Kogan KASPAMSDLTA User manual
DELIGHT INFLATABLE PORTABLE
OUTDOOR HOT TUB MASSAGE SPA
6 PERSONS
KASPAMSDLTA
Read all of the instructions before use, and retain this user guide for future reference.
SAFETY INSTRUCTIONS
WARNING!
When installing and using this electrical equipment, basic safety precaution should always
be followed, including the following:
Important safety instructions – read and follow all instructions.
WARNING:
• WARNING: This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
• Risk of Accidental Drowning: Extreme caution must be exercised to prevent
unauthorized access by children. To avoid accidents, ensure that children cannot
use this spa unless they are supervised at all times.
• For safety around children and to minimise drowning risk, always fit the spa cover
after each use.
• RISK OF INJURY: Do not operate spa if inlet or outlet pipes are broken or missing.
Never attempt to replace the inlet and outlet pipes. Contact help.kogan.com for
assistance.
• Risk of electric shock: Install at least 2 metres from all metal surfaces.
• Risk of electric shock: Never operate any electrical appliance when in your spa or
when your body is wet. Do not place any electrical appliance (such as a light,
telephone, radio or television) within 2 metres of spa.
• TO AVOID ELECTRIC SHOCK, DO NOT USE THE SPA WHEN IT IS RAINING.
• WARNING: Always keep plug dry. NEVER plug or unplug with a wet hand.
• WARNING: For electrical safety, a leakage current detecting device is incorporated
in the power cord. If leakage current exceeding 10mA is detected, the device will cut
off the power supply. In the event of cut-off, unplug the spa and stop using at once.
Contact help.kogan.com for assistance in resetting the space. Do not attempt to
reset the spa by yourself.
• Caution: In order to avoid a hazard due to inadvertent resetting of the thermal cutout, this appliance must not be supplied through an external switching device,
such as a timer or connected to a circuit that is regularly switched on and off by the
utility.
• Caution: Read the instruction before using the appliance and installation or
reassemble every time
• The spa must be supplied through an isolating transformer or supplied through a
residual current device (RCD) having a rated residual operating current not
exceeding 30mA.
• The pump must be tested before each use. Refer to the PRCD page of the
Installation section for instructions.
• If the supplied power cord is damaged, it must be replaced by the manufacturer or
Kogan.com representative. Do not use if damaged.
• To reduce the risk of electric shock, do not use extension cord to connect unit to
electric supply; provide a properly located outlet.
• No part of the appliance is to be located above the spa during use.
• Parts containing live parts (except parts supplied with safety extra-low voltage not
exceeding 12V) must be out of reach and inaccessible to a person in the spa.
• Parts incorporating electrical components (except remote control devices) must be
located or fixed so that they cannot fall into the spa pool.
• The plug of the pump shall be more than 3.5 metres away from the spa at all
times.
• It is necessary to have the plug accessible after installation of the spa.
• The power source on the wall of the building should keep more than 4 metres away
from spa and at a height of at least 1.2 metres.
• Do not use extension cords.
• Always unplug the appliance:
o on rainy days
o before cleaning or other maintenance
o if leaving unattended for a long period (holidays, etc)
• The plug shall be directly connected only to a socket-outlet of the fixed electrical
installation.
• When the appliance will be not used for a long time, such as in the winter, the spa
or pool set should be disassembled and stored indoor.
• Never wear contact lenses when in the spa.
• Do not use spa during chemical maintenance.
• Keep this user guide for future reference. If the user guide is lost, refer to kogan.com
for a digital copy.
• The appliance must be supplied by earthed power source. An earthed power cord
is supplied.
• Cleaning and user maintenance must be performed by an adult above 18 years old
who is understands the risk of electric shock.
• Do not bury cord. Locate cord to minimize damage from lawn mowers, hedge
trimmers and other equipment.
• During pregnancy, soaking in hot water may result in serious injury or death to the
unborn child. Limit use to 10 minutes at a time and be conscious of temperature.
To reduce the risk of injury:
• The water in a spa should never exceed 40°C. Water temperature between 38°C
and 40°C is considered safe for a healthy adult. Lower water temperatures are
recommended for young children and when spa use exceeds 10 minutes.
• Since excessive water temperatures have a high potential for causing fetal damage
during the early months of pregnancy, users who are pregnant or possibly pregnant
should limit spa water temperature to 38°C.
• Before entering a spa, the user should measure the water temperature with an
accurate thermometer since the tolerance of water temperature regulating device
varies.
• The use of alcohol, drugs or medication before or during spa use may lead to
unconsciousness with the possibility of drowning.
• The use of alcohol, drugs or medication can greatly increase the risk of fatal
hyperthermia. Hyperthermia occurs when the internal temperature of the body
reaches a level that is several degrees above the normal body temperature of 37°C.
The symptoms of hyperthermia include an increase in the internal temperature of
the body, dizziness, lethargy, drowsiness and fainting.
The effects of hyperthermia include failure to perceive heat; failure to recognize the
need to exit spa or hot tub; unawareness of impending hazard; fetal damage in
pregnant people; physical inability to exit the spa or hot tub; and unconsciousness
resulting in the danger of drowning.
• Obese persons and persons with a history of heart disease, low or high blood
pressure, circulatory system problems or diabetes should consult a physician before
using a spa.
• Persons using medication should consult a physician before using a spa since
some medication may induce drowsiness while other medication may affect heart
rate, blood pressure and circulation.
• TO REDUCE THE RISK OF INJURY: Never pour water with a temperature higher
than 40°C into the spa pool directly.
• Electric installations must follow national wiring rules; consult a qualified
electrician with any questions.
• Consult your physician for recommendations.
Caution:
• We strongly recommend not to unfold and inflate the spa if the ambient
temperature is below 15°C. We suggest inflating the spa indoors and then
continuing set up outdoors. If the outdoor temperature is lower than 6°C, the spa
heater must always be on. In this mode, the Freeze Shield system can keep the
internal temperature between 6°C and 10°C to prevent damage, such as water
freezing in the pipes or the circulation system.
Important: If the Freeze Shield system isn't working, alarms will pop up on the spa. Be sure
to check the status of your spa if the outdoor temperature is below 6°C. In case of a longterm absence from home when there is a risk of temperatures falling below 6°C, we strongly
suggest disassembling the spa and storing it following the storage procedure.
• Do not use the spa alone.
• People with infectious diseases should not use a spa.
• Do not use the spa immediately following strenuous exercise.
• Always enter and exit the spa slowly and cautiously. Wet surfaces are slippery.
• To avoid damage to the pump, the spa must never be operated unless the spa is
filled with water.
• Immediately leave spa if the user feels uncomfortable or sleepy.
• Never add water to chemicals. Always add chemicals to water to avoid strong
fumes or violent reactions that may result in hazardous chemical spray.
• Refer to the Cleaning and Care section of this user guide regarding information
pertaining to cleaning, maintenance of water, and disposal of water.
After using your spa for 3-5 years, you should contact your local qualified maintenance
technician to ensure the safety and performance of the spa. The main components, such as
heating element, air blower motor and non-return valves within the electric unit should be
checked and replaced (if necessary) by professionals.
Note:
• Please examine equipment before use. Notify Bestway at the customer service
address listed on this manual for any damaged or missing parts at the time of
purchase. Verify that the equipment components represent the models that you
had intended to purchase.
• This product is not intended for commercial use.
E Filter cartridge and
Cartridge base
F Spa drain
Valve adapter
A Spa Cover B Spa tub
C Wired controller D Digital lock
G Repair kit H Wrench
Zones
Description of the zones
Zone 0 is the interior of the basin including any recesses in
their walls or floors.
Zone 1 is limited by:
Zone 2 is limited by:
Note:
The measured zone dimensions are limited by walls and fixed partitions.
Zone 0
• Zone 0
Zone 1
Zone 2
• A vertical plane 2m from the rim of the basin.
• The floor or the surface expected the be occupied
by persons
• The horizontal plane 2.5m above the floor or the
surface
• A vertical plane external the zone 1 and parallel
plane 1.5m from the former.
• By the floor or surface intended to be occupied by
persons.
FIRST USE AND SET-UP PREPARATION
Site preparation and requirements
• The spa can be installed indoor and outdoor around 10 minutes by at least one
person. For household use only.
• The spa must be set up on a flat, smooth and supporting surface that can support
the maximum load of the filled spa with listed maximum occupants.
• Make sure the area is free of sharp objects under or around the spa. Uneven or
unsound surfaces can damage the spa and void your warranty. Level the surface
before filling spa with water.
• Provide adequate drainage system around the spa to deal with overflow water and
splashes.
• Make sure there is enough clearance around the spa for full access to the spa
equipment for maintenance and/or service.
Additional requirements for indoor installation
• Verify the supporting floor can support the filled weight of spa with maximum
number of occupants. Check with a qualified contractor or structural engineer to
verify the requirement.
• Make sure the floor is water resistant and provides non-slip surface. Do not install
the spa on a carpet or any other material that could be damaged by the moisture.
• Humidity is a natural side effect of indoor spa installation. The room shall be
properly ventilated to allow moisture to escape. Install a ventilating system to
prevent excess condensation moisture in the room.
Additional requirements for outdoor installation
• Make sure to set up the spa on a firm, level and smooth surface that is strong
enough to support the full weight of the filled spa and maximum occupants.
• Do not set up the spa on grass or dirt, as this increases the amount of debris
entering the spa and damage the spa floor.
• Do not leave the spa tub exposed to direct sun light for longer lifespan.
• Always keep the manometer on yellow section when using the spa at a
temperature higher than 20°C or exposed to sunlight for a short time.
• It is recommended to install and leave the spa outside at a temperature not lower
than 4°C to ensure the water inside the circulation system, pump, pipe are not
frozen. Put a Heat Preservation Mat between the spa bottom and the ground to
prevent heat loss from the bottom of the spa and to provide better heat retention.
