Page 1

Fiery X3e Color Server

SERVER & CONTROLLER SOLUTIONS

CONFIGURATION GUIDE

Page 2

About the Documentation

This manual is part of a set of Fiery X3e Color Server™ documentation that includes the following manuals for users and system administrators. Most are available as Acrobat PDF (Portable Document Format) ﬁles on the User Documentation CD

• The

Quick Start Guide

Server and printing. It also describes how to access the Acrobat PDF ﬁles on User Documentation CD.

• The

User Software Installation Guide

User Software CD to enable users to print to the Fiery X3e Color Server, and also describes setting up printing connections to the Fiery X3e.

• The

Conﬁguration Guide

the Fiery X3e Color Server for the supported platforms and network environments. It also includes guidelines for setting up UNIX, Windows NT 4.0/2000/Server 2003, and Novell NetWare servers to provide printing services to users.

• The

Printing Guide

users who send jobs from their computers.

• The

Color Guide

Fiery X3e. It explains how to calibrate your Fiery X3e Color Server and take advantage of the ColorWise ColorWise Pro Tools™.

• The

Fiery Color Reference

color output of the Fiery X3e Color Server and outlines key workﬂow scenarios. In addition, it offers information on printing color documents from popular Microsoft Windows and Apple Mac OS applications.

summarizes the steps for conﬁguring the Fiery X3e Color

describes how to install software from the

explains basic conﬁguration and administration of

describes the printing features of the Fiery X3e Color Server for

provides information on managing the color output of the

color management system, as well as features in

addresses concepts and issues associated with managing

• The

Job Management Guide

utilities, including Command WorkStation™, Command WorkStation LE™, and DocBuilder Pro™, and how you can use them to monitor and control jobs on the Fiery X3e Color Server. This manual is intended for an operator or administrator, or a user with the necessary access privileges, who monitors and manages job ﬂow, performs color calibration, and troubleshoots problems that may arise.

•

Release Notes

the problems you may encounter.

provide last-minute product information and workarounds for some of

explains the functions of the job management

Page 3

This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics for Imaging, Inc. Information in this document is subject to change without notice and does not represent a commitment on the part of Electronics for Imaging, Inc.

This publication is provided in conjunction with an EFI product (the “Product”) which contains EFI software (the “Software”). The Software is furnished under license and may only be used or copied in accordance with the terms of the Software license set forth below.

This product may be covered by one or more of the following U.S. Patents: 4,716,978, 4,828,056, 4,917,488, 4,941,038, 5,109,241, 5,170,182, 5,212,546, 5,260,878, 5,276,490, 5,278,599, 5,335,040, 5,343,311, 5,398,107, 5,424,754, 5,442,429, 5,459,560, 5,467,446, 5,506,946, 5,517,334, 5,537,516, 5,543,940, 5,553,200, 5,563,689, 5,565,960, 5,583,623, 5,596,416, 5,615,314, 5,619,624, 5,625,712, 5,640,228, 5,666,436, 5,745,657, 5,760,913, 5,799,232, 5,818,645, 5,835,788, 5,859,711, 5,867,179, 5,940,186, 5,959,867, 5,970,174, 5,982,937, 5,995,724, 6,002,795, 6,025,922, 6,035,103, 6,041,200, 6,065,041, 6,112,665, 6,116,707, 6,122,407, 6,134,018, 6,141,120, 6,166,821, 6,173,286, 6,185,335, 6,201,614, 6,215,562, 6,219,155, 6,219,659, 6,222,641, 6,224,048, 6,225,974, 6,226,419, 6,238,105, 6,239,895, 6,256,108, 6,269,190, 6,271,937, 6,278,901, 6,279,009, 6,289,122, 6,292,270, 6,299,063, 6,310,697, 6,321,133, 6,327,047, 6,327,050, 6,327,052, 6,330,071, 6,330,363, 6,331,899, 6,340,975, 6,341,017, 6,341,018, 6,341,307, 6,347,256, 6,348,978, 6,356,359, 6,366,918, 6,369,895, 6,381,036, 6,400,443, 6,429,949, 6,449,393, 6,476,927, 6,490,696, 6,501,565, 6,519,053, 6,539,323, 6,543,871, 6,546,364, 6,549,294, 6,549,300, 6,550,991, 6,552,815, 6,559,958, 6,572,293, 6,590,676, 6,606,165, 6,633,396, 6,636,326, 6,643,317, 6,647,149, 6,657,741, 6,662,199, 6,678,068, RE33,973, RE36,947, D341,131, D406,117, D416,550, D417,864, D419,185, D426,206, D439,851, D444,793.

Trademarks

Auto-Count, ColorCal, ColorWise, Command WorkStation, EDOX, EFI, Fiery, the Fiery logo, MicroPress, Printcafe, PrinterSite, Prograph, Proteus, and Spot-On are registered trademarks of Electronics for Imaging, Inc., in the U.S. Patent and Trademark Ofﬁce and/or certain other foreign jurisdictions. Bestcolor is a registered trademark of Best GmbH in the U.S. Patent and Trademark Ofﬁce.

AutoCal, Digital StoreFront, DocStream, Fiery Link, FreeForm, Hagen, Intelligent Device Management, Logic, OneFlow, PrintFlow, PrintMe, PrintSmith Site, PrintSmith, PSI Flexo, PSI, SendMe, Splash, VisualCal, the EFI logo, Essential to Print are trademarks of Electronics for Imaging, Inc. Best, the Best logo, Colorproof, PhotoXposure, Remoteproof, and Screenproof are trademarks of Best GmbH.

All other terms and product names may be trademarks or registered trademarks of their respective owners, and are hereby acknowledged.

Legal Notices

APPLE COMPUTER, INC. (“APPLE”) MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, REGARDING THE APPLE SOFTWARE. APPLE DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE APPLE SOFTWARE IN TERMS OF ITS CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR OTHERWISE. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE APPLE SOFTWARE IS ASSUMED BY YOU. THE EXCLUSION OF IMPLIED WARRANTIES IS NOT PERMITTED BY SOME STATES. THE ABOVE EXCLUSION MAY NOT APPLY TO YOU.

IN NO EVENT WILL APPLE, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE TO YOU FOR ANY CONSEQUENTIAL, INCIDENTAL OR INDIRECT DAMAGES (INCLUDING DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, AND THE LIKE) ARISING OUT OF THE USE OR INABILITY TO USE THE APPLE SOFTWARE EVEN IF APPLE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BECAUSE SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

Apple’s liability to you for actual damages from any cause whatsoever, and regardless of the form of the action (whether in contract, tort [including negligence], product liability or otherwise), will be limited to $50.

PANTONE® Colors displayed in the software application or in the user documentation may not match PANTONE-identiﬁed standards. Consult current PANTONE Color Publications for accurate color. PANTONE® and other Pantone, Inc. trademarks are the property of Pantone, Inc. © Pantone, Inc., 2004.

Pantone, Inc. is the copyright owner of color data and/or software which are licensed to Electronics for Imaging, Inc., to distribute for use only in combination with the products, or software of Electronics for Imaging, Inc. PANTONE Color Data and/or Software shall not be copied onto another disk or into memory except as part of the delivery of the Electronics for Imaging, Inc., products or software.

This product includes software developed by the Apache Software Foundation (http://www.apache.org/).

Part Number: 45040406 13 February 2004

Page 4

FCC Information

WARNING: FCC Regulations state that any unauthorized changes or modiﬁcations to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment.

Class B Declaration of Conformity

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

In order to maintain compliance with FCC regulations, shielded cables must be used with this equipment. Operation with non-approved equipment or unshielded cables is likely to result in interference to radio and TV reception. The user is cautioned that changes and modiﬁcations made to the equipment without the approval of manufacturer could void the user’s authority to operate this equipment.

Industry Canada Class B Notice

This Class B digital apparatus complies with Canadian ICES-003.

Avis de Conformation Classe B de l’Industrie Canada

Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du Canada.

RFI Compliance Notice

This equipment has been tested concerning compliance with the relevant RFI protection requirements both individually and on system level (to simulate normal operation conditions). However, it is possible that these RFI Requirements are not met under certain unfavorable conditions in other installations. It is the user who is responsible for compliance of his particular installation.

Dieses Gerät wurde sowohl einzeln als auch in einer Anlage, die einen normalen Anwendungsfall nachbildet, auf die Einhaltung der Funkentstörbestimmungen geprüft. Es ist jedoch möglich, dass die Funkentstörbestimmungen unter ungünstigen Umständen bei anderen Gerätekombinationen nicht eingehalten werden. Für die Einhaltung der Funkentstörbestimmungen einer gesamten Anlage, in der dieses Gerät betrieben wird, ist der Betreiber verantwortlich.

Compliance with applicable regulations depends on the use of shielded cables. It is the user who is responsible for procuring the appropriate cables.

Die Einhaltung zutreffender Bestimmungen hängt davon ab, dass geschirmte Ausführungen benützt werden. Für die Beschaffung richtiger Ausführungen ist der Betreiber verantwortlich.

Software License Agreement

YOU SHOULD CAREFULLY READ THE FOLLOWING TERMS AND CONDITIONS BEFORE USING THIS SOFTWARE. IF YOU DO NOT AGREE TO THE TERMS AND CONDITIONS OF THIS AGREEMENT, DO NOT USE THE SOFTWARE. INSTALLING OR USING THE SOFTWARE INDICATES THAT YOU AGREE TO AND ACCEPT THE TERMS OF THIS AGREEMENT. IF YOU DO NOT AGREE TO ACCEPT THE TERMS OF THIS AGREEMENT YOU MAY RETURN THE UNUSED SOFTWARE FOR A FULL REFUND TO THE PLACE OF PURCHASE.

Page 5

License

EFI grants you a non-exclusive license to use the Software and accompanying documentation (“Documentation”) included with the Product. The Software is licensed, not sold. You may use the Software solely for your own customary business or personal purposes. You may not rent, lease, sublicense or lend the Software or use the Software in any time sharing, service bureau, or similar arrangement.

You may not make or have made, or permit to be made, any copies of the Software or portions thereof, except one (1) copy for backup or archive purposes in support of your use of the Software as permitted hereunder. You may not copy the Documentation. You may not attempt to localize, translate, disassemble, decompile, decrypt, reverse engineer, discover the source code of, modify, create derivative works of, or in any way change any part of the Software.

The terms, conditions, and restrictions in the License Agreement apply to all bug ﬁxes, patches, releases, release notes, updates, and upgrades related to the Software.

Proprietary Rights

You acknowledge and agree that all rights, title and interest, including all intellectual property rights, in and relating to the Software, Documentation and all modiﬁcations and derivative works thereof are solely owned by and shall remain with EFI and its suppliers. Except for the express limited license granted above to use the Software, no right or license of any kind is granted. You receive no rights or license under any patents, copyrights, trade secrets, or trademarks (whether registered or unregistered). You agree not to adopt, register, or attempt to register any EFI trademark or trade name (“EFI Mark”) or any confusingly similar mark, URL, internet domain name, or symbol as your own name or the name of your afﬁliates or products, and not to take any other action which impairs or reduces the trademark rights of EFI or its suppliers.

Conﬁdentiality

The Software is conﬁdential, proprietary information of EFI and you may not distribute or disclose the Software. You may, however, permanently transfer all of your rights under this Agreement to another person or legal entity provided that: (1) such a transfer is authorized under all applicable export laws and regulations, including the U.S. Export Administration Regulations, (2) you transfer to the person or entity all of the Software and Documentation (including all copies, updates, upgrades, prior versions, component parts, the media and printed materials, and this Agreement); (3) you retain no copies of the Software and Documentation, including copies stored on a computer; and (4) the recipient agrees to the terms and conditions of this Agreement.

Remedies and Termination

Unauthorized use, copying, or disclosure of the Software, or any breach of this Agreement will result in automatic termination of this license and will make available to EFI other legal remedies. In the event of termination, you must destroy all copies of the Software, Documentation, and all component parts thereof. All provisions of this Agreement relating to disclaimers of warranties, limitation of liability, remedies, damages, governing law, jurisdiction, venue, and EFI’s proprietary rights shall survive termination.

Limited Warranty and Disclaimer

EFI warrants to the original purchaser (“Customer”) for thirty (30) days from the date of original purchase from EFI or its authorized retailer that the Software will perform in substantial conformance to the Documentation when the Product is used as authorized by EFI’s speciﬁcations. EFI warrants the media containing the Software against failure during the above warranty period. EFI makes no warranty or representation that the Software will meet your speciﬁc requirements, that the operation of the Software will be uninterrupted, secure, fault-tolerant, or error free, or that all defects in the Software will be corrected. EFI makes no warranty, implied or otherwise, regarding the performance or reliability of any third party products (software or hardware. THE INSTALLATION OF ANY THIRD PARTY PRODUCTS OTHER THAN AS AUTHORIZED BY EFI WILL VOID THIS WARRANTY. IN ADDITION, USE, MODIFICATION, AND/OR REPAIR OF THE PRODUCT OTHER THAN AS AUTHORIZED BY EFI WILL VOID THIS WARRANTY.

EXCEPT FOR THE ABOVE EXPRESS LIMITED WARRANTY AND TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, EFI MAKES AND YOU RECEIVE NO WARRANTIES OR CONDITIONS ON THE SOFTWARE, EXPRESS, IMPLIED, STATUTORY, OR IN ANY OTHER PROVISION OF THIS AGREEMENT OR COMMUNICATION WITH YOU, AND EFI SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR NONINFRINGEMENT OF THIRD PARTY RIGHTS.

Page 6

Limitation of Liability

TO THE MAXIMUM EXTENT PERMITTED BY LAW, EFI AND ITS SUPPLIERS SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOST PROFITS, COST OF COVER OR OTHER SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING FROM THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE OR FAILURE OF THE SOFTWARE, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY. THIS LIMITATION WILL APPLY EVEN IF EFI HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. YOU ACKNOWLEDGE THAT THE PRICE OF THE PRODUCT REFLECTS THIS ALLOCATION OF RISK. BECAUSE SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT APPLY TO YOU.

You are hereby notiﬁed that Adobe Systems Incorporated, a Delaware corporation located at 345 Park Avenue, San Jose, CA 95110-2704 (“Adobe”) is a thirdparty beneﬁciary to this agreement to the extent that this agreement contains provisions which relate to your use of any software, font programs, typefaces, and/or trademarks licensed or supplied by Adobe. Such provisions are made expressly for the beneﬁt of Adobe and are enforceable by Adobe in addition to EFI. ADOBE WILL HAVE NO LIABILITY WHATSOEVER TO YOU FOR ANY ADOBE SOFTWARE OR TECHNOLOGY LICENSED HEREUNDER.

Export Controls

EFI’s Products are subject to U.S. export laws and regulations, including the U.S. Export Administration Regulations, as well as foreign export laws and regulations. You agree that you will not use, distribute, transfer, export, or re-export any portion of the Product or the Software in any form in violation of any applicable laws or regulations of the United States or the country in which you obtained them.

U.S. Government Restricted Rights:

Use, duplication, or disclosure of the Software by the United States Government is subject to restrictions as set forth in FAR 12.212 or DFARS 227.7202-3 -

227.7202-4 and, to the extent required under U.S. federal law, the minimum restricted rights as set out in FAR 52.227-14, Restricted Rights Notice (June 1987) Alternate III(g)(3)(June 1987) or FAR 52.227-19 (June 1987). To the extent any technical data is provided pursuant to the Agreement, such data is protected per FAR 12.211 and DFARS 227.7102-2 and to the extent explicitly required by the U.S. Government, is subject to limited rights as set out in DFARS 252.227.7015 (November 1995) and DFARS 252.227-7037 (September 1999). In the event that any of the above referenced agency regulations are modiﬁed or superceded, the subsequent or equivalent regulation shall apply. The name of the Contractor is Electronics for Imaging.

General

The rights and obligations of the parties related to this Agreement will be governed in all respects by the laws of the State of California exclusively, as such laws apply to contracts between California residents performed entirely within California. The United Nations Convention on Contracts for the International Sale of Goods and any other similar convention does not apply to this Agreement. For all disputes related to this Agreement, you consent to the personal and exclusive jurisdiction and venue of the state courts in San Mateo County, California and the federal court for the Northern District of California. This Agreement is the entire agreement held between us and supersedes any other communications or advertising with respect to the Software. If any provision of this Agreement is held invalid, such provision shall be deemed modiﬁed to the extent necessary to be enforceable and the other provisions in this Agreement shall continue in full force and effect.

If you have any questions, please see EFI’s web site at www.eﬁ.com.

Electronics for Imaging 303 Velocity Way Foster City, CA 94404

Page 7

Contents

About the Documentation

Introduction

About this manual

Chapter 1: Connecting to the Network

Fiery X3e on the network

Stages of installation on the network

Quick path to installation

Connecting network cable to the Fiery X3e

Back view of the Fiery X3e 1-11

Ethernet connection 1-12

Parallel cable connection 1-12

Chapter 2: Setting up Network Servers

Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003

Tips for experts—Windows with TCP/IP 2-2

Conﬁguring a Windows NT 4.0/2000/Server 2003 server to communicate with the Fiery X3e 2-3

Fiery X3e on a NetWare network

Tips for experts—IPX networks 2-9

Overview of IPX printing to the Fiery X3e 2-9

Conﬁguring a NetWare server for printing 2-10

xii

1-1

1-2

1-4

1-11

2-1

2-8

Fiery X3e on a NetWare network with NDPS

Tips for experts—NetWare networks 2-14

Conﬁguring a NetWare server for printing with NDPS 2-15

2-14

Page 8

viii Contents

Fiery X3e on a network with UNIX workstations

Tips for experts—UNIX workstations 2-18

Important note about the remote printer name 2-18

Setting up the Fiery X3e on TCP/IP networks 2-19

Managing print jobs 2-20

Chapter 3: Preparing for Fiery X3e Setup

Levels of access and control

Fiery X3e print connections 3-1

Passwords 3-3

WebTools 3-4

Control level scenarios 3-6

About Setup

Network server setup requirements 3-8

Ensuring the copier connection 3-9

Chapter 4: Performing Setup from the Control Panel

Fiery X3e Setup from the Control Panel

Fiery X3e copier Control Panel

Safety warnings 4-3

Accessing Setup options 4-4

About the Control Panel Setup interface 4-4

Types of Setup screens 4-5

2-17

3-1

3-7

4-1

4-3

Server Setup options

Network Setup options

Port Setup options 4-10

Protocol Setup options 4-12

Service Setup options 4-20

4-5

4-8

Page 9

ix Contents

Printer Setup options

PostScript Setup options

PCL Setup options

Color Setup options

Administrative functions in the Setup menu

Job Log Setup 4-50

Chapter 5: Setting up the Fiery X3e from a Windows Computer

Accessing Setup

Remote Fiery Setup 5-1

General Setup options

Job Log Setup 5-5

Network Setup

Adapters/Ports 5-7

Protocols 5-9

Services 5-15

Windows print sharing with Server Message Block (SMB) 5-25

Printer Setup options

Printer connections 5-31

PS (PostScript) Setup 5-32

4-39

4-41

4-43

4-45

4-49

5-1

5-3

5-6

5-31

Setting up printing groups

Exiting Setup

Printing the Conﬁguration page

Chapter 6: Conﬁguring Fiery WebTools

Conﬁguring the Fiery X3e and clients for WebTools

Setting up Fiery WebTools

Setting the WebLink destination

5-34

5-35

5-36

6-1

6-2

6-3

Page 10

x Contents

Chapter 7: Administering the Fiery X3e

Administrator functions

Setting passwords

Passwords from the Control Panel 7-3

Passwords 7-4

Clearing the Fiery X3e

Managing address books

Printing a Conﬁguration page from the Control Panel

Maintaining optimal Fiery X3e performance

Shutting down, rebooting, and restarting the Fiery X3e

Shutting down and rebooting the Fiery X3e 7-11

Restarting the Fiery X3e 7-12

Appendix A: Troubleshooting

Troubleshooting the Fiery X3e

Tr oubleshooting during Setup from the Control Panel A-1

Runtime error messages A-7

Index

7-1

7-2

7-5

7-6

7-8

7-9

7-11

A-1

Page 11

Introduction

This manual is intended for anyone who is responsible for integrating the Fiery X3e Color Server into a business environment that includes networked personal computers. After the Fiery X3e Color Server and client workstations are set up, individual users can print to the Fiery X3e Color Server as a high-performance PostScript or PCL copier.

This manual describes how to set up network servers and clients to use the Fiery X3e Color Server and how to install user software and set up printing from Microsoft Windows and Apple Mac OS computers. For general information on using the copier, your computer, your software, or your network, see the manuals that accompany those products.

OTE

The term “Fiery X3e” is used in this manual to refer to the Fiery X3e Color

Server. The name “Aero” is used in illustrations to represent the Fiery X3e. The term “Windows” is used to refer to Windows 98, Windows Me, Windows NT 4.0, Windows 2000, Windows XP, and Windows Server 2003, wherever appropriate. “Setup” is used to refer to conﬁguring the Fiery X3e for proper performance in your network environment, including settings that affect all jobs. The administrator can perform Setup from the WebSetup and Command WorkStation.

The Fiery X3e includes support for the Fiery WebTools™ and software for Command WorkStation, which allow an operator to manage all jobs sent to the Fiery X3e. Although it may not be the case at all sites, the documentation for this product assumes the presence of an operator who controls and manages jobs sent by users from remote workstations.

Any additional connectivity or administrative features speciﬁc to the copier are described in the

Printing Guide

or the

Release Notes.

Page 12

xii Introduction

About this manual

This manual covers the following topics:

•Basic conﬁguration of the Fiery X3e to support printing over AppleTalk, TCP/IP, and IPX (Novell) networks

•Administering network printing

• Conﬁguring Novell and Microsoft Windows NT 4.0/2000/Server 2003 servers and UNIX systems to provide Fiery X3e printing services

•Using the Fiery X3e in mixed network environments

OTE

The network guidelines in this book are not intended to replace the services of

an experienced network engineer.

This manual is organized as follows:

• Chapter 1 illustrates the supported network conﬁgurations and shows the network connectors on the Fiery X3e.

• Chapter 2 provides guidelines for setting up Windows network servers and UNIX systems for printing to the Fiery X3e and for using WebTools.

• Chapter 3 describes how to prepare for Fiery X3e Setup, including planning system security through access levels.

• Chapter 4 describes Fiery X3e conﬁguration (Setup) from the Control Panel.

• Chapter 5 describes Fiery X3e Setup from a Windows computer.

• Chapter 6 describes setting up the Fiery X3e for Fiery WebTools.

• Chapter 7 summarizes some administrative features of Fiery X3e software that are available for IPX/SPX, TCP/IP, and AppleTalk networks, and offers troubleshooting hints.

• Appendix A describes issues that may occur in setting up the Fiery X3e and offers solutions.

OTE

Administrator features described in other manuals are summarized on page 7-1.

Page 13

1-1 Fiery X3e on the network

Chapter 1: Connecting to the Network

This chapter summarizes the stages in setting up the Fiery X3e, and includes diagrams that refer you to other chapters or other manuals for completing your installation. Check those references to ﬁnd the information you need quickly.

Fiery X3e on the network

When the Fiery X3e is connected to a network, it behaves as a networked PostScript printer. The built-in Ethernet interface on the Fiery X3e supports the following network protocols (rules that enable computers on a network to communicate with each other):

•AppleTalk

• TCP/IP (the lpd, nbt, and http protocols)

TCP/IP stands for Transmission Control Protocol/Internet Protocol. The lpd protocol is the standard TCP/IP printing protocol. The nbt protocol supports Windows (SMB) printing. The port 9100 is the printer server port number to publish print connections between the print server and a remote computer. The http protocol is commonly used for Web pages on the Internet and on intranets. The http protocol also supports IPP printing.

• IPX/SPX (Novell)

IPX/SPX stands for Internetwork Packet Exchange/Sequenced Packet Exchange.

These protocols are supported on Mac OS, Windows, and UNIX platforms and can run concurrently on the same cable. Workstations that use other protocols can print through a server that uses one of the protocols mentioned.

When you add the Fiery X3e to a network, it is assumed that a network administrator has already installed a network cabling system and connected workstations and servers.

Page 14

1-2 Connecting to the Network

•Physically connecting the Fiery X3e to a functioning network

• Conﬁguring the network server

• Setting up the Fiery X3e

Stages of installation on the network

Installation can be performed by a network or printing administrator. The stages of a successful installation are:

Prepare a network node for the Fiery X3e—obtain cable, route it to the location where the Fiery X3e will be installed, and attach the cable to the network interface. For details, see page 3-9.

When network servers are required, you need to conﬁgure those servers to provide client access to the Fiery X3e as a PCL or PostScript printer. For information on conﬁguring network servers in Windows and UNIX network environments, see

Chapter 2.

Conﬁgure the Fiery X3e for your particular printing and network environment. First read Chapter 2, and then see subsequent chapters for details.

•Preparing client workstations for printing

Install the ﬁles needed for printing, install additional user software, and connect the client to the Fiery X3e over the network. These steps are described in the

Installation Guide

•Administering the Fiery X3e

Monitor and maintain system performance and troubleshoot problems that arise. For details, see Chapter 7 of this manual and the

, and some information is also provided in Chapter 2.

Job Management Guide

User Software

Page 15

1-3 Stages of installation on the network

Summary of Fiery X3e network installation

CONNECTION

SERVER CONFIGURATION

FIERY X3E SETUP

CLIENT SETUP

Fiery X3e

Network server

Fiery X3e

UNIX Mac OS Windows

Prepare a network node. Connect the Fiery X3e to the network. If you use a computer running Command WorkStation software, connect it to the network.

Conﬁgure UNIX, Windows NT 4.0/2000/Server 2003, and IPX (Novell) servers to specify Fiery X3e print queues and Fiery X3e users.

No special conﬁguration of AppleShare servers is required.

On the Fiery X3e Control Panel, conﬁgure, at a minimum, the Server Setup, Network Setup, and Printer Setup.

At each workstation that will print to the Fiery X3e:

•Install the appropriate printer ﬁles and connect to one or more queues.

• For computers that will use them, install Fiery utilities and an Internet browser.

•Verify the Fiery X3e in the list of printers and run a test print.

Fiery X3e available on the network

Page 16

1-4 Connecting to the Network

Quick path to installation

The diagrams on the following pages show typical systems you can use to print and run Fiery software from remote workstations. Find the page with your preferred platform and network type, and then look up the setup procedures referenced in the “Key to setup” in the upper-left corner of each diagram.

The diagrams describe devices that use the supported networking protocols. They are logical diagrams and are not intended to describe the physical arrangement (topology) of devices on the network. A variety of physical arrangements is possible with each logical arrangement. For example, twisted pair Ethernet networks commonly use a star conﬁguration around a hub, rather than a bus arrangement. The design of physical networks is beyond the scope of this manual.

If your network uses more than one protocol or more than one type of workstation, combine the setups listed for each component of your system. Multiple protocols (shown in the diagrams as parallel lines) can run on the same cable. A solid connection from the Fiery X3e with an arrow indicates that other supported network types can be operational at the same time.

The protocols used in these diagrams are indicated as follows:

IPX (Novell)

AppleTalk

TCP/IP (lpd, nbt, or http)

Parallel

Other

Page 17

1-5 Quick path to installation

Mac OS environment with AppleTalk

Key to setup:

1Mac OS computer User Software Installation Guide

2Fiery Setup Chapter 4

Fiery X3e installed in the copier

TCP/IP (http) for Fiery WebTools

AppleTalk

Mac OS computer

AppleTalk protocol

TCP/IP

Mac OS computer

Mac OS computers can print directly

Mac OS computer

Printing on this network

Mac OS computers can print directly using the AppleTalk protocol.

For using Fiery Utilities

Fiery utilities can be used with the AppleTalk protocol. To use ColorWise Pro Tools, TCP/IP

required.

For using Fiery WebTools

A Mac OS computer with TCP/IP (http) loaded.

Page 18

1-6 Connecting to the Network

Windows computers in a Novell environment

Key to setup:

1NetWare server page 2-14

2Fiery X3e Setup Chapter 4

3NetWare client User Software Installation Guide

Windows computer with SPX page 2-9

Fiery X3e installed in the copier

Another supported protocol

Windows computer: NetWare client

IPX protocol

SPX protocol (TCP/IP or AppleTalk possible)

IPX

Windows computer: NetWare client

NetWare server

Windows computer: NetWare client running SPX

3, 4

IPX

TCP/IP (http) for Fiery WebTools

Printing on this network

All Windows computers can print through the NetWare server.

For using Fiery WebTools

A Windows computer with TCP/IP (http) loaded.

Page 19

1-7 Quick path to installation

Windows NT 4.0/2000/Server 2003 Server environment

Key to setup:

1 Windows Server page 2-3

2Fiery X3e Setup Chapter 4

3 Windows client page 2-6

Another supported protocol

Windows NT 4.0/2000/XP Workstation or Windows NT 4.0/2000/Server 2003 Server acting as print server

LAN with NETBEUI, etc.

Windows computer

NETBEUI or other protocol available on the clients and the server

TCP/IP

Fiery X3e installed in the copier

TCP/IP (lpd) for printing TCP/IP (http) for Fiery WebTools TCP/IP for Fiery utilities

Windows computer with TCP/IP loaded

Printing on this network

Windows clients can print using a protocol available on the Windows NT 4.0/2000/Server 2003 print

Windows computers can print using TCP/IP with the lpd protocol.

For running Fiery utilities and Fiery WebTools

A Windows computer with TCP/IP loaded.

server.

Page 20

1-8 Connecting to the Network

Windows computers using Windows printing

Key to setup:

1 Windows computer User Software Installation Guide

2Fiery X3e Setup Chapter 4

Another supported protocol

Fiery X3e installed in the copier

TCP/IP (nbt)

Windows computer

TCP/IP (nbt) protocol

Windows computer

For Windows printing

Windows (SMB) printing enabled on the Fiery X3e.

Windows NetBios and TCP/IP enabled on

computer.

the

Page 21

1-9 Quick path to installation

UNIX workstations and Windows computers on a TCP/IP network

Key to setup:

1 UNIX server/host page 2-17

2Fiery X3e Setup Chapter 4

3 UNIX workstation page 2-17

4TCP/IP client User Software Installation Guide,

Chapter 4

5 Windows client page 2-6

UNIX server or workstation

1, 3

Another supported protocol

Fiery X3e installed in the copier

TCP/IP (lpd) protocol

TCP/IP client PC

TCP/IP (lpd, http, and ipp)

Windows computer with TCP/IP loaded

Printing on this network

UNIX workstations with the TCP/IP (lpd) protocol can print directly and act as host for shared printing.

TCP/IP clients can print through UNIX server or directly; requires TCP/IP and the lpr print service loaded.

For running Fiery utilities and Fiery WebTools

Windows computers with TCP/IP loaded can use these applications.

Page 22

1-10 Connecting to the Network

Fiery X3e parallel port connection

Key to setup:

1Fiery X3e Setup Chapter 4

2 Windows computer Printing Guide

A supported network protocol

With the parallel port enabled, the Fiery X3e can accept and print jobs sent to its parallel port

Parallel

Fiery X3e installed in

copier

Parallel input

Protocol not directly supported on Fiery X3e

PC workstation, server, or laptop

Page 23

1-11 Connecting network cable to the Fiery X3e

Parallel Port

RJ-45 Ethernet (10/100Base T)

Connecting network cable to the Fiery X3e

In this section, the back panel of the Fiery X3e is illustrated, followed by information for connecting to the Ethernet board.

Back view of the Fiery X3e

Page 24

1-12 Connecting to the Network

Ethernet connection

For Ethernet connections, the Fiery X3e supports cabling, deﬁned as Category 5 for use with 100BaseT; or as Category 3, Category 4, or Category 5 for use with 10BaseT. The cable uses an 8-pin RJ-45 connector that plugs into the RJ-45 socket on the Fiery X3e.

NOTE: The 100BaseT type supported by the Fiery X3e is 100BaseTX, also known as

Fast Ethernet. If an Ethernet hub is used, it must be a 100BaseTX hub. The term “100BaseT” is used to refer to 100BaseTX.

TO CONNECT TO THE ETHERNET BOARD

• Connect the network cable to the RJ-45 connector on the back of the Fiery X3e.

You must use a Category 5 unshielded twisted pair cable network cable for 100BaseT.

Parallel cable connection

The Fiery X3e can accept print jobs from a Windows computer through its high-speed parallel port. This connection is advantageous for portable computers and for workstations on dedicated networks using protocols other than AppleTalk, TCP/IP, or IPX.

The parallel port connection can be active at the same time as the network ports.

NOTE: The parallel port cannot be used to connect the Fiery X3e with

Command WorkStation or other Fiery utilities.

TO USE PARALLEL CABLE

1. With the Fiery X3e and the Windows computer turned off, attach the parallel cable to the parallel port of the Fiery X3e.

For the location of the parallel port, see the illustration on page 1-11.

2. Connect the other end of the cable to the parallel port on the Windows computer.

3. Turn on the computer and the Fiery X3e.

4. Proceed to Setup.

Page 25

2-1 Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003

Chapter 2: Setting up Network Servers

This chapter describes environments that typically include one or more network servers—Novell NetWare servers and Windows NT 4.0/2000/Server 2003 servers— that share printing to the Fiery X3e. It describes setting up servers that use IPX/SPX or TCP/IP protocols for communicating with the Fiery X3e. In addition, it includes guidelines for setting up direct communication from Windows NT 4.0/2000/XP workstations or UNIX workstations, where a network server is optional. This chapter also outlines the requirements for users to print to the Fiery X3e and run Fiery utilities and Fiery WebTools.

The Fiery X3e can accept jobs concurrently from NetWare, Windows NT 4.0/2000/ Server 2003, and AppleShare servers, as well as jobs sent directly from Windows or UNIX workstations. Because AppleShare servers require no special conﬁguration, they are not discussed in this chapter, except for use in a Windows NT 4.0/2000/XP environment (see “Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/

Server 2003” in the following section).

If your network is based on Windows NT 4.0/2000/Server 2003, proceed to the following section. For information on UNIX workstations, proceed to page 2-17.

Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003

When a Windows NT 4.0/2000/XP computer is conﬁgured to connect to the Fiery X3e using TCP/IP, it can print directly to the Fiery X3e. If the computer shares the printer over the network, it is acting as a print server to Windows clients. Client computers print to the Fiery X3e by printing to the Windows NT 4.0/2000/Server 2003 print server. You can then monitor and control printing at the Windows NT 4.0/ 2000/Server 2003 server computer.

Page 26

2-2 Setting up Network Servers

• Make sure you have a valid IP address for the Fiery X3e and any workstations that will

Typical system combinations are:

•Print server running Windows NT 4.0/2000/Server 2003 Server; clients running

Windows NT 4.0/2000/XP Workstation and Windows 98/Me

•Print server running Windows NT 4.0/2000/XP Workstation and clients running

Windows 98/Me

With TCP/IP protocols loaded, you can run Fiery utilities and Fiery WebTools from a Windows computer.

Tips for experts—Windows with TCP/IP

Setting up printing from Windows using TCP/IP protocols is similar to setting up UNIX workstations with TCP/IP. When TCP/IP network connections are made from Windows NT 4.0/2000/XP workstations, note the following:

print to it or run the Fiery utilities.

• In Fiery X3e Setup, enable TCP/IP and enter the IP address, subnet mask, and gateway address for the Fiery X3e.

Enter these addresses manually or use DHCP or BOOTP protocols to assign them dynamically.

• Make sure the Fiery X3e name and address are listed in a domain name server (DNS) or host name database used by your system.

• Make sure the system host table includes the correct internal name for the Fiery X3e as a remote printer.

For more information, see page 2-18.

•For Windows, install the appropriate printer driver ﬁles (PCL or PostScript) on the Windows NT 4.0/2000/Server 2003

For more information, see the User Software Installation Guide.

• Repeat the installation for all users who print to the Fiery X3e.

Each server and workstation running the Fiery utilities with TCP/IP also needs the TCP/IP protocol and the Fiery utility software.

server.

Page 27

2-3 Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003

• Load the TCP/IP network protocol on the server and conﬁgure it with an IP address,

• Enter the host name of the Fiery X3e in the host name database used by your system

•Perform Fiery X3e Setup.

• On the Windows NT 4.0/2000/Server 2003 server, create a printer for each Fiery X3e

• Enter the host name and remote printer name of the Fiery X3e in the printer

Conﬁguring a Windows NT 4.0/2000/Server 2003 server to communicate with the Fiery X3e

To conﬁgure a Windows NT 4.0/2000/Server 2003 server to communicate with the Fiery X3e, follow these general steps. More detail is provided in subsequent sections in this chapter and in your Microsoft documentation.

subnet mask, and gateway.

(see page 2-4).

print connection, install the appropriate printer drivers, and (optionally) share the printer on the network (see page 2-5).

connection. For more information, see page 2-18.

• If the Windows NT 4.0/2000/Server 2003 server is also a workstation, install Fiery utilities (see the User Software Installation Guide).

Page 28

2-4 Setting up Network Servers

Adding the Fiery X3e to the TCP/IP network

If your TCP/IP network consists of Windows NT 4.0/2000/Server 2003 servers and Windows clients, follow the procedures in this section. If the network includes UNIX workstations, also see the procedures on page 2-19.

TO ADD THE FIERY X3E TO A TCP/IP NETWORK WITH A WINDOWS NT 4.0/2000/SERVER 2003 SERVER

1. Register the IP address of the Fiery X3e in the host name database used by your system.

For installations that do not have a network administrator or central host name database, add the Fiery X3e to the hosts ﬁle on the Windows NT 4.0/2000/Server 2003 server. Also add it to the hosts ﬁle on any workstations that have TCP/IP loaded and will use the Fiery utilities.

The Windows NT 4.0/2000/Server 2003 hosts ﬁle provides compatibility with the UNIX hosts ﬁle. The hosts ﬁle is used as a local Domain Name Services (DNS) equivalent. It has the same format as the /etc/hosts ﬁle on UNIX servers. The format of the hosts entry is:

IP Address<TAB>host name<TAB>#comments

where <TAB> indicates that you press the Tab key.

To determine the IP address and server name of your system, print a Conﬁguration page (see page 7-8).

NOTE: If the Fiery X3e has already been deﬁned in an /etc/hosts ﬁle or equivalent host

name database on a UNIX workstation on your network, we recommend you use the same host name here as you used for the name of the remote printer in the /etc/

printcap

2. Perform Fiery X3e Setup to support TCP/IP printing.

Enter the options in Protocol Setup (IP address of the Fiery X3e, subnet mask, and gateway address).

ﬁle.

Page 29

2-5 Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003

Installing the Fiery X3e as a shared printer

The ﬁrst step in creating a printer is installing the printer driver ﬁles, which give your applications access to printer features. You can use the installation instructions in the

User Software Installation Guide for every workstation that will print directly and

independently to the Fiery X3e. However, if you are an administrator running a Windows NT 4.0/2000/Server 2003 server or Windows NT 4.0/2000/XP workstation, you can also create a printer and share it with clients on the network. This allows clients who do not have permission to establish an independent network connection to the Fiery X3e to print through the server.

You can specify sharing of the printer during installation of the Fiery X3e printer ﬁles. If you have not yet installed the Fiery X3e printer ﬁles on the Windows NT 4.0/2000/ Server 2003 print server computer, do so now, following the instructions in the User

Software Installation Guide. During installation, enter the information necessary to

share the Fiery X3e.

If you have already installed the Fiery X3e printer ﬁles on the computer you are using as a Windows NT 4.0/2000/Server 2003 print server, see your Windows documentation for information about sharing the Fiery X3e.

If more than one Fiery X3e print connection is published (for example, if both the Print queue and the Hold queue are published), you may want to create a printer for each print connection, so that you and other users can print to each connection directly. When prompted to specify the printer name, enter a name that indicates the Fiery X3e print connection.

Page 30

2-6 Setting up Network Servers

Conﬁguring clients of a Windows NT 4.0/2000/Server 2003 server

Each client of a Windows NT 4.0/2000/Server 2003 server is already using a network protocol to communicate with the server. Each client can print to the Fiery X3e if it has been shared by a Windows NT 4.0/2000/Server 2003 server, or Windows NT 4.0/ 2000/XP computer. In that case, the client does not have to use the same network protocol to connect to the Windows NT 4.0/2000/Server 2003 server as the server uses to communicate with the Fiery X3e.

TO CONNECT AND PRINT TO THE FIERY X3E SHARED

BY A WINDOWS NT 4.0/2000/SERVER 2003 SERVER

• Windows 98/Me: Before printing, double-click the Windows NT 4.0/2000/Server 2003 server icon in the Network Neighborhood window, and then double-click the printer name.

You are prompted to set up the printer. When you choose to set it up, the Add Printer Wizard dialog box appears. Follow the procedures in the User Software

Installation Guide.

• Windows NT 4.0/2000/XP: Before printing, connect to the print server computer and select the Fiery X3e. Right-click and choose the Open command.

When prompted, click Yes to have Windows set up the printer.

After clients have selected the printer, they can choose it from the Print Setup, Page Setup, or Print dialog box of their application. Clients can change printing options for their own job, but printer properties appear dimmed, and are unavailable for changing. When a client chooses Print, the job is transmitted to the Windows NT 4.0/2000/ Server 2003 print server, and from there to the selected print connection on the Fiery X3e. The job is listed in the Print Manager on the client workstation, and the administrator can track it in the Fiery X3e window in the Print Manager on the Windows NT 4.0/2000/Server 2003 print server.

Page 31

2-7 Fiery X3e on a TCP/IP network with Windows NT 4.0/2000/XP/Server 2003

• Print a Conﬁguration page (see page 5-36).

• Load the TCP/IP network protocol on the computer.

Conﬁguring Windows computers without a Windows NT 4.0/2000/Server 2003 server

If your network does not have a Windows NT 4.0/2000/Server 2003 server, Windows workstations can still print to the Fiery X3e. This method of printing is called Windows, or SMB printing. In this type of network environment, computers running Windows 98/Me and Windows NT 4.0/2000/XP workstations operate in a peer-topeer environment and communicate directly with the Fiery X3e when users send print jobs.

Many of the same prerequisites for setting up printing through a Windows NT 4.0/ 2000/Server 2003 server also apply to setting up Windows printing where a server is not present. The prerequisites are summarized in the following list, and you can ﬁnd more detail in your Microsoft documentation.

Use the information on this page to determine the current Fiery X3e settings.

Windows 98/Me: Load File and printer sharing for Microsoft Network. Windows 2000/XP: Load Client for Microsoft Networks.

• In the Windows Network Control Panel, verify the Workgroup name of the computer. Make sure that the Workgroup name is the same as the one listed in Fiery X3e Setup.

• Windows 98/Me: In the File and printer sharing for Microsoft Network Properties dialog box, specify Automatic or Enabled for Browse Master, and select Yes for LM

Announce.

Windows 2000/XP: In the Client for Microsoft Networks Properties dialog box, conﬁgure the computer to allow ﬁle sharing, and then restart the computer.

• Ping the Fiery X3e to verify TCP/IP communication is successful (see page 2-19).

Page 32

2-8 Setting up Network Servers

Fiery X3e on a NetWare network

The NetWise™ features built into the Fiery X3e support the following network operating environments:

•NetWare—NDS (Novell Directory Services)

•Servers running NetWare in bindery emulation mode

The term “Netware” is used to refer to Netware 4.x, 5.x, and 6.x.

NOTE: Setting up a NetWare environment correctly requires the presence and active

cooperation of the Novell network administrator. You must have administrator privileges on the network to create new NDS or bindery objects.

NOTE: The iPrint feature available with NetWare 6.x is not supported.

The term “bindery server” is used to refer to a Novell ﬁle server running NetWare in emulation mode. The term “NDS” is used to describe components of a NetWare operating system running NetWare in native mode.

NetWare clients print to the Fiery X3e through the Novell network server. Server setup and client network setup are outlined in this chapter, client printing setup is described in the User Software Installation Guide, and printing is described in the Printing Guide.

The Fiery X3e can receive print jobs from NetWare clients over Ethernet network topologies. During Fiery X3e Setup, you select the frame type or types that will be used for communication between the Fiery X3e and network servers. Frame type refers to the format of a communications packet; frame types are speciﬁed in a startup ﬁle when the NetWare server (or any other workstation) loads its network drivers.

Page 33

2-9 Fiery X3e on a NetWare network

•A minimum connection to the Fiery X3e consists of a NetWare ﬁle server, a NetWare

•A single directory tree and up to eight bindery servers can be conﬁgured

• The Fiery X3e looks for print jobs on one NetWare print server per bindery server.

• Each print server can store jobs for any print connection on the Fiery X3e.

Tips for experts—IPX networks

Setting up the Fiery X3e is similar to setting up any other PostScript printer on the network.

The Fiery X3e with IPX connections has the following characteristics:

print server, and a NetWare queue.

simultaneously.

Overview of IPX printing to the Fiery X3e

NetWare ﬁle servers support the creation of print queues, which are storage areas for print jobs. When a client on a remote computer decides to print, the job is directed to a print queue on the NetWare ﬁle server and spooled to the NetWare server disk, freeing up the client workstation.

You must give the NetWare queue names a speciﬁc extension corresponding to the Fiery X3e print connection, as follows:

_print _hold _direct

NOTE: These extension names must be in English and in all lowercase letters.

Page 34

2-10 Setting up Network Servers

You do not need to rerun Setup when you add or remove a NetWare queue; however, you should restart the Fiery X3e after you create or remove a queue.

When the Fiery X3e is conﬁgured to connect to a NetWare server, it polls the NetWare server for jobs in each of its queues. If jobs are found, they are automatically transferred over the network to the matching connection on the Fiery X3e. For example, jobs from the NetWare queue with the _print extension are sent to the Fiery X3e Print queue. While a job is processed and printed, a record of the job is being created. You can access the Job Log containing these records at any time.

Conﬁguring a NetWare server for printing

The following sections explain how to set up a NetWare ﬁle server so networked users can print to the Fiery X3e from their workstations, and the Fiery X3e can obtain print jobs from the NetWare server.

For each NetWare ﬁle server that you conﬁgure, follow these general steps. More detail is provided in subsequent sections and in your NetWare documentation.

•Make sure the server is connected to a functioning IPX network.

• Log in as the Supervisor on a PC connected to the NetWare ﬁle server.

•For NetWare installations, set up an NDS connection (see page 2-12).

•For NetWare in emulation mode, set the bindery context (see page 2-12).

•For NetWare in bindery emulation, set up a ﬁle server, print server, and print queue

for the Fiery X3e (see page 2-13).

With bindery services, you can route all Fiery X3e print jobs through the same NetWare ﬁle server, or you can conﬁgure more than one ﬁle server to handle Fiery X3e jobs.

The functions you perform on the Novell server, the Fiery X3e, and the client workstation are summarized in the following tables. The ﬁrst table applies to NDS connections, and the second to bindery connections. Complete the operations in the left column, then the center column, then the right column.

Page 35

2-11 Fiery X3e on a NetWare network

Conﬁguring an NDS connection

Abbreviations:

FS = ﬁle server PS = print server PQ = print queue (on the NetWare server)

On NDS FS

In NETADMIN:

Create NDS PQs

Create NDS printer and assign PQs

Create PS and assign the printer

Conﬁgure users of the PQs

Conﬁguring a bindery connection

On Bindery FS

In PCONSOLE:

Select NetWare FS (up to 8)

For each FS: Conﬁgure PS

Conﬁgure PQ

Conﬁgure users of the PQ

Port Setup

Protocol Setup

Service Setup

Port Setup

Protocol Setup

Service Setup

In Setup from

Command WorkStation

Ethernet Setup

IPX/SPX Setup—select frame types

PServer Setup and NDS Setup Select Root Browse to select PS Specify PQ search root (optional) Set Polling Interval

In Setup from

Command WorkStation

Ethernet Setup

IPX/SPX Setup—select frame types

PServer Setup and Bindery Setup Add FS (up to 8) Set Polling Interval

On client workstation

Install user software.

For printing: Connect client to PQs that you set up on the NetWare FS (associated with the PS selected in NDS Setup).

For running Fiery utilities: Conﬁgure the connection to the Fiery X3e.

On client workstation

Install user software.

For printing: Connect client to PQs that you set up on the NetWare FS (associated with the PS selected in Bindery Setup).

For running Fiery utilities: Conﬁgure the connection to the Fiery X3e.

Page 36

2-12 Setting up Network Servers

Setting up an NDS connection

In NDS, all NetWare entities (objects) are organized in a hierarchical tree structure. Objects have a name, properties, and a context that deﬁnes the location of the object in the directory tree. For the Fiery X3e, you are mainly concerned with deﬁning a printer, a print server object, and one or more print queue objects. Objects are created in NetWare administrator programs such as PCONSOLE, NETADMIN, or NetWare Administrator.

The top-level tree object is known as the [Root] object. The name of the [Root] object is also the name of the tree. Below the [Root] are other objects: either containers (which consist of other objects) or leaf objects (which do not contain other objects). Access to objects is controlled by rights that are deﬁned as properties of each object. Rights are established by network administrators.

Setting the NetWare bindery context

You can connect only one directory tree to the Fiery X3e. If you need to connect additional NetWare servers, you can do so by using bindery emulation. You can connect up to eight bindery servers to the Fiery X3e.

NOTE: The ﬁle server you select must not be in the same tree as the one you selected in

NDS Setup.

In order to set up the NetWare server in bindery emulation mode for printing to the Fiery X3e, the network administrator must do the following:

•Determine the Directory Services path to the container in which the print server and

the print queue for the Fiery X3e will be created.

The container deﬁnes the “bindery context” for your network structure.

•Edit the network startup ﬁle to set the bindery context.

•Activate the new bindery context.

Page 37

2-13 Fiery X3e on a NetWare network

Setting up a NetWare print queue for bindery

For NetWare in emulation mode, the NetWare print server and print queue for the Fiery X3e are created and conﬁgured from NetWare Print Console (PCONSOLE), a NetWare utility that is stored in the NetWare PUBLIC directory.

As with NDS, you can create several NetWare entities on a Novell server, and you can then select them in Network Setup.

Setting up NetWare Windows clients for printing

Before setting up client workstations for printing, perform Network Setup (see

page 4-8), and verify that the settings reﬂect the entities you created in the NetWare

administrator utilities (see page 2-10).

NOTE: For printing to the Fiery X3e, connect all Windows clients to a NetWare server

and permit them to connect to the Netware print server or servers on which you deﬁned a NetWare print queue for the Fiery X3e.

After the Novell server and the Fiery X3e have been set up, client setup consists of:

•Installing the networking protocol, binding it to the network adapter card, and

permitting the client to log in to the NetWare ﬁle server.

On Windows 98/Me workstations, load both the IPX/SPX-compatible protocol and the Client for NetWare Networks from the Network Control Panel.

On Windows NT 4.0/2000/XP workstations, install Client Services for NetWare. Use the CSNW option in the Control Panel to set printing options and specify a preferred NetWare server.

•Setting up the Fiery X3e as a PostScript printer by installing a PostScript printer

driver and the Fiery X3e PPD (PostScript printer description).

•Adding a network port and connecting the workstation to one or more NetWare

queues that have been deﬁned for the Fiery X3e.

•Installing Fiery X3e software, such as color reference ﬁles.

For details, see the User Software Installation Guide.

Page 38

2-14 Setting up Network Servers

Fiery X3e on a NetWare network with NDPS

The Fiery X3e supports printing over a NetWare 5.x or later network running either the TCP/IP protocols or the IPX protocol. For pure IP printing, the Fiery X3e takes advantage of features in NDPS (Novell Distributed Print Services). For IPX printing, the Fiery X3e supports the PServer service in Bindery emulation or through NDS (Novell Directory Services). For more information on IPX-based printing, see

“Fiery X3e on a NetWare network” on page 2-8.

NOTE: Setting up a NetWare environment correctly requires the presence and active

cooperation of the Novell network administrator. You must have administrator privileges on the network to create new NDS or bindery objects.

NDPS is not like earlier queue-based versions of NetWare printing. Instead, you use an NDPS Manager and a Printer Agent, which control the tasks previously handled by a print queue, print server, and spooler. You can also make the printer driver available for clients to download from Windows 98/Me and Windows NT 4.0/2000/XP computers.

During Fiery X3e Setup, you select the frame type or types that will be used for communication between the Fiery X3e and network servers. Frame type refers to the format of a communications packet; frame types are speciﬁed in a startup ﬁle when the NetWare server (or any other workstation) loads its network drivers.

Tips for experts—NetWare networks

Setting up the Fiery X3e in an NDPS environment is similar to setting up any other PostScript printer on the network. When setting up the Fiery X3e in such an environment, refer to the following information:

• Make sure you have a valid IP address for the Fiery X3e and for any workstations that will print to it or run Fiery utilities.

• In Fiery X3e Setup, enable TCP/IP and enter the IP address, subnet mask, and gateway address for the Fiery X3e. You can enter these manually or use DHCP or BOOTP protocols to assign the addresses dynamically.

• Bidirectional communication features in NDPS are not supported on the Fiery X3e.

Page 39

2-15 Fiery X3e on a NetWare network with NDPS

Conﬁguring a NetWare server for printing with NDPS

Before you begin

The following procedure assumes NDPS has been installed during NetWare 5.x or later installation and that a Broker is running on the server. Unless you have manually unloaded the Broker, it loads and runs when you install NDPS. Make sure you are using the latest NetWare service pack and Novell gateway. Finally, create an NDPS Manager. For more information, see your NetWare documentation.

In Fiery X3e Setup, make sure you have enabled TCP/IP and LPD printing on the Fiery X3e. You can ping the Fiery X3e to verify that TCP/IP communication is successful.

Setting up the Fiery X3e printer driver

You ﬁrst need to create a directory for Windows NT 4.0/2000/XP or a folder for Windows 98/Me in the NetWare server for NDPS to install the corresponding printer driver ﬁles from the User Software CD.

TO SET UP THE PRINTER DRIVER FOR WINDOWS NT 4.0/2000/SERVER 2003

1. Log on to the Novell ﬁle server as a superuser or Administrator.

2. Create a directory called Fiery in the following location: SYS:ndps\resdir\Prndrv\NT4 for Windows NT 4.0 SYS:ndps\resdir\Prndrv\2000 for Windows 2000 SYS:ndps\resdir\Prndrv\XP for Windows XP SYS:ndps\resdir\Prndrv\Server 2003 for Windows Server 2003

3. From the User Software CD, copy the contents of the following folder to the Fiery directory: ENGLISH\INSTALRS\PS_DRVR\WIN_NT for Windows NT 4.0 ENGLISH\INSTALRS\PS_DRVR\WIN_2000 for Windows 2000 ENGLISH\INSTALRS\PS_DRVR\WIN_XP for Windows XP and Windows Server 2003

Page 40

2-16 Setting up Network Servers

TO SET UP THE PRINTER DRIVER FOR WINDOWS 98/ME

1. Log on to the Novell ﬁle server as a superuser or Administrator.

2. In the SYS:ndps\resdir\Prndrv\Win98/Me directory, create a directory called Fiery.

3. From the User Software CD, copy the contents of the ENGLISH\INSTALRS\PS_DRVR\WIN_98/Me folder to the Fiery directory.

Setting up the Fiery X3e on a NetWare network

Depending on the security needs at your organization, you can set up the Fiery X3e as a Public Access printer or a Controlled Access printer. The following procedure describes setting up a Public Access printer. You can then convert the printer to Controlled Access if necessary. For more information, see your NetWare documentation.

TO SET UP THE FIERY X3E AS A PUBLIC ACCESS PRINTER

1. In NetWare Administrator, double-click the NDPS Manager object you created.

2. In the Details window for the NDPS Manager object, click Printer Agent List.

The list of Printer Agents appears.

3. Click New.

4. In the Printer Agent (PA) Name ﬁeld, enter a name.

Page 41

2-17 Fiery X3e on a network with UNIX workstations

5. Under Gateway Types, select Novell Printer Gateway, and click OK.

6. In the Conﬁgure Novell PDS for Printer Agent dialog box, select “((NONE))”,

7. In the Conﬁgure Port Handler dialog box, choose “Remote LPR on IP” as the

8. For Host Address, enter the IP address of the Fiery X3e.

9. For Printer Name, enter the name of the Fiery X3e print connection you want users to

10. In the Select Printer Drivers dialog box, select the printer driver for Windows 98/Me

11. Click Continue, and then click OK.

and click OK.

connection type, and click Next.

print to, and click Finish.

This name must be either print or hold.

and the driver for Windows NT 4.0/2000/XP.

Fiery X3e on a network with UNIX workstations

When a UNIX workstation is conﬁgured with the lpd protocol and connected to the Fiery X3e over a TCP/IP network, it can print directly to the Fiery X3e.

Setting up UNIX workstations requires an administrator with root privileges. After the initial conﬁguration, UNIX users simply submit print jobs to a named printer.

The job management tools, along with the other Fiery utilities and WebTools, are unavailable on the UNIX platform. A Windows or Mac OS computer on the same network as the UNIX computer that is set up to use TCP/IP for printing to the Fiery X3e can use the job management tools to manage print jobs that originate from all workstations on the network.

Page 42

2-18 Setting up Network Servers

•A distinct IP address is required for the Fiery X3e as well as for each workstation on

•A name must be selected for the Fiery X3e that goes with the IP address.

• The IP address of the Fiery X3e must be registered for the network in a host name

•At least one print connection (Print or Hold) must be published.

• The Fiery X3e is a printer controller that understands lpd protocols.

• The Fiery X3e has a remote printer name you must use in order to communicate with

Tips for experts—UNIX workstations

Setting up the Fiery X3e in a UNIX environment has the same requirements as setting up any printer or new device:

the network.

database, and also on the Fiery X3e itself.

The following information applies especially to the Fiery X3e:

it successfully.

For details, see the following section.

Important note about the remote printer name

Whichever UNIX system you use, the name used for the remote printer (or rp in the

/etc/printcap ﬁle) in conﬁguring the Fiery X3e must be one of the following:

print hold

The remote printer name is also used when setting up a Windows NT 4.0/2000/XP workstation or Windows NT 4.0/2000/Server 2003 server to connect to the Fiery X3e over TCP/IP. Enter the remote printer name when you set up your Windows NT 4.0/ 2000/Server 2003 printer, as the “Name of printer or print queue on that (lpd host) server” in the Add LPR Compatible Printer dialog box.

For the Windows 2000/XP printer driver, enter the remote printer name for Queue Name under LPR Settings in the Conﬁgure Standard TCP/IP Port Monitor dialog box.

Page 43

2-19 Fiery X3e on a network with UNIX workstations

Setting up the Fiery X3e on TCP/IP networks

Every machine (host) on a TCP/IP network, including the Fiery X3e, must have a unique 32-bit internet address (IP address). Contact your network administrator to obtain an address for the Fiery X3e. Workstations on a TCP/IP network can print directly to the Fiery X3e as a remote printer, or can print to a Windows NT 4.0/ 2000/Server 2003 server or UNIX workstation acting as a print server. Since the Fiery X3e spools jobs and acts as a print server, there is no advantage in placing another print server between a workstation and the Fiery X3e. If you choose to do so, however, there is no difference in setup except that a client machine does not have its own spooling area.

TO SET UP FIERY X3E PRINTING ON UNIX SYSTEMS

1. Specify the appropriate settings in Fiery X3e Network Setup.

Enter a valid IP address, subnet mask, and gateway address for the Fiery X3e.

2. Specify the appropriate settings in Fiery X3e Printer Setup.

Publish the Print queue, Hold queue, and/or Direct queue.

TO SET UP TCP/IP FOR COMMUNICATION WITH THE FIERY X3E

1. A superuser (with root login) must add the Fiery X3e to the network’s IP host table or other system database of network printers.

2. In the ﬁle or utility used by your network, specify the remote printer name, the print server protocol, the queue, and the spool ﬁle for the Fiery X3e name you assigned.

3. Make the Fiery X3e available as a printer to other network users.

4. To verify the TCP/IP connection, ping the IP address or the host name. From any Windows computer on the network, at the MS-DOS command prompt, type:

ping <IP address>

Type the Fiery X3e IP address assigned in Fiery X3e Network Setup.

After the Fiery X3e is set up as a network printer, you can also ping the name you gave to the Fiery X3e:

ping <hostname>

Page 44

2-20 Setting up Network Servers

The server should respond with a message such as

Reply from <IP address> ...

Some systems will respond with a continuous display of output from the IP address. To stop the output, type Control-C. You can use the ping command at any time.

TO PRINT TO THE FIERY X3E

• On a UNIX system running SunOS 4.x or other BSD-based variant, use the lpr command to send a job to the Fiery X3e.

• On a UNIX system running Solaris 2.x or any System V implementation of UNIX, use the lp command to send a job to the Fiery X3e.

• Windows NT 4.0/2000/XP users with the TCP/IP protocol loaded can send print jobs to the Fiery X3e from their applications or from a command prompt.

When Windows NT 4.0/2000/XP users print from applications, they can set print options with the driver but not from the UNIX command line.

Managing print jobs

UNIX network administrators can use UNIX utilities for viewing the list of jobs, and for printing and removing jobs that are spooled on UNIX servers. If the network includes a Windows NT 4.0/2000/XP workstation that has TCP/IP protocols loaded, you can use Command WorkStation or Fiery Downloader not only to view the list of jobs and to print and remove jobs but also to download fonts and ﬁles directly to the Fiery X3e. For more information on these job management tools, see the Job

Management Guide.

Even without the Fiery utilities, you can do the following:

•Set up the Fiery X3e to print a log of printed jobs automatically after every 55 jobs.

•Print a Job Log manually at any time from the Command WorkStation

Functions menu (see the Job Management Guide).

Page 45

3-1 Levels of access and control

Chapter 3: Preparing for Fiery X3e Setup

To prepare for printing at your site, you must do some initial Fiery X3e conﬁguration, or Setup, to specify the network environment and the kind of printing you will do. Before you perform Setup, you must decide the levels of access you will implement for your site. Administrators and operators must also understand how Fiery X3e system software is structured in order to conﬁgure and use the Fiery X3e system correctly.

Levels of access and control

When you conﬁgure the Fiery X3e during Setup, you (as system administrator) implement a particular level of control by enabling or not enabling print connections, passwords, and access to WebTools. The level of control you implement can range from minimum to moderate to maximum—or none at all.

•Minimum control might be appropriate for a small site where anyone on the local

network can control all printing and Fiery X3e functions. Although there may be an administrator or operator charged with certain duties, all users have equal access to the system and job management tools.

•Maximum control might be appropriate for a high-volume printing environment

where an administrator or operator controls the job ﬂow and all printing; jobs sent by users are spooled (stored) to the Fiery X3e hard disk until the operator decides it is time to print them. In addition, only the administrator and operator have access to job management tools. This is the recommended level of control.

NOTE: The term “job management tools” is used in this manual to refer to

Command WorkStation and Command WorkStation LE.

Fiery X3e print connections

The Fiery X3e supports three print connections: Hold queue, Print queue, and Direct connection. These print connections can be enabled, or “published,” to users on the network when you conﬁgure Printer Setup. All published connections are constantly checked for the presence of jobs. The Print queue and Direct connection give remote users more direct access to the Fiery X3e than the Hold queue. Therefore, do not publish the Print queue and the Direct connection in environments where maximum control is desired.

Page 46

3-2 Preparing for Fiery X3e Setup

In addition, you can enable the Printed queue, which is a storage area for the most recent jobs from the Print queue. The Printed queue makes it convenient to reprint those jobs. In Setup, you can enable the Printed queue and specify the maximum number of jobs retained in the queue (see page 4-7). Reprinting jobs in the Printed queue requires the job management tools.

NOTE: To use the Fiery utilities and Fiery WebTools, you must enable at least one of the

print connections.

Hold queue

Jobs sent to the Hold queue are spooled to the Fiery X3e hard disk for printing at a later time or for reprinting. Because the Hold queue is a storage place, jobs sent to it cannot proceed through the printing process until the operator intervenes using the job management tools (see the Job Management Guide).

Print queue

This is the standard Fiery X3e queue. Jobs sent to the Print queue are processed and printed in the order they are received. Jobs prioritized by an operator with the job management tools and jobs sent via the Direct connection can take priority over jobs sent to the Print queue.

Direct connection

The Direct connection transmits jobs directly to the Fiery X3e, but only when the Fiery X3e is Idle. If the Fiery X3e is busy, the job remains at the user workstation until the Fiery X3e is ready. The job is then processed as soon as the previous job is ﬁnished and before the next queued job is processed.

NOTE: The Direct connection is not supported for LPR printing.

Jobs sent to the Direct connection are not stored on the Fiery X3e hard disk, and cannot be selected for reprinting, moving, or deletion. Therefore, the Direct connection provides a measure of security for sensitive ﬁles. Jobs sent to the Direct connection do appear in the Job Log, for accounting purposes.

NOTE: To download fonts to the Fiery X3e, you must publish the Direct connection.

Page 47

3-3 Levels of access and control

Passwords

You can implement passwords as a means of controlling access to Fiery X3e functions. The Fiery X3e allows you to set the following passwords in Setup:

•Administrator—remotely from Command WorkStation, or locally from the Control

Panel

•Operator—from Command WorkStation or Fiery WebSetup

NOTE: By default, no passwords are set on the Fiery X3e. If you do not speciﬁcally

set passwords, all users will have administrator privileges, which include access to important functions such as Setup (including setting passwords), and job control. We strongly recommend that you set at least an Administrator password to protect the Fiery X3e from random or accidental changes to Setup.

Administrator privileges

Administrator control, which confers control of Setup, is the highest level of control, since the person who has access to Setup can control the printing and job management environment. Administrator privileges include publishing print connections, setting passwords, deleting fonts, controlling print jobs from the job management tools, overriding job settings, clearing the Fiery X3e of all job data, performing calibration, deﬁning default color proﬁles, and setting default values for print options.

When performing a function from the Fiery X3e Control Panel that prompts you for the Administrator password, you must enter it promptly. Otherwise, the Fiery X3e Control Panel returns to Idle, and you must start over again.

Operator privileges

Operator control includes control of print jobs from the job management tools, including the ability to override job settings.

Guest privileges (no password)

No password is needed for a user to log in as a Guest from the job management tools. A Guest can view the status of active jobs but cannot make changes to jobs or to the Fiery X3e state.

Page 48

3-4 Preparing for Fiery X3e Setup

WebTools

The Fiery X3e supports Internet or intranet access with WebTools from Windows and Mac OS computers. To enable the use of WebTools, you must do the following in Setup:

•Enable TCP/IP.

•Set an IP address, subnet mask, and gateway address for the Fiery X3e.

•Enable Web Services.

For more information, see Chapter 6.

You can set passwords to control access to WebTools features. If you do not speciﬁcally set these passwords, all users have access to all WebTools functions (see page 3-3). WebTools include Status, WebLink, WebScan, WebDownloader, WebSetup, and Installer.

Status

The Status WebTool provides you with current information on the jobs processing and printing on the Fiery X3e. It is not affected by passwords. For more information, see the Printing Guide.

WebLink

WebLink provides all users with a link to an address on the Internet. To change the WebLink Internet address, see page 6-3. This function requires the Administrator password, if one has been set (see “Passwords” on page 3-3).

NOTE: If you do not set the Administrator password, any user can change the WebLink

address, which affects all users. For this reason, we strongly recommend that you set an Administrator password.

Page 49

3-5 Levels of access and control

WebScan

With WebScan, you can retrieve scanned documents from a computer on the Internet or your organization’s intranet. It is not affected by passwords. For more information, see the Printing Guide.

WebDownloader

WebDownloader allows you to print PostScript, EPS, PDF, and TIFF ﬁles directly to the Fiery X3e without ﬁrst opening the ﬁle in an application. It is not affected by passwords.

WebSetup

WebSetup allows you to view and modify Fiery X3e Setup options from a remote workstation. This function requires an Administrator password. For more information, see Chapter 5.

NOTE: WebSetup is supported on Windows computers only.

Installer

The Installer WebTool allows users to download installers for printer drivers directly from the Fiery X3e. It is not affected by passwords. For more information, see the

User Software Installation Guide.

Page 50

3-6 Preparing for Fiery X3e Setup

1. No designated administrator or operator (Minimum control—not recommended)

2. An administrator but no operator

Control level scenarios

Typical scenarios of access and control, ranging from minimum control to maximum control, are described in this section. Choose the scenario that best matches your site requirements, and refer to the corresponding number in the following table for guidance on how to conﬁgure your system for those requirements.

NOTE: We strongly recommend that you set at least an Administrator password to

prevent unauthorized changes to system settings.

All users have equal access to all system functions including Setup, clearing the Fiery X3e, deleting printer fonts, setting the WebLink address, performing calibration, printing to all Fiery X3e print connections, and managing all jobs from the job management tools.

Only an administrator can perform Setup, calibration, and other administrator functions, but all other system functions are accessible to all users, including printing to all Fiery X3e print connections, and managing all jobs from the job management tools.

3. An administrator and an operator

4. An administrator and an operator; no WebTool access

Only an administrator can perform Setup, calibration, and other administrator functions, and only an operator or administrator can control jobs from the job management tools. Users can print to the Hold queue and Print queue, but not to the Direct connection. The operator controls all job ﬂow, but jobs sent to the Print queue may not require operator intervention. There is no access to WebTools.

Page 51

3-7 About Setup

5. An administrator and an operator; operator controls all jobs; no WebTool access (Maximum control)

Only an administrator can perform Setup, calibration, and other administrator functions, and only an operator or administrator can control jobs from the job management tools. Users can print only to the Hold queue. The administrator and the operator have complete control of job ﬂow. There is no access to WebTools.

Use these settings

in Setup

Enable Direct connection √ √ √

Enable Print queue √ √ √ √

Enable Web Services √ √ √

Set an Administrator Password (strongly recommended )

Set an Operator password √ √ √

(Minimum)

234 5

(Maximum)

√ √ √ √

About Setup

Setup conﬁgures the Fiery X3e to communicate with other devices and manage print jobs. You must perform Setup the ﬁrst time you turn on the Fiery X3e after new system software is loaded, or any time Server software is reinstalled. An initial Setup using default settings is adequate for allowing users to print to the Fiery X3e and use the WebTools. When your network or user printing environment changes, you can change Setup options accordingly.

Page 52

3-8 Preparing for Fiery X3e Setup

The ﬁrst time you perform Setup, you must use the Fiery X3e Control Panel. Conﬁgure, at a minimum, Server Setup, Network Setup, and Printer Setup, in that sequence. After the initial Setup, you can change Setup options from the Control Panel (page 4-3) or Command WorkStation. Most Setup options can be set using any of these methods.

If you do not conﬁgure the remaining Setups, the Fiery X3e uses default settings. You need to make settings appropriate for the printing environment at your site.

Network server setup requirements

For Novell and Windows NT 4.0/2000/Server 2003 (using TCP/IP) networks, you must conﬁgure the network servers for printing to the Fiery X3e before you conﬁgure Fiery X3e network settings in Setup. For chapter references to information about network server Setup, see the diagrams in Chapter 1.

To conﬁgure network settings in Setup, you must have a live network connection, so the Fiery X3e can query the network for zones, servers, and server-based queues.

Whenever the conﬁguration of the Fiery X3e, the copier, or the network itself changes at your site, you can alter individual settings to correspond to the changed environment. Changing network or port settings may require that you also make changes to other Setup options.

NOTE: You must configure the Fiery X3e with the correct Windows

Windows NT 4.0/2000/Server 2003 domain name. This is especially important for Windows printing, also known as SMB printing.

NOTE: The Fiery X3e does not support the Windows 2000/Server 2003 Active

Directory Service. When you use the Fiery X3e in a Windows 2000/Server 2003 server environment, assign the Fiery X3e to a Domain or Workgroup.

Page 53

3-9 About Setup

Ensuring the copier connection

Complete the following steps before you conﬁgure the Fiery X3e and the workstations that will print to the Fiery X3e. A service technician will have performed some initial installation.

TO PREPARE FOR FIERY X3E CONFIGURATION

1. Print a copier Test Page to verify the copier is functioning normally.

2. With both the Fiery X3e and the copier turned off, connect the network cable to the Fiery X3e, as described in Chapter 1.

The network should already be installed and operational.

3. Turn on the copier and then the Fiery X3e.

Proceed to Fiery X3e Setup, described in Chapter 4.

Page 54

Page 55

4-1 Fiery X3e Setup from the Control Panel

Chapter 4: Performing Setup from the Control Panel

Setup is required the ﬁrst time the Fiery X3e is turned on after new system software is loaded. In this initial Setup, you (or the service technician who loads the software) choose the language for Fiery X3e Control Panel menus and messages. If you do not conﬁgure a particular Setup option, the Fiery X3e uses default settings. Make sure the settings are appropriate for the printing environment at your site.

Fiery X3e Setup from the Control Panel

Setup performed from the Control Panel conﬁgures the Fiery X3e to communicate with other devices and manage print jobs sent to it.

Setup provides these groups of options:

•Server Setup to specify system options

•Network Setup to specify all the active network systems that transmit print jobs to

the Fiery X3e

•Printer Setup to specify how print jobs and queues are managed

• PS Setup to specify PostScript settings

• PCL Setup to specify PCL settings

• Color Setup to specify color settings

•Job Log Setup to specify how the Fiery X3e handles its log of printed jobs

•Enable Options to activate additonal optional features

The Change Password option in the Setup menu allows you to create and change the Administrator password on the Fiery X3e.

Page 56

Touch Panel

4-2 Performing Setup from the Control Panel

The Control Panel on the front of the copier allows you to set options and view information about jobs printed to the Fiery X3e. It consists of the following parts:

•Touch Panel—shows status information and options for setting up the Fiery X3e

•Up and down arrow buttons—scroll menus, options, and settings

Fiery X3e copier Control Panel

Page 57

4-3 Fiery X3e copier Control Panel

Fiery X3e copier Control Panel

Use the Fiery X3e copier Control Panel supported at your site to view status information, print special pages, and set up printing. While most elements in the Control Panel display have counterparts in Command WorkStation, you can view current functions on the Control Panel even when Command WorkStation is not connected to the server or is not running.

Safety warnings

The Fiery X3e display window is a liquid crystal display (LCD) made of glass, and it can break. Do not subject it to strong shocks.

If the display window breaks and the liquid crystal material leaks out, do not inhale, ingest, or touch it. If the material gets on your skin or clothing, wash it off with soap and water immediately.

Do not touch or put pressure on the display window. This will change the color of the window.

Page 58

4-4 Performing Setup from the Control Panel

Accessing Setup options

TO ACCESS SETUP WHEN THE FIERY X3E IS IDLE

1. Make sure the copier is Idle.

If Printing or RIPping appears, the Fiery X3e is processing, and you must wait until the system ﬁnishes and reaches the Idle state.

2. Press the Print button on the copier Control Panel.

3. In the Touch Panel, press Menu/Esc.

4. Use the down arrow button to scroll to Run Setup.

At the main Setup window, press the button for the Setup you want to access.

For ﬁrst-time Setup, you must perform at least these Setups in this order: Server Setup, Network Setup, and Printer Setup. After performing these Setups, you can continue with the remaining Setups, or exit Setup and save your changes.

About the Control Panel Setup interface

When you perform Setup from the Control Panel, you select one menu after another and enter information about your Fiery X3e and your network and printing environment.

In each Setup screen, the last line of the display window shows the name of the current Setup menu.

Page 59

4-5 Server Setup options

Types of Setup screens

There are two types of Setup options:

Multiple choice questions

Information entry options

You are given choices (for example, Yes or No, or a list of options from which to choose). Only one choice is displayed at a time. The currently selected (or default) value appears ﬁrst.

Use the up and down arrow buttons to scroll through the choices, and choose OK when the correct information is displayed.

You must specify the information for your site (the copier name or IP address). Press the Key Pad button and use the copier’s 10-Key pad to enter numbers. Use the available character keys in the Touch Panel to specify numbers. When you are done, press Enter.

Press the Key Pad button in the Touch Panel to enter text. When you are done, press Enter.

When you have entered the settings, you must save the changes. You are usually prompted to do so. If you choose Yes, your settings overwrite previous settings. If you choose No, your previous settings are retained. If necessary, the Fiery X3e restarts after you exit from the Setup menu.

Server Setup options

The Server Setup menu lets you specify system information that pertains to the Fiery X3e and all users. To access the menu, follow the instructions on page 4-4.

When you choose Server Setup, the options appear in sequence, as follows. Default values, where applicable, appear in square brackets. Words shown in italics indicate that a product- or site-specific value is displayed.

Page 60

4-6 Performing Setup from the Control Panel

Server Name

Default server name

Enter a name for the Fiery X3e (up to 15 characters long). This name appears in the Chooser on an AppleTalk network.

System Date

Enter the correct system date in the standard form for your use. The date appears on the Job Log.

System Time

Enter the correct system time. Enter the time based on the 24-hour clock in the form

HH:MM (Hours:Minutes). The time appears on the Job Log.

Time Zone

Specify the correct time zone. Select from a list of major cities and standard time zones.

Print Start Page Yes/No [No]

Specify whether the Fiery X3e should print a start page every time it restarts. The start page displays information about the Fiery X3e, including the server name, current date and time, amount of memory installed in the Fiery X3e, network protocols enabled, and connections published.

Use Character Set Macintosh/DOS/Windows [Macintosh]

Specify whether the Control Panel and Command WorkStation should use the Macintosh, DOS, or Windows character set for displaying ﬁle names. This is important if ﬁle names include accented or composite characters (such as é or æ).

For mixed-platform networks, choose the option that gives the best overall representation of the special characters you use.

Enable Printing Groups Yes/No [No]

Specify whether to enable printer groups for Member Printing. If you enable this option, you must use Command WorkStation to deﬁne user groups and passwords. Users must then enter their group name and password when they print.

Page 61

4-7 Server Setup options

Enable Printed Queue Yes/No [Yes]

Specify whether to enable the Printed queue, which creates a storage location on the Fiery X3e disk for recent jobs that were printed from the Print queue. Users with Administrator or Operator access to the job management tools can reprint jobs from the Printed queue without resending them to the Fiery X3e. If you select No, jobs are deleted from the Fiery X3e disk immediately after they are printed.

Jobs Saved in Printed Queue 1-99 [10]

This option appears only if Enable Printed Queue is set to Yes. Specify the number of jobs to be stored in the Printed queue. Jobs in the Printed queue take up space on the Fiery X3e hard disk. If disk space is low, use a smaller value for saved jobs.

Clear Each Scan Job After 1 day/Manually/After 1 week [After 1 day]

Specify how you want to remove scanned data from the hard disk. If you select Manually, the scanned data remains on the hard disk until speciﬁcally deleted, or until all scanned jobs are cleared by the Administrator.

Clear Each Scan Job Now Yes/ No [No]

Specify when you want to immediately clear the scan jobs from the hard disk.

Preview While Processing Yes/ No [No]

Specify whether a preview thumbnail should be displayed in the Command WorkStation when a job is being processed. If you select Yes, the preview thumbnail is always displayed in the Processing section of the Activity Monitor.

Save Changes Yes/No [Yes]

Select Yes to activate any changes made in the Server Setup; select No to return to the main Setup menu without making any changes.

Page 62

4-8 Performing Setup from the Control Panel

Network Setup options

When you perform Network Setup, you conﬁgure the Fiery X3e to receive print jobs over the network systems that are used at your site.

In the Setup menu, choose Network Setup, where you specify network addresses and names to be used by workstations, servers, and the Fiery X3e when they communicate with each other.

The Network Setup menu includes three submenus that allow you to choose port types, protocols, and network services. You must perform Port Setup and enable at least one port.

For each item you enable, you are prompted to enter settings for that item. Default values, where applicable, appear in this manual with square brackets.

You should display and select options only for the network systems that are currently used at your site. If your network requirements change, you can change Network Setup at any time.

If the Fiery X3e is configured to enable more than one protocol, it automatically switches to the correct protocol when it receives a print job. When the parallel port and one or two network ports are enabled, print jobs can be received over all of those ports at the same time.

Page 63

4-9 Network Setup options

The available network types, and the Setup areas that pertain to them, are summarized in the following table.

For this Network or

Connection Type

AppleTalk over Ethernet Ethernet Setup AppleTalk Setup AppleTalk printing (PAP) is

TCP/IP over Ethernet Ethernet Setup TCP/IP Setup: Ethernet Setup LPD Setup

IPX/SPX over Ethernet Ethernet Setup IPX/SPX Setup PServer Setup (NDS, Bindery,

Parallel Parallel Port Setup

TO ACCESS NETWORK SETUP OPTIONS

1. Conﬁrm that the network cable is connected to the Fiery X3e.

2. Choose Network Setup from the main Setup menu.

Use this

Port Setup

During Network Setup, the Fiery X3e queries the network for zones, servers, and server-based queues. If you perform Network Setup without a connected and functioning network, default settings are used that may not meet your needs.

Use this Protocol Setup Use this Service Setup

enabled automatically.

Web Services Setup Windows Setup Port 9100 Setup IPP Setup

or both)

—

3. Choose Port Setup from the Network Setup menu.

4. To use Ethernet, choose Ethernet Setup from the Port Setup menu, and enter the appropriate settings.

5. To print to the parallel port, choose Parallel Port Setup from the Port Setup menu, and enter the appropriate settings.

6. When you have ﬁnished entering port settings, choose Exit Port Setup, and then choose Protocol Setup.

7. Enter the appropriate settings for the protocol or protocols you will use.

Page 64

Network Setup

Port Setup

4-10 Performing Setup from the Control Panel

8. When you have ﬁnished entering protocol settings, choose Exit Protocol Setup, and then choose Service Setup.

9. Enter the appropriate settings for the services you will use.

The options are described in detail in the following pages.

TO EXIT NETWORK SETUP

1. When you have ﬁnished entering service settings, choose Exit Network Setup.

2. Choose Yes when prompted to save changes.

3. From the main Setup menu, choose another Setup or choose Exit Setup.

Port Setup options

You can enable Ethernet and parallel communication simultaneously. To conﬁgure the Fiery X3e, choose each port type you use and enter the settings for that port. Since network setups are nested, the names of higher-level menus are shown in this chapter to the left of each menu heading.

Ethernet Setup

Enable Ethernet Yes/No [Yes]

Select Yes if you have Ethernet cabling connected to the Fiery X3e.

Ethernet Speed Auto Detect/100 Mbps/10 Mbps [Auto Detect]

Select Auto Detect if your network environment is mixed or if you do not know the network speed. If you know the speed of the network to which the Fiery X3e is attached (10 Mbps or 100 Mbps), select it.

Page 65

Network Setup

Port Setup

4-11 Network Setup options

Parallel Port Setup options

You must enable the parallel port in order to enter the Parallel Port Setup options and print to the parallel port.

Parallel Port Setup

Enable Parallel Port Yes/No [No]

Select Yes if you want to print through the parallel port. You can connect a single Windows computer to the parallel port and print directly to the Fiery X3e.

Port Timeout in Seconds 5–60 [5]

This option appears only if Enable Parallel Port is set to Yes. Your setting determines how long (in seconds) the Fiery X3e waits without receiving data from the parallel port before deciding that the current job is complete. Until the timeout, the Fiery X3e cannot receive new jobs through the parallel port, but it can continue to receive network print jobs.

Ignore EOF Character Yes/No [Yes]

This option appears only if Enable Parallel Port is set to Yes. This option speciﬁes that the Fiery X3e should ignore end-of-ﬁle (EOF) messages in a ﬁle. This option must be set to Yes to print PostScript ﬁles in binary format (not ASCII); under normal circumstances, it should be set to No. When this option is set to Yes, the Fiery X3e uses the parallel port timeout value to determine when the end of the ﬁle has been reached. If you experience printing problems, set this option to No.

Page 66

Network Setup

Protocol Setup

4-12 Performing Setup from the Control Panel

Protocol Setup options

To conﬁgure the Fiery X3e, choose each protocol and enter the settings for that protocol. You can enable AppleTalk, TCP/IP, and IPX/SPX communication simultaneously.

AppleTalk Setup

Enable AppleTalk Yes/No [Yes]

Select Yes if you have an AppleTalk network connected to the Fiery X3e. This setting enables the Fiery X3e to communicate over AppleTalk networks.

AppleTalk Zone

List of zones

The Fiery X3e searches the network for AppleTalk zones in your network segment. Scroll through the list to select the AppleTalk zone in which you want the Fiery X3e to appear. If your segment has only one zone, the Fiery X3e is assigned to that zone automatically.

The message “No AppleTalk zone found” may mean your network has no zones, or the network cable is not connected (see Appendix A). Choose OK to dismiss the message.

TCP/IP Setup options

To conﬁgure the Fiery X3e for TCP/IP, choose TCP/IP Setup.

Choose Ethernet Setup and enter the appropriate settings. Choose each network type you use (Ethernet) and enter the appropriate settings.

When you set an IP address, subnet mask, or gateway address for the Fiery X3e during Setup, you can allow the Fiery X3e to get these addresses automatically from a DHCP or BOOTP server. First, turn on or restart the Fiery X3e and allow it to reach Idle. Make sure the DHCP or BOOTP server is running, and then perform Fiery X3e Setup.

Page 67

Network Setup

Protocol Setup

TCP/IP Setup

4-13 Network Setup options

TCP/IP Setup with Ethernet

Ethernet Setup

Enable TCP/IP for Ethernet Yes/No [Yes]

Select Yes if you have a TCP/IP network connected to the Fiery X3e over Ethernet cabling.

NOTE: If you are using TCP/IP for printing from Windows computers, enabling

TCP/IP here also enables you to use Fiery utilities from Windows computers using TCP/IP protocols.

Enable Auto IP Configuration Yes/No [Yes]

Select Yes to allow the Fiery X3e to obtain its Ethernet IP address by searching the network. Depending on your network and the protocol you select in the following option (DHCP or BOOTP), the IP address can change. Select No to assign the Fiery X3e a static IP address. If you select No, you proceed to the IP Address option, where you manually set the IP address.

Select protocol DHCP/BOOTP [DHCP]

This option appears only if you answered Yes to Enable Auto IP Conﬁguration. Select the protocol over which the Fiery X3e should search for its IP address. Both DHCP and BOOTP allow the Fiery X3e to obtain the Ethernet IP address and Subnet Mask automatically.

Depending on your network, the Fiery X3e might be assigned a different address after you restart the Fiery X3e. With the DHCP setting, the Fiery X3e can be assigned a different address even if it is not restarted. Make sure the network is already conﬁgured properly for the protocol you select.

Get Gateway Address Automatically Yes/No [Yes]

Use this option to assign the gateway address automatically for printing with TCP/IP.

Page 68

4-14 Performing Setup from the Control Panel

IP Address [127.0.0.1]

Enter the Fiery X3e IP address for Ethernet. This IP address, unlike an IP address set automatically, remains the same if you restart the Fiery X3e. You must change the default to a valid address for your network. For information about setting up printing with TCP/IP, see Chapter 2.

Subnet Mask

This option lets you modify the subnet mask for printing with TCP/IP over Ethernet. To set the subnet mask, enter one of the following values:

• 255.0.0.0 if the IP address starts with a number less than 128

• 255.255.0.0 if the IP address starts with a number from 128 through 191

• 255.255.255.0 if the IP address starts with a number greater than 191

NOTE: Conﬁrm the subnet mask setting with your network administrator before

proceeding. In some cases, the required setting may be different from that listed.

Gateway Address [127.0.0.1]

This option appears only if you answered No to Get Gateway Address Automatically.

Use this option to set the gateway address for printing with TCP/IP. If your network uses a gateway, you must change the default to a correct gateway address for your network.

Page 69

Network Setup

Protocol Setup

DNS Setup

4-15 Network Setup options

DNS Setup

Enable DNS Yes/No [No]

Select Yes to allow the Fiery X3e to resolve a name to an IP address.

Get DNS Automatically Yes/No [No]

Select Yes to allow the Fiery X3e to resolve a name to an IP address automatically.

Primary DNS Server IP Address

255.255.255.255

This option only appears if you have selected No to Get DNS Automatically. Specify the IP address of the primary DNS server. Repeat this for the Secondary DNS Server.

Domain Name

Enter the DNS domain name.

Host Name

Enter the DNS host name of the Fiery X3e.

Page 70

Network Setup

Protocol Setup

Security Setup

4-16 Performing Setup from the Control Panel

Security Setup options

Use the IP Filtering and IP Port Setup options for Security Setup.

Using IP Filtering options, you can set controlled access to the Fiery X3e by specifying IP address(es) that the Fiery X3e permits or rejects receiving. This prevents unlimited access to the Fiery X3e over your network and ensures network security in your environment.

Using IP Port Setup options, you can close unnecessary ports and help reject inbound access from the network.

IP Filtering

By default, the Fiery X3e permits all IP addresses. To control access, you can set an IP address or a range of IP addresses.

Enable IP Filtering Yes/No [No]

Select Yes to allow the Fiery X3e to enable IP ﬁltering. Proceed to the subsequent IP ﬁltering settings.

Default Policy Accept/Deny [Accept]

If you selected Yes to enable IP ﬁltering, this option appears.

Select Accept to accept IP addresses other than the IP addresses you specify at this setup. Select Deny to reject IP addresses other than the IP addresses you specify at this setup.

If you selected Yes to enable IP filtering, the following three options appear. Add, delete, and edit filters as required. To add filters, enter the IP address, IP range, and accept the filter policy.

Page 71

4-17 Network Setup options

Add Filter

IP Filter Type IP Address/IP Range [IP Address]

Select IP Address to permit or reject individual IP addresses. Select IP Range to specify a range of IP addresses to be permitted or rejected. Up to 16 IP addresses can be speciﬁed.

NOTE: Do not enter “0.0.0.0” or “255.255.255.255”.

Delete Filter Yes/No [No]

This option allows you to delete IP addresses individually or by range.

Edit Filter Yes/No [No]

This option allows you to make changes to IP addresses or a range of IP addresses to be permitted or rejected.

IP Port Setup

All ports not listed in the following setup options are closed. Supported protocols are listed in parenthesis after the port number.

Configure IP Ports Yes/No [Yes]

Select Yes to proceed to the subsequent IP Port settings.

80 (HTTP) Enabled/Disabled [Enabled]

Select Enabled to enable the 80 (HTTP) port. (Fiery WebTools and IPP printing)

137-139 (NetBIOS) Enabled/Disabled [Enabled]

Select Enabled to enable the 137-139 (NetBIOS) ports. (SMB printing)

161-162 (SNMP) Enabled/Disabled [Enabled]

Select Enabled to enable the 161-162 (snmp) ports. (Command WorkStation)

Page 72

4-18 Performing Setup from the Control Panel

515 (LPD/Fiery Tools) Enabled/Disabled [Enabled]

Select Enabled to enable the 515 (lpd) port. (Fiery WebTools and LPD printing)

631 (IPP) Enabled/Disabled [Enabled]

Select Enabled to enable the 631 (IPP) port. (IPP printing)

9100-9103 (Port 9100) Enabled/Disabled [Enabled]

Select Enabled to enable the 9100-9103 (Port 9100) ports. (Port 9100 printing)

EFI Ports Enabled/Disabled [Enabled]

Select Enabled to enable EFI ports 8021-8022. (Fiery utilities and printer driver Two-Way Communication feature)

IPX/SPX Setup options

To specify the frame types the Fiery X3e uses for IPX/SPX protocols, choose IPX/SPX Setup from the Protocol Setup menu. You must choose at least one frame type to enable IPX/SPX protocols. The Fiery X3e supports the following frame types for IPX/SPX:

•For Ethernet—Ethernet 802.2, Ethernet 802.3, Ethernet II, and Ethernet SNAP

For protocols other than IPX/SPX, the frame type is automatically enabled and does not require setup, as follows:

With this protocol And these printing services

AppleTalk PAP (Printer Access Protocol) Ethernet SNAP

TCP/IP with Ethernet LPD (Line Printer Daemon) Ethernet II

This frame type is

automatically enabled

Page 73

4-19 Network Setup options

Select Frame Types

Enable IPX Auto Frame Type Yes/No [No]

Specify whether the Fiery X3e should try to bind to all available frame types automatically. The Fiery X3e does so whether or not all frame types are appropriate. To determine the frame types that were successfully bound, save your changes, exit Setup, restart the Fiery X3e, and print a Conﬁguration page. The Conﬁguration page lists only one of the frame types that were successfully bound.

If you answer No to this option, you can select frame types manually. You must choose at least one frame type to enable IPX/SPX protocols.

The frame selection screen allows you to make multiple selections. Depending on your Port Setup selection, only Ethernet frame types or all frame types are displayed.

Press OK for each frame type used on your IPX/SPX network. An asterisk (*) appears beside each selected frame type. Press the line selection button again to cancel a selected frame type. Use the up and down arrow buttons to scroll to additional frame types. The Fiery X3e binds to each frame type as you select it.

When you have selected all the frame types used, choose Exit IPX/SPX Setup.

Clear Frame Types

You can clear all frame types at once by choosing Exit IPX/SPX Setup, choosing IPX/SPX Setup, and then choosing Clear Frame Types.

Page 74

Network Setup

Service Setup

LPD Setup

4-20 Performing Setup from the Control Panel

Service Setup options

PServer is a program in the Fiery X3e software that services the Novell print queues assigned to the Novell print servers set up for printing to the Fiery X3e. When you choose PServer Setup and enable PServer, you can set up NDS (Novell Directory Services), Bindery Services, or both.

LPD Setup options

Enable LPD Yes/No [Yes]

Select Yes to allow lpd printing. For more information, see “Setting up the

Fiery X3e on TCP/IP networks” on page 2-19.

PServer Setup options

Network Setup

Service Setup

PServer Setup

Enable PServer Yes/No [No]

Select Yes if you have a Novell network connected to the Fiery X3e.

Choose NDS Setup if your network uses NetWare in native mode. Choose Bindery Setup if your network uses NetWare in bindery emulation mode.

If your network uses both NDS and Bindery, set up NDS ﬁrst. If you set up NDS after Bindery, you will overwrite Bindery Setup.

If your network uses both NDS and Bindery, and uses NetWare servers in bindery emulation, note that the Fiery X3e cannot service NDS and bindery emulation servers on the same NDS tree.

Page 75

Network Setup

Service Setup

PServer Setup

4-21 Network Setup options

NDS Setup

Before entering NDS settings, make sure the Fiery X3e is connected to the network and that you have conﬁgured an NDS directory tree with a Printer, Print Server, and one or more Print Queue objects for Fiery X3e jobs (see page 2-13). To perform NDS Setup, you may need permission to browse the NDS tree. If access to the Print Server is restricted, you need a login password.

The main objective of NDS Setup is to specify the Print Server object. In addition, you can indicate the location of the Fiery X3e print queues.

NOTE: The terms NetWare server, Novell server, and IPX server are in common use

and are used here interchangeably to mean the server on an IPX network running Novell NetWare networking software.

Enable NDS Yes/No [No]

Select Yes if the NetWare servers you will use to print to the Fiery X3e are running NetWare in native mode.

Select NDS Tree

List of trees

Use the up and down arrow buttons to browse the list of NDS trees available to the Fiery X3e. Choose OK when you have displayed the tree that contains the Printer, Print Server, and Print Queue objects you previously deﬁned for the Fiery X3e.

Your new NDS tree selection automatically overwrites any previous tree selection. If you change the NDS tree selection and there are also current Bindery settings, you are alerted that they will be deleted. If you continue with NDS Setup, you can replace Bindery settings later. If you do not want to continue, press the Menu button to exit NDS Setup.

Page 76

4-22 Performing Setup from the Control Panel

Is user login needed to browse NDS tree? Yes/No [No]

Select No if no password is required to browse the tree. You can proceed to navigate to the Print Server object.

Select Yes if network permissions require that you log in to browse the NDS tree and see the Print Server object you want to select. If you select Yes, you are prompted to navigate to the User Login object.

Navigate the NDS tree to User Login object.

This message is displayed if you selected Yes for the previous option. Choose OK and browse the NDS tree, as described in the following paragraphs.

NDS Tree name Object list, “..”

Browsing to ﬁnd the User Login object begins with the NDS tree that you selected previously (with Select NDS Tree). Use the up and down arrow buttons to scroll through a list of objects in the tree beneath the [Root] in the hierarchy, or use the navigation symbol “..” to go up one level at a time.

In each subsequent browse screen, the top line represents your current location. The second line contains:

•A list of objects in the current container directly below your current location

• The symbol “..” to go up one level

With an object selected, choose OK to travel down the tree, or choose “..” to go up the tree. When you select an object and choose OK, that object is displayed on the top line, and the second line lists objects directly below it.

Continue to browse the NDS tree until the User Login object is displayed in the second line. Choose OK.

Page 77

4-23 Network Setup options

Enter Password

Enter the login password for the NDS tree, using the up and down arrow buttons to select characters, and the left and right arrow buttons to move the cursor. Choose OK.

Navigate NDS Tree to the Print Server.

Choose OK to browse the NDS tree to the Print Server object.

Browsing to ﬁnd the Print Server object begins with the NDS tree that you selected previously (with Select NDS Tree). In each subsequent browse screen, the top line represents your current location. The second line contains:

•A list of objects in the current container directly below your current location

• The symbol “..” to go up one level

With a container object selected, choose OK to travel down the tree, or choose “..” to go up the tree. When you select an object and choose OK, that object is displayed on the top line, and the second line lists objects directly below it.

When the Print Server is displayed in the second line, choose OK.

Enter Print Server Password

Enter the Print Server password, using the up and down arrow buttons to enter characters, and the left and right arrow buttons to move the cursor. Choose OK. (If no password is required, choose OK.)

Server should look for print queues in: Entire NDS Tree/Specif. Subtree [Entire NDS Tree]

By default, the Fiery X3e searches the entire NDS tree for Fiery X3e print connections. This option lets you restrict the search for Fiery X3e print jobs to a subtree (the Print Queue root) in which the Fiery X3e print connections have been deﬁned. This makes the search more efﬁcient. Select Entire NDS Tree if the tree is small. Select Specif. Subtree to restrict the search and specify the subtree.

If you select Entire NDS Tree, choosing OK returns to PServer Setup. Proceed with Bindery Setup (see page 4-25), set the Polling Interval (see page 4-30), or choose Exit PServer Setup to return to the Service Setup menu.

Page 78

4-24 Performing Setup from the Control Panel

Browse to the root of the Print Queue Subtree.

This message is displayed if you selected Specif. Subtree in the previous option. Choose OK to browse the NDS tree to the Print Queue subtree.

Browsing to ﬁnd the container object begins with the NDS tree that you selected previously (with Select NDS Tree). In each subsequent browse screen, the top line represents your current container. The second line contains:

•A list of objects directly below your current location

• The symbol “..” to go up one level

• The symbol “.” to select the current container object (displayed in the top line)

without traveling down the tree

With an object selected, choose OK to travel down the tree, or choose “..” to go up the tree. When you select an object and choose OK, that object is then displayed on the top line, and the second line lists objects contained

When the container that contains print queues is displayed in the second line, choose OK. In the next screen, choose “.” and choose OK to select the object in the top line.

within.

When the Fiery X3e displays the container name, choose OK to return to PServer Setup.

Proceed with Bindery Setup (see page 4-25), set the Polling Interval (see page 4-30), or choose Exit PServer Setup to return to the Service Setup menu when prompted.

Page 79

Network Setup

Service Setup

PServer Setup

4-25 Network Setup options

Bindery Setup options

Bindery Setup

Use Bindery Setup if you have already conﬁgured one or more bindery servers (ﬁle servers running NetWare in bindery emulation) with a Print Server and a Print Queue for Fiery X3e jobs. Before entering bindery settings, be sure the Fiery X3e is connected to the network and the NetWare ﬁle server is running. If Guest Login is not supported, you need a valid user name and password.

NOTE: The terms NetWare server, Novell server, and IPX ﬁle server are in common use

and are used here interchangeably to mean the server on an IPX network running Novell NetWare networking software.

Bindery Setup menu

Because you can set up more than one Novell server to handle Fiery X3e print jobs, an additional menu is displayed for this purpose. The options are:

•Add File Server—creates a new ﬁle server connection to the Fiery X3e. You can set

up a maximum of eight ﬁle server connections. After you have ﬁnished adding a new server, you return to the Bindery Setup menu, where you can set up another server.

•View Server List—displays the list of ﬁle servers that have already been selected to

communicate with the Fiery X3e.

•Edit Connection—lets you change the NetWare Print Server that will print to the

Fiery X3e.

•Remove File Server—lets you disconnect the Fiery X3e from a ﬁle server to which it

is currently connected. Remove a ﬁle server when you want to reduce the number of connections to the Fiery X3e or reassign the connection to a different NetWare ﬁle server.

•Exit Bindery Setup—lets you exit this menu after you have added all servers, viewed

a list of ﬁle servers, or removed a ﬁle server from the list.

NOTE: If you change your mind about any of the menus you have selected, use the

Menu button to escape and return to the main Bindery Setup menu. To cancel all changes, exit Network Setup and select No to Save Changes.

Page 80

Network Setup

Service Setup

PServer Setup

Bindery Setup

4-26 Performing Setup from the Control Panel

Add File Server

This option gives you two ways to add a Novell NetWare ﬁle server.

Select File Server From List/Search by Name [From List]

You may select the ﬁle server from a scrollable list, or by a name search. Choose From List if your network does not have a large number of ﬁle servers. Choose Search by Name if the number of ﬁle servers is so large that scrolling through the list would take a long time.

If you selected From List:If you selected Search by Name:

Add Server

List of all servers

The Fiery X3e obtains a list of NetWare ﬁle servers by querying the IPX network. Use the up and down arrow buttons to select a NetWare ﬁle server from the list. Choose the server on which you have conﬁgured a print server and print queue to handle Fiery X3e print jobs.

Once you have chosen a file server, the Fiery X3e immediately tries to log in as a guest without a password. If it succeeds, it skips to the NetWare Print Server option.

If you try to add a ﬁle server but all Fiery X3e connections are already in use, you are prompted to remove a ﬁle server (see “Remove File Server” on page 4-29).

Enter First Letters of Server Name

Use the up and down arrow buttons to enter the ﬁrst letters of the name of the ﬁle server you want to use, and then choose OK.

Add Server

List of servers matching the search

This option is displayed if you entered letters to search. Scroll through the list to select the server you want.

Page 81

4-27 Network Setup options

File Server Login administrator/supervisor/Enter Login Name [supervisor]

This option appears only if a password is required for login, or if there is no guest account, or the guest account is restricted. Choose Enter Login Name to enter your own login name and password or log in as a guest. Choose administrator or supervisor if you have those privileges.

Enter Your Login Name [guest]

This option and the next appear only if you selected Enter Login Name for the File Server Login. Enter your login name or select guest.

Enter Your File Server Password

Enter the password for logging in to your NetWare ﬁle server.

NetWare Print Server

Print Server Name

Select the name of the print server that you conﬁgured in the NetWare utility PCONSOLE. This print server will route print jobs to the Fiery X3e from computers on IPX networks.

Print Servr Password

This option appears only if your NetWare print server is set up to require you to log in with a password. Enter your print server password.

Choose Add Server again until you have connected each NetWare file server you have configured for printing to the Fiery X3e. When you have added all the IPX file servers for your site, choose Exit Bindery Setup.

Page 82

Network Setup

Service Setup

PServer Setup

Bindery Setup

Network Setup

Service Setup

PServer Setup

Bindery Setup

4-28 Performing Setup from the Control Panel

View Server List

Supported servers

This option allows you to view the list of ﬁle servers currently connected to the Fiery X3e—that is, servers you have added in Bindery Setup. You are notiﬁed if there are none. When you choose OK, you return to the Bindery Setup menu.

Edit Connection

On each connected NetWare ﬁle server, you have deﬁned a print server to handle Fiery X3e print jobs. Choose this option to change the print server assigned to the Fiery X3e.

Choose File Server

File server name

From the list of connected NetWare ﬁle servers, choose the ﬁle server whose print server you want to change.

NetWare Print Server

List of print servers on selected file server

Choose the name of the print server to use. This is the print server that will route print jobs to the Fiery X3e from computers on IPX networks.

If you do not want to make any changes, press the Menu button to return to the Bindery Setup menu.

Page 83

Network Setup

Service Setup

PServer Setup

Bindery Setup

4-29 Network Setup options

Enter Your Print Server Password

This option appears only if your NetWare print server is password-protected. Enter your print server password.

The Bindery Setup menu is displayed again. You can edit other connections, choose another Bindery Setup option, or choose Exit Bindery Setup.

Remove File Server

Remove support for

File server name

This option allows you to select a NetWare ﬁle server from a list of connected ﬁle servers and remove the connection to it. You are notiﬁed that you have removed the connection, and the Bindery Setup menu is displayed again. If you change your mind and do not want to remove any of the ﬁle servers, press the Menu button.

Network Setup

Service Setup

PServer Setup

Bindery Setup

You can choose another Bindery Setup option (such as adding another ﬁle server) or choose Exit Bindery Setup and proceed to set the polling interval.

Exit Bindery Setup

Choose Exit Bindery Setup after you view a list of IPX ﬁle servers, remove a ﬁle server from the list, or connect all the conﬁgured NetWare ﬁle servers. After you select Exit Bindery Setup, you return to the PServer Setup menu.

Page 84

Network Setup

Service Setup

PServer Setup

4-30 Performing Setup from the Control Panel

Polling Interval options

Polling Interval

Whether you use NDS or Bindery services, choose Polling Interval from the main PServer Setup menu. If you do not reset the interval, the default value of 15 seconds is used.

NetWare Server Poll Interval in Seconds 1–3600 [15]

Specify the interval, in seconds, at which the Fiery X3e communicates with the Novell print server to see if there are print jobs waiting.

NOTE: If you select a short interval, the amount of network trafﬁc increases. This may

slow down other network jobs.

Windows Setup options

Network Setup

Service Setup

Windows Setup

Enable Windows Printing Yes/No [Yes]

Enabling Windows Printing enables Server Message Block (SMB), the ﬁle and printer sharing protocol built into Windows. Enabling SMB allows the Fiery X3e to be listed on the network so that Windows clients can print to a particular print connection (Hold, Print, or Direct) on the Fiery X3e without any other networking software. For information on setting up a Windows computer for Windows printing, see the User Software Installation Guide. Windows printing runs via TCP/IP, so you must conﬁgure TCP/IP on the Fiery X3e and on all computers that use Windows printing.

Page 85

4-31 Network Setup options

Use Automatic Configuration Yes/No [No]

This option appears if you chose DHCP or BOOTP as the protocol for automatically obtaining the IP address of the Fiery X3e.

Choose Yes and the Fiery X3e uses a WINS name server and automatically obtains its IP address. Make your choice and proceed to the Server Name option.

Choose No to proceed to the Use WINS Name Server option, where you specify whether to use a WINS name server, and then to the WINS IP Address option, where you specify its IP address.

Use WINS Name Server Yes/No [No]

Broadcasts from SMB devices cannot pass across a router without a WINS name server. Setting up the WINS name server is outside the scope of this manual. To ﬁnd out if a name server is available, contact your network administrator.

WINS IP Address [127.0.0.1]

This option appears only if you choose Yes for WINS Name Server. Change the default address to the correct IP address for the WINS Name Server. Obtain the correct address from your network administrator.

Point and Print Drivers PS/PCL [PS]

Select the type of driver to download when setting up a printer for Windows printing.

Server Name

Default Name

The server name is the name that will appear on the network for accessing the Fiery X3e via SMB. The default name is the same as the server name assigned in Server Setup (see page 4-5).

Page 86

4-32 Performing Setup from the Control Panel

Server Comments

Server comments (optional) can contain information about the printer. These comments are listed in the Fiery X3e Properties in Network Neighborhood and can be up to 15 characters.

Set Domain Name Select from list/Enter manually [Select from list]

This option provides two ways to specify the workgroup or domain in which you want the Fiery X3e to appear.

If you selected Select from list:If you selected Enter manually:

Choose Domain

List of domains

Select the workgroup or domain from the list.

Workgroup or Domain

Enter the name of the workgroup or domain. For more information about entering text and characters, see “Types of

Setup screens” on page 4-5.

Network Setup

Service Setup

Web Services Setup

Enable Web Services Yes/No [Yes]

Select Yes to make the WebTools available to users (see page 6-1). TCP/IP must be enabled on the Fiery X3e and on user workstations. The WebTools include Status, WebLink, WebScan, WebDownloader, WebSetup, and Installer.

A Java-enabled Web browser and a valid IP address are required for each user. For details on browser choice and workstation requirements, see the User Software

Installation Guide.

Page 87

Network Setup

Service Setup

IPP Setup

Network Setup

Service Setup

Port 9100 Setup

4-33 Network Setup options

IPP Setup

Enable IPP Yes/No [Yes]

Select Yes to enable printing with the Internet Printing Protocol (IPP). You must enable Web Services. For information on setting up user computers to use IPP printing, see the User Software Installation Guide.

Port 9100 Setup

Enable Port 9100 Yes/No [No]

This option enables applications to open a TCP/IP socket to the Fiery X3e at Port 9100 to download a print job.

Network Setup

Service Setup

E-mail Setup

Port 9100 Queue Direct/Print Queue/Hold Queue [Print Queue]

Specify the Fiery X3e print connection for downloading jobs to Port 9100. Only the print connections you have enabled in Printer Setup are available.

E-mail Setup

Enable E-mail Services Yes/No [No]

This option enables the Fiery X3e to use e-mail as a means of communication for a variety of purposes. The Fiery X3e serves as a messenger between the copier and the e-mail recipient.

Enable Print via E-mail Yes/No [No]

Choose Yes to enable printing through e-mail.

Page 88

4-34 Performing Setup from the Control Panel

Enable Remote Diagnostics Yes/No [No]

Enabling this option allows the service technician to remotely run diagnostics through e-mail. Contact your authorized service/support center for more information.

RD Outgoing Server

127.0.0.1
