mITX-BYT - QUICK INSTALLATION GUIDE
Thank you for purchasing the Kontron mITX-BYT embedded board. This document provides information to allow you to quickly
install this product.
Packing Checklist
1. Take the mITX-BYT out of the packing box and check if the unit is properly secure in the plastic bag.
2. Check the contents of the carton box: (*: optional)
mITX-BYT main board
Rear I/O Shield
COM Port Cable*
DIO Cable*
1-Port USB 2.0 Cable*
SATA Cable*
SATA Power Cable*
LPT Cable*
PS/2 Cable*
mITX-BYT - Quick Installation Guide - Version 1.1 // www.kontron.com // 2
Jumper and Internal Connector Locations
Jumper List
Item
Designation
Description
1
JP1
Panel & Backlight Power Selection for LVDS1
2
JP2
Backlight Power Enable Selection for LVDS1
3
JP3
AT / ATX Mode Selection
4
JP4
LVDS1 Backlight DC / PWM Selection
5
JP5
Signal / Power Selection for COM5
6
JP6
Signal / Power Selection for COM6
7
JP7
Signal / Power Selection for COM3
8
JP8
Signal / Power Selection for COM4
9
JP9
ME F/W Selection
10
JP10
MPCIE Activity LED Indication
11
JP11
Signal / Power Selection for COM2
12
JP12
Signal / Power Selection for COM1
13
JP13
USB Power Selection
14
JP15
RTC Reset Selection
2 4 27
3 5 6
7
8
9
10
12
11
13
14
15
16
18
17
19
20
22
23 1 21
24
25
26
28
29
30
31
32
34
33
35
36
37
38
39
40
mITX-BYT - Quick Installation Guide - Version 1.1 // www.kontron.com // 3
Internal Connector List
Item
Designation
Description
15
ATX1
4-pin ATX Power Input Connector
16
BAT1
CR2032 Battery Holder
17
COM3
RS-232 Port 3 Pin Header
18
COM4
RS-232 Port 4 Pin Header
19
COM5
RS-232 Port 5 Pin Header
20
COM6
RS-232 Port 6 Pin Header
21
CN1
Panel Backlight Wafer for LVDS1
22
CN2
Keyboard & Mouse Wafer
23
CN3
Digital Input / Output Pin Header
24
CN5
USB2.0 Port USB DN1 Pin Header
25
CN8
HDD Power Output Wafer
26
CN10
Right Channel 3W Audio AMP Output Wafer
27
CN11
Left Channel 3W Audio AMP Output Wafer
28
SIM1
SIM Interface Wafer for MPCIE1
29
DIMM1
Primary DDR3 Memory SO-DIMM Socket
30
DIMM2
Secondary DDR3 Memory SO-DIMM Socket
31
FAN1
CPU FAN Wafer
32
FAN2
SYSTEM FAN Wafer
33
FP1
Front Panel 1 Pin Header
34
FP2
Front Panel 2 Pin Header
35
LVDS1
Primary 24-bit, 1-channel LVDS Panel Connector
36
MPCIE1
Half Size Mini-PCIE Express v1.2 Socket
37
PEG1
PCIE Express x1Slot
38
SATA1
Serial ATA Port 0 Connector
39
SATA2
Serial ATA Port-1 mSATA Socket (Full Size)
40
LPT1
Parallel Port Pin Header
mITX-BYT - Quick Installation Guide - Version 1.1 // www.kontron.com // 4
Jumper Settings
Panel & Backlight Power Selection for LVDS1 (JP1)
Jumper 1 Position
Description
Pin 1-3
Pin 3-5
X - Backlight Power = +12V
- X Backlight Power = +5V
Jumper 2 Position
Description
Pin 2-4
Pin 4-6
X - Panel Power = +3.3V
- X Panel Power = +5V
“X” = Jumper set (short) and “-” = jumper not set (open)
Backlight Power Enable Selection for LVDS1 (JP2)
Jumper 1 Position
Description
Pin 1-3
Pin 3-5
X - Backlight Enable Voltage = +3.3V
- X Backlight Enable Voltage = +5V
Jumper 2 Position
Description
Pin 2-4
Pin 4-6
X - Active High
- X Active Low
“X” = Jumper set (short) and “-” = jumper not set (open)
21
65
21
65
mITX-BYT - Quick Installation Guide - Version 1.1 // www.kontron.com // 5
AT / ATX Power Mode Selection (JP3)
Jumper 1 Position
Description
Pin 1-2
Pin 2-3
X - ATX Mode
- X AT Mode
“X” = Jumper set (short) and “-” = jumper not set (open)
LVDS1 Backlight DC / PWM Selection (JP4)
Jumper 1 Position
Description
Pin 1-2
Pin 2-3
X - DC Mode
- X PWM Mode
“X” = Jumper set (short) and “-” = jumper not set (open)
2
3
1
2
3
1
mITX-BYT - Quick Installation Guide - Version 1.1 // www.kontron.com // 6
Signal / Power Selection for COM1 ~ COM6 (JP5 ~ JP8, JP11, JP12)
Jumper 1 Position
Description
Pin 1-3
Pin 3-5
Pin 5-7
Pin 7-9
X - - - Pin 1 = +12V
- X - - Pin 1 = +5V
- - X - Pin 1 = +5V
- - - X Pin 1 = DCD
Jumper 2 Position
Description
Pin 2-4
Pin 4-6
Pin 6-8
Pin 8-10
X - - - Pin 9 = +12V
- X - - Pin 9 = +5V
- - X - Pin 9 = +5V
- - - X Pin 9 = RI
“X” = Jumper set (short) and “-” = jumper not set (open)
ME F/W Selection (JP9)
Jumper Position
Description
Pin 1-2
X
ME F/W Disabled
-
Normal Operation
“X” = Jumper set (short) and “-” = jumper not set (open)
10
1
9
2
mITX-BYT - Quick Installation Guide - Version 1.1 // www.kontron.com // 7
MPCIE Activity LED Indication (JP10)
Pin
Signal
Note
1
LED+
2 LED-
USB Power Selection (JP13)
Jumper Position
Description
Pin 1-2
X
USB power is always supply.
-
USB power will be cut off in S4 & S5 state.
“X” = Jumper set (short) and “-” = jumper not set (open)
RTC Reset Selection (JP15)
Jumper Position
Description
Pin 1-2
X
Enable Clear CMOS RTC content
(board does not boot with the jumper in this position)
-
Normal operation (default position)
“X” = Jumper set (short) and “-” = jumper not set (open)
1
2
mITX-BYT - Quick Installation Guide - Version 1.1 // www.kontron.com // 8
Real I/O Panel Connector Locations
Item
Designation
Description
1
J1
Power Input DC Jack
2
CN4
LAN1 & USB2.0 Port 0,1 Connector
3
CN6
LAN2 & USB2.0 Port 2,3 Connector
4
USB1
USB3.0 Port 0 Connector
5
VGA1
VGA Connector
6
HDMI1
HDMI Connector
7
CN9
RS-232 / 422 / 485 Port 1, 2 Connector
8
AUDIO1
2 Stack-up Azalia Audio Phone Jack
5 1 2 3 4 6 7
