Klein Tools Klein Tools MM600 Manual

ENGLISH
Auto-Ranging
Digital Multimeter
10A
40M
INSTRUCTION MANUAL
• DATA & RANGE HOLD
• AUDIBLE CONTINUITY
• MIN / MAX / RELATIVE
• TEMPERATURE
• DIODE TEST
• CAPACITANCE & FREQUENCY
MM600
Ω
ENGLISH
GENERAL SPECIFICATIONS
Klein Tools MM600 is an automatically ranging digital multimeter that measures AC/DC voltage, AC/DC current, and resistance. It can also measure temperature, capacitance, frequency, duty-cycle, test diodes and continuity.
• Operating Altitude: 6562 ft. (2000m)
• Relative Humidity: <90% non-condensing
• Operating Temp: 14°F to 122°F (-10°C to 50°C)
• Storage Temp: -4°F to 140°F (-30°C to 60°C)
• Accuracy: Values stated at 65°F to 83°F (18°C to 28°C)
• Temp Coef cient: 0.1 x (Quoted Accuracy) per °C above
28°C or below 18°C, corrections are required when ambient working temp is outside of Accuracy Temp range
• Dimensions: 7.02" x 3.54" x 2.10" (178.3 x 89.9 x 53.3 mm)
• Weight: 14.6 oz. (414 g)
• Calibration: Accurate for one year
• Standards: Conforms to: UL STD 61010-1, 61010-2-030,
61010-2-033.
Certified to: CSA STD C22 2 # 61010-1,
61010-2-030, 61010-2-033. IEC EN 61010-1, 61010-2-030,
61010-2-033, 61326-1.
• Pollution degree: 2
• Accuracy: ± (% of reading + # of least significant digits)
• Drop Protection: 6.6 ft. (2m)
• Ingress Protection: IP42 (except test lead jacks, see WARNINGS)
• Safety Rating:
CAT IV 600V, CAT III 1000V, Class 2,
Double insulation
CAT III: Measurement category III is applicable to test and measuring circuits connected to the distribution part of the building’s low-voltage MAINS installation.
CAT IV: Measurement category IV is applicable to test and measuring circuits connected at the source of the building’s low-voltage MAINS installation.
• Electromagnetic Environment: IEC EN 61326-1. This
equipment meets requirements for use in basic and controlled electromagnetic environments like residential properties, business premises, and light-industrial locations.
Specifications subject to change.
99 Washington Street Melrose, MA 02176
Phone 781-665-1400 Toll Free 1-800-517-8431
2
Visit us at www.TestEquipmentDepot.com
ELECTRICAL SPECIFICATIONS
VOLTAGE (AUTO-RANGING)
Function Range Resolution Accuracy (
4.000V 1mV ±(1.0% + 5 digits)
AC Voltage
(V AC)
DC Voltage
(V DC)
Input Impedance: 10MΩ Frequency Range: 50 to 400Hz Maximum Input: 1000V AC RMS or 1000V DC
40.00V 10mV ±(1.2% + 5 digits)
400.0V 100mV 1000V 1V
400.0mV 0.1mV ±(1.0% + 8 digits)
4.000V 1mV
400.0V 100mV 1000V 1V ±(1.2% + 3 digits)
±(1.5% + 5 digits)
±(1.0% + 3 digits)40.00V 10mV
50–60 Hz
CURRENT (AUTO-RANGING)
400.0μA 0.1μA
AC Current
(μA and mA)
DC Current
(μA and mA)
Overload Protection: 500mA / 1000V and 10A / 1000V Fuses Frequency Range: 50 to 400Hz Maximum Input: µA/mA setting: 400mA AC RMS / DC
4000μA 1μA
40.00mA 10μA
400.0mA 100μA
10.00A 0.01A ±(2.0% + 5 digits)
400.0μA 0.1μA 4000μA 1μA
40.00mA 10μA
400.0mA 100μA
10.00A 0.01A ±(1.5% + 3 digits)
10A setting: 10A AC RMS / DC
±(1.5% + 3 digits)
±(1.0% + 3 digits)
RESISTANCE (AUTO-RANGING)
Function Resolution Accuracy
400.0Ω 0.1Ω
4.000kΩ
40.00kΩ 10Ω
400.0kΩ 100Ω
4.000MΩ 1kΩ
40.00MΩ 10kΩ
Maximum Input: 600V DC or 600V AC RMS
±(1.5% + 5 digits)
±(2.0% + 10 digits)
)
3
ENGLISH
ELECTRICAL SPECIFICATIONS
CAPACITANCE (AUTO-RANGING)
Range Resolution Accuracy
40.00nF 10pF ±(5.0% + 35 digits)
400.0nF 0.1nF
4.000μF 1nF
40.00μF 10nF
400.0μF 100nF 1000μF 1μF ±(5.0% + 5 digits)
Maximum Input: 600V DC or 600V AC RMS
±(3.0% + 5 digits)
FREQUENCY (AUTO-RANGING)
9.999Hz 0.001Hz
99.99Hz 0.01Hz
999.9Hz 0.1Hz
9.999kHz 1Hz
99.99kHz 10Hz
500.0kHz 100Hz
Sensitivity: >8V RMS Maximum Input: 600V DC or 600V AC RMS
±(1.0% + 5 digits)
DUTY CYCLE
1% to 99.9%
Pulse width: 0.1 – 100ms Frequency width: 5Hz to 10kHz Sensitivity: >8V RMS Maximum Input: 600V DC or 600V AC RMS
0.1% ±(1.2% + 2 digits)
TEMPERATURE
0° to 1000°F 0.1°F / 1°F ±(2.0% + 9°F)
-18° to 538°C 0.1°C / 1°C ±(2.0% + 5°C)
99 Washington Street Melrose, MA 02176
Phone 781-665-1400 Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
4
ELECTRICAL SPECIFICATIONS
OTHER MEASUREMENT APPLICATIONS
Maximum Input: 600V DC or 600V AC RMS
Diode Test: 1.5 mA max, open circuit voltage 3.0V DC
Continuity Check: Audible signal when resistance <50Ω,
max test current 0.35mA
Auto Power off: After ~30 minutes of inactivity
Sampling Frequency: 3 samples per second
Overload: "OL" indicated on display, 1000V RMS in voltage
settings, 600V RMS in all other settings
Polarity: "-" on display indicates negative polarity
Display: 3 ¾ digit, 4000 Count LCD
WARNINGS
To ensure safe operation and service of the meter, follow these instructions. Failure to observe these warnings can result in severe injury or death.
• Before each use verify meter operation by measuring a known voltage or current.
• Never use the meter on a circuit with voltages that exceed the category based rating of this meter.
• Do not use the meter during electrical storms or in wet weather.
• Do not use the meter or test leads if they appear to be damaged.
• Use only with CAT IV rated test leads.
• Ensure meter leads are fully seated, and keep fingers away from the metal probe contacts when making measurements.
• Do not open the meter to replace batteries while the probes are connected.
• Use caution when working with voltages above 25V AC RMS or 60V DC. Such voltages pose a shock hazard.
• To avoid false readings that can lead to electrical shock, replace batteries when a low battery indicator appears.
• Do not attempt to measure resistance or continuity on a live circuit.
• Always adhere to local and national safety codes. Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed.
• Meter is IP42 dust & water resistant. Following any contact with water, thoroughly dry meter and test lead jacks prior to subsequent use.
5
ENGLISH
SYMBOLS ON METER
AC/DC Voltage or Current Resistance (in Ohms) Audible Continuity Diode Capacitance Duty-cycle Double Insulated Class II
%
Warning or Caution Fuse (with rating below symbol) Warning or Caution
To ensure safe operation and service of this meter, follow all warnings and instructions detailed in this manual.
Risk of Electrical Shock
Improper use of this meter can lead to risk of electrical shock. Follow all warnings and instructions detailed in this manual.
Frequency
Hz
Risk of Electrical Shock
SYMBOLS ON LCD
Data Hold Audible Continuity
H
Diode Auto Ranging AC (Alternating Current) DC (Direct Current) Low Battery Auto Power Off
MAX
Maximum Value
°F
Degrees Fahrenheit
M
Mega (value x 106)
m
mili (value x 10-3)
n
nano (value x 10-9)
A
Amps Ohms
%
Duty-Cycle
MIN
Minimum Value
°C
Degrees Celsius
k
kilo (value x 103)
μ
micro (value x 10-6)
V
Volts
F
Farads
Hz
Hertz (Frequency)
REL
Relative Mode
99 Washington Street Melrose, MA 02176
Phone 781-665-1400 Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
6
