KoldFront PDW45E User Manual
Thank you for purchasing this Koldfront product. We are glad you chose us. We believe that your purchase of
this product opens a relationship between you and Koldfront. We will provide the customer support needed to
nurture that relationship.
This manual contains important information regarding the proper installation, use and maintenance of your
product. Following this manual will ensure that your product will work at its peak performance and efficiency.
Please save the original product packaging in case you need to safely transport your product.
For Your Records:
Please write down the model number and serial number below for future reference. Both
numbers are located on the ratings label- which is usually on the back of your unit- and are
needed to obtain warranty service. You may also want to staple your receipt to this manual
as it is the proof of your purchase, and is also needed for service under your warranty.
Model Number: __________________________________
Serial Number: __________________________________
Date of Purchase: __________________________________
To better serve you, please do the following before contacting customer service:
x If you received a damaged product, immediately contact the dealer that sold you the product.
x Read and follow this instruction manual carefully to help you install, use and maintain your product.
x Read the troubleshooting section of this manual as it will help you diagnose and solve common issues.
x Visit us on the web at http://www.edgestar.com for product guides, additional troubleshooting
resources and up-to-date information. If you need service, our friendly customer service
representatives are available via email at service@edgestar.com or by telephone at 1 (866) 319-
5473.
Table of Contents
Page
Components-------------------------------------------------------------------------------------------------------------- 1
Important Safety Instructions---------------------------------------------------------------------------------------- -2
Installation Instructions -------------------------------------------------------------------------------------------------3
Water Pressure-----------------------------------------------------------------------------------------------------------3
Disconnecting the Dishwasher----------------------------------------------------------------------------------------4
Control Panel and LED Display---------------------------------------------------------------------------------------4
Loading Your Dishwasher- -------------------------------------------------------------------------------------------- 5
Preparing Your Dishes for Washing----------------------------------------------------------------------------------5
Detergent and Rinse Aid Use------------------------------------------------------------------------------------------6
Operating Instructions-------------------------------------------------------------------------------------------------- 7
Technical Data and Troubleshooting---------------------------------------------------------------------------------8
Limited Warranty----------------------------------------------------------------------------------------------------------9
Components
Front view
1
2
3
Note that your dishwasher may vary slightly
in appearance from this unit. The
functionality should be the same.
4
5 Back view
6
9 8 7
Inside view
10
11
12
13 14 15
1. Door lock button 6. Power light 11. Filter assembly
2. Digital LED display 7. Power button 12. Rinse aid dispenser
3. Program button 8. Lower front panel 13. Water inlet connection (Inlet valve)
4. Start/pause button 9 . Door 14. Drain hose connection
5. Delayed start button 10. Spray arm 15. Power Cord
1
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
ൺ
Important Safety Instructions
WARNING
When using your dishwasher, follow basic safety precautions, including the following:
Please read the installation and operating instructions carefully before using the dishwasher for the
first time.
These instructions contain very important information with regard to installation, use and maintenance
of your dishwasher.
The manufacturer will not be responsible for problems caused by ignoring these safety and cautionary
instructions.
This dishwasher is designed for normal household use.
Do not use the dishwasher for industrial and commercial use, or any other purpose.
This dishwasher must be plugged directly into a grounded electrical outlet (Do not use an extension cable
or cord.)
Only suitable household utensils should be placed in the dishwasher. (Please avoid utensils that are
not heat-resistant, are decorated metal, etc.)
Keep detergents away from children.
If your hot water temperature in your pipes exceeds 149˚F adjust the your home’s water heater setting. If
your hot water temperature exceeds 149˚F, the dishwasher must be connected to a cold water source.
Do not use any kinds of solvents in your dishwasher. They may cause an explosion or fire.
Do not spray water into the appliance. This may cause the failure of electrical parts or electric shock.
Do not push down or sit on the door when the door is opened. This may cause deformation of the door
or a risk of personal injury.
Do not use dishwasher detergent for hand washing. Dishwasher detergent should be used for
dishwashers only.
ൺIf the power supply cord is damaged, it must been replaced by a technician, service agent or a
similarly qualified person.
This appliance should be positioned so that the plug is accessible.
The appliance is not intended for use by young children or infirm persons without supervision.
Young children should be supervised to ensure that they do not play with the appliance.
Dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid
contact with skin and eyes and keep children away from the dishwasher when the door is open.
Check that the detergent receptacle is empty after completion of the wash cycle.
Connect the dishwasher to your water source using new hoses. Old hoses should not be re-used.
WARNING
Instructions below advise about a risk of fire, electric shock, or injury to persons.
Electrical Instructions:
An electrical supply of 120 volts AC only, 60Hz is required. Make sure that a suitable electrical outlet is located
close to the dishwasher. For your personal safety, the appliance must be grounded.
2
Installation Instructions
Remove All Packing Materials Carefully
1. The water inlet hose from the machine terminates in a ¾” female connector. Connect the hose to ¾” male
connector. We suggest that your water outlet have a stopcock close by in the pipe. It is best to connect the
machine to a hot water supply, but a cold water supply will also suffice. Connect the straight connector from
the inlet hose to the water supply securely. Connect the other end (bent connector) to the water inlet valve
at the back of the dishwasher cabinet. Do not over-tighten the hose connections – this may damage the
threads.
Note: If you so desire, you may connect the water inlet hose on to the kitchen sink tap. Connect the water
supply hose to a threaded ¾” quick-connect adapter and make sure that it is fastened tightly in place.
2. Prepare the drain hose so that it is hooked at the end furthest from the dishwasher. Use the supplied
plastic U-bend fitting provided for this purpose. The end of this should be dropped into a drainage
standpipe, the maximum height of which should be no more than 6” above the base of the dishwasher. To
allow for an air gap around the end of the drain hose, the diameter of the standpipe should be at least 30
mm. Connect the other end of the drain hose (L shaped) to the drain port connection at the back of the
dishwasher cabinet. Tighten the drain hose end on to the drain port using the metal clip included in the
package.
Note: You may also drain this dishwasher into a sink- just make sure that the drain line is secure- so that
water does not leak onto your counter or floor.
Water connection Back view
Inlet valve
Inlet hose
Drain hose Power cord
3. Turn on the water supply and check for leaks. If leaks are located, immediately shut off the water supply
and check the hose connections. Tighten the connections if necessary.
4. If for any reason you are unable to stop the leak yourself please seek advice from a qualified plumber.
5. Make sure there is an electrical outlet within easy reach of the machine. The power cord is about 83” long.
6. The dishwasher must be installed on a solid, level surface.
7. To level the dishwasher, adjust the 4 leveling legs (feet) under the dishwasher. Unscrew them to make
them longer. Screw them in tighter to make them shorter.
Water Pressure
The machine can be used with a hot water supply or cold water supply. A hot water supply is preferred.
For best operating results, incoming water pressure should be between 0.03ᨺ1Mpa. The incoming water
supply for the dishwasher is monitored by a ‘low water pressure switch’, so if the water pressure is too low (or
if there is no water supplied to the machine), the dishwasher will stop.
For Best Results:
3
