Hand Mixer
KHM31, KHM51 and KHM61
PARTS AND FEATURES
4
3
7
5
2
1
10
1 Swivel Lock Power Cord
2 Non-Tip Heel Rest
3 Comfort Designed Handle
4 Easy-to-Use Speed Control
5 Oversized Beater Ejector Button
6 Air Vents
7 3-Speed Control
11
6
8
/ 0
12
8 5-Speed Control
9 6-Speed Control
10 Stainless Steel Turbo Beater™
Accessory
11 Flex Edge Beaters*
12 Stainless Steel 16-Tine Pro Whisk*
13 Integrated Storage Clip*
9
/ 0
13
*Accessories available with select models.
2
PRODUCT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. To protect against the risk of electrical shock do not put Hand Mixer in water or
other liquid.
3. This appliance is not intended for use by children or by persons with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge.
Close supervision is necessary when any appliance is used near children.
Children should be supervised to ensure that they do not play with the appliance.
4. Turn the appliance OFF/0, then unplug from the outlet when not in use, before
assembling or disassembling parts and before cleaning. To unplug, grasp the
plug and pull from the outlet. Never pull from the power cord.
5. Avoid contacting moving parts. Keep hands, hair, and clothing, as well as
spatulas and other utensils, away from Beater during operation to reduce the risk
of injury to persons and/or damage to the Hand Mixer.
6. Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions, or is dropped or damaged in any manner. Return
appliance to the nearest Authorized Service Facility for examination, repair, or
electrical or mechanical adjustment.
7. The use of accessories or attachments not recommended or sold by the
manufacturer may cause re, electric shock or injury.
8. Never leave the appliance unattended while it is in operation.
9. Do not use the appliance outdoors.
10. Do not let the cord hang over the edge of table or counter.
ENGLISH
3
PRODUCT SAFETY
11. Do not let the cord contact hot surface, including the stove.
12. Remove any accessories from the Hand Mixer before washing.
SAVE THESE INSTRUCTIONS
This product is designed for household use only.
ELECTRICAL REQUIREMENTS
Voltage: 120 V
Frequency: 60 Hz
NOTE: This Hand Mixer has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not modify the plug in any way.
ACCESSORY GUIDE
Accessory Uses
Turbo Beater™
Flex Edge Beaters*
16-Tine Pro Whisk*
Storage Clip*
To order these accessories
In USA: visit www.shopkitchenaid.com, or call 1-800-541-6390.
In Canada: call 1-800-807-6777.
Cookie dough, Cake batter
Cake batter, Pancake batter,
Cookie dough, Cheese spreads,
Frosting, Mashed potatoes,
Brownie mixes
Whipped cream, Puddings,
Whipped egg whites, Sauces
To store accessories
KHM31 KHM51 KHM61
Included with Model
• • •
•
•
•
*Accessories available with select models.
4
SPEED CONTROL GUIDE
First, clean all parts and accessories (see “Care and Cleaning” section).
IMPORTANT: Hand Mixer should always be set on the lowest speed to start mixing.
Move to higher speeds as needed.
ENGLISH
3-Speed
Hand Mixer
1
2
3
5-Speed
Hand Mixer
1 1
2 2
3 3
4
5 6
6-Speed
Hand Mixer
4
5
Attachment Uses
For slow stirring,
combining, and starting
all mixing procedures. Use
Turbo Beater
Flex Edge Beater
Turbo Beater
Flex Edge Beater
Turbo Beater
Flex Edge Beater
Turbo Beater
Flex Edge Beater
Turbo Beater
Flex Edge Beater
Turbo Beater
Flex Edge Beater
Turbo Beater
Flex Edge Beater
Turbo Beater
16-Tine Pro Whisk
Turbo Beater
16-Tine Pro Whisk
this speed to stir in nuts,
™,
chocolate chips, shredded
cheese, onions, olives, and
other chunky ingredients.
Helps prevent ingredients
from splashing out of bowl.
Mix flour and other dry
™,
ingredients with liquids or
other moist mixtures.
™,
Mix pancake batter.
Combine heavy mixtures,
such as cookie dough.
™,
Mix light cream cheese
spreads. Stir batters and
gelatin mixtures.
Mix muffins and quick
breads. Combine heavy
™,
cream cheese mixtures.
Mash potatoes or squash.
Mix batter breads. Blend
™,
butter and sugar. Mix
frostings.
Finish mixing cake and
other batters. Whip
™,
heavy cream and mousse
mixtures.
Beat egg whites. Whip
™,
heavy cream and mousse
mixtures.
™,
Beat meringue mixtures.
NOTE: The Turbo Beater™ accessories are not designed for mixing and kneading
bread dough.
5
PRODUCT ASSEMBLY
ATTACHING THE ACCESSORIES
1
IMPORTANT: Be sure to read and follow
the specific instructions in this manual for
proper use of the Hand Mixer.
2
DC
Paired accessories (Beaters, optional
Dough Hooks) include one accessory
with a collar (D) and one without (C).
The single accessory comes with a collar
(D) (Liquid Blending Rod) or without (C)
(Whisk).
4
A
B
Before attaching an Accessory, make sure
the Hand Mixer is unplugged from the
electrical outlet.
3
B
D
Insert the accessory shaft with the collar
(D) into the larger opening (B) of the
Hand Mixer. Align the flanges on the shaft
with the slots in the opening. Push to lock
into place.
NOTE: An accessory shaft without a collar
maybe used in either opening (A or B).
Those with a collar may only be used in
the larger opening (B).
Insert the Accessory without a collar (C)
into the smaller opening (A). Align and
push to lock into place.
6
PRODUCT DISASSEMBLY
REMOVING THE ACCESSORIES
1
/ 0
First, stop the Hand Mixer by sliding the
Speed Control to the “OFF/0” position.
Then unplug from the electrical outlet.
PRODUCT USAGE
OPERATING THE SPEED CONTROL
2
Press the Ejector Button to release the
accessories from the Hand Mixer, then
remove them.
This KitchenAid® Hand Mixer will beat faster
and more thoroughly than most other electric
Hand Mixers. Therefore, the beating time in
most recipes must be adjusted to avoid over
beating. Beating time is faster due to larger
Beater sizes.
To help determine the ideal beating time,
observe the batter or dough and beat only
until it has the desired appearance described
in your recipe, such as “smooth and creamy”.
To select the best beating speeds, see the
“Speed Control Guide” section.
ENGLISH
1
/ 0
First, turn the Hand Mixer to the “OFF/0”
position. Then plug into an electrical
outlet.
2
Always start mixing at the lowest speed,
which is Speed 1.
7
PRODUCT USAGE
3
To increase the speed, slide the Speed
Control forward.
To decrease the speed, slide the Speed
Control backward.
4
/ 0
When finished, turn the Hand Mixer to
the “OFF/0’’ position. Then unplug from
the electrical outlet.
CARE AND CLEANING
IMPORTANT: Do not immerse the Hand Mixer body in water or other liquids. Do not
use abrasive cleansers or scouring pads to avoid scratching.
Electrical Shock Hazard
Do not put in water.
Doing so can result in death or
electrical shock.
1
/ 0
Turn the Hand Mixer to the “OFF/0’’
position. Then unplug from an electrical
outlet.
8
2
Wipe the Hand Mixer body with a soft,
damp cloth.
CARE AND CLEANING
3 4
ENGLISH
The following parts are dishwasher-safe,
top rack only: Turbo Beater*, Flex Edge
Beaters*, 16-Tine Pro Whisk*, and
Storage Clip*.
After cleaning of the Flex Edge Beaters*
and 16-Tine Pro Whisk*, fix those to the
Integrated Storage Clip* and assemble
the Clip onto the bottom of the Hand
Mixer.
TROUBLESHOOTING GUIDE
Problem Solution
Check if the Hand Mixer is securely plugged into an
If the Hand Mixer fails to start:
If the problem cannot be
corrected:
outlet.
If you have a circuit breaker box, make sure the circuit is
closed.
Contact KitchenAid or an Authorized Service Center**.
See the “Warranty and Service” section.
Do not return the Hand Mixer to the retailer; retailers do
not provide service.
*These parts can also be washed by hand in warm, soapy water and dry thoroughly.
** USA/Puerto Rico: 1-800-541-6390,
Canada: 1-800-807-6777,
Mexico: 01-800-024-17-17
(JV Distribuciones)
or
01-800-902-31-00
(Industrias Birtman)
9
WARRANTY AND SERVICE
KITCHENAID® HAND MIXER WARRANTY FOR THE 50 UNITED
STATES, THE DISTRICT OF COLUMBIA, PUERTO RICO, AND CANADA
This warranty extends to the purchaser and any succeeding owner for Hand Mixer
operated in the 50 United States, the District of Columbia, Puerto Rico, and Canada.
Length of Warranty: One Year Full Warranty from date of purchase.
KitchenAid Will Pay
for Your Choice of:
Hassle-Free Replacement of your Hand Mixer. See
the next page for details on how to arrange for
service, or call the Customer eXperience Center
toll-free at 1-800-541-6390.
OR
The replacement parts and repair labor costs to correct
defects in materials and workmanship. Service must be
provided by an Authorized KitchenAid Service Center.
KitchenAid Will
Not Pay for:
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
IMPLIED WARRANTIES, INCLUDING TO THE EXTENT APPLICABLE WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE EXCLUDED
TO THE EXTENT LEGALLY PERMISSIBLE. ANY IMPLIED WARRANTIES THAT MAY
BE IMPOSED BY LAW ARE LIMITED TO ONE YEAR, OR THE SHORTEST PERIOD
ALLOWED BY LAW. SOME STATES AND PROVINCES DO NOT ALLOW LIMITATIONS
OR EXCLUSIONS ON HOW LONG AN IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY
TO YOU.
IF THIS PRODUCT FAILS TO WORK AS WARRANTED, CUSTOMER’S SOLE AND
EXCLUSIVE REMEDY SHALL BE REPAIR OR REPLACEMENT ACCORDING TO THE
TERMS OF THIS LIMITED WARRANTY. KITCHENAID AND KITCHENAID CANADA
DO NOT ASSUME ANY RESPONSIBILITY FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES. This warranty gives you specific legal rights and you may also have other
rights which vary from state to state or province to province.
A. Repairs when your Hand Mixer is used in other
than normal single family home use.
B. Damage resulting from accident, alteration,
misuse or abuse.
C. Any shipping or handling costs to deliver your
Hand Mixer to an Authorized Service Center.
D. Replacement parts or repair labor costs for
Hand Mixer attachments operated outside the
50 United States, District of Columbia, Puerto
Rico, and Canada.
10
WARRANTY AND SERVICE
HASSLE-FREE REPLACEMENT WARRANTY – 50 UNITED STATES,
DISTRICT OF COLUMBIA, AND PUERTO RICO
We’re so confident the quality of our
products meets the exacting standards
of KitchenAid brand that, if your Hand
Mixer should fail within the first year
of ownership, KitchenAid will arrange
to deliver an identical or comparable
replacement to your door free of charge
and arrange to have your original Hand
Mixer returned to us. Your replacement unit
will also be covered by our one year limited
warranty.
If your Hand Mixer should fail within the
first year of ownership, simply call our
HASSLE-FREE REPLACEMENT WARRANTY – CANADA
toll-free Customer eXperience Center at
1-800-541-6390 Monday through Friday.
Please have your original sales receipt
available when you call. Proof of purchase
will be required to initiate the claim. Give
the consultant your complete shipping
address. (No P.O. Box numbers, please.)
When you receive your replacement Hand
Mixer, use the carton, packing materials,
and prepaid shipping label to pack up your
original Hand Mixer and send it back to
KitchenAid.
ENGLISH
We’re so confident the quality of our
products meets the exacting standards
of the KitchenAid brand that, if your Hand
Mixer should fail within the first year of
ownership, we will replace your Hand
Mixer with an identical or comparable
replacement. Your replacement unit will
also be covered by our one year limited
warranty.
If your Hand Mixer should fail within the
first year of ownership, simply call our
toll-free Customer eXperience Center at
1-800-807-6777 Monday through Friday.
Please have your original sales receipt
available when you call. Proof of purchase
will be required to initiate the claim. Give
the consultant your complete shipping
address.
When you receive your replacement Hand
Mixer, use the carton, packing materials,
and prepaid shipping label to pack up your
original Hand Mixer and send it back to
KitchenAid.
ARRANGING FOR SERVICE AFTER THE WARRANTY EXPIRES, OR
ORDERING ACCESSORIES AND REPLACEMENT PARTS
In the United States and Puerto Rico:
For service information, or to order
accessories or replacement parts, call
toll-free at 1-800-541-6390 or write to:
Customer eXperience Center,
KitchenAid Small Appliances,
P.O. Box 218, St. Joseph, MI 49085-0218
Outside the United States and
Puerto Rico:
Consult your local KitchenAid dealer or the
store where you purchased the Hand Mixer
for information on how to obtain service.
For service information in Canada:
Call toll-free 1-800-807-6777.
For service information in Mexico:
Call toll-free 01-800-0022-767.
®/™ ©2020 KitchenAid. All rights reserved. Used under license in Canada.
11
Loading...
