KitchenAid KFP1444ACA, KFP1444AFP User Manual
Food Processor
5KFP1333, 5KFP1444
INSTRUCTIONS
Processador de alimentos
KJA13
INSTRUÇÕES
食品加工机
5KFP1333, 5KFP1444
指南
Table of Contents
FOOD PROCESSOR SAFETY
Important Safeguards.................................................................................................3
Electrical Requirements-Plastic Models .....................................................................5
Electrical Requirements-Metal Models ......................................................................5
Electrical Requirements for Brazil Only ....................................................................6
PARTS AND FEATURES ................................................................................................ 7
ACCESSORIES
Included Accessories .................................................................................................8
Disc Assembly Overview...........................................................................................9
Accessories Selection Guide .................................................................................... 10
PREPARING THE FOOD PROCESSOR FOR FIRST USE
Before First Use ......................................................................................................11
Removing the Work Bowl Cover from the Work Bowl ..........................................11
Storing Parts ............................................................................................................11
SETTING UP YOUR FOOD PROCESSOR
Attaching the Work Bowl ........................................................................................12
Attaching the Work Bowl Cover .............................................................................12
Installing the Adjustable Slicing Disc ........................................................................ 13
Adjusting the Slicing Thickness ................................................................................ 13
Installing Other Slicing or Shredding Discs .............................................................. 14
Installing the Multipurpose Blade or Dough Blade ..................................................15
Installing the Mini-Bowl and Mini-Blade ..................................................................15
Using the 3-in-1 Feed Tube .....................................................................................16
USING YOUR FOOD PROCESSOR
Before Use ..............................................................................................................17
Maximum Liquid Level ............................................................................................17
Using the Speed 1/Speed 2 Control ........................................................................ 17
Using the Pulse Control ..........................................................................................17
Removing Processed Foods .....................................................................................18
CARE AND CLEANING ............................................................................................... 19
TIPS FOR GREAT RESULTS
Using the Multipurpose Blade .................................................................................19
Using a Slicing or Shredding Disc.............................................................................20
Using the Dough Blade ............................................................................................ 21
Helpful Hints............................................................................................................21
TROUBLESHOOTING ................................................................................................. 23
For more information, visit our website at: KitchenAid.com.au
2
FOOD PROCESSOR SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including
the following:
1. Read all instructions. Misuse of appliance may result
in personal injury.
2. To protect against risk of electrical shock, do not put
Food Processor in water or other liquid.
3. This appliance is not intended for use by persons with
reduced physical sensory or mental capabilities, or
lack of experience and knowledge, unless they have
been given supervision or instructions concerning use
of the appliance in a safe way and understand the
hazards involved.
4. Children should be supervised to insure they do not
play with the appliance. The appliance is not to be
used by children. The appliance and cord should be
out of reach of children. Children shall not clean or
perform user maintenance on the appliance without
supervision.
5. Unplug from the outlet when not in use, before putting
on or taking off parts, and before cleaning.
ENGLISH
3
FOOD PROCESSOR SAFETY
6. Avoid contacting moving parts.
7. Do not operate any appliance with a damaged cord or
plug, or after the appliance malfunctions, or is dropped
or damaged in any manner. Return appliance to the
nearest Authorized Service Facility for examination,
repair, or electrical or mechanical adjustment.
8. The use of attachments not recommended or sold by
KitchenAid may cause re, electric shock, or injury.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter.
11. Keep hands and utensils away from moving blades
or discs while processing food to reduce the risk of
severe injury to persons or damage to the Food
Processor. A scraper may be used but must be
used only when the Food Processor is not running.
12. Blades are sharp. Care should be taken when handling
the sharp cutting blades, emptying the bowl and
during cleaning.
13. To reduce the risk of injury, never place cutting blade
or discs on base without rst putting bowl properly
in place.
14. Be certain cover is securely locked in place before
operating appliance.
15. Never feed food by hand. Always use the food pusher.
16. Do not attempt to defeat the cover interlock mechanism.
17. To disconnect, turn any control to “OFF,” then remove
plug from wall outlet.
18. This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, ofces, and other
working environments
-farm houses
-by clients in hotels, motels, and other residential
type environments
-bed and breakfast type environments.
19. Be careful if hot liquid is poured into the Food
Processor as it can be ejected out of the appliance
due to a sudden steaming.
SAVE THESE INSTRUCTIONS
4
FOOD PROCESSOR SAFETY
Electrical Requirements- Plastic Models
Volts: 220-240 Volts VAC
Hertz: 50/60 Hz
NOTE: This Food Processor is equipped
with a polarized plug (one blade is wider
than the other). To reduce the risk of
electrical shock, this plug will t in a
polarized outlet only one way. If the plug
does not t fully in the outlet, reverse
Fire Hazard
Do not use an extension cord.
Doing so can result in death
or fire.
the plug. If it still does not t, contact a
qualied electrician. Do not modify the
plug in any way.
Do not use an extension cord. If the power
supply cord is too short, have a qualied
electrician or serviceman install an outlet
near the appliance.
Electrical Requirements- Metal Models
Do not use an extension cord. If the power
supply cord is too short, have a qualied
electrician or serviceman install an outlet
near the appliance.
A short power supply cord (or detachable
power supply cord) should be used to
reduce the risk resulting from becoming
entangled in or tripping over a longer cord.
Longer detachable power supply cords
or extension cords are available and may
be used.
If a longer detachable power supply cord or
extension cord is used:
• The marked electrical rating of the cord
set or extension cord should be at least
as great as the electrical rating of the
appliance.
• The cord should be arranged so that it will
not drape over the countertop or tabletop
where it can be pulled on by children or
Volts: 220-240 Volts VAC
Hertz: 50/60 Hz
NOTE: This Food Processor has a
grounded plug. To reduce the risk of
electrical shock, this plug will t in an outlet
only one way. If the plug does not t in the
outlet, contact a qualied electrician. Do not
modify the plug in any way.
tripped over unintentionally.
If the appliance is of the grounded type, the
extension cord should be a grounding-type
3-wire cord.
ENGLISH
5
FOOD PROCESSOR SAFETY
Electrical Requirements for Brazil Only
Use appropriate outlet type for your
appliance plug, as shown below:
Before operating
this appliance,
make sure the
main voltage at the
installation site is
the same as indicated
on product technical
data label.
This information is also included on the
label attached to your appliance’s cord
near the plug.
IMPORTANT:
Residence mains:
The mains wires must be of copper
with a minimum cross-section per ABNT
(NBR-5410.)
To protect this appliance and the mains
against over loading, this appliance
must be connected to a circuit that
is protected with a thermo-magnetic
circuit breaker.
If the household circuit does not include
a circuit breaker, contact an electrician
to have one installed.
Electric outlet:
For your safety and to avoid damage to
your product, it is very important that
your product is earthed correctly.
Your appliance power cord features a
hexagon-shaped plug, 10A, per ABNT
(NBR 14136).
Your residence electrical installation
must have a suitable electric outlet for
this type of plug. If not, it is your
responsibility to have one installed
by a qualified electrician.
• If it is necessary to convert your
• Never plug your
• In case of oscillation in mains voltage,
• If the cord of this appliance is
127V appliance to 220V, use a
1.0 KVA stabiliser.
appliance into
multi-plug
adapters with
another
appliance in the
same socket. Do
not use an extension cord. This type
of connection may cause electrical
overload in the mains, and can
damage the appliance and could
cause a fire. The appliance should
be plugged into its own outlet.
install an automatic voltage stabiliser
with minimum rating of 1000 Watts
between the appliance and the
socket.
damaged, it must be replaced.
Contact your nearest authorized
KitchenAid Customer Care Center.
6
PARTS AND FEATURES
Julienne Disc
(select models only)
Reversible
(2 mm and 4 mm)
Shredding Disc
Disc
Adapter
Work Bowl
Cover with
3-in-1 Feed
Tube
Slicing
Adapter
Externally
Adjustable
Slicing Disc
Thin to Thick
Drive
Adapter
3-Piece Food
Pusher
ENGLISH
Chef’s Accessory
Case
945 ml (4-Cup)
Mini-Bowl and
Mini-Blade
Work Bowl
Externally
Adjustable
Slicing Control
Heavy-Duty
Base
Stainless Steel
Multipurpose
Blade
Dough Blade
7
PARTS AND FEATURES
Important parts and accessories included with your new Food Processor are highlighted
below. Refer to the following pages for additional details on accessories included with your
Food Processor as well as optional accessories you can order separately (some optional
accessories included with select models).
Externally Adjustable Slicing Control
KitchenAid brand’s exclusive externally
adjustable slicing disc allows you to adjust
slicing thickness from thin to thick, without
having to remove the blade assembly. With
the slicing disc installed, simply slide the
Slicing Thickness Control to the desired
setting - no need to remove the cover or
even turn off the Food Processor.
Speed 1/ Speed 2/ Pulse Control
Two speeds and Pulse provide precise
control to give great results with most
any food.
Work Bowl Cover with 3-in-1 Feed Tube
One of the industry’s largest, the 3-in-1
feed tube accommodates large items – like
tomatoes, cucumbers, and potatoes – with
a minimum of sectioning or slicing.
ACCESSORIES
Included Accessories
945 ml (4-cup) Mini-Bowl and
Mini-Blade
Mini-bowl and stainless steel mini-blade are
perfect for small chopping and mixing jobs.
Work Bowl
The durable, large work bowl provides
capacity for large jobs.
Externally Adjustable Slicing Disc
Disc is adjustable from approximately
1
/16 inch) to 6 mm (1/4 inch) for
1 mm (
slicing most foods.
Reversible Shredding Disc
Shredding disc is reversible to allow coarse
or nely shredded cheese or vegetables.
Drive Adapter
The drive adapter is used with the
appropriate adapter to connect the slicing/
shredding discs and mini-blade to the power
shaft on the base.
Disc Adapter
Adapter ts over the drive adapter and into
the bottom of the adjustable slicing disc.
3-Piece Food Pusher
Three pushers are nested inside of each
other. Remove the medium pusher from the
large pusher to reveal a medium-size feed
tube for continuous processing.
For continuous processing of smaller items
(like herbs, nuts, single carrots, and celery),
remove the narrow pusher and use the
narrow feed tube.
A small hole in the bottom of the narrow
pusher makes it easy to drizzle oil into
ingredients – just ll with the desired
amount of oil or other liquid ingredient.
Heavy-Duty Base
The heavy, slip-resistant base helps
provide improved stability and reduced
vibration during tough food processing jobs.
Julienne Disc (Select Models Only)
Julienne disc is great for making shoestring
potatoes or vegetables.
Slicing Adapter
Adapter ts over the drive adapter and into
the bottom of the shredding or Julienne disc.
Stainless Steel Multipurpose Blade
Versatile blade chops, minces, blends, mixes,
and emulsies in a matter of seconds.
Dough Blade
The dough blade is specially designed
for mixing and kneading yeast dough.
Chef’s Accessory Case
Stylish and durable case organizes and
protects blades, discs, and accessories.
Spatula/Cleaning Tool (not shown)
Special shape facilitates food removal from
bowls, discs, and blades.
8
Loading...
