Knog STRONGMAN User Manual

100% HARD

LOCKS BY KNOG

www.knog.com.au

STRONGMAN

High Security U-Lock

ENGLISH 2-x
DEUTSCH x-x
ESPANOL x-x
ITALIANO x-x
JAPANESE x-x
FRENCH x-x

ENGLISH

CONTENTS

Strongman components 4
How to lock your Strongman 5
Mount Bracket 10
Key Replacements 13
Limited Warranty 15
Taking care of your Strongman 17

STRONGMAN COMPONENTS 4

Your strongman should come with:

1 x Unique key
code card

1 x Strongman

3 x High Security keys

1 x Mount Bracket

6HOW TO LOCK YOUR STRONGMAN 5

1. To unlock the Strongman insert key and
rotate 180 degrees clockwise. Be sure to hold
the bottom half of the lock body as it will
become free from the shackle.

2. To lock the Strongman you must reattach the
bottom half of the lock body, insert the key and
rotate 180 degress counter-clockwise. Remove
the key and CHECK THE LOCK before leaving
your bike to make sure it’s properly secured.

Position your bike against a solid, well­anchored object (like a bike rail or tall sign
post) with the chainring facing outwards

Follow one of the lock-up procedures
displayed for where to best place your
Strongman. (Images displayed on the
following page).

(A) Place KNOG Strongman shackle around
the rail/post and a closed-loop section of
your bike frame. This is the quickest way to
lock up your bike but has the lowest security.

(B) Place KNOG Strongman shackle around
the rail/post, through a closed-loop section of
your bike frame and through a wheel (front or
rear). This is a quick way to lock up your bike
with medium security.

(C) Remove your front wheel and place it by
your rear wheel. Place KNOG Strongman shackle
around the pole and through both seat stays
or seat tube (if frame size will allow) and the
two wheels. This method takes a little bit more
time to lock up your bike but has high levels
of security.

(D) A quicker alternative is to place the KNOG
Strongman shackle around the rail/pole, through
a closed-loop section of your bike frame and
rear wheel. Then loop a KNOG Ringmaster
cable, around your front wheel, bike frame, and
onto your Strongman shackle. This method has
high levels of security.
