FieldFox Handheld Analyzers
4/6.5/9/14/18/26.5/32/44/50 GHz
This configuration guide describes configurations, options and
accessories for the FieldFox family of portable analyzers. This guide
should be used in conjunction with the technical overview and data
sheet for a complete description of the analyzers. The table on Page 3
titled “FieldFox Family and Options” shows a comparison of the
functions available in the FieldFox family of analyzers.
Note: Combination analyzer (combo) = Cable and antenna tester
(CAT) + Vector network analyzer (VNA) + Spectrum analyzer (SA)
Included accessories
The following accessories
are included with every
FieldFox:
AC/DC adapter
•
Battery
•
Soft carrying case
•
LAN cable
•
Quick Reference Guide
•
Find us at www.keysight.com Page 1
Table of Contents
FieldFox Family and Options ................................................................................................................. 3
FieldFox RF and Microwave (Combination) Analyzers ............................................................................ 4
FieldFox RF and Microwave (Combination) Analyzer FAQs ................................................................... 6
ERTA System Typical Configuration ...................................................................................................... 10
FAQs – Applicable To All FieldFox RF and Microwave Analyzers ...................................................... 11
FieldFox Microwave Vector Network Analyzers ...................................................................................... 13
FieldFox Microwave Vector Network Analyzer FAQs .............................................................................. 14
FieldFox Microwave Spectrum Analyzers ............................................................................................... 15
FieldFox Spectrum Analyzer FAQs ........................................................................................................ 16
Upgrades............................................................................................................................................... 17
Documentation ...................................................................................................................................... 19
Calibration Kits ...................................................................................................................................... 20
Accessories ........................................................................................................................................... 22
Find us at www.keysight.com Page 2
FieldFox Family and Options
Vector Netwo rk
N992xA
Spect ru m
N993xA , N 996xA
112
QuickCal
√ on N991xA
√
—
211
VNA full 2-port S-parameters
√ √ —
320
Reflection meas. (RL, VSWR and scalar meas.)
— 3
— 3
√
Spectrum analysis
220
Tracking generator
— 4 — √
236
Interference analyzer and spectrogram
√ — √
312
Channel scanner
√ — √
355
Analog demodulation
√ — √
358
EMF measurements
√ (Not on N9912A)
—
√
377
Over-the-Air (OTA) 5GTF
√ (Not on N9912A)
—
√
Option
Description
Combination Analyzers
N991xA , N 995xA
Analyzers
CAT/vector network analysis
010 VNA time domain √ √ —
(Not on N995xA)
210 VNA transmission/reflection √ Base model 1 —
212 1-port mixed-mode S-parameters √ √ —
215 TDR cable measurements √ √ —
305 Cable and antenna analyzer Base model 1 √ — 2
308 Vector voltmeter √ √ —
209 Extended range transmission analysis (ERTA) √ — √
233 Spectrum analyzer √ — Base model 1
235 Pre-amplifier √ — √
Analyzers
238 Spectrum analyzer time gating √ — √
350 Real-time spectrum analyzer (RTSA) √ (Not on N9912A) — √
351 I/Q Analyzer (IQA) √ (Not on N9912A) — √
352 Indoor and outdoor mapping √ (Not on N9912A) — √
356 Noise figure (NF) √ (Not on N9912A) — √
360 Phased array antenna support √ (N995xA only) — √ (N996xA only)
370 Over-the-Air (OTA) LTE FDD √ (Not on N9912A) — √
1
Base model means that the functionality listed is the primary function of that instrument. For example, on the N991xA or N995xA combo
analyzers, cable and antenna analysis is the standard function included with every N991xA or N995xA.
2
Option 305 is not available on the N993xA or N996xA. However, a subset of cable and antenna analyzer measurements, return loss
and VSWR, is available as Option 320.
3
Option 320 is not applicable to N991xA, N995xA, or N992xA. The reflection measurements of return loss and VSWR are included with every
N991xA, N995xA, and N992xA. So, there is no need for an Option 320 on these analyzers.
4
On the N991xA or N995xA analyzers, order Options 233 and 210 to obtain a tracking generator with the spectrum analyzer. Option 220
is not available on the N 991xA or N995xA analyzers. Option 233 provides the spectrum analyzer capability and Option 210 the “tracking”
capability.
Find us at www.keysight.com Page 3
Option
Vector Netwo rk
N992xA
Spect ru m
Power measurements
302
USB power sensor support
√ √ √
System features
030
Remote control capability
√ √ √
307
GPS receiver √ √
√
309
DC bias variable-voltage source
√ √ √
Windows based software
89601B
PathWave VSA (89600 VSA) software
√ (Not on N9912A)
—
√
N6820ES
Surveyor 4D soft w are
√ (Not on N9912A)
—
√
CAT and VNA
Description
208 USB power sensor meas. versus frequency √ √ √
310 Built-in power meter √ √ √
330 Pulse meas. with USB peak power sensor √ √ √
— Frequency extender support 1 √ (Not on N9912A) — √
Combination Analyzers
N991xA , N 995xA
Analyzers
Analyzers
N993xA , N 996xA
FieldFox RF and Microwave (Combination) Analyzers
Analyzer models
Step 1. Select the model that provides the desired frequency range.
Model Description
N9913A 4 GHz FieldFox RF analyzer 30 kHz to 4 GHz 100 kHz to 4 GHz Type-N (f)
N9914A 6.5 GHz FieldFox RF analyzer 30 kHz to 6.5 GHz 100 kHz to 6.5 GHz Type-N (f)
N9915A 9 GHz FieldFox microwave analyzer 30 kHz to 9 GHz 100 kHz to 9 GHz Type-N (f)
N9916A 14 GHz FieldFox microwave analyzer 30 kHz to 14 GHz 100 kHz to 14 GHz Type-N (f)
N9917A 18 GHz FieldFox microwave analyzer 30 kHz to 18 GHz 100 kHz to 18 GHz Type-N (f)
N9918A 26.5 GHz FieldFox microwave analyzer 30 kHz to 26.5 GHz 100 kHz to 26.5 GHz 3.5 mm (m)
N9950A 32 GHz FieldFox microwave analyzer 300 kHz to 32 GHz 9 kHz to 32 GHz NMD 2.4 mm (m)
N9951A 44 GHz FieldFox microwave analyzer 300 kHz to 44 GHz 9 kHz to 44 GHz NMD 2.4 mm (m)
N9952A 50 GHz FieldFox microwave analyzer 300 kHz to 50 GHz 9 kHz to 50 GHz NMD 2.4 mm (m)
frequency
SA frequency 2 Test port connectors
1
Frequency extenders are not currently supporte d on models N9913A, N9914A and N9915/35A si nce the starting LO frequency of
these mixers is higher than 9 GHz and the LO is provide d to the mixer from FieldFox Port 1. For a list of supported OML frequency
extenders, see Accessories p age 23.
2
Useable to 5 kHz.
Find us at www.keysight.com Page 4
Analyzer options
010
VNA time domain
Requires 210, recommend 211. See page 7, FAQ #7
210
VNA transmission/reflection
Recommend ordering a cal kit. See page 6, FAQ #4 and page 7,
212
1-port mixed-mode S-parameters
Requires 210 and 211
215
TDR cable measurements
—
Spectrum analysis
235
Pre-amplifier
Requires 233
350
Real-time spectrum analyzer (RTSA) 1
Requires 233, Recommend 235. See page 8, FAQ #12
Requires 233, 307, and at least one of 312, 360, 370 or 377. See
355
Analog demodulation
Requires 233
358
EMF measurements
Requires 233. Also requires triaxial antenna. See page 9, FAQ #18
360
Phased array antenna support
Requires 233. See page 9, FAQ #16
370
Over-the-Air (OTA) LTE FDD 1
Requires 233, 307. Recommend 235.
302
USB power sensor support
Need to order USB power sensor 2
310
Built-in power meter
No power sensor required. See page 11, FAQ #1
Need to order USB peak power sensor. See page 12, FAQs #7 and
Step 2. Select optional measurement capabilities.
Any of these options can easily be added as a software upgrade in the future. Exception: Option 112 is only applicable to N991xA models. It is not applicable to N995xA models.
Option Description Prerequisite options/notes
CAT/vector network analysis
112 QuickCal Not available for N995xA models. See page 7, FAQ #9
211 VNA full 2-port S-parameters Requires 210, recommend ordering a cal kit. See page 6, FAQ #5
308 Vector voltmeter 210 and 211 required to obtain full VVM functionality. See page 7,
FAQ #6
FAQ #8
209 Extended range transmission analysis (ERTA)
Requires 233 and 210. Recommend 307. Requires two FieldFox
units. See page 8, FAQ # 10. See page 10 for typical configuration.
233 Spectrum analyzer —
236 Interference analyzer and spectrogram Requires 233
238 Spectrum analyzer time gating Requires 233
312 Channel scanner Requires 233
351 I/Q Analyzer (IQA) 1 Requires 233
352 Indoor and outdoor mapping
page 9, FAQ #17
Requires 233, 235, 309 and accessory item N9910X-713 BNC to
356 Noise Figure (NF) 1
SMB cable. See page 9, FAQ #15 for external preamplifier and noise
source requirements.
377 Over-the-Air (OTA) 5GTF 1 Requires 233, 307. Recommend 235. See page 9, FAQ #19
Power measurements
208 USB power sensor meas. versus frequency Requires 302
330 Pulse meas. with USB peak power sensor
1
Requires CPU2 fast processor. See page 9, FAQ #13.
2
List of compatible sensors available from www.keysight.com/find/fieldfoxsupport.
Find us at www.keysight.com Page 5
#8
Option
Description
Prerequisite options/notes
System features
030 Remote control capability Requires an iOS device
307
GPS receiver
Need to order GPS antenna, N9910X-825. See page 12, FAQ #3
309
DC bias variable-voltage source
Recommend N9910X-713 cable, see page 12, FAQ #4
Windows based software
Note: 2-port insertion loss is NOT included with the base model, if 2-port insertion loss is needed,
2. What is included with
3. What is included with
4. What is included with
Adds tracking mode to the tracking generator/independent source included with Option 233,
— Frequency extender support
Requires 233. Optional 350, 351, 360, 370, 377, PathWave VSA
software. See Accessories, page 23
89601B PathWave VSA (89600 VSA) software Requires 233 and CPU2 processor. See page 9, FAQ #13
N6820ES Surveyor 4D software 1 Requires 233, 235 and 307, see page 10, FAQ #20
FieldFox RF and Microwave (Combination) Analyzer FAQs
Question Answer
1. What is included with a base
N991xA/N995xA analyzer?
N991xA/N995xA Option 233?
N991xA/N995xA Option 236?
N991xA/N995xA Option 210?
The base model includes the cable and antenna analyzer
Measurements: DTF (dB, linear, VSWR), return loss and DTF, return loss (dB), and 1-port cable loss
Calibrations: CalReady, OSL, and response cal
order Option 210
Note: Base analyzer does not have phase information, for S11 or S21 phase, order Option 210
Basic spectrum analysis, four traces, different detector types, radio standar d selection, limit lines
Channel power, occupied bandwidth, adjacent channel power, spectrum emission mask
AM/FM tune and listen, field strength measurem ents, antenna factors, frequency count er marker
Tracking generator (TG)/Independent source:
- TG CW mode (source CW frequency can be set independent of SA frequency) - included
- TG CW coupled mode (source CW frequency is auto coupled to SA’s center frequency) -
included
- TG tracking mode (traditional TG operation, swept SA coupled to swept source) - (requires
Option 210)
Interference analyzer and spectrogram
Trace playback and recor ding
Option 210 adds a VNA with transmission/reflection (T/R) capability
Measurements: S21, S11, magnitude and phase
Additionally, in the CAT mode, you can measure 2-port insertion loss
Calibrations: CalReady, OSL, response, and enhanced response cal
If you need all four S-parameters, order Options 210 and 211
If you need 2-port cal, order Options 210 and 211
spectrum analyzer
5. What is included with
N991xA/N995xA Option 211?
Option 211 adds full 2-port S-parameter capability to the VNA mode
Measurements: All four S-parameters (S11, S21, S22, S12), magnitude and phase
Calibrations: CalReady, OSL, response, enhanced response, and full 2-port cal
1
Requires CPU2 fast processor. See page 9, FAQ #13.
Find us at www.keysight.com Page 6
Question Answer
6. Can I measure group delay on
N991xA/ N995xA analyzers?
7. What is included with
N991xA/N995xA Option 010?
8. What is included with
N991xA/N995xA Option 308?
9. What is included with N991xA
Option 112?
If you have phase measurem ent capability, then you can measure group delay. Option 210 is
required for any phase measurement capability. So, if you do not have Option 210, you cannot
measure group delay.
S11/S21 in time domain, if Option 210 is ordered. To get time domain data for all four S-parameters
and full 2-port cal, order Option 211.
View both time and frequency domain data at the same time
Low-pass, impulse, and band-pass modes
Minimum, medium, and maximum window
Gating
With Option 308: 1-port cable trimming
With Options 308 and 210: 1-port cable trimming, 2-port transmission
With Options 308, 210, and 211: 1-port cable trimming, 2-port transmission, A/B and B/A
Note: A/B and B/A measurements require an external source
Option 112 (QuickCal), is not available for N995xA analyzers. It is available for N991xA analyzers.
QuickCal is included with Option 112.
- 1-port QuickCal with a base analyzer
- 1-port and enhanced response QuickCal with a T/R analyzer (one that has Option 210)
- 1-port, enhanced response, and 2-port QuickCal with a full 2-port analyzer (one that has Option
211)
QuickCal is most accurate for DUTs with 7/16 and Type-N connectors and measurement
uncertainties are provided for frequencies ≤ 18 GHz. Reduced accuracy for DUTs with 3.5 mm (m),
SMA (m), or other male coaxial connectors; performance is unspecified. QuickCal is not
recommended for DUTs with 3.5 mm (f), SMA (f), or other similar female connectors. QuickCal is not
applicable to waveguide.
Find us at www.keysight.com Page 7
Question Answer
10. What are the requirements for
Extended Range Transmission Analysis (ERTA) or Option 209 is a scalar measur ement system
E. LAN connection – For ERTA, the two FieldFox units communicate via a LAN connection. For a
Recommended accessory
11. What is included with Option
FieldFox analog demodulation has two parts: (1) Tune and listen, and (2) AM/FM metrics. Tune and
Option 209?
based on the use of two (2) FieldFox units. One FieldFox acts as the source and reference receiver,
while the second FieldFox acts as the measurement receiver. When different frequency models are
used in an ERTA pair, the ERTA system frequency range is limited to the lowest of the pair.
Required hardware
A. Two (2) FieldFox units. FieldFox units can be any of these models:
- FieldFox microwave combination analyzers: N9913A, N9914A, N9915A, N9916A, N9917A,
N9918A, N9950A, N9951A, N9952A
- FieldFox microwave spectrum analyzers: N9935A, N9936A, N9937A, N9938A, N9960A,
N9961A, N9962A
- ERTA cannot use N9912A, N9923A, N9925A, N9926A, N9927A or N9928A
The two FieldFox units used in ERTA do not have to be the same model.
ERTA requires the following options on Combo FieldFox models (N9913A, N9914A, N9915A,
N9916A, N9917A, N9918A, N9950A, N9951A, N9952A):
- Option 210, VNA transmission/reflection
- Option 233, spectrum analyzer
ERTA requires the following options on SA FieldFox models (N9935A, N9936A, N9937A, N9938A,
N9960A, N9961A, N9962A)
- Option 220, tracking generator
Both FieldFox units (the one used as the source, and the other used as the receiver) must have the
options listed above. The ERTA option (209) cannot be installed unless 210 and 233 are present on a
combo analyzer; or 220 is present on a SA analyzer.
With either the Combo or SA FieldFox units, the following options are highly recommended:
- Option 235, preamplifier – this option increases the measurement dynamic range by increasing
the received signal power
- Option 307, GPS receiver – this option increases the dynamic range by increasing the frequency
accuracy and permitting the use of a narrower RBW
B. Power splitter, two-resistor model, Keysight 11667A, 11667B, or 11667C. Other power splitters
can be used but the specifications listed are based on the match and tracking performance of
11667A, 11667B, or 11667C. Three-resistor pow er splitters are not recommended.
C. N9910X-712, Trigger/Reference-in cable, SMA (m) to BNC(f), 1 m, quantity two
D. N9910X-713, Trigger/Reference-out cable, SMB (m) to BNC (m), 1 m, quantity two
direct connection, a cross-over LAN cable is required. Alternately, both analyzers can be on a local
area network.
F. N9910X-825, GPS Antenna
355?
12. What is included with Option
350?
13. How do I determine if my
FieldFox has CPU2 fast
processor?
Find us at www.keysight.com Page 8
listen is available with the purchase of the spectrum analyzer option 233. AM/FM metrics becomes
available when Option 355 is purchased. AM/FM metrics provides the user with RF spectrum view,
demodulated baseband signal waveform, carrier power, frequency deviation, SINAD and more.
Real-time spectrum analyzer (RTSA) or Option 350 provides real-time measurements on a FieldFox.
The FieldFox must be equipped with spectrum analysis capability. The preamplifier option is
recommended, as elusiv e signals often have low power levels. The maximum real-time bandwidth for
option 350 is 10 MHz. RTSA includes trace recording and playback capabilities. It does not include a
frequency-mask trigger (FMT).
All N995xA and N996xA analyzers include CPU2. On other FieldFox models, if the serial number
starts with MY5607/SG5607/US5607, then it has CPU2. If the serial number prefix is different, then
the analyzer firmware needs to be checked to see if the instrument has been upgraded with
N9910HU-100/200/300/400 to have CPU2.
Question Answer
Trace record/playback features
SA mode
RTSA mode
Record and playback spectrogram data
Yes
No 1
17. What is included with indoor
FieldFox’s mapping function is available in the following modes: Channel Scanner (312), Phased-
18. What is required for EMF
Requires triaxial antenna, not sold or provided by Keysight. Supported antenna is AGOS advanced
14. Is Spectrum Analyzer Trace
Recording and Playback
standard or an option?
15. What are the requirements for
Noise figure (NF) Option 356?
16. What is required for phased
array antenna support (Option
360)?
and outdoor mapping (Option
352)?
Spectrum Analyzer mode (Option 233) does not include Trace Recording and Playback by default.
To obtain this capability in SA mode, Option 236 Interference Analyzer and Spectrogram needs to be
purchased.
RTSA mode (Option 350) does include Trace Recording and Playback by default in RTSA mode.
Purchasing RTSA mode (Option 350) does not enable Trace Recording and Playback in SA mode
(Option 233).
SA and Interference Analyzer
Options 233 and 236
Record and playback spectrum traces Yes Yes
Save trace data with GPS time stamp over time Yes Yes
Requires spectrum analyzer mode (Option 233 on combination models), internal preamplifier (Option
235) and DC bias variable voltage source (Option 309) as well as CPU2 processor. An external noise
source is also required and FieldFox supports Keysight noise source models 346A/B/C/K40/K01.
Also recommended to improve accuracy is an external preamplifier Keysight models U7227A/C/F or
U7228A/C/F. Requires accessory item N9910X-713 BNC to SMB cable for DC bias variable voltage
source to noise source connection.
Requires spectrum analyzer mode (Option 233 on combination models). Recommend GPS receiver
(Option 307) and internal preamplifier (Option 235). Supported only on N995xA and N996xA models,
since phased array antenna operates at 28 GHz.
Array Antenna (360), OTA LTE (370), and OTA 5GTF (377). Mapping is currently not available in SA
or RTSA modes. Outdoor mapping requires the availability of GPS (Option 307). Maps can be saved
to the FieldFox internal memory, SD card or USB drive. Using a direct wired LAN connection,
FieldFox will automatically access OSM once location coordinates (latitude and longitude) and zoom
levels have been entered the Map Explorer menu. If using the l
map files can be downloaded to a .zip file and imported to FieldFox internal memory. If the FieldFox
GPS receiver is enabled and OSM maps have been previously saved to FieldFox with those GPS
coordinates, FieldFox can automatically load the corresponding map to match the current GPS
coordinates.
FieldFox Map Support Tool, OSM
RTSA
Option 350
measurements (Option 358)?
19. What is required for 5GTF
over-the-air (OTA)
measurements (Option 377)?
20. What is required for N6820ES
Surveyor 4D software?
technologies Triaxial Isotropic Antenna model SDIA-6000 30 MHz to 6 GHz. EMF measurements are
supported with spectrum analyzer mode (Option 233 on combination models).
Recommend 32, 44 or 50 GHz FieldFox model (N995xA and N996xA) to support 5GTF FR2
frequency of 28 GHz. Requires spectrum analyzer mode (Option 233 on combination models). Also
recommend GPS receiver (Option 307) and internal preamplifier (Option 235). FieldFox models 26.5
GHz and below will require external mixer to down convert millimeter wave frequency to intermediate
frequency (IF). For Keysight direct sales, mixer is orderable as Keysight model N9910XM28-H2A. For
indirect sales, the mixer is orderable as OML Inc. model M28H2ADC-K, please see website
www.omlinc.com for more information or contact a Keysight representative. OML mixer RF input
interface is 2.92 mm (f).
Surveyor 4D software connected to FieldFox spectrum analyz er mode offers a versatile, truly
portable spectrum monitoring system that covers VLF to 50 GHz, including 5G millimeter wave
bands. The software runs on an external PC or tablet. FieldFox required options include spectrum
analyzer mode (Option 233 on combination models), preamplifier (Option 235) and built-in GPS
receiver (Option 307). Core Surveyor 4D software for Windows (Option N6820ES-114) is required to
run the Surveyor 4D software. Other Surveyor 4D software optional licenses that are supported
include basic modulation recognition application (N6820ES-MR1) and universal signal detection
(N6820ES-USD). Requires Surveyor 4D software version 4.3 or later (May 2019).
1
RTSA trace recordings can be recalled and played back in SA mode Spectrogram. This has the added benefit that the measurements are
shown ‘slower’, making it easier for the human eye to decipher the signal content.
Find us at www.keysight.com Page 9
Loading...
