Installing the software
ENGLISH
IMPORTANT:
www.kodak.com/go/c743support or c703support 1
Before connecting any cables, install the software that was included with
your camera. Follow the on-screen instructions.
After installing the software, return
to this Getting Started Guide.
ENGLISH
Loading the batteries
CRV3 lithium
(non-rechargeable)
Ni-MH
(rechargeable)
2 AA lithium or Ni-MH
(may be rechargeable
or non-rechargeable)
Turning on the camera
2 www.kodak.com/go/easysharecenter
Setting the language, date/time
Language:
1
2
1
to change.
to accept.
OK
Date/Time:
At the prompt, press OK.
ENGLISH
2
www.kodak.com/go/c743support or c703support 3
to change.
for previous/next field.
to accept.
OK
OK
ENGLISH
Taking a picture/video
Pictures Videos
1
Ready
light
LCD/Info
Press the LCD/Info button to turn
2
LCD on (or use the viewfinder).
Press the Shutter button halfway to
3
focus and set exposure.
When the Ready light turns green,
press the Shutter button completely
down.
4 www.kodak.com/go/easysharecenter
1
Press the Shutter button
2
completely down and release.
To stop recording, press the
Shutter button again.
Reviewing pictures/videos
1
Press Review. (Press again to exit.)
ENGLISH
2
www.kodak.com/go/c743support or c703support 5
for previous/next.
Videos:
Play/pause.
OK
Adjust the volume.
Rewind to beginning (during playback)
Next picture/video (during playback).
ENGLISH
Transferring pictures/videos
USB cable Kodak EasyShare printer dock
or camera dock
1
(May be sold separately.)
For dock compatibility, visit
www.kodak.com/go/dockcompatibility.
To purchase accessories, visit
www.kodak.com/go/c743accessories or
www.kodak.com/go/c703accessories.
To use an EasyShare dock, see its
Getting Started Guide.
2
6 www.kodak.com/go/easysharecenter
Keep learning about your camera!
Congratulations!
You have:
• set up your camera
• taken pictures
• transferred pictures to your computer
Keep learning!
Finish reading this book, so you can take and
Visit www.kodak.com/go/c743support or
www.kodak.com/go/c703support and
www.kodak.com/go/easysharecenter for:
• the extended user’s guide
• interactive troubleshooting and repairs
• interactive tutorials
• FAQs
• downloads
• accessories
• printing information
• product registration
share your best pictures!
ENGLISH
www.kodak.com/go/c743support or c703support 7
ENGLISH
Front view
1 Shutter button 7 Viewfinder
2Mode dial 8Lens
3 Self-timer/Video light 9 Speaker
4 Flash button 10 DC-In (3V) ,for optional AC adapter
5 Self-timer/Burst button 11 Microphone
6Flash
1
2
3
4
5
6
7
8
9
10
11
8 www.kodak.com/go/easysharecenter
Back view
2
3
4
5
6
15
14
7
8
9
10
11
12
13
1
19
18
1 LCD 8 Telephoto button 15 Battery compartment
2 Viewfinder 9 16 Menu button
3 Ready light 10 Strap post 17 Review button
4 Share button 11 SD/MMC card (sold separately) 18 Dock connector
5 LCD/Info button 12 Slot for optional SD/MMC card 19 Tripod socket
6 Delete button 13 USB, A/V Out
7 Wide angle button 14 OK button
1617
ENGLISH
www.kodak.com/go/c743support or c703support 9
1 Doing more with your camera
Using optical zoom
Use optical zoom to get up to 3X closer to your subject. Optical zoom is effective when
the lens is no closer than 24 in. (60 cm) to the subject or 5.1 in. (12.9 cm) in Close-up
mode. You can change optical zoom before (but not during) video recording.
1 Press Telephoto (T) to zoom in. Press Wide Angle (W) to zoom out.
2 Take the picture or video.
Zoom indicator
Optical
zoom
range
WTD
Using digital zoom
Press the Telephoto (T) button to the optical zoom limit (3X). Release the button, then
press it again.
NOTE: You cannot use digital zoom for video recording. You may notice decreased image quality when using
digital zoom. The blue slider on the zoom indicator pauses and turns red when the picture quality
reaches the limit for an acceptable 4 x 6-in. (10 x 15 cm) print.
10 www.kodak.com/go/easysharecenter
Digital
zoom
range
Doing more with your camera
Using the self-timer
Place camera on a tripod or flat surface.
1
In any Still mode, press the Self-timer button.
2
• Once for a 10-second delay (so you have time to get into the scene)
• Again for a 2-second delay (for a steady, auto-shutter release on a tripod)
• Again for 2-shot (one picture taken after 10 seconds and another picture taken
8 seconds later)
Compose the scene.
3
Press the Shutter button halfway, then completely down.
4
To cancel the Self-timer before the picture is taken, press the Self-timer button. (The
Self-timer setting remains active.)
Use the same procedure to take a video, but:
■ Turn the Mode dial to Video.
■ Press the Shutter button completely down.
NOTE: The video stops when no storage space remains. Only the 2- and 10-second options are available in
video mode.
www.kodak.com/go/c743support or c703support 11
Doing more with your camera
Using the flash
Press the Flash button repeatedly to change flash modes.
The current flash mode is shown in the LCD status area.
Flash-to-subject distance
Wide angle 2–11.8 ft (0.6–3.6 m) @ ISO 140
Telephoto 2–6.9 ft (0.6–2.1 m) @ ISO 140
Flash modes Flash fires
When the lighting conditions require it.
Auto
Fill Every time you take a picture, regardless of the lighting conditions. Use when
the subject is in shadow or is “backlit” (when the light is behind the subject).
In low light, hold the camera steady or use a tripod.
Red-
If the Red-eye Pre-flash feature
eye
is turned off:
■ The flash fires once.
■ The camera then
automatically corrects
red-eye in the picture.
Never
Off
If the Red-eye Pre-flash feature is turned on:
■ The flash fires once so the eyes become
accustomed to the flash, then fires again
when the picture is taken.
12 www.kodak.com/go/easysharecenter
Picture-taking modes
Choose the mode that best suits your subjects and surroundings.
Use this mode For
General picture taking—offers an excellent balance of image quality
and ease of use.
Far-away scenes. The camera uses infinity auto-focus. Auto-focus
framing marks are not available in Landscape.
Close range. Use available light instead of flash if possible. The camera
automatically sets the focus distance depending on the zoom position.
Point-and-shoot simplicity when taking pictures under special
conditions.
Capturing video with sound.
SCN
Auto
Landscape
Close-up
Scene
Video
Doing more with your camera
www.kodak.com/go/c743support or c703support 13
Doing more with your camera
Scene modes
1 Turn the Mode dial to Scene .
2 Press to display Scene mode descriptions.
NOTE: If the Help text turns off, press the OK button.
3 Press the OK button to choose a Scene mode.
Use this
For
SCN mode
Portrait Full-frame portraits of people.
Sport Subjects that are in motion.
Children Action pictures of children in bright light.
Party People indoors. Minimizes red eye.
Beach Bright beach scenes.
Snow Bright snow scenes.
Fireworks Flash does not fire. Place the camera on a flat, steady surface or use a tripod.
Self-
Portrait
Backlight Subjects that are in shadow or “backlit” (when light is behind the subject).
Night
Portrait
Close-ups of yourself. Assures proper focus and minimizes red eye.
Reduces red eye of people in night scenes or low-light conditions. Place the
camera on a flat, steady surface or use a tripod.
14 www.kodak.com/go/easysharecenter
Doing more with your camera
Using exposure compensation to adjust brightness
In Auto, you can adjust exposure compensation to make your pictures darker or lighter.
Press to decrease exposure compensation, and to increase exposure
compensation.
The exposure compensation level is shown on the LCD and the LCD gets dimmer
or brighter.
Using burst
Option Description Purpose
Camera takes up to 3 pictures (1.5 per second) while the
Shutter button is pressed.
Capture an expected
event.
Burst
First 3 pictures are saved.
Example:
A person swinging a
golf club.
1 In most Still modes, press the Burst button.
2 Press the Shutter button halfway to focus and set exposure.
3 Press the Shutter button completely down and hold it to take pictures.
The camera stops taking pictures when you release the Shutter button, when the pictures
are taken, or when there is no more storage space.
www.kodak.com/go/c743support or c703support 15
Doing more with your camera
Copying pictures and videos
You can copy pictures/videos from a card to internal memory or from internal memory
to a card.
Before you copy, make sure that:
■ A card is inserted in the camera.
■ The camera’s picture storage location is set to the location from which you are
copying.
Copy pictures or videos:
1 Press the Review button, then press the Menu button.
2 Press to highlight Copy, then press the OK button.
3 Press to highlight an option.
4 Press the OK button.
NOTE: Pictures/videos are copied, not moved. To remove pictures/videos from the original location after
copying, delete them. Tags that you applied for print, email, and favorites are not copied. Protection
settings are not copied.
16 www.kodak.com/go/easysharecenter
Doing more with your camera
Understanding picture-taking icons
In capture mode—no buttons pressed
Self-timer Flash
Date stamp
Picture size
Pictures/time remaining
location
Storage
wide
Zoom:
telephoto
digital
Exposure metering
White balance
ISO speed
Low battery
Camera
mode
Exposure compensation
www.kodak.com/go/c743support or c703support 17
2 Working with pictures/videos
Magnifying a picture during review
magnify 2X - 8X.
W/T
view other parts of the picture.
OK
return to 1X.
Viewing multi-up (thumbnails)
view multi-up thumbnails.
view previous/next row of thumbnails.
view previous/next thumbnail.
view single picture.OK
18 www.kodak.com/go/easysharecenter
Working with pictures/videos
Deleting pictures/videos
Press Review.
1
2
3
4
Using the undo delete feature
If you accidentally delete a picture/video, you can use Undo Delete to retrieve it. This
feature is only available immediately after you delete a picture/video.
for previous/next.
Press Delete.
Follow the screen prompts.
www.kodak.com/go/c743support or c703support 19
Working with pictures/videos
Cropping pictures
Cropped picture
1
2
3
4
5
Review.
Press
for previous/next.
Press Menu, choose Crop
Press Telephoto (T) to zoom in, or
to move the crop box.
Follow the screen prompts.
, then press OK.
The picture is copied, then cropped. The original picture is saved. A cropped picture cannot
be cropped again on the camera.
Press the Menu button to exit the menu
20 www.kodak.com/go/easysharecenter
3 Solving camera problems
For step-by-step product support, visit www.kodak.com/go/c743support or
www.kodak.com/go/c703support and select Interactive Troubleshooting & Repairs.
Camera problems
If... Try one or more the following
Camera does not
turn on/off.
Stored pictures are
corrupted.
Short battery life
with Kodak Ni-MH
rechargeable
digital camera
batteries.
■ Install new batteries (page 2).
■ Charge rechargeable batteries.
■ Remove the battery, then reinsert or replace it.
■ Retake pictures. Do not remove card while the Ready light is blinking.
Keep rechargeable batteries charged.
■ Transfer the pictures to the computer (page 6), format the SD/MMC
card in the camera. (Press the Menu button, choose Setup and find
Format).
Formatting deletes all pictures/videos, including protected files.
Removing the card during formatting may damage the card.
■ Wipe the contacts with a clean, dry cloth before loading batteries in
the camera.
■ Limit the following activities that quickly deplete battery power:
reviewing pictures/videos on the LCD; using the LCD as a viewfinder;
and excessive use of the flash.
■ Use the Refresh feature on your camera dock series 3 or printer dock
series 3.
www.kodak.com/go/c743support or c703support 21
4 Appendix
Camera specifications
For more specifications, visit www.kodak.com/go/c743support
Kodak EasyShare C743/C703 zoom digital camera
CCD (charge-coupled device)
CCD 1/2.5 in. CCD, 4:3 aspect ratio
Output image size 7.1 MP: 3072 x 2304 pixels
6.1 MP (3:2): 3072 x 2048 pixels
4.0 MP: 2304 x 1728 pixels
1.9 MP: 1600 x 1200 pixels
0.8 MP: 1024 x 768 pixels
Displays
Color display 6.1 cm (2.4 in) color hybrid LCD, 112 K pixels
Preview Frame rate: 30 fps; Field-of-view: 100%.
Lens
Taking lens 3X optical zoom lens f/2.7 - f/4.8
Aperture: maximum - f/2.7; minimum - f/8.5
37 mm - 111 mm (35 mm equivalent)
Lens barrier Automatic built-in
or www.kodak.com/go/c703support.
22 www.kodak.com/go/easysharecenter
Kodak EasyShare C743/C703 zoom digital camera
Focus system TTL-AF; Multi-zone AF, and Center-zone AF. Working range:
0.6 m (24 in.)-infinity @ normal
0.13 - 0.7 m (5.1-27.6 in.) @ wide close-up
0.22 - 0.7 m (8.7-27.6 in.) @ telephoto close-up
10 m (32.8 ft.)-infinity @ Landscape
Digital zoom 5.0X continuous with 0.2X increments
Not supported for video capture
Exposure
Exposure metering TTL-AE; Center-weighted
Exposure compensation +/-2.0 EV with 0.5 EV step
Shutter speed Mechanical shutter with CCD electrical
Auto: 4 - 1/1400 sec.
ISO speed Auto, Portrait, Close-up, Landscape: 80 - 160; Sport: 80 - 200;
Night Portrait, Long Time Exposure: 80
Selectable: 80, 100, 200, 400, 800 (800 available only for smallest picture size
setting)
Flash
Electronic flash Guide no. 8.5 (@ ISO 100)
Auto flash with pre-flash
Working range at ISO 140: 0.6-3.6 m (2-11.8 ft.) @ Wide
0.6-2.1 m (2-6.9 ft.) @ Tele
Flash modes Auto, Fill, Red-eye, Off
Capture
Capture modes Auto, Landscape, Close-up, SCN (Scene Modes), Video
Appendix
www.kodak.com/go/c743support or c703support 23
Appendix
Kodak EasyShare C743/C703 zoom digital camera
Video capture VGA (640 x 480) @ 30 fps
QVGA (320 x 240) @ 30 fps
Image file format Still: EXIF 2.21 (JPEG compression); file organization: DCF
Video: QuickTime (CODEC MPEG4)
Image storage Optional SD/MMC Card . (The SD logo is a trademark of the SD Card
Internal storage capacity 32 MB internal memory/28 MB available for image storage
Review
Quickview Yes
Video output NTSC or PAL selectable
Power
2 Kodak oxy-alkaline digital camera batteries AA ZR6 (non-rechargeable); 2-AA lithium digital camera
batteries; 2-AA alkaline batteries; 2 Kodak Ni-MH rechargeable digital camera batteries AA; 1 Kodak lithium
digital camera battery CRV3 (non-rechargeable); 1 Kodak Ni-MH rechargeable digital camera battery KAA2HR,
3V AC adapter
Communication with computer
USB 2.0 (PIMA 15740 protocol), via USB cable model U-8, EasyShare camera dock or printer dock
Other features
PictBridge support Yes
Self Timer 2 seconds, 10 seconds, or 2-shot
White balance Auto, Daylight, Tungsten, Fluorescent
Auto power off Selectable 1, 3, 5, 10 minutes
Association.)
(1 MB equals one million bytes)
24 www.kodak.com/go/easysharecenter
Appendix
Kodak EasyShare C743/C703 zoom digital camera
Color modes Color, Black & White, Sepia
Date stamp None, YYYY/MM/DD, MM/DD/YYYY, DD/MM/YYYY
Tripod mount 1/4 inch
Viewfinder Optical, real-image; 83% field of view
Operating temperature 32-104°F (0-40°C)
Size 32.4 mm (1.3 in.) x 65.7 mm (2.6 in.) x 92.2 mm (3.6 in.) @ power off
Weight 145 g (5.1 oz.) without battery or card
www.kodak.com/go/c743support or c703support 25
Appendix
Important safety instructions
CAUTION:
Do not disassemble this product; there are no user-serviceable parts inside. Refer servicing to
qualified service personnel. Do not expose this product to liquid, moisture, or extreme
temperatures. Kodak AC adapters and battery chargers are intended for indoor use only. The
use of controls, adjustments, or procedures other than those specified herein may result in
exposure to shock and/or electrical or mechanical hazards. If the LCD breaks, do not touch the
glass or liquid. Contact Kodak customer support.
■ The use of an accessory that is not recommended by Kodak may cause fire, electric shock, or injury.
■ Use only a USB-certified computer. Contact your computer manufacturer if you have questions.
■ If using this product in an airplane, observe all instructions of the airline.
■ When removing the battery, allow it to cool; it may be hot.
■ Read and follow all warnings and instructions supplied by the battery manufacturer.
■ Use only batteries approved for this product to avoid risk of explosion.
■ Keep batteries out of the reach of children.
■ Do not allow batteries to touch metal objects, including coins. Otherwise, a battery may short circuit,
discharge energy, become hot, or leak.
■ Do not disassemble, install backward, or expose batteries to liquid, moisture, fire, or extreme temperature.
■ Remove the battery when the product is stored for an extended period of time. In the unlikely event that
battery fluid leaks inside the product, contact Kodak customer support.
■ In the unlikely event that battery fluid leaks onto your skin, wash immediately with water and contact your
local health provider. For additional health-related information, contact your local Kodak customer support.
■ Dispose of batteries according to local and national regulations.
■ Do not charge non-rechargeable batteries.
For more information on batteries, see www.kodak.com/go/batterytypes
.
26 www.kodak.com/go/easysharecenter
Appendix
Upgrading your software and firmware
Download the latest versions of the software included on the Kodak EasyShare software CD and the camera
firmware (the software that runs on the camera). See www.kodak.com/go/c743downloads
www.kodak.com/go/c703downloads.
Additional care and maintenance
■ If the camera has been subjected to inclement weather or you suspect water has gotten inside the camera,
turn off the camera and remove the batteries and card. Allow components to air-dry for at least 24 hours
before using the camera again.
■ Blow gently on the lens or LCD to remove dust and dirt. Wipe gently with a soft, lint-free cloth or an
untreated lens-cleaning tissue. Do not use cleaning solutions unless designed specifically for camera lenses.
Do not allow chemicals, such as suntan lotion, to contact painted surfaces.
■ Service agreements are available in some countries. Contact a dealer of Kodak products for more
information.
■ For digital camera disposal or recycling information, contact your local authorities. In the US, visit the
Electronics Industry Alliance Web site at www.eiae.org or visit www.kodak.com/go/c743support or
www.kodak.com/go/c703support.
Warranty
Kodak warrants Kodak EasyShare digital cameras and accessories (excluding batteries) to be free from
malfunctions and defects in both materials and workmanship for one year from the date of purchase.
Retain the original dated sales receipt. Proof of the date of purchase will be required with any request for
warranty repair.
This limited warranty will be honored only within the geographical location that Kodak digital cameras and
accessories were purchased.
Kodak will REPAIR or REPLACE Kodak EasyShare digital cameras and accessories if they fail to function properly
during the warranty period, subject to any conditions and/or limitations stated herein. Such repair service will
include all labor as well as any necessary adjustments and/or replacement parts. Such repair or replacement is
the sole remedy under this warranty.
If replacement parts are used in making repairs, these parts may be remanufactured, or may contain
remanufactured materials. If it is necessary to replace the entire product, it may be replaced with a
remanufactured product.
or
www.kodak.com/go/c743support or c703support 27
Appendix
Request for Warranty service will not be accepted without proof of date of purchase, such as a copy of the
original dated Kodak EasyShare digital camera or accessory sales receipt. (Always keep the original for your
records.)
This warranty does not apply to the battery(s) used in digital cameras or accessories. This warranty does not
cover circumstances beyond Kodak’s control, nor problems caused by failure to follow the operating instructions
in the Kodak EasyShare digital cameras and accessories User’s Guides.
This warranty does not apply when failure is due to shipping damage, accident, alteration, modification,
unauthorized service, misuse, abuse, use with incompatible accessories or attachments, failure to follow
Kodak’s operation, maintenance or repacking instructions, failure to use items supplied by Kodak (such as
adapters and cables), or claims made after the duration of this warranty.
Kodak makes no other express or implied warranty for this product. In the event that the exclusion of any
implied warranty is ineffective under the law, the duration of the implied warranty will be one year from the
purchase date.
The option of replacement is Kodak’s only obligation. Kodak will not be responsible for any special,
consequential or incidental damages resulting from the sale, purchase, or use of this product, regardless of the
cause. Liability for any special, consequential or incidental damages (including but not limited to loss of revenue
or profit, downtime costs, loss of the use of the equipment, cost of substitute equipment, facilities or services, or
claims of your customers for such damages resulting from the purchase, use or failure of the product),
regardless of cause or for breach of any written or implied warranty is expressly disclaimed and excluded
herefrom.
Your r i ghts
Some states or jurisdictions do not allow exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. Some states or jurisdictions do not allow limitations on how
long an implied warranty lasts, so the above limitation may not apply to you.
This warranty gives you specific rights, and you may have other rights which vary from state to state or by
jurisdiction.
Outside the United States and Canada
In countries other than the United States and Canada, the terms and conditions of this warranty may be
different. Unless specific Kodak warranty is communicated to the purchaser in writing by a Kodak company, no
warranty or liability exists beyond any minimum requirements imposed by law, even though defect, damage, or
loss may be by negligence or other act.
28 www.kodak.com/go/easysharecenter
Appendix
FCC compliance and advisory
Kodak EasyShare C743/C703 zoom digital camera
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed or used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures: 1) reorient or relocate the receiving antenna; 2) increase the separation between the
equipment and the receiver; 3) connect the equipment to an outlet on a circuit different from that to which the
receiver is connected; 4) consult the dealer or an experienced radio/TV technician for additional suggestions.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment. Where shielded interface cables have been provided with the
product or specified additional components or accessories elsewhere defined to be used with the installation of
the product, they must be used in order to ensure compliance with FCC regulation.
Australian C-tick
N137
Canadian DOC statement
DOC Class B Compliance
This Class B digital apparatus complies with Canadian ICES-003.
Observation des normes-Classe B
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
www.kodak.com/go/c743support or c703support 29
Appendix
Waste Electrical and Electronic Equipment labeling
In the European Union, do not discard this product as unsorted municipal waste. Contact
your local authorities or go to www.kodak.com/go/recycle for recycling program information.
VCCI Class B ITE
English translation: This is a Class B product based on the standard of the Voluntary Control Council for
Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in
a domestic environment, it may cause radio interference. Install and use the equipment according to the
instruction manual.
Korean Class B ITE
MPEG-4
Use of this product in any manner that complies with the MPEG-4 visual standard is prohibited, except for use
by a consumer engaging in personal and non-commercial activities.
Eastman Kodak Company
Rochester, New York 14650
Eastman Kodak Company, 2006
Kodak and EasyShare are trademarks of Eastman Kodak Company.
4J4884_en
30 www.kodak.com/go/easysharecenter
Loading...
