KOHLER® Faucets Service Parts
Finding the right service part for your faucet repair can seem like a daunting task. To simplify the process, this catalog will help you identify which faucet parts you need to complete the repair. When you choose KOHLER genuine parts, you can be sure your faucet will continue to deliver exceptional performance.
Tips to Finding the Right Part
Determine Your Faucet Type
All KOHLER faucets are described along with their common replacement parts. To determine your faucet type, compare your faucet with those pictured in this catalog.
This book contains the most popular KOHLER faucets and their corresponding parts. For a complete listing of faucets and parts available, please visit KOHLER.com/ServiceParts or call 800-558-5700.
Faucets–Detailed Parts Matrix
Bathroom Sink Faucets
Widespread Bathroom Sink Faucets ............................................................................ 6-10
Centerset Bathroom Sink Faucets ...............................................................................11-13
Single-Handle Bathroom Sink Faucets ........................................................................14 -15
Wall-Mount Bathroom Sink Faucets ........................................................................... 16 -17
Showering
Standard and Custom Showering .............................................................................. 18-21
Wall-Mount Bath Faucets ..........................................................................................22-25
Deck-Mount Bath Faucets .........................................................................................26-29
Kitchen Faucets
Two-Handle Kitchen Faucets ..................................................................................... 31-34
Single-Handle Kitchen Faucets ..................................................................................34-36
Pull-Down/Pullout Kitchen Faucets ........................................................................... 36-38
Wall-Mount Kitchen Faucets ......................................................................................38-39
Bar Faucets
Bar Faucets ..............................................................................................................40 -41
Commercial
Touchless Faucets ......................................................................................................... 42
Urinal Flush Valves .........................................................................................................43
Commercial Faucets .................................................................................................44-45
Red/Blue Indexing ....................................................................................................44-45
Red/Blue Indexing ....................................................................................................46-47
Kohler Co. reserves the right to make changes in product characteristics, packaging or availability at any time without notice. Every effort has been made to ensure the correct part numbers are listed in this matrix.
Unable to locate a part?
If you have identified the parts you need, but cannot find them within the genuine service parts matrix, please call us toll-free at 800-4KOHLER (800-456-4537), Monday - Friday, between 8am and 6pm CST, and a customer service representative will assist you. Or visit KOHLER.com/ServiceParts.
2
INDEX
Bathroom Sink Widespread
K-107 ............................... 6
K-108 ............................... 6
K-153 ............................... 6
K-223 ............................... 6
K-275 ............................... 6
K-280 ............................... 6
K-310 ............................... 8
K-394 ............................... 8
K-454 ............................... 9
K-942 ............................. 10
K-5317 ............................. 9
K-6274 ............................. 9
K-6762 ............................. 7
K-6811 ............................. 6
K-6813 ............................. 6
K-6846 ............................. 7
K-6847 ............................. 7
K-6848 ............................. 7
K-6849 ............................. 7
K-6850 ............................. 7
K-6952 ............................. 6
K-6954 ............................. 6
K-6955 ............................. 6
K-6956 ............................. 6
K-6961 ............................. 6
K-6962 ............................. 6
K-7411 ............................. 8
K-7416 ....................... 7, 10
K-7417 ....................... 7, 10
K-7419 ....................... 7, 10
K-7433 ............................. 8
K-7435 ....................... 8, 10
K-7436 ....................... 8, 10
K-7437 ........................... 10
K-7438 ............................. 8
K-7439 ....................... 8, 10
K-7449 ....................... 8, 10
K-7465 ........................... 10
K-7467 ........................... 10
K-7468 ........................... 10
K-7471 ........................... 10
K-7472 ........................... 10
K-7473 ........................... 10
K-7476 ........................... 10
K-7481 ............................. 8
K-7914 ............................. 6
K-7914 ............................. 7
K-7916 ............................. 7
K-7980 ............................. 6
K-8211 ........................... 10
K-8212 ........................... 10
K-8215 ........................... 10
K-10086 ........................... 9
K-10272 ........................... 8
K-10577 ........................... 7
K-11076 ........................... 6
K-11810 ......................... 10
K-12265 ........................... 8
K-13132 ........................... 9
K-13328 ........................... 8
K-13330 ........................... 8
K-13335 ........................... 8
K-13337 ........................... 8
K-13338 ........................... 8
K-13339 ........................... 8
K-13340 ........................... 8
K-13391 ........................... 8
K-13392 ........................... 8
K-13394 ........................... 8
K-13395 ........................... 8
K-13491 ...........................
K-14406 ........................... 9
K-14407 ........................... 9
........................... 9
K-14408
K-14410 ........................... 9
K-14661 ........................... 9
K-14662 ........................... 9
K-15261 ........................... 7
K-15262 ........................... 7
K-15265 ........................... 7
K-15268 ........................... 7
K-15269 ........................... 7
K-15815 ........................... 7
K-15816 ........................... 7
K-15817 ........................... 7
K-15850 ........................... 7
K-15886 ........................... 7
K-16102 ........................... 9
K-16104 ........................... 9
K-16232 ........................... 9
K-45102 ........................... 6
Bathroom Sink Centerset
K-393 ............................. 12
K-452 ............................. 13
K-5316 ........................... 13
K-6212 ........................... 12
K-6763 ........................... 12
K-6882 ........................... 11
K-6883 ........................... 11
K-6950 ........................... 11
K-6960 ...........................
K-7401 ........................... 13
K-7401-T ...................... 12
K-7401-TL ...................... 13
K-7403 ........................... 13
K-7403-TL ...................... 13
K-7404 ........................... 13
K-7404-TL ...................... 13
K-7405 ........................... 13
K-7406 ........................... 13
K-7408 ........................... 13
K-7408-TL ...................... 13
K-7409 ........................... 13
K-7412 ........................... 12
K-7415 ........................... 13
K-7474 ........................... 13
K-8201 ........................... 13
K-10085 ......................... 13
K-10270 ......................... 12
K-10579 ......................... 11
K-10800 ......................... 13
K-11075 ......................... 11
K-11550 ......................... 11
K-11800 ......................... 13
K-12266 ......................... 12
K-13360 ......................... 12
K-13490 ......................... 12
K-14513 ......................... 13
K-14514 ......................... 13
K-15240 ......................... 11
K-15240-4 ...................... 12
K-15240-7 ...................... 12
K-15241 ......................... 11
K-15243 ......................... 11
K-15260 ......................... 11
K-15635 ......................... 11
K-15636 ......................... 11
K-15637 ......................... 11
K-15640 ......................... 11
K-15641 ......................... 11
K-15643 ......................... 11
K-15645 ......................... 11
K-15810 ......................... 12
K-15850 ......................... 11
K-15885 ......................... 12
K-16100 ......................... 13
K-45100 ......................... 11
Bathroom Sink Single-Handle
K-138 ............................. 14
K-139 ............................. 14
9
K-6268 ........................... 14
K-8959 ........................... 15
K-8990 ........................... 15
K-10215 ......................... 14
K-10217 ......................... 14
K-11000 ......................... 14
K-11010 ......................... 15
K-12181 ......................... 14
K-12182 ......................... 14
K-12183 ......................... 14
K-14402 ......................... 15
K-14404 ......................... 15
K-14516 ......................... 14
K-14517 ......................... 14
K-14616 ......................... 14
K-14661 ......................... 14
K-14760 ......................... 15
K-15182 ......................... 14
K-15191 ......................... 14
K-15192 ......................... 14
K-15198 ......................... 14
K-15199 ......................... 14
K-15681 ......................... 14
K-16230 ......................... 14
K-16231 ......................... 14
K-18140 ......................... 15
K-19480 ......................... 15
K-19774 ......................... 15
K-19909 ......................... 15
Bathroom Sink Wall-Mount
K-10087 ......................... 17
11
K-11820 ......................... 17
K-13322 ......................... 16
K-149 ............................. 16
K-159 ............................. 16
K-2443 ........................... 16
K-6269 ........................... 17
K-6971 ........................... 16
K-7445 ........................... 16
K-7450 ........................... 16
K-7480 ........................... 16
K-7481 ........................... 16
K-7482 ........................... 17
K-7483 ........................... 17
K-7485 ........................... 16
K-7486
K-8040 ........................... 16
K-T14412 ....................... 17
K-T14413 ....................... 17
K-T14414 ....................... 17
K-T14415 ....................... 17
K-T14416 ....................... 17
K-T14417 ....................... 17
K-T14419 ....................... 17
K-T154 ........................... 16
K-T16106 ....................... 17
K-T196 ........................... 16
K-T197 ........................... 16
K-T198 ........................... 16
K-T199 ........................... 16
K-T343 ........................... 16
K-T344 ........................... 16
K-T448 ........................... 17
K-T6277 ......................... 17
K-T944 ........................... 17
K-T945 ........................... 17
Bath/Shower Single-Handle
K-129 ............................. 18
K-130 ............................. 18
K-131 ............................. 18
K-132 ............................. 18
K-133 ............................. 18
K-134 ............................. 18
K-304 ............................. 18
K-305 ............................. 18
K-306 ............................. 18
K-2971 ........................... 18
K-6872 ........................... 18
K-6873 ........................... 18
K-6874 ........................... 18
K-6875 ........................... 18
K-6900 ........................... 18
K-6902 ........................... 18
K-6904 ........................... 18
K-6908-7A ..................... 19
K-6908-8A ..................... 19
K-7027 ........................... 19
K-7028 ........................... 19
K-7076 ........................... 19
K-7205 ........................... 19
K-7215 ........................... 19
K-7216 ........................... 19
........................... 16
K-7217 ........................... 19
K-7224 ........................... 19
K-7244 ........................... 19
K-7245 ........................... 19
K-7248 ........................... 19
K-7250 ........................... 19
K-7256 ........................... 19
K-7300 ........................... 19
K-7301 ........................... 19
K-11748 ......................... 18
K-15101 ......................... 19
K-15108 ......................... 19
K-15110 ......................... 19
K-15112 ......................... 19
K-15114 ......................... 19
K-15116 ......................... 19
K-15120 ......................... 19
K-15128 ......................... 19
......................... 19
K-15129
K-15134 ......................... 19
K-15143 ......................... 19
K-15155 ......................... 19
K-15177 ......................... 19
K-15301 ......................... 19
K-15303 ......................... 19
K-15305 ......................... 19
K-15307 ......................... 19
K-15310 ......................... 19
K-15312 ......................... 19
K-15314 ......................... 19
K-15316 ......................... 19
K-15326 ......................... 19
K-15328 ......................... 19
K-T130 ........................... 18
K-T132 ........................... 18
K-T134 ........................... 18
K-T309 ........................... 18
K-T312 ........................... 18
K-T313 ........................... 18
K-T395 ........................... 18
K-T396 ........................... 18
K-T397 ........................... 18
K-T461 ........................... 18
K-T462 ........................... 18
K-T463 ........................... 18
K-T464 ........................... 18
K-T465 ........................... 18
K-T466 ........................... 18
K-T948 ........................... 18
K-T949 ........................... 18
K-T950 ...........................
K-T4501 ......................... 18
K-T6808 ......................... 18
K-T6809 ......................... 18
K-T6810 ......................... 18
K-T6908 ......................... 19
K-T6910 ......................... 19
K-T6912 ......................... 19
K-T6913 ......................... 19
K-T6914 ......................... 19
K-T8224 ......................... 19
K-T8225 ......................... 19
K-T8226 ......................... 19
K-T8227 ......................... 19
K-T8228 ......................... 19
K-T8229 ......................... 19
K-T9492 ......................... 18
K-T10055 ....................... 18
K-T10056 ....................... 18
K-T10057 ....................... 18
K-T10274 ....................... 18
K-T10275 ....................... 18
K-T10276 ....................... 18
K-T10277 ....................... 18
K-T10581 ....................... 18
K-T10582 ....................... 18
K-T10583 ....................... 18
K-T10584 ....................... 18
K-T11077 ....................... 18
K-T11078 ....................... 18
K-T11552 ....................... 18
K-T11553 ....................... 18
K-T12007 ....................... 18
K-T12014 ....................... 18
K-T12021 ....................... 18
18
K-T13133 ....................... 18
K-T13134 ....................... 18
K-T13135 ....................... 18
K-T14420 ....................... 18
K-T14421 ....................... 18
K-T14422 ....................... 18
K-T14423 ....................... 18
K-T14540 ....................... 19
K-T14541 ....................... 19
K-T14542 ....................... 19
K-T15601 ....................... 18
K-T15603 ....................... 18
K-T15611 ....................... 18
K-T15613 ....................... 18
K-T15621 ....................... 18
K-T16113 ....................... 18
K-T16114 ....................... 18
K-T16115 ....................... 18
K-T16116 ....................... 18
K-T16117 ....................... 18
K-T16225 ....................... 18
K-T16233 ....................... 18
K-T16234 ....................... 18
K-T16235 ....................... 18
K-T18488 ....................... 18
K-T18489 ....................... 18
K-T18490 ....................... 18
Bath/Shower Custom Showering
K-400 ............................. 20
K-401 ............................. 20
K-402 ............................. 20
K-403 ............................. 21
K-404 ............................. 20
K-405 ............................. 21
K-406 ............................. 21
K-407 ............................. 21
K-669 ............................. 20
K-670 ............................. 20
K-671 ............................. 21
K-672 ............................. 21
K-679 ............................. 20
K-680 ............................. 20
K-681 ............................. 21
K-687 ............................. 21
K-728 ............................. 21
K-T376 ........................... 21
K-T10058 ....................... 21
K-T10067 ....................... 21
K-T10069 ....................... 20
K-T10110 ....................... 20
K-T10111 ....................... 21
K-T10113 ....................... 21
K-T10182 ....................... 20
K-T10183 ....................... 20
K-T10184 ....................... 21
K-T10185 ....................... 21
K-T10290 ....................... 21
K-T10301 ....................... 20
K-T10302 ....................... 20
K-T10303 ....................... 21
K-T10304 ....................... 21
K-T10357 ....................... 20
K-T10358 ....................... 21
K-T10359 ....................... 20
K-T10360 ....................... 21
K-T10421 ....................... 20
K-T10422 ....................... 20
K-T10423 ....................... 21
K-T10424 ....................... 21
K-T10426 ....................... 20
K-T10427 ....................... 20
K-T10428 ....................... 21
K-T10429 ....................... 21
K-T10593 ....................... 20
K-T10594 ....................... 20
K-T10595 ....................... 21
K-T10596 ....................... 21
K-T10680 ....................... 20
K-T10681 ....................... 21
K-T10682 ....................... 21
K-T10940 ....................... 20
K-T10941 ....................... 20
K-T10943 ....................... 21
K-T10944 ....................... 21
K-T12189 ....................... 21
K-T13173 ....................... 20
K-T13174 ....................... 21
K-T13175 ....................... 21
K-T14488 ....................... 20
K-T14489 ....................... 20
K-T14490 ....................... 21
K-T14491 ....................... 21
K-T16175 ....................... 20
K-T16176 ....................... 20
K-T16177 ....................... 21
K-T16178 ....................... 21
K-T16239 ....................... 20
K-T16241 ....................... 21
K-T16242 ....................... 21
K-T18090 ....................... 20
K-T18091 ....................... 21
K-T18491 ....................... 21
Bath/Shower Wall-Mount
K-119 ............................. 22
K-120 ............................. 22
K-122 ............................. 22
K-123 ............................. 22
K-124 ............................. 22
K-302 ............................. 22
K-303 ............................. 22
K-6758 ........................... 23
K-6759 ........................... 23
K-6804 ........................... 22
K-6805 ........................... 22
K-6806 ........................... 22
K-6807 ........................... 22
K-6831 ........................... 22
K-6838 ........................... 23
K-6840 ........................... 23
K-6842 ........................... 23
K-6845 ........................... 23
K-6929 ........................... 22
K-6930 ........................... 22
K-6931 ........................... 22
K-6932 ........................... 22
K-6933 ........................... 22
K-6934 ........................... 22
K-6944 ........................... 22
K-6962 ........................... 22
K-6962 ........................... 22
K-6995 ........................... 22
K-7004 ........................... 23
K-7004 ........................... 24
K-7004-7A ..................... 24
K-7004-8A ..................... 24
K-7004-T ........................ 25
K-7006 ........................... 23
K-7010 ........................... 23
K-7010 ........................... 24
K-7010-7A ..................... 24
K-7010-T ........................ 25
K-7014 ........................... 23
K-7014 ........................... 24
K-7014-7A ..................... 24
K-7014-8A ..................... 24
K-7014-T ........................ 25
K-7022 ........................... 24
K-7022-T ........................ 25
K-7034 ........................... 23
K-7034 ........................... 24
K-7034-7A ..................... 24
K-7034-8A ..................... 24
K-7034-T ........................ 25
K-7036 ........................... 24
K-7042 ........................... 25
K-7043-T ........................ 25
K-7045 ........................... 25
K-7047 ........................... 25
K-7226 ........................... 23
K-7226 ........................... 24
K-7226-7A ..................... 24
K-7226-8A ..................... 24
K-7227-T ........................ 25
K-7234 ........................... 24
3
INDEX
Bath/Shower Wall-Mount (cont.)
K-7234-T ........................ 25
K-7252 ........................... 24
K-7254 ........................... 24
K-7258 ........................... 24
K-7735 ........................... 24
K-7744 ........................... 24
K-7744-7A ..................... 24
K-7744-8A ..................... 24
K-7751 ........................... 24
K-7751-7A ..................... 24
K-7751-8A ..................... 24
K-7901 ........................... 23
K-7905 ........................... 23
K-7907 ........................... 23
K-7951 ........................... 24
K-10106 ......................... 22
K-10116 ......................... 22
K-10120 ......................... 22
K-11606 ......................... 24
K-11608 ......................... 24
K-11612 ......................... 24
K-11614 ......................... 24
K-11616 ......................... 24
K-11618 ......................... 24
K-11620 ......................... 24
K-11622 ......................... 24
K-11638 ......................... 24
K-11730 ......................... 24
K-13363 ......................... 23
K-13367 ......................... 23
K-15226 ......................... 23
K-15801 ......................... 23
K-15802 ......................... 23
K-15803 ......................... 23
K-15851 ......................... 23
K-T15201 ....................... 23
K-T15202 ....................... 23
K-T15204 ....................... 23
K-T15211 ....................... 23
K-T15214 ....................... 23
K-T15221 ....................... 23
K-T15224 ....................... 23
K-T15225 ....................... 23
K-T15231 ....................... 23
K-T15235 ....................... 23
K-T15401 ....................... 23
K-T15411 ....................... 23
K-T15431 ....................... 23
Bath/Shower Deck-Mount
K-103 .............................27
K-104 .............................27
K-109 .............................27
K-110 .............................27
K-125 .............................27
K-300 .............................26
K-301 .............................26
K-438 .............................26
K-6504 ...........................26
K-6766 ...........................28
K-6842 ...........................27
K-6843 ...........................27
K-6905 ...........................26
K-6926 ...........................26
K-6929 ...........................26
K-6942 ...........................26
K-6949 ...........................27
K-7019 ...........................28
K-7024 ...........................29
K-7030 ...........................29
K-7030-ZY .....................29
K-7902 ...........................27
K-7908 ...........................27
K-7909 ...........................27
K-7910 ...........................27
K-7913 ...........................27
K-7915 ...........................27
K-7923 ...........................27
K-7926 ...........................27
K-7936 ...........................28
K-7938 ...........................28
K-7963 ...........................28
K-7964 ...........................28
K-7976 ...........................26
K-7977 ...........................26
K-7978 ...........................26
K-8230 ...........................29
K-8235 ...........................29
K-8238 ...........................29
K-14475 .........................26
K-14520 .........................28
K-14774 .........................26
K-15290 .........................27
K-15291 .........................27
K-15295 .........................27
K-15296 .........................27
K-15708 .........................27
K-15806 .........................27
K-15807 .........................27
K-15851 .........................27
K-15856 .........................27
.........................27
K-15857
K-15880 .........................27
K-15881 .........................27
K-15882 .........................27
K-15883 .........................27
K-16119 .........................28
K-16122 .........................28
K-16124 .........................28
K-T125 ...........................26
K-T135 ...........................26
K-T314 ...........................26
K-T333 ...........................26
K-T387 ...........................26
K-T398 ...........................26
K-T413 ...........................26
K-T428 ...........................26
K-T467 ...........................26
K-T469 ...........................26
K-T614 ...........................28
K-T954 ...........................26
K-T955 ...........................26
K-T6501 .........................26
K-T6906 .........................26
K-T6915 .........................26
K-T8230 .........................26
K-T8232 .........................26
K-T8235 .........................26
K-T8238 .........................26
K-T10059 .......................26
K-T10068 .......................26
K-T10278 .......................26
K-T10291 .......................26
K-T10292 .......................26
K-T10585 .......................26
K-T10587 .......................26
K-T10592 .......................26
K-T12885 .......................26
K-T12887 .......................26
K-T13140 .......................26
K-T13151 .......................26
K-T13494 .......................26
K-T14428 .......................26
K-T14429 .......................26
K-T14675 .......................26
K-T15290 .......................26
K-T15294 .......................26
K-T16119 .......................26
K-T16122 .......................26
K-T16124 .......................26
K-T16236 .......................26
K-T16237 .......................26
K-T16248 .......................26
Kitchen Two-Handle
K-117 .............................31
K-118 .............................31
K-147 .............................31
K-148 .............................31
K-158 .............................31
K-377 .............................32
K-6125 ...........................33
K-6126 ...........................33
K-6130 ...........................33
K-6131 ...........................33
K-6972 ...........................31
K-6973 ...........................31
K-6974 ...........................31
K-7337 ...........................33
K-7547 ...........................33
K-7548 ...........................33
K-7341 ...........................33
K-7761 ...........................34
K-7763 ...........................34
K-7765 .....................32, 34
K-7765-8A .....................33
K-7765-FVC ...................32
K-7771 ...........................32
K-7771-8A .....................33
K-7771-FVC ...................32
K-7776 ...........................34
K-7776-8A .....................33
K-7776-DB .....................32
K-7776-FCV ...................32
K-7779 ...........................34
K-7779-8A .....................33
K-7779-FCV ...................32
K-7782 ...........................34
K-7794 ...........................34
K-7825 ...........................34
K-7826 ...........................34
K-7827 ...........................34
K-8219 ...........................33
K-8220 ...........................33
K-8221 ...........................33
K-8762 ...........................32
K-8763 ...........................32
K-10445 .........................33
K-10900 .........................33
K-10905 .........................33
K-11900 .........................34
K-11905 .........................34
K-11920 .........................34
K-11920-R .....................34
K-11925 .........................34
K-11925-R .....................34
K-11933 .........................34
K-11935 .........................34
K-12230 .........................32
K-12231 .........................32
K-13393 .........................32
K-13580 .........................32
K-15251 .........................31
K-15253 .........................31
K-15255 .........................31
K-15255-P .....................31
K-15256 .........................31
K-15258 .........................31
K-15259 .........................31
K-15259-P .....................31
K-15270 .........................31
.........................31
K-15271
K-15834-K .....................31
K-15836-K .....................31
K-15888 .........................31
K-15889 .........................31
K-16109 .........................33
K-16111 .........................33
Kitchen Single-Handle
K-168 .............................34
K-169 .............................34
K-170 .............................34
K-171 .............................34
K-6227 ...........................36
K-6333 ...........................35
K-6334 ...........................35
K-6335 ...........................35
K-6336 ...........................35
K-6356 ...........................35
K-6895 ...........................35
K-6896 ...........................35
K-6897 ...........................35
K-7323 ...........................36
K-7507 ...........................36
K-7508 ...........................36
K-7509 ...........................36
K-7511 ...........................36
K-10411 .........................35
K-10412 .........................35
K-10413 .........................35
K-10415 .........................35
K-10416 .........................35
K-10430 .........................35
K-10441 .........................35
K-12171 .........................35
K-12172 .........................35
K-12173 .........................35
K-12175 .........................35
K-12176 .........................35
K-12185 .........................35
K-15071 .........................35
K-15072 .........................35
K-15073 .........................35
K-15075 .........................35
K-15076 .........................35
K-15167 .........................35
K-15168 .........................35
K-15171 .........................35
K-15172 .........................35
K-15173 .........................35
K-15174 .........................35
K-15175 .........................35
K-15176 .........................35
K-15177 .........................35
K-15178 .........................35
K-R10434 ......................35
Kitchen Pull-Down/ Pullout
K-560 .............................36
K-596 .............................37
K-597 .............................37
K-647 .............................38
K-649 .............................38
K-690 .............................38
K-691 .............................38
K-692
.............................36
K-780 .............................36
K-6330 ...........................37
K-6331 ...........................37
K-6332 ...........................37
K-6350 ...........................36
K-6352 ...........................36
K-6353 ...........................36
K-6996 ...........................37
K-6997 ...........................37
K-7344 ...........................37
K-7505 ...........................37
K-7506 ...........................37
K-10433 .........................37
K-12177 .........................37
K-13963 .........................36
K-14502 .........................37
K-15160 .........................36
K-15165 .........................36
K-15170 .........................36
K-15405 .........................37
K-R648 ..........................38
Kitchen Wall-Mount
K-149 .............................38
K-155 .............................38
K-159 .............................38
K-165 .............................38
K-6127 ...........................39
K-6132 ...........................39
K-6228 ...........................39
K-7319 ...........................39
K-7320 ...........................39
K-7322 ...........................39
K-7338 ...........................39
K-7549 ...........................39
K-7854 ...........................38
K-7855 ...........................38
K-7856 ...........................38
K-7857 ...........................38
K-8888 ...........................38
K-8892 ...........................38
K-8904 ...........................39
K-8905 ...........................39
K-8906 ...........................39
K-8924 ...........................39
K-8928 ...........................39
K-8950 ...........................38
K-8955 ...........................38
Bar
K-118 .............................40
K-6665 ...........................41
K-6666 ...........................41
K-7322 ...........................41
K-7323 ...........................41
K-7342 ...........................41
K-7894 ...........................40
K-7895 ...........................40
K-8207 ...........................41
K-8761 ...........................40
K-9707 ...........................41
K-9709 ...........................41
K-10443 .........................41
K-11930 .........................41
K-11935 .........................41
K-12183 .........................40
K-14506 .........................41
K-14507 .........................41
K-14508 .........................41
K-15270 .........................40
K-15271 .........................40
K-15275 .........................40
K-15276 .........................40
K-15279 .........................40
K-15840 .........................40
K-15850 .........................40
K-16112 .........................41
K-16114 .........................41
K-18865 .........................40
Touchless
K-7514 ...........................42
K-7515 ...........................42
K-7516 ...........................42
K-7517 ...........................42
K-7518 ...........................42
K-7519 ...........................42
K-13460 .........................42
K-13461 .........................42
K-13462 .........................42
K-13463 .........................42
K-13466 .........................42
K-13467 .........................42
K-13468 .........................42
K-13469 .........................42
K-13472 .........................42
K-13473 .........................42
K-13474 .........................42
K-13475 .........................42
K-13660 .........................42
K-13660-2E ...................42
K-13662 .........................42
K-13662-2E ...................42
K-13664 .........................42
K-13666 .........................42
K-T11836 .......................42
K-T11837 .......................42
K-T11838 .......................42
K-T11839 .......................42
K-T11840 .......................42
K-T11841 .......................42
Urinals
K-10666 .........................43
K-10668 .........................43
K-10669 .........................43
K-10673 .........................43
K-10674 .........................43
K-10675 .........................43
K-10676 .........................43
K-10677 .........................
K-10678 .........................43
K-10679 .........................
K-10949
.........................43
K-10956 .........................43
K-10957 .........................43
K-10958 .........................43
43
43
K-10959 .........................43
K-10960 .........................43
K-10961 .........................43
K-10962 .........................43
K-10963 .........................43
K-10964 .........................43
K-10965 .........................43
K-10966 .........................43
K-13516 .........................43
K-13517 .........................43
K-13518 .........................43
K-13519 .........................43
K-13520 .........................43
K-13521 .........................43
K-13522 .........................43
K-13686 .........................43
Commercial
K-7490 ...........................45
K-7491 ...........................45
K-8496 ...........................44
K-8525 ...........................44
K-8526 ...........................44
K-8899 ...........................45
K-13055 .........................45
K-13056 .........................45
K-13061 .........................45
K-13175 .........................45
K-13330 .........................44
K-13341 .........................44
K-13343 .........................44
K-13344 .........................44
K-13328 .........................44
K-13583 .........................44
K-13584 .........................44
K-13585 .........................44
K-13595 .........................44
K-13596 .........................44
K-13629 .........................45
K-13639 .........................45
K-13640 .........................44
K-13711 .........................45
K-13760 .........................44
K-13761 .........................44
K-13762 .........................44
K-13770 .........................44
K-13772 .........................44
K-13774 .........................44
K-13782 .........................44
K-13786 .........................44
K-13808 .........................44
K-13812 .........................44
K-13816 .........................44
K-13817 .........................44
K-13839 .........................44
K-13925 .........................44
K-13931-2A ...................44
Red/Blue Indexing
See pages ................ 46-47
4
Bathroom Sink Faucets
Bathroom Sink Faucets
Faucet Types
Page 6-10
Page 11-13
Page 11-13
Page 14-15
Widespread
Two-handle faucet for 8"-16" centers
Centerset
Two-handle faucet for 4" centers
Monoblock
Two-handle single-hole faucet with or without an escutcheon
Single-Handle
Faucet with one handle mounted on the top or side of the faucet
Common Valves
UltraGlide® 1/4-Turn
GP1092204 (H) GP1092203 (C)
GP76672 (H) GP76671 (C)
GP77548 1000739 1126312 1066371 GP1017426 1162061 1170273
1/4-Turn
GP77005-RP (H) GP77006-RP (C)
1152349 (H) 1152350 (C) (For select centerset faucets)
Valvet
Full-Turn
®
GP30002 (H) GP30004 (C)
Hose
GP1092201 Only for use with UltraGlide valves
Hose
GP73151-A
UltraGlide complete valve assembly
1131481 (H) 1131482 (C)
Bathroom Sink
Faucets
Wall-Mount
Single- or two-handle faucet which is mounted on the wall
Full-Turn
GP30002 (H) GP30004 (C)
Page 16-17
1/4-Turn GP77005-RP (H) GP77006-RP (C)
Remote Valve
One- or two-handle faucet with the valves and handles mounted to one side of the spout
Page 14
1090948 1088996
Bathroom Sink Drain Stoppers Aerators – Control Water Flow and Reduce Splash
1.30" 1.30" 1.55" 1.55"
74412*
58155* 1037021*
(Plastic)
1037022*
(Metal)
1.875"
78172*
Complete Drain Assembly
1035350*
Mixes airfl ow to reduce splash
GP77548 1090948
Aerated Laminar Spray
Eliminates air for single stream of water without splash (Ex.: garden hose)
Delivers water fl ow in multiple streams (Ex.: showerhead)
For individual bathroom sink faucet details, see pages 6-17.
(H) = Hot (C) = Cold *Include the color or fi nish code after the part number when ordering.
5
Widespread
Bathroom Sink Faucets
Widespread
Product Name
IV Georges Brass
K-6811
K-6813
Alteo
®
K-45102
Alterna
K-6952
K-6956
K-6954
K-6961
K-6955
Aerator Kit
Valve/ Valvet
®
Current
GP1092204 (H) GP1092203 (C)
Prior to 1990
GP30002 (H) GP30004 (C)
®
1990-2010
GP77005-RP (H) GP77006-RP (C)
30127-BC (H) 30128-BC (C)
49/32"
GP1092204 (H) GP1092203 (C)
GP77005-RP (H) GP77006-RP (C) (Lever Handle)
GP30002 (H & C) (Square Handle)
GP77005-RP (H & C) (Square Handle)
GP30002 (H) GP30004 (C) (Lever Handle)
Includes Washer,
Aerator and Nozzle
1104111* (1.5 gpm)
41781* (1.5 gpm)
1030351* (2.2 gpm)
59620* (2.0 gpm)
59621* (2.0 gpm)
55604 1103469*
1.5 gpm
1.0 gpm
0.5 gpm
1.5 gpm
1.0 gpm
0.5 gpm
1100416 (1.5 gpm)
43185
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 57844
Insert Options
1104546 Laminar
1097180 Aerated
1139285 Laminar
1139284 Aerated
1075456 Spray
1075455 Spray
Washer 79441
41007* (2.2 gpm)
41056* (2.2 gpm)
(1.5 gpm)
Handle
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Square Insert Discontinued
Plug Button/
Cap
N/A
N/A
Lever Insert 52546*
Brass Insert 22494*
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Sidespray 1021724*
K-6962
K-7914
K-7980
Antique
K-107 K-108 K-223 K-275
K-280
K-153
Current
GP1092204 (H) GP1092203 (C)
Current
GP1092204 (H) GP1092203 (C)
Prior to 1990
GP30002 (H) GP30004 (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
30127-BC (H) 30128-BC (C)
Prior to 1990
GP30002 (H) GP30004 (C)
49/32"
1104111* (1.5 gpm)
59620* (2.0 gpm)
N/A
1.5 gpm
1.0 gpm
0.5 gpm
N/A
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 57844
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Ceramic Inserts 22493*
42728*
(Large)
(Small)
Brass Inserts
42730*
22494*
(Large)
(Small)
N/A
Lever Insert 52546*
Ceramic Inserts
42728*
22493*
(Large)
(Small)
Brass Inserts 22494*
42730*
(Large)
(Small)
Inserts used with K-280 faucet only
K-258*
K-274*
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Archer
K-11076
®
Current
GP1092204 (H) GP1092203 (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1103460* (1.5 gpm)
1.5 gpm
1.0 gpm
0.5 gpm
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 78783
See KOHLER.com/
ServiceParts
N/A
See KOHLER.com/
ServiceParts
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
6
Bathroom Sink Faucets
Widespread
Product Name
Bancroft
®
K-10577
Bravura
K-6846 K-6847
Bravura
K-6848 K-6849 K-6850
Cirrus
K-7914 K-7916
Constellation
K-7416 K-7417 K-7419
Valve/ Valvet
Current
GP1092204 (H) GP1092203 (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H & C)
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
GP30002 (H) GP30004 (C)
®
GP30002 (H & C)
GP30002 (H & C)
30583 (H & C)
1103462* (1.5 gpm)
41056* (2.2 gpm)
Aerator Kit
Includes Washer,
Aerator and Nozzle
41007* (2.2 gpm)
1.5 gpm
1.0 gpm
0.5 gpm
41056* (2.2 gpm)
Insert Options
Washer 43118
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
43185
Handle
See KOHLER.com/
ServiceParts
Discontinued
Discontinued43185
58930-CP
Plug Button/
Cap
N/A
48695*
52546* Lever Insert
52622-CP (Chrome)
52623-H (Red) 52623-C (Blue)
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Widespread
Coralais
K-15261 K-15265
K-15262 K-15268 K-15269 K-15815 K-15816 K-15817 K-15850 K-15886
®
GP76672 (H) GP76671 (C)
GP76672 (H) GP76671 (C)
1105050* (2.2 gpm)
59619* (2.2 gpm) Female Threads
41007* (2.2 gpm) Male Threads
1.5 gpm
1.0 gpm
0.5 gpm
59620* (2.0 gpm)
41056* (2.2 gpm)
76892*
Insert Options
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
Washer 54646
See KOHLER.com/
ServiceParts
73264
23/4"
70572*
Handle Inserts
70579-0L
70306 Acrylic Bonnet
70731* (C) 70730* (H)
70577*
Discontinued
Discontinued
57068*
N/A
70505 (Red) 70504 (Blue)
N/A
70614*
N/A
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Cygnet
K-6762
GP77005-RP (H) GP77006-RP (C)
Discontinued
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
Discontinued
N/A
7
Widespread
Bathroom Sink Faucets
Widespread
Product Name
Devonshire
®
K-394
Fairfax
®
K-12265
Finesse
K-13328 K-13330 K-13335 K-13337 K-13338 K-13339 K-13340 K-13391 K-13392 K-13394 K-13395
Traditional
Finial
®
K-310
Flair
K-7433 K-7436 K-7438 K-7449 K-7481
Current
GP1092204 (H) GP1092203 (C)
Current
GP1092204 (H) GP1092203 (C)
GP30002 (H) GP30004 (C)
Current
GP1092204 (H) GP1092203 (C)
Valve/ Valvet
1990-2010
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
®
30127-BC (H) 30128-BC (C)
49/32"
Prior to 1990
GP30002 (H) GP30004 (C)
1103468* (1.5 gpm)
76963* (2.2 gpm)
(1.5 gpm)
79402* (2.2 gpm)
29614* (Rosespray)
1103470* (1.5 gpm)
1108527* (1.5 gpm)
Aerator Kit
Includes Washer,
Aerator and Nozzle
Insert Options
1104957 Laminar
1.5 gpm 1103116 Aerated
1139283 Laminar
1139282 Aerated
1.0 gpm
1068614 Spray
1068613 Spray
0.5 gpm
Washer 75442
Insert Options
1104546 Laminar
1.5 gpm 1097180 Aerated
1139285 Laminar
1139284 Aerated
1.0 gpm
1078456 Spray
1075455 Spray
0.5 gpm
Washer 79441
1105050*
(1.5 gpm)
59619*
(2.2 gpm)
Female Threads
1.5 gpm
1.0 gpm
0.5 gpm
41007*
(2.2 gpm)
55604
Insert Options
1104546 Laminar
1097180 Aerated
1139285 Laminar
1139284 Aerated
1078456 Spray
1075455 Spray
Washer 79441
30341* (Rosespray)
43185
Handle
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
1000440-CP
See KOHLER.com/
ServiceParts
43267* (Pair)
Plug Button/
GP1078439
2"
Cap
N/A
GP1077792* 1103119*
N/A
43152 (H) 43153 (C) (For 43267* Handles)
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Flair High Country
K-7435
Flair Centerspread
K-7411 K-7439
Forté
®
K-10272
Current
GP1092204 (H) GP1092203 (C)
GP30002 (H & C) (Knob Handle)
GP30002 (H) GP30004 (C) (Lever Handle)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1103463* (1.5 gpm)
41056*
(2.2 gpm)
43185
1.5 gpm
1.0 gpm
0.5 gpm
Insert Options
1104546 Laminar
1097180 Aerated
1139285 Laminar
1139284 Aerated
1078456 Spray
1075455 Spray
Washer 79441
70579-0L
70572*
(Insert)
(Lever)
40194-CP
40193 (Insert)
Discontinued
See KOHLER.com/
ServiceParts
N/A
Sidespray GP1021724*
See KOHLER.com/
ServiceParts
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
8
Bathroom Sink Faucets
Widespread
Product Name
Karbon
®
K-6274
Kelston
®
K-13491
Loure
®
K-14661 K-14662
Margaux
®
K-16232
Memoirs
®
K-454
Oblo
®
K-10086
Valve/ Valvet
Current
GP1092204 (H) GP1092203 (C)
GP1092204 (H) GP1092203 (C)
Current
GP1092204 (H) GP1092203 (C)
Current
GP1092204 (H) GP1092203 (C)
GP1092204 (H) GP1092203 (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1071965 (H) 1088996 (C)
Aerator Kit
®
Includes Washer,
Aerator and Nozzle
1151265
(Sprayhead)
1100416 (1.5 gpm)
Handle
See KOHLER.com/
ServiceParts
N/A
1138481 (2.2 gpm)
See KOHLER.com/
ServiceParts
1103468* (1.5 gpm)
1103464* (1.5 gpm)
1.5 gpm
1.0 gpm
0.5 gpm
1.5 gpm
1.0 gpm
0.5 gpm
1089003 (1.5 gpm)
Insert Options
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
Washer 75442
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 73737
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Plug Button/
Cap
N/A
N/A
N/A
N/A
N/A
N/A
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Widespread
Pinstripe
®
K-13132
Purist
®
K-14406 K-14407
K-14408 K-14410
Refinia
®
K-5317
Revival
®
K-16102 K-16104
Current
GP1092204 (H) GP1092203 (C)
Current
GP1092204 (H) GP1092203 (C)
Current
GP1092204 (H) GP1092203 (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
GP1092204 (H) GP1092203 (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
Prior to 1990
GP30002 (H) GP30004 (C)
1103468* (1.5 gpm)
1106716* (1.5 gpm)
1018475* (1.5 gpm VR)
1100416 (1.5 gpm)
1108235* (1.5 gpm)
57376* (2.0 gpm) 3/4" Male 27-Thread
1000952* (2.5 gpm) 13/16" 27-Thread
1.5 gpm
1.0 gpm
0.5 gpm
1.5 gpm
1.0 gpm
0.5 gpm
1.5 gpm
1.0 gpm
0.5 gpm
Washer 1108035
Insert Options
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
Washer 75442
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 78783
Insert Options
1104546 Laminar
1097180 Aerated
1139285 Laminar
1139284 Aerated
1078456 Spray
1075455 Spray
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
N/A
N/A
N/A
N/A
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
(H) = Hot (C) = Cold VR = Vandal-Resistant *Include the color or finish code after the part number when ordering.
9
Widespread
Bathroom Sink Faucets
Widespread
Product Name
Stillness
®
K-942
Taboret
®
K-8215
K-8211 K-8212
Trend
®
K-11810
Current
GP1092204 (H) GP1092203 (C)
Current
GP1092204 (H) GP1092203 (C)
Current
GP1092204 (H) GP1092203 (C)
Valve/ Valvet
1990-2010
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
30397-RP (H & C) (Knob Handle)
30397-RP (H) 30398-RP (C) (Lever Handle)
®
Prior to 1990
GP30002 (H) GP30004 (C)
Prior to 1990
GP30002 (H) GP30004 (C)
Includes Washer,
Aerator and Nozzle
1106493* (1.5 gpm)
1103470* (1.5 gpm)
1108527* (1.5 gpm)
1103469* (1.5 gpm)
41007* (2.2 gpm)
1105050* (1.5 gpm) Female Threads
59619* (1.5 gpm) Female Threads
Aerator Kit
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer 38820
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer 79441
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer 43118
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
1104546 Laminar
1097180 Aerated
1139285 Laminar
1139284 Aerated
1078456 Spray
1075455 Spray
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
Handle
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
GP21087-CP (Chrome) GP21094 (Clear) 21188 (Charcoal)
Obsolete
Plug Button/
Cap
N/A
N/A
N/A
GP30000
(Knob Handles)
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Triton
K-7435 K-7436 K-7437 K-7439 K-7416 K-7417 K-7419 K-7449
55172* (.5 gpm VR) 41056* (2.2 gpm) Male Threads
®
K-7465 K-7467 K-7468 K-7471 K-7472 K-7473 K-7476
GP77005-RP (H) GP77006-RP (C)
GP30002 (H & C) (Knob Handle)
GP30002 (H) GP30004 (C) (Lever Handle)
41007* (2.2 gpm)
50318* (0.5 gpm VR) 54927* (2.2 gpm)
50327* (0.5 gpm VR) 54928* (2.2 gpm)
50316* (2.2 gpm VR) 74122* (1.0 gpm VR)
59874* (2.0 gpm VR)
Use 58895-CP (Pair)
Use 58895-CP (Pair)
1000439-CP
1000442-CP
100048-CP
1000441-CP
Discontinued
52622-CP (Chrome)
52623-H (Red) 52623-C (Blue)
78868 (VR Wrench)
GP1021724* (Sidespray)
10
41056** (2.2 gpm)
41781* (1.5 gpm)
(H) = Hot (C) = Cold VR = Vandal-Resistant *Include the color or finish code after the part number when ordering.
Bathroom Sink Faucets
Centerset
Product Name
Alteo
®
K-45100
Alterna
K-6950
Archer
®
K-11075
Monoblock
Bancroft
®
K-10579
Bellhaven
®
K-11550
Centura
K-6882 K-6883
Valve/ Valvet
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
1152349 (H) 1152350 (C)
GP30082
®
GP30002 (H) GP30004 (C)
41056* (2.2 gpm)
1103460* (1.5 gpm)
1103462* (1.5 gpm)
1103463* (1.5 gpm)
Aerator Kit
Includes Washer,
Aerator and Nozzle
1100416 (1.5 gpm)
59620* (2.0 gpm)
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm Washer 78783
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer 43118
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer79441
41056* (2.2 gpm)
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Handle
See KOHLER.com/
ServiceParts
Discontinued
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
42352 (Clear) 42353 (Amber)
73082*
Plug Button/
Cap
N/A
42730* (For 73082 Handle)
1063732*
N/A
1060628*
GP42361
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
1033947* (Escutcheon)
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Centerset
Constellation
K-6960
Coralais
®
K-15635 K-15636 K-15637 K-15240 K-15241 K-15243 K-15640 K-15641 K-15643 K-15645
K-15850 K-15260
GP30002 (H) GP30004 (C)
GP76672 (H) GP76671 (C)
GP76672 (H) GP76671 (C)
41056* (2.2 gpm)
59619* (1.5 gpm)
59728* (2.0 gpm)
41056* (2.2 gpm)
Discontinued
73238
(Clear)
73238-SM
(Smoke)
70508-CP
115/16"
56449-CP
70731-0 (H) 70730-0 (C)
70572*
Discontinued
73238 (Clear) 73238-SM (Smoke)
1
1
1
/2"
15
/16"
N/A
70505 (Red)
70504 (Blue)
56523 (H) (Red) 56523 (C) (Blue)
N/A
70579-0L 70577*
(Handle Inserts)
70614*
70505 (Red) 70504 (Blue)
See KOHLER.com/
ServiceParts
78868 (VR Wrench)
See KOHLER.com/
ServiceParts
(H) = Hot (C) = Cold VR = Vandal-Resistant *Include the color or finish code after the part number when ordering.
11
Centerset
Bathroom Sink Faucets
Product Name
Coralais
®
K-15810 K-15885
K-15240-4 K-15240-7
Cygnet
K-6763
Devonshire
K-393
Centerset
Fairfax
®
K-12266
Finesse
K-13360
59619* (1.5 gpm)
59728* (2.0 gpm)
1105050* (1.5 gpm)
Aerator Kit
Includes Washer,
Aerator and Nozzle
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer 54646
Handle
76892* 78868 VR Wrench
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
70731-0 (H) 70730-0 (C)
57068*
See KOHLER.com/
ServiceParts
22372-7
(Black only)
Valve/ Valvet
GP76672 (H) GP76671 (C)
GP77005-RP (H) GP77006-RP (C)
®
Discontinued
®
GP77005-RP (H) GP77006-RP (C)
1100416 (1.5 gpm)
See KOHLER.com/
ServiceParts
Plug Button/
Cap
N/A
1004101-H* (H) 1004101-C* (C)
N/A
N/A
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
1033953*
GP77005-RP (H) GP77006-RP (C)
GP30002 (H) GP30004 (C)
1097764* (1.5 gpm)
1.5 gpm
1.0 gpm
0.5 gpm
41056* (2.2 gpm)
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 78783
See KOHLER.com/
ServiceParts
1000435-CP
GP1077791*
GP1078439 (Red & Blue)
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Flair
K-7401-FL K-7401-DB
K-7412 K-6212
Forté
®
K-10270
Kelston
®
K-13490
GP30002 (H) GP30004 (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
41056* (2.2 gpm)
59620* (2.0 gpm)
1103463* (1.5 gpm)
1100416 (1.5 gpm)
43267* (Pair)
Discontinued
43267* (Pair)
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
2"
2"
43144 (H) 43145 (C)
43144 (H) 43145 (C)
N/A
1060628*
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
12
(H) = Hot (C) = Cold VR = Vandal-Resistant *Include the color or finish code after the part number when ordering.
Bathroom Sink Faucets
Centerset
Product Name
Memoirs
K-452
Memoirs
K-452
Oblo
Monoblock
®
K-10085
Provence
K-14513 K-14514
Revival
®
K-16100
Refinia
®
K-5316
Stately
®
Classic
®
Valve/ Valvet
GP77005-RP (H) GP77006-RP (C)
1071965 (H) 1088996 (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
1152349 (H) 1152350 (C)
Aerator Kit
1103464* (1.5 gpm)
Includes Washer,
Aerator and Nozzle
1.5 gpm
1.0 gpm
0.5 gpm
1089003 (1.5 gpm)
1103469* (2.0 gpm)
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 73737
®
Handle
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
57068*
Plug Button/
Cap
N/A
N/A
N/A
57739-CP (H) 57738-CP (C)
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
N/A
N/A
1108235* (1.5 gpm)
57376*
(2.0 gpm)
3/4"- 27
Male
Threads
1000952* (2.5 gpm)
13/16"-27
Threads
1.5 gpm
1.0 gpm
0.5 gpm
1100416 (1.5 gpm)
Insert Options
1104546 Laminar
1097180 Aerated
1139285 Laminar
1139284 Aerated
1078456 Spray
1075455 Spray
Washer 1108035
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Centerset
Shoreham
K-10800
Taboret
K-8201
Trend
®
K-11800
/Flair
Triton
®
K-7401 K-7403 K-7404 K-7405 K-7406 K-7408 K-7409 K-7415 K-7474
30395-RP 30396-RP
41056* (2.2 gpm)
58895-CP (Pair)
N/A
See KOHLER.com/
ServiceParts
Discontinued
®
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
30395-RP (H) 30396-RP (C)
GP30002 (H) GP30004 (C)
41007* (2.2 gpm) 59874* (2.0 gpm VR)
1103469* (1.5 gpm)
41056* (2.2 gpm)
74122* (1.0 gpm VR) 41781* (1.5 gpm) 41056* (2.2 gpm) 50316* (3.0 gpm VR)
59620* (2.0 gpm) 59722* (2.0 gpm VR)
See KOHLER.com/
ServiceParts
GP20986-CP GP30000
15/8"
1000439-CP
1000438-CP
43267* Pair
1000442-CP
1000441-CP
Obsolete
38615-H-CP (H) 38615-C-CP (C)
N/A
52622-CP
52623-H (Red) 52623-C (Blue)
43144 (H) 43145 (C)
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
78868 VR Wrench
43267* (Pair)
(H) = Hot (C) = Cold VR = Vandal-Resistant *Include the color or finish code after the part number when ordering.
13
Single-Handle
Bathroom Sink Faucets
Product Name
Antique
K-138 K-139
Bol
®
K-11000
Cabriole
®
K-14616
Coralais
®
K-15182 K-15681
K-15191 K-15192 K-15198 K-15199
Valve/ Valvet
1170273
®
1104109*
(1.5 gpm)
1000739
GP1017426 1103469*
GP77548
(1.5 gpm)
1103469* (1.5 gpm)
GP30413
Aerator Kit
Includes Washer,
Aerator and Nozzle
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer 41163
N/A
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer 43118
Insert Options
1.5 gpm
1.0 gpm
0.5 gpm
Washer 43118
1105050*
(1.5 gpm)
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
Handle
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
30423*
71520
Plug Button/
Cap
N/A
N/A
834705*
76712*
76712-A (Red & Blue)
71521
Other Common
Parts
79352* (Escutcheon)
89477* (Skirt)
79352* (Escutcheon)
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Single-
Handle
Fairfax
K-12181 K-12182 K-12183
Forté
K-10215 K-10217
Karbon
K-6268
Loure
K-14661
Margaux
K-16230 K-16231
Paladar
K-14516 K-14517
®
®
®
®
®
GP77548 78205*1097762*
GP1017426 1103459*
(1.5 gpm)
(1.5 gpm)
1090948 1151265
1090948 1138481
1066371 1103468*
(1.5 gpm)
77096
1.5 gpm
1.0 gpm
0.5 gpm
1.5 gpm
1.0 gpm
0.5 gpm
(1.5 gpm)
(2.2 gpm)
1.5 gpm
1.0 gpm
0.5 gpm
1103469* (1.5 gpm)
Insert Options
1104546 Laminar
1097180 Aerated
1139285 Laminar
1139284 Aerated
1078456 Spray
1075455 Spray
Washer 1005256
Insert Options
1104546 Laminar 1097180 Aerated
1139285 Laminar
1139284 Aerated
1078456 Spray
1075455 Spray
Washer 79441
Insert Options
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray
1068613 Spray
Washer 75442
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
73819*
N/A
N/A
N/A
N/A
Discontinued
78050* (Escutcheon)
1051514* (Escutcheon)
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
14
*Include the color or finish code after the part number when ordering.
Faucet Faucet Details
Bathroom Sink Faucets
Single-Handle
Product Name
Panache
™
K-18140
Purist
®
K-14402 K-14404
Stance
®
K-14760
Symbol
®
K-19480 K-19774 K-19909
Toobi
™
K-8959 K-8990
Aerator Kit
(1.5 gpm)
(1.5 gpm)
1103467* (1.5 gpm)
Includes Washer,
Aerator and Nozzle
(1.5 gpm)
Valve/ Valvet
®
GP1017426 1103468*
GP1017426 1103466*
1126312 1124439*
GP1017426
1162061
1.5 gpm
1.0 gpm
0.5 gpm
1.5 gpm
1.0 gpm
0.5 gpm
1.5 gpm
1.0 gpm
0.5 gpm
N/A
Insert Options
1104957 Laminar
1103116 Aerated
1139283 Laminar
1139282 Aerated
1068614 Spray 1068613 Spray
Washer 75442
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 38820
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 871642
Handle
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Plug Button/
Cap
834705*
N/A
N/A
836939
N/A
Other Common
Parts
77945* (Decorator Ring)
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Insert
3013333 (White) 3010708 (Green) 3013335 (Black)
Handle
Single-
Vas
®
K-11010
1000739
N/A
See KOHLER.com/
ServiceParts
N/A
1000110* (Skirt)
89137* (Trim Ring)
*Include the color or finish code after the part number when ordering.
15
Wall-Mount
Bathroom Sink Faucets
Product Name
Antique
K-T154
K-149 K-159
Alterna K-6971
Constellation Triton II
K-7445 K-7450
Falling Water
K-T196 K-T197 K-T198 K-T199
Aerator Kit
Valve/ Valvet
GP77005-RP (H) GP77006-RP (C)
GP30002 (H) GP30004 (C)
GP30002 (H) GP30004 (C)
®
GP77548
GP30002 (H & C)
®
Includes Washer,
Aerator and Nozzle
1105579* (1.5 gpm)
41056* (2.2 gpm)
(2.2 gpm)
41007* (2.2 gpm)
1013355* (1.5 gpm)
Handle
See KOHLER.com/
ServiceParts
Discontinued41007*
1000439-CP 34400*
Discontinued
Plug Button/
Cap
N/A
Discontinued
N/A
Other Common
Parts
See KOHLER.com/
ServiceParts
37668* (Soap Dish)
See KOHLER.com/
ServiceParts
(Ice Water Knob)
Finesse
K-13322
Wall-Mount
Flair
K-8040
Finial® Tradtional
K-T343 K-T344
Fountainhead
K-2443
See KOHLER.com/
1106493* (1.5 gpm)
GP30002 (H & C)
GP30002 (H) GP30004 (C)
GP77005-RP (H) GP77006-RP (C)
®
41056* (2.2 gpm)
(2.2 gpm)
1103471* (1.5 gpm)
1001960*1070730
ServiceParts
43267* (Pair)
100043*41007*
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
2"
N/A
43144 (H) 43145 (C)
GP1078439 (Red & Blue)
N/A
N/A
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
16
Institutional
K-7480 K-7481 K-7485 K-7486
30132 (Rebuilding Kit)
34118-BC
N/A
30032-CP (Pair)
See KOHLER.com/
ServiceParts
(H) = Hot (C) = Cold *Include the color or fi nish code after the part number when ordering.
Faucet Faucet Details
Bathroom Sink Faucets
Wall-Mount
Product Name
Institutional
K-7482 K-7483
Karbon® Single-Handle
K-6269
Two-Handle
K-T6277
Laminar
K-T945 K-T14419
Memoirs® Stately
K-T448
Aerator Kit
Valve/ Valvet
1090948 1151265*
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
®
30132 (Rebuilding Kit)
Includes Washer,
Aerator and Nozzle
N/A
(1.5 gpm)
1021767*
(1.85 gpm)
1109008* (1.5 gpm)
Handle
N/A
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Plug Button/
Cap
30032-CP (Pair)
N/A
N/A
N/A
Other Common
Parts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Oblo
®
K-10087
Purist
®
K-T14412 K-T14413 K-T14414 K-T14415 K-T14416 K-T14417
Revival
®
K-T16106 K-T945
Stillness
K-T944
Trend
®
K-11820
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
®
GP77005-RP (H) GP77006-RP (C)
30140-RP (H & C)
1106493* (1.5 gpm)
1074274*
1106493* (1.5 gpm)
1103471* (1.5 gpm)
1.5 gpm
1.0 gpm
0.5 gpm
41056* (2.2 gpm)
Insert Options
1053532 Laminar
1053576 Aerated
1139287 Laminar
1139286 Aerated
1104405 Spray
1049937 Spray
Washer 38820
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
20984 (Acrylic)
GP20986-CP (Chrome)
N/A
N/A
N/A
N/A
GP30000
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
See KOHLER.com/
ServiceParts
Wall-Mount
(H) = Hot (C) = Cold *Include the color or fi nish code after the part number when ordering.
58895-CP (Pair)
See KOHLER.com/
ServiceParts
17
Single-Handle
Rite-Temp® Pressure-Balancing Valves
Bath/Shower Faucets
Single-
Handle
K-304
1/2"
May have stops
1083638
Stops (1985-2008)
77148
GP500520 (Cartridge)
GP77759 (Cap)
Rite-Temp Pressure-Balancing Valves with Diverter
K-11748 K-305 (Prior to 2009)
1/2"
May have stops
1083638
Stops (1985-2008)
77148
GP500520 (Cartridge)
GP77759 (Cap)
Handle and Trim Styles 1998-Present:
K-2971 K-306
3/4"
May have stops
79701
1081410 (Diverter for K-11748)
1144925 (Cartridge)
89773 (Diverter for K-305 prior to 2009)
85500 (Cap)
IV Georges Brass
®
K-T6808 K-T6809 K-T6810
Margaux
K-T16225 K-T16233 K-T16234 K-T16235
®
Alterna
K-6900 K-6902 K-6904
MasterShower
K-T9492
Antique
K-129 K-130 K-131 K-132
®
K-133 K-134 K-T130 K-T132 K-T134
Memoirs Stately
K-T461 K-T462 K-T463
®
Handle and Trim Styles Prior to 1998:
Product Name
Centura
K-6872 K-6873 K-6874 K-6875
GP30082 (Repair Kit)
Archer
®
K-T11077 K-T11078
Memoirs Classic
K-T464 K-T465 K-T466
Valve/ Valvet
Bancroft
K-T10581 K-T10582 K-T10583 K-T10584
Oblo
K-T10055 K-T10056 K-T10057
®
(Cartridge)
Bellhaven
®
K-T11552 K-T11553
Pinstripe
®
K-T13133 K-T13134 K-T13135
Coralais
®
K-T15601 K-T15603 K-T15611 K-T15613 K-T15621
Purist
®
K-T14420 K-T14421 K-T14422 K-T14423 K-T4501
Devonshire
®
K-T395 K-T396 K-T397
®
Revival
K-T16113 K-T16114 K-T16115 K-T16116 K-T16117
Fairfax
®
®
®
K-T12007 K-T12014 K-T12021
Stillness
K-T948 K-T949 K-T950
®
Handle
42352 (Clear)
Lever Handle Discontinued
42353 (Amber)
Finial
®
Traditional
K-T309 K-T312 K-T313
Symbol
K-T18488 K-T18489 K-T18490
®
Plug Button/
GP42361GP500520
Forté
®
K-T10274 K-T10275 K-T10276 K-T10277
Cap
18
Faucet Faucet Details
Bath/Shower Faucets
Single-Handle
Product Name
Coralais
®
K-15134 K-15143 K-15155
Coralais
K-15101 – K-15108 K-15110 – K-15112 K-15114 – K-15116 K-15120 – K-15129 K-15177 K-15301 K-15303 K-15305 K-15307 K-15310 K-15312 K-15314
Flair II
K-6908-7A (Lever) K-6908-8A (Knob)
K-15316 K-15326 K-15328
GP71969 (Plastic Stem)
GP30413
Valve/ Valvet
(Brass Stem)
®
(Cartridge)
GP500520 (Cartridge)
GP500520 (Cartridge)
71904*
50349-0L GP43146 43147GP77759
Handle
71840GP500520
30316
Plug Button/
Cap
71909
71909GP77886
Handle
Single-
Niedecken
K-7027
K-7217
K-7028
K-7224
K-7076
K-7245
K-7205
K-7248
K-7215
K-7300
K-7216
K-7301
(Industrial Exposed Valve)
K-7250 K-7244 K-7256
Paladar
K-T14540 K-T14541 K-T14542
Taboret
®
K-T8224 K-T8225 K-T8226 K-T8227 K-T8228 K-T8229
GP30090
(Repair Kit)
GP77759
GP77759
GP77759
21502-A (Yoke)
30092 (For Seized Handle)
GP500520
GP500520 (Cartridge)
GP500520 (Cartridge)
23063-CP
Discontinued
Discontinued
30750* 92414*
42674*
22920-CP
N/A
N/A
Discontinued
N/A
N/A
Triton
®
K-T6908 K-T6910 K-T6912 K-T6913 K-T6914
GP77759
*Include the color or finish code after the part number when ordering.
GP500520 (Cartridge)
52631-CP
52620-CP
52622 (Chrome)
52623-A (Black)
19
Custom Showering
Thermostatic Valves
Bath/Shower Faucets
Controls water temperature ONLY. Does NOT turn water on or off.
Custom
Showering
IV Georges Brass
K-T10680
Current
K-679-KS (1/2") K-669-KS (3/4")
Prior to 2006
K-402-K (1/2")
Used with trim only
MasterShower
®
1021119 (Valve)
1032546 (Stop Assembly)
1046104 (Valve)
79146 (Stop)
K-400-K (3/4")
78913 (Valve)
Traditional
®
Antique
K-T10110
Bancroft
K-T10593
®
Devonshire
K-T10357
®
Finial
®
K-T10301
Forté
®
K-T10359
Margaux
K-T16239
®
MasterShower
K-T10182
Memoirs Stately
K-T10421
®
Memoirs Classic
K-T10426
Oblo
®
K-T10069
Pinstripe
K-T13173
®
Stacked Thermostatic Valves with Volume Control
Current
K-670-KS (1/2") K-680-KS (3/4")
GP77006* (1/2" Valve)
1032546 (Stop Assembly)
1045321
1046104 (Valve)
(3/4" Valve)
Purist
®
K-T14488
Prior to 2006
K-404-K (1/2")
79146 (Stop)
K-401-K (3/4")
Revival
K-T16175
®
Stillness
K-T10940
Used with trim only
®
MasterShower
Symbol
K-T18090
®
®
1021121 (Valve)
1021119 (Valve)
78948 (Valve)
78913 (Valve)
20
Bancroft
K-T10594
Finial Traditional
K-T10302
MasterShower
K-T10183
Memoirs Stately
K-T10422
Memoirs Classic
K-T10427
Purist
K-T14489
Revival
K-T16176
Stillness
K-T10941
Faucet Faucet Details
Bath/Shower Faucets
Volume Control Valves (Usually Multiple in Showers)
Custom Showering
IV Georges Brass
®
K-T10681
Antique
K-T10111
Current
K-671-KS (1/2") K-681-KS (3/4")
Bancroft
K-T10596
GP77006-RP* (1/2" Valve)
1045321 (3/4" Valve)
®
Devonshire
K-T10358
Prior to 2006
K-406 (1/2")
Used with Trim Only
MasterShower
®
1021121 (1/2" Valve)
K-403 (3/4")
Showering
78948 (3/4" Valve)
Traditional
®
Finial
®
K-T10303
Forté
®
K-T10360
Margaux
K-T16241
®
MasterShower
K-T10184
Custom
Memoirs
®
Stately
K-T10423
Transfer Valves
IV Georges Brass
K-T10682
Memoirs Classic
K-T10428
Antique
K-T10113
Oblo
®
K-T10067
Current
K-728-K (1/2") K-672-K
Bancroft
K-T10595
Pinstripe
K-T13174
1145688 (Valve)
Devonshire
K-T376
Purist
®
®
K-T14490
Revival
®
K-T16177
Stillness
K-T10943
®
Symbol
K-T18091
®
Prior to 2006
K-405 K-687-K
78896 (Valve)
K-407
75244 (Valve)
Fairfax
K-T12189
Finial Traditional
K-T10304
Forté
K-T10290
Margaux
K-T16242
MasterShower
K-T10185
Memoirs Stately
K-T10424
Memoirs Classic
K-T10429
Oblo
K-T10058
Pinstripe
K-T13175
Purist
K-T14491
Revival
K-T16178
Stillness
K-T10944
Symbol
K-T18491
21
Wall-Mount
Bath/Shower Faucets
Wall-Mount Bath Faucets
The majority of these style faucets use the K-302-K or the K-303-K valve system.
Product Name
IV Georges Brass
K-6806
K-6804
Wall-Mount
K-6805
Alterna
K-6831 K-6929 K-6962 K-6930 K-6931 K-6932
Antique
K-119 K-120 K-122
K-6807
K-123 K-124
K-302-K
Wall-Mount Valve
®
K-6933 K-6934 K-6944 K-6962 K-6995
Valve/ Valvet
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
Prior to 1990 GP30002 (H & C) (Knob Handle)
GP30002-RP (H) GP30004-RP (C) (Lever Handle)
GP77005-RP (H) GP77006-RP (C)
®
Prior to 1990
GP30002 (H) GP30004 (C)
30127-BC (H) 30128-BC (C)
1/4-Turn
GP77005-RP (H) GP77006-RP (C)
Full-Turn
Prior to 1990 GP30002 (H) GP30004 (C)
Diverter Diverter Handle
N/A
42011*
K-303-K
Wall-Mount Valve with Diverter
42011* (Diverter)
Handle
N/A N/ASee KOHLER.com/ServiceParts
20364*
29718-AU (Gold)
29718-BG (Brushed Gold)
50282* (C) 50281* (H)
52701*
1/4-Turn
GP77005-RP (H) GP77006-RP (C)
Full-Turn
Prior to 1990 GP30002 (H) GP30004 (C)
Plug Button/
Cap
40343*
Discontinued
1120993*
22
Aquaric
K-10106 K-10116 K-10120
7
/8"
2
30137-CP 23070 1020053-D*
21
3
/32"
N/A N/A N/A
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
57024*
1020053-H* 1020053-C*
52722* (Insert)
N/A
Faucet Faucet Details
Bath/Shower Faucets
Wall-Mount
Product Name Valve/Valvet
Bravura
K-6838 K-6840 K-6842 K-6845
Cirrus
K-7901 K-7905 K-7907
Constellation
K-7006
Coralais
®
K-T15201 K-T15202 K-T15204 K-T15211 K-T15214 K-T15221 K-T15224
K-15226 K-15801 K-15802 K-15803 K-15851
K-T15225 K-T15231 K-T15235 K-T15401 K-T15411 K-T15431
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP30002-RP (H) GP30004-RP (C)
GP76672 (H) GP76671 (C)
Prior to 1990 GP30002 (H & C)
70096 (Stem Extension)
Diverter Diverter Handle
4
4
42011*
42011*
70424
21
/32"
70462
9
/20"
N/A
N/A
20364*
Discontinued
73238 (Clear) 73238-SM (Smoke)
15
/16"
1
Handle
48691*
52700* Discontinued
Discontinued Discontinued
73264 (Acrylic)
23/4"
Plug Button/
Cap
Discontinued
N/A
N/A
70505 (H) 70504 (C) (For large handle)
70252 (For diverter handle)
Wall-Mount
Cygnet
K-6758 K-6759
Finesse
K-13363 K-13367
GP77005-RP (H) GP77006-RP (C)
GP30002 (H) GP30004 (C)
42011*
Discontinued
N/A N/A
70306 (Bonnet for Lever)
Discontinued
1007375
Discontinued
Discontinued Discontinued
70593* (Brass Insert)
70591* (Ceramic Insert)
Discontinued (Wood Insert)
Discontinued (Acrylic Insert)
Discontinued
1000440-CP
N/A
N/A
GP1078439 (Red & Blue)
Flair
K-7004 K-7010 K-7014 K-7034 K-7226
GP77005-RP (H & C)
Prior to 1990 GP30002 (H) GP30004 (C)
42011* 20364*
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
GP43146 43152 (H)
25/8"
Discontinued
43153 (C) (For GP43146)
23
Wall-Mount
Bath/Shower Faucets
Product Name
Flair II
K-7004-7A K-7004-8A K-7010-7A K-7014-7A K-7014-8A K-7034-7A K-7034-8A K-7226-7A K-7226-8A K-7744-7A K-7744-8A K-7751-7A K-7751-8A
Pillows
®
K-7951
Trend
®
K-11606 K-11612 K-11616 K-11620
Valve/ Valvet
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
21076 (Stem Assembly)
Plug Button/
Cap
43152 (H) 43153 (C)
Discontinued
50595*
Handle
25/8"
Discontinued
58895-CP (Pair) (Chrome)
50349-0L (Insert)
®
Diverter Diverter Handle
42011* 20364* GP43146
N/A N/A N/A
20868-CP 20860-CP
GP20986-CP (Chrome)
20984 (Acrylic)
K-11608
Wall-Mount
K-11614 K-11618 K-11622 K-11638 K-11730
Triton
®
K-7004 K-7010 K-7014 K-7022 K-7034 K-7036 K-7226 K-7234 K-7735 K-7744 K-7751
GP30119 (H & C)
GP77005-RP (H) GP77006-RP (C) (All Handles)
GP30002 (H & C) (Knob Handle)
GP30002 (H) GP30004 (C) (Lever Handle)
5
/8"
1
30467
N/A
23070 GP43146 (Acrylic)
Discontinued
GP21087-CP (Chrome) GP21094 (Acrylic)
1
/8"
2
57746-CP
(Chrome)
25/16"
5
/8"
2
1000439-CP
52641-CP
52638-CP
1116314-CP
57743 (Red) 57744 (Blue)
GP30000 (Hot, Cold & Diverter)
43152 (H) 43153 (C)
52622-CP
52623-H (Red Hollow Cap)
52623-C (Blue Hollow Cap)
52623-A (Black Hollow Cap)
24
Triton II
K-7252 K-7254 K-7258
GP30002 (H) GP30004 (C)
1020053-H 1020053-C
N/A N/A N/A
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
Faucet Faucet Details
Bath/Shower Faucets
Wall-Mount
Product Name
Triton® II
K-7004-T K-7010-T K-7014-T K-7022-T K-7034-T K-7043-T K-7227-T K-7234-T
K-7042 K-7045 K-7047
Valve/ Valvet
GP30002 (H) GP30004 (C)
20242-BC 22862-BC
®
Diverter Diverter Handle
42011*
23064*
N/A N/A
1041140-CP (2-Handle Kit)
1041141-CP (3-Handle Kit)
Handle
41981-H-CP (H) 41981-C-CP (C) 41981* (Plain)
Plug Button/
Cap
N/A
Wall-Mount
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
25
Deck-Mount
Bath/Shower Faucets
Deck-Mount Bath Faucets
IV Georges
Brass
®
K-T6906
K-T6915
K-300-K ½" High-Flow Valve
K-301-K ¾" High-Flow Valve
(1/2" Valve)
1/4 Turn
GP77005-RP (H) GP77006-RP (C)
Antique
K-T125
K-T135
Bancroft
K-T10585
K-T10587
K-T10592
®
(3/4" Valve)
1/4 Turn
1000187 (H) 1000188 (C)
®
Coralais
K-T15290
K-T15294
Prior to 1990
Full Turn
GP30002 (H) GP30004 (C)
Devonshire
K-T387
K-T398
K-T413
®
Diverter
1053358 (Diverter)
Fairfax
®
K-T12885
K-T12887
K-438-K
½" High-Flow Valve with Diverter
(1/2" Valve)
1/4 Turn
GP77005-RP (H) GP77006-RP (C)
Forté
K-T10278
K-T10291
K-T10292
®
Finial® Traditional
K-T314
K-T333
Kelston
K-T13494
Other Diverter Option K-9530 (Deck-Mount)
74392 (Diverter)
Prior to 1990
Full Turn
GP30002 (H) GP30004 (C
Loure
®
®
K-14675
Margaux
®
K-T16236
K-T16237
K-T16248
Product Name
IV Georges Brass
®
K-6905
Alterna
K-6504 K-6926
Deck-Mount
K-6929 K-7978
K-T6501 K-6942 K-7976 K-7977
®
Memoirs
K-T428 K-T467 K-T469
GP77005-RP (H) GP77006-RP (C) (1/2")
GP77005-RP (H) GP77006-RP (C) (1/2")
Oblo
K-T10059
K-T10068
Valve Cartridge
GP77006-RP (C)
GP30002 (H) GP30004 (C)
Prior to 1990
GP30002 (H & C) (Square/Cube Handle)
®
1000188 (H) 1000187 (C) (3/4")
Pinstripe
K-T13140
K-T13151
1000188 (H) 1000187 (C) (3/4")
®
Diverter
500452 (Rebuild Kit)
54992 (Long Stem)
®
Purist
K-T14428 K-T14429
59239 (Rebuild Kit)
Discontinued
Revival
K-T16119
K-T16122
K-T16124
40343*
40343*
®
Stillness
K-T954
K-T955
Handle
21682*
Discontinued (Acrylic Cube)
®
Discontinued (Lever)
Discontinued (Lever)
Stance
K-14774
K-14775
®
®
Taboret
K-T8230
K-T8235
Plug Button/
Cap
N/A
N/A
N/A
K-T8232
K-T8238
Stream Breaker
42232*GP77005-RP (H)
N/A
38808
26
Prior to 1990
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
Faucet Faucet Details
Bath/Shower Faucets
Deck-Mount
Product Name
Antique
K-103 K-104 K-109 K-110
K-125
Bravura
K-6842 K-6843 K-6949
Valve Cartridge
GP77005-RP (H) GP77006-RP (C)
1000188 (H) 1000187 (C)
GP77005-RP (H) GP77006-RP (C) (1/2")
GP30002 (H & C)
30138-CP (H) 30137-CP (C)
1000188 (H) 1000187 (C) (3/4")
Diverter
50281* (H) 50282* (C)
N/A N/A N/A
50281* (H) 50282* (C)
N/A
59239 (Rebuild Kit)
54992 (Long Stem)
Handle
1120993* (Lever)
48691*
1120993*
57024* (Oval)
Plug Button/
Cap
52722* (Oval Inserts)
48687*
Stream Breaker
42232*
N/A
Cirrus
K-7902 K-7908 K-7909 K-7910
Coralais
K-15295 K-15296
K-15290 K-15291 K-15708 K-15806 K-15807 K-15851
K-7913 K-7915 K-7923 K-7926
®
K-15856 K-15857 K-15880 K-15881 K-15882 K-15883
Prior to 1990
1000188 (H) 1000187 (C)
GP76672 (H) GP76671 (C)
GP77005-RP (H) GP77006-RP (C)
54992 (Long Stem)
N/A
N/A
73264 (Acrylic Knob)
70572*
Discontinued
Discontinued
70306 (Bonnet)
23/4"
Discontinued
73264 (Acrylic Knob)
Discontinued
3
/4"
2
70579-0L 70577*
Handle Inserts
N/A
70505 (H) 70504 (C)
70505 (H) 70504 (C)
N/A
70614*
38808
Deck-Mount
38808
38808
57068* (Euro Handle)
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
70731-0* (H)
70730-0 (C)
N/A
27
Deck-Mount
Bath/Shower Faucets
Product Name Valve Cartridge
Cygnet
K-6766
Finial
®
K-T614
Flair II
K-7019
Pillows
K-7936 K-7938 K-7963 K-7964
Art
GP77005-RP (H) GP77006-RP (C) (1/2")
1000188 (H) 1000187 (C)
1000188 (H) 1000187 (C)
GP30002 (H & C)
Prior to 1990
1000188 (H & C)
1000188 (H) 1000187 (C) (3/4")
Diverter
Discontinued
N/A
59239 (Rebuild Kit)
59239 (Rebuild Kit)
Discontinued
Discontinued
1000499-CP (Lever)
Handle
GP43146 (Rebuild Kit)
Discontinued
49155*
75711* (Left) 75645* (Right)
25/8"
50349-0L* (Lever Insert)
Plug Button/
Cap
N/A
N/A
43152 (H) 43153 (C)
Stream Breaker
Discontinued
38808
38808
38808
Provence
K-14520
Deck-Mount
Revival
®
K-16119 K-16122 K-16124
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
59239 (Rebuild Kit)
N/A
54992 (Long Stem)
70624-0 (White)
76153* 58742*
75143*
N/A
38808
N/A
58744
N/A
28
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
Faucet Faucet Details
Bath/Shower Faucets
Deck-Mount
Product Name Valve Cartridge
Seawall System K-7926
Taboret
®
K-7030-ZY
K-8230 K-8235 K-8238
Triton
®
K-7024 K-7030
1000188 (H) 1000187 (C)
GP30002 (H) GP30004 (C)
GP77005-RP (H)
GP77006-RP (C)
1000188 (H) 1000187 (C) (3/4")
Diverter
59239 (Rebuild Kit)
Discontinued
54992 (Long Stem)
N/A
Handle
48691*
See KOHLER.com/ServiceParts
Discontinued
1000439-CP73620
Discontinued
1000442-CP
Plug Button/
Cap
48687*
57330* 38808
N/A
52622-CP
Stream Breaker
N/A
N/A
38808
GP77005-RP (H) GP77006-RP (C) (1/2")
GP30002 (H) GP30004 (C)
1000438-CP 1000441-CP
1000499-CP (Lever)
50349-0L* (Lever insert)
GP43146
25/8"
52623-H (Red) 52623-C (Blue)
43152 (H) 43153 (C)
Deck-Mount
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
29
Kitchen Faucets
Kitchen Faucets
Kitchen Faucets
Pages 36-38
Pages 36-38
Pages 34-36
Page 35, 38
If there is a leak from the base of the spout, kit GP30420 may need to be replaced along with the valve.
Pullout
Single-handle faucet with sprayhead that pulls out towards you.
Pull-Down
Faucet with sprayhead that pulls down towards the sink.
Single-Handle
The handle may be located on the top or side of the faucet. Faucet may have a sidespray next to the faucet. Faucets with a sidespray always have an internal diverter. If the sidespray is not working, it is most likely the diverter malfunctioning.
Remote Valve
Faucet that has the handle located to the side of the spout. Faucets may have a pull-down sprayhead or sidespray.
Common ValvesFaucet Types
GP77548
1170273 (Antique only – See page 31)
If there is dripping from the spout, replace the faucet valve.
GP1016515 GP1017426
GP1093674 1090948
GP30420 O-Ring Kit (See pages 34-35 to see if this is required.)
Suggest replacing with valve, if applicable.
Pages 38-39
Page 33
Pages 31-34
Page 33, 37
Common Sidesprays
Wall-Mount
Faucet that is mounted to the wall. Most have two handles.
Bridge
Two-handle faucet which is raised off the deck. These faucets may have a sidespray. If the sidespray is not working, it is most likely the diverter inside the faucet that is malfunctioning.
Two-Handle
Two-handle faucets come with or without an escutcheon. These faucets may have a sidespray. If the sidespray is not working, it is most likely the diverter inside the faucet that is malfunctioning.
Single-Hole, Two-Handle
These faucets may have a sidespray. If the sidespray is not working, it is most likely the diverter inside the faucet that is malfunctioning.
Common Miscellaneous Kitchen Parts
Full Turn
GP30002 (H) GP30004 (C)
UltraGlide 1/4 Turn
GP1092204 (H) GP1092203 (C)
1/4 Turn
GP77005-RP (H) GP77006-RP (C)
GP76672 (H) GP76671 (C)
30
1011130* (Includes hose and holder)
1021724* (Sprayhead with Hose) 1021728* (Holder)
1148477* (Sprayhead) 1141915 (Hose) 1132472* (Holder)
For individual kitchen faucet details, see pages 31-39.
1088395* (Sprayhead) 1088396 (Hose) 1087232 (Holder)
1023391* (Stopper) 1023393* (Flange)
41398* (Strainer) 87404 (1.5 gpm Filter)
87406 (0.6 gpm Filter)
Faucet Faucet Details
Kitchen Faucets
Two-Handle
Product Name
Antique
K-117 K-118 K-147 K-148 K-158
Alterna
K-6973 K-6974
K-6972
Coralais
®
K-15251 K-15253
Valve/ Valvet
Current
GP1092204 (H) GP1092203 (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
GP30002 (H & C)
GP77005-RP (H) GP77006-RP (C)
GP76672 (H) GP76671 (C)
Diverter
®
78444
GP75878
Discontinued Discontinued
78444
78444
Aerator
36686*
(White) 30456-CP (Black) (Swinger)
30455-CP (White) 30456-CP (Black) (Swinger)
40106* (2.5 gpm)
41056* (Male 2.2 gpm)
Handle
50281* (H) 50282* (C)
73238 (Clear) 73238-SM (Smoke)
1120992*
Discontinued30455-CP
KOHLER.com/ServiceParts
115/16"
See
K-253 K-258 (Ceramic Inserts)
70508-CP
Plug Button/
Cap
N/A
42728* (Ceramic) 42730* (Brass)
70505 (H) 70504 (C)
Sidespray
1011130* (Sidespray with Hose and Holder)
1021724* (Sidespray with Hose)
34329* (Holder)
1021724* (Sidespray with Hose)
34329* (Holder)
Other
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
Two-Handle
K-15255 K-15256 K-15258 K-15259
K-15255-P K-15259-P K-15834-K K-15836-K
Laundry Faucet
K-15270 K-15271
Coralais Decorator
K-15888 K-15889
GP76672 (H) GP76671 (C)
GP76672 (H) GP76671 (C)
GP76672 (H) GP76671 (C)
GP77005-RP (H) GP77006-RP (C)
59619* (Female
1.5 gpm)
500476* (2.2 gpm VR)
Insert Options
1054432
1.5 gpm
41056* (2.2 gpm)
N/A
78444
N/A N/A
78444
GP75878
41056* (2.2 gpm)
76892* (2.2 gpm)
1031237*
(2.2 gpm)
Insert Options
1.5 gpm
1054425
73264 (Acrylic Knob)
73238 (Clear) 73238-SM (Smoke)
Discontinued
Discontinued
3
2
/4"
73264 (Acrylic)
23/4"
70508-CP 70505 (H)
115/16"
See
KOHLER.com/ServiceParts
70456 (Acrylic Bonnet for Lever)
70275 (Acrylic)
70456 (Acrylic Bonnet for Lever)
70505 (H) 70504 (C)
70504 (C)
N/A
1033012 (Sidespray with Hose)
1037431*
(Holder)
N/A
1021724* (Sidespray with Hose)
1021724* (Sidespray with Hose)
1037431*
(Holder)
30456-CP (Swinger) (Black)
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
31
Two-Handle
Kitchen Faucets
Product Name
Constellation
K-7765
Essex
®
K-8762 K-8763
Two-Handle
Fairfax
®
K-12230 K-12231
Finial
®
K-377
Valve/ Valvet
GP30002 (H) GP30004 (C)
GP77005-RP (H) GP77006-RP (C)
Current
GP1092204 (H) GP1092203 (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
Current
GP1092204 (H) GP1092203 (C)
®
Diverter
Discontinued
GP75878
GP75878
78444
Aerator
41056* (2.2 gpm)
41056* (2.2 gpm)
Insert Options
1.5 gpm
(2.2 gpm)
Insert Options
1.5 gpm
74405* (2.2 gpm)
1054423
1054421
1000434-CP
KOHLER.com/ServiceParts
KOHLER.com/ServiceParts
Handle
See
See
Discontinued
Plug Button/
Cap
N/A
N/A
GP107779279402*
Sidespray
1021724* (Sidespray with Hose)
34329* (Holder)
1021724* (Sidespray with Hose)
1037431* (Holder)
1021724* (Sidespray with Hose)
1037431* (Holder)
1021724* (Sidespray with Hose)
Other
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
1990-2010
GP77005-RP (H) GP77006-RP (C)
Finesse
®
K-13393 K-13580
Flair II
K-7776-DB K-7776-FCV K-7779-FCV
K-7771 GP30002
GP30002 (H) GP30004 (C)
GP77005-RP (H) GP77006-RP (C)
Prior to 1990
GP30002 (H) GP30004 (C)
(H & C)
GP75878
N/A
78444
GP75878
Insert Options
1.5 gpm
(1.5 gpm)
41056* (2.2 gpm)
30455-CP (White) 30456-CP (Black) (Swinger)
1054432
See
KOHLER.com/ServiceParts
1000440-CP59619*
43267* (Pair)
See
N/A
GP1078439 (H & C)
43152 (H) 43153 (C)
1037431* (Holder)
N/A
1021724* (Sidespray with Hose)
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
2"
34329*
(Holder)
See
KOHLER.com/
ServiceParts
32
Flair
K-7765-FVC K-7771-FVC
GP77005-RP (H) GP77006-RP (C)
78444
41056* (2.2 gpm)
43267* (Pair)
43152 (H) 43153 (C)
1021724* (Sidespray with Hose)
2"
34329* (Holder)
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
Swinger 30455-CP (White) 30456-CP (Black)
Faucet Faucet Details
Kitchen Faucets
Two-Handle
Product Name
Flair
K-7765-8A K-7771-8A K-7776-8A K-7779-8A
Forté
®
K-10445
HiRise
®
K-7337
Parq® Bridge
K-6130 K-6131
Bridge
Purist
®
K-7547 K-7548
Revival
®
K-16109 K-16111
K-7341
Valve/ Valvet
GP77005-RP (H) GP77006-RP (C)
Current
GP1092204 (H) GP1092203 (C)
1990-2010
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
Current
GP1092204 (H) GP1092203 (C)
Diverter
®
78444 41056*
GP75878
N/A
GP75878
GP75878
78444 75143*76153* 58742*
Aerator
(2.2 gpm)
1031237* (2.2 gpm)
Insert Options
1.5 gpm
1069094* (2.2 gpm)
Insert Options
1.5 gpm
1088956 (1.8 gpm)
Insert Options
1.5 gpm
1074274 (1.8 gpm)
Insert Options
2.2 gpm
1.5 gpm
74405* (2.2 gpm)
1053334
1054424
1089003
1088956
1089003
Handle
1000499-CP 50349-0L
KOHLER.com/ServiceParts
KOHLER.com/ServiceParts
KOHLER.com/ServiceParts
KOHLER.com/ServiceParts
See
See
See
See
(Insert)
Plug Button/
Cap
N/A
N/A
N/A N/A
N/A
N/A
Sidespray
1021724* (Sidespray with Hose)
34329* (Holder)
1021724* (Sidespray with Hose)
1037431* (Holder)
1085211* (Sidespray with Hose/Holder)
1148477* (Sprayhead) 1141915 (Hose) 1132472* (Holder)
1021724* (Sidespray with Hose)
Other
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
Two-Handle
GP75878
Insert Options
1.5 gpm
Discontinued
78444 41056*
GP75878
Insert Options
1.5 gpm
1054432
(1.5 gpm)
(2.2 gpm)
1074274 (1.8 gpm)
1089003
KOHLER.com/ServiceParts
KOHLER.com/ServiceParts
Shoreham
K-10900 K-10905
Taboret
®
K-8219 K-8220 K-8221
Tor q® Bridge
K-6125 K-6126
1990-2010
GP77005-RP (H) GP77006-RP (C)
30393-RP (H) 30394-RP (C)
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
See
N/A
58895-CP59619*
34329*
(Holder)
1033012 (Sidespray with Hose)
N/A
1037431* (Holder)
1021724*
(Sidespray
with Hose)
See
See
N/A
N/A
1069552* (Sidespray with Hose/Holder)
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
33
Two-Handle
Kitchen Faucets
Product Name
Trend
®
K-11900 K-11905 K-11920 K-11925
K-11920-R K-11925-R K-11933 K-11935
Two-Handle
Triton
®
K-7825 K-7827
K-7782 K-7794
Valve/ Valvet
30393-RP (H) 30394-RP (C)
Current
GP1092204 (H) GP1092203 (C)
GP30002 (H) GP30004 (C)
Prior to 1990
GP30002 (H) GP30004 (C)
®
GP77005-RP (H) GP77006-RP (C)
Diverter
Discontinued
N/A
N/A
Discontinued
Aerator
59619*
(1.5 gpm)
1105050* 57745-CP
41056* (2.0 gpm)
41056* (2.2 gpm) (Male Threads)
Handle
58895-CP 20984 (Acrylic)
KOHLER.com/ServiceParts
1000434-CP Discontinued
GP20986-CP (Chrome)
See
Plug Button/
Cap
GP30000
N/A
N/A N/A
Sidespray
1033012 (Sidespray with Hose)
1037431* (Holder)
1021724* (Sidespray with Hose)
1037431*
(Holder)
Other
29678-BC (Hose Connector)
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
K-7776 K-7779
K-7761 K-7763 K-7765 K-7826
Single-Handle
Antique
K-168 K-169 K-170 K-171
Single-
Handle
GP77006-RP (C)
GP30002 (H) GP30004 (C)
1170273
**GP30420 (Seal Kit)
78444GP77005-RP (H)
Discontinued
GP75878
59620* (2.0 gpm) 41056* (2.2 gpm) (Male Threads)
41781* (1.5 gpm)
41056* (2.2 gpm) (Male Threads)
73326*
1000439-CP 1000442-CP
1000438-CP 1000441-CP
41981*
See
KOHLER.com/ServiceParts
52622-CP
52623-H (Red) 52623-C (Blue)
N/A
N/A
1021724* (Sidespray
with Hose)
34329*
(Holder)
1021724* (Sidespray
with Hose)
34329* (Holder)
1011130* (Sidespray with Hose/Holder)
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
34
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering. **Recommended when replacing valve.
Faucet Faucet Details
Kitchen Faucets
Single-Handle
Product Name
Avatar
®
K-6356
Centura
K-6895 K-6896 K-6897
Evoke
®
K-6333 K-6334 K-6335 K-6336
Coralais
®
K-15071 K-15072 K-15073 K-15075 K-15076
Valve/ Valvet
GP77548 89929*
Diverter
®
78444
GP30082 42352
Aerator
Insert Options
1.5 gpm
(1.5 gpm)
1054424
Discontinued
GP1016515
GP77548
GP75878
GP75878
1074274 (2.2 gpm)
Insert Options
1.5 gpm
76963* (2.2 gpm)
Insert Options
1.5 gpm
59619* (2.2 gpm)
1089003
1053334
Handle
See
KOHLER.com/ServiceParts
Discontinued59619*
See
KOHLER.com/ServiceParts
1001795*
100558*
Plug Button/
Cap
See
KOHLER.com/
ServiceParts
42355
GP42361
N/A
76712* 76712-A (Red/Blue)
Sidespray
N/A
1033012 (Sidespray with Hose)
1037431*(Holder)
1088396 1088395* (Sidespray Hose)
1087231* (Holder)
1021724* (Sidespray with Hose)
1037431* (Holder)
Other
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
Handle
Single-
K-15171 K-15172 K-15173 K-15174 K-15175 K-15176
K-15167 K-15168 K-15177 K-15178
Fairfax
®
K-12171 K-12172 K-12173 K-12175 K-12176
Remote Valve
K-12185
Forté
®
K-10411 K-10412 K-10413 K-10415 K-10416
Remote Valve
K-10430 K-10441 K-R10434
**GP30420 (Seal Kit)
GP30413 30422
GP77548
**GP30420 (Seal Kit)
GP75878
GP1016515
N/A
GP1016515 1156410*
GP30420* (Seal Kit)
GP75878
GP1017426
N/A
Insert Options
1054432
1.5 gpm
41056* (2.2 gpm)
41056* (2.2 gpm)
59619* (1.5 gpm)
79402* Kit (2.2 gpm)
Insert Options
1054421
1.5 gpm
79402* (2.2 gpm)
Insert Options
1054421
1.5 gpm
1031237* (2.2 gpm)
Insert Options
1053334
1.5 gpm
1031237* (2.2 gpm)
Insert Options
1053334
1.5 gpm
30423*
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
78205*
78205* (Handle) 1031994* (Spout)
1018337*
N/A
N/A
1021724* (Sidespray with Hose)
1037431* (Holder)
1021724* (Sidespray with Hose)
1037431* (Holder)
1021724* (Sidespray with Hose)
1037431* (Holder)
1021724* (Sidespray with Hose)
1037431* (Holder)
1021724* (Sidespray with Hose)
1037431* (Holder)
Swinger 30456-CP (Black)
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
*Include the color or finish code after the part number when ordering. **Recommended when replacing valve.
35
Single-Handle
Kitchen Faucets
Product Name
Pot Filler
K-7323
Karbon
®
K-6227
Purist
®
K-7507 K-7508 K-7509 K-7511
Pull-Down/ Pullout
Product Name
Avatar
®
K-6350 K-6352 K-6353
®
Bellera
K-560
Coralais
®
K-15160
Valve/ Valvet
Diverter
®
GP77005-RP
1090948
GP1093674
Valve/ Valvet
GP77548
GP1093674 1061023
GP77548
Aerator Handle
®
1171998* (1.8 gpm)
Insert Options
1.5 gpm
(1.8 gpm)
Insert Options
2.2 gpm
1.5 gpm
1171998*
(1.8 gpm)
GP75878
1055715
1167290
1167289
Aerator
1046672*
1179931* (1.8 gpm)
Insert Options
1151266
2.2 gpm
1151265
1.5 gpm
1074274 (1.8 gpm)
Insert Options
1089003
1.5 gpm
1025581* 78381*
See
KOHLER.com/ServiceParts
1001795*
Handle
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
Plug Button/
Cap
N/A
N/A
1001552*
76712-A (Red/Blue)
Plug Button/
Cap
N/A
N/A
N/A
1036940* (Pullout Spray)
1155250* (Sprayhead)
1109445* (Sprayhead)
Sidespray
1179931* (Sprayhead Adapter Kit)
1148477* (Sidespray) 1141915 (Hose)
1132472* (Holder)
1054559-CP (Hose)
1114111-BC (Hose)
1056336-CP (Braided Hose)
Other
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
See
KOHLER.com/
ServiceParts
OtherSidespray
1052379 (Weight)
1046153 (Weight)
1004899 (Weight)
See
Pullout
K-15165 K-15170
Pull-Down/
Clairette
®
K-692
®
Cruette
K-780
Elate
®
K-13963
Insert Options
1.5 gpm
GP77548
N/A
GP1016515
GP1093674 1061023
GP1093674
1171998* (1.8 gpm)
Insert Options
1.5 gpm
(1.8 gpm)
Insert Options
2.2 gpm
1.5 gpm
1061023
(1.8 gpm)
Insert Options
2.2 gpm
1.5 gpm
1055715
1179913
1167290
1167289
1177880
1177879
71610*
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
*Include the color or finish code after the part number when ordering.
N/A
N/A
N/A
N/A
GP1003736-0 (White) 1109445* (Sprayhead)
1013837* (Sprayhead)
1155355* (Sprayhead)
1176828* (Sprayhead)
107526 (Threaded Hose)
GP78825 (Hose)
1013839-CP (Hose)
1042007 (Check Valve Kit) (Prior to 2008)
1114111-BC (Hose)
1114111-BC (Hose)
1052379 (Weight)
1046153 (Weight)
1004899 (Weight)
36
Faucet Faucet Details
Kitchen Faucets
Pull-Down/ Pullout
Product Name
Epicure
K-6996
K-6997
Evoke
®
K-6331 K-6332
Fairfax
®
K-12177
Forté
®
K-10433
HiRise Independent Sidespray
K-7344
Valve/ Valvet
Discontinued
GP77005-RP (H) GP77006-RP (C)
GP1016515
GP77548
GP1016515
1069078
Aerator Handle
®
N/A Discontinued
1066758* (2.2 gpm)
Insert Options
1055715
1.5 gpm
1171998* (1.8 gpm)
Insert Options
1055715
1.5 gpm
1171998* (1.8 gpm)
Insert Options
1184741
2.2 gpm
1177879
1.5 gpm
N/A
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
Plug Button/
Cap
N/A
N/A
78205*
N/A
N/A
Sidespray
Discontinued
1074398* (Sprayhead)
1152299* (Sprayhead)
Discontinued
1041319* (Sprayhead)
1069055* (Sprayhead)
Other
48046 (Hose) Discontinued
1052379 (Weight)
1060796* (Hose for 9" Spout)
1074407* (Hose for 8" Spout)
1075256-CP (Quick-Connect Hose)
1004941-CP (Threaded Hose)
1114379-BC (Hose)
1069058* (Hose)
1046153 (Weight)
1052379 (Weight)
1046153 (Weight)
Pull-Down/
Pullout
ProMaster
K-6330
Provence
K-14502
K-15405
Purist
®
K-7505 K-7506
Simplice
K-596 K-597
®
®
GP77548
77096
86378-BC (2.2 gpm)
See
KOHLER.com/ServiceParts
Discontinued
N/A
N/A
GP77005-RP (H) GP77006-RP (C)
GP1093674
®
GP1093674
N/A
1141646 (1.8 gpm)
Insert Options
1.5 gpm
1061023
(1.8 gpm)
Insert Options
2.2 gpm
1.5 gpm
1055715
1167290
1167289
57718*
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
57739* (H) 57738* (C)
O-Ring 57853 (Red) 57854 (Blue)
N/A
N/A
79374* (Sprayhead)
GP1003736-0 (White) (Sprayhead)
1109445* (Sprayhead)
76625* (White, Black) (Sprayhead)
1148476* (Sprayhead)
1176882* (Sprayhead)
1076066 (Hose)
GP78825 (Hose)
1154836 (Hose)
1114111-BC (Hose)
1052379 (Weight)
1046153 (Weight)
1046153 (Weight)
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
37
Pull-Down/ Pullout
Kitchen
Product Name
Simplice® Remote Valve
K-647 K-649 K-R648
Vinnata
®
K-690 K-691
Valve/ Valvet
GP1017426
GP1016515
Aerator Handle
®
1061023 (1.8 gpm)
Insert Options
1167290
2.2 gpm
1167289
1.5 gpm
1171998* (1.8 gpm)
Insert Options
1179913
1.5 gpm
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
Plug Button/
Cap
N/A
N/A
Sidespray
1176882* (Sprayhead)
1013838* (Sprayhead)
Other
1060796-CP (Hose)
1013839-CP (Hose) (Use w/ 9½" Spout K-690)
1014048-CP (Hose) (Use w/ 7½" Spout K-691)
1042007 (Check Valve) (Prior To 2008)
1004899 (Weight)
1004899 (Weight)
Pullout
Pull-Down/
Wall-Mount
Product Name
Antique
K-149 K-155 K-159 K-165
Wall-Mount
Calder
™
Cannock
K-8888 K-8892
Clearwater
K-7854 K-7855 K-7856 K-7857
Farnley Fordwick
K-8950 K-8955
Valve/ Valvet
GP30002 (H) GP30004 (C)
GP30002 (H)
™
®
GP30004 (C)
GP30002 (H) GP30004 (C)
GP30002 (H) GP30004 (C)
Aerator
41056* (2.2 gpm)
30341* 34064-H*
41056* (2.2 gpm)
Insert Options
1054423
1.5 gpm
N/A
50281* (H) 50282* (C)
34064-H* 34064-C*
Handle
34064-C*
34064-H* 34064-C*
1120992* 37668*
1020053-H* 1020053-C*
Other
(Soap Dish)
See
KOHLER.com/ServiceParts
37668* (Soap Dish)
See
KOHLER.com/ServiceParts
38
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
Faucet Faucet Details
Kitchen
Wall-Mount
Product Name
HiRise
K-7338
Karbon
®
K-6228
Knoxford
™
K-8904 K-8905 K-8906 K-8924
Parq
®
K-6132
HiRise Pot Filler
K-7322
Valve/ Valvet
GP77005-RP (H) GP77006-RP (C)
1090948
GP30002 (H) GP30004 (C)
GP77005-RP (H) GP77006-RP (C)
®
Aerator
1069094*
(2.2 gpm)
Insert Options
1.5 gpm
1179931*
(1.8 gpm)
Insert Options
1.5 gpm
N/A
1088956* (1.8 gpm)
Insert Options
1.5 gpm
1046672*GP77005-RP
1054424
1151265
1089003
Handle
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
34064-H* 34064-C*
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
Other
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
Purist
®
K-7549
Service Sink Faucet
K-8928
Tor q
®
K-6127
Triton
®
K-7319
K-7320
GP77005-RP (H) GP77006-RP (C)
GP30002 (H) GP30004 (C)
GP77005-RP (H) GP77006-RP (C)
GP30002 (H) GP30004 (C)
1074274* (1.8 gpm)
Insert Options
2.2 gpm
1.5 gpm
N/A
1074274* (1.8 gpm)
Insert Options
2.2 gpm
1.5 gpm
30341*
1105050*
(1.5 gpm)
Insert Options
1.5 gpm
1088956
1089003
1088956
1089003
1054432
See
KOHLER.com/ServiceParts
34064-H* 34064-C*
See
KOHLER.com/ServiceParts
34064-H* 34064-C*
1020053-H* 1020053-C*
See
KOHLER.com/ServiceParts
29254 (Hose)
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
Wall-Mount
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
39
Bar
Bar Faucets
Bar
Product Name
Antique
K-118
Bardney
™
K-7895
Blagdon
™
K-7894
Carafe
®
K-18865
Coralais
®
K-15275
K-15276 K-15840 K-15850
Valve/ Valvet
GP1099204 (H) GP1099203 (C)
(Regular Water)
GP77005-RP (H) GP77006-RP (C)
®
GP77005-RP (H) GP77006-RP (C)
GP30002
GP30002 (H) GP30004 (C)
1071964 (Filtered Water)
GP76672 (H) GP76671 (C)
Aerator Handle
41056* (2.2 gpm) 59620* (2.0 gpm) 1030351 (2.2 gpm) (Laminar Flow)
41056* (2.2 gpm)
41056* (2.2 gpm)
10675531071965
41056*
Insert Options
1054423
1.5 gpm
59619* (1.5 gpm)
76892* (2.2 gpm)
KOHLER.com/ServiceParts
34064-H* (H) 34064-C* (C)
KOHLER.com/ServiceParts
KOHLER.com/ServiceParts
73238 (Clear) 73238-SM (Smoke)
34064*
115/16"
See
See
See
70508-CP (Lever)
Plug Button/
Cap
N/A
N/A
N/A
N/A
70505 (H) 70504 (C)
70208 (H) 70207 (C)
Other
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
K-15270
K-15271
K-15279
Essex
®
K-8761
Fairfax
K-12183
GP77005-RP (H) GP77006-RP (C)
GP76672 (H) GP76671 (C)
N/A
40106* (2.2 gpm)
See
KOHLER.com/ServiceParts
70505 (H) 70504 (C)
See
KOHLER.com/ServiceParts
N/A
GP76672 (H) GP76671 (C)
41056* (2.2 gpm)
500170-SM (Smoke)
70505 (H) 70504 (C)
115/16"
GP77005-RP (H) GP77006-RP (C)
®
GP77548
41056* (2.2 gpm)
Insert Options
1.5 gpm
1054423
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
N/A
78205*1097762*
76697*
See
KOHLER.com/ServiceParts
40
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
Faucet Faucet Details
Bar Faucets
Bar
Product Name
Forté
®
K-10443
HiRise
K-7342
Pot Fillers
K-7322 K-7323
Piping Hot
®
Hot Water Dispenser
K-9707 K-9709
Provence
®
K-14506 K-14507 K-14508
Valve/ Valvet
GP1017426
GP77005-RP (H) GP77006-RP (C)
GP77005-RP (H) GP77006-RP (C)
Aerator Handle
®
1031237*
Insert Options
1053334
1.5 gpm
1069094*
Insert Options
1054424
1.5 gpm
1046672*GP77005-RP
57718*
Discontinued
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
For Service, Call 800-558-5700
57739* (H) 57738* (C)
Plug Button/
Cap
N/A
N/A
N/A
N/A
Sidespray
N/A
N/A
N/A
57853 (Red) 57854 (Blue) (O-Rings) (For 57718* Handle)
Other
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
GP1021724* (Sidespray with Hose)
Bar
Revival
®
K-16112 K-16114
Taboret
®
K-8207
Trend
®
K-11935
K-11930 30393-RP (H)
GP77005-RP (H) GP77006-RP (C)
GP1099204 (H) GP1099203 (C)
GP77005-RP (H) GP77006-RP (C)
30395 (H) 30396 (C)
30394-RP (C)
57376* (2.0 gpm)
41056* (2.2 gpm)
59874* (2.0 gpm VR)
Insert Options
1.5 gpm
1105050*
41056* (2.2 gpm)
1054423
75143*
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
Discontinued
5
1
34329* (Holder)
N/A
N/A
57743 (H) 57744 (C)
GP30000
N/A
N/A
N/A
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
/8"
Wellspring
K-6665 K-6666
®
GP77005-RP (H) GP77006-RP (C)
55604 87390
See
KOHLER.com/ServiceParts
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
(Filter Head)
Aquifier® Hi-Flow Replacement Cartridge
87404 (Hi-Flow 1.5 gpm) 87406 (Premium .6 gpm)
41
Touchless
Touchless Electronic Faucets
Commercial Faucets
Touchless
Product Name
Sculpted
AC
K-13462, K-13463
DC
K-13460, K-13461 Hybrid
K-7514, K-7515
Geometric
AC
K-13468, K-13469 DC K-13466, K-13467 Hybrid K-7516, K-7517
Gooseneck
AC
K-13474, K-13475
DC
K-13472, K-13473 Hybrid K-7518, K-7519
Falling Waters
K-T11836
AC
Powered by an AC power pack that plugs into a wall outlet.
Hybrid
Powered by a hybrid 30-year energy cell below the counter.
DC
Powered by alkaline batteries inside the faucet.
1093425*
1093425*
1105912*
Handle
GP1095915 (Handle Assembly)
GP1095915 (Handle Assembly)
GP1095915 (Handle Assembly)
N/A
Diaphragm
1097710
GP1105675 (Seal Only)
1097710
GP1105675 (Seal Only)
1097710
GP1105675 (Seal Only)
®
1098135 (Seal Only)
1101642*
(0.5 gpm)
1101643
(0.5 gpm)
1105674
Aerator Kit
Insert Options
1104546 Laminar
1.5 gpm 1097180 Aerated
1139285 Laminar
1.0 gpm 1139284 Aerated
1075455 Spray
0.5 gpm
1160595 Spray
0.35 gpm
Washer 79441
Insert Options
1100596 Laminar
1.5 gpm 1139290 Aerated
1139289 Laminar
1.0 gpm 1139288 Aerated
1101643 Spray
0.5 gpm
1096839 Large Concealed
Key Aerator
Insert Options
1053532 Laminar
1.5 gpm 1053576 Aerated
1139287 Laminar
1.0 gpm 1139286 Aerated
1049937 Spray
0.5 gpm
Washer 78783
1097747*
Solenoid
GP1102542
GP1102542
GP1102542
GP1097740
1019975 (VR Wrench)
GP1023199-CP (Tamper-Resistant Plug Button) (Kit of 4)
1052495 (VR Wrench)
Other
GP1023199-CP (Tamper-Resistant Plug Button) (Kit of 4)
GP1023199-CP (Tamper-Resistant Plug Button) (Kit of 4)
N/A
Purist
®
K-T11837 K-T11839 K-T11840 K-T11841
Memoirs
®
K-T11838
Touchless Electronic Faucet
K-13660 K-13660-2E K-13662 K-13662-2E
K-13664 K-13666
1098135 (Seal Only)
1098135 (Seal Only)
N/A
N/A
59621* (2.0 gpm)
59874* (2.0 gpm VR)
1097745*
1097748*
59722* (2.0 gpm VR)
GP1097740
GP1097740
Discontinued
Discontinued
N/A
N/A N/A
N/A
N/A
95168 (Sensor)
95168 (Sensor)
N/A
78868 (VR Wrench)
78868 (VR Wrench)
42
VR = Vandal-Resistant *Include the color or finish code after the part number when ordering.
Urinals
Faucet Faucet Details
Commercial Faucets
Urinals
Urinals
Tripoint
®
Product Name Solenoid Other
Tripoint
DC
Flush Valve
K-10669 K-10949 K-10956 K-10957 K-10958 K-10959 K-10960 K-10961 K-10962 K-10963 K-10964 K-10965 K-10966
WAVE
DC
Flush Valve
K-10666 K-10668 K-10673 K-10674 K-10675 K-10676 K-10677 K-10678 K-10679
Touchless
Diaphragm/Piston Assembly
GP1055637 (Diaphragm)
GP1055637 (Diaphragm)
GP1056873 (Piston)
GP1056873 (Piston)
WAVE Manual
GP1055666
GP1104235
GP1118986-CP (Extension Kit)
GP1132369-CP (12" Rough-In Kit)
GP1118986-CP (Extension Kit)
GP1132369-CP (Rough-In Kit)
Touchless
DC
Flush Valve
K-13686
Manual Flush Valves
K-13516 K-13517 K-13518 K-13519 K-13520 K-13521 K-13522
GP1157029 (1.28 gpf) GP1157032 (1.6 gpf) Piston (Toilet)
Discontinued
GP1151743 (0.5 gpf) GP1151746 (1.0 gpf) GP1151752 (.0125 gpf) Piston (Urinal)
82901 (Discontinued) (Sensor Assembly)
GP1059515 (Vacuum Breaker)
N/A
GP1149404 (Handle Seal Kit)
43
Commercial
Commercial Faucets
Faucets
Commercial
Product Name
Aspirator with Horizontal Ejector
K-13839
Built-In Bed Pan Washer
K-13931-2A
Exposed Bed Pan Washer
K-13925
Drinking Fountain Fitting
K-8496 K-8525 K-8526
Finesse
K-13330 K-13341 K-13343 K-13344
K-13328
No image
available
Valve/Valvet
GP30002
GP30002
30271-RP
(Rebuilding Kit)
GP30002 (H) GP30004 (C)
®
Aerator
N/A
N/A
N/A
59619* (1.5 gpm)
41056* (2.2 gpm)
Handle
1020053-PL-CP
36285-CP 41981-CP
41127-H-CP (H) 41127-C-CP (C)
41125-H-CP (H) 41125-C-CP (C)
Other
See
KOHLER.com/ServiceParts
30266 (Rosespray)
30352*35284*
30341* (Rosespray)
29240 (Hose )
K-13583 K-13584 K-13585 K-13595 K-13596
Floor-Mounted Pedal Valve
K-13808 K-13812
Foot-Control Mixing Valve
K-13816 K-13817
Gooseneck Spout
Deck-Mount
K-13760 K-13761 K-13762 K-13770 K-13772 K-13774
Wall-Mount
K-13782 K-13786
41063-H-CP (H) 41063-C-CP (C)
30301 (Rebuilding Kit) 36283 (H)
N/A
30301 (Rebuilding Kit) 36276 (H)
N/A
59619* (1.5 gpm)
N/A
36282 (C) (Pedal)
36275 (C) (Pedal)
N/A
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
30341* (Rosespray)
44
Laundry Tray Faucet
K-13640
GP30002 (H) GP30004 (C)
38615-H-CP (H) 38615-C-CP (C)
N/A
See
KOHLER.com/ServiceParts
(H) = Hot (C) = Cold *Include the color or finish code after the part number when ordering.
Faucet Faucet Details
Commercial Faucets
Commercial
Product Name
Metering Faucet
K-7490 K-7491
Niedecken Mixer Valve for Knee-Action Fittings
K-13175
Service Sink Fitting
K-13629 K-8899
Built-In
Triton
®
Shampoo Faucet
K-13061
Triton II Built-In Service Sink Faucet
K-13639
Valve/Valvet
30129 (Rebuilding Kit)
21518 (Rebuilding Kit)
GP30002 (H) GP30004 (C)
GP30002 (H & C)
GP30002 (H & C)
®
Aerator
59874* (2.0 gpm VR)
N/A
N/A
N/A
N/A
Handle
Discontinued
21707-CP
Discontinued
1000439-CP
1000439-CP
Other
78868 (VR Wrench)
22117-A (Spindle Wrench)
22116 (Seat Wrench)
See
KOHLER.com/ServiceParts
23054* (Sprayhead)
KOHLER.com/ServiceParts
See
29240* (Hose)
Commercial
Faucets
Vacuum Breaker
K-13055
Vacuum Breaker
K-13056
Wheelchair Bathroom Sink Supply
K-13711
21286* (Vacuum Breaker)
30372 (Rebuilding Kit)
30267-BC
N/A
N/A N/A
N/A
N/A
32338-C
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
See
KOHLER.com/ServiceParts
(H) = Hot (C) = Cold VR = Vandal-Resistant *Include the color or finish code after the part number when ordering.
45
Red/Blue Indexing
Only the faucets listed can be ordered with Red & Blue indexing options
Single-Handle Faucets
Coralais
and Purist® faucets can be ordered
®
with Red & Blue plug buttons.
76928-A
Coralais
Centerset Faucets
Coralais, Memoirs with Red & Blue washers.
and Forté® faucets can be ordered
®
76712-A
Coralais
1032011-X*
Purist
These SKUs have Red & Blue washers installed in the handles. Note: Cannot be used with other faucets.
Bath and Shower Trim
Coralais and Memoirs faucets can be ordered with Red & Blue indexing already applied.
See Price Book for SKU listing.
Coralais
Deck-Mount Bath Trim
Memoirs faucets can be ordered with Red & Blue washers.
Memoirs
These SKUs have Red & Blue washers installed in the handles. Note: Cannot be used with other faucets.
Indexing
Red/Blue
Coralais
Widespread Faucets
The following faucets can be ordered with Red & Blue indexing. These SKUs have Red & Blue washers installed in the handles. See Price Book for SKU listing.
Coralais
Traditional
Finial
®
Memoirs
Memoirs
Purist
Forté
These SKUs have Red & Blue washers installed in the handles. Note: Cannot be used with other faucets.
Forté
Memoirs
Kitchen Sink Faucets
Coralais faucets can be ordered with Red & Blue indexing. See Price Book for SKU listing.
76712-A
Coralais Coralais
Coralais
46
*Please contact your customer service representative to obtain products with Red/Blue indexing.
Red/Blue Indexing
Only the faucets listed can be ordered with Red & Blue indexing options
Most single-handle faucets can have the Red & Blue sticker added. The sticker should be placed near the handle as shown.
1141978 Red & Blue Sticker for Single-Handle Faucets
¼"
Fairfax
®
Forté
®
Margaux
®
Purist
®
Stance
®
The following Red & Blue stickers can be ordered for the bath and shower trim.
®
1015346 Red & Blue Sticker
7
/8")
Bancroft
®
Place sticker between the H and C.
Purist
.85"
Devonshire
®
Place sticker on the outside of the H and C.
Refinia
®
1015345 Red & Blue Sticker
27/8"
Placement Locations for Large Sticker (2
Alteo
®
Place sticker on the inside of the H and C near bonnet.
Oblo
®
Archer
®
Place sticker along the outside edge of the dial plate.
Pinstripe
Symbol
®
Fairfax
Place sticker tight against the white trim piece.
Symbol
Toobi
™
Finial® Traditional
Place sticker against the bonnet.
Toobi
Forté
Place sticker between the H and C.
Place sticker over the H and C.
Place sticker on the outside of the H and C.
Place sticker on the inside of the H and C near bonnet.
Placement Locations for Small Sticker (0.85")
Revival
®
Place sticker in between the H and C on the line.
Margaux
Place sticker in between the H and C on the line.
Stillness
Place sticker in between the H and C.
Please contact your customer service representative to obtain products with red/blue indexing.
Place sticker on the inside of the H and C near bonnet.
We do not
®
recommend the
Place sticker on the inside of the H and C near bonnet.
IV Georges Brass
Place sticker on the inside of the H and C near bonnet.
®
Antique
Cabriole
®
use of a Red & Blue sticker on the following trim:
Red/Blue
Indexing
Kelston
®
Loure
®
Taboret
®
Stance
47
For more service parts information, visit
Form 12-1319-0412
Kohler Co., Kohler, Wisconsin 53044
© 2012 by Kohler Co.
Printed in U.S.A.
1-800-4-KOHLER
(1-800-456-4537)
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
