Page 1
KA600CDSTVA
600W Corded 2-in-1
Stick Vacuum
Page 2
Table of Contents
Safety & Warnings..................................................................................................................1
Product Overview..................................................................................................................2
Assembly.................................................................................................................................2
Operation.................................................................................................................................3
Cleaning and Care.................................................................................................................3
Troubleshooting.....................................................................................................................4
Safety & Warnings
• Read all instructions before using the appliance
• Before the first operation, make sure the dust cup or the dust bag is properly
installed.
• Only use the vacuum cleaner indoors on dry surfaces and keep the area your
cleaning well lit.
• Don’t use this vacuum cleaner if it has been dropped, damaged or left
outdoors.
• Don’t handle the plug or use the vacuum cleaner with wet hands.
• Don’t pull or carry this vacuum cleaner by the power cord. Don’t use the
power cord as a handle, pull the power cord around corners, sharp edges or
close a door over the Power cord. Don’t unplug vacuum cleaner by pulling on
the power cord.
• Don’t vacuum up any flammable or combustible materials (lighter fluid,
petrol, kerosene etc.) or use the vacuum cleaner in an area with explosive
vapours or liquid.
• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning
items or use in an area where there may be harmful fluids (chlorine, bleach, and
ammonia drain cleaner).
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your vacuum cleaner.
• Don’t attempt to remove blockages with sharp objects as this may cause
damage to your vacuum cleaner.
• If abnormal noise, smell, smoke or any other failure or breakage, including any
issue with the power cord is found during the operation, cease use immediately
and contact Kogan Support.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
1
Page 3
Product Overview
1. Handle
2. Top electric cord storage holder
3. Detachable rod handle
4. Power cord
5. Air outlet openings
6. Dust compartment
7. Dust filter (inside dust compartment)
8. Unlocking button for dust
compartment
9. On/O switch
10. Rod handle connector
11. Bottom electric cord storage holder
12. Crevice accessory
13. Floor nozzle attachment
14. Suction opening
15. Handheld vacuum unit
Assembly
Main unit
Conversion from handheld to floor vacuum cleaner
Remove all parts from the packaging and place carefully on
a flat area. If necessary, put protective sheeting underneath
to avoid harm to easily damaged surfaces. Carefully remove
all packing materials and ensure there are no missing parts.
Using as a handheld vacuum cleaner
The appliance is ready for use as a handheld
appliance as soon as it has been unpacked.
Using as a floor vacuum cleaner
• Open the small flap on the handle of the handheld vacuum unit.
• Insert the rod handle connector in the opening in the handheld vacuum unit
and push in as far as it will go.
• Press the flap against the connector so that it snaps into place.
Removing rod handle
• Open the flap.
• Pull out the rod handle.
• Close the flap on the handle again.
2
Page 4
Fitting and removing nozzles
CAUTION: Always switch o the vacuum cleaner before changing nozzles.
• To fit nozzles, insert in the suction opening.
• To remove nozzles, pull out of the suction opening.
Floor Nozzle Attachment
The floor nozzle attachment is suitable for both carpets and
smooth floors.
Crevice Accessory
The crevice accessory is designed for upholstery, cleaning the
interior of cars and for getting into all corners and cracks that
are inaccessible with the floor nozzle attachment or without a
nozzle.
CAUTION: Never hold the crevice nozzle close to the body or it may stick to the
skin, and cause injury.
If the nozzle does get stuck, set the switch o immediately.
Operation
• Ensure all parts are fully assembled and filters correctly inserted before use.
• Do not use the appliance on the following:
– liquids or wet materials (e. g. carpet shampoo when wet)
– ash, cigarette ends, matches, etc.
– combustible or in flammable substances
– very fine dust (e. g. concrete dust) or toner
– hard, pointed objects such as large splinters of glass
1. Fit or remove the rod handle according to desired use.
2. To quickly unwind the cable from the floor vacuum cleaner,
twist down the cord holder on the top handle.
3. Insert the power plug in a wall outlet and turn on.
4. Begin cleaning
5. After use, switch o and unplug.
6. After use, always empty the dust compartment and clean the
dust filter.
Cleaning and Care
• Remove the power plug before cleaning and/or putting away.
• Do not use caustic or abrasive products or you may damage the surface.
• Never immerse the appliance in water.
Emptying and cleaning the dust container
1. Hold down the unlock button for the dust compartment and
carefully remove.
3
Page 5
2. Hold over a bin, carefully remove the dust filter and empty.
3. Tap the dust filter gently.
4. Occasionally wash the dust filter under cold running water.
CAUTION: Do not wash the dust filter in the washing machine.
5. Leave the dust filter to air dry for 24 hours until completely dry
before reinserting.
CAUTION: Do not use a hair dryer.
6. Press firmly back in so it fits tightly in the dust compartment
housing.
CAUTION: Never use the vacuum cleaner without the dust filter inserted.
7. Press the unlocking button to engage. The dust cup must be securely
engaged at the top and bottom of the appliance for it to work properly.
Cleaning and replacing motor protection filter
Once you have removed the dust cup, you will find a piece of nonwoven material on the open side of the appliance. This is the motor
protection filter. It needs to be cleaned from time to time.
1. Remove from the appliance, shake and tap o the dust.
2. Rinse with lukewarm water.
3. Shake again and leave to dry o completely.
Cleaning housing
Clean the housing with a slightly damp, soft cloth if
necessary.
Storage
• The power cord can be wrapped around the rod handle is fitted.
• To unwind next use, twist the cord holder down on the top handle.
• The vacuum cleaner should be stored indoors in a cool, dry place.
Troubleshooting
IMPORTANT: If you are experiencing any issue with the appliance whatsoever,
first inspect the filters and all parts of the brush head carefully and ensure there
is no buildup of dust or dirt.
This is the most common cause of vacuum cleaner faults and problems,
including powering on and suction strength.
If you experience any issues, contact Kogan Support.
User manual is subject to change without notice. For the latest version of your user manual,
please visit https://www.kogan.com/usermanuals/
4
