A Reference Archive provides trustworthy copies of

records to validate transactions, satisfy litigation, or meet

regulatory and audit requirements. These documents are

maintained in an analog format on ISO-standard micro-

graphic media via digital-to-film writing technology such

as the KODAK i9600 Series Writers or paper micro-

filmers.

Today, microfilm continues to be a low-cost, low-risk

method of managing documents and information, and

is the media of choice for secure, “Reference Archive”

storage. With the KODAK i7300 Scanner you can

bridge microfilm’s proven stability with the efficiency of

digital technology. Now, you can have the best of both

worlds.

NO OTHER MICROFILM SCANNER
GIVES YOU THIS LEVEL OF PERFOR­MANCE.

The KODAK i7300 Scanner virtually eliminates

the inefficient aspects of traditional microfilm

retrieval – including slow, tedious viewing or limited

Bring your Reference

Archive

to

the desktop.

i7300 Scanner

i7300 Scanner Application Software • Image Server Software •
POWERFILM Application Software for the i7300 Scanner

output and delivery options. It can reduce ongoing

costs associated with older printers and readers

– from maintenance to high-priced consumables.

With the i7300 Scanner, your images are retrieved

fast, displayed digitally for identification, then

printed, faxed, and/or sent as e-mail. You’ll have

exceptionally high-quality images that are

deskewed, cropped, merged (duplexed), and dis-

played in seconds. The i7300 Scanner does it all

with twice the scanning speed and even more work-

saving functionality than its predecessor, the

KODAK DIGITAL SCIENCETMIntelligent

Microimage Scanner.

www.kodak.com/go/docimaging

A POSITIVE CHANGE IN ON-SCREEN
VIEWING.

Traditional microfilm readers displayed small negative­appearing images. KODAK i7300 Scanner Application
Software displays high-quality positive-appearing
images (bitonal to full grayscale). That makes viewing
more comfortable and productive.

• Real time image control.

Operators can adjust image
contrast and brightness
during scanning, saving time
and avoiding costly re-scans.

• Review images easily. For

reviewing documents, index­ing, QC, or just browsing, this
feature scans and presents each
document for a user-defined
period of time. Batch Scan mode
will scan, save and/or print
specified documents within a
specified image address range.

ONLY FROM KODAK – DIGITAL SCROLLING
ENABLES “MANUAL SEARCHING” ON THE
DESKTOP.

For film without image marks or an unknown
image address, Kodak’s exclusive digital scrolling
mode enables operators to perform manual
searches from a PC. While viewing a positive
appearing image, scrolling controls allow
operators to set speed, direction, and fast
forward or reverse film movement.

• Zoom in on important details. With the click of

a mouse, operators can zoom in on any part of a
document – even as it’s moving – to make finding key
information more efficient than ever.

Dynamic Contrast/Brightness Control

KODAK i7300 Scanner Application Software

↔

Batch Scan Save/Print Controls

Browse Control

Scrolling
Mode and
Controls

Electronic Zoom Controls

• Add highlights or notes for enhanced productivity. Images can

be easily annotated to call out key information. Note can be
included to improve end-user information. In a production
environment, a standard annotation such as date, operator name
or department can be added to each image. This improves pro­ductivity and customer service. If desired, these tools can be
locked out to prevent changes.

• A choice of output options. Images and docu-

ments can be saved to specified directories
with unique naming conventions to meet your
retrieval application needs. Images can be saved as
TIFF, Multi-page TIFF, or JPEG file formats.
Various page layout options improve printing
output.

• Easy Application Set-Up. Our versa-

tile Application Set-Up meets every
retrieval need. Controls can be viewed or
hidden, making operation more pleasant.
Image processing controls, as seen here,
are easily accessible when needed.
Operators can make quick adjustments –
for high-quality images that result in less
waste and greater productivity.

IMAGE SERVER SOFTWARE EXPANDS
YOUR OUTPUT OPTIONS TO THE NETWORK
AND BEYOND.

Accelerate your productivity even more by creating
your own retrieval network. KODAK Image Server
Software works with our Application Software to
integrate KODAK IMAGELINK Digital
Workstations, Intelligent Microimage Scanners, and
i7300 Scanners. With it, they feed into one central
server for a full range of routing options and output.
The software also:

• Accepts CAR commands*

• Centralizes printing to non-proprietary printers

• Supports BIN printing

• Batch prints from document file folders

• Enables faxing and e-mail

• Provides remote image delivery through a Gateway

interface to your network

* The application automatically accepts and stores images and annotations

that the CAR system has grouped into logical documents or folders.

Image Server Software also maximizes your hardware
investment. The software serves as many as four
MICROSOFT WINDOWS OS-supported printers
(scalable to eight). And because it lets you continue to
use your current retrieval devices you can begin
implementing newer technology at your own rate.

KODAK Image Server Software POWERFILM Application Software for the i7300 Scanner

IMS

IDW

i7300

e-mail

FAX

Folder

A central server integrates all your retrieval devices.

output

local

remote

Image Annotation

e

• Create CDs. With CD Publish you can store

scanned images, index databases, and the CD
Retrieve Viewer on either a CD or a DVD, for
efficient storage and retrieval of items later.

• Index Utility. Flexible indexing offers as many as

10 fields – text, numeric or date – with up to 32
characters per field. Auto-repeat indexing, such as
“current date,” is another efficiency feature that’s
included.

UNLEASH THE POWER OF FILM WITH
YOUR PC.

POWERFILM Application Software combines a
user-friendly interface with a wide range of output,
indexing, retrieval and distribution tools. It’s specially
designed for batch scanning and digitization of 16 mm
image-marked film. Here are just some of the ways
it can make you more productive.

• Output options provide versatile image

distribution – including TIFF, multi-page
TIFF, CD Publish and optional PDF and
KOFAX Ascent output modules.

• Save options allow efficient job management.

Operators can interrupt, suspend, and return to
jobs later. Accept or Reject options are also
available for scanned batches.

CD

Publish

CD

Retrieve

Viewer

CDS FROM FILM HAVE NEVER BEEN SO SIMPLE.

KODAK i7300 Scanner Application Software

This interface goes beyond other 16mm film scanning
products, delivering speed and efficiency with features made
for today’s technology. It offers complete connectivity with
CAR (Computer Assisted Retrieval) systems, integration with
both local and wide area networks, and consistently fast and
accurate digital image retrieval.

KODAK Image Server Software

By letting you create your own retrieval network for
centralized printing and network distribution, Image Server
Software can maximize your productivity while minimizing
costs. With it, you can serve as many as four MICROSOFT
WINDOWS-supported printers (scalable to eight). It helps
you manage input, printing and network distribution from
KODAK i7300 Scanners, IMAGELINK Digital
Workstations (IDW) and Intelligent Microimage Scanners
(IMS).

POWERFILM Application Software

A smart choice when an i7300 Scanner is used for
applications that require high productivity batch scanning of
images from microfilm. In addition to batch scanning,
POWERFILM Application Software is also designed for
batch indexing, document reconstruction, roll
conversion, and database creation using POWERFILM’s
CD Publish/Retrieve software.

Choose software that meets your needs.

This is just the beginning! All the software choices above (purchased separately) offer you an extensive
range of tools and flexibility.

KODAK SERVICE & SUPPORT’S COMMITMENT TO SERVICE
EXCELLENCE.

Today’s competitive business environment demands maximum productivity and effi­ciency. KODAK Service & Support provides the protection of a global team of more
than 4,000 employees dedicated to the quality services needed to keep our equipment
and business running at peak performance. From maintenance services to a full comple­ment of professional services, Kodak can design a plan that is right for you.

Compact, space-saving design: The i7300 Scanner fits
easily on your desktop for convenient use with minimal
space requirements.

Paper-saving technology: Direct film-to-digital conver­sion saves paper, time and steps.

Advanced transport: The scanner’s new design elimi­nates glass guides and minimizes the possibility of film
scratches.

Accurate retrieval: Your choice of software includes the
tools you need to find the images you want fast – even
from unmarked film.

Easy-to-use interface: All tools and procedures are
accessible via icons, toolbars, and pull-down menus.

Technology evolution: The i7300 Scanner reduces costs
associated with traditional microfilm reader/printers,
equipment and space requirements. Once again, micro­film demonstrates that as technology evolves it can be
fully integrated to take advantage of cost savings and
productivity-enhancing functionality.

Improved imaging: Powerful algorithms deliver consis­tently high-quality images. This enables your operators
to reduce waste, be more productive, and improve
customer satisfaction.

SPECIFICATIONSFEATURES/BENEFITS

Cat.- No. 740 7166 © Eastman Kodak Company, 2003.. Kodak, Digital Science and Imagelink are trademarks of Eastman Kodak Company. PowerFilm is a trademark of InfoCAP Technologies, used under license by Eastman Kodak Company.

M

Official Mark Canadian Olympic Association. DoldeMedien 0071/03_UK

i7300 SCANNER:

i7300 Scanner

Scanning resolution 200 to 300 dpi
Electrical requirements 100-120 or 220-240 VAC, 50-60 Hz, 1200W, 6 amps max
Heat dissipation <750 Btu/hr
PC minimum Processor: PENTIUM III, PENTIUM 4, 2.0 GHz, with PCI
requirements Bus Master Slot for full, 512 MB SRAM, height, 3/4 length

scanner interface card included
Operating System: MICROSOFT WINDOWS 98 (excluding
POWERFILM for the i7300), WINDOWS NT Workstation
v 4.0/SP3 or higher, WINDOWS 2000 Professional,
XP Professional
Monitor: 17” recommended; 16 MB graphics card
Connectivity: Ethernet or token ring card as required;
serial port for scanner

Height

28.5 cm

Width

38.1 cm

Depth

55.9 cm

Weight

29.5 kg
