~100 % | 61:18 | +-----------+-------------------+------------------------------------+----------+ | +19 | Trim | 0~127=0~127 | 61:19 | +-----------+-------------------+------------------------------------+----------+

49

KORG RADIAS MIDI Implementation

17 Modulation Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay Tempo Sync | 0,1=Off,On | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~1380 msec *T06-11 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | R Delay Time | 0~127=0~1380 msec *T06-11 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | L Delay Time | 0~13=1/64~1/1 *T06-14 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | R Delay Time | 0~13=1/64~1/1 *T06-14 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FeedBack | 0~127=0~127 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Depth | 0~127=0~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Spread | 64+/-18=-180~180 [degree] | 61:10 | +-----------+-------------------+------------------------------------+----------+

18 St.Modulation Delay +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay Tempo Sync | 0,1=Off,On | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | L Delay Time | 0~127=0~680 msec *T06-10 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | R Delay Time | 0~127=0~680 msec *T06-10 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | L Delay Time | 0~13=1/64~1/1 *T06-14 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | R Delay Time | 0~13=1/64~1/1 *T06-14 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FeedBack | 0~127=0~127 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Depth | 0~127=0~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Spread | 64+/-18=-180~180 [degree] | 61:10 | +-----------+-------------------+------------------------------------+----------+

19 Tape Echo +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Delay Tempo Sync | 0,1=Off,On | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | Tap1 Delay Time | 0~127=0~1380 msec *T06-11 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Tap2 Delay Time | 0~127=0~1380 msec *T06-11 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Tap1 Delay Time | 0~13=1/64~1/1 *T06-14 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Tap2 Delay Time | 0~13=1/64~1/1 *T06-14 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Tap1 Level | 0~127=0~127 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Tap2 Level | 0~127=0~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | FeedBack | 0~127=0~127 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | High Damp | 0~100=0~100 % | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Low Damp | 0~100=0~100 % | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | Trim | 0~127=0~127 | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | Saturation | 0~127=0~127 | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Wah Flatter Freq | 0~127=0.01~100.0 Hz *T03-01 | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | Wah Flatter Depth | 0~127=0~127 | 61:15 | +-----------+-------------------+------------------------------------+----------+ | +16 | Pre ToneÅ@ | 0~127=0~127 | 61:16 | +-----------+-------------------+------------------------------------+----------+ | +17 | Spread | 0~127=0~127 | 61:17 | +-----------+-------------------+------------------------------------+----------+

50

RADIAS Effect Parameter Structure

20 St.Chorus +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mod Depth | 0~127=0~127 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | LFO Spread | 64+/-18=-180~180 [degree] | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | PreDelay L | 0~119=0~50 msec *T06-12 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | PreDelay R | 0~119=0~50 msec *T06-12 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Trim | 0~127=0~127 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Low EQ Gain | 64+/-30=-15~+15 dB | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | High EQ Gain | 64+/-30=-15~+15 dB | 61:08 | +-----------+-------------------+------------------------------------+----------+

21 Ensemble +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mod Depth | 0~127=0~127 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Speed | 1~127=1~127 | 61:02 | +-----------+-------------------+------------------------------------+----------+

22 St.Flanger/CombFilter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0,1=Flanger,Comb | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | [Flanger]Delay | 0~113=0~30 msec *T06-13 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | [Comb] CutOff | 0~127=0~127 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Mod Depth | 0~127=0~127 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Feedback | 0~127=0~127 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | [Flanger]Phase | 0,1=+,- | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Tempo Sync | 0,1=Off,On | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Shape | 64+/-63=-63~+63 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO KeySync | 0,1=Off,Timbre | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO Spread | 64+/-18=-180~180 [degree] | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | High Damp | 0~100=0~100 % | 61:15 | +-----------+-------------------+------------------------------------+----------+

51

KORG RADIAS MIDI Implementation

23 St.Phaser +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Type | 0,1=Blue,U-VB | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Manual | 0~127=0~127 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Mod Depth | 0~127=0~127 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Resonance | 0~127=0~127 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | Phase | 0,1=+,- | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Tempo Sync | 0,1=Off,On | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Shape | 64+/-63=-63~+63 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO KeySync | 0,1=Off,Timbre | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Spread | 64+/-18=-180~180 [degree] | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | High Damp | 0~100=0~100 % | 61:14 | +-----------+-------------------+------------------------------------+----------+

24 St.Tremolo +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mod Depth | 0~127=0~127 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | LFO Tempo Sync | 0,1=Off,On | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Shape | 64+/-63=-63~+63 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO KeySync | 0,1=Off,Timbre | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Spread | 64+/-18=-180~180 [degree] | 61:09 | +-----------+-------------------+------------------------------------+----------+

25 St.Ring Modulator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | OSC Mode | 0,1=Fixed,Note | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Frequency | 0~127=0~12.0 kHz *T03-03 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Offset | 64+/-48=-48~+48 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Fine | 64+/-50=-100,-98~0~98,100 cent | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | OSC Waveform | 0~2=Saw,Tri,Sine | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Intensity | 64+/-63=-63~+63 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Tempo Sync | 0,1=Off,On | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | LFO Shape | 64+/-63=-63~+63 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO KeySync | 0,1=Off,Timbre | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Pre LPF | 0~127=0~127 | 61:14 | +-----------+-------------------+------------------------------------+----------+

52

RADIAS Effect Parameter Structure

26 St.Pitch Shifter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Pitch Shift | 64+/-24=-24~+24 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Fine | 64+/-50=-100,-98~0~98,100 cent | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Delay Tempo Sync | 0,1=Off,On | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:04 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +5 | Delay Time | 0~127=0~500 msec *T06-03 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Delay Time | 0~13=1/64~1/1 *T06-14 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | FB Position | 0,1=Pre,Post | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Feedback | 0~127=0~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | Mode | 0~2=Slow,Medium,Fast | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | High Damp | 0~100=0~100 % | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Trim | 0~127=0~127 | 61:11 | +-----------+-------------------+------------------------------------+----------+

27 St.Grain Shifter +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Duration TempoSync| 0,1=Off,On | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Time Ratio | 0~127=12.5~400% (Sync=On) *T06-01 | 61:02 | | | | 0~127=0.5~400% (Sync=Off) *T06-02 | | +-----------+-------------------+------------------------------------+----------+ | +3 | Duration | 0~127=0~350 msec *T06-07 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Duration | 0~13=1/64~1/1 *T06-14 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | LFO Tempo Sync | 0,1=Off,On | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO KeySync | 0,1=Off,Timbre | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Init PhaseÅ@ | 0~18=0,10,20~180 [degree] | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | LFO SpreadÅ@ | 64+/-18=-180~180 [degree] | 61:10 | +-----------+-------------------+------------------------------------+----------+

28 St.Vibrato +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mod Depth | 0~127=0~127 | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | LFO Tempo Sync | 0,1=Off,On | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | LFO Shape | 64+/-63=-63~+63 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | LFO KeySync | 0,1=Off,Timbre | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | LFO Spread | 64+/-18=-180~180 [degree] | 61:09 | +-----------+-------------------+------------------------------------+----------+

53

KORG RADIAS MIDI Implementation

29 Rotary Speaker +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Mode Switch | 0,1=Rotate,Stop | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | ModeSw. Ctrl. Src | 0~11=Off~MIDI3 *T04-01 | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | ModeSw. Ctrl. Mode| 0,1=Toggle,Moment | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Speaker Ctrl. Type| 0,1=Switch,Manual | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | [Sw]Speed Switch | 0,1=Slow,Fast | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | [Sw]Sw. Ctrl. Src | 0~11=Off~MIDI3 *T04-01 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | [Sw]Sw. Ctrl. Mode| 0,1=Toggle,Moment | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | [Ml]Speed | 1~127=1~127 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | [Ml]Speed Ctrl.Src| 0~11=Off~MIDI3 *T04-01 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | [Ml]Speed Ctrl.Int| 64+/-63=-63~+63 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | Horn/Rotor Balance| 0,1~99,100=Rotor,1:99 ~ 99:1,Horn | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | Horn Acceleration | 0~127=0~127 | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | Horn Ratio | 0,1~76=stop,0.5~2.0 *T01-10 | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | Rotor Acceleration| 0~127=0~127 | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | Rotor Ratio | 0,1~76=stop,0.5~2.0 *T01-10 | 61:15 | +-----------+-------------------+------------------------------------+----------+ | +16 | Mic Distance | 0~127=0~127 | 61:16 | +-----------+-------------------+------------------------------------+----------+ | +17 | Spread | 0~127=0~127 | 61:17 | +-----------+-------------------+------------------------------------+----------+ | +18 | Trim | 0~127=0~127 | 61:18 | +-----------+-------------------+------------------------------------+----------+

30 Talking Modulator +-----------+-------------------+------------------------------------+----------+ | No. (bit)| PARAMETER | VALUE DESCRIPTION | ID:SubID | +-----------+-------------------+------------------------------------+----------+ | +0 | Dry/Wet | 0,1~99,100=Dry,1:99 ~ 99:1,Wet | 61:00 | +-----------+-------------------+------------------------------------+----------+ | +1 | Voice Control | 64+/-63=Bottom,-62~Center~+62,Top | 61:01 | +-----------+-------------------+------------------------------------+----------+ | +2 | Voice Top | 0~4=A,I,U,E,O | 61:02 | +-----------+-------------------+------------------------------------+----------+ | +3 | Voice Center | 0~4=A,I,U,E,O | 61:03 | +-----------+-------------------+------------------------------------+----------+ | +4 | Voice Bottom | 0~4=A,I,U,E,O | 61:04 | +-----------+-------------------+------------------------------------+----------+ | +5 | ResonanceÅ@ | 0~127=0~127 | 61:05 | +-----------+-------------------+------------------------------------+----------+ | +6 | Drive | 0~127=0~127 | 61:06 | +-----------+-------------------+------------------------------------+----------+ | +7 | Mod Source | 0~2=Auto,LFO,Ctrl | 61:07 | +-----------+-------------------+------------------------------------+----------+ | +8 | Mod Intensity | 64+/-63=-63~+63 | 61:08 | +-----------+-------------------+------------------------------------+----------+ | +9 | Mod Response | 0~127=0~127 | 61:09 | +-----------+-------------------+------------------------------------+----------+ | +10 | [Auto] Env.Sens | 0~127=0~127 | 61:10 | +-----------+-------------------+------------------------------------+----------+ | +11 | [Auto] Env.Shape | 64+/-63=-63~+63 | 61:11 | +-----------+-------------------+------------------------------------+----------+ | +12 | LFO Tempo Sync | 0,1=Off,On | 61:12 | +-----------+-------------------+------------------------------------+----------+ | +13 | LFO Frequency | 0~127=0.01~100.0 Hz *T03-01 | 61:13 | +-----------+-------------------+------------------------------------+----------+ | +14 | LFO Sync Note | 0~16=8/1~1/64 *T03-02 | 61:14 | +-----------+-------------------+------------------------------------+----------+ | +15 | LFO Waveform | 0~4=Saw,Squ,Tri,Sin,S&H | 61:15 | +-----------+-------------------+------------------------------------+----------+ | +16 | LFO Shape | 64+/-63=-63~+63 | 61:16 | +-----------+-------------------+------------------------------------+----------+ | +17 | LFO KeySync | 0,1=Off,Timbre | 61:17 | +-----------+-------------------+------------------------------------+----------+ | +18 | LFO Init Phase | 0~18=0,10,20~180 [degree] | 61:18 | +-----------+-------------------+------------------------------------+----------+ | +19 | [Ctrl] Ctrl.l Src | 0~11=Off~MIDI3 *T04-01 | 61:19 | +-----------+-------------------+------------------------------------+----------+

54

RADIAS Effect Parameter Structure

*T01-01 : [msec] 0: 0.1 16: 1.7 32: 4.7 48: 10.5 64: 23.0 80: 50.0 96: 110 112: 240 1: 0.2 17: 1.8 33: 5.0 49: 11.0 65: 24.0 81: 53.0 97: 115 113: 252 2: 0.3 18: 1.9 34: 5.3 50: 11.5 66: 25.0 82: 55.0 98: 121 114: 265 3: 0.4 19: 2.0 35: 5.6 51: 12.0 67: 27.0 83: 58.0 99: 127 115: 278 4: 0.5 20: 2.2 36: 5.9 52: 12.5 68: 28.0 84: 61.0 100: 133 116: 292 5: 0.6 21: 2.4 37: 6.2 53: 13.0 69: 29.0 85: 64.0 101: 140 117: 307 6: 0.7 22: 2.6 38: 6.5 54: 13.5 70: 31.0 86: 68.0 102: 147 118: 322 7: 0.8 23: 2.8 39: 6.8 55: 14.0 71: 32.0 87: 71.0 103: 155 119: 338 8: 0.9 24: 3.0 40: 7.1 56: 15.0 72: 34.0 88: 75.0 104: 162 120: 355 9: 1.0 25: 3.2 41: 7.4 57: 16.0 73: 36.0 89: 78.0 105: 170 121: 373 10: 1.1 26: 3.4 42: 7.8 58: 17.0 74: 37.0 90: 82.0 106: 179 122: 391 11: 1.2 27: 3.6 43: 8.2 59: 18.0 75: 39.0 91: 86.0 107: 188 123: 411 12: 1.3 28: 3.8 44: 8.6 60: 19.0 76: 41.0 92: 91.0 108: 197 124: 432 13: 1.4 29: 4.0 45: 9.0 61: 20.0 77: 43.0 93: 95.0 109: 207 125: 453 14: 1.5 30: 4.2 46: 9.4 62: 21.0 78: 46.0 94: 99.0 110: 218 126: 476 15: 1.6 31: 4.4 47: 10.0 63: 22.0 79: 48.0 95: 104 111: 229 127: 500

*T01-02 : 0: 1.0:1 16: 9.0:1 32: 17.0:1 48: 30.0:1 64: 46.0:1 1: 1.5:1 17: 9.5:1 33: 17.5:1 49: 31.0:1 65: 47.0:1 2: 2.0:1 18: 10.0:1 34: 18.0:1 50: 32.0:1 66: 48.0:1 3: 2.5:1 19: 10.5:1 35: 18.5:1 51: 33.0:1 67: 49.0:1 4: 3.0:1 20: 11.0:1 36: 19.0:1 52: 34.0:1 68: 50.0:1 5: 3.5:1 21: 11.5:1 37: 19.5:1 53: 35.0:1 69: Inf:1 6: 4.0:1 22: 12.0:1 38: 20.0:1 54: 36.0:1 7: 4.5:1 23: 12.5:1 39: 21.0:1 55: 37.0:1 8: 5.0:1 24: 13.0:1 40: 22.0:1 56: 38.0:1 9: 5.5:1 25: 13.5:1 41: 23.0:1 57: 39.0:1 10: 6.0:1 26: 14.0:1 42: 24.0:1 58: 40.0:1 11: 6.5:1 27: 14.5:1 43: 25.0:1 59: 41.0:1 12: 7.0:1 28: 15.0:1 44: 26.0:1 60: 42.0:1 13: 7.5:1 29: 15.5:1 45: 27.0:1 61: 43.0:1 14: 8.0:1 30: 16.0:1 46: 28.0:1 62: 44.0:1 15: 8.5:1 31: 16.5:1 47: 29.0:1 63: 45.0:1

*T01-03 : 24: -40 32: -32 40: -24 48: -16 56: -8 64: 0 25: -39 33: -31 41: -23 49: -15 57: -7 26: -38 34: -30 42: -22 50: -14 58: -6 27: -37 35: -29 43: -21 51: -13 59: -5 28: -36 36: -28 44: -20 52: -12 60: -4 29: -35 37: -27 45: -19 53: -11 61: -3 30: -34 38: -26 46: -18 54: -10 62: -2 31: -33 39: -25 47: -17 55: -9 63: -1

*T01-04 : 23: -Inf 33: -31 43: -21 53: -11 63: -1 73: 9 83: 19 24: -40 34: -30 44: -20 54: -10 64: 0 74: 10 84: 20 25: -39 35: -29 45: -19 55: -9 65: 1 75: 11 85: 21 26: -38 36: -28 46: -18 56: -8 66: 2 76: 12 86: 22 27: -37 37: -27 47: -17 57: -7 67: 3 77: 13 87: 23 28: -36 38: -26 48: -16 58: -6 68: 4 78: 14 88: 24 29: -35 39: -25 49: -15 59: -5 69: 5 79: 15 30: -34 40: -24 50: -14 60: -4 70: 6 80: 16 31: -33 41: -23 51: -13 61: -3 71: 7 81: 17 32: -32 42: -22 52: -12 62: -2 72: 8 82: 18

*T01-05 : [msec] 0: 0.3 16: 5.1 32: 14 48: 32 64: 69 80: 151 96: 329 112: 720 1: 0.6 17: 5.4 33: 15 49: 33 65: 72 81: 158 97: 346 113: 756 2: 0.9 18: 5.7 34: 16 50: 35 66: 76 82: 166 98: 363 114: 794 3: 1.2 19: 6.0 35: 17 51: 36 67: 80 83: 174 99: 381 115: 834 4: 1.5 20: 6.6 36: 18 52: 38 68: 84 84: 183 100: 400 116: 876 5: 1.8 21: 7.2 37: 19 53: 39 69: 88 85: 193 101: 420 117: 920 6: 2.1 22: 7.8 38: 20 54: 41 70: 92 86: 203 102: 441 118: 966 7: 2.4 23: 8.4 39: 21 55: 42 71: 97 87: 213 103: 464 119: 1014 8: 2.7 24: 9.0 40: 22 56: 45 72: 101 88: 224 104: 487 120: 1065 9: 3.0 25: 9.6 41: 23 57: 48 73: 107 89: 235 105: 511 121: 1118 10: 3.3 26: 10.2 42: 24 58: 51 74: 112 90: 247 106: 537 122: 1174 11: 3.6 27: 10.8 43: 25 59: 54 75: 118 91: 259 107: 564 123: 1233 12: 3.9 28: 11.4 44: 26 60: 57 76: 124 92: 272 108: 592 124: 1295 13: 4.2 29: 12.0 45: 27 61: 60 77: 130 93: 284 109: 622 125: 1360 14: 4.5 30: 12.6 46: 28 62: 63 78: 137 94: 298 110: 653 126: 1428 15: 4.8 31: 13.2 47: 30 63: 66 79: 143 95: 313 111: 686 127: 1500

*T01-06 : 0: Y-CRY 1: RM-A 2: RM-B 3: J-CRY 4: VOX 5: M-VOX

*T01-07 : [Hz] 0: 20 8: 50 16: 125 24: 315 32: 900 40: 2.24k 48: 6.30k 56: 16.0k 1: 22 9: 56 17: 140 25: 400 33: 1.0k 41: 2.50k 49: 7.10k 57: 18.0k 2: 25 10: 63 18: 160 26: 450 34: 1.12k 42: 2.80k 50: 8.00k 58: 20.0k 3: 28 11: 71 19: 180 27: 500 35: 1.25k 43: 3.15k 51: 9.00k 4: 32 12: 80 20: 200 28: 560 36: 1.4k 44: 4.00k 52: 10.0k 5: 36 13: 90 21: 224 29: 630 37: 1.6k 45: 4.50k 53: 11.2k 6: 40 14: 100 22: 250 30: 710 38: 1.8k 46: 5.00k 54: 12.5k 7: 45 15: 112 23: 280 31: 800 39: 2.0k 47: 5.60k 55: 14.0k

55

KORG RADIAS MIDI Implementation

*T01-08 : 0: Tweed1x8 1: Tweed1x12 2: Tweed4x10 3: Black2x10 4: Black2x12 5: AC15 6: AC30 7: AD412 8: UK_H30 9: UK_T75 10: US_V30

*T01-09 : ER Time 0: 10 16: 26 32: 42 48: 90 64: 170 80: 330 96: 490 112: 650 1: 11 17: 27 33: 43 49: 95 65: 180 81: 340 97: 500 113: 660 2: 12 18: 28 34: 44 50: 100 66: 190 82: 350 98: 510 114: 670 3: 13 19: 29 35: 45 51: 105 67: 200 83: 360 99: 520 115: 680 4: 14 20: 30 36: 46 52: 110 68: 210 84: 370 100: 530 116: 690 5: 15 21: 31 37: 47 53: 115 69: 220 85: 380 101: 540 117: 700 6: 16 22: 32 38: 48 54: 120 70: 230 86: 390 102: 550 118: 710 7: 17 23: 33 39: 49 55: 125 71: 240 87: 400 103: 560 119: 720 8: 18 24: 34 40: 50 56: 130 72: 250 88: 410 104: 570 120: 730 9: 19 25: 35 41: 55 57: 135 73: 260 89: 420 105: 580 121: 740 10: 20 26: 36 42: 60 58: 140 74: 270 90: 430 106: 590 122: 750 11: 21 27: 37 43: 65 59: 145 75: 280 91: 440 107: 600 123: 760 12: 22 28: 38 44: 70 60: 150 76: 290 92: 450 108: 610 124: 770 13: 23 29: 39 45: 75 61: 155 77: 300 93: 460 109: 620 125: 780 14: 24 30: 40 46: 80 62: 160 78: 310 94: 470 110: 630 126: 790 15: 25 31: 41 47: 85 63: 165 79: 320 95: 480 111: 640 127: 800

*T01-10 : Horn/Roter Ratio 0: Stop 16: 0.80 32: 1.12 48: 1.44 64: 1.76 1: 0.50 17: 0.82 33: 1.14 49: 1.46 65: 1.78 2: 0.52 18: 0.84 34: 1.16 50: 1.48 66: 1.80 3: 0.54 19: 0.86 35: 1.18 51: 1.50 67: 1.82 4: 0.56 20: 0.88 36: 1.20 52: 1.52 68: 1.84 5: 0.58 21: 0.90 37: 1.22 53: 1.54 69: 1.86 6: 0.60 22: 0.92 38: 1.24 54: 1.56 70: 1.88 7: 0.62 23: 0.94 39: 1.26 55: 1.58 71: 1.90 8: 0.64 24: 0.96 40: 1.28 56: 1.60 72: 1.92 9: 0.66 25: 0.98 41: 1.30 57: 1.62 73: 1.94 10: 0.68 26: 1.00 42: 1.32 58: 1.64 74: 1.96 11: 0.70 27: 1.02 43: 1.34 59: 1.66 75: 1.98 12: 0.72 28: 1.04 44: 1.36 60: 1.68 76: 2.00 13: 0.74 29: 1.06 45: 1.38 61: 1.70 14: 0.76 30: 1.08 46: 1.40 62: 1.72 15: 0.78 31: 1.10 47: 1.42 63: 1.74

*T02-01 : [msec] 0: 0 16: 16 32: 32 48: 48 64: 74 80: 106 96: 138 112: 170 1: 1 17: 17 33: 33 49: 49 65: 76 81: 108 97: 140 113: 172 2: 2 18: 18 34: 34 50: 50 66: 78 82: 110 98: 142 114: 174 3: 3 19: 19 35: 35 51: 51 67: 80 83: 112 99: 144 115: 176 4: 4 20: 20 36: 36 52: 52 68: 82 84: 114 100: 146 116: 178 5: 5 21: 21 37: 37 53: 53 69: 84 85: 116 101: 148 117: 180 6: 6 22: 22 38: 38 54: 54 70: 86 86: 118 102: 150 118: 182 7: 7 23: 23 39: 39 55: 56 71: 88 87: 120 103: 152 119: 184 8: 8 24: 24 40: 40 56: 58 72: 90 88: 122 104: 154 120: 186 9: 9 25: 25 41: 41 57: 60 73: 92 89: 124 105: 156 121: 188 10: 10 26: 26 42: 42 58: 62 74: 94 90: 126 106: 158 122: 190 11: 11 27: 27 43: 43 59: 64 75: 96 91: 128 107: 160 123: 192 12: 12 28: 28 44: 44 60: 66 76: 98 92: 130 108: 162 124: 194 13: 13 29: 29 45: 45 61: 68 77: 100 93: 132 109: 164 125: 196 14: 14 30: 30 46: 46 62: 70 78: 102 94: 134 110: 166 126: 198 15: 15 31: 31 47: 47 63: 72 79: 104 95: 136 111: 168 127: 200

*T03-01 : [kHz] 0: 0.01 16: 0.17 32: 0.83 48: 2.75 64: 4.75 80: 8.50 96: 15.0 112: 39.0 1: 0.02 17: 0.18 33: 0.92 49: 2.88 65: 4.88 81: 8.75 97: 16.0 113: 41.0 2: 0.03 18: 0.19 34: 1.00 50: 3.00 66: 5.00 82: 9.00 98: 17.0 114: 44.0 3: 0.04 19: 0.20 35: 1.13 51: 3.13 67: 5.25 83: 9.25 99: 18.0 115: 47.0 4: 0.05 20: 0.21 36: 1.25 52: 3.25 68: 5.50 84: 9.50 100: 19.0 116: 50.0 5: 0.06 21: 0.22 37: 1.38 53: 3.38 69: 5.75 85: 9.75 101: 20.0 117: 53.0 6: 0.07 22: 0.23 38: 1.50 54: 3.50 70: 6.00 86: 10.0 102: 21.5 118: 57.0 7: 0.08 23: 0.24 39: 1.63 55: 3.63 71: 6.25 87: 10.5 103: 23.0 119: 61.0 8: 0.09 24: 0.25 40: 1.75 56: 3.75 72: 6.50 88: 11.0 104: 24.5 120: 65.0 9: 0.10 25: 0.29 41: 1.88 57: 3.88 73: 6.75 89: 11.5 105: 26.0 121: 70.0 10: 0.11 26: 0.33 42: 2.00 58: 4.00 74: 7.00 90: 12.0 106: 27.5 122: 75.0 11: 0.12 27: 0.42 43: 2.13 59: 4.13 75: 7.25 91: 12.5 107: 29.0 123: 80.0 12: 0.13 28: 0.50 44: 2.25 60: 4.25 76: 7.50 92: 13.0 108: 31.0 124: 85.0 13: 0.14 29: 0.58 45: 2.38 61: 4.38 77: 7.75 93: 13.5 109: 33.0 125: 90.0 14: 0.15 30: 0.67 46: 2.50 62: 4.50 78: 8.00 94: 14.0 110: 35.0 126: 95.0 15: 0.16 31: 0.75 47: 2.63 63: 4.63 79: 8.25 95: 14.5 111: 37.0 127: 100

*T03-02 : 0: 8/1 4: 3/4 8: 1/4 12: 1/12 16: 1/64 1: 4/1 5: 1/2 9: 3/16 13: 1/16 2: 2/1 6: 3/8 10: 1/6 14: 1/24 3: 1/1 7: 1/3 11: 1/8 15: 1/32

56

RADIAS Effect Parameter Structure

*T03-03 : [kHz] 0: 0.000 16: 0.10 32: 0.37 48: 1.05 64: 2.00 80: 3.60 96: 5.80 112: 9.00 1: 0.002 17: 0.11 33: 0.39 49: 1.10 65: 2.10 81: 3.70 97: 6.00 113: 9.20 2: 0.004 18: 0.12 34: 0.41 50: 1.15 66: 2.20 82: 3.80 98: 6.20 114: 9.40 3: 0.006 19: 0.13 35: 0.43 51: 1.20 67: 2.30 83: 3.90 99: 6.40 115: 9.60 4: 0.008 20: 0.14 36: 0.45 52: 1.25 68: 2.40 84: 4.00 100: 6.60 116: 9.80 5: 0.010 21: 0.15 37: 0.50 53: 1.30 69: 2.50 85: 4.10 101: 6.80 117: 10.0 6: 0.015 22: 0.17 38: 0.55 54: 1.35 70: 2.60 86: 4.20 102: 7.00 118: 10.2 7: 0.020 23: 0.19 39: 0.60 55: 1.40 71: 2.70 87: 4.30 103: 7.20 119: 10.4 8: 0.025 24: 0.21 40: 0.65 56: 1.45 72: 2.80 88: 4.40 104: 7.40 120: 10.6 9: 0.03 25: 0.23 41: 0.70 57: 1.50 73: 2.90 89: 4.50 105: 7.60 121: 10.8 10: 0.04 26: 0.25 42: 0.75 58: 1.55 74: 3.00 90: 4.60 106: 7.80 122: 11.0 11: 0.05 27: 0.27 43: 0.80 59: 1.60 75: 3.10 91: 4.80 107: 8.00 123: 11.2 12: 0.06 28: 0.29 44: 0.85 60: 1.65 76: 3.20 92: 5.00 108: 8.20 124: 11.4 13: 0.07 29: 0.31 45: 0.90 61: 1.70 77: 3.30 93: 5.20 109: 8.40 125: 11.6 14: 0.08 30: 0.33 46: 0.95 62: 1.80 78: 3.40 94: 5.40 110: 8.60 126: 11.8 15: 0.09 31: 0.35 47: 1.00 63: 1.90 79: 3.50 95: 5.60 111: 8.80 127: 12.0

*T04-01 : Control Source 0: Off 1: Velocity 2: AfterTouch 3: PitchBend 4: ModWheel 5: Assignable Pedal 6: Assignable SW 7: Damper 8: Env.Follower 9: MIDI1 10: MIDI2 11: MIDI3 12: MIDI4 13: MIDI5

*T05-01 : Reverb Time [sec] *Type (Hall,SmthHall,WetPlate,DryPlate) 0: 0.1 5: 0.6 10: 1.1 15: 1.6 20: 2.1 25: 2.6 1: 0.2 6: 0.7 11: 1.2 16: 1.7 21: 2.2 26: 2.7 2: 0.3 7: 0.8 12: 1.3 17: 1.8 22: 2.3 27: 2.8 3: 0.4 8: 0.9 13: 1.4 18: 1.9 23: 2.4 28: 2.9 4: 0.5 9: 1.0 14: 1.5 19: 2.0 24: 2.5 29: 3.0

*T05-02 : Reverb Time Type [sec] *Type(Room,BritRoom) 0: 0.1 15: 1.6 30: 3.1 45: 4.6 60: 6.1 75: 7.6 90: 9.1 1: 0.2 16: 1.7 31: 3.2 46: 4.7 61: 6.2 76: 7.7 91: 9.2 2: 0.3 17: 1.8 32: 3.3 47: 4.8 62: 6.3 77: 7.8 92: 9.3 3: 0.4 18: 1.9 33: 3.4 48: 4.9 63: 6.4 78: 7.9 93: 9.4 4: 0.5 19: 2.0 34: 3.5 49: 5.0 64: 6.5 79: 8.0 94: 9.5 5: 0.6 20: 2.1 35: 3.6 50: 5.1 65: 6.6 80: 8.1 95: 9.6 6: 0.7 21: 2.2 36: 3.7 51: 5.2 66: 6.7 81: 8.2 96: 9.7 7: 0.8 22: 2.3 37: 3.8 52: 5.3 67: 6.8 82: 8.3 97: 9.8 8: 0.9 23: 2.4 38: 3.9 53: 5.4 68: 6.9 83: 8.4 98: 9.9 9: 1.0 24: 2.5 39: 4.0 54: 5.5 69: 7.0 84: 8.5 99: 10.0 10: 1.1 25: 2.6 40: 4.1 55: 5.6 70: 7.1 85: 8.6 11: 1.2 26: 2.7 41: 4.2 56: 5.7 71: 7.2 86: 8.7 12: 1.3 27: 2.8 42: 4.3 57: 5.8 72: 7.3 87: 8.8 13: 1.4 28: 2.9 43: 4.4 58: 5.9 73: 7.4 88: 8.9 14: 1.5 29: 3.0 44: 4.5 59: 6.0 74: 7.5 89: 9.0

*T05-03 : 0: Hall 1: SmoothHall 2: WetPlate 3: DryPlate 4: Room 5: BrightRoom

*T06-01 : Time Ratio [%] Sync=ON 0: 12.5 16: 25.0 32: 50.0 48: 66.6 64: 100.0 80: 133.0 96: 200.0 112: 300.0 1: 12.5 17: 25.0 33: 50.0 49: 66.6 65: 100.0 81: 133.0 97: 200.0 113: 300.0 2: 12.5 18: 25.0 34: 50.0 50: 75.0 66: 100.0 82: 133.0 98: 200.0 114: 300.0 3: 12.5 19: 25.0 35: 50.0 51: 75.0 67: 100.0 83: 133.0 99: 200.0 115: 300.0 4: 12.5 20: 25.0 36: 50.0 52: 75.0 68: 125.0 84: 133.0 100: 200.0 116: 300.0 5: 12.5 21: 25.0 37: 50.0 53: 75.0 69: 125.0 85: 133.0 101: 200.0 117: 300.0 6: 12.5 22: 25.0 38: 50.0 54: 75.0 70: 125.0 86: 150.0 102: 200.0 118: 300.0 7: 12.5 23: 25.0 39: 50.0 55: 75.0 71: 125.0 87: 150.0 103: 200.0 119: 300.0 8: 16.7 24: 33.3 40: 50.0 56: 75.0 72: 125.0 88: 150.0 104: 250.0 120: 400.0 9: 16.7 25: 33.3 41: 66.6 57: 75.0 73: 125.0 89: 150.0 105: 250.0 121: 400.0 10: 16.7 26: 33.3 42: 66.6 58: 75.0 74: 125.0 90: 150.0 106: 250.0 122: 400.0 11: 16.7 27: 33.3 43: 66.6 59: 100.0 75: 125.0 91: 150.0 107: 250.0 123: 400.0 12: 16.7 28: 33.3 44: 66.6 60: 100.0 76: 125.0 92: 150.0 108: 250.0 124: 400.0 13: 16.7 29: 33.3 45: 66.6 61: 100.0 77: 133.0 93: 150.0 109: 250.0 125: 400.0 14: 16.7 30: 33.3 46: 66.6 62: 100.0 78: 133.0 94: 150.0 110: 250.0 126: 400.0 15: 16.7 31: 33.3 47: 66.6 63: 100.0 79: 133.0 95: 200.0 111: 250.0 127: 400.0

*T06-02 : Time Ratio [%] Sync=OFF 0: 0.5 16: 8.5 32: 23.0 48: 59.0 64: 100.0 80: 120.0 96: 158.0 112: 210.0 1: 1.0 17: 9.0 33: 25.0 49: 62.0 65: 100.0 81: 122.0 97: 161.0 113: 215.0 2: 1.5 18: 9.5 34: 28.0 50: 65.0 66: 101.0 82: 123.0 98: 164.0 114: 220.0 3: 2.0 19: 10.0 35: 30.0 51: 66.6 67: 102.0 83: 125.0 99: 167.0 115: 225.0 4: 2.5 20: 11.0 36: 32.0 52: 72.0 68: 103.0 84: 128.0 100: 170.0 116: 230.0 5: 3.0 21: 12.5 37: 33.3 53: 75.0 69: 104.0 85: 130.0 101: 173.0 117: 240.0 6: 3.5 22: 13.0 38: 36.0 54: 78.0 70: 105.0 86: 133.3 102: 176.0 118: 250.0 7: 4.0 23: 14.0 39: 38.0 55: 81.0 71: 106.0 87: 134.0 103: 179.0 119: 260.0 8: 4.5 24: 15.0 40: 40.0 56: 85.0 72: 107.0 88: 136.0 104: 182.0 120: 270.0 9: 5.0 25: 16.7 41: 42.0 57: 89.0 73: 108.0 89: 138.0 105: 185.0 121: 280.0 10: 5.5 26: 17.0 42: 44.0 58: 92.0 74: 109.0 90: 140.0 106: 188.0 122: 300.0 11: 6.0 27: 18.0 43: 46.0 59: 95.0 75: 110.0 91: 143.0 107: 191.0 123: 320.0 12: 6.5 28: 19.0 44: 48.0 60: 98.0 76: 112.0 92: 146.0 108: 194.0 124: 340.0 13: 7.0 29: 20.0 45: 50.0 61: 100.0 77: 114.0 93: 150.0 109: 197.0 125: 360.0 14: 7.5 30: 21.0 46: 53.0 62: 100.0 78: 116.0 94: 152.0 110: 200.0 126: 380.0 15: 8.0 31: 22.0 47: 56.0 63: 100.0 79: 118.0 95: 155.0 111: 205.0 127: 400.0

57

KORG RADIAS MIDI Implementation

*T06-03 : DelayTime 0~500[msec] 0: 0 16: 16 32: 34 48: 66 64: 125 80: 205 96: 285 112: 365 1: 1 17: 17 33: 36 49: 68 65: 130 81: 210 97: 290 113: 370 2: 2 18: 18 34: 38 50: 70 66: 135 82: 215 98: 295 114: 375 3: 3 19: 19 35: 40 51: 72 67: 140 83: 220 99: 300 115: 380 4: 4 20: 20 36: 42 52: 74 68: 145 84: 225 100: 305 116: 390 5: 5 21: 21 37: 44 53: 76 69: 150 85: 230 101: 310 117: 400 6: 6 22: 22 38: 46 54: 78 70: 155 86: 235 102: 315 118: 410 7: 7 23: 23 39: 48 55: 80 71: 160 87: 240 103: 320 119: 420 8: 8 24: 24 40: 50 56: 85 72: 165 88: 245 104: 325 120: 430 9: 9 25: 25 41: 52 57: 90 73: 170 89: 250 105: 330 121: 440 10: 10 26: 26 42: 54 58: 95 74: 175 90: 255 106: 335 122: 450 11: 11 27: 27 43: 56 59: 100 75: 180 91: 260 107: 340 123: 460 12: 12 28: 28 44: 58 60: 105 76: 185 92: 265 108: 345 124: 470 13: 13 29: 29 45: 60 61: 110 77: 190 93: 270 109: 350 125: 480 14: 14 30: 30 46: 62 62: 115 78: 195 94: 275 110: 355 126: 490 15: 15 31: 32 47: 64 63: 120 79: 200 95: 280 111: 360 127: 500

*T06-04 : DelayTime 0~1000[msec] 0: 0 16: 16 32: 60 48: 140 64: 250 80: 410 96: 570 112: 730 1: 1 17: 18 33: 65 49: 145 65: 260 81: 420 97: 580 113: 740 2: 2 18: 20 34: 70 50: 150 66: 270 82: 430 98: 590 114: 750 3: 3 19: 22 35: 75 51: 155 67: 280 83: 440 99: 600 115: 760 4: 4 20: 24 36: 80 52: 160 68: 290 84: 450 100: 610 116: 780 5: 5 21: 26 37: 85 53: 165 69: 300 85: 460 101: 620 117: 800 6: 6 22: 28 38: 90 54: 170 70: 310 86: 470 102: 630 118: 820 7: 7 23: 30 39: 95 55: 175 71: 320 87: 480 103: 640 119: 840 8: 8 24: 32 40: 100 56: 180 72: 330 88: 490 104: 650 120: 860 9: 9 25: 34 41: 105 57: 185 73: 340 89: 500 105: 660 121: 880 10: 10 26: 36 42: 110 58: 190 74: 350 90: 510 106: 670 122: 900 11: 11 27: 38 43: 115 59: 200 75: 360 91: 520 107: 680 123: 920 12: 12 28: 40 44: 120 60: 210 76: 370 92: 530 108: 690 124: 940 13: 13 29: 45 45: 125 61: 220 77: 380 93: 540 109: 700 125: 960 14: 14 30: 50 46: 130 62: 230 78: 390 94: 550 110: 710 126: 980 15: 15 31: 55 47: 135 63: 240 79: 400 95: 560 111: 720 127: 1000

*T06-05 : DelayTime 0~700[msec] 0: 0 16: 16 32: 44 48: 100 64: 180 80: 260 96: 390 112: 550 1: 1 17: 17 33: 46 49: 105 65: 185 81: 265 97: 400 113: 560 2: 2 18: 18 34: 48 50: 110 66: 190 82: 270 98: 410 114: 570 3: 3 19: 19 35: 50 51: 115 67: 195 83: 275 99: 420 115: 580 4: 4 20: 20 36: 52 52: 120 68: 200 84: 280 100: 430 116: 590 5: 5 21: 22 37: 54 53: 125 69: 205 85: 285 101: 440 117: 600 6: 6 22: 24 38: 56 54: 130 70: 210 86: 290 102: 450 118: 610 7: 7 23: 26 39: 58 55: 135 71: 215 87: 300 103: 460 119: 620 8: 8 24: 28 40: 60 56: 140 72: 220 88: 310 104: 470 120: 630 9: 9 25: 30 41: 65 57: 145 73: 225 89: 320 105: 480 121: 640 10: 10 26: 32 42: 70 58: 150 74: 230 90: 330 106: 490 122: 650 11: 11 27: 34 43: 75 59: 155 75: 235 91: 340 107: 500 123: 660 12: 12 28: 36 44: 80 60: 160 76: 240 92: 350 108: 510 124: 670 13: 13 29: 38 45: 85 61: 165 77: 245 93: 360 109: 520 125: 680 14: 14 30: 40 46: 90 62: 170 78: 250 94: 370 110: 530 126: 690 15: 15 31: 42 47: 95 63: 175 79: 255 95: 380 111: 540 127: 700

*T06-06 : DelayTime 0~1400[msec] 0: 0 16: 22 32: 90 48: 190 64: 350 80: 510 96: 780 112: 1100 1: 1 17: 24 33: 95 49: 200 65: 360 81: 520 97: 800 113: 1120 2: 2 18: 26 34: 100 50: 210 66: 370 82: 530 98: 820 114: 1140 3: 3 19: 28 35: 105 51: 220 67: 380 83: 540 99: 840 115: 1160 4: 4 20: 30 36: 110 52: 230 68: 390 84: 550 100: 860 116: 1180 5: 5 21: 35 37: 115 53: 240 69: 400 85: 560 101: 880 117: 1200 6: 6 22: 40 38: 120 54: 250 70: 410 86: 580 102: 900 118: 1220 7: 7 23: 45 39: 125 55: 260 71: 420 87: 600 103: 920 119: 1240 8: 8 24: 50 40: 130 56: 270 72: 430 88: 620 104: 940 120: 1260 9: 9 25: 55 41: 135 57: 280 73: 440 89: 640 105: 960 121: 1280 10: 10 26: 60 42: 140 58: 290 74: 450 90: 660 106: 980 122: 1300 11: 12 27: 65 43: 145 59: 300 75: 460 91: 680 107: 1000 123: 1320 12: 14 28: 70 44: 150 60: 310 76: 470 92: 700 108: 1020 124: 1340 13: 16 29: 75 45: 160 61: 320 77: 480 93: 720 109: 1040 125: 1360 14: 18 30: 80 46: 170 62: 330 78: 490 94: 740 110: 1060 126: 1380 15: 20 31: 85 47: 180 63: 340 79: 500 95: 760 111: 1080 127: 1400

*T06-07 : Duration DelayTime 0~350[msec] 0: 0 16: 16 32: 32 48: 48 64: 78 80: 110 96: 190 112: 270 1: 1 17: 17 33: 33 49: 49 65: 80 81: 115 97: 195 113: 275 2: 2 18: 18 34: 34 50: 50 66: 82 82: 120 98: 200 114: 280 3: 3 19: 19 35: 35 51: 52 67: 84 83: 125 99: 205 115: 285 4: 4 20: 20 36: 36 52: 54 68: 86 84: 130 100: 210 116: 290 5: 5 21: 21 37: 37 53: 56 69: 88 85: 135 101: 215 117: 295 6: 6 22: 22 38: 38 54: 58 70: 90 86: 140 102: 220 118: 300 7: 7 23: 23 39: 39 55: 60 71: 92 87: 145 103: 225 119: 305 8: 8 24: 24 40: 40 56: 62 72: 94 88: 150 104: 230 120: 310 9: 9 25: 25 41: 41 57: 64 73: 96 89: 155 105: 235 121: 315 10: 10 26: 26 42: 42 58: 66 74: 98 90: 160 106: 240 122: 320 11: 11 27: 27 43: 43 59: 68 75: 100 91: 165 107: 245 123: 325 12: 12 28: 28 44: 44 60: 70 76: 102 92: 170 108: 250 124: 330 13: 13 29: 29 45: 45 61: 72 77: 104 93: 175 109: 255 125: 335 14: 14 30: 30 46: 46 62: 74 78: 106 94: 180 110: 260 126: 340 15: 15 31: 31 47: 47 63: 76 79: 108 95: 185 111: 265 127: 350

58

RADIAS Effect Parameter Structure

*T06-08 : DelayTime 0~480[msec] 0: 0 16: 16 32: 32 48: 62 64: 115 80: 195 96: 275 112: 355 1: 1 17: 17 33: 33 49: 64 65: 120 81: 200 97: 280 113: 360 2: 2 18: 18 34: 34 50: 66 66: 125 82: 205 98: 285 114: 365 3: 3 19: 19 35: 36 51: 68 67: 130 83: 210 99: 290 115: 370 4: 4 20: 20 36: 38 52: 70 68: 135 84: 215 100: 295 116: 375 5: 5 21: 21 37: 40 53: 72 69: 140 85: 220 101: 300 117: 380 6: 6 22: 22 38: 42 54: 74 70: 145 86: 225 102: 305 118: 390 7: 7 23: 23 39: 44 55: 76 71: 150 87: 230 103: 310 119: 400 8: 8 24: 24 40: 46 56: 78 72: 155 88: 235 104: 315 120: 410 9: 9 25: 25 41: 48 57: 80 73: 160 89: 240 105: 320 121: 420 10: 10 26: 26 42: 50 58: 85 74: 165 90: 245 106: 325 122: 430 11: 11 27: 27 43: 52 59: 90 75: 170 91: 250 107: 330 123: 440 12: 12 28: 28 44: 54 60: 95 76: 175 92: 255 108: 335 124: 450 13: 13 29: 29 45: 56 61: 100 77: 180 93: 260 109: 340 125: 460 14: 14 30: 30 46: 58 62: 105 78: 185 94: 265 110: 345 126: 470 15: 15 31: 31 47: 60 63: 110 79: 190 95: 270 111: 350 127: 480

*T06-09 : DelayTime 0~980[msec] 0: 0 16: 16 32: 60 48: 140 64: 240 80: 400 96: 560 112: 720 1: 1 17: 18 33: 65 49: 145 65: 250 81: 410 97: 570 113: 730 2: 2 18: 20 34: 70 50: 150 66: 260 82: 420 98: 580 114: 740 3: 3 19: 22 35: 75 51: 155 67: 270 83: 430 99: 590 115: 750 4: 4 20: 24 36: 80 52: 160 68: 280 84: 440 100: 600 116: 760 5: 5 21: 26 37: 85 53: 165 69: 290 85: 450 101: 610 117: 780 6: 6 22: 28 38: 90 54: 170 70: 300 86: 460 102: 620 118: 800 7: 7 23: 30 39: 95 55: 175 71: 310 87: 470 103: 630 119: 820 8: 8 24: 32 40: 100 56: 180 72: 320 88: 480 104: 640 120: 840 9: 9 25: 34 41: 105 57: 185 73: 330 89: 490 105: 650 121: 860 10: 10 26: 36 42: 110 58: 190 74: 340 90: 500 106: 660 122: 880 11: 11 27: 38 43: 115 59: 195 75: 350 91: 510 107: 670 123: 900 12: 12 28: 40 44: 120 60: 200 76: 360 92: 520 108: 680 124: 920 13: 13 29: 45 45: 125 61: 210 77: 370 93: 530 109: 690 125: 940 14: 14 30: 50 46: 130 62: 220 78: 380 94: 540 110: 700 126: 960 15: 15 31: 55 47: 135 63: 230 79: 390 95: 550 111: 710 127: 980

*T06-10 : DelayTime 0~680[msec] 0: 0 16: 16 32: 44 48: 100 64: 180 80: 260 96: 370 112: 530 1: 1 17: 17 33: 46 49: 105 65: 185 81: 265 97: 380 113: 540 2: 2 18: 18 34: 48 50: 110 66: 190 82: 270 98: 390 114: 550 3: 3 19: 19 35: 50 51: 115 67: 195 83: 275 99: 400 115: 560 4: 4 20: 20 36: 52 52: 120 68: 200 84: 280 100: 410 116: 570 5: 5 21: 22 37: 54 53: 125 69: 205 85: 285 101: 420 117: 580 6: 6 22: 24 38: 56 54: 130 70: 210 86: 290 102: 430 118: 590 7: 7 23: 26 39: 58 55: 135 71: 215 87: 295 103: 440 119: 600 8: 8 24: 28 40: 60 56: 140 72: 220 88: 300 104: 450 120: 610 9: 9 25: 30 41: 65 57: 145 73: 225 89: 305 105: 460 121: 620 10: 10 26: 32 42: 70 58: 150 74: 230 90: 310 106: 470 122: 630 11: 11 27: 34 43: 75 59: 155 75: 235 91: 320 107: 480 123: 640 12: 12 28: 36 44: 80 60: 160 76: 240 92: 330 108: 490 124: 650 13: 13 29: 38 45: 85 61: 165 77: 245 93: 340 109: 500 125: 660 14: 14 30: 40 46: 90 62: 170 78: 250 94: 350 110: 510 126: 670 15: 15 31: 42 47: 95 63: 175 79: 255 95: 360 111: 520 127: 680

*T06-11 : DelayTime 0~1380[msec] 0: 0 16: 22 32: 90 48: 190 64: 350 80: 510 96: 760 112: 1080 1: 1 17: 24 33: 95 49: 200 65: 360 81: 520 97: 780 113: 1100 2: 2 18: 26 34: 100 50: 210 66: 370 82: 530 98: 800 114: 1120 3: 3 19: 28 35: 105 51: 220 67: 380 83: 540 99: 820 115: 1140 4: 4 20: 30 36: 110 52: 230 68: 390 84: 550 100: 840 116: 1160 5: 5 21: 35 37: 115 53: 240 69: 400 85: 560 101: 860 117: 1180 6: 6 22: 40 38: 120 54: 250 70: 410 86: 570 102: 880 118: 1200 7: 7 23: 45 39: 125 55: 260 71: 420 87: 580 103: 900 119: 1220 8: 8 24: 50 40: 130 56: 270 72: 430 88: 600 104: 920 120: 1240 9: 9 25: 55 41: 135 57: 280 73: 440 89: 620 105: 940 121: 1260 10: 10 26: 60 42: 140 58: 290 74: 450 90: 640 106: 960 122: 1280 11: 12 27: 65 43: 145 59: 300 75: 460 91: 660 107: 980 123: 1300 12: 14 28: 70 44: 150 60: 310 76: 470 92: 680 108: 1000 124: 1320 13: 16 29: 75 45: 160 61: 320 77: 480 93: 700 109: 1020 125: 1340 14: 18 30: 80 46: 170 62: 330 78: 490 94: 720 110: 1040 126: 1360 15: 20 31: 85 47: 180 63: 340 79: 500 95: 740 111: 1060 127: 1380

*T06-12 : DelayTime 0~50[msec] 0: 0.0 16: 1.6 32: 4.4 48: 8.4 64: 14.0 80: 22.0 96: 30.0 112: 43.0 1: 0.1 17: 1.7 33: 4.6 49: 8.7 65: 14.5 81: 22.5 97: 30.5 113: 44.0 2: 0.2 18: 1.8 34: 4.8 50: 9.0 66: 15.0 82: 23.0 98: 31.0 114: 45.0 3: 0.3 19: 1.9 35: 5.0 51: 9.3 67: 15.5 83: 23.5 99: 31.5 115: 46.0 4: 0.4 20: 2.0 36: 5.2 52: 9.6 68: 16.0 84: 24.0 100: 32.0 116: 47.0 5: 0.5 21: 2.2 37: 5.4 53: 9.9 69: 16.5 85: 24.5 101: 32.5 117: 48.0 6: 0.6 22: 2.4 38: 5.6 54: 10.2 70: 17.0 86: 25.0 102: 33.0 118: 49.0 7: 0.7 23: 2.6 39: 5.8 55: 10.5 71: 17.5 87: 25.5 103: 34.0 119: 50.0 8: 0.8 24: 2.8 40: 6.0 56: 10.8 72: 18.0 88: 26.0 104: 35.0 9: 0.9 25: 3.0 41: 6.3 57: 11.1 73: 18.5 89: 26.5 105: 36.0 10: 1.0 26: 3.2 42: 6.6 58: 11.4 74: 19.0 90: 27.0 106: 37.0 11: 1.1 27: 3.4 43: 6.9 59: 11.7 75: 19.5 91: 27.5 107: 38.0 12: 1.2 28: 3.6 44: 7.2 60: 12.0 76: 20.0 92: 28.0 108: 39.0 13: 1.3 29: 3.8 45: 7.5 61: 12.5 77: 20.5 93: 28.5 109: 40.0 14: 1.4 30: 4.0 46: 7.8 62: 13.0 78: 21.0 94: 29.0 110: 41.0 15: 1.5 31: 4.2 47: 8.1 63: 13.5 79: 21.5 95: 29.5 111: 42.0

59

KORG RADIAS MIDI Implementation

*T06-13 : DelayTime 0~30[msec] 0: 0.0 16: 1.6 32: 3.2 48: 4.8 64: 6.8 80: 10.5 96: 15.3 112: 28.0 1: 0.1 17: 1.7 33: 3.3 49: 4.9 65: 7.0 81: 10.8 97: 15.6 113: 30.0 2: 0.2 18: 1.8 34: 3.4 50: 5.0 66: 7.2 82: 11.1 98: 15.9 3: 0.3 19: 1.9 35: 3.5 51: 5.1 67: 7.4 83: 11.4 99: 16.2 4: 0.4 20: 2.0 36: 3.6 52: 5.2 68: 7.6 84: 11.7 100: 16.5 5: 0.5 21: 2.1 37: 3.7 53: 5.3 69: 7.8 85: 12.0 101: 17.0 6: 0.6 22: 2.2 38: 3.8 54: 5.4 70: 8.0 86: 12.3 102: 17.5 7: 0.7 23: 2.3 39: 3.9 55: 5.5 71: 8.2 87: 12.6 103: 18.0 8: 0.8 24: 2.4 40: 4.0 56: 5.6 72: 8.4 88: 12.9 104: 18.5 9: 0.9 25: 2.5 41: 4.1 57: 5.7 73: 8.6 89: 13.2 105: 19.0 10: 1.0 26: 2.6 42: 4.2 58: 5.8 74: 8.8 90: 13.5 106: 19.5 11: 1.1 27: 2.7 43: 4.3 59: 5.9 75: 9.0 91: 13.8 107: 20.0 12: 1.2 28: 2.8 44: 4.4 60: 6.0 76: 9.3 92: 14.1 108: 21.0 13: 1.3 29: 2.9 45: 4.5 61: 6.2 77: 9.6 93: 14.4 109: 22.0 14: 1.4 30: 3.0 46: 4.6 62: 6.4 78: 9.9 94: 14.7 110: 24.0 15: 1.5 31: 3.1 47: 4.7 63: 6.6 79: 10.2 95: 15.0 111: 26.0

*T06-14 : DelayTime TempoSync=ON 0: 1/64 6: 1/6 12: 3/4 1: 1/32 7: 3/16 13: 1/1 2: 1/24 8: 1/4 3: 1/16 9: 1/3 4: 1/12 10: 3/8 5: 1/8 11: 1/2

60

KORG INC.

4015-2 Yanokuchi, Inagi-city, Tokyo 206-0812 Japan

 2005 KORG INC.

Korg RADIAS-R User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1.TRANSMITTED DATA

2.RECOGNIZED RECEIVE DATA

RADIAS Effect Parameter Structure
