VIDEOMATE 2030/2030P

Video Slide Projector
Instruction Manual

The World Leader in Image Quality

Table of Contents

3 Product Overview
4 Safety Precautions
5 Voltage Selection
7 Installation
9 Slide Tray Installation
11 Lamp/Fuse Replacement
13 Troubleshooting
15 Specifications
16 Appendix
17 Warranty

2

Product Overview

Universities, boardrooms, and conventions have the
common goal of effective information communication.
Today’s individual is continually being bombarded by
sophisticated media presentation. To compete effectively
for his attention (and retention) one must utilize similar
techniques. The basis for most current efforts is elec­tronic data manipulation.

A picture is still “worth a thousand words”, therefore, in
may presentations there is a need to insert pictures
electronically for display, image enhancement, publishing,
etc. Some of the “best” pictures around are stored on the
millions of existing 35mm slides.

The sole function of the VideoMate 2030 (NTSC) & 2030
(PAL) is to provide an electronic representation of the
contents of a normal 35mm slide. The output signals
available are Composite Video and S-Video.

Product Description

Product Overview

The VideoMate 2030 utilizes a standard Kodak slide
transport mechanism to present the 35mm slide image to
a “state-of-the-art” color CCD array. Included in the
package is a color balanced illumination system and high
resolution Navitar zoom imaging lens. The zoom lens
permits both the viewing of “vertical” slides and some
“blowing up” of the center portion of the image.

Output is standard Composite Video through the BNC
connector and S-Video output is available through a 4-pin
MiniDin plug.

3

Safety Precautions

Safety Precautions

For safety, before connecting the projector to the main,
ensure that the voltage selector is set to your main
voltage and the required fuse is fitted. An incorrectly
adjusted main voltage can damage the projector.

To prevent damage to equipment and operating personnel,
please observe the following precautions:

Insure that the voltage source contains a satisfactory path
to ground.

Do not operate where fluids could come into contact with
electrical components.

Maintain a six inch (15cm) air space around all sides of
equipment to allow proper ventilation.

Do not operate projector with a damaged cord or if the
projector has been dropped or damaged until it has been
examined by a qualified service technician.

Other than lamp changing, there are no user serviceable
components. Opening of the unit will expose dangerous
voltage levels and damage sensitive electronic
components.

All repairs should be performed by a qualified service
technician.

To protect unit from damaging condensation and thermal
shocks, these procedures should be followed:

1. In cold weather, always put the unit in moisture proof
container or enclosure before transporting.

2. Keep the unit warm while transporting or allow the
unit’s chassis to return to room temperature before
being turned on.

The goal is to prevent warm moist air from striking cold
electric and optical components and causing damaging
condensation.

Warning! Never operate a cold projector.

4

7

Voltage Selection

Voltage Selection

Check voltage setting.

The Navitar VideoMate will be exported throughout the
world to countries with differing mains voltages. The
projectors are already set during manufacture to a fixed
main voltage.

100-200V mains:

Shipments to countries with 100 or 200V mains will be
equipped with a 5A fuse. A spare fuse for replacement is
also supplied.

220, 230, or 240V mains:

Shipments to countries with 220, 230 or 240V mains will
be equipped with 2.5A fuse. A spare fuse for replacement
is also supplied.

Before you switch on your projector ensure that voltage is
correctly adjusted! An incorrectly adjusted mains voltage
can damage the projector. The voltage selector must
show your country’s actual mains voltage. To set the
voltage selector simply turn the selector until the arrow of
your main voltage lines up with the arrow on the projector
housing. To fit or check the fuse, pull out the fuse holder
located beneath the main socket.

5

Voltage Selection

Voltage Selector

Lock Ring

Fuse Holder

6

Alignment
Mark

Tray Positioning
Index Mark

Installation

Installation

Before installing please review precautions.

For those users familiar with both the operation of 35mm
slide projector and their own video displays, the following
is an abbreviated start-up procedure.

1. Check the voltage setting before powering on. Make
sure that the setting is correct. In addition, the fuse
needs to be checked.

2. Plug in power cable.

3. Connect peripheral equipment to the BNC and/or S­Video Connector located under the lamp module.

4. Make sure there is no slide left in the slide gate.
Place slide tray on the projector with the “0” slide slot
at the gate index.

5. Turn on peripherals and set the VideoMate power
switch to high. If white light from the projector spills
onto the monitor screen when the projector is first
turned on, the automatic dark-screen shutter built into
the projector is not engaged. To engage the shutter,
simply press the select bar. The shutter will engage
and the projector light will be blocked.

6. Select a relatively “white” slide to represent the highest
signal level the electronic must accommodate. Adjust
the Iris Control “I” and the peripheral controls to
produce a suitable image. The Focus control “F”
should also be adjusted at this time. Turn Zoom wheel
to achieve desired magnification.

NOTE: A very dark slide may require readjustment of
the Iris Control, but normally, a setting can be reached
that produces an acceptable display throughout the
range of slides.

The more the iris is open, the less the depth of field.
What this means is that with the darker slides, you will
open the iris more and will be able to judge focus more
critically; but also means that any deformities in the slide
will cause a visible “out-of-focus” condition.

7

Select Bar

Installation

9. To shut down the system, hold down the select bar
and rotate the slide tray to the “0” index position. Set
the power switch to “off”.

10. For instructions regarding setting up slide tray
changing lamps, etc., refer to the appropriate section
of the manual.

IRIS Knob

FOCUS Knob

ZOOM Knob

Lamp module

4-Pin Mini Din (V/C) S-Video

BNC (Composite Video)

8

Slide Tray Set-Up

Slide Tray Installation

This system was designed to permit usage of prepared
presentations without reorientation of the slides in the
tray.

Your new Navitar VideoMate will accept Kodak Ektapro
80, Kodak Ektagraphic 80 for holding 80 slides with a
maximum slide mount thickness of 3.2mm and Kodak
Carousel Transvue 140 Slide Tray for holding 140 slides
with a maximum mount thickness of 1.6mm. We recom­mend the 80 slide tray more maximum reliability.

For those setting up a new tray and/or presentation:

1. Arrange your slides in the order you wish them to
appear in the presentation. Orient them such that they
are upright and reading correctly from left to right.

2. Rotate each slide to turn the image upside down (do
not turn the slide over). Mark a sequential number in
the upper right corner of each slide (this will be ex­tremely useful should the slides become mixed). Use
a felt tipped market rather than a label that will be
loosened by the heat.

3. Make sure the bottom metal plate on the slide tray is
indexed into the “0” position (the plate will not rotate
with respect to the top tray). Remove the top lock ring
by rotating it counterclockwise.

4. Insert slide number 1 into slot “1”. The number written
on the upper right corner of each slide should be at the
top and facing the next higher numbered slot. Load all
slides and replace and lock the top lock ring.

Slide Tray Installation

1. Center the tray over the post of the projector.

2. Gently rotate the tray until the “0” slide slot is at the
index mark and the tray will drop into position. If the
tray doesn’t drop into position, check if the lower metal
plate is located in the zero position (rotate until it
locks).

9

Slide Tray Removal

To remove the tray from the projector without losing slides:

1. Hold the selector bar down and rotate the tray back to

2. Lift the tray at a point opposite the index mark.

Slide Tray Jam

The tray may jam if a damaged slide is caught in the gate.
To release the tray:

1. Move the power switch to “off”.

2. Push the select bar down and the slide should come

If the tray is still jammed:

1. Hold the release tab on the projector post out while

Slide Tray Installation

the zero index position.

up.

lifting the tray on the side opposite the index mark.
When the tray is removed, the select bar will release
the slide.

10

2. Invert the slide and rotate the bottom metal plate until
it locks into the zero position.

3. Turn the tray back upright and remove the lock ring. If
the slide in undamaged, return it to its proper slot.
Replace the lock ring and continue.

Lamps

Lamps/Fuse Replacement

The VideoMate will function with either of the following 82
volt or 85 watt lamps. One provides a higher color
temperature, with the other exhibits a much longer life.

Do not use 82 volt, 25-300 watt slide projection lamps or
your equipment will suffer severe damage.

pmaLtloVttaW

HSE2858052K0592

*JSE285804K0533

Replacement of the Lamp

The entire illumination system is contained in a unit called
a lamp module. This module is a drawer type configura­tion which may be removed from the projector for lamp
changing. If anticipated usage of the VideoMate is such
that the downtime associated with changing a lamp would
be detrimental to the goal, a second (spare) VideoMate
lamp may be purchased which will reduce the lapse to a
fraction of a minute. It will also eliminate the accumula­tion of partially burned lamps with unknown remaining life.
Please call for price and availability.

To replace the lamp:

1. Turn power off and allow the unit to cool down before
handling.

efiL

)sruoH(

.deilppuspmaldradnatS*

roloC

.pmeT

2. Press down on the door latch of the lamp module and
pull slowly outward until the module clears the projec­tor.

3. Unclasp the wire bail which holds the lamp in place
and push from underneath the lamp to slide the lamp
out of the receptacle.

11

Fuses

Lamps/Fuse Replacement

4. Reverse the procedure to insert a new lamp (make
sure the new lamp is properly seated).

5. Lock the new lamp in place with wire bail.

Always switch off the projector and unplug the main lead
before replacing a fuse. Avoid the risk of fire, replace only
with a fuse of same type and rating.

Simply pull out the fuse holder, remove the blown fuse and
fit the required replacement.

1. 1 x T2.5 A H/250 V for 220, 230 and 240V

2. 1 x 5A Slownblow/250 V for 100, 115 and 130V

12

Troubleshooting

Symptom #1:
After switching on, projector is not operable.

Possible Cause:

1. All equipment not “powered up”. Check outlets and
individual unit (monitor, video projector, etc.).

2. Check input voltage selector.

3. Lamp blown. Look in film gate for “light on condition”.
Also depress select bar to check for stuck gate
shutter.

4. Fuse is blown. Check fuse and replace if necessary.

5. Wait 1 minute with the power switch off and try to
restart.

6. Bad cables.

Troubleshooting

Symptom #2
Unable to recover picture after brief interruption of power.

Possible Cause:

1. The lamp has blown with the thermal shock of turning
on.

2. The gate shutter is stuck in the closed position. Push
down on the select bar.

Symptom #3
The tray can not be moved.

Possible cause:

Tray has not been placed correctly on the transport ring.
Lift off the tray, switch projector on and then off again and
then replace tray.

13

Symptom #4
Image too dark or too light.

Possible cause:

1. Illumination level inadequate. Set knob “I” as required.

2. Monitor not adjusted properly.

Symptom #5
Image not sharp.

Possible cause:

1. Adjust focus knob.

2. Illumination level is too high or too low. Adjust

3. Monitor not adjusted.

4. Substandard cabling. Make sure cables are “ground

Troubleshooting

illumination knob.

shield video” grade.

Symptom #6
Image does not stabilize.

14

Possible cause:

Improper “sync” signal. Check peripheral equipment
requirements.

snoitacificepSaremaC

eciveDpu-kciPDCCrefsnarTenilretnI"2/1

tnuoClexiP)V(285x)H(257

retliFroloCciasoMroloCyratnemilpmoC

metsySlangiS)elbaliavACSTN(dradnatSLAP

noituloseRlatnoziroHsenilVT054

ytivitisneSerutarepmetroloc°K0023,)xuL5(4.1F

kcolneGkcolnegoN

oitaRN/SdradnatsBd05

snoitacificepSrotcejorP

rebmuNledoM58321-1

noitpmusmoCrewoPspma7.1,sttaw191

rewoPzH05,tlov042-001

pmaLnoitcejorPJSEEGttaw58,ltov28

Specifications

rotcejorPedilS0001etilatkEkadoKdeifidoM

sneL8.2/f,moozmm53-71

lortnoCsucoF/sirIlaunaM

yticapaCyarTedilSyartedils041/08kadoK

launaM/slortnoC siri&sucof,tuo/nimooz,esrever/drawrof,ffo/nO

noitarepOetomeR

srotcennoCaremaCoediVetisopmoC-CNB

snoisnemiD

)lanoitpo(selbaCoediV

VASgnisuerusolctcatnocybelballortnocetomeR

lortnocotrotcennocetomerniDnip-6epyt

esrever/drawrof

mm911/ni96.4thgieHmm282/.ni11.11htgneL

.gk28.6/.sbl51thgieWmm823/.ni39.21htdiW

.elbacoediV-Stoof21,31111-8ledoM

.elbacoedivtoof21,78711-8ledoM

15

Appendix

Appendix

Due to transportation, the image position might shift from
the factory setting. To correct this shift:

1. Remove the two plugs as shown in the figure below:

2. Using the Phillips screw driver, rotate screw #1 to
adjust the vertical position and screw #2 to adjust the
horizontal position.

3. Replace the hole plugs.

Adjustment for
Vertical Movement
Screw #1

Adjustment for





















Horizontal Movement
Screw #2



Do Not Remove Lower Plug

Ektalite and Kodak are both trademarks of the Eastman Kodak Company.
VideoMate and Navitar are both trademarks of Navitar, Inc.

16

1 Year Parts /1 Year Labor

This product is warranted to be free from defects in
material and workmanship for a period of five years from
the date of invoice to the original purchaser.

If during the warranty period the product is found to be
defective, it will be repaired or replaced at the facilities
of Navitar. However, Navitar reserves the right to refund
the purchase price if the replacement or repair is not
commercially practical or timely. Parts not manufactured
by Navitar carry only the warranty of their manufacturer.
Lamps and fuses carry no warranty.

This warranty does not cover damage caused in transit;
damage caused by misuse, neglect or carelessness;
or damage resulting from either improper servicing or
modification by someone other than Navitar. Further, this
warranty does not cover any routine maintenance work
that is reasonably expected to be performed by the
purchaser.

No responsibility is assumed for unsatisfactory operating
performance due to environmental conditions such as
humidity, dust, corrosive chemicals, deposition of oil or
other foreign matter, spillage or other conditions beyond
the control of Navitar.

Warranty

For service, repair or return procedures under this
warranty, contact your distributor, your local Navitar
field officer or Navitar direct at [phone] or
[phone] in the United States.

Except as stated herein, Navitar makes no other
warranties, expressed or implied by law, whether of
merchantability, fitness for a particular purpose or
otherwise. Further, Navitar shall not, under any
circumstances, be liable for incidental, consequential
or other damages.

17

Navitar, Inc.
200 Commerce Drive
Rochester, NY 14623
[phone] phone
[phone] fax
Internet http://navitar.com/
e-mail [e-mail]

18
