KitchenAid 5KFP0925 Instructions Manual
Model 5KFP0925
W10529658A_01_EN.indd 1 10/23/12 2:14 PM
5
English
Table of Contents
FOOD PROCESSOR SAFETY
Important Safeguards.................................................................................................6
Electrical Requirements ............................................................................................. 7
Electrical Equipment Waste Disposal ........................................................................7
PARTS AND FEATURES
Food Processor Parts ................................................................................................8
Important Food Processor Features .........................................................................9
ACCESSORIES
Included Accessories .................................................................................................9
Accessories Selection Guide .................................................................................... 10
PREPARING FOOD PROCESSOR FOR FIRST USE
Before First Use ......................................................................................................11
Removing the Work Bowl Cover from the Work Bowl ..........................................11
SETTING UP YOUR FOOD PROCESSOR
Attaching the Work Bowl ........................................................................................12
Attaching the Work Bowl Cover .............................................................................12
Installing the Adjustable Slicing Disc ........................................................................13
Installing the Reversible Shredding Disc ..................................................................13
Installing the Multipurpose Blade or Dough Blade ..................................................14
Installing the Mini-Bowl and Mini-Blade ..................................................................14
Using the 3-in-1 Feed Tube .....................................................................................15
USING YOUR FOOD PROCESSOR
Before Use ..............................................................................................................16
Maximum Liquid Level ............................................................................................16
Using the Speed 1/Speed 2 Control ........................................................................ 16
Using the Pulse Control ..........................................................................................16
Removing Processed Foods .....................................................................................17
CARE AND CLEANING ............................................................................................... 18
TIPS FOR GREAT RESULTS
Using the Multipurpose Blade .................................................................................19
Using a Slicing or Shredding Disc.............................................................................20
Using the Dough Blade ............................................................................................ 21
Helpful Hints............................................................................................................21
TROUBLESHOOTING ................................................................................................. 23
SERVICE AND WARRANTY .......................................................................................24
FOOD PROCESSOR INSTRUCTIONS
6
FOOD PROCESSOR SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
including the following:
1. Read all instructions.
2. To protect against risk of electrical shock, do not put Food Processor in water or other liquid.
3. This appliance is not intended for use by persons (including children) with reduced
physical sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
4. Children should be supervised to ensure that they do not play with the appliance.
5. Unplug from the outlet when not in use, before putting on or taking off parts, and
before cleaning.
6. Avoid contacting moving parts.
7. Do not operate any appliance with a damaged cord or plug, or after the appliance
malfunctions, or is dropped or damaged in any manner. Return appliance to the nearest
Authorized Service Facility for examination, repair, or electrical or mechanical adjustment.
8. The use of attachments not recommended or sold by KitchenAid may cause re, electric
shock, or injury.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter.
11. Keep hands and utensils away from moving blades or discs while processing food to
reduce the risk of severe injury to persons or damage to the Food Processor. A scraper
may be used but must be used only when the Food Processor is not running.
12. Blades are sharp. Handle carefully.
13. To reduce the risk of injury, never place cutting blade or discs on base without rst
putting bowl properly in place.
14. Be certain cover is securely locked in place before operating appliance.
SAVE THESE INSTRUCTIONS
7
English
FOOD PROCESSOR SAFETY
Electrical Requirements
Voltage: 220-240 Volts
Frequency: 50/60 Hertz
Wattage: 240 Watts
NOTE: If the plug does not t in the outlet,
contact a qualied electrician. Do not modify
the plug in any way.
This appliance is marked according to the
European directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed
of correctly, you will help avoid potential
negative consequences for the environment
and human health, which could otherwise
be caused by inappropriate waste handling
of this product.
The symbol
on the product, or on the
documents accompanying the product,
indicates that this appliance may not be
treated as household waste. Instead it shall
be handed over to the applicable collection
point for the recycling of electrical and
electronic equipment.
Disposal must be carried out in accordance
with local environmental regulations
for waste disposal.
For more detailed information about
treatment, recovery and recycling of this
product, please contact your local city ofce,
your household waste disposal service or
the shop where you purchased the product.
Electrical Equipment Waste Disposal
IMPORTANT SAFEGUARDS
15. Never feed food by hand. Always use the food pusher.
16. Do not attempt to defeat the cover interlock mechanism.
17. This product is designed for household use only.
SAVE THESE INSTRUCTIONS
8
PARTS AND FEATURES
Base
2.1 L
Work Bowl
Reversible
(2 mm and 4 mm)
Shredding Disc
Adjustable Slicing
Disc (Thin to Thick)
Stainless Steel
Multipurpose
Blade
Work Bowl
Cover with
3-in-1 Feed
Tube
3-Piece
Food Pusher
710 ml Mini-Bowl
and Mini-Blade
Plastic
Dough Blade
Shredding
Adapter
Food Processor Parts
9
English
PARTS AND FEATURES
Adjustable Slicing Control
KitchenAid’s adjustable slicing disc allows you
to manually adjust slicing thickness from thin
to thick.
Speed 1/Speed 2/Pulse Control
Two speeds and Pulse provide precise
control to give great results with almost
any food.
Work Bowl Cover with 3-in-1 Feed Tube
The 3-in-1 feed tube accommodates large
items – like tomatoes, cucumbers, and
potatoes – with a minimum of sectioning
or slicing.
3-Piece Food Pusher
Three pushers are nested inside of each
other. Remove the medium pusher from the
large pusher to reveal a medium-size feed
tube for continuous processing.
For continuous processing of smaller items
(like herbs, nuts, single carrots, and celery),
remove the narrow pusher and use the
narrow feed tube.
A small hole in the bottom of the narrow
pusher makes it easy to drizzle oil into
ingredients – just ll with the desired
amount of oil or other liquid ingredient.
Base
The heavy, slip-resistant base helps
provide improved stability and reduced
vibration during tough food processing jobs.
2.1L Work Bowl
The durable, large work bowl provides
capacity for large jobs.
710 ml Mini-Bowl and Mini-Blade
Mini-bowl and stainless steel mini-blade are
perfect for small chopping and mixing jobs.
Adjustable Slicing Disc
Disc is adjustable from approximately
1 to 6 mm (1/16 to 1/4 inch) for slicing
most foods.
Reversible Shredding Disc
Shredding disc is reversible to allow coarse
or nely shredded cheese or vegetables.
Shredding Adapter
The shredding adapter is used to connect
the shredding disc to the power shaft on
the base.
Stainless Steel Multipurpose Blade
Versatile blade chops, minces, blends, mixes,
and emulsies in a matter of seconds.
Dough Blade
The dough blade is specially designed for
mixing and kneading yeast dough.
ACCESSORIES
Included Accessories
Important Food Processor Features
10
Accessories Selection Guide
ACCESSORIES
+
Cheese
Chocolate
Fruit
Fresh Herbs
Nuts
Tofu
Vegetables
Meat
Pasta Sauce
Pesto
Salsa
Sauces
Cake Batter
Pie Dough
Yeast Dough
Potatoes
Vegetables (soft)
Cabbage
Cheese
Chocolate
Fruit (hard)
Vegetables (hard)
Fruit (soft)
Potatoes
Tomatoes
Vegetables (soft)
Cheese
Chocolate
Fruit (hard)
Vegetables (hard)
Slice
Thick
Slice
Thin
Shred
Medium
Shred
Fine
Action Setting Food Accessory
ChopMince Puree
Mix
Knead
OR
Multipurpose Stainless Steel Blade
Adjustable Slicing Disc
Reversible Shredding Disc
Plastic Dough Blade
Mini-bowl and Mini Multipurpose
Stainless Steel Blade
