5KSB5553
English ................................................................................5
Deutsch ............................................................................ 25
Français ............................................................................45
Italiano ..............................................................................65
Nederlands ......................................................................85
Español ........................................................................... 105
Português ....................................................................... 125
Ελληνικά ......................................................................... 145
Svenska ..........................................................................165
Norsk .............................................................................. 185
Suomi ..............................................................................205
Dansk ..............................................................................225
Íslenska ........................................................................... 245
Русский .......................................................................... 265
Polski ...............................................................................285
Český ..............................................................................305
Türkçe ............................................................................ 325
.............................................................................345
TABLE OF CONTENTS
BLENDER SAFETY
Important Safeguards...........................................................................................6
Electrical Requirements ....................................................................................... 9
Electrical Equipment Waste Disposal ..................................................................9
BLENDER FEATURES ...........................................................................................10
0.75 L CULINARY BLENDER JAR FEATURES ..................................................12
PREPARING THE BLENDER FOR USE
Before First Use ................................................................................................ 13
Blender Assembly .............................................................................................. 13
USING THE BLENDER
Before Use ........................................................................................................ 14
Operating the Blender ....................................................................................... 14
CRUSH ICE ....................................................................................................... 15
PULSE Mode ..................................................................................................... 16
Ingredient Cup ................................................................................................... 16
Soft Start Blending Feature ................................................................................ 16
SPEED CONTROL GUIDE ....................................................................................17
CARE AND CLEANING ........................................................................................ 18
TROUBLESHOOTING .......................................................................................... 19
BLENDER TIPS.......................................................................................................20
CULINARY BLENDER JAR TIPS ......................................................................... 22
WARRANTY AND SERVICE ................................................................................23
English
NOTE: DUE TO THE UNIQUE CONTAINER AND BLADE DESIGN,
READ THESE INSTRUCTIONS AND RECIPES BEFORE USING YOUR NEW
KITCHENAID BLENDER TO ACHIEVE MAXIMUM PERFORMANCE RESULTS.
5
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including
the following:
1. Read all instructions. Misuse of appliance may result
in personal injury.
2. This appliance is not intended for use by persons
(including children) with reduced physical, sensory,
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
6
BLENDER SAFETYBLENDER SAFETY
3. Europe Only: Appliances can be used by persons
with reduced physical, sensory, or mental capabilities
or lack of experience and knowledge if they have
been given supervision or instruction concerning
use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the
appliance.
4. Europe Only: This appliance shall not be used by
children. Keep the appliance and its cord out of
reach of children.
5. Children should be supervised to ensure that they do
not play with the appliance.
6. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent, or similarly
qualied persons in order to avoid a hazard.
7. To protect against risk of electrical shock, do not put
appliance in water or other liquid.
8. Never leave the appliance unattended while it is in
operation.
9. Unplug from outlet when not in use, before putting on
or taking off parts, and before cleaning.
10. Avoid contacting moving parts. Keep hands, hair,
and clothing, as well as spatulas and other utensils
away from blade during operation to reduce the risk
of injury to persons and/or damage to the appliance.
11. Do not operate any appliance with a damaged cord
or plug or after the appliance malfunctions or has
been damaged in any manner. Return appliance
to the nearest Authorised Service Centre for
examination, repair, or adjustment.
12. Do not let the cord hang over the edge of table or
counter.
13. The use of attachments not recommended or sold by
KitchenAid may cause re, electrical shock, or injury.
English
7
14. Do not use the appliance outdoors.
15. Blades are sharp. Care should be taken when
handling the sharp cutting blades, emptying the jar,
and during cleaning.
16. Be careful if hot liquid is poured into the Blender as
it can be ejected out of the appliance due to sudden
steaming.
17. Always operate Blender with lid in place.
18. Flashing light indicates ready to operate — avoid any
contact with blades or movable parts.
19. Keep hands and utensils out of jar while blending to
reduce the risk of severe injury to persons or damage
to the appliance. A scraper may be used but must be
used only when appliance is not running.
20. Refer to the “Care and Cleaning” section for
instructions on cleaning the surfaces in contact with
food.
21. This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, ofces, or other
working environments;
- farmhouses;
- by clients in hotels, motels, and other residential
type environments;
- bed and breakfast type environments.
SAVE THESE INSTRUCTIONS
8
BLENDER SAFETYBLENDER SAFETY
Electrical Requirements
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
Electrical Equipment Waste Disposal
Volts: 220-240 Volts
Hertz: 50 Hz
NOTE: This product is supplied with
a Y-type power cord. If the power cord
is damaged, it must be replaced by the
manufacturer or its service agent in order
to avoid a hazard.
Do not use an extension cord. If the power
supply cord is too short, have a qualified
electrician or serviceman install an outlet
near the appliance.
English
Disposal of packing material
The packing material is 100% recyclable
and is marked with the recycle symbol .
The various parts of the packing must
therefore be disposed of responsibly
and in full compliance with local authority
regulations governing waste disposal.
Scrapping the product
- This appliance is marked in compliance
with European Directive 2012/19/EU, Waste
Electrical and Electronic Equipment (WEEE).
- By ensuring this product is disposed of
correctly, you will help prevent potential
negative consequences for the environment
and human health, which could otherwise
be caused by inappropriate waste handling
of this product.
- The symbol on the product or on the
accompanying documentation indicates
that it should not be treated as domestic
waste but must be taken to an appropriate
collection centre for the recycling of
electrical and electronic equipment.
For more detailed information about
treatment, recovery and recycling of this
product, please contact your local city ofce,
your household waste disposal service or the
shop where you purchased the product.
9
Easy Pour
1.5 L Glass
Pitcher
Durable
Steel-Reinforced
Couplers
Stay-Put Lid
with Clear 60 mL
Ingredient Cup
Stainless
Steel Blade
Locking Collar
and Blade Assembly
Speed
Selection
Buttons
Clean Touch
Control Pad
WARNING: Flashing light indicates ready to operate. Do not touch blades.
10
Die-Cast
Metal Base
BLENDER FEATURESBLENDER FEATURES
This Blender was built and tested to
KitchenAid quality standards for optimum
performance and long, trouble-free life.
Robust Motor
Rugged 0.9-horsepower motor supplies
the power for superb performance with
all blending tasks – from pureeing sauces
to making chunky salsas, or uniformly
crushing a pitcher of ice or frozen fruit
within seconds for silky smoothies.
Easy Pour 1.5 L
Glass Pitcher
Glass Pitcher resists scratches,
stains and odors. Pitcher is
removable from locking collar
for easy cleaning, and withstands a range
of extreme temperatures. Easy pour spout
provides smooth, drip-free pouring.
Stay-Put Lid with Clear 60 mL
Ingredient Cup
Provides a strong seal. The flexible lid
will maintain its tight seal throughout
the life of the Blender. The lid incorporates
a removable 60 mL cup for convenience
in measuring and adding ingredients.
Stainless Steel Blade
Sharp oversized blade tines are positioned
on four different planes for fast, thorough,
and consistent blending.
Locking Collar and Blade Assembly
Durable, one-piece blade design is built
into the locking collar for easy handling and
cleaning. This assembly keeps the blades
from rotating until the pitcher is properly
attached to the collar and put on the
Blender base.
Durable Steel-Reinforced Couplers
Commercial-quality couplers with 12
interlocking teeth provide direct transfer
of motor power to the blade. Pitcher
coupler is coated for quiet operation.
Speed Selection Buttons
Create frozen drinks and puree sauces or
soups in seconds. Blend with confidence,
control, and consistency at all speed
settings:
STIR (), CHOP ( ), MIX ( ), PURÉE
( ), and LIQUEFY ( ). The PULSE
( ) mode works with all five speeds.
The CRUSH ICE ( ) feature is designed
specifically for crushing ice and will
automatically pulse at staggered intervals
for optimal results.
Intelli-Speed Motor Control
Exclusive Intelli-Speed control automatically
works to keep speed constant – even
through density changes when ingredients
are added. This advanced KitchenAid design
maintains an optimal blending speed for
each culinary task and control-pad setting.
Soft Start Blending Feature
The Blender starts at a slower speed
to pull food into the blade, then quickly
increases to selected speed setting. This
design feature reduces start-up kick and
allows hands-free operation.
Die-Cast Metal Base
Heavy, die-cast metal base ensures stable,
quiet operation when blending a full pitcher
of ingredients. Four rubber feet on wide,
solid base provide a no-slip, non-marring
grip. Smooth and rounded, the base is
easy to clean and features cord storage
underneath.
Clean Touch Control Pad
Wipes clean in an instant. Smooth
control pad has no crevices or cracks
to trap ingredients.
English
11
0.75 L
Culinary
Blender Jar
Culinary Blender
Jar Lid with
Drizzle Cap*
*On the lid,
the following
caution is written:
“CAUTION: DO
NOT OPERATE
WITHOUT THIS
COVER IN PLACE.”
Shatter-Resistant Culinary Blender Jar
Clear jar is shatter-, scratch-, and stainresistant (BPA-free material). Durable
Culinary Blender Jar is useful for small
capacity recipes and individual servings.
12
Culinary Blender Jar Lid
with Drizzle Cap
The twist-lock lid includes a removable
drizzle cap that fits both the Culinary
Blender Jar and pitcher lids. This
versatile cap can be used to drizzle
oils or other ingredients while the
Blender is in operation.
PREPARING THE BLENDER FOR USE0.75 L CULINARY BLENDER JAR FEATURES
Before First Use
Before using your Blender for the first time,
wipe Blender base with a warm, sudsy
cloth, then wipe clean with a damp cloth.
Dry with a soft cloth. Wash pitcher, culinary
jar, lids, locking collar, and blade assembly,
sealing ring and ingredient cup in warm,
sudsy water (see “Care and Cleaning”).
Rinse parts and wipe dry.
Blender Assembly
1. Put locking collar with blade assembly
pointing up on a sturdy surface.
2. Put sealing ring, flat side down, around
the blades and into the groove within
the locking collar.
Sealing
Ring
3. Align the pitcher (or culinary jar) tabs
with the slots of the locking collar.
English
4. Press down and rotate pitcher (or
culinary jar) clockwise approximately
1/4 turn, until two clicks are heard.
5. Adjust the length of the Blender
power cord.
Locking
Collar
6. Put pitcher (or culinary jar) assembly
onto the Blender base.
13
NOTE: When properly positioned,
pitcher (or culinary jar) assembly will rest
completely on Blender base. If not, repeat
steps 3 and 4.
Gap
7. Put lid on pitcher (or culinary jar).
No
Gap
USING THE BLENDER
Before Use
NOTE: While the Blender is on or the
PULSE ( ) mode indicator light is blinking:
- Do not interfere with blade movement.
-
Do not remove pitcher (or culinary jar) lid.
Operating the Blender
The KitchenAid Blender has five speeds:
STIR (), CHOP ( ), MIX ( ),
PUREE ( ), and LIQUEFY ( ). In
addition, it also features CRUSH ICE ( )
and PULSE ( ) mode.
Electrical Shock Hazard
Plug into an earthed outlet.
Do not remove earth prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these
instructions can result in
death, fire, or electrical shock.
8. Plug power cord into an earthed outlet.
Blender is now ready for operation.
9. Before removing the pitcher (or culinary
jar) assembly from the base, always press
“O” (OFF) and unplug the power cord.
1. With convenient one-step operation,
this unit will operate only when a speed
selection button is pressed.
2. Before operating the Blender, make
sure the pitcher (or culinary jar) is
properly secured in the locking collar
and assembly is positioned on the
Blender base.
14
USING THE BLENDERPREPARING THE BLENDER FOR USE
NOTE: If a gap exists between the locking
collar and the base, the pitcher (or culinary
jar) might not be locked into the locking
collar or the assembly is not positioned
properly on the Blender base. See “Blender
Assembly” for further instructions.
Gap
3. Put ingredients in pitcher (or culinary jar)
and firmly attach lid.
4. Press the desired speed button for
continuous operation at that speed.
The green indicator light by the
selected speed will stay lit. You may
change settings without stopping the
unit by pressing a new speed button.
IMPORTANT: If blending hot foods or
liquids, remove the centre ingredient
cup. Operate only on STIR ( ) speed.
5. To turn off the Blender, press “O”. The
“O” (OFF) button will stop any speed
and deactivate the Blender at the same
time.
6. Before removing the pitcher (or culinary
jar) assembly, unplug the power cord.
No
Gap
CRUSH ICE
Your KitchenAid Blender offers a CRUSH
ICE ( ) feature. When selected, the
Blender will automatically pulse at staggered
intervals at the optimal speed for crushing
ice or other ingredients.
1. Before operating the Blender, make
sure the pitcher assembly is properly
positioned on the Blender base.
NOTE: If a gap exists between the locking
collar and the base, the pitcher (or culinary
jar) might not be locked into the locking
collar or the collar is not positioned
properly on the Blender base. See “Blender
Assembly” for further instructions.
2. Put ingredients into the pitcher
and firmly attach lid.
3. Press CRUSH ICE ( ). The indicator
light will stay lit. The Blender will
automatically pulse at staggered intervals.
4. To turn off the CRUSH ICE ( ) feature,
press “O”. The Blender is now ready for
continuous operation.
5. Before removing the pitcher assembly,
unplug the power cord.
English
15
PULSE Mode
Your KitchenAid Blender offers PULSE
( ) mode, which allows a “Pulse-at-anySpeed” feature.
NOTE: PULSE ( ) mode will not work
with the CRUSH ICE ( ) feature.
1. Before operating the Blender, make sure
the pitcher (or culinary jar) assembly is
properly positioned on the Blender base.
NOTE: If a gap exists between the
locking collar and the base, the pitcher
(or culinary jar) might not be locked
into the locking collar or the collar is not
positioned properly on the Blender base.
See “Blender Assembly” for further
instructions.
2. Put ingredients into pitcher (or culinary
jar), and firmly attach lid.
3. Press PULSE ( ). The indicator light
above the button will blink to indicate
that all five speeds are in the PULSE
( ) mode.
5. To turn off the PULSE ( ) mode
feature, press “O”. The Blender is now
ready for continuous operation.
6. Before removing the pitcher (or culinary
jar) assembly, unplug the power cord.
Ingredient Cup
The 60 mL ingredient cup can
be used to measure and add
ingredients. Remove cup and
add ingredients at STIR (), CHOP ( )
or MIX ( ), speeds. When operating at
higher speeds, with a full pitcher or with
hot contents, stop the Blender and then
add ingredients.
IMPORTANT: If blending hot foods or
liquids, remove the centre ingredient
cup. Operate only on STIR () speed.
Soft Start Blending Feature
The Soft Start blending feature automatically
starts the Blender at a lower speed to
draw ingredients into the blades, then
quickly increases to the selected speed
for optimal performance.
NOTE: The Soft Start blending feature
only works when a speed is selected from
the “O” (OFF) mode and does not work
with the PULSE ( ) mode or CRUSH ICE
( ) features.
4. Select a speed button. Press and hold
for the desired length of time. Both the
speed button and PULSE ( ) mode
indicators will stay lit when pulsing at the
selected speed. When button is
released, the blending will stop, but
the Blender will remain in PULSE ( )
mode and the PULSE ( ) mode
indicator will return to blinking. To
pulse again or at another speed, simply
press and hold the button of the desired
speed.
16
SPEED CONTROL GUIDEUSING THE BLENDER
Item Speed
Blended ice drink ...................
Cheesecake ........................
Chopped fruits ..................
Chopped vegetables ..............
Cream cheese-based spread. . . . . . . . . . .
Cream soup .......................
Crushed/chopped ice ................
Dip ...............................
Finely chopped fresh fruits ............
Finely chopped
fresh vegetables. . . . . . . . . . . . . . . . . . .
Fluffy gelatin for pie/desserts ..........
Frozen chopped fruit
(defrost slightly until it
can be probed with a
knife tip) ........................
Frozen yogurt-based drink ...........
Fruit juice from
frozen concentrate ................
Fruit-based drink (thin) ...............
Fruit-based drink (thick) ..............
Fruit-based sauce ...................
Grated hard cheese. . . . . . . . . . . . . . . . . .
TIP: Process up to one standard ice cube tray or 12 to 14 standard ice cubes at a time.
Occasional stirring with a spatula will be helpful only when Blender is “O” (OFF). The
CRUSH ICE ( ) feature has been optimised to crush and chop ice without adding any
liquid ingredients.
Item Speed
Gravy ..............................
Ice milk-based drink .................
Meat salad for
sandwich filling ................
Mousse ...........................
Oatmeal ...........................
Pancake batter .......................
Pesto .............................
Puréed fruit/Baby food ................
Puréed meat/Baby food meat ..........
Puréed vegetables/Baby food
vegetables .......................
Salad dressing ......................
Savoury crumb topping ............
Sherbet-based drink .................
Smooth ricotta or
cottage cheese ...................
Streusel topping ....................
Sweet crumb topping .............
Sweet crunch topping ............
Vegetable-based main dish sauce .......
Waffle batter ........................
White sauce .......................
English
17
The Blender pitcher, culinary jar, locking
collar, and blade assembly can be easily
cleaned as individual components or
together without disassembly.
• Clean the Blender thoroughly
after every use
• Do not immerse the Blender
base or cord in water
• Do not use abrasive cleansers
or scouring pads
To Clean Individual Components
1. Lift the pitcher (or culinary jar) assembly
in a straight, upwards motion off the
Blender base. Place assembly on a
hard surface. Then, while holding
locking collar, rotate pitcher (or
culinary jar) counterclockwise, two
clicks, to separate locking collar and
blade assembly, and sealing ring from
the pitcher (or culinary jar). Wash
components with soapy water. Rinse and
wipe dry.
NOTE: Hand-wash the lid, ingredient cup,
locking collar, and sealing ring — these
items may be damaged in the dishwasher.
Pitcher can be placed in the bottom rack
of an automatic dishwasher.
To Clean Without Disassembly
1. Put the pitcher (or culinary jar) on the
Blender base, fill half full with warm
(not hot) water, and add 1 or 2 drops
of dishwashing liquid. Put the lid on the
pitcher (or culinary jar), press the STIR
() speed setting, and run the Blender
for 5 to 10 seconds. Remove the pitcher
(or culinary jar) and empty contents.
Rinse with warm water until clean.
2. To clean the lids and ingredient cup,
wash in warm soapy water, then rinse
and dry thoroughly.
3. Wipe the Blender base and cord with
a warm, sudsy cloth; wipe clean with
a damp cloth, and dry with a soft cloth.
Pitcher
Sealing
Ring
Locking
Collar
and Blade
Assembly
2. Wipe the Blender base and cord with
a warm, sudsy cloth; wipe clean with
a damp cloth, and dry with a soft cloth.
18
Culinary
Jar
TROUBLESHOOTINGCARE AND CLEANING
The Blender does not operate when a setting is selected:
Check to see if the Blender is plugged into
an outlet. If it is, press “O” (OFF), then
unplug the Blender. Plug it back in to the
same outlet. If the Blender still does not
work, check the fuse or circuit breaker
on the electrical circuit the Blender is
connected to and make sure the circuit is
No indicator lights are lit.
The Blender stops while blending:
All indicator lights are flashing
at the same time.
Indicator lights are flashing alternately.
closed.
The Blender may be overloaded. If the
Blender becomes overloaded when
blending heavy ingredients, it will
automatically shut off to prevent damage
to the motor. Press “O” (OFF) to reset the
Blender and unplug the power cord. Remove
the pitcher assembly from the base and
divide contents into smaller batches. Adding
liquid to the pitcher may also reduce the
load on the Blender.
The Blender may be jammed. If it’s
jammed, the Blender will stop running to
prevent damage to the motor. Press “O”
(OFF) to reset the Blender and unplug the
power cord. Remove the pitcher assembly
from the base and with a scraper, free
the blades by breaking up or removing the
contents at the bottom of the pitcher.
English
The Blender turns on, but blades will not rotate:
The pitcher is not properly secured in the
locking collar, not allowing couplers to
engage. Remove pitcher (or culinary jar)
Gap
If the problem cannot be fixed with the steps provided in this section, then contact an
Authorised Service Centre (see “Warranty and Service”).
Do not return the Blender to the retailer – retailers do not provide service.
from base and fully seat into collar. Press
down and rotate pitcher clockwise in the
locking collar past the second “click.” This
will allow the pitcher assembly to engage
the coupler. See “Blender Assembly”.
19
Quick Tips
• In order to produce a smoother texture,
blend with CRUSH ICE ( ) if you’re
making beverages using ice.
• Smaller ice cubes can be chopped or
crushed faster than large ones.
• Add food to this Blender pitcher in
larger quantities than you would with
other blenders – you can add 2 to 3 cups
(475 to 710 mL) at a time versus 1 cup
(235 mL) portions.
• For many ingredient mixtures, start
the blending process at STIR ( ) to
thoroughly combine the ingredients. Then
increase to a higher speed, if necessary.
• Be sure to keep lid on pitcher
while blending.
• If desired, remove centre ingredient cup
of pitcher lid to add liquids or ice cubes
while the Blender is operating at STIR ( ),
CHOP ( ), or MIX ( ) speeds.
• When operating at higher speeds with
a full pitcher or with hot contents, stop
the Blender and then add ingredients.
• Stop the Blender before using utensils
in the pitcher. Use a rubber spatula to mix
ingredients only when the Blender is “O”
(OFF). Never use any utensil, including
spatulas, in the pitcher while the motor
is running.
• Cool hot foods, if possible, before
blending. Begin blending warm foods
at STIR ( ). Increase to a higher speed,
if necessary.
• Remove centre ingredient cup when
blending hot liquids and operate only
on STIR ( ). Do not place bare
hand on pitcher lid when processing
hot liquids.
• Stop and check the consistency
of foods after a few seconds to
prevent over-processing.
How To ...
Reconstitute frozen juice: For a 175 mL
can of orange juice concentrate, combine
the juice and correct amount of water in
the pitcher. Cover and blend at MIX ( )
until thoroughly combined, about 10 to
15 seconds.
For a 355 mL can, combine the juice
and 1 can of water in the pitcher. Cover
and blend at MIX ( ) until thoroughly
combined, about 20 to 30 seconds. Stir
in remaining 2 cans of water.
Dissolve flavoured gelatin: Pour boiling
water into the pitcher; add gelatin. Remove
centre ingredient cup and blend at STIR ( )
until gelatin is dissolved, about 10 to
30 seconds. Add other ingredients.
Make cookie and graham cracker
crumbs: Break larger cookies into pieces
about 4 cm in diameter. Use smaller cookies
as-is. Place in pitcher. In PULSE ( ) mode,
cover and blend at CHOP ( ), pulsing
a few times, about 3 seconds each time,
until desired consistency is reached. Use
the crumbs to make a quick topping for
frozen yoghurt, pudding, or a fruit compote.
To make a finer crumb for pie and dessert
crusts, break graham crackers or cookies
into pieces about 4 cm in diameter and place
in the pitcher. In PULSE ( ) mode, cover
and blend at LIQUEFY ( ), pulsing a few
times until desired consistency is reached,
about 20 to 30 seconds.
Make cracker crumbs: Follow procedure
for cookies. Use as a topping or as an
ingredient in main dish casseroles and
vegetable dishes.
Make bread crumbs: Tear bread into
pieces about 4 cm in diameter. Follow
procedure for cookies. Use as a topping
or as an ingredient in main dish casseroles
and vegetable dishes.
20
BLENDER TIPSBLENDER TIPS
Chop fruits and vegetables: Put 2 cups
(475 mL) of fruit or vegetable chunks in
pitcher. In PULSE ( ) mode, cover and blend
at STIR ( ), pulsing a few times, about
2 to 3 seconds each time, until desired
consistency is reached.
Puree fruits: Place 2 cups (475 mL)
canned or cooked fruit in pitcher. Add 2 to
4 tablespoons (30 to 60 mL) fruit juice or
water per cup (240 mL) of fruit. Cover and
blend at PUREE ( ) about 5 to 10 seconds.
Puree vegetables: Place 2 cups (475 mL)
canned or cooked vegetables in pitcher. Add
2 to 4 tablespoons (30 to 60 ml) broth,
water, or milk per cup (240 mL) of
vegetables. Cover and blend at PUREE ( )
about 10 to 20 seconds.
Puree meats: Place cooked, cubed, tender
meat in pitcher. Add 3 to 4 tablespoons
(45 to 60 mL) broth, water, or milk per cup
(240 mL) of meat. Cover and blend on STIR
( ) 10 seconds. Stop the Blender and
scrape sides of pitcher. Cover and blend on
PUREE ( ) 10 to 20 seconds longer.
Puree cottage cheese or ricotta cheese:
Place cottage cheese or ricotta cheese in
pitcher. Cover and blend at MIX ( ) until
smooth, about 25 to 35 seconds. Stop
the Blender and scrape sides as needed. If
necessary, add 1 tablespoon (15 mL) of skim
milk per cup (240 mL) of cottage cheese.
Use as a base for low-fat dips and spreads.
Combine liquid ingredients for baked
goods: Pour liquid ingredients in pitcher.
Cover and blend at LIQUEFY ( ) until
well-mixed, about 10 to 15 seconds. Pour
liquid mixture over dry ingredients and
stir well.
Take lumps out of gravy: If sauce or
gravy becomes lumpy, place in the pitcher.
Cover and blend at MIX ( ) until smooth,
about 5 to 10 seconds.
Combine flour and liquid for thickening:
Place flour and liquid in pitcher. Cover and
blend at STIR ( ) until smooth, about 5 to
10 seconds.
Prepare white sauce: Place milk, flour, and
salt, if desired, in pitcher. Cover, and blend
at STIR ( ) until well-mixed, about 5 to
10 seconds. Pour into saucepan and cook
as usual.
Prepare pancake or waffle batter from
mix: Place mix and other ingredients in
pitcher. Cover and blend at MIX ( )
until well-mixed, 10 to 20 seconds. Stop
the Blender and scrape sides of the pitcher
as needed.
Grate cheese: Cut very cold cheese into
1,5 cm cubes. Place up to 1/2 cup (120 mL)
cheese in the pitcher. Cover, and blend at
LIQUEFY ( ) about 5 to 10 seconds.
For hard cheeses, such as Parmesan,
bring to room temperature, then blend
at LIQUEFY ( ) for 10 to 15 seconds.
Make oatmeal for a baby: Place uncooked
rolled oats in pitcher. In PULSE ( ) mode,
blend at MIX ( ) until desired consistency,
about 5 pulses, 2 to 3 seconds each pulse.
Cook as usual.
Make baby food from adult food: Place
prepared adult food in pitcher. Cover
and blend at STIR ( ) about 10 seconds.
Then blend at PURÉE ( ) about 10 to
30 seconds.
Rinse your Blender Pitcher: Fill pitcher
one-half full with warm water. Add a few
drops of dishwashing liquid. Cover and blend
at STIR ( ) until sides are clean, about 5
to 10 seconds. Rinse and dry. For complete
cleaning, pitcher can also be cleaned in an
automatic dishwasher. For best results,
hand-washing is recommended for the lid,
ingredient cup, locking collar and blade
assembly, and sealing ring. Refer to “Care
and Cleaning”.
English
21
CULINARY BLENDER JAR TIPS WARRANTY AND SERVICE
Culinary blender jar
The Culinary blender jar is ideal for blending
salad dressings, fresh mayonnaise, salsa, or
pesto and just the right size for single serving
shakes or smoothies. Or use it to chop fresh
herbs or nuts while preparing recipes.
Process smaller quantities of specific ingredients to obtain the following results:
- bread crumbs (100 g brown or 50 g white) very fine result
- processing carrots evenly fine chopped result
- hummus (using 130 g drained chickpeas) very good result
- mayonnaise (2 large eggs and 150/200 mL olive oil) very consistent (thick) result
(best result by adding vinegar,
salt and pepper once mixture
has thickened)
- herbs (such as 25 g of parsley) coarsely chopped result
- peanut butter (100 g peanuts) fine ground result
- almond nuts (50 g or 150 g) ground to very fine texture
- soup (up to 750 g vegetables and herbs) very good result
- smoothie (210 g or 425 g tinned fruit; whole banana; perfect results
cup full of juice and 1 Tbsp. yogurt)
- chopping cheese very fast and perfect result
- pesto (70 mL, 1 garlic clove, 20 g basil, 20 g pine nuts very good consistency
and 45 g Parmesan cheese)
- spices (30 mL coriander seeds) fine (but not as powder)
- spices (30 mL mustard seeds) good, fine result to powder fine
on high speed
- biscuits (8 or 100 g) perfect fine result
Drizzle Cap
This versatile cap fits into both the pitcher and Culinary blender jar lid and is used to drizzle
oils or other liquids while the Blender is in operation.
This Culinary blender jar complements
the Artisan 1.5 L glass pitcher. This small
Culinary blender jar performs better and
faster for smaller amounts, and processing
will result in a finer texture: such as baby
food, puréeing soups, fresh herbs, spices,
smoothies, bread crumbs, biscuits, and dips
(hummus, pesto, mayonnaise).
22
KitchenAid Blender Warranty
Length of Warranty: KitchenAid Will Pay For: KitchenAid Will Not Pay For:
Europe, Middle East
and Africa:
For model 5KSB5553:
Three years full
warranty from date
of purchase.
The replacement parts
and repair labour costs to
correct defects in materials
or workmanship. Service
must be provided by an
Authorised KitchenAid
Service Centre.
A. Repairs when Blender is
used for operations other
than normal household food
preparation.
B. Damage resulting from
accident, alterations,
misuse, abuse, or installation/
operation not in accordance
with local electrical codes.
KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR
INDIRECT DAMAGES.
Customer Service
In U.K. and Ireland:
For any questions, or to find the nearest KitchenAid Authorised Service Centre, please find
our contact details below.
NOTE: All service should be handled locally by an Authorised KitchenAid
Service Centre.
General hotline number:
In other countries:
For all product related questions and after sales matters, please contact your dealer to
obtain the name of the nearest Authorised KitchenAid Service/Customer Centre.
For more information, visit our website at:
www.KitchenAid.co.uk
www.KitchenAid.eu
English
Specications subject to change without notice.
©2018 All rights reserved.
23
Loading...
