Kitchenaid 5ksb52sbu5, 5ksb52sgr5, 5ksb52sob5, 5ksb52swh5, 5ksb52ser5 Installation Template

5−SPEED BLENDER− SWISS

MODELS:

5KSB52SWH5 (White)
5KSB52SOB5 (Onyx Black)
5KSB52SBU5 (Cobalt Blue)
5KSB52SGR5 (Imperial Grey)
5KSB52SER5 (Empire Red)

05−06 Litho in U.S.A. (skr)

c

2006 KITCHENAID

Part No. 8212374

UNIT PARTS

For Variations Of Model: 5KSB52S_ _5

8212374

2

UNIT PARTS

For Variations Of Model: 5KSB52S_ _5

Illus. Part

No. No. DESCRIPTION

1 Literature

9709310 Use & Care Guide

8212374 Repair Parts List
2 9704296 Overlay, Switch
3 Housing, Upper

9706989 White

9706993 Onyx Black

9706991 Cobalt Blue

9706996 Imperial Grey

9706995 Empire Red
4 9704299 EMI Filter

W10068250

5
6 9706613 Board, Control

7 3184398 Seal, Motor
8 9706760 Motor (240V)
9 3400062 Screw

10 9701904 O−Ring
12 9704230 Coupling, Drive
13 Base

9706718 White

9706722 Onyx Black

9706720 Cobalt Blue

9706722 Imperial Grey

9706724 Empire Red

14 9704295 Band, Trim
16 3184608 Screw
17 115792 Foot, Rubber
18 Power Cord

9707862 White

9707863 Black

Screw
(230V)

3

8212374

ATTACHMENT PARTS

For Variations Of Model: 5KSB52S_ _5

Illus. Part

No. No. DESCRIPTION

1 Lid And Cap

2 Jar
3 9707580 Dome & Blade Assy

4 9704204 Seal, Insert
5 Collar

6 Upper Assembly,

9707909 White
9707911 Onyx Black
9707913 Cobalt Blue
9707912 Empire Red

9704200 Clear Glass

9704251 White
9704253 Onyx Black
9704255 Cobalt Blue
9704254 Empire Red

Complete
9707581 White
9707587 Onyx Black
9707584 Cobalt Blue
9707583 Empire Red

8212374

4
