Manual P/N 820-1536 Rev. B 10/12
ATTENTION: Please take a few minutes to thoroughly read this
user’s guide, which should be saved for future reference and
passed on to any subsequent owner.
Smoke Alarm
User’s Guide
900-0252
With Rechargeable Battery Backup
KN-SMFM-i-CA
with Smart Hush
™
S
INGLE AND/OR MULTIPLE
STATION SMOKE ALARM
Smoke Alarm Procedure
NEVER IGNORE THE SOUND OF THE ALARM!
Smoke alarms are designed to minimize false alarms. Cigarette
smoke will not normally set off the alarm, unless the smoke is
blown directly into the alarm. Combustion particles from cooking
may set off the alarm if it is located too close to the cooking area.
Large quantities of combustion particles are generated from spills or
when broiling. Using the fan on a range hood which vents to the
outside (non-recirculating type) will also help remove these
combustion particles from the kitchen.
If the alarm sounds, check for fires first. If a fire is discovered,
follow these steps. Become thoroughly familiar with these steps
and review with all family members:
• Alert small children in the home.
• Leave immediately by your escape plan. Every second counts, so
don’t waste time getting dressed or picking up valuables.
• In leaving, don’t open any inside door without first feeling its
surface. If hot, or if you see smoke seeping through cracks, don’t
open that door! Instead, use your alternate exit. If the inside of
the door is cool, place your shoulder against it, open it slightly
and be ready to slam it shut if heat and smoke rush in.
• If the air is smoky, stay close to the floor. Breathe shallowly
through a cloth, wet if possible.
• Once outside, go to your selected meeting place and make sure
everyone is there.
• Call the fire department from your neighbor’s home – not from yours!
• Don’t return to your home until the fire officials say that it is all
right to do so.
What to do When the Alarm Sounds!
Welcome
AC Wire-in Single and/or Multiple Station Ionization Smoke Alarm
with Smart HUSH
™
Control to temporarily silence nuisance alarms.
Model K-SMFM-i-CA has a Rechargeable Backup Battery That
Does Not Need To Be Replaced for the Life of The Alarm.
Thank you for purchasing this smoke alarm. It is an important part of
your family’s home safety plan. You can trust this product to provide the
highest quality safety protection. We know you expect nothing less
when the lives of your family are at stake. Kidde alarms and accessories
CAN ONLY BE interconnected with other Kidde alarms and accessories as
well as specified brands and models of interconnect compatible alarms.
Connection of Kidde products to a non-specified manufacturer’s
interconnect system, or connection with non-specified equipment from
another manufacturer into an existing Kidde system could result in
nuisance alarming, failure to alarm, or damage to one or all of the
devices in the interconnect system. Refer to the User’s Guide supplied
with each Kidde product for interconnect compatible models, brands,
and devices. Refer to the wiring instructions in section 3 for NFPA
initiating device limits.
Important Warning Statements
LOSS OF POWER (AC AND BATTERY BACKUP) TO THE ALARM
WILL RENDER THIS ALARM INOPERATIVE.
IMPORTANT! Read all instructions before installation and keep
this manual near the alarm for future reference.
This Smoke alarm requires a continuous supply of electrical
power – it will not work without power. Models without battery
backup will not operate during power failure.
Contents of This User’s Guide
1. Recommended Locations for Smoke Alarms
2. Locations to avoid
3. Installation Instructions
4. Operation and testing
5. Nuisance Alarms
6. Maintenance
7. Limitations of Smoke Alarms
8. Good Safety Habits
9. NRC Information
10. NFPA Protection Standard 72
11. Limited Warranty
This alarm detects products of combustion using the ionization
technique. It contains 0.9 microcurie of Americium 241, a radioactive
material (see section 9). Distributed under U.S. NRC License No.
32-23858-01E. Manufactured in compliance with U.S. NRC safety
criteria in 10 CFR 32.27. The purchaser is exempt from any regulatory
requirements. Do not try to repair the smoke alarm yourself. Refer to the
instructions in section 11 for service.
Smoke alarms are devices that can provide early warning of possible fires
at a reasonable cost; however, alarms have sensing limitations. Ionization
sensing alarms may detect invisible fire particles (associated with fast
flaming fires) sooner than photoelectric alarms. Photoelectric sensing
alarms may detect visible fire particles (associated with slow smoldering
fires) sooner than ionization alarms. Home fires develop in different ways
and are often unpredictable. For maximum protection, Kidde
recommends that both Ionization and Photoelectric alarms be installed.
LOSS OF POWER (AC AND BATTERY BACKUP) TO THE ALARM
WILL RENDER THIS ALARM INOPERATIVE.
ELECTRICAL RATING: 120 VAC, 60HZ, 30mA maximum per alarm
(maximum 30mA for originating unit with 24 devices interconnected. The
interconnect system should not exceed the NFPA interconnect limit of
12 smoke alarms and/or 18 alarms total (smoke, heat, carbon monoxide,
or similar alarms).
Product Specifications
• Locate the first alarm in the immediate area of the bedrooms. Try to
monitor the exit path as the bedrooms are usually farthest from the
exit. If more than one sleeping area exists, locate additional alarms in
each sleeping area (See Image 1A and 1B).
• Locate additional alarms to monitor any stairway as stairways act like
chimneys for smoke and heat.
• Locate at least one alarm on every floor level.
• Locate an alarm in every bedroom.
• Locate an alarm in every room where electrical appliances are
operated (i.e. portable heaters or humidifiers).
• Locate an alarm in every room where someone sleeps with the door
closed. The closed door may prevent an alarm not located in that
room from waking the sleeper.
• Smoke, heat, and combustion products rise to the ceiling and spread
horizontally. Mounting the smoke alarm on the ceiling in the center of
the room places it closest to all points in the room. Ceiling mounting
is preferred in ordinary residential construction.
• When mounting an alarm on the ceiling, locate it at a minimum of 10
cm (4”) from the side wall (see Image 2A).
• When mounting the alarm on the wall, use an inside wall with the top
edge of the alarm at a minimum of 10 cm (4”) and a maximum of
30.5 cm (12”) below the ceiling (see Image 2A).
• Put smoke alarms at both ends of a bedroom hallway or large room if
the hallway or room is more than 9.1 m (30 ft) long.
1. Recommended Locations for Smoke Alarms
DINING
ROOM
LIVING
ROOM
Required Smoke Alarms
Ionization Type Smoke Alarm with
Hush
®
Control or Photoelectric Type
Smoke Alarms for Additional Protection
KITCHEN BEDROOM
BEDROOM
BEDROOM
LIVING
ROOM
KITCHEN
BEDROOMBEDROOM HALL
BASEMENT
IMAGE 1A IMAGE 1B
SINGLE FLOOR PLAN MULTIPLE FLOOR PLAN
1. Recommended Locations for Smoke Alarms
IMAGE 2A
IMAGE 2C
IMAGE 2B
HORIZONTAL DISTANCE FROM PEAK
CEILING
10 cm (4”)
MINIMUM
10 cm (4”)
MINIMUM
30.5 cm (12”)
MAXIMUM
SIDE WALL
BEST
PLACEMENT
ACCEPTABLE
PLACEMENT
NEVER HERE
STA
G
N
A
N
T
A
I
R
0.9 m (3’) 0.9 m (3’)
NOT IN
THIS AREA
ANYWHERE IN THIS
AREA
NOT IN
THIS AREA
ANYWHERE IN
THIS AREA
0.9 m (3’)
