Kiddy World plus User Manual
Toddler / Booster Car Seat Instruction Manual
Toddler Car Seat
Booster Car Seat
• Certified for use in motor vehicles
• Meets or exceeds all applicable requirements of Federal
Motor Vehicle Safety Standard FMVSS 213
Para atención al cliente en
Espanol llame al siguiente
número 1-855-92-KIDDY o log
en www.kiddy-usa.com.
Stand 02/2013 USA
Car Seat parts
top tether belt
backrest
top tether hook
seat cushion
strap
snap fastener
seat cushion
LATCH
connector
storage pocket
Protection
Shield Buckle
LATCH
connector
headrest
height adjust-
ment handle
instruction
manual &
locking clip
storage box
car seat
protection shield
back side
headrest
shoulder belt
guide
shoulder rest
armrest
protection
shield slot
seat cushion
seat
belt guide
belt channel
lower anchor
belt with
LATCH
connectors
tether storage
pocket
locking clip
1. Introduction............................................................................... 3
2. Recommended use................................................................... 3
2.1 Toddler Car Seat Use (WITH protection shield)........................................ 3
2.2 Booster Car Seat Use (WITHOUT protection shield)................................ 4
3. General safety warnings.......................................................... 5
4. Vehicle seating position and adjustment............................... 8
4.1 Vehicle seat location requirements............................................................ 8
4.2 Vehicle seat belts....................................................................................... 9
4.3 Vehicle lap and shoulder belts with a free sliding latch plate.................... 11
4.4 Vehicle seat back and headrest adjustment............................................. 13
5. Toddler use mode WITH protection shield for children
from 22 to 40 lb (10 to 18 kg) and up to 43 in. (109 cm)....... 14
5.1 Adjustments for toddlers............................................................................ 14
5.1.1 Adjusting the seat cushion height.............................................................. 14
5.1.2 Adjusting the headrest height.................................................................... 16
5.2 Toddler use mode installation.................................................................... 17
5.2.1 Installation using the LATCH system and top tether.................................. 17
5.2.2 Installation usingthevehicle'slap and shoulder belt andtop tether............... 23
5.2.3 Installation using the vehicle's lap belt and top tether............................... 27
6. Booster use mode WITHOUT protection shield from 40 to
110 lb (18 to 50 kg) and up to 57 in (145 cm).......................... 31
6.1 Installation using the vehicle's shoulder and lap belt................................ 31
7. Storing LATCH, the assembly of top tether and removing
the protection shield................................................................ 36
7.1 Storing LATCH connectors........................................................................ 36
7.2 Storing top tether........................................................................................ 36
7.3 Removal and assembly of protection shield.............................................. 37
7.3.1 Removing the protection shield................................................................. 37
7.3.2 Assembling the protection shield............................................................... 37
8. Certification and use on aircraft.............................................. 38
9. Removing and replacing the covers........................................ 38
9.1 Removing the headrest cover.................................................................... 38
9.2 Removing the backrest cover.................................................................... 39
9.3 Removing the seat cover........................................................................... 39
9.4 Protection shield cover............................................................................... 39
9.5 Replacing the covers................................................................................. 39
10. Instructions for care and cleaning.......................................... 39
10.1 Washing the covers.................................................................................... 39
10.2 Cleaning plastic parts................................................................................. 40
11. Warranty..................................................................................... 40
12. Product registration.................................................................. 42
‘kiddy world plus‘ – Operating Manual
1. Introduction
We’re delighted that you have chosen the ‘kiddy world plus’ car seat as your
preferred car seat.
The ‘kiddy world plus’ car seat is the latest innovative product in our car seat
line. Our special energy-absorbing protection shield offers the greatest
possible safety in the event of frontal or side impact crash. You can use your
“kiddy world plus” car seat with the protection shield for toddlers and children
at least one year of age and weighing 22 - 40 lbs (10 to 18 kg) and whose
height is 43 in. (109 cm) or less. For children weighing 40 to 110 lbs (18 to
50 kg) and whose height is 57 in. (145 cm) or less your ‘kiddy world plus’ car
seat is used without the protection shield as a booster car seat and is
secured with a vehicle shoulder and lap belt.
To provide the optimum protection for your child, the ‘kiddy world plus’ car
seat must be used exactly as described in this instruction manual.
2. Recommended use
The ‘kiddy world plus’ has been tested and certified to FMVSS 213 for use
with children over one year of age, capable of sitting upright alone and who
weigh between from 22 to 110 lbs (10 to 50 kg) and whose height is 57 in.
(145 cm) or less.
2.1 Toddler Car Seat Use (WITH protection shield)
WARNING
!
• Children must be at least one year of age and able to sit upright
unassisted to use this car seat.
• Protection shield must be used with children 22 to 40 lbs (10 to 18kg).
• Seat cushion must be used with children 22 to 30 lbs (10 to 13.6 kg).
• Discontinue use of the protection shield when child exceeds either
40 lbs (13.6 kg) or height of 43 in. (109 cm).
DEATH or SERIOUS INJURY can occur
3
Children must meet all of the following
criteria to use the Toddler car seat WITH
the protection shield:
• Age - At least one year of age and
• Able to sit upright alone (unassisted) and
• Weight – 22 to 40 lbs (10 to 13.6 kg) and
• Height 43 in. (109 cm) or less
The American Academy of Pediatics (AAP) and
kiddy USA recommend keeping a child in a
Toddler car seat as long as possible before
changing to a booster car seat. Use the toddler
car seat until the childs weight exceeds 40 lbs (13.6 kg) or height exceeds
43 inches (109 cm) before to the booster car seat mode.
2.2 Booster CarSeat Use(WITHOUT protectionshield)
WARNING
!
• Child must weigh at least 40 lbs (18 kg) and 40 in. (102 cm) to use
booster car seat mode.
• Do not use protection shield with children over 40 lbs (18 kg).
• Discontinue use of car seat when
- The child exceeds either 110 lbs (50 kg) or 57 in. (145 cm)
- The top of the child’s ears are above the top of the seat back.
Children must meet all of the following criteria to
use the Booster car seat WITHOUT
shield:
• Weight - 40 to 110 lbs (18 to 50 kg) and
• Height – 40 to 57 in. (102 to 145 cm) and
• Top of ears must be below top of seat back.
The American Academy of Pediatics (AAP) and
kiddy USA recommend keeping a child in a
booster car seat as long as possible before
changing to vehicle seat belts. Use the boostercar
seat until the childs weight exceeds 110 lbs (50 kg)
or height exceeds 57 inches (145 cm) before using
a vehicle seat belt.
DEATH or SERIOUS INJURY can occur
the protection
4
3. General safety Warnings
WARNING
!
• Failure to follow the instructions and labels can result in serious injury or
death from ejection or contacting the vehicle interior. Read and follow
the information provided in this instruction manual and on the product
labels before using this car seat.
• Children must be at least one year of age, able to sit upright unassisted
and over 22 lbs (10 kg) to use this car seat.
Toddler car seat use (WITH
• Children weighing 22 to 40 lbs (10 to 18 kg) and whose height is 43 in.
(109 cm) or less must use Toddler car seat mode WITH
• Children 22 to 30 lbs (10 to 13.6 kg) must use Toddler car seat mode
WITH protection shield and seat cushion. Seat cushion must be used
and adjusted properly.
• Snugly adjust the LATCH lower anchor belt or vehicle seat belt around
the protection shield. The LATCH belt or vehicle seat belt must stay
snugly adjusted around the protection shield.
• Secure this car seat with the top tether whenever possible.
• The top tether hook must only be attached to a vehicle tether anchor
provided by the vehicle manufacturer.
• Always check the vehicle owner’s manual how to secure and use a car
seat and the seat belts in your vehicle.
Booster car seat use (WITHOUT
• Children 40 to 110 lbs (18 to 50 kg) must use the booster car seat mode
WITHOUT protection shield.
• Discontinue use of this car seat when child’s weight exceeds 110 lbs
(50 kg), height exceeds 57 in. (145 cm) or top of ears are above top of
seat back.
• Secure the child in this booster car seat with only a vehicle lap and
shoulder belt.
• Never use a only a vehicle lap belt to secure a child in this booster car
seat.
• Do not use the top tether to secure this car seat when using in the
booster mode.
DEATH or SERIOUS INJURY can occur
protection shield):
protection shield.
protection shield):
5
WARNING
!
• To prevent ejection or injury in a crash, proper adjustment and use
is required.
- Check to make sure the car seat is properly adjusted to the size of your
child prior to travel. Do not attempt to make adjustments during travel.
- Make sure that all parts of the car seat are properly locked in place.
- Make sure that the car seat has been securely installed in the vehicle
according to this instruction manual and all car seat installation
instructions provided in your vehicle owner’s manual.
- Use only the vehicle belt routing described in this instruction manual
and on the car seat labels to secure the child and car seat.
- Only use the vehicle’s seat belt or the LATCH system and top tether to
secure this car seat as described in this instruction manual.
• Only adjustment the car seat as recommended in this instruction manual.
• Use this car seat system forward-facing only.
- The underside of the car seat must contact the vehicle seat. Do not
place anything (e.g. cushions) under the car seat.
• Never leave a child unattended in the car seat.
• If you need assistance with installation, please contact kiddy USA
Consumer Services at 1-855-92-KIDDY or consult your vehicle dealer.
• Prevent burns. Keep the car seat out of direct sunlight to prevent heating
of car seat surfaces.
• Allow your child to take breaks during longer trips, and be sure that she /
he does not step out of the vehicle into oncoming traffic.
• The top tether hook must only be attached to a tether anchoring point
provided by the vehicle manufacturer.
• The vehicle seat back must be in the upright position or adjustment
position recommended by the vehicle manufacturer and vehicle seat
back must be locked in position (Seat backs such as found in vehicles
with fold-down backrests, through-loading openings etc.).
• Only transport a child when properly secured in the car seat. Never
transport parcels or other objects in this car seat.
• Improper handling during installation or removal can cause damage to
your vehicle (e.g. paint damage or tears in the seat covers etc.) as
well as to the car seat.
DEATH or SERIOUS INJURY can occur
6
WARNING
!
• Vehicle Seat covers made from materials such as velour, leather etc.
may show wear marks after using your car seat.
• Do not use any accessories or parts supplied by other manufacturers.
• Do not make any modifications to the car seat or parts; doing so will
reduce its effectiveness in a crash.
• Never use this car seat without the seat cover. Only use a seat cover
provided by the manufacturer as it is an integral part of the car seat and
certification.
• Always secure this car seat with the LATCH System or a vehicle belt and
top tether belt even when unoccupied. An unsecured car seat can injure
other occupants in a sudden stop or crash.
• Do not place any heavy items on the rear window shelf; these can
become dangerous projectiles in an sudden stop or crash.
• Do not use the car seat if used in a crash where speed exceeded
10 mph. Car seat must be returned to kiddy USA Inc. for inspection
and replacement if necessary.
Contact kiddy US Consumer Services at 1-855-92-KIDDY or log on to
www.kiddyusa.com.
• Discontinue use of this car seat after 8 years from the manufacture
date noted on the label on the bottom of the product.
• You must register your car seat to be reached in the event of a product
recall or safety notice. Please take the time to fill out the registration card
and register today. You could also register your product online:
http://kiddyusa.com/registration_carseat.html
• Always use the child safety locks in your vehicles passenger doors, if
available.
• Make sure that none of the car seat's parts are caught in doors or
reclining seats.
DEATH or SERIOUS INJURY can occur
7
4. Vehicle seating position and adjustment
WARNING
!
• Do not use this car seat in a vehicle front seating location unless
specifically recommended by the vehicle manufacturer in the vehicle
owner's manual.
• Always read the vehicle owner’s manual on how to use and secure car in
the vehicle or contact your dealer to make sure that you follow the
instructions of the vehicle’s manufacturer.
• Some vehicles have no seating positions which are compatible with this
car seat or any other car seat. If in doubt, contact the vehicle
manufacturer for assistance.
• Some types of vehicle seat belts will not stay tightly secured around a
car seat and as a result are NOT compatible with this car seat.
DEATH or SERIOUS INJURY can occur
4.1 Vehicle seat location requirements
According to accident statistics, children 12 and under are safer when
properly restrained in the rear seating positions than in the front seating
positions. The vehicle’s back seat is the safest place for children. Use a
vehicle rear seating position whenever possible.
Use a vehicle seating location equipped with the LATCH anchorage system
or a vehicle seat belt that can be tightly secured around this car seat. Always
use a top tether anchor if available. For information on vehicle seating
locations equipped with LATCH that can be used with car seats and top
tether anchor locations, see the vehicle owner’s manual.
Never install a car seat in a vehicle front seating location unless specifically
recommended in the vehicle owner’s manual.
For vehicles with air bags, refer to the vehicle owner’s manual for car seat
installation and use information. Never place a car seat in a seating
location with an air bag unless recommended in the vehicle owner’s manual
and all instructions are followed.
8
In vans and minivans it is particularly important to ensure that the car seat
installed in an easily accessible seat in the event that third-party rescue is
required.
For use in a motor vehicle, please follow the
manufacturer’s recommendations in the
vehicle manual, or contact your vehicle dealer.
Please familiarize yourself thoroughly with the
recommended use of car seats as described in
your vehicle owner’s manual.
This car seat MUST be used only with forwardfacing vehicle seats. Do not use this car seat
with vehicle seats that face the side or rear of
the vehicle (Fig. 1).
Fig. 1
4.2 Vehicle seat belts
Many vehicle seat belt systems are not safe to use with a car seat. The
vehicle seat belt must be designed to hold a car seat tightly and stay tightly
adjusted at all the times. Do not use a vehicle seat belt that changes length
while driving.
Vehicle seat belts with top or bottom
anchor points on the vehicle door (Fig. 2)
Fig. 2
9
Fig. 3
Fig. 4
Motorized, automatic vehicle seat belts
(Fig. 3.)
Lap-and shoulder belts that have a
separate retractors for the lap section and
shoulder section (Fig. 4)
Vehicle Lap belts that have a retractor that
locks only in case of a sudden stop
(emergency locking retractor or ELR)
(Fig. 5)
Fig. 5
10
Vehicle Lap belts forward of the vehicle
seat bight (intersection of the vehicle seat
back and vehicle seat cushion) (Fig. 6)
Fig. 6
4.3Vehiclelapandshoulderbeltswithafreeslidinglatchplate
Vehicle lap and shoulder belts with a free sliding latch plate may be used in
with both the Toddler Car Seat and Booster Car Seat.
For use with Toddler Car Seat
This type of lap and shoulder belt may be used to secure the Toddler Car
Seat if the lap portion of the vehicle seat belt can be tightened to be snugly
adjusted around the protection shield and will stay snugly adjusted while
traveling. Two types of lap and shoulder belt systems with a free sliding latch
plate shown below are common in vehicles and require specific steps to use
to secure the protection shield and the child. Check your vehicle owner’s
manual for the type of lap and shoulder belt system in the vehicle.
Lap and shoulder belt with Emergency Locking Retractor (ELR) on the
shoulder belt.
A shoulder belt with an ELR only locks the belt in a sudden stop or crash.
The shoulder belt can be extended and retracted all the way without locking.
A shoulder belt with ELR requires installation of a locking clip to lock the belt
so that is stays snugly adjsusted around the Toddler Car Seat. See the
information in the “locking Clip Installation and Use” section on how to install
and tighten the locking clip.
11
For use with Toddler Car Seat
- This type of lap and shoulder belt may be used with the Booster Car Seat
to secure the child.
- Always read and follow the information provided in the vehicle owner’s
manual for the use, positioning and adjustment of the vehicle seat belt.
Locking Clip Installation and use
You MUST use locking clip provided with this car seat with a vehicle belt that
slides freely through the latch plate or if the lap portion of the lap/shoulder
belt can not be tightly secured.
WARNING
!
Avoid serious injury or death:
• Failure to use locking clip where required will result in car seat not
being securely held in place.
• Remove locking clip from vehicle seat belts when not being used
with car seat.
• DO NOT use locking clip as a vehicle seat belt shortener.
Fig. 7
DEATH or SERIOUS INJURY can occur
• Install car seat forward-facing on vehicle seat, route
the lap belt around the protection shield and snuggly
adjust the vehicle lap belt around the protection shield
and child.
• While holding vehicle lap and shoulder belts together
at the latch plate (Fig. 7), unbuckle vehicle belt.
12
• Slide locking clip onto vehicle seat belts
approximately 1/2 inch (1 cm) away from latch plate
(Fig. 8).
• Re-buckle vehicle seat belt.
- Check to be sure vehicle lap belt is still correctly
routed throughout entire belt path.
Fig. 8
- Check to see that the protection shield is snuggly
adjusted onto child.
-If not snuggly adjusted, readjusting the vehicle seat
belt tightening is required.
- Unbuckle vehicle seat belt.
- Hold vehicle seat belts together and remove locking
clip.
- Readjust the lap belt.
- Re-attach locking clip.
- Buckle vehicle seat belt.
- Test installation to see if protection shield is snuggly
adjusted, if not snugly adjusted, repeat above steps
until protection shield is snugly adjusted.
• Check that the protection shield is snuggly adjusted
onto the child’s torso each time the child is secured
into the Todder car Seat.
4.4 Vehicle seat back and headrest adjustment
- Place the car seat on the vehicle seat,
center the car seat in the seating position
so that car seat back contacts the vehicle
seat back.
- The backrest of your car seat should sit
right up against the vehicle’s seat back.
- If the vehicle headrest holds the car seat
forward of the vehicle seat back, the
Fig. 9
headrest should be removed (car seat
forward of vehicle seat back) (Fig. 9).
13
Loading...
