Introduction
The Magic Touchpad is a touchpad mouse designed to fully utilize the power of multi-touch
gestures, with plenty area to roam and navigate through your Windows/ Mac OS systems.
Connecting to device
No software installations are required to connect the Magic Touchpad. The Magic Touchpad
runs with a 2.4Ghz wireless RF. To connect to computers, tablets or smartphones, just power
on the Magic Touchpad (as shown below) and insert the 2.4Ghz mini dongle into the USB
slot in your main device. Within 5 seconds, you will find the ‘Magic Touchpad’ on your main
device. Please charge the Magic Touchpad via mini USB port. A Red LED will turn on during
charging and will turn off once charging is completed.
2
Page 3
Touchpad mouse top view
Touch gestures for Windows 8
Touch gesture Functions
Touch and move with
one finger
Move pointing
cursor
Touch and move two
fingers
Vertical scrolling
(up/down),
horizontal scrolling
(left/right)
3
Page 4
Move along Touch
Edge C with single
finger
Vertical scrolling
Swipe in from left
Touch Edge B and
move vertically with
one finger
Switch applications
Swipe from top Touch
Edge A with one finger
Show Windows 8
application menu
Swipe in from right
Touch Edge C with one
finger
Show Windows 8
charms
Swipe in from bottom
Touch edge D with one
finger
Toggle between
Windows 8 Metro
screen and active
application
Swipe In from lower
left corner
Windows 8: pop up
desktop advanced
menu at bottom left
corner
Tap, Double tap with
one finger
Double click
4
Page 5
2 finger single tap Right click
Tap and move single
finger
Left click, drag and
move
Multi-touch gestures
Touch gesture Functions
Touch and move three
fingers (left/right)
(top/bottom)
Drag and move
selected object
Swipe four fingers
down
Windows 8: Switch
between start
screen and desktop
Swipe four fingers up Switch between
start screen and the
foremost running
application
Pinch with two fingers Zoom out for
browsing
Spread with two fingers Zoom in for
browsing
5
Page 6
Touch gestures for Mac
Touch gesture Functions
Touch and move with
one finger
Move pointing
cursor
Touch and move two
fingers
Vertical scrolling
(up/down),
horizontal scrolling
(left/right)
Move along Touch
Edge C with single
finger
Vertical scrolling
Single tap with one
finger
Click.
Tap and move single
finger
Left click, drag and
move
Shortcuts / navigate
Touch gesture Functions
Touch and move three
fingers (left/right)
(top/bottom)
Drag and move
6
Page 7
Swipe left or right with
3 fingers
Swipe among full
screen apps, for
example, Mission
Control
Four fingers swipe right Application windows
all exposed
Four fingers swipe left Show
Mission control
Spread/pinch with five
fingers
Show Launchpad
7
Page 8
Software compatibility
The Magic Touchpad has been tested for various operating systems and popular media
center applications, including:
Windows 8 / Windows 7
Apple Macintosh - OS X
iOS (iPad and iPhone series)
Google Android 4.0 and above
Linux
Specifications
Item Descriptions
Dimensions 191mm X 115mm X 13 (7) mm
Rechargeable battery in use Li-Ion battery
Work time One month operation (@ 2 hours daily)
Touch sensor type Projected capacitive touch sensor
Touch resolution 800x480 matrix in touch active area
Touch sensor capability Full finger multi-touch operation.
(Max. five fingers)
Wireless standard 2.4GHz RF
Total weight (approx.) 269g
Operation temperature 5 °C to 35 °C
External power Charging via mini USB connector - 5V DC input
