Koldfront WAC8001W, WAC12001W User Manual
V2.9 10132020
Window Air Conditioner
with Supplemental Heater
Owner’s Manual
For more information on other great Koldfront products on the web, go to www.koldfront.com
WAC8001W / WAC12001W
i
Important Safety Information
Improper handling can cause serious damage to the appliance and/or to the user. Please read the
following safety information.
Warning: The water produced by the window AC is not potable or suitable for drinking.
Do not drink the water drained from the unit as it contains contaminates and could make you sick.
Electrical Safety
• Make sure your hands are dry and not wet before operating the unit.
• Do not wet the front housing or control panel.
• Do not directly spray water on this Air Conditioner.
• Do not pull the unit by the cord.
• Always turn the unit off and unplug it from the socket when cleaning.
• Unplug the unit if it is not going to be used for a long period of time.
• Do not operate the unit with a damaged or loose plug and / or socket.
• Use only the correct power supply with appropriate amperage.
• If the power cord is damaged, it must be replaced by the manufacturer, a service agent, or qualified
technician.
• Do not turn the unit off or on by inserting or pulling the power plug.
• Do not modify the power cord length or share the outlet with another appliance.
• Do not use this unit with an extension cord and/or adapter plug.
• Do not use this unit near flammable gases/combustibles or in close proximity to heating appliances.
• During operation do not remove any part of the outside casing.
General Safety
• Do not let people or pets sit or set an object directly in front of air flow.
• If a strange sound, smell, or smoke comes from the unit, turn it off and review the troubleshooting
page of this manual.
• Stop operation and unplug unit in the event of a severe storm.
• To ensure proper air flow and intake, make sure the air vents are not obstructed.
• See instructions for cleaning air filters and how often cleaning should occur.
• Do not use strong detergents when cleaning.
• Children should be supervised when operating this unit.
• Do not allow children to play with the controls or drop any objects into the air outlets or vents.
• Do not place objects or let any person sit on top of the unit.
• Route the power cord carefully to avoid a tripping hazard.
• This unit is intended for domestic home use only. Do not use the window air conditioner for
commercial or industrial use. Any other use may invalidate the warranty.
• Use caution when unpacking and installing the unit as there may be some sharp edges.
ii
Operation of Safety Plug
Your window air conditioner is supplied with a Leakage-Current Detection and Interruption (LCDI)
safety plug. This device provides protection to reduce the risk of fire due to arcing faults in the power
supply cord. Before using your window air conditioner, follow the instructions below to ensure that
the LCDI plug is working properly:
1. Plug the power cord into a grounded outlet.
2. Press the TEST button on the LCDI plug. This should trip the plug and cut the power to the air
conditioner. If the plug does not trip and you are able to turn on the unit, please contact Koldfront
support.
DO NOT USE YOUR WINDOW AIR CONDITIONER IF THE TEST FAILS.
3. Press the RESET button to start using your air conditioner.
Note: Electrical products should not be disposed of with household waste. Please contact
your local recycling center for more information on how to recycle electronic waste.
Notes:
• Always make sure the “Reset” button is pushed in for proper operation.
• The power supply cord with LCDI plug must be replaced if it fails to reset.
• Do not use the TEST and RESET buttons as an ON/OFF switch.
iii
Table of Contents
IMPORTANT SAFETY INFORMATION .......................................................................................................................... I
OPERATION OF SAFETY PLUG…….. ......................................................................................................................... II
TABLE OF CONTENTS………………........................................................................................................................... III
INTRODUCTION………………………. ........................................................................................................................... 1
PARTS IDENTIFICATION………….. .............................................................................................................................. 2
SIDE VIEW……………………………………. ..................................................................................................................... 2
FRONT VIEW……………………………………….. ............................................................................................................. 2
PREPARATIONS FOR INSTALLATION ....................................................................................................................... 3
PARTS SUPPLIED………………………………. ................................................................................................................... 3
WINDOW INSTALLATION INSTRUCTIONS ................................................................................................................. 4
PREPARING THE UNIT FOR WINDOW INSTALLATION .............................................................................................................. 4
Remove the Air Conditioner Unit from Cabinet ............................................................................................................... 4
Attaching the Top Channel and Side curtains ................................................................................................................ 4
Attaching Foam Adhesive………………………. ............................................................................................................. 5
INSTALLING CABINET INTO WINDOW………….. ................................................................................................................... 6
ATTACH SIDE CURTAINS TO WINDOW FRAME ...................................................................................................................... 7
COMPLETING INSTALLATION…………. ..................................................................................................................... 8
CONTROL PANEL OPERATIONS. ............................................................................................................................... 9
USING THE CONTROL PANEL……………………………………………………. ..................................................................... 9
To Turn Unit on……………………………… .................................................................................................................... 9
To Change Temperature………………………. ............................................................................................................... 9
To Adjust Fan Speeds…………………………. ............................................................................................................... 9
To Select Operating Mode…………………….. ............................................................................................................. 10
To Operate in Auto Mode…………………….. ............................................................................................................... 10
To Operate in Fan Only Mode………………………… .................................................................................................. 10
To Operate in Dry Mode………………………… ........................................................................................................... 10
To Use the Energy Saver Feature…………… .............................................................................................................. 10
To Use the Sleep Feature……………………. ............................................................................................................... 11
To Use the Timer (Auto Start/Stop) Feature. ................................................................................................................ 11
To Use the Check Filter Feature………………. ............................................................................................................ 11
Digital Display…………………………………. ............................................................................................................... 11
Error Codes………………………………………. ........................................................................................................... 11
AIR DIRECTIONAL LOUVERS…… ............................................................................................................................. 12
ADDITIONAL TIPS……………………. ......................................................................................................................... 12
REMOTE OPERATIONS……………… ........................................................................................................................ 13
MAINTENANCE………………………. .......................................................................................................................... 14
AIR FILTER CLEANING…………………………… .............................................................................................................. 15
CABINET CLEANING……………………………. ................................................................................................................. 16
NORMAL SOUNDS……………………… ..................................................................................................................... 16
ENERGY SAVING GUIDE……………… ...................................................................................................................... 16
TROUBLESHOOTING………………… ........................................................................................................................ 17
SPECIFICATIONS……………………….. ..................................................................................................................... 19
EDGESTAR LIMITED WARRANTY ............................................................................................................................. 20
1
Introduction
Thank you for purchasing this Koldfront window air conditioner. We hope that this purchase will
be the beginning of a lasting and rewarding relationship between you and Koldfront. We will
provide the customer support and exemplary products necessary to nurture that relationship.
This manual contains important information regarding the proper installation, use, and
maintenance of your window air conditioner. Following this manual will ensure that your product
will work at its peak performance, efficiency, and safety.
Please save the original product packaging in case you need to safely transport your window air
conditioner.
For Your Records:
Please write down the model number and serial number below for future reference.
Both numbers are located on the ratings label on the back of your unit and are
needed to obtain warranty service. You may also want to staple your receipt to this
manual as it is the proof of your purchase, and is also needed for service under your
warranty.
Model Number:
Serial Number:
Date of Purchase:
For a more efficient experience, please do the following before contacting customer service:
• If you received a damaged product, immediately contact the dealer that sold you the
product.
• Read and follow this instruction manual carefully to help you install, use and maintain your
window air conditioner.
• Read the troubleshooting section of this manual as it will help you diagnose and solve
common issues.
• Visit us on the web at www.koldfront.com for product guides, additional troubleshooting
resources and up-to-date information.. If you need service, our friendly customer service
representatives are available via email at service@koldfront.com.
2
Parts Identification
Side View
Front View
CAUTION: Make sure the drain plug is firmly installed before using the unit to prevent leaking.
3
Preparations for Installation
Note: To avoid risk of injury and/or product/property damage, please take the following precautions:
- Two or more people are needed to properly handle and install.
- Use proper lifting and carrying techniques.
- Before installation, make sure to inspect the window and sill to ensure they are able to handle the
weight and size of this unit.
- Wearing protective gloves will help to avoid injury from sharp edges.
Before you begin, make sure you have all the parts necessary for installation.
If you have multiple windows, choose one that is near an electrical outlet that will be able to
provide sufficient power to your unit. See the power requirements listed on the product label
printed on the side or the back of your window air conditioner.
The following measurements are required to properly install the air conditioner.
• Window Width: 26 7/8” to 36”
Tools Needed:
• Flat Screwdriver • Phillips Screwdriver • Tape Measure • Level • Drill
Parts Supplied:
(3) #10 x ½” Phillip Screws (1) Top Channel
(7) #10 x ½” Flat Screws (1) Window Sash Seal
(5) #10 x ¼” Phillip Screws (1) Foam Seal
(1) Set of Side Curtains (1) Window Lock Bracket
(2) Safety Lock (only vinyl windows) (5) Weather Seals
Note: You may need to contact your electrician if your room’s circuit is not able to power your
unit.
4
Window Installation Instructions
Preparing the unit for Window Installation
Remove the Air Conditioner Unit from Cabinet
1. Remove the air conditioner from the carton and place on cardboard.
2. Remove 1 shipping screw from each side. (Figure 1)
3. Remove front panel by removing 1 Phillips screw from each side of the front panel. Set
screws aside and save. (Figure 2)
4. Pull on the handles to slide the air conditioner out of the cabinet. Place the air conditioner
on cardboard. (Figure 3)
Attaching the Top Channel and Side curtains
Make sure to attach the top channel and side curtains prior to installing the cabinet into the
window.
1. Locate the provided bag of screws.
2. Place the top channel on top of the air conditioner cabinet, lining up the three holes in the
top channel with the three holes on top of the cabinet.
3. Using the indicated screws in the figure below attach the top channel to the air conditioner
cabinet.
Note: When choosing your window make sure power supply cord is within 4 feet of a grounded 3prong outlet.
A. # 10 x ¼” Phillips
Screw
B. Top Channel
