Kodak EasyShare C653, EasyShare C623 User Manual

Kodak EasyShare C653/C623

zoom digital camera

User’s guide

www.kodak.com

For interactive tutorials, www.kodak.com/go/howto

For help with your camera, www.kodak.com/go/c653support or

www.kodak.com/go/c623support

Eastman Kodak Company
Rochester, NY 14650
© Eastman Kodak Company, 2006

All screen images are simulated.

Kodak, EasyShare, and Perfect Touch are trademarks of Eastman Kodak Company.

P/N 4J6052_en

Front view

Product features

1

2

3

4

5

6

7

8

9

10

12

1 Shutter button 7 Flash
2 Mode dial 8 Viewfinder
3 Self-timer/Video light 9 Lens

4Microphone

5Flash button
6 Self-timer/Burst button 12 Grip

www.kodak.com/go/support

10 DC-In (3V) ,for optional AC adapter

11 Speaker

11

i

Product features

Back view

1

2

3

4

5

6

7

8

9

10

11

12

13

19

14

18

15

16

17

1LCD 11 4-way arrows

2 Viewfinder 12 Strap post
3 Ready light

4Review button

5 LCD/Info button 15 Battery compartment
6 Share button 16 Slot for optional SD or MMC card
7 Delete button 17 SD or MMC card (sold separately)

13 USB, A/V Out

14 Menu button

8 Wide angle button 18 Dock connector
9 Telephoto button 19 Tripod socket
10 OK button

ii www.kodak.com/go/support

Table of contents 1

1 Setting up your camera .........................................................................1

Attaching the strap .......................................................................................1

Loading the battery ....................................................................................... 1

Turning on the camera .................................................................................. 2

Setting the language, date/time.....................................................................2

Storing pictures on an SD or MMC card .........................................................3

2 Taking pictures/videos ...........................................................................4

Picture-taking modes ....................................................................................4

Taking a picture ............................................................................................ 7

Taking a video ..............................................................................................8

Reviewing the picture/video just taken........................................................... 8

Using optical zoom ..................................................................................... 10

Using the digital zoom ................................................................................ 10

Using the flash............................................................................................11

Using the self-timer..................................................................................... 12

Using burst ................................................................................................. 13

Using the framing grid to compose a picture................................................ 13

Using exposure compensation to adjust picture brightness ...........................14

Using camera Help ...................................................................................... 14

Taking panoramic pictures........................................................................... 15

Understanding the picture-taking icons........................................................ 16

3 Working with pictures/videos ..............................................................17

Reviewing pictures/videos ........................................................................... 17

Deleting pictures/videos .............................................................................. 19

Cropping pictures........................................................................................ 21

Using Kodak Perfect Touch technology ........................................................21

Editing videos ............................................................................................. 22

Running a slide show .................................................................................. 23

Copying pictures/videos...............................................................................26

www.kodak.com/go/support iii

Table of contents

Understanding the review icons................................................................... 27

4 Transferring and printing pictures .......................................................28

Installing the software................................................................................. 28

Transferring pictures with the USB cable ...................................................... 29

Printing pictures.......................................................................................... 30

Dock compatibility for your camera.............................................................. 32

5 Doing more with your camera .............................................................33

Changing picture-taking settings ................................................................. 33

Customizing your camera ............................................................................ 37

Pre-tagging for album names ...................................................................... 40

Tagging pictures/videos for albums.............................................................. 41

Sharing your pictures................................................................................... 42

6 Troubleshooting ..................................................................................47

Camera problems........................................................................................ 47

Camera ready light status............................................................................49

Camera/computer communications.............................................................. 50

LCD screen messages .................................................................................. 51

7 Getting help ........................................................................................54

Helpful links ................................................................................................ 54

8 Appendix .............................................................................................56

Camera specifications ................................................................................. 56

Storage capacities .......................................................................................59

Important safety instructions ....................................................................... 60

Battery life .................................................................................................. 61

Upgrading your software and firmware........................................................62

Care and maintenance ................................................................................62

Warranty..................................................................................................... 63

Regulatory compliance ................................................................................ 65

iv www.kodak.com/go/support

1 Setting up your camera

Attaching the strap

Loading the battery

Ni-MH
(rechargeable)

For battery types, see page 58. To extend battery life, see page 61.

CRV3 lithium
(non-rechargeable)

2 AA (rechargeable or
non-rechargeable)

www.kodak.com/go/support 1

Setting up your camera

Turning on the camera

Setting the language, date/time

OK (press)

1

2

OK

to change.

for previous/next field.

to accept.

2 www.kodak.com/go/support

Setting up your camera

Setting the language, date/time at other times

Press Menu.

1

to highlight Setup Menu

2

3

then press OK.

to highlight Language

or Date/Time

, then press OK.

Storing pictures on an SD or MMC card

Your camera has 32 MB of internal memory. You can purchase an SD or MMC card to
conveniently store more pictures and videos.

NOTE: When using the card for the first time, format the card in this camera before taking pictures (see

page 39).

We recommend Kodak SD or MMC cards.

SD/MMC card slot

Notched corner

SD/MMC card (optional)

CAUTION:
A card can only be inserted one way; forcing it may cause

damage. Inserting or removing a card when the Ready light is
blinking may damage the pictures, the card, or the camera.

See page 59 for storage capacities. Purchase SD or MMC cards at a dealer of Kodak
products or at www.kodak.com/go/c653accessories or

www.kodak.com/go/c623accessories.

www.kodak.com/go/support

3

2 Taking pictures/videos

Picture-taking modes

Choose the mode that best suits
your subjects and surroundings.

Use this mode For

Auto General picture-taking—offers an excellent balance of image quality and

ease of use.

Anti-Blur Minimizing the effects of camera shake and subject movement.

Close-up Close range. Use available light instead of flash if possible. The camera

automatically sets the focus distance depending on the zoom position.

SCN

Scene Point-and-shoot simplicity when taking pictures under special conditions.

(See page 5.)

Video Capturing video with sound. (See page 4.)

4 www.kodak.com/go/support

Scene modes

1 Turn the Mode dial to Scene .

2 Press to display Scene mode descriptions.

NOTE: If the Help text turns off, press the OK button.

3 Press the OK button to choose a Scene mode.

Taking pictures/videos

Use this

For

SCN mode

Hi-ISO Low-light conditions using a higher ISO.
Portrait Full-frame portraits of people.

Panorama
Left-Right

Panorama
Right-Left

Landscape Far-away scenes. The camera uses infinity auto-focus. Auto-focus framing marks

Sport Subjects in motion.
Night

Portrait
Night

Landscape

Stitching up to 3 captured images from left to right into one image.

Stitching up to 3 captured images from right to left into one image.

are not available in Landscape.

Reducing red eye of people in night scenes or low-light conditions. Place the
camera on a flat, steady surface or use a tripod.

Distant scenery at night. Flash does not fire. Place the camera on a flat, steady
surface or use a tripod.

Snow Bright snow scenes.
Beach Bright beach scenes.
Text Documents. Focus is set to Auto Focus (see page 35).
Fireworks Bright, colorful light displays. Flash does not fire. Place the camera on a flat,

steady surface or use a tripod.

Flower Close-ups of flowers or other small subjects in bright light. Focus is set to Auto

Focus (see page 35).

Manner/
Museum

Quiet occasions, like a wedding or lecture. Flash and sound are disabled.

www.kodak.com/go/support

5

Taking pictures/videos

Use this

For

SCN mode

Self­Portrait

Children Action pictures of children in bright light.

Candle light
Backlight Subjects that are in shadow or “backlit” (when light is behind the subject).
Sunset Capturing the deep hues seen at sunset.

Close-ups of yourself. Assures proper focus and minimizes red eye.

Capturing the ambiance of candle light.

6 www.kodak.com/go/support

Taking a picture

Taking pictures/videos

1 2

Use the LCD or viewfinder.
Press to turn on/off:

• LCD (LCD off to use viewfinder)

• Status icons

• Framing grid

• Help (when in Menu)

LCD/Info

Press the Shutter button halfway
to focus and set exposure.

When the Ready light turns green,
press the Shutter button
completely down.

3

Using the framing marks to take pictures

Framing marks indicate the camera focus area. The camera attempts to focus on
foreground subjects, even if the subjects are not centered in the scene.

Framing marks

1 Press the Shutter button halfway.

When the framing marks turn green, focus is
accomplished.

2 If the camera is not focusing on the desired subject

(or if the framing marks disappear), release the
Shutter button and recompose the scene.

3 Press the Shutter button completely down to

take the picture.

NOTE: Framing marks do not appear in Landscape, Night Landscape, Fireworks, or Video mode. When you

use Focus Zone and set Center Zone, the framing marks are fixed at Center Wide.

www.kodak.com/go/support

7

Taking pictures/videos

Taking a video

1 2

Press the Shutter button completely
down and release.

To stop recording, press and release the
Shutter button again.

Reviewing the picture/video just taken

After you take a picture or video, the LCD displays a quickview for approximately 10
seconds. If you press no buttons, the picture or video is saved.

Tag a picture/video for email or as a
favorite, or tag a picture for print.

If you press
no buttons,
the picture/
video is saved.

Delete

Play a video.

(

to adjust volume.)

To review pictures/videos anytime, see page 17.

8 www.kodak.com/go/support

Taking pictures/videos

Understanding blur warning icons

A picture blur warning icon is displayed during quickview and review.

Green—Picture is sharp enough for an acceptable 4 x 6-inch (10 x 15 cm) print.

Yellow—Picture may be sharp enough for an acceptable 4 x 6-inch (10 x 15 cm)

print or sharpness is not determined.

Red—Picture is not sharp enough for an acceptable 4 x 6-inch (10 x 15 cm) print.

White—Printability is still being determined.

www.kodak.com/go/support

9

Taking pictures/videos

Using optical zoom

Use optical zoom to get up to 3X closer to your subject. Optical zoom is effective
when the lens is no closer than 24 in. (60 cm) to the subject or 5.1 in. (12.9 cm) in
Close-up mode. You can change optical zoom before (but not during) video recording.

1 Use the viewfinder or LCD to frame your subject.

2 Press Telephoto (T) to zoom in. Press Wide Angle (W) to zoom out.

The zoom indicator shows zoom status. When you are video recording, only the digital
zoom range appears.

3 Take the picture or video.
NOTE: In Video mode, the zoom indicator changes and only the digital zoom range appears.

Zoom indicator

Optical
zoom
range

WTD

Digital
zoom
range

Using the digital zoom

Use digital zoom in any Still mode or during video recording to get up to 5X
magnification beyond optical zoom.

1 Press Telephoto (T) to the maximum optical zoom limit. Release the button, then

press it again.

2 Take the picture.
NOTE: You may notice decreased image quality when using digital zoom. The slider on the zoom indicator

turns red when the picture quality reaches the limit for an acceptable 4 x 6-in. (10 x 15 cm) print.

10 www.kodak.com/go/support

Taking pictures/videos

Using the flash

Use the flash when you take pictures at night, indoors, or outdoors in heavy shadows.

Press the
through flash modes (see Flash modes below).

The current flash mode appears in the LCD
screen.

button repeatedly to scroll

Flash-to-subject distance

Zoom position Flash distance

Wide angle 2–11.5 ft (0.6–3.5 m) @ ISO 200

Telephoto 2–6.6 ft (0.6–2.0 m) @ ISO 200

Flash modes Flash fires

Auto

When the lighting conditions require it.

Flash

Fill Every time you take a picture, regardless of the lighting conditions. Use when

the subject is in shadow or is “backlit” (when the light is behind the subject).
In low light, hold the camera steady or use a tripod.

Red­eye

If Red-eye Pre-flash is turned off:

■ The flash fires twice (to

evaluate lighting conditions;
and then again when the
picture is taken).

■ The camera then

automatically corrects
red-eye in the picture.

To turn the Red-eye Pre-flash feature on/off, see page 37.

Off Never.

www.kodak.com/go/support

If Red-eye Pre-flash is turned on:

■ The flash fires multiple times (for

focusing in low-light conditions; for the
eyes to become accustomed to the
flash; and when the picture is taken).

11

Taking pictures/videos

Using the self-timer

Use the self-timer when you want to be included in a picture, or to ensure a steady
Shutter button press.

Place camera on a tripod or flat surface.

1

In most Still modes, press the Self-Timer/Burst button

2

• Once for a 10-second delay (so you have time to get into the scene)

• Again for a 2-second delay (for a steady, auto-shutter release on a tripod)

• Again for 2-shot (one picture taken after 10 seconds and another picture
taken 8 seconds later)

Compose the scene.

3

Press the Shutter button halfway, then

4

completely down.

:

To cancel the Self-timer before the picture is taken, press the Self-timer/Burst button

, or press the Shutter button completely down.

Use the same procedure to use the self-timer in Video mode, but:

■ Turn the Mode dial to Video .

■ Press the Shutter button completely down.

NOTE: The video stops when no storage space remains. Only the 2- and 10-second options are available in

video mode.

12 www.kodak.com/go/support

Taking pictures/videos

Using burst

Option Description Purpose

Burst

Camera takes up to 3 pictures while the Shutter button is
pressed.

All the pictures are
saved.

Capture an expected
event.

Example:
A person swinging a
golf club.

1 In most Still modes, press the Self-timer/Burst button .
NOTE: Burst is unavailable in Anti-Blur, Hi-ISO, and Panorama modes.

2 Press the Shutter button halfway to focus and set exposure.

3 Press the Shutter button completely down and hold it to take pictures.

The camera stops taking pictures when you release the Shutter button, when the
pictures are taken, or when there is no more storage space.

NOTE: During quickview, you can delete all pictures in the burst series. To delete selectively, do so in

Review (see page 11).

Using the framing grid to compose a picture

The framing grid divides the LCD into thirds—vertically and horizontally. This is
helpful if, for example, you want to balance a picture between water, earth, and sky.

To turn on the framing grid in Capture mode, press
the LCD/Info button until the grid

appears.

www.kodak.com/go/support

13

Taking pictures/videos

Using exposure compensation to adjust picture
brightness

In Auto, Landscape, Close-up, or Panorama mode, you can adjust exposure
compensation before you take a picture to make your pictures darker or lighter. Only
the first image in Panorama mode is adjusted.

1 Press to decrease exposure compensation.

2 Press to increase exposure compensation.

An exposure compensation level between -2.0 and +2.0 is shown on the LCD as the LCD
image gets darker or lighter.

3 Take the picture when you are satisfied with the exposure compensation level.

Using camera Help

Use the camera Help screen to better understand menu options when the User’s
Guide is not readily available, and you need to obtain information quickly. The Help
screen operates when you are in the main menu or in most submenu selections.

Press
obtain screen Help.

repeatedly to

14 www.kodak.com/go/support

Taking pictures/videos

Taking panoramic pictures

Use panorama to “stitch” up to 3 pictures into a panoramic scene.
NOTE: For best results, use a tripod. Individual pictures are saved only when panorama capture is cancelled

before stitching occurs. (Picture size is set to 3.1 MP for each picture. Exposure and white balance
are set with the first picture. The flash is set to Off.)

1 Turn the Mode dial to SCN.

2 Press on the 4-way button to highlight Panorama Left-Right or Panorama

Right-Left (depending on the direction you want to pan), then press the OK
button.

3 Take the first picture.

After a quickview, the LCD displays the liveview and an “overlay” from the first picture.

4 Compose the second picture. Make the overlay from the first picture cover the

same portion in the new picture. (You may press the Delete button to delete each
panorama picture you took.)

5 If you are taking only 2 pictures, press the OK button to stitch them together.

After you take 3 pictures, the pictures are automatically stitched together.

12 3

Take 2 or 3
pictures.

Get 1
panoramic picture.

NOTE: For printing options, visit the

www.kodak.com/go/support

Kodak EasyShare

Gallery at

www.kodakgallery.com

.

15

Taking pictures/videos

Understanding the picture-taking icons

In capture mode—no buttons pressed

Picture size

Flash

Blur warning

Self-timer

Date stamp

In capture mode—shutter pressed halfway

Pictures/time remaining
Storage location

Zoom:

Exposure metering

White balance

ISO speed

Low battery

Camera mode

Exposure compensation

wide
telephoto
digital

Album

Auto Exposure/
Auto Focus warning

Low battery

Exposure compensation

16 www.kodak.com/go/support

3 Working with pictures/videos

Reviewing pictures/videos

Press the Review button to view and work with your pictures/videos. Press Review
again to exit.

1 Press the Review button.

2 Press to view previous/next picture/video.

To save battery power, use an optional Kodak

Review

NOTE: Pictures taken at the 5.4 MP (3:2) picture size setting are displayed at a 3:2 aspect ratio with a black

bar at the top

and bottom of the screen. A video’s duration is displayed at the top of the LCD.

EasyShare dock or Kodak 3-volt AC adapter. (See

www.kodak.com/go/c653accessories or
www.kodak.com/go/c623accessories.

Magnifying pictures

1 Press the Review button.

2 Press W/T to magnify 2X–8X.

3 Press to view other parts of the

picture.

4 Press the OK button to return to 1X.

NOTE: If you press while at 1X, the view changes from

www.kodak.com/go/support 17

single-picture to multi-up thumbnails. (See page 18.)

Working with pictures/videos

Playing a video

1 Press the Review button.

2 Press to locate previous/next video.

3 Press OK to play or pause a video.

2X

4X

Reverse

Playback speed

1X

2X

Forward

4X

4 Press to adjust the audio volume.

5 Press during playback to play at 2X speed;

press again for 4X.

6 Press to reverse at 2X speed; press again for

4X.

Viewing thumbnails (multi-up)

1 Press the Review button.

2 Press to change from single-picture view to

multi-up thumbnails.

3 Press OK to return to single-picture view.

Viewing picture/video information

18 www.kodak.com/go/support

1 Press the Review button.

2 Repeatedly press the LCD/Info button to

turn on/off status icons and picture/video info.

Deleting pictures/videos

1 Press the Review button.

2 Press for previous/next picture/video.

3 Press the Delete button.

4 Follow the screen prompts.

NOTE: After you delete a picture/video, the next picture/video

(overlaid with the Delete menu with the Undo Delete option)
appears. If there are no more pictures/videos, the Delete
menu on a blank screen appears. See Using the undo delete

feature for more information.

Using the undo delete feature

Working with pictures/videos

If you accidentally delete a picture or video, use Undo Delete to retrieve it. This feature
is available only immediately after you delete a picture/video in Review mode and the
Undo Delete option appears.

1 Press to highlight Undo Delete.

2 Press OK.

The deleted picture/video (overlaid with the Delete menu) appears.

3 Select Exit to exit the Delete menu.

www.kodak.com/go/support

19

Working with pictures/videos

Protecting pictures/videos from deletion

1 Press the Review button.

2 Press for previous/next picture/video.

3 Press the Menu button.

4 Press to highlight Protect, then press OK.

The picture/video is protected and cannot be deleted.
The Protect icon appears with the protected
picture/video.

To remove

protection

, repeat steps 1-4.

The Protect icon is removed from the
picture/video.

■ Press the Menu button to exit the menu.

CAUTION:

Formatting internal memory or an SD or MMC card deletes all (including
protected) pictures/videos. (Formatting internal memory also deletes
email addresses, album names, and favorites. To restore them, see
EasyShare software Help.)

20 www.kodak.com/go/support

Working with pictures/videos

Cropping pictures

You can crop a picture so that only the desired portion of the picture remains.

1 Press the Review button, then to find a

picture.

2 Press the Menu button, choose Crop, then press the


Cropped picture

OK button.

3 Press Telephoto (T) to zoom in, or to move the crop box. Press OK.

4 Follow the screen prompts.

The picture is cropped. The original is saved. (Cropped pictures cannot be cropped
again.)

■ Press the Menu button to exit the menu.

Using Kodak Perfect Touch technology

Kodak Perfect Touch technology helps ensure better, brighter pictures.

1 Press the Review button, then for previous/next picture.

2 Press the Menu button, choose Perfect Touch tech. , then press the OK

button.

The enhancement is previewed in a split screen. Press to view other parts of the
picture.

3 Press OK. Follow the screen prompts to replace the original picture or to save the

enhanced picture as a new one.

NOTE: You cannot enhance previously enhanced or panorama pictures, or videos.

■ Press the Menu button to exit the menu.

www.kodak.com/go/support

21

Working with pictures/videos

Editing videos

Making a picture from a video

You can choose a single frame from a video, then make a picture suitable for printing.

1 Press the Review button, then to find a video.

2 Press the Menu button, choose Make Picture, then

press the OK button.

Video


3 Press OK to select a video frame, then press .

4 Follow the screen prompts.

A picture is created. (The original video is saved.)

■ Press the Menu button to exit the menu.

Trimming a video

You can delete an unwanted portion from the beginning or end of a video.

1 Press the Review button, then to find a video.

2 Press the Menu button, choose Edit Video, then

press the OK button. Choose Trim, then press OK.

3 Follow the screen prompts.

Video

Trimmed video

The video is trimmed. (You can save it as a new video
or replace the original.)

22 www.kodak.com/go/support

■ Press the Menu button to exit the menu.

Working with pictures/videos

Making a video action print

From a video, you can make a 4-, 9-, or 16-up picture, suitable for a 4 x 6-inch
(10 x 15 cm) print.

1 Press the Review button, then to find a

video.

2 Press the Menu button, choose Edit Video, then

press the OK button. Choose Action Print, then

Video

3 Choose an option, then press the OK button.

Auto options: The camera includes the first and last frames, then 2, 7, or 14

equally spaced frames.

4-, 9-, or
16-up picture

press the OK button.

Manual options: You choose the first and last frames; the camera chooses 2, 7,
or 14 equally spaced frames.

■ Press the Menu button to exit the menu.

Running a slide show

Use Slide Show to display your pictures/videos on the LCD.

Starting the slide show

1 Press the Review button, then the Menu button.

2 Press to highlight Slide Show, then press the OK button.

3 Press to highlight Begin Show, then press the OK button.

Each picture/video is displayed once.

To interrupt the Slide Show, press the OK button.

www.kodak.com/go/support

23

Working with pictures/videos

Changing the slide show display interval

The default interval setting displays each picture for 5 seconds. You can set the display
interval from 3–60 seconds.

1 On the Slide Show menu, press to highlight Interval, then press the OK

button.

2 Select a display interval.

To scroll through the seconds quickly, press and hold .

3 Press the OK button.

The interval setting remains until you change it.

Running a continuous slide show loop

When you turn on Loop, the slide show is continuously repeated.

1 On the Slide Show menu, press to highlight Loop, then press the OK

button.

2 Press to highlight On, then press the OK button.

3 Press to highlight Begin Show, then press the OK button.

The slide show repeats until you press the OK button or until battery power is
exhausted. The Loop feature remains until you change it.

24 www.kodak.com/go/support

Working with pictures/videos

Displaying pictures and videos on a television

You can display pictures/videos on a television, computer monitor, or any device
equipped with a video input. To connect the camera to a television, use the A/V
(audio/video) cable (may be sold separately).

NOTE: Ensure that the Video Out setting (NTSC or PAL) is correct (see page 38). The slide show stops if you

connect a cable while the slide show is running. (Image quality on a television screen may not be as
good as on a computer monitor or when printed.)

www.kodak.com/go/support

A/V Cable

25

Working with pictures/videos

Copying pictures/videos

You can copy pictures/videos from a card to internal memory or from internal memory
to a card.

Before you copy, make sure that:

■ A card is inserted in the camera.

■ The camera’s image storage location is set to the location from which you are

copying (see page 36).

Copy pictures/videos:

1 Press the Review button, then the Menu button.

2 Press to highlight Copy , then press the OK button.

3 Press to highlight an option.

4 Press the OK button.

NOTE: Pictures/videos are copied, not moved. To remove pictures/videos from the original location after

copying, delete them (see page 19).
Tags that you applied for print, email, and favorites are not copied. Protection settings are not

copied. To apply protection to a picture/video, see page 20.

26 www.kodak.com/go/support

Working with pictures/videos

Understanding the review icons

Pictures

Print tag/number of prints
Protected

Favorite tag
Email tag

Album

Scroll arrows

Videos

Video length
Favorite tag

Email tag

Blur warning
Kodak Perfect Touch

Picture number
Image storage location

Review mode

Video number

Image storage
location

Date/Time

Scroll arrows

www.kodak.com/go/support

Review mode

27

4 Transferring and printing

pictures

Installing the software

CAUTION:
Install EasyShare software

computer. Failure to do so may cause the software to load
incorrectly.

1 Close all software applications that are open on your computer (including

anti-virus software).

2 Place the EasyShare software CD into the CD-ROM drive.

3 Load the software:

Windows OS—if the install window does not appear, choose Run from the Start
menu and type d:\setup.exe where d is the drive letter that contains the CD.

Mac OS X—double-click the CD icon on the desktop, then click the Install icon.

4 Follow the on-screen instructions to install the software.

NOTE: When prompted, take few minutes to electronically register your camera and software. To register

later, see

www.kodak.com/go/register

before

.

connecting the camera to the

5 If prompted, restart the computer. If you turned off anti-virus software, turn it back

on. See the anti-virus software manual for details.

For information on the software applications included on the EasyShare software CD,
click the Help button in EasyShare software.

28 www.kodak.com/go/support

Transferring and printing pictures

Transferring pictures with the USB cable

1

Turn off camera.

2

Connect USB cable (U-8).

Turn on camera.

3

Kodak EasyShare software opens on your computer
and prompts you through the transfer process.

NOTE: Visit

www.kodak.com/go/howto

for an online tutorial on connecting.

Also available for transferring

You can also use these Kodak products to transfer your pictures and videos.

■ Kodak EasyShare camera dock, Kodak EasyShare printer dock (see page 30)

■ Kodak multi-card reader, Kodak SD multimedia card reader-writer

Purchase these and other accessories at a dealer of Kodak products or

www.kodak.com/go/c653accessories or www.kodak.com/go/c623accessories.

www.kodak.com/go/support

29

Transferring and printing pictures

Printing pictures

Printing with a Kodak EasyShare printer dock

Dock your camera to the Kodak EasyShare printer dock and print directly—with or
without a computer. Purchase this and other accessories at a dealer of Kodak
products or visit www.kodak.com/go/c653accessories or

www.kodak.com/go/c623accessories.

Direct printing with a PictBridge enabled printer

Your camera is compatible with PictBridge technology, so you can print directly to
PictBridge enabled printers. You need:

■ Camera with fully charged batteries ■ PictBridge enabled printer

■ USB cable (may be sold separately)

Connecting the camera to a PictBridge enabled printer

1 Turn off the camera and printer.

2 Connect the appropriate USB cable from the camera to the printer. (See your

printer user guide or visit www.kodak.com/go/c653accessoriesor

www.kodak.com/go/c623accessories.)

30 www.kodak.com/go/support

Transferring and printing pictures

Printing from a PictBridge enabled printer

1 Turn on the printer. Turn on the camera.

The PictBridge logo is displayed, followed by the current picture and menu. (If no
pictures are found, a message is displayed.) If the menu interface turns off, press any
button to redisplay it.

2 Press to choose a printing option, then press the OK button.

Current Picture Press to choose a picture. Choose the number of copies.
Tagged Pictures If your printer is capable, print pictures that you tagged for printing and

choose a print size.

Index Print Print thumbnails of all pictures. This option requires one or more sheets

of paper. If the printer is capable, choose a print size.

All Pictures Print all pictures in internal memory, on a card, or in Favorites. Choose

the number of copies.

Image Storage Access internal memory, a card, or Favorites.

NOTE: During direct printing, pictures are not permanently transferred or saved to the computer or printer.

Disconnecting the camera from a PictBridge enabled printer

1 Turn off the camera and printer.

2 Disconnect the USB cable from the camera and the printer.

Using a printer that is not PictBridge enabled

For details on printing pictures from your computer, click the Help button in EasyShare
software.

www.kodak.com/go/support

31

Transferring and printing pictures

Ordering prints online

Kodak EasyShare

Gallery (www.kodakgallery.com) is one of the many online print

services offered in the Kodak EasyShare software. You can easily:

■ Upload your pictures.

■ Edit, enhance, and add borders to your pictures.

■ Store pictures, and share them with family and friends.

■ Order high-quality prints, photo greeting cards, frames, and albums—and have

them delivered to your door.

Printing from an optional SD/MMC card

■ Automatically print tagged pictures when you insert your card into a printer with

an SD/MMC card slot. See your printer user’s guide for details.

■ Make prints at an SD/MMC-capable Kodak picture maker/picture kiosk. (Contact a

location prior to visiting. See www.kodak.com/go/picturemaker.)

■ Take the card to your local photo retailer for professional printing.

Dock compatibility for your camera

To see which EasyShare printer docks are compatible with your camera, visit

www.kodak.com/go/dockcompatibility.

Purchase camera docks, printer docks, and other accessories at a dealer of Kodak
products or www.kodak.com/go/c653accessories or

www.kodak.com/go/c623accessories.

32 www.kodak.com/go/support

5 Doing more with your camera

Changing picture-taking settings

You can change settings to get the best results from your camera:

1 Press the Menu button.

2 Press to highlight a setting, then press the OK button.

3 Choose an option, then press the OK button.

4 Press the Menu button to exit.

NOTE: Some settings remain until you change them; others remain until you turn the Mode dial or turn off

the camera. Some settings are unavailable in some modes.

NOTE: Press the LCD/Info button for information about camera settings and options.

Setting Options

Picture Size

Choose a picture resolution.

6.1 MP (default)—for printing up to 20 x 30 in. (51 x 76
cm); pictures are highest resolution and largest file size.

5.4 MP (3:2)—ideal for printing 4 x 6 in.
(10 x 15 cm) prints without cropping. Also for printing up to
20 x 30 in. (51 x 76 cm).

4.0 MP— for printing up to 20 x 30 in. (51 x 76 cm);
pictures are medium resolution with smaller file size.

3.1 MP—for printing up to 11 x 14 in. (28 x 36 cm);
pictures are medium resolution with smaller file size.

1.1 MP—for printing 4 x 6 in. (10 x 15 cm), emailing,
Internet, screen display, or for conserving space.

www.kodak.com/go/support 33

Doing more with your camera

Setting Options

White Balance

Choose your lighting condition.

ISO Speed

Control the camera’s sensitivity

to light.

Auto (default)—automatically corrects white balance.
Ideal for general picture taking.

Daylight—for pictures in natural lighting.
Tungsten—corrects the orange cast of household light

bulbs. Ideal for indoor pictures under tungsten or halogen
lighting without flash.

Fluorescent—corrects the green cast of fluorescent
lighting. Ideal for indoor pictures under fluorescent lighting
without flash.

Open Shade—for pictures in shade in natural lighting.

Choose a lower ISO setting in brightly lit scenes; use a
higher ISO for low-light scenes. Choose Auto (default), 80,
100, 200, 400, 800, 1250.

NOTE: ISO returns to Auto when the camera is set to Portrait, or

SCN mode, or during Long Time Exposure.

Exposure Metering

Evaluate light levels at specific

areas of a scene.

Unavailable in Video mode.

Multi-pattern (default)—evaluates lighting conditions
throughout the image to give an optimum picture exposure.
Ideal for general picture taking.

Center-weighted—evaluates the lighting conditions of
the subject centered in the viewfinder. Ideal for backlit
subjects.

Center-Spot—similar to Center-weighted, except the
metering is concentrated on a smaller area of the subject
centered in the viewfinder. If used with Selectable AF zones,
the exposure spot follows the focus zone. Ideal when you
need an exact exposure of a specific area in the picture.

34 www.kodak.com/go/support

Setting Options

Doing more with your camera

Auto Focus Zone

Select a large or concentrated

area of focus.

Color Mode

Choose color tones.

Multi-zone (default)—evaluates 5 zones to give an even
picture focus. Ideal for general picture taking.

Center-zone—evaluates the small area centered in the
viewfinder. Ideal when precise focus of a specific area in the
picture is needed.

NOTE: For the best pictures, the camera is set to Multi-zone when

in Landscape mode.

High Color
Natural Color (default)
Low Color
Black & White
Sepia—pictures have a reddish-brown, antique look.

NOTE: EasyShare software also lets you change a color picture to

black-and-white or sepia.

Unavailable in Video mode.

Long Time Exposure

Choose how long the shutter

stays open.

Set Album

Choose Album names.

Maintain Settings

Choose which settings are

saved, even after the camera is

turned off.

Available only in Auto and

Close-up modes.

0.5 - 4.0 seconds

On or Off

Pre-select album names before you take pictures or videos.
Then, all the pictures or videos you take are tagged with
those album names. See page 40.

Exit (default)
Flash
White Balance
ISO Speed
Color mode
Exposure Metering
Focus Zone

www.kodak.com/go/support

35

Doing more with your camera

Setting Options

Image Storage

Choose a storage location for

pictures/videos.

Video Size

Available only in Video mode.

Setup Menu

Choose additional settings.

Auto (default)—the camera uses the card if one is in the
camera. If not, the camera uses internal memory.

Internal Memory—the camera uses internal memory,
even if a card is installed.

NOTE: If you fill up your card while taking pictures, your camera’s

memory plus feature prompts you to switch to internal
memory, if space is available. Memory plus is unavailable in
Video mode.

640 x 480
320 x 240

See Customizing your camera on page 37.

36 www.kodak.com/go/support

Doing more with your camera

Customizing your camera

Use Setup to customize your camera settings.

1 In any mode, press the Menu button.

2 Press to highlight Setup , then press the OK button.

3 Press to highlight the setting you wish to change, then press the OK button.

4 Choose an option, then press the OK button.

5 Press the Menu button to exit.

NOTE: These settings remain until you change them.

NOTE: Press the LCD/Info button for information about camera settings and options.

Setting Options

Return to previous menu.
Liveview

Change liveview default to on or off.

On (default)
Off

NOTE: In some modes, the LCD turns on even if

the liveview option is set to Off. (To turn
the LCD on/off any time, press the
LCD/Info button.)

Orientation Sensor

Orient pictures so that they are displayed
with the correct side up.

Red-eye Pre-flash

Choose if the Red-eye flash fires
automatically before a picture is taken.

On (default)
Off

On (default)
Off

NOTE: The camera automatically corrects red-eye,

when the Red-eye Pre-flash is set to Off.

www.kodak.com/go/support

37

Doing more with your camera

Setting Options

Camera Sounds

Choose sound effects.

Theme—applies the same sound effect set to
all functions.

Individual—choose a sound effect for each
function.

Sound Volume Off

Low (default)
Medium

High
Date & Time See page 2.
Auto Power Off

Choose inactivity time until camera turns off.

10 minutes

5 minutes

3 minutes (default)

1 minute

Video Out

Choose the regional setting that lets you

NTSC (default)—used in North America and

Japan; most common format.
connect the camera to a television or other

PAL—used in Europe and China.
external device.

Date Stamp

Imprint the date on pictures.

Video Date Display

Display Date/Time at the start of video

Choose a date option, or turn off the feature.

(Default is off.)

On (default)—choose from date formats.

Off

playback.
Language See page 2.

38 www.kodak.com/go/support

Setting Options

Doing more with your camera

Format

CAUTION:
Formatting deletes all

pictures/videos, including
those that are protected.
Removing a card during
formatting may damage
the card.

About

View camera information.

Memory Card—deletes everything on the

card; formats the card.

Cancel—exits without making a change.

Internal Memory—deletes everything in

internal memory including email addresses,

album names, and favorites; formats the

internal memory.

www.kodak.com/go/support

39

Doing more with your camera

Pre-tagging for album names

Use the Set Album (Still or Video) feature to pre-select album names before you take
pictures or videos. Then, all the pictures or videos you take are tagged with those
album names.

First—on your computer

Use the EasyShare software that was packaged with your camera to create album
names on your computer. The next time you connect the camera to the computer, copy
up to 32 albums to the album name list. See EasyShare software Help for details.

Second—on your camera

1 In any mode, press the Menu button.

2 Press to highlight Set Album , then press the OK button.

3 Press to highlight an album name, then press the OK button. Repeat to

mark pictures or videos for albums.

Selected albums are noted with a check mark.

4 To remove a selection, highlight an album name and press the OK button. To

remove all album selections, select Clear All.

5 Highlight Exit, then press the OK button.

Your selections are saved. If you turn on the LCD, your album selection is displayed on
the screen. A plus (+) after the album name means more than one album is selected.

6 Press the Menu button to exit the menu.

Third—transfer to your computer

When you transfer the tagged pictures or videos to your computer, EasyShare
software opens and categorizes your pictures in the appropriate album. See EasyShare
software Help for details.

40 www.kodak.com/go/support

Doing more with your camera

Tagging pictures/videos for albums

Use the Album feature in Review mode to tag the pictures/videos in your camera with
album names.

First—on your computer

Use EasyShare software to create albums on your computer, then copy up to 32 album
names to the camera’s internal memory. See EasyShare software Help for details.

Second—on your camera

1 Press the Review button, then locate the picture or video.

2 Press the Menu button.

3 Press to highlight Album , then press the OK button.

4 Press to highlight an album folder, then press the OK button.

5 To add other pictures to the same album, press to scroll through the pictures.

When the picture you want is displayed, press the OK button.

6 To add the pictures to more than one album, repeat step 4 for each album.

The album name appears with the picture. A plus (+) after the album name means the
picture was added to more than one album.

To remove a selection, highlight an album name and press the OK button. To remove
all album selections, select Clear All.

Third—transfer to your computer

When you transfer the tagged pictures/videos to your computer, EasyShare software
opens and categorizes your pictures/videos in the appropriate album folder. See
EasyShare software Help for details.

www.kodak.com/go/support

41

Doing more with your camera

Sharing your pictures

Press the Share button to tag your pictures and videos. When they are transferred to
your computer, you can share them. Use the Share button:

■ Any time. (The most recent picture/video taken is then displayed.)

■ Just after you take a picture/video, during quickview.

■ After pressing the Review button.

Tagging pictures for printing

1 Press the Share button. Press to locate a picture.

2 Press to highlight Print , then press the OK button.*

3 Press to select the number of copies (0-99). Zero removes the tag for that

picture.
Optional: You can apply a print quantity to other pictures. Press to locate a
picture. Press to change the print quantity. Repeat until the desired print

quantity is applied to pictures.

4 Press the OK button.

The Print icon appears in the status area.

5 Press the Share button to exit the menu.

* To tag all pictures in the storage location, highlight Print All, press the OK button,
then indicate the number of copies. Print All is not available in quickview. To remove
print tagging for all pictures in the storage location, highlight Cancel Prints, then press
the OK button. Cancel Prints is not available in quickview.

Printing tagged pictures

When you transfer the tagged pictures to your computer, the Kodak EasyShare
software print screen opens. For details, click the Help button in EasyShare software.

For more information on printing from your computer, printer dock, PictBridge
enabled printer, or card, see page 30.

42 www.kodak.com/go/support

Doing more with your camera

NOTE: For the best 4 x 6 in. (10 x 15 cm) prints, set the camera to the 5.4 MP (3:2) picture size setting.

(See page 33.)

Tagging pictures and videos for emailing

First—on your computer

Use Kodak EasyShare software to create an email address book on your computer.
Then copy up to 32 email addresses to the camera’s internal memory. For details, click
the Help button in EasyShare software.

Second—tag pictures/videos on your camera

1 Press the Share button. Press to locate a picture/video.

2 Press to highlight Email , then press the OK button.

The Email icon appears in the status area.

3 Press to highlight an email address, then press the OK button.

4 To tag other pictures/videos with the same address, press to scroll through

them. When the picture you want is displayed, press OK.

5 To send the pictures/videos to more than one address, repeat step 3 for each

address.

Selected addresses are checked.

6 To remove a selection, highlight a checked address and press the OK button. To

remove all email selections, highlight Clear All.

7 Press to highlight Exit, then press the OK button.

8 Press the Share button to exit the menu.

Third—transfer and email

When you transfer the tagged pictures/videos to your computer, the Email screen
opens and lets you send them to the addresses you specified. For details, click the
Help button in Kodak EasyShare software.

www.kodak.com/go/support

43

Doing more with your camera

Tagging pictures as favorites

You can preserve your favorite pictures in the Favorites section of your camera’s
internal memory, then share them with friends and family.

NOTE: When you transfer pictures from your camera to your computer, all pictures (including favorites) are

stored on your computer at full size. Favorite pictures - smaller copies of your originals - are loaded
back to your camera, so you can share and enjoy more.

1. Tag pictures as
favorites

2. Transfer
pictures to your
computer

3. View favorites
on your camera

1 Press the Share button. Press to locate a picture.

2 Press to highlight Favorite , then press the OK button.

The Favorite icon appears in the status area. To remove the tag, press
the OK button again.

Press the Share button to exit the menu.

1 To enjoy all the available features, load and use the EasyShare

software that was packaged with this camera. (See page 28.)

2 Connect the camera to the computer using the USB cable (see

page 29) or an EasyShare dock.

The first time you transfer pictures, the software helps you make choices
about your favorite pictures. Then, your pictures are transferred to the
computer. Favorite pictures (smaller versions of the originals) are loaded
to the Favorites section of your camera’s internal memory.

1 Turn the Mode dial to Favorites .
2 Press to scroll through favorites.

NOTE: The camera holds a limited number of favorites. Use Camera Favorites in the EasyShare software to

customize the size of your camera Favorites section. Videos tagged as favorites remain in the
Favorites folder in EasyShare software. For details, click the Help button in EasyShare software.

44 www.kodak.com/go/support

Doing more with your camera

Optional settings

In Favorites mode, press the Menu button to access optional settings.

Slide Show (page 23) Remove favorites (page 45)

Multi-up (page 18) Setup Menu (page 37)

NOTE: Pictures taken at the 5.4 MP (3:2) picture size setting are displayed at a 3:2 aspect ratio with a black

bar at the top and bottom of the screen.

Removing favorites from your camera

1 Turn the Mode dial to Favorites .

2 Press the Menu button.

3 Highlight Remove Favorites , then press the OK button.

All pictures stored in the Favorites section of internal memory are removed. Favorites are
restored the next time you transfer pictures to the computer.

4 Press the Menu button to exit the menu.

Preventing favorites from transferring to the camera

1 Open Kodak EasyShare software. Click the My Collection tab.

2 Go to the Albums view.

3 Click the Camera Favorites Album for your camera.

4 Click Remove Album.

The next time you transfer pictures from your camera to the computer, use the Camera
Favorites Wizard/Assistant to either recreate your Camera Favorites Album or to turn off
the Camera Favorites feature.

www.kodak.com/go/support

45

Doing more with your camera

Printing and emailing favorites

1 Turn the Mode dial to Favorites . Press to locate a picture.

2 Press the Share button.

3 Highlight Print or Email , then press the OK button.

NOTE: Favorites that were taken on this camera (not imported from another source) are good for prints up

to 4 x 6 in. (10 x 15 cm).

46 www.kodak.com/go/support

6 Troubleshooting

For step-by-step product support, visit www.kodak.com/go/c653support or

www.kodak.com/go/c623support and select Interactive Troubleshooting & Repairs.

Camera problems

If... Try one or more the following

Camera does not
turn on.

Camera does not
turn off.

Pictures remaining
number does not
decrease after
taking a picture.

Short battery life
with Kodak Ni-MH
rechargeable
digital camera
batteries.

■ Install new batteries (page 1).

■ Charge rechargeable batteries.

■ Remove the battery, then reinsert or replace it. If the camera still does

not function, visit www.kodak.com/go/c653support or

www.kodak.com/go/c623support and select Interactive

Troubleshooting & Repairs.

■ The camera is operating normally. Continue taking pictures.

■ Wipe the contacts with a clean, dry cloth (see page 62) before loading

batteries in the camera.

■ Limit the following activities that quickly deplete battery power:

reviewing pictures/videos on the LCD; using the LCD as a viewfinder;
and excessive use of the flash.

■ Use the Refresh feature on your camera dock series 3 or printer dock

series 3.

Stored pictures are
corrupted.

■ Retake pictures. Do not remove card while the Ready light is blinking.

Keep rechargeable batteries charged.

Transfer the pictures to the computer (page 29), then format the card in the
camera (see page 39).

Caution: Formatting a card deletes all pictures and videos,
including protected files.

www.kodak.com/go/support 47

Troubleshooting

If... Try one or more the following

In Review mode,
you do not see a
picture (or the
expected picture)
on the LCD screen.

In Review mode, a
blue or black
screen is displayed
instead of a
picture.

Shutter button
does not work.

Slide show does
not run on external
video device.

■ Check the image storage location setting (see page 36).

■ Transfer the picture to the computer (page 29), then format the card in

the camera (see page 39).

Caution: Formatting a card deletes all pictures and videos,
including protected files.

■ Turn on the camera (page 2).

■ Wait until the Ready light stops blinking red before attempting to take

another picture.

■ Transfer pictures to the computer (page 29), delete pictures from the

camera (page 19), switch image storage locations (see page 36), or
insert a card with available memory (page 3).

■ Adjust the camera Video Out setting (NTSC or PAL, see page 38).

■ See the external device’s user’s guide.

Picture is too light.

■ Move so there is at least 2 ft (0.6 m) between the camera and the

subject.

■ Decrease Exposure Compensation (page 14).

Picture is not clear.

■ Clean the lens (see page 62).

■ Make sure your camera is not in Close-up mode.

■ Move so there is at least 2 ft (0.6 m) between the camera and the

subject.

■ Place the camera on a flat, steady surface or use a tripod.

48 www.kodak.com/go/support

If... Try one or more the following

Troubleshooting

Picture is too dark.

Camera does not
recognize
SD/MMC card.

Camera freezes up
when a card is
inserted or
removed.

■ Turn on the flash (page 11).

■ Move so there is no more than 11.8 ft (3.6 m) in wide angle and

6.9 ft (2.1 m) in telephoto between the camera and the subject.

■ Use Fill flash (see page 11) or change your position so light is not

behind the subject.

■ Increase Exposure Compensation (page 14).

■ Purchase a certified SD/MMC card.

■ Reformat the card (see page 39).

Caution: Formatting a card deletes all pictures and videos,
including protected files.

■ Insert a card into the slot, then push to seat (page 3).

■ Turn the camera off, then back on. Make sure the camera is turned off

before inserting or removing a card.

Memory card full.

■ Insert a new card (page 3), transfer pictures to the computer

(page 29), or delete pictures (page 19).

Memory card and
internal memory
full.

■ Transfer pictures to the computer (page 29), then format the card or

internal memory (see page 39).

Caution: Formatting a card deletes all pictures and videos,
including protected files.

Camera ready light status

If... Try one or more of the following

Ready light does
not turn on and the
camera does not
work.

■ Turn on the camera (page 2).

■ Install new batteries (page 1) or charge rechargeable batteries.

■ Turn camera off, then back on.

www.kodak.com/go/support

49

Troubleshooting

If... Try one or more of the following

Ready light blinks
green.

Ready light blinks
amber.

Ready light blinks
red and camera
turns off.

Ready light glows
steady red.

Ready light glows
steady green.

Ready light is off

■ Camera is operating normally.

■ Wait. Resume picture taking when the light stops blinking and turns

green.

■ Install new batteries (page 1) or charge rechargeable batteries.

■ Transfer pictures to the computer (page 29), delete pictures from the

camera (page 19), switch image storage locations (see page 36), or
insert a card with available memory (page 3).

■ Wait. Resume picture taking when the light turns green.

■ Change the image storage location to internal memory (see page 36),

or use a different card.

■ Camera is operating normally.

■ Camera is operating normally.

and LCD is on.

Camera/computer communications

If... Try one or more of the following

The computer does
not communicate
with the camera.

■ Visit www.kodak.com/go/c653support or

www.kodak.com/go/c623support.

■ Turn on the camera (page 2).

■ Install new batteries (page 1) or charge rechargeable batteries.

■ Connect cable to camera and computer port (page 29).

■ Install the software (page 28).

■ Disconnect the USB cable. Close all open applications. Re-install the

software (page 28).

■ Disconnect camera from the computer. Close all software applications,

reconnect camera.

50 www.kodak.com/go/support

If... Try one or more of the following

Troubleshooting

Cannot transfer
pictures.

(The Add New
Hardware Wizard
cannot locate
drivers.)

■ Disconnect USB cable. (If using camera dock or printer dock,

disconnect cable and remove camera from dock). Close all open
applications. Re-install the software (page 28).

■ Disconnect the USB cable. Close all open applications. Re-install the

software (page 29).

LCD screen messages

If... Try one or more of the following

No images to
display

Memory card
requires
formatting

Memory card

■ Change image storage location setting (see page 36).

■ Insert a new card (page 3) or format the card (see page 39).

Caution: Formatting a card deletes all pictures and videos,
including protected files.

cannot be read
(Please format
memory card or
insert another
card)

Only one USB
connection
allowed.

Disconnect cable
or rem. (remove)
camera from dock.

■ Unplug the USB cable from the camera.

www.kodak.com/go/support

51

Troubleshooting

If... Try one or more of the following

Internal memory
requires
formatting

Internal memory
cannot be read
(Please format
internal memory)

No memory card
(Files not copied)

Not enough space
to copy files (Files
not copied)

Memory card is
locked (Insert new
memory card)

Read-only memory

■ Format the internal memory (see page 39).

Caution: Formatting deletes all pictures and videos, including
protected files. (Formatting internal memory also deletes email
addresses, album names, and Favorites. To restore them, see the
Kodak EasyShare software Help.)

■ Insert a card (page 3).

■ Delete pictures from the image storage location you are copying to

(page 19), or insert a new card (page 3).

■ Insert a new card (page 3), move the switch on the card to unlock the

card, or change the image storage location to internal memory (see

page 36).

card.
Remove write

protection to
capture or write to
card.

Memory card is
unusable (Insert
new memory card)

Date and time
have been reset

No address book
on camera
(Connect with
computer to
import address
book)

■ Insert a new card (page 3) or format the card (see page 39).

Caution: Formatting a card deletes all pictures and videos,
including protected files.

■ Reset the clock (page 2).

■ Create and copy address book from computer. See the Kodak

EasyShare software Help.

52 www.kodak.com/go/support

If... Try one or more of the following

Troubleshooting

No album names
on camera
(Connect with
computer to
import album
names)

High camera
temperature.
(Camera will be
turned off.)

Can only mark
image with 32
album names. Only
the first 32 album
names will be
saved

■ Create and copy album names from computer. See the Kodak

EasyShare software Help.

■ Leave the camera off until it’s cool to the touch, then turn it back on.

If the message reappears, visit www.kodak.com/go/c653support or

www.kodak.com/go/c623support and select Interactive Troubleshooting &

Repairs.

■ Delete one or more album names associated with the image

(page 40).

Unrecognized file
format

Camera error
#XXXX. See user’s
guide.

■ Transfer the picture to the computer (page 29), or delete it (page 19).

■ Turn camera off, then back on. If the message reappears, visit

www.kodak.com/go/c653support or www.kodak.com/go/c623support

and select Interactive Troubleshooting & Repairs.

www.kodak.com/go/support

53

7 Getting help

Helpful links

Camera

Email, write, or phone customer support www.kodak.com/go/contact
Get support for your product (FAQs,

troubleshooting information, arrange for repairs,
etc.)

Purchase camera accessories (camera docks,
printer docks, lenses, cards, etc.)

Download the latest camera firmware and
software

See online demonstrations of your camera www.kodak.com/go/howto

www.kodak.com/go/c653support or
www.kodak.com/go/c623support

www.kodak.com/go/c653accessories or
www.kodak.com/go/c623accessories

www.kodak.com/go/c653downloads or
www.kodak.com/go/c623downloads

Software

Get information on EasyShare software www.kodak.com/go/easysharesw (or click

the Help button in EasyShare software)

Get help with the Windows operating system and
working with digital pictures

www.kodak.com/go/pcbasics

Other

Get support for other cameras, software, accessories www.kodak.com/go/support
Get information on Kodak EasyShare printer docks www.kodak.com/go/printerdocks
Get information on Kodak inkjet products www.kodak.com/go/inkjet
Optimize your printer for truer, more vibrant colors www.kodak.com/go/onetouch
Register your camera www.kodak.com/go/register

54 www.kodak.com/go/support

Getting help

NOTE: If you have questions concerning this product, you may speak with Kodak customer support.

Australia 1800 147 701 New Zealand 0800 440 786
Austria 0179 567 357
Belgium 02 713 14 45
Brazil 0800 891 4213
Canada 1 800 465 6325
China 800 820 6027
Denmark 3 848 71 30
Ireland 01 407 3054
Finland 0800 1 17056
France 01 55 1740 77
Germany 069 5007 0035
Greece 00800 44140775
Hong Kong 800 901 514
India 91 22 617 5823
Italy 02 696 33452

Norway 23 16 21 33
Philippines 1 800 1 888 9600
Poland 00800 4411625
Portugal 021 415 4125
Russia 8 495 929 9166
Singapore 800 6363 036
Spain 91 749 76 53
Sweden 08 587 704 21
Switzerland 01 838 53 51
Taiwan 0800 096 868
Thailand 001 800 631 0017
Turkey 00800 448827073
United Kingdom 0870 243 0270

United States 1 800 235 6325
Japan 03 5540 9002
Korea 080 708 5600
Netherlands 020 346 9372

www.kodak.com/go/support

International Toll Line [phone]

International Toll Fax [phone]

55

8 Appendix

Camera specifications

For more specifications, visit www.kodak.com/go/c653support or

www.kodak.com/go/c623support.

Kodak EasyShare C653/C623 zoom digital camera

CCD (charge-coupled device)

CCD 1/2.5 in. CCD, 4:3 aspect ratio
Output image size 6.1 MP: 2848 x 2144 pixels

5.4 MP (3:2): 2848 x 1899 pixels

4.0 MP: 2304 x 1728 pixels

3.1 MP: 2048 x 1536 pixels

1.1 MP: 1200 x 900 pixels

Displays

Color display 6.1 cm (2.4 in) color hybrid LCD, 112 K (480 x 234) pixels
Preview Frame rate: 30 fps; Field-of-view: 100%.

Lens

Taking lens 3X optical zoom lens f/2.73 - f/4.85

Aperture: maximum - f/2.73; minimum - f/8.54

36 mm - 108 mm (35 mm equivalent)
Lens barrier Automatic built-in
Focus system TTL-AF; Multi-zone AF, and Center-zone AF. Working range:

0.6 m (24 in.)-infinity @ normal

0.10 - 0.7 m (3.9-27.6 in.) @ wide close-up

0.20 - 0.7 m (7.9-27.6 in.) @ telephoto close-up

10 m (32.8 ft.)-infinity @ Landscape
Digital zoom 5.0X continuous with 0.2X increments

56 www.kodak.com/go/support

Kodak EasyShare C653/C623 zoom digital camera

Combined zoom 15X

Exposure

Exposure metering TTL-AE; Multi-pattern; Center-weighted; Center spot
Exposure compensation +/-2.0 EV with 1/3 EV steps
Shutter speed Mechanical shutter with CCD electrical

Auto: 4 - 1/1400 sec.

Appendix

ISO speed

Auto, Snow, Beach, Backlight, Sunset: 80-200

Close-up, Landscape, Flower, Text, Panorama: 80-160

Candlelight, Children: 80-400

Manner/Museum: 80-800

Sport, Anti-Blur, Hi-ISO: 80-1250

Anti-Blur, Hi-ISO: 80-1250

Portrait, Night Portrait: 80 - 140

Self-Portrait, Night Landscape, Fireworks, Long Time Exposure: 80

Flash

Electronic flash Guide no. 7.0 (@ ISO 100)

Auto flash with pre-flash

Working range at ISO 200: 0.6-3.5 m (2-11.5 ft.) @ Wide

0.6-2.0 m (2-6.6 ft.) @ Tele

Flash modes Auto, Fill, Red-eye, Off

Capture

Capture modes Auto, Anti-Blur, Close-up, SCN (19 scene modes), Video
Video capture VGA (640 x 480) @ 10 fps

QVGA (320 x 240) @ 20 fps
Image file format Still: EXIF 2.21 (JPEG compression); file organization: DCF

Video: MOV; CODEC Motion JPEG; G.711 (audio)
Image storage Optional SD/MMC Card . (The SD logo is a trademark of the

SD Card Association.)

www.kodak.com/go/support

57

Appendix

Kodak EasyShare C653/C623 zoom digital camera

Internal storage
capacity

Review

Quickview Yes
Video output NTSC or PAL selectable

Power

2 Kodak oxy-alkaline digital camera batteries AA ZR6 (non-rechargeable); 2-AA lithium digital
camera batteries; 2-AA alkaline batteries; 2 Kodak Ni-MH rechargeable digital camera batteries
AA; 1 Kodak lithium digital camera battery CRV3 (non-rechargeable); 1 Kodak Ni-MH
rechargeable digital camera battery KAA2HR, 3V AC adapter

Communication with computer

USB 2.0 (PIMA 15740 protocol), via USB cable model U-8, EasyShare camera dock or printer
dock

Other features

PictBridge support Yes

32 MB internal memory/22 MB available for image storage

(1 MB equals one million bytes)

Self Timer 2 seconds, 10 seconds, or 2-shot
White balance Auto, Daylight, Tungsten, Fluorescent, Open Shade
Auto power off Selectable 1, 3, 5, 10 minutes

Microphone Yes (for audio recording at Video mode)

Speaker Yes
Color modes Color (High, Natural, Low), Black & White, Sepia
Date stamp None, YYYY/MM/DD, MM/DD/YYYY, DD/MM/YYYY
Tripod mount 1/4 inch
Viewfinder Optical, real-image; 81% field of view
Operating temperature 32-104
Size 89 mm (3.5 in.) x 66 mm (2.6 in.) x 35 mm (1.4 in.) @ power off
Weight 145 g (5.1 oz.) without battery or card

°F (0-40°C)

58 www.kodak.com/go/support

Appendix

Storage capacities

Actual storage capacity varies depending on subject composition, card brand, and
other factors. You may be able to store more or fewer pictures and videos. Favorites
take up additional space in internal memory.

Picture storage capacity

Number of pictures

6.1 MP 5.4 MP (3:2) 4.0 MP 3.1 MP 1.1 MP
Internal memory 13 15 20 26 66
32 MB SD/MMC 19 21 28 35 89
64 MB SD/MMC 39 43 58 73 183
128 MB SD/MMC 80 89 119 149 372
256 MB SD/MMC 158 174 233 292 725
512 MB SD/MMC 326 360 482 603 1496
1 GB SD/MMC 629 694 929 1161 2878

Video storage capacity

Minutes/seconds of video

VGA (640 x 480) QVGA (320 x 240)
Internal memory 42 sec. 1 min. 21 sec.
32 MB SD/MMC 57 sec. 1 min. 49 sec.
64 MB SD/MMC 1 min. 58 sec. 3 min. 45 sec.
128 MB SD/MMC 4 min. 7 min. 36 sec.
256 MB SD/MMC 7 min. 49 sec. 14 min. 49 sec.
512 MB SD/MMC 16 min. 8 sec. 30 min. 35 sec.
1 GB SD/MMC 31 min. 2 sec. 58 min. 49 sec.

www.kodak.com/go/support

59

Appendix

Important safety instructions

CAUTION:

Do not disassemble this product; there are no user-serviceable parts
inside. Refer servicing to qualified service personnel. Kodak AC adapters
and battery chargers are intended for indoor use only. The use of controls,
adjustments, or procedures other than those specified herein may result
in exposure to shock and/or electrical or mechanical hazards. If the LCD
breaks, do not touch the glass or liquid. Contact Kodak customer support.

■ The use of an accessory that is not recommended by Kodak may cause fire, electric

shock, or injury. For approved accessories, visit www.kodak/go/accessories.

■ Use only a USB-certified computer equipped with a current-limiting motherboard.

Contact your computer manufacturer if you have questions.

■ If using this product in an airplane, observe all instructions of the airline.

■ When removing the battery, allow it to cool; it may be hot.

■ Read and follow all warnings and instructions supplied by the battery

manufacturer.

■ Use only batteries approved for this product to avoid risk of explosion.

■ Keep batteries out of the reach of children.

■ Do not allow batteries to touch metal objects, including coins. Otherwise, a battery

may short circuit, discharge energy, become hot, or leak.

■ Do not disassemble, install backward, or expose batteries to liquid, moisture, fire,

or extreme temperature.

■ Remove the battery when the product is stored for an extended period of time. In

the unlikely event that battery fluid leaks inside the product, contact Kodak
customer support.

■ In the unlikely event that battery fluid leaks onto your skin, wash immediately with

water and contact your local health provider. For additional health-related
information, contact your local Kodak customer support.

60 www.kodak.com/go/support

Appendix

■ Dispose of batteries according to local and national regulations. Visit

www.kodak.com/go/kes.

■ Do not charge non-rechargeable batteries.

For more information on batteries, see www.kodak.com/go/batterytypes.

Battery life

Use these Kodak batteries. (Battery types are also molded into the battery door.)

CRV3 lithium battery

AA (2) lithium batteries

Ni-MH rechargeable digital
camera battery (per charge)

AA (2) Ni-MH rechargeable
batteries (per charge)

AA (2) oxy-alkaline
non-rechargeable batteries

AA (2) alkaline
non-rechargeable batteries

500 - 700

500 - 700

300 - 500

300 - 500

200 - 300

100 - 200

0

Approximate number of pictures in Auto mode

(CIPA testing method using 128 MB SD card)

400

700

For acceptable battery life, and to make sure your camera operates dependably, use
the batteries listed. Actual battery life may vary based on usage.

www.kodak.com/go/support

61

Appendix

Extending battery life

■ See Auto Power Off (see page 38).

■ Limit the following activities that quickly deplete battery power:

– Reviewing your pictures on the LCD (see page 17)

– Using the LCD as a viewfinder (see page 7)

– Excessive use of the flash

■ Dirt on the battery contacts can affect battery life. Wipe the contacts with a clean,

dry cloth before loading batteries in the camera.

■ Battery performance is reduced at temperatures below 41° F (5° C). When using

your camera in cold weather, carry spare batteries and keep them warm. Do not
discard cold batteries that do not work; when they return to room temperature,
they may be usable.

Upgrading your software and firmware

Download the latest versions of the software included on the Kodak EasyShare
software CD and the camera firmware (the software that runs on the camera). See

www.kodak.com/go/c653downloads or www.kodak.com/go/c623downloads.

Care and maintenance

■ If you suspect water has gotten inside the camera, remove the battery and card.

Allow all components to air-dry for at least 24 hours before using the camera.

■ Blow gently on the lens or LCD to remove dust and dirt. Wipe gently with a soft,

lint-free cloth or an untreated lens-cleaning tissue. Do not use cleaning solutions
unless designed specifically for camera lenses. Do not allow chemicals, such as
suntan lotion, to contact painted surfaces.

■ Service agreements may be available in your country. Contact a dealer of Kodak

products for more information.

■ For digital camera disposal or recycling information, contact your local authorities.

62 www.kodak.com/go/support

Appendix

In the US, visit the Electronics Industry Alliance Web site at www.eiae.org or the
Kodak Web site at www.kodak.com/go/c653support or

www.kodak.com/go/c623support.

Warranty

Limited warranty

Kodak warrants Kodak consumer electronic products and accessories ("Products"),
excluding batteries, to be free from malfunctions and defects in both materials and
workmanship for one year from the date of purchase.

Retain the original dated sales receipt. Proof of the date of purchase will be required
with any request for warranty repair.

Limited warranty coverage

Warranty service is only available from within the country where the Products were
originally purchased. You may be required to ship Products, at your expense, to the
authorized service facility for the country where the Products were purchased.

Kodak will repair or replace Products if they fail to function properly during the
warranty period, subject to any conditions and/or limitations stated herein. Warranty
service will include all labor as well as any necessary adjustments and/or replacement
parts. If Kodak is unable to repair or replace a Product, Kodak will, at its option,
refund the purchase price paid for the Product provided the Product has been
returned to Kodak along with proof of the purchase price paid. Repair, replacement,
or refund of the purchase price are the sole remedies under the warranty.

If replacement parts are used in making repairs, those parts may be remanufactured,
or may contain remanufactured materials. If it is necessary to replace the entire
Product, it may be replaced with a remanufactured Product. Remanufactured
Products, parts and materials are warranted for the remaining warranty term of the
original Product, or 90 days after the date of repair or replacement, whichever is
longer.

www.kodak.com/go/support

63

Appendix

Limitations

This warranty does not cover circumstances beyond Kodak’s control. This warranty
does not apply when failure is due to shipping damage, accident, alteration,
modification, unauthorized service, misuse, abuse, use with incompatible accessories
or attachments (such as third party ink or ink tanks), failure to follow Kodak’s
operation, maintenance or repacking instructions, failure to use items supplied by
Kodak (such as adapters and cables), or claims made after the duration of this
warranty.

Kodak makes no other express or implied warranty for this product, and
disclaims the implied warranties of merchantability and fitness for a
particular purpose. In the event that the exclusion of any implied warranty is

ineffective under the law, the duration of the implied warranty will be one year from
the purchase date or such longer period as required by law.

The option of repair, replacement, or refund is Kodak’s only obligation. Kodak will not
be responsible for any special, consequential or incidental damages resulting from the
sale, purchase, or use of this product regardless of the cause. Liability for any special,
consequential or incidental damages (including but not limited to loss of revenue or
profit, downtime costs, loss of the use of the equipment, cost of substitute
equipment, facilities or services, or claims of your customers for such damages
resulting from the purchase use or failure of the Product), regardless of cause or for
breach of any written or implied warranty is expressly disclaimed.

Your rights

Some states or jurisdictions do not allow exclusion or limitation of incidental or
consequential damages, so the above limitation or exclusion may not apply to you.
Some states or jurisdictions do not allow limitations on how long an implied warranty
lasts, so the above limitation may not apply to you.

This warranty gives you specific rights, and you may have other rights which vary from
state to state or by jurisdiction.

64 www.kodak.com/go/support

Appendix

Outside the United States and Canada

In countries other than the United States and Canada, the terms and conditions of
this warranty may be different. Unless a specific Kodak warranty is communicated to
the purchaser in writing by a Kodak company, no warranty or liability exists beyond
any minimum requirements imposed by law, even though defect, damage, or loss may
be by negligence or other act.

Regulatory compliance

FCC compliance and advisory

Kodak EasyShare C653/C623 zoom digital camera

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.

This equipment generates, uses, and can radiate radio frequency energy and, if not
installed or used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures: 1) reorient
or relocate the receiving antenna; 2) increase the separation between the equipment
and the receiver; 3) connect the equipment to an outlet on a circuit different from that
to which the receiver is connected; 4) consult the dealer or an experienced radio/TV
technician for additional suggestions.

Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment. Where shielded

www.kodak.com/go/support

65

Appendix

interface cables have been provided with the product or specified additional
components or accessories elsewhere defined to be used with the installation of the
product, they must be used in order to ensure compliance with FCC regulation.

Australian C-Tick

N137

Canadian DOC statement

DOC Class B Compliance

This Class B digital apparatus complies with Canadian ICES-003.

Observation des normes-Classe B

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Waste Electrical and Electronic Equipment labeling

In the European Union, do not discard this product as unsorted municipal waste.
Contact your local authorities or go to www.kodak.com/go/recycle for recycling
program information.

Korean Class B ITE

VCCI Class B ITE

66 www.kodak.com/go/support

Index 1

A

A/V out, 25
AA battery, loading, 1
about picture, video, 18
about this camera, 39
accessories, 29

battery, 62
buying, 54
printer dock, 30
SD/MMC card, 3

album

set, 35

tagging pictures, 40
appendix, 56
auto, 4

enhancement, 21

flash, 11

focus framing marks, 7

delete, ii, 8
flash, flash button, i
flash/status, 11
info, ii
LCD/Info, ii
menu, ii
OK, ii
review, 17
Share, ii
shutter, i
telephoto, ii
wide angle, ii
zoom, 10

C

cable

audio/video, 25
USB, 29

camera screen

B

batteries

expected life, 61

extending life, 62

loading, 1

types, 58, 61
battery compartment, ii
battery life, 61
beach, 5
blur, 9
burst, using, 13
button

burst, 13

www.kodak.com/go/support 67

error messages, 51
camera sounds, 38
caring for your camera, 62
children, 6
Class B ITE, 66
clock, setting, 2
color mode, 35
compatibility, dock, 32
copy pictures

card to memory, 26

memory to card, 26

to computer, 28
cropping pictures, 21, 22

Index

CRV3 battery

loading, 1
customer support, 54, 55
customizing camera settings, 37

D

date setting, 2
date stamp, 38
DC-in, i
delete button, ii
deleting

during quickview, 8

from internal memory, 19

from SD/MMC card, 19

protecting pictures, videos, 20
digital zoom, using, 10
displaying slide show, 23

exposure metering, 34
external video device

viewing pictures, videos, 25

F

favorites

removing, 45
settings, 45

tagging, 44
fireworks, 5
firmware, upgrading, 62
flash

settings, 11
focus

framing marks, 7

zone, 35
format, 39

disposal, recycling, 63, 66
dock

connector, ii

printer, 30
dock compatibility, 32
doing more with your camera, 33
download pictures, 28

E

EasyShare software

installing, 28
emailing pictures, videos, 43
error messages, 51
expected battery life, 61
exposure

compensation, 14

long time, 35

framing grid, 13

G

grid, framing, 13
guidelines, battery, 62

H

help, 47

camera, 47
web links, 54

I

icon

blur, 9
icons, mode dial, 4
image storage, 36
info button, ii
information

68 www.kodak.com/go/support

Index

about pictures, videos, 18

installing

batteries, 1
SD/MMC card, 3
software, 28

internal memory

storage capacity, 59

K

Kodak EasyShare software

upgrading, 62
Kodak Perfect Touch technology, 21
Kodak web sites, 54
Korean Class B ITE, 66

L

landscape, 5
LCD, ii

reviewing pictures, 17

maintenance, camera, 62
memory

full, 36
inserting card, 3

storage capacities, 59
memory plus, 36
menu button, ii
mode dial, i, 4
modes

auto, 4

beach, 5

children, 6

fireworks, 5

landscape, 5

night portrait, 5

SCN, 4

snow, 5

text, 5

reviewing videos, 17
LCD/Info button, ii
lens

cleaning lens, 62
light

ready, 49
liveview, 37
loading

batteries, 1

SD/MMC card, 3

software, 28
long time exposure, 35

M

Macintosh computers, installing

software on, 28

N

night portrait, 5

O

OK button, ii
online prints, ordering, 32
optical zoom, 10
orientation sensor, 37

P

panoramic pictures, 15
Perfect Touch technology, 21
PictBridge enabled printer, 30
picture size, 33
pictures

checking settings, 27

www.kodak.com/go/support 69

Index

copying, 26

cropping, 21, 22

deleting, 19

emailing tagged, 43

Kodak Perfect Touch, 21

printing, 31

protecting, 20

reviewing, 17

storage capacity, 59

tagging, 40

taking, modes, 4

transfer, 28
picture-taking settings, 33
power

camera, 2
printer dock, 30
printing

regulatory information, 65

Class B ITE, 66
removing favorites, 45
repair, 54
return, 37
review button, 17
reviewing pictures

as you take them, 8

deleting, 19

LCD, 17

protecting, 20

slide show, 23
reviewing videos

deleting, 19

LCD, 17

protecting, 20

slide show, 23

from a card, 32
from computer, 31
optimizing printer, 54
order online, 32
PictBridge technology, 30
tagged pictures, 32

with EasyShare printer dock, 30
problem-solving, 47
protecting pictures, videos, 20

Q

quickview, using, 8

R

ready light, 7, 49
recycling, disposal, 63, 66
red-eye, flash, 11

running slide show, 23

S

scene modes, 5

panorama, 15
SCN, 4
SD/MMC card

inserting, 3

printing from, 32

storage capacities, 59
self-timer

with pictures, 12
service and support telephone

numbers, 55

setting

about, 39

album, 35

70 www.kodak.com/go/support

Index

camera sounds, 38
color mode, 35
date and time, 2
date stamp, 38
exposure metering, 34
flash, 11
focus zone, 35
image storage, 36
liveview, 37
long time exposure, 35
orientation sensor, 37
picture size, 33
picture taking mode, 4
return, 37
self-timer, 12
setup menu, 36
sound volume, 38

problems, 48

running, 23
snow, 5
software

installing, 28

upgrading, 62
sound volume, 38
sounds, 38
specifications, camera, 56
status

blur, 9

camera ready light, 49
storage capacity, 59
storage location

switching, 36
support, technical, 54, 55
switching storage location, 36

video date display, 38
video out, 38
video size, 36
white balance, 34

settings

picture taking, 33
setup menu, 36
setup mode, using, 37
shaking hand, 9
Share button, ii
sharing pictures, videos, 42
shutter

problems, 48

self-timer delay, 12
shutter button, i
slide show

continuous loop, 24

T

tagging

favorites, 44
for albums, 40
for email, 43

for print, 42
telephone support, 55
telephoto button, ii
television, slide show, 25
text, 5
time, setting, 2
timer, shutter delay, 12
tips

care & maintenance, 62
transferring pictures, videos, 28
trash can, deleting, 8

www.kodak.com/go/support 71

Index

tripod socket, ii
troubleshooting, 47

camera, 47
camera/computer

communications, 50
error messages, 51
ready light status, 49

turning camera on and off, 2

U

undelete, 19
undo, 19
upgrading software, firmware, 62
URLs, Kodak web sites, 54
USB cable, 29
USB, A/V out, ii

viewing picture

after taking, 8, 17
viewing picture, video information, 18
volume, 38

W

warranty, 63
WEEE, 66
white balance, 34
wide angle button, ii
Windows OS-based computers

installing software, 28
wrist strap, 1
wrist strap post, ii

Z

zoom

V

VCCI compliance, 66
video

action print, 23
checking settings, 27
copying, 26
date display, 38
deleting, 19
out, 38
protecting, 20
reviewing, 17
storage capacities, 59

viewing, 17
video size, 36
videos

emailing tagged, 43

transfer, 28

digital, 10
optical, 10

72 www.kodak.com/go/support
