Kodak EasyShare C310, EasyShare CD40 User Manual
Kodak EasyShare C310/CD40
digital camera
FPO
User’s guide
www.kodak.com
For interactive tutorials, www.kodak.com/go/howto
For help with your camera, www.kodak.com/go/c310support or
www.kodak.com/go/cd40support
Eastman Kodak Company
Rochester, New York 14650
© Eastman Kodak Company, 2005
All screen images are simulated.
Kodak, EasyShare, and Retinar are trademarks of Eastman Kodak Company.
P/N 4J3200_en
Front view
Product features
4
5
6
7
3
2
1
1 Grip 5 Mode dial/Power
8
2 Strap post 6 Flash unit
3 Self Timer/Video light 7 Viewfinder lens
4 Shutter button 8 Lens
www.kodak.com/go/support
i
Product features
Back view
3
4
5
2
6
7
1
8
9
10
11
12
13
14
15
16
1 Tripod socket 9 Camera screen
(LCD: liquid crystal display)
2 Dock connector 10 Flash/Status button
3 Share button 11 Grip
4 Controller buttons (4) 12 Slot for optional SD/MMC card
5 OK button 13 Menu button
6 Delete button 14 Review button
7 Viewfinder 15 USB (Universal Serial Bus) port
8 Ready light 16 Battery compartment
ii www.kodak.com/go/support
Table of contents 1
1 Setting up your camera .........................................................................1
Attaching the wrist strap ............................................................................... 1
Loading the batteries .................................................................................... 1
Turning on the camera .................................................................................. 2
Setting the date/time, first time ..................................................................... 2
Setting the language and date/time, other times............................................ 3
Storing pictures on an SD or MMC card ......................................................... 3
2 Taking pictures and videos ....................................................................4
Taking a picture ............................................................................................4
Using digital zoom ........................................................................................ 7
Using the flash..............................................................................................7
Reviewing pictures and videos.......................................................................8
Protecting pictures and videos from deletion................................................ 11
3 Transferring and printing pictures .......................................................13
Installing the software................................................................................. 13
Transferring pictures with the USB cable ...................................................... 14
Printing pictures.......................................................................................... 15
Dock compatibility for your camera.............................................................. 18
4 Doing more with your camera .............................................................19
Putting yourself in the picture or video......................................................... 19
Running a slide show .................................................................................. 20
Copying pictures and videos ........................................................................ 22
Choosing a flash setting .............................................................................. 23
Changing picture-taking settings ................................................................. 24
Customizing your camera ............................................................................ 27
Viewing picture/video information ............................................................... 29
Pre-tagging for album names ...................................................................... 30
Sharing your pictures................................................................................... 32
www.kodak.com/go/support iii
Table of contents
5 Troubleshooting ..................................................................................37
Camera problems........................................................................................ 37
Camera/computer communications.............................................................. 41
Camera screen messages ............................................................................42
Camera ready light status............................................................................ 45
6 Getting help ........................................................................................47
Helpful Web links........................................................................................ 47
Software help..............................................................................................47
Telephone customer support ....................................................................... 48
7 Appendix .............................................................................................50
Camera specifications ................................................................................. 50
Storage capacities ....................................................................................... 53
Power-saving features................................................................................. 54
Important safety instructions ....................................................................... 54
Battery information .....................................................................................56
Upgrading your software and firmware........................................................57
Additional care and maintenance ................................................................ 58
Warranty..................................................................................................... 58
Regulatory compliance ................................................................................ 61
iv www.kodak.com/go/support
1 Setting up your camera
Attaching the wrist strap
Loading the batteries
CRV3 lithium
(non-rechargeable)
For information on replacing batteries and extending battery life, see page 56.
www.kodak.com/go/support 1
Ni-MH
(rechargeable)
KAA2HR
2-AA
or oxy-alkaline AA
lithium, Ni-MH,
Setting up your camera
Turning on the camera
Setting the date/time, first time
At the prompt, press OK.
to change.
for previous/next field.
OK
t
o accept.
2 www.kodak.com/go/support
Setting up your camera
Setting the language and date/time, other times
Press Menu.
1
2
3
to highlight Setup Menu
then press OK.
to highlight Language
or Date/Time
If setting the date/time:
to change.
for previous/next field.
OK
to accept.
, then press OK.
Storing pictures on an SD or MMC card
Your camera has 16 MB of internal memory. You can purchase an SD or MMC card to
conveniently store more pictures and videos.
NOTE: We recommend Kodak SD and MMC cards. When using the card for the first time, format it in this
camera before taking pictures (see page 28).
SD or MMC
card (optional)
Notched corner
CAUTION:
A card can only be inserted one way; forcing it may cause
damage. Inserting or removing a card when the Ready light is
blinking may damage pictures, card, or camera.
See page 53 for storage capacities. Purchase SD or MMC cards at a dealer of Kodak
products or www.kodak.com/go/c310accessories or
www.kodak.com/go/cd40accessories
www.kodak.com/go/support
3
2 Taking pictures and videos
Taking a picture
1
Tur n o n came ra:
for general picture-taking
—
—for night scenes or low-light
conditions
2
Frame your subject in
viewfinder or LCD screen.
Taking a video
1
Tur n on came ra .
Press the Shutter button
3
to take the picture.
Ready light
When the Ready light
4
blinks green, the picture is
being saved; you can still
take pictures.
3
Press the Shutter button down
and release, or press and hold
for more than 2 seconds.
2
Frame your subject in
viewfinder or LCD
screen.
4 www.kodak.com/go/support
The camera does not record
audio.
To stop recording, press the
Shutter button again.
Taking pictures and videos
Reviewing the picture or video just taken
After you take a picture or video, the camera LCD screen displays a Quickview for
approximately 5 seconds.
While the picture or video and are displayed:
Delete
OK to play/pause a video
Tag a picture/video for email or as a
favorite, or tag a picture for print.
If you take no
action, the
picture/video is
saved.
To view pictures and videos anytime, see page 8.
Checking camera and picture status
The icons that appear on the camera LCD screen indicate the active camera and
picture settings.
If is displayed in the status
area, press to display
additional settings.
Flash/Status
button
www.kodak.com/go/support
5
Taking pictures and videos
Using the camera LCD screen as a viewfinder
IMPORTANT:
The Liveview feature significantly depletes battery power; use it sparingly.
1 Turn the Mode dial to any Still mode.
2 Press the OK button to turn on the camera screen.
3 Frame your subject in the camera screen.
4 Press the Shutter button to take the picture.
5 To turn off the LCD screen, press the OK button.
OK button
To make the LCD screen turn on whenever the camera is on, see Liveview, page 25
Picture/video capture screens
Self-timer
Date stamp
Album name
Zoom:
Telephoto
Wide
Flash
Picture quality
Pictures/video time remaining
Image storage location
Mode description
ISO speed
Low battery
Capture mode
Exposure compensation
6 www.kodak.com/go/support
Taking pictures and videos
Using digital zoom
Use digital zoom in any Still mode to get up to 5X closer to your subject.
IMPORTANT:
You may notice a decrease in printed image quality when using digital
zoom. The blue slider on the zoom indicator pauses, then turns red when
the picture quality is less than 1 MP. For an acceptable 4 x 6 in. (10 x 15 cm)
print, ensure that the slider remains blue.
1 Press the OK button to turn on the LCD screen, then
press to activate digital zoom.
The camera screen displays the zoomed image and the
zoom indicator.
2 Press to zoom in or out (T - Telephoto or
W - Wide).
Zoom indicator
3 Press the Shutter button to take the picture.
To turn off digital zoom, from the lowest setting,
press .
NOTE: You cannot use digital zoom for video recording.
Using the flash
Use the flash when you take pictures at night, indoors, or outdoors in heavy shadows.
Flash is effective between 2.6 - 7.9 ft (0.8 - 2.4 m). You can only change the flash
setting in Still modes.
Press the button repeatedly to scroll
through flash options (see Flash modes table on
page 23).
The active flash icon is displayed in the
LCD screen status area (see page 5).
To change the flash settings, see page 23.
www.kodak.com/go/support
7
Taking pictures and videos
Reviewing pictures and videos
Press the Review button to view and work with your pictures and videos.
Videos:
OK to play/pause
Rewind to beginning (during playback)
Next picture/video (during playback)
Review
1
2
(previous/next)
(Press again to exit)
To save battery power, use the optional Kodak EasyShare camera or printer dock, or
Kodak 3-volt AC adapter. (See www.kodak.com/go/c310accessories or
www.kodak.com/go/cd40accessories.)
NOTE: Pictures taken at 3.5 MP (3:2) quality setting are displayed at a 3:2 aspect ratio with a black bar at
the top of the screen.
8 www.kodak.com/go/support
What the review icons mean
Print tag/number of prints
Favorite tag
Email tag
Taking pictures and videos
Protect
Picture/video number
Image storage location
Scroll arrows
Video length
Video lengthVideo length
Scroll arrows
Review mode
Video number
Image storage
location
Press OK to
Play or Pause
Review mode
www.kodak.com/go/support
9
Taking pictures and videos
Magnifying a picture during review
OK
OK
magnify at 2X. Press again for 4X.
view other parts of the picture.
return to 1X
.
Viewing multi-up (thumbnails) during review
view multi-up thumbnails.
view previous/next row of thumbnails.
view previous/next thumbnail.
view single picture.
OK
10 www.kodak.com/go/support
Taking pictures and videos
Protecting pictures and videos from deletion
Press Review.
1
for previous/next.
,
Note: To cancel Protect,
press OK again.
2
Press Menu.
3
Press to
4
highlight Protect
then press OK.
The picture or video is protected and cannot be deleted. The Protect icon appears
with the protected picture or video.
Press the Menu button to exit.
CAUTION:
Formatting internal memory or an SD or MMC card deletes all
(including protected) pictures, videos. (Formatting internal
memory also deletes email addresses, album names, and
favorites. To restore them, see EasyShare software Help.)
www.kodak.com/go/support
11
Taking pictures and videos
Deleting pictures and videos
Press Review. (To exit, press
1
Review again.)
2
Press Delete.
3
Follow the screen prompts.
4
for previous/next.
PICTURE or VIDEO—deletes the displayed picture or video.
EXIT—exits the Delete screen.
ALL—deletes all pictures and videos from your current storage location.
NOTE: To delete protected pictures and videos, remove protection before deleting.
12 www.kodak.com/go/support
3 Transferring and printing
pictures
Installing the software
CAUTION:
Install Kodak EasyShare software
optional dock to the computer. Failure to do so may cause the
software to load incorrectly.
1 Close all software applications that are open on your computer (including
anti-virus software).
2 Place the Kodak EasyShare software CD into the CD-ROM drive.
3 Load the software:
Windows OS—if the install window does not appear, choose Run from the Start
menu and type d:\setup.exe where d is the drive letter that contains the CD.
Mac OS X—double-click the CD icon on the desktop, then click the Install icon.
4 Follow the on-screen instructions to install the software.
Windows OS—select Complete to automatically install the most commonly used
applications. Select Custom to choose the applications you wish to install.
Mac OS X—follow the on-screen instructions.
before
connecting the camera or
NOTE: When prompted, register your camera and software. Registering lets you sign up for information
that keeps your system up-to-date. To register later, visit
5 If prompted, restart the computer. If you turned off anti-virus software, turn it back
on. See the anti-virus software manual for details.
For information on the software applications included on the Kodak EasyShare
software CD, click the Help button in the Kodak EasyShare software.
www.kodak.com/go/support 13
www.kodak.com/go/register.
Transferring and printing pictures
Transferring pictures with the USB cable
1 Turn off the camera.
2 Plug the labeled end of the USB cable
(model U-8) into the labeled USB port on your
computer. See your computer user’s guide for
details.
3 Plug the other end of the USB cable into the labeled
USB port on the camera.
4 Turn on the camera.
Kodak EasyShare software opens on your computer.
The software prompts you through the transfer
process.
NOTE: Visit
www.kodak.com/go/howto
for an online tutorial on connecting.
Also available for transferring
You can also use these Kodak products to transfer your pictures and videos.
■ Kodak EasyShare camera dock, Kodak EasyShare printer dock (see page 18)
■ Kodak multi-card reader, Kodak SD multimedia card reader-writer
Purchase these and other accessories at a dealer of Kodak products or
www.kodak.com/go/c310accessories or www.kodak.com/go/cd40accessories
14 www.kodak.com/go/support
Transferring and printing pictures
Printing pictures
Printing with a Kodak EasyShare printer dock
Dock your camera to the Kodak EasyShare printer dock and print directly—with or
without a computer. Purchase this and other accessories at a dealer of Kodak
products or www.kodak.com/go/c310accessories or
www.kodak.com/go/cd40accessories
Direct printing with a PictBridge enabled printer
Your camera is compatible with PictBridge technology, so you can print directly to
PictBridge enabled printers. You need:
■ Camera with fully charged batteries, or
with optional Kodak 3-volt AC adapter
■ PictBridge enabled printer
■ USB cable (may be sold separately)
Connecting the camera to a PictBridge enabled printer
1 Turn off the camera and printer.
2 Optional: If you have a Kodak 3-volt AC adapter (optional accessory), plug it into
the camera and into an electrical outlet.
IMPORTANT:
Do not use the AC adapter included with the EasyShare camera dock or
printer dock to power your camera.
3 Connect the appropriate USB cable from the camera to the printer. (See your
printer user guide or www.kodak.com/go/c310accessories or
www.kodak.com/go/cd40accessories for details.)
www.kodak.com/go/support
15
Transferring and printing pictures
Printing from a PictBridge enabled printer
1 Turn on the printer. Turn on the camera.
The PictBridge logo is displayed, followed by the current picture and menu. (If no
pictures are found, a message is displayed.) If the menu interface turns off, press any
button to redisplay it.
2 Press to choose a printing option, then press the OK button.
Current Picture Press to choose a picture. Choose the number of copies.
Tagged Pictures If your printer is capable, print pictures that you tagged for
printing and choose a print size.
Index Print Print thumbnails of all pictures. This option requires one or more
sheets of paper. If the printer is capable, choose a print size.
All Pictures Print all pictures in internal memory, on a card, or in Favorites.
Choose the number of copies.
Image Storage Access internal memory, a card, or Favorites.
NOTE: During direct printing, pictures are not permanently transferred or saved to the computer or printer.
To transfer pictures to your computer, see page 13. In Favorites mode, the current favorite picture
is displayed.
16 www.kodak.com/go/support
Transferring and printing pictures
Disconnecting the camera from a PictBridge enabled printer
1 Turn off the camera and printer.
2 Disconnect the USB cable from the camera and the printer.
Using a printer that is not PictBridge enabled
For details on printing pictures from your computer, click the Help button in the Kodak
EasyShare software.
Ordering prints online
Kodak EasyShare gallery ( www.kodakgallery.com) is one of the many online print
services offered in the Kodak EasyShare software. You can easily:
■ Upload your pictures.
■ Edit, enhance, and add borders to your pictures.
■ Store pictures, and share them with family and friends.
■ Order high-quality prints, photo greeting cards, frames, and albums—and have
them delivered to your door.
Printing from an optional SD or MMC card
■ Automatically print tagged pictures when you insert your card into a printer with
an SD/MMC card slot. See your printer user’s guide for details.
■ Make prints at an SD/MMC card-capable Kodak picture maker. (Contact a location
prior to visiting. See www.kodak.com/go/picturemaker.)
■ Take the card to your local photo retailer for professional printing.
www.kodak.com/go/support
17
Loading...
