Page 1
Memoirs® Stately
Features
•
Quarter-turn washerless ceramic disc valves.
•
5" (127 mm) spout reach.
•
Stately Deco lever handles.
•
Stationary spout.
•
Red and blue index rings.
•
Pop-up drain with lift rod and tailpiece.
•
1.2 gpm (4.5 lmin) maximum flow rate.
•
Widespread.
•
KOHLER ceramic disc valves exceed industry longevity
standards for a lifetime of durable performance.
•
Fluid design lines for ease of cleaning.
•
Completes Memoirs design solution with KOHLER® fixtures
and accessories.
Material
•
Brass.
•
Brass valve bodies.
•
KOHLER finishes resist corrosion and tarnishing.
Installation
•
For 8" - 16" (203 - 406 mm) centers.
•
Handles are preassembled on valves to simplify installation.
Recommended Products/Accessories
K-23726 Drain treatment
K-23723 Faucet cleaner
Optional Products/Accessories
1160593 .35 gpm Aerator, Small
Codes/Standards
ASME A112.18.1/CSA B125.1
NSF/ANSI 61
NSF/ANSI 372
All applicable US Federal and State material
regulations
DOE - Energy Policy Act 1992
EPA WaterSense
®
ADA
ICC/ANSI A117.1
CSA B651
OBC
KOHLER® Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Available Colors/Finishes
Color tiles intended for reference only.
Color Code Description
CP Polished Chrome
widespread sink faucet
K-454-X4V
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 19:25 - US/CA
Page 2
Memoirs® Stately
Ø 2-1/4"
(57 mm)
9/16" (14 mm)
15/16" (24 mm)
7-1/4"
(184 mm)
2-5/8"
(67 mm)
4" (102 mm)
Pop-Up Drain
1-1/4" OD
11/16"
(17 mm)
5" (127 mm)
1-1/4"
(32 mm)
1-7/8" (48 mm)
3-1/4"
(83 mm)
1-3/8" (35 mm) Max
Ø 9/16"
Ø 1-1/8"
1-15/16"
(49 mm)
16" (406 mm) Max
8" (203 mm) Min
2-1/2"
(64 mm)
3-1/4"
(83 mm)
1-7/8"
(48 mm)
Technical Information
All product dimensions are nominal.
Faucet:
Flow rate: 1.2 gal/min (4.5 l/min)
Pressure: 60 psi (4.1 bar)
Drain included: Yes
Drain tailpiece
included:
Yes
Spout:
Spout reach: 5" (127 mm)
Notes
Install this product according to the installation
guide.
ADA compliant for handles only.
ADA, OBC, CSA B651 compliant when
installed to the specific requirements of these
regulations.
widespread sink faucet
K-454-X4V
1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
5-29-2021 19:25 - US/CA
