Keysight N6700 User's Guide

User’s Guide
Keysight Series N6700 Low-Profile Modular Power System
2 Keysight N6700 User’s Guide

Legal Notices

© Keysight Technologies 2006 - 2015
No part of this document may be photocopied, reproduced, or translated to another language without the prior agreement and written consent of Keysight Technologies as governed by United States and international copyright laws.
Warranty
The material contained in this document is provided “as is,” and is subject to being changed, without notice, in future editions. Further, to the maximum extent permitted by applicable law, Keysight disclaims all warranties, either express or implied, with regard to this manual and any information contained herein, including but not limited to the implied warranties of merchantability and fitness for a particular purpose. Keysight shall not be liable for errors or for incidental or consequential damages in connection with the furnishing, use, or performance of this document or of any information contained herein. Should Keysight and the user have a separate written agreement with warranty terms covering the material in this document that conflict with these terms, the warranty terms in the separate agreement shall control.
Manual Editions
Manual Part Number: 5969-2937 Edition 8, January 2015 Printed in Malaysia.
Reprints of this manual containing minor corrections and updates may have the same printing date. Revised editions are identified by a new printing date. .
Declaration of Conformity
Declarations of Conformity for this product and for other Keysight products may be downloaded from the Web. Go to
http://www.keysight.com/go/conformity
and click on “Declarations of Conformity.” You can then search by product number to find the latest Declaration of Conformity
Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
This product complies with the WEEE Directive 2002/96/EC) marketing requirement. The affixed product label (see below) indicates that you must not discard this electrical/electronic product in domestic household waste.
Product Category: With reference to the equipment types in the WEEE directive Annex 1, this product is classified as “Monitoring and Control instrumentation” product.
Do not dispose in domestic household waste.
To return unwanted products, contact our local Keysight office, or see
www.keysight.com/environment/product
for more information.
Certification
Keysight Technologies certifies that this product met its published specifications at time of shipment from the factory. Keysight Technologies further certifies that its calibration measurements are traceable to the United States National Institute of Standards and Technology, to the extent allowed by the Institute's calibration facility, and to the calibration facilities of other International Standards Organization members.
Exclusive Remedies
THE REMEDIES PROVIDED HEREIN ARE THE CUSTOMER'S SOLE AND EXCLUSIVE REMEDIES. KEYSIGHT TECHNOLOGIES SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON CONTRACT, TORT, OR ANY OTHER LEGAL THEORY.
Assistance
This product comes with the standard product warranty. Warranty options, extended support contacts, product maintenance agreements and customer assistance agreements are also available. Contact your nearest Keysight Technologies Sales and Service office for further information on Keysight Technologies' full line of Support Programs.
Technologies Licenses
The hardware and or software described in this document are furnished under a license and may be used or copied only in accordance with the terms of such license.
U.S. Government Restricted Rights
Software and technical data rights granted to the federal government include only those rights customarily provided to end user customers. Keysight provides this customary commercial license in Software and technical data pursuant to FAR 12.211 (Technical Data) and 12.212 (Computer Software) and, for the Department of Defense, DFARS 252.227-7015 (Technical Data – Commercial Items) and DFARS
227.7202-3 (Rights in Commercial Computer Software or Computer Software Documentation).
Trademarks
Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.
Keysight N6700 User’s Guide 3
Both direct and alternating current
current
equipment
equipment.
is off
push switch
push switch
CAUTION

Safety Notices

The following general safety precautions must be observed during all phases of operation of this instrument. Failure to comply with these precautions or with specific warnings or instructions elsewhere in this manual violates safety standards of design, manufacture, and intended use of the instrument. Keysight Technologies assumes no liability for the customer's failure to comply with these requirements.
General
Do not use this product in any manner not specified by the manufacturer. The protective features of this product may be impaired if it is used in a manner not specified in the operation instructions.
Before Applying Power
Verify that all safety precautions are taken. Make all connections to the unit before applying power. Note the instrument's external markings described under "Safety Symbols"
Ground the Instrument
This product is a Safety Class 1 instrument (provided with a protective earth terminal). To minimize shock hazard, the instrument chassis and cover must be connected to an electrical ground. The instrument must be connected to the AC power mains through a grounded power cable, with the ground wire firmly connected to an electrical ground (safety ground) at the power outlet. Any interruption of the protective (grounding) conductor or disconnection of the protective earth terminal will cause a potential shock hazard that could result in personal injury.
Fuses
The instrument contains an internal fuse, which is not customer accessible.
Do Not Operate in an Explosive Atmosphere
Do not operate the instrument in the presence of flammable gases or fumes.
Do Not Remove the Instrument Cover
Only qualified, service-trained personnel who are aware of the hazards involved should remove instrument covers. Always disconnect the power cable and any external circuits before removing the instrument cover.
Do Not Modify the Instrument
Do not install substitute parts or perform any unauthorized modification to the product. Return the product to a Keysight Sales and Service Office for service and repair to ensure that safety features are maintained.
In Case of Damage
Instruments that appear damaged or defective should be made inoperative and secured against unintended operation until they can be repaired by qualified service personnel.
A CAUTION notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly performed or adhered to, could result in damage to the product or loss of important data. Do not proceed beyond a CAUTION notice until the indicated conditions are fully understood and met.
WARNING
A WARNING notice denotes a hazard. It calls attention to an operating procedure, practice, or the like that, if not correctly performed or adhered to, could result in personal injury or death. Do not proceed beyond a WARNING notice until the indicated conditions are fully understood and met.
Safety Symbols
Direct current
Alternating current
Three phase alternating
Earth (ground) terminal
Protective earth ground terminal.
Frame or chassis terminal
Terminal is at earth potential.
Neutral conductor on permanently installed
Line conductor on permanently installed
On supply
Off supply
Standby supply. Unit is not completely disconnected from AC mains when switch
In position of a bi-stable
Out position of a bi-stable
Caution, risk of electric shock
Caution, hot surface
Caution, refer to accompanying description
4 Keysight N6700 User’s Guide

In this Book

NOTE
Technologies at one of the following telephone
Specific chapters in this manual contain the following information:
Quick Reference – Chapter 1 is a quick reference section that helps
you quickly become familiar with your Keysight N6700 Modular Power System. It describes the differences between the various modules in the power system.
Installation – Chapter 2 describes how to install your power system.
It describes how to connect various loads to the output. It discusses remote sensing as well as parallel and series operation.
Getting Started – Chapter 3 describes how to set the voltage,
current, over-voltage protection, and turn on the output. It also describes how to configure the remote interface.
Operating the Power System – Chapter 4 describes how to use the
advanced features of the power system using the front panel menus and the corresponding SCPI commands.
Specifications – Appendix A describes the mainframe characteristics. Using the Digital Port – Appendix B describes how to configure and
use the digital port on the back of the instrument.
Power Allocation – Appendix C describes the power allocation
function, which applies to power system in which the combined ratings of the power modules exceed the power rating of the mainframe.
Output On/Off Synchronization – Appendix D discusses output
on/off synchronization, which lets you accurately synchronize output turn-on sequences across multiple mainframes.
Source Operating Modes – Appendix E discusses operating mode
information for all power modules.
For complete details on the SCPI (Standard Commands for Programmable Instruments) commands, refer to the N6700 Programmer’s Reference Help file included on the Keysight N6700 Product Reference CD. This CD-ROM is shipped along with your instrument.
You can contact Keysight numbers for warranty, service, or technical support information. In the United States: (800) 829-4444 In Europe: 31 20 547 2111 In Japan: 0120-421-345 Or use our Web link for information on contacting Keysight in your country or specific location:
www.keysight.com/find/assist
Or contact your Keysight Technologies Representative.
Keysight N6700 User’s Guide 5

Contents

1 – Quick Reference ....................................................................................................... 7
2 – Installation ............................................................................................................. 23
3 – Getting Started ...................................................................................................... 45
4 – Operating the Power System ................................................................................. 61
The Keysight N6700 Modular Power System – At a Glance ........... 8
The Front Panel – At a Glance ....................................................... 11
The Rear Panel – At a Glance ........................................................ 11
Front Panel Display – At a Glance ................................................. 12
Front Panel Keys – At a Glance ..................................................... 13
Front Panel Menu Reference ......................................................... 14
SCPI Command Summary ............................................................. 16
General Information ....................................................................... 24
Inspecting the Unit ......................................................................... 25
Installing the Unit ........................................................................... 26
Connecting the Line Cord .............................................................. 30
Connecting the Outputs ................................................................. 31
Remote Sense Connections ........................................................... 36
Parallel Connections ...................................................................... 38
Series Connections ......................................................................... 40
Additional Load Considerations ..................................................... 42
Connecting the Auxiliary Voltage Measurement Input ................. 44
Turning the Unit On ........................................................................ 46
Selecting an Output Channel ......................................................... 46
Entering an Output Voltage Setting .............................................. 46
Entering a Current Limit Setting .................................................... 47
Enabling the Output ....................................................................... 47
Using the Front Panel Menu .......................................................... 48
Connecting to the Interfaces ......................................................... 50
Communicating Over the LAN ....................................................... 57
Securing the Interfaces .................................................................. 59
Programming the Output ............................................................... 62
Synchronizing Output Steps .......................................................... 68
Programming Output Lists ............................................................. 72
Making Measurements ................................................................... 77
Using the Digitizer .......................................................................... 79
Using the Protection Functions ..................................................... 87
External Data Logging .................................................................... 91
System-Related Operations ........................................................... 95
6 Keysight N6700 User’s Guide
A – Specifications ........................................................................................................ 99
B – Using the Digital Port .......................................................................................... 103
C – Power Allocation ................................................................................................. 109
D – Output On/Off Synchronization ........................................................................... 113
E – Source Operating Modes ..................................................................................... 119

Updates

Keysight N6700B, N6701A, N6702A MPS Mainframes .............. 100
Digital Control Port ...................................................................... 104
Configuring the Digital Control Port ............................................ 105
Power Limit Operation ................................................................. 110
Module Power Allocation ............................................................. 111
Synchronizing Output Turn-on Delays ........................................ 114
Synchronizing Multiple Mainframes ............................................ 117
Operation ...................................................................................... 118
Single Quadrant Operation .......................................................... 120
Keysight N678xA Multi-Quadrant Operation .............................. 122
This manual describes firmware revision D.03.08 and up. Go to
http://www.keysight.com/find/N6700firmware
this or any later versions of the firmware. Information on how to install the firmware is available on the web site.
Refer to “Instrument Identification” in chapter 4 to view the firmware version that is currently installed in your mainframe.
Updated versions of this manual are also posted on the web. Go to
http://www.keysight.com/find/N6700
manual.
to get the latest version of the
if you need to download
1 Quick Reference
NOTE
The Keysight N6700 Modular Power System – At a Glance ........... 8
The Front Panel – At a Glance ....................................................... 11
The Rear Panel – At a Glance ........................................................ 11
Front Panel Display – At a Glance ................................................. 12
Front Panel Keys – At a Glance ..................................................... 13
Front Panel Menu Reference ......................................................... 14
SCPI Command Summary ............................................................. 16
This chapter concisely describes the operation of the Keysight N6700 Modular Power System (MPS).
This chapter does not describe every operating feature in detail. It is simply a quick reference guide to quickly become familiar with the essential operating features of the power system.
For complete details on the SCPI (Standard Commands for Programmable Instruments) commands, refer to the Programmer’s Reference Help file included on the Keysight N6700 Product Reference CD. This CD-ROM is shipped along with your instrument.
Unless otherwise noted, the Keysight N6700 Modular Power System will also be referred to as “MPS” and “power system” throughout this manual.
1 Quick Reference
8 Keysight N6700 User’s Guide

The Keysight N6700 Modular Power System – At a Glance

Output Features

Programmable voltage and current
Full programming capability is provided for the entire range of output voltage and current. Outputs can operate as either constant voltage (CV) or constant current (CC) sources.
Low output noise
Available on <4.5 mV peak-to-peak, which is comparable to linear supplies.
Fast up/down programming
Available on
≤1.5 millisecond response time from 10% to 90% of the output rating.
Fast transient response
Available on Transient response is less than 100 μs.
The Keysight N6700 Modular Power System is a configurable, one rack­unit (1U) platform that lets you mix and match power modules to create a power system optimized for your test system requirements.
Keysight N6700–N6702 MPS mainframes are available in power levels of 400 W, 600 W, and 1,200 W. Up to four power modules can be installed in each mainframe. Power modules come in power levels of 20 W through 500 W, have various voltage and current combinations, and provide the following performance features:
The N673xB, N674xB, and N677xA DC Power Modules provide
programmable voltage and current, measurement, and protection features, making these economical models suitable for powering the device-under-test or system resources such as fixture controls.
The N675xA High-Performance, Autoranging DC Power Modules
provide low noise, high accuracy, fast programming times, and advanced programming and measurement capabilities to speed test throughput.
The N676xA Precision DC Power Modules provide precise control
and measurements in the milli- and micro-ampere region with the ability to simultaneously digitize voltage and current and capture those measurements into an oscilloscope-like data buffer.
The N678xA Source/Measure Units (SMU) have a multiple-quadrant
The N6783A Application-Specific DC Power Modules are two-
The output and system features are described in the following sections. Not all output features are available on every power module. The “Model Differences” section describes the features that apply only to specific power modules.
power mesh with separate voltage and current priority source modes. These models are optimized for applications such as battery drain analysis and functional testing.
quadrant low-wattage models specifically designed for battery charging/discharging and mobile communications applications.
Keysight N676xA and N675xA power modules. Output noise is
Keysight N675xA, N676xA, and N678xA SMU power modules.
Keysight N675xA, N676xA, and N678xA SMU power modules.
Quick Reference 1
Keysight N6700 User’s Guide 9
Output autoranging capability
Availa Autoranging supplies the maximum rated power over a continuous range of voltage and current settings.
Output On/Off sequencing
A turn sequen
Remote voltage sensing
Two remote sensing terminals are provided for each output. When shipped, the remote sense jumpers are included in a separate bag. See Chapter 2.
Output protection
Each output has over protection. Over-voltage and over-current protection are programmable.
Multiple-Quadrant operation
Available on Keysight N678xA SMU and N6783A power modules. 2 model N6784A offers 4- quadrant output operation.

Measurement Features

Multiple-output/Single­output meter display
Switch between a 4 power supply information. All power modules display real voltage and current measurements as well as status information.
Seamless measurement autoranging
Available on modules. however, the 10 μA current range must be selected manually.
Microampere current measurements
Available on Current measurement can be made as low as 1
Fast digitizing
Available on
5.12 μs/sample for one parameter; 10.24 μs/sample for two parameters.

System Features

Choice of three interfaces
GPIB (IEEE-488), LAN, and USB remote programming interfaces are built in.
Built-in Web server
A internet browser on your computer.
SCPI language
The instrument is compatible with the Standard Commands for Programmable Instruments (SCPI).
Front panel I/O setup
Menus let you set up
Real-time status information
The front panel indicates the status of each output. It also indicates when a protection shut
Module identification
Each module has identifying data stored in Information includes model number, serial number, and options.
Universal AC input
Mainframes have correction.
ble on Keysight N676xA and N675xA power modules.
-on/turn-off delay capability for each output allows output on/off cing.
- quadrant operation provides source and sink output capability. Keysight
-voltage, over-current, and over-temperature
-output summary view and a 1-output detailed view of
-time output
Keysight N6781A, N6782A, N6785A, and N6786A SMU power
Output measurements seamlessly autorange between ranges –
Keysight N6761A, N6762A, and N678xA SMU power modules.
μA in the 10 μA range.
Keysight N678xA SMU power modules.
built-in Web server lets you control the instrument directly from an
GPIB and LAN parameters from the front panel.
-down has occurred.
non-volatile memory.
universal input voltage capability with active power factor
1 Quick Reference
10 Keysight N6700 User’s Guide

Model Differences

Feature
DC Power
High-Performance
Precision
N673xB, N674xB, N677xA
N675xA
N676xA
Feature
Source/Measure Units (SMU)
Application-Specific
N6781A
N6782A
N6784A
N6785A
N6786A
N6783A
BAT
N6783A
MFG
● ● ● ●
● ● ● ● ●
● ● ● ● ● ● ●
● ● ● ● ●
3 3 4 4
3 4 4 4
3 3
4 4 3 3 2
● ● ● ● ●
● ●
● ● ● ● ● ● ●
● ● ● ● ● ● ●
● ● ● ● ● ● ●
● ● ● ● ● ● ●
(● = available) 50 W output rating 100 W output rating 300 W output rating 500 W output rating
Output disconnect relays Output disconnect/polarity reversal relays Autoranging output capability Voltage or current turn-on priority
Precision voltage and current measurements Low voltage and low current output range Low voltage and low current measurement range 200 microampere measurement range Simultaneous voltage and current measurements
SCPI command output list capability SCPI command array readback
NOTE 3
SCPI command programmable sample rate SCPI command external data logging Double-wide (occupies 2 channel locations)
NOTE 1
NOTE 2
NOTE 3
NOTE 3
NOTE 3
N6731B – N6736B N6741B – N6746B N6773A – N6777A
Option 761 Option 760
Option 054 Option 054 Option 054 Option 054
N6751A N6752A
N6761A
N6762A N6753A, N6754A N6763A, N6764A N6755A, N6756A N6765A, N6766A
Option 761 Option 760
Option 761 Option 760
N6761A, N6762A
N6761A, N6762A
Option 2UA
Option 054 Option 054 Option 054 Option 054
N6753A – N6756A N6763A – N6766A
(● = available)
Output rating
20 W 20 W 2-quadrant operation 4-quadrant operation Auxiliary voltage measurement input
Output disconnect relays Negative voltage protection Voltage or current priority mode Programmable output resistance
Multiple voltage output ranges Multiple current output ranges Multiple voltage measurement ranges Multiple current measurement ranges
3 3 3 4
Simultaneous voltage and current measurements
Seamless measurement autoranging SCPI command output list capability SCPI command array readback SCPI command programmable sample rate SCPI command external data logging
NOTE 3, 4
NOTE 3
NOTE 3
NOTE 3
Double-wide (occupies 2 channel locations)
1
Output current is limited to 10A max. on Models N6742B and N6773A with Option 760.
Option 760 is not available on Models N6741B, N6751A, N6752A, N6761A, and N6762A.
2
Option 2UA.is only available on Models N6761A and N6762A. It includes Option 761.
3
Only available when using the remote interfaces; not from the front panel.
4
List capability is not available on the negative current output on Model N6783A
20 W 80 W
80 W
24 W
18 W
Option 761 Option 761
2
Quick Reference 1
Keysight N6700 User’s Guide 11

The Front Panel – At a Glance

Display
inactivity. Press any key to
Navigation keys
Output keys
20.007V 4.004A
CV Set:
20.
000V 5.500A
o -
Menu
3
E
+/-
Back
.
2
0
1
4 5 6
987
Sel
Meter
Channel
Help
On/Off
Voltage
Current
1
Error
Enter
Low-Profile MPS Mainframe 600 Watt
N6700B
On/Off switch and LED
System keys
channel and
Numeric entry keys

The Rear Panel – At a Glance

GPIB connector
Chassis ground binding post
3-pin IEC 320 AC input connector
+s + -s
+s + -s
+s + -s +s + -s
1 2 3 4 5 6 7
Output connector.
8-pin digital control connector
USB connector
LAN connector
WARNING
SHOCK HAZARD The power cord provides a chassis ground through a third conductor. Be certain that your power outlet is of the three­conductor type with the correct pin connected to earth ground.
Turns off after 1 hour of
restore the display.
LED indicates power is on. Green = normal operation. Amber = display is screen­ saver mode.
Move the cursor to a menu item. Select the highlighted menu item.
Toggle between single­multiple-channel view. Access front panel command menu. Select an output channel to control.
Turn the outputs on or off.
Enter voltage or current.
Enter values. Arrow keys increment or decrement voltage
and current settings.
Power cord requires ground conductor.
Includes +/output and +/ sense terminals.
Connector function is user-configurable.
10/100 Base-T Left LED indicates activity. Right LED indicates link integrity.
1 Quick Reference
12 Keysight N6700 User’s Guide

Front Panel Display – At a Glance

Single-channel view
Bar indicates output polarity is reversed
Current measurement
Press the to toggle between views
Operating status
Voltage and current settings
Interface status (IO = activity on interface)
Multiple-channel view
Press the to toggle between views
Grouped-channel view
Refer to Chapter 4, under “System Related Operations” for more information
Grouped channels are addressed using the channel number of the lowest
Double-wide view
Interface status indicators
Err = an error has occurred (press Error key to display error message) Lan = the LAN is connected and has been configured IO = there is activity on one of the remote interfaces
Meter key
Meter key
Voltage measurement
(CV = constant voltage)
Voltage and Current measurements
The highlighted channel is the active channel
Channels 2 through 4 are connected in parallel and have been configured or grouped to act as a single, higher-power channel
-
channel in the group
Channel 2 is a double-wide power module that occupies two channel locations in the mainframe
Quick Reference 1
Keysight N6700 User’s Guide 13
Operating status indicators
OFF = the output is off CV = the output is in constant voltage mode CC = the output is in constant current mode CP+ = the output is CP V C OV = OV OC = the output is disabled by the over OT = the over PF = the output is disabl OSC = the output is disabled by the oscillation protection INH = the output is disabled by an external inhibit signal UNR = the output is unregulated PROT = the output is disabled by a condition from a coupled channel

Front Panel Keys – At a Glance

System keys
Menu
Back
Meter
Channel
Help Error
Meter Menu Channel Back Help Error
Navigation keys
Sel
The Arrow keys let you move around in the command menus. The Select k It also lets you enter edit mode for numeric parameters.
Output keys
On/Off
Voltage
Current
On/Off
All
Voltage Current
Number keys
Enter
3
E
+/-
.
2
0
1
4 5
6
987
The 0 through 9 keys enter numbers. The (.) key is the decima The +/ The E key enters an exponent. Add the value to the right of the E. The The set The Enter key enters a value. If you exit a field without pressing the Enter key, the value is ignored.
– = the output is limited (or disabled) by the negative power limit
L+/– = the output is in positive or negative voltage limit mode
L+/– = the output is in positive or negative current limit mode
– = the output is disabled by the negative over-voltage protection
limited (or disabled) by the positive power limit
the output is disabled by the over-voltage protection
-current protection
-temperature protection has tripped ed by a power-fail condition
returns the display to metering mode.
accesses the command menu.
selects or highlights a channel to control. backs out of a menu without activating any changes. accesses information about the displayed menu control. displays any error messages in the error queue.
This key is only active in Single- channel or Multiple-channel view.
backspace key deletes digits as it backspaces over them.   arrow keys increment or decrement the voltage or current
tings. They are also used to select letters in alphabetic entry fields.
ey lets you make a selection in the command menus.
controls the selected output (or all outputs when
is lit).
lets you change the voltage setting of the selected channel.
lets you change the current setting of the selected channel.
l point.
key is only used to enter a minus sign.
1 Quick Reference
14 Keysight N6700 User’s Guide

Front Panel Menu Reference

NOTE
Menu Command
Control Description
Menu commands that appear grayed-out on the front panel are either not available for the power module, or are password protected.
Output Voltage Programs voltage setting, limits, and ranges. Current Programs current setting, limits, and ranges.
Mode Programs output priority mode on Models N678xA SMU. Sequence Delay Programs Turn-on /Turn off delay. Couple Couples output channels for output on/off synchronization.
Advanced Slew Voltage Programs voltage slew rate. Current Programs current slew rate on Models N678xA SMU. Power Programs the power allocation function.
Pol Lets you reverse the polarity of the output and sense terminals. Resistance Programs output resistance on Models N6781A, N6785A. Bandwidth Programs output voltage bandwidth on Models N678xA SMU.
Tmode Programs turn-on/turn-off impedance on Models N678xA SMU. Measure Range Selects voltage and current measurement range. Sweep Specifies measurement points, time interval, and trigger offset.
Window Selects measurement window: Rectangular, Hanning. Input Selects Auxiliary voltage measurements on Models N6781A, N6785A.
Control Lets you abort a measurement in progress. Transient Mode Selects voltage or current transient mode: Fixed, Step, List.
Step Programs voltage and current step value. Enables step triggers.
List Pace Specifies Dwell or Trigger paced list.
Repeat Specifies number of list repetitions, or specifies continuous list.
Terminate Specifies list settings when the list terminates.
Config Configures list step voltage, current, dwell, and trigger signals.
Reset Aborts the list and resets all list parameters.
TrigSource Specify the trigger source: Bus, Tran 1-4, Pin 1-7, Ext.
Control Initiates, Triggers, or Aborts output triggers. Displays trigger state.
Protect OVP Configures over-voltage protection function. OCP Configures over-current protection function. Inhibit Configures the external inhibit signal: Off, Latching, Live
Coupling Disables ALL output channels when a protection fault occurs. Wdog Configures the output watchdog timer. Osc Enables/disables oscillation protection on Models N678xA SMU.
Clear Clears output protection. Displays output state. States Reset Resets the instrument to its reset (*RST) state. SaveRecall Saves or recalls an instrument state.
PowerOn Selects the power-on state: *RST, RCL0.
Quick Reference 1
Keysight N6700 User’s Guide 15
Menu Command
Control Description
System IO LAN ActiveSettings Displays the LAN interface settings that are presently active.
Config IP Configures the IP addressing of the instrument. Name Configures the Dynamic DNS and NetBIOS naming service. Domain Configures the Domain Name.
DNS Configures the DNS server. TCP Configures the TCP keepalive function. Reset Resets the LAN interface settings to the factory-shipped state.
USB Status Displays status, speed, packets received, and packets sent. Identification USB connect string - the instrument’s unique USB identifier. GPIB Selects the GPIB address.
DigPort Pins<1> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, FaultOut. Pins<2> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut. Pins<3> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, InhibitIn.
Pins<4-7> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, OnC, OffC. Pins<1-7> Polarity Specifies the pin polarity: Positive, Negative Data Sends/reads data from the digital I/O port
Groups Defines groups of output channels that are connected in parallel. Preferences Display Contrast Configures the display contrast. Saver Configures the screen saver and wake-on I/O timer.
View Selects 1-channel or 4-channel view at turn-on Keys Enables/disables key clicks and configures the On/Off key. Lock Locks front panel keys. Enter a password to unlock the front panel.
Admin Login/Logout Enter a password to access the admin functions. Cal Volt Vprog Calibrates High and Low voltage ranges. Vlim Calibrates voltage limit High and Low ranges
Vmeas Calibrates High, Low, and Aux voltage measurement ranges. Curr Iprog Calibrates High and Low current ranges. Ilim Calibrates current limit.
Imeas Calibrates High and Low current measurement ranges. Misc CMRR Calibrates common mode rejection ratio.
Dprog Calibrates the downprogrammer. Ipeak Calibrates I peak. Resistance Calibrates output resistance High and Low ranges.
Date Saves the calibration date for each channel. Save Saves the calibration data. LAN Enables/disables the LAN interface and the built-in Web server.
USB Enables/disables the USB interface. Nvram Resets all non-volatile RAM settings to their factory defaults. Password Changes the password for the admin functions.
About Frame Displays model, serial number, and firmware revisions. Module Displays model, serial number, options, voltage, current, power.
1 Quick Reference
16 Keysight N6700 User’s Guide

SCPI Command Summary

Subsystem Commands

NOTE
SCPI Command
Description
ABORt
:ACQuire (@chanlist)
Resets the measurement trigger system to the Idle state
:ELOG (@chanlist)
Stops the external data log
:TRANsient (@chanlist)
Resets the transient trigger system to the Idle state
CALibrate
:CURRent
[:LEVel] <NRf>, (@channel)
Calibrates the output current programming
:LIMit
:NEGative <NRf>, (@channel)
Calibrates the negative current limit (only on N6783A)
:POSitive <NRf>, (@channel)
Calibrates the positive current limit (only on N678xA SMU)
:MEASure <NRf>, (@channel)
Calibrates the current measurement
:PEAK (@channel)
Calibrates the peak current limit (only on N675xA, N676xA)
:DATA <NRf>
Enters the calibration value
:DATE <”date”>, (@channel)
Sets the calibration date
:DPRog (@channel)
Calibrates the current downprogrammer
:LEVel P1 | P2 | P3
Advances to the next calibration step
:PASSword <NRf>
Sets the numeric calibration password
:RESistance 20| 6, (@channel)
Calibrates the output resistance (only on N6781A, N6785A)
:SAVE
Saves the new cal constants in non-volatile memory
:STATE <Bool> [,<NRf>]
Enables/disables calibration mode
:VOLTage
[:LEVel] <NRf>, (@channel)
Calibrates the output voltage programming
:CMRR (@channel)
Calibrates common mode rejection ratio (only N675xA, N676xA)
:LIMit
:POSitive <NRf>, (@channel)
Calibrates the positive voltage limit (only on N678xA SMU)
:MEASure <NRf>, (@channel)
Calibrates the voltage measurement
:AUXiliary (@channel)
Calibrates the auxiliary voltage measurement (only on N6781A, N6785A)
DISPlay
[:WINDow]
:CHANnel <channel>
Selects the channel in 1-channel meter view
:VIEW METER1 | METER4
Selects 1-channel or 4-channel meter view
FETCh
(Fetch commands only on N676xA, N678xA SMU and Option 054)
[:SCALar]
:CURRent
[:DC]? (@chanlist)
Returns the average current
:ACDC? (@chanlist)
Returns the total rms current (AC + DC)
:HIGH? (@chanlist)
Returns the high level of a current pulse
:LOW? (@chanlist)
Returns the low level of a current pulse
:MAXimum? (@chanlist)
Returns the maximum current
:MINimum? (@chanlist)
Returns the minimum current
:POWer
[:DC]? (@chanlist)
Returns the average output power
:VOLTage
[:DC]? (@chanlist)
Returns the average voltage
:ACDC? (@chanlist)
Returns the total rms voltage (AC + DC)
:HIGH? (@chanlist)
Returns the high level of a voltage pulse
:LOW? (@chanlist)
Returns the low level of a voltage pulse
:MAXimum? (@chanlist)
Returns the maximum voltage
:MINimum? (@chanlist)
Returns the minimum voltage
Some [optional] commands have been included for clarity. All settings commands have a corresponding query. Not all commands apply to all models
.
Quick Reference 1
Keysight N6700 User’s Guide 17
SCPI Command
Description
FETCh (continued)
:ARRay
:CURRent [:DC]? (@chanlist)
Returns the instantaneous output current
:POWer [:DC]? (@chanlist)
Returns the instantaneous output power
:VOLTage [:DC]? (@chanlist)
Returns the instantaneous output voltage
:ELOG <NR1>, (@chanlist)
Returns the most recent external data log records
FORMat
[:DATA] ASCII | REAL
Returns data as ASCII or binary
:BORDer NORMal | SWAPped
Sets the byte order of the external data log data
INITiate
[:IMMediate]
(Acquire command only on N676xA, N678xA SMU and Option 054)
:ACQuire (@chanlist)
Enables the measurement system to receive triggers
:ELOG (@chanlist)
Enables external data log measurements
:TRANsient (@chanlist)
Enables the output transient system to receive triggers
:CONTinuous
:TRANsient <Bool>, (@chanlist)
Enables/disables continuous transient triggers
MEASure
[:SCALar]
:CURRent
[:DC]? (@chanlist)
Takes a measurement; returns the average current
:ACDC? (@chanlist)
Takes a measurement; returns the total rms current (AC + DC)
:HIGH? (@chanlist)
Takes a measurement; returns the high level of a current pulse
:LOW? (@chanlist)
Takes a measurement; returns the low level of a current pulse
:MAXimum? (@chanlist)
Takes a measurement, returns the maximum current
:MINimum? (@chanlist)
Takes a measurement, returns the minimum current
:POWer
[:DC]? (@chanlist)
Takes a measurement, returns the average output power
:VOLTage
[:DC]? (@chanlist)
Takes a measurement; returns the average voltage
:ACDC? (@chanlist)
Takes a measurement; returns the total rms voltage (AC + DC)
:HIGH? (@chanlist)
Takes a measurement; returns the high level of a voltage pulse
:LOW? (@chanlist)
Takes a measurement; returns the low level of a voltage pulse
:MAXimum? (@chanlist)
Takes a measurement, returns the maximum voltage
:MINimum? (@chanlist)
Takes a measurement, returns the minimum voltage
:ARRay
(Array commands only on N676xA, N678xA SMU and Option 054)
:CURRent [:DC]? (@chanlist)
Takes a measurement; returns the instantaneous output current
:POWer [:DC]? (@chanlist)
Takes a measurement; returns the instantaneous output power
:VOLTage [:DC]? (@chanlist)
Takes a measurement; returns the instantaneous output voltage
OUTPut
[:STATe] <Bool> [,NORelay], (@chanlist)
Enables/disables the specified output channel(s)
:COUPle
[:STATe] <Bool>
Enables/disables channel coupling for output synchronization
:CHANNel [<NR1> {,<NR1>}]
Selects which channels are coupled
:DOFFset <NRf>
Specifies a maximum delay offset to synchronize output changes
:MAX
:DOFFset?
Returns the maximum delay offset required for a mainframe
:DELay
:FALL <NRf+>, (@chanlist)
Sets the output turn-off sequence delay
:RISE <NRf+>, (@chanlist)
Sets the output turn-on sequence delay
:PMODe VOLTage | CURRent, (@chanlist)
Sets the mode for turn on/off transitions (N6761A, N6762A)
:TMODe HIGHZ | LOWZ, (@chanlist)
Specifies the turn-on/turn-off impedance (only on N678xA SMU)
:INHibit
:MODE LATChing | LIVE | OFF
Sets the remote inhibit input
:PON
:STATe RST | RCL0
Programs the power-on state
1 Quick Reference
18 Keysight N6700 User’s Guide
SCPI Command
Description
:PROTection
:CLEar (@chanlist)
Resets latched protection
:COUPle <Bool>
Enables/disables channel coupling for protection faults
:DELay <NRf+>, (@chanlist)
Sets over-current protection programming delay
:OSCillation <Bool>, (@chanlist)
Enables/disables output oscillation protection (N678xA SMU)
:WDOG
[:STATe] <Bool>
Enables/disables the I/O watchdog timer
:DELay <NRf+>
Sets the watchdog timer delay
:RELay
:POLarity NORMal | REVerse, (@chanlist)
Sets the output relay polarity (Option 760)
SENSe
:CURRent
:CCOMpensate <Bool>, (@chanlist)
Enables/disables the capacitive current compensation
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Selects the current measurement range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A, N6785A,
:ELOG
N6786A)
:CURRent
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Sets the external data log current range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A, N6785A, N6786A)
:FUNCtion
:CURRent <Bool>, (@chanlist)
Enables/disables external current data logging
:MINMax <Bool>, (@chanlist)
Enables/disables external min/max current data logging
:VOLTage <Bool>, (@chanlist)
Enables/disables external voltage data logging
:MINMax <Bool>, (@chanlist)
Enables/disables external min/max voltage data logging
:PERiod <NR1>, (@chanlist)
Sets the integration time of the external data logging
:VOLTage
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Sets the external data log voltage range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A)
:FUNCtion “VOLTage” | ”CURRent” | “NONE”, (@chanlist)
Selects the measurement function (for backward compatibility)
:CURRent <Bool>, (@chanlist)
Enables/disables current measurements (replaces FUNCtion)
:VOLTage <Bool>, (@chanlist)
Enables/disables voltage measurements (replaces FUNCtion)
:INPut MAIN | AUXiliary, (@chanlist)
Selects the voltage measurement input (only on N6781A, N6785A)
:SWEep
(Sweep commands only on N676xA, N678xA SMU and Option 054)
:OFFSet
:POINts <NRf+>, (@chanlist)
Defines the trigger offset in the measurement sweep
:POINts <NRf+>, (@chanlist)
Defines the number of data points in the measurement
:TINTerval <NRf+>, (@chanlist)
Sets the measurement sample interval
:RESolution RES20 | RES40, (@chanlist)
Sets the measurement resolution
:VOLTage
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Selects the voltage measurement range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A N6782A)
:WINDow
[:TYPE] HANNing | RECTangular, (@chanlist)
Selects measurement window (N676xA, N678xA SMU, Option 054)
[SOURce:]
CURRent
[:LEVel]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the output current
:TRIGgered [:AMPLitude] <NRf+>, (@chanlist)
Sets the triggered output current
:LIMit
[:POSitive]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the positive current limit (only on N678xA SMU, N6783A)
:COUPle <Bool>, (@chanlist)
Sets the current limit tracking state (only on N678xA SMU)
:NEGative
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the negative current limit (only on N678xA SMU, N6783A-BAT)
Quick Reference 1
Keysight N6700 User’s Guide 19
SCPI Command
Description
[SOURce:]CURRent (continued)
:MODE FIXed | STEP | LIST, (@chanlist)
Sets the current trigger mode
:PROTection
:DELay
[:TIME] <NRf+>, (@chanlist)
Sets the over-current protection programming delay
:STARt SCHange | CCTRans, (@chanlist)
Sets the over-current protection programming mode
:STATe <Bool>, (@chanlist)
Enables/disables over-current protection on the selected output
:RANGe <NRf+>, (@chanlist)
Sets the output current range
:SLEW
[:IMMediate] <NRf+> | INFinity, (@chanlist)
Sets the output current slew rate (only N678xA SMU)
:MAXimum <Bool>, (@chanlist)
Enables/disables the maximum slew rate override (N678xA SMU)
DIGital
:INPut:DATA?
Reads the state of the digital port pins
:OUTPut:DATA <NRf>
Sets the digital port
:PIN<1-7>
| INHibit | ONCouple | OFFCouple
:POLarity POSitive | NEGative
Sets the selected pin’s polarity
:TOUTput
:BUS[:ENABle] <Bool>
Enables/disables BUS-generated triggers on digital pins
FUNCtion CURRent | VOLTage, (@chanlist)
Specifies current priority or voltage priority mode (N678xA SMU)
LIST
(List commands only on N676xA, N678xA SMU and Option 054)
:COUNt <NRf+> | INFinity, (@chanlist)
Sets the list repeat count
:CURRent
[:LEVel] <NRf> {,<NRf>}, (@chanlist)
Sets the current list
:POINts? (@chanlist)
Returns the number of current list points
:DWELl <NRf> {,<NRf>}, (@chanlist)
Sets the list of dwell times
:POINts? (@chanlist)
Returns the number of dwell list points
:STEP ONCE | AUTO, (@chanlist)
Specifies how the list responds to triggers
:TERMinate
:LAST <Bool>, (@chanlist)
Sets the list termination mode
:TOUTput
:BOSTep
[:DATA] <Bool> {,<Bool>}, (@chanlist)
Generate triggers at the Beginning Of Step
:POINts? (@chanlist)
Returns the number of beginning of step list points
:EOSTep
[:DATA] <Bool> {,<Bool>}, (@chanlist)
Generate triggers at the End Of Step
:POINts? (@chanlist)
Returns the number of end of step list points
:VOLTage
[:LEVel] <NRf> {,<NRf>}, (@chanlist)
Sets the voltage list
:POINts? (@chanlist)
Returns the number of voltage level points
POWer
:LIMit <NRf+>, (@chanlist)
Sets the power limit on output channels
RESistance
[:LEVel][:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the output resistance (only on N6781A, N6785A)
:STATe <Bool>, (@chanlist)
Enables/disables output resistance programming (only N6781A, N6785A)
STEP
:TOUTput <Bool>, (@chanlist)
Generate a trigger output on the voltage or current step transient
VOLTage
[:LEVel]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the output voltage
:TRIGgered [:AMPLitude] <NRf+>, (@chanlist)
Sets the triggered output voltage
:BWIDth LOW | HIGH1 | HIGH2 | HIGH3, (@chanlist)
Sets the voltage bandwidth (only on N678xA SMU)
:FUNCtion DIO | DINPut | TOUTput | TINPut | FAULt
Sets the selected pin’s function
1 Quick Reference
20 Keysight N6700 User’s Guide
SCPI Command
Description
[SOURce:]VOLTage (continued)
:LIMit
[:POSitive]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the positive voltage limit (only on N678xA SMU)
:COUPle <Bool>, (@chanlist)
Sets the voltage limit tracking state (only on N6784A)
:NEGative
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the negative voltage limit (only on N6784A)
:MODE FIXed | STEP | LIST, (@chanlist)
Sets the voltage trigger mode
:PROTection
[:LEVel] <NRf+>, (@chanlist)
Sets the over-voltage protection level
:DELay[:TIME] <NRf+>, (@chanlist)
Sets the over-voltage protection delay (only on N6783A)
:REMote
[:POSitive][:LEVel] <NRf+>, (@chanlist)
Sets the positive remote OV protection level (only on N678xA SMU)
:NEGative[:LEVel] <NRf+>, (@chanlist)
Sets the negative remote OV protection level (only on N6784A)
:TRACking
(Tracking commands only on Option J01)
[:STATe] <Bool>, (@chanlist)
Enables/disables tracking OVP
:OFFSet <NRf+>, (@chanlist)
Sets the tracking OVP offset
:RANGe <NRf+>, (@chanlist)
Sets the output voltage range
:SLEW
[:IMMediate] <NRf+> | INFinity, (@chanlist)
Sets the output voltage slew rate
:MAXimum <Bool>, (@chanlist)
Enables/disables the maximum slew rate override
STATus
:OPERation
[:EVENt]? (@chanlist)
Returns the value of the operation event register
:CONDition? (@chanlist)
Returns the value of the operation condition register
:ENABle <NRf>, (@chanlist)
Enables specific bits in the Event register
:NTRansition <NRf>, (@chanlist)
Sets the Negative transition filter
:PTRansition <NRf>, (@chanlist)
Sets the Positive transition filter
:PRESet
Presets all enable and transition registers to power-on
:QUEStionable
[:EVENt]? (@chanlist)
Returns the value of the questionable event register
:CONDition? (@chanlist)
Returns the value of the questionable condition register
:ENABle <NRf>, (@chanlist)
Enables specific bits in the Event register
:NTRansition <NRf>, (@chanlist)
Sets the Negative transition filter
:PTRansition <NRf>, (@chanlist)
Sets the Positive transition filter
SYSTem
:CHANnel
[:COUNt]?
Returns the number of output channels in a mainframe
:MODel? (@chanlist)
Returns the model number of the selected channel
:OPTion? (@chanlist)
Returns the option installed in the selected channel
:SERial? (@chanlist)
Returns the serial number of the selected channel
:COMMunicate
:RLSTate LOCal | REMote | RWLock
Specifies the Remote/Local state of the instrument
:TCPip:CONTrol?
Returns the control connection port number
:ERRor?
Returns the error number and error string
:GROup
(Group commands do NOT apply to N678xA SMU)
:CATalog?
Returns the groups that have been defined
:DEFine (@chanlist)
Group multiple channels to create a single output
:DELete <channel>
Removes the specified channel from a group
:ALL
Ungroups all channels
:PASSword:FPANel:RESet
Resets the front panel lock password to zero
:REBoot
Returns the unit to its power-on state
:VERSion?
Returns the SCPI version number
TRIGger
:ACQuire
(Acquire commands only on N676xA, N678xA SMU and Option 054)
[:IMMediate] (@chanlist)
Triggers the measurement immediately
:CURRent
[:LEVel] <NRf>, (@chanlist)
Sets the current trigger level
:SLOPe POSitive | NEGative, (@chanlist)
Sets the current trigger slope
Quick Reference 1
Keysight N6700 User’s Guide 21
SCPI Command
Description
TRIGger (continued)
|TRANsient<1-4> | VOLTage<1-4>, (@chanlist)
:TOUTput[:ENABle] <Bool>, (@chanlist)
Enables measurement triggers to be sent to a digital port pin
:VOLTage
[:LEVel] <NRf>, (@chanlist)
Sets the voltage trigger level
:SLOPe POSitive | NEGative, (@chanlist)
Sets the voltage trigger slope
:ELOG
[:IMMediate] (@chanlist)
Triggers the external data log immediately
:SOURce BUS|EXTernal|IMMediate|PIN<1-7>, (@chanlist)
Sets the external data log trigger source
:TRANsient
[:IMMediate] (@chanlist)
Triggers the output immediately

Common Commands

Command
Description
Command
Description
*CLS
Clear status
*RDT?
Return output channel descriptions
*ESE <NRf>
Standard event status enable
*RST
Reset
*ESR?
Return event status register
*SAV <NRf>
Saves an instrument state
*IDN?
Return instrument identification
*SRE <NRf>
Set service request enable register
*LRN
Returns a sequence of SCPI commands
*STB?
Return status byte
*OPC
Enable "operation complete" bit in ESR
*TRG
Trigger
*OPT?
Return option number
*TST?
Performs self-test, then returns result
:SOURce BUS | CURRent<1-4> | EXTernal | PIN<1-7>
:SOURce BUS | EXTernal | IMMediate | PIN<1-7> | TRANsient<1-4>, (@chanlist)
Sets the measurement trigger source
Sets the output trigger source
*RCL <NRf> Recalls a saved instrument state *WAI Waits until all device commands are done
1 Quick Reference
22 Keysight N6700 User’s Guide

*RST Settings

CAL:STAT
OFF
SENS:ELOG:CURR:RANG:AUTO
OFF
CURR
0.08 or MIN
SENS:ELOG:FUNC:CURR
ON
CURR:LIM
MAX
SENS:ELOG:FUNC:CURR:MINM
OFF
CURR:LIM:COUP
ON
SENS:ELOG:FUNC:VOLT
OFF
CURR:LIM:NEG
MIN
SENS:ELOG:FUNC:VOLT:MINM
OFF
CURR:MODE
FIX
SENS:ELOG:PER
0.1
CURR:PROT:DEL
0.02
SENS:ELOG:VOLT:RANG:AUTO
OFF
CURR:PROT:DEL:STAR
SCH
SENS:FUNC
“VOLT”
CURR:RANG
MAX
SENS:FUNC:VOLT
ON
CURR:SLEW
9.9E+37
SENS:FUNC:VOLT:INP
MAIN
CURR:SLEW:MAX
ON
SENS:SWE:POIN
1024 or 4883
CURR:TRIG
MIN
SENS:SWE:OFFS:POIN
0
DIG:OUTP:DATA
0
SENS:SWE:TINT
20.48E−6
DISP:VIEW
METER1
SENS:SWE:TINT:RES
RES20
INIT:CONT:TRAN
OFF
SENS:VOLT:RANG
MAX
LIST:COUN
1
SENS:VOLT:RANG:AUTO
OFF
LIST:CURR
MIN
SENS:WIND
RECT
LIST:DWEL
0.001
STEP:TOUT
FALSE
LIST:STEP
AUTO
TRIG:ACQ:CURR
MIN
LIST:TERM:LAST
OFF
TRIG:ACQ:CURR:SLOP
POS
LIST:TOUT:EOST
OFF
TRIG:ACQ:TOUT
OFF
LIST:VOLT
MIN
TRIG:ACQ:VOLT
MIN
OUTP
OFF
TRIG:ACQ:VOLT:SLOP
POS
OUTP:COUP
OFF
TRIG:ELOG:SOUR
BUS
OUTP:DEL:FALL
0
TRIG:TRAN:SOUR
BUS
OUTP:DEL:RISE
0
VOLT
MIN
OUTP:PMOD
VOLT
VOLT:BWID
LOW
OUTP:TMOD
LOWZ
VOLT:LIM
MAX
OUTP:PROT:COUP
OFF
VOLT:LIM:COUP
ON
OUTP:PROT:DEL
0.02
VOLT:LIM:NEG
MIN
OUTP:PROT:OSC
ON
VOLT:MODE
FIX
OUTP:PROT:WDOG
OFF
VOLT:PROT:DEL
0
OUTP:REL:POL
NORM
VOLT:PROT:REM
MAX
POW:LIM
MAX
VOLT:PROT:REM:NEG
MIN
RES 0 VOLT:RANG
MAX
RES:STAT
OFF
VOLT:SLEW
9.9E+37
SENS:CURR:RANG
MAX
[SOUR:]VOLT:TRIG
MIN
SENS:CURR:RANG:AUTO
OFF
CURR:PROT:STAT
LIST:TOUT:BOST
OFF
OFF
SENS:FUNC:CURR
TRIG:ACQ:SOUR
OFF
BUS
SENS:CURR:CCOM
ON
VOLT:SLEW:MAX
ON
2 Installation
General Information ....................................................................... 24
Inspecting the Unit ......................................................................... 25
Installing the Unit ........................................................................... 26
Connecting the Line Cord .............................................................. 30
Connecting the Outputs ................................................................. 31
Remote Sense Connections ........................................................... 36
Parallel Connections ...................................................................... 38
Series Connections ......................................................................... 40
Additional Load Considerations ..................................................... 42
Connecting the Auxiliary Voltage Measurement Input ................. 44
This chapter describes how to install your power system. It discusses rack mounting and line cord connections.
This chapter also discusses how to connect your load to the output terminals. It discusses what you need to know about wire sizes and how to compensate for voltage drops in the load leads. It describes various loads configurations and how to connect the output terminals in series and parallel.
Before installing the instrument, check the list under “Items Supplied” and verify that you have received these items with your instrument. If anything is missing, please contact your nearest Keysight Sales and Support Office.
2 Installation
24 Keysight N6700 User’s Guide

General Information

Models

Keysight Model
Description

Options

Mainframe Options
Description Power Module Options
N6700B / N6701A / N6702A 400 W / 600 W / 1200W MPS Mainframe - without power modules N6710B / N6711A / N6712A Build-to-order Modular Power System – mainframe with installed power modules N6731B / N6741B 50 W / 100 W 5 V DC Power Module N6732B / N6742B 50 W / 100 W 8 V DC Power Module N6733B / N6743B / N6773A 50 W / 100 W / 300 W 20 V DC Power Module N6734B / N6744B / N6774A 50 W / 100 W / 300 W 35 V DC Power Module N6735B / N6745B / N6775A 50 W / 100 W / 300 W 60 V DC Power Module N6736B / N6746B / N6776A, N6777A 50 W / 100 W / 300 W 100 V DC Power Module N6751A / N6752A 50 W / 100 W High-Performance Autoranging DC Power Module N6753A, N6754A / N6755A , N6756A 300 W / 500 W High-Performance Autoranging DC Power Module N6761A / N6762A 50 W / 100 W Precision DC Power Module N6763A, N6764A / N6765A, N6766A 300 W / 500 W Precision DC Power Module N6781A, N6782A, N6784A 20 W Source/Measure Unit (SMU) N6785A, N6786A 80 W Source/Measure Unit (SMU) N6783A-MFG / N6783A-BAT 18 W / 24 W Application-Specific DC Power Module
0L1 English Manual Set. Contains User’s Guide and Service Guide. Also available as part number 5969-2939. 908 Rack Mount Kit. For mounting in a 19-inch EIA rack cabinet. Also available as Model N6709A. FLR Filler module. For mainframes with less than four power modules. Also available as Model N6708A.
054 High-Speed Test Extensions. Includes digitized output measurements and output list capability.
Available for Models N673xB,- 4xB,-5xA, -7xA. Included with Models N676xA, N678xA SMU, and N6783A.
NOTE 1
760
761 UK6 Commercial calibration with test results data 1A7 ISO 17025 calibration certificate 2UA 200 microampere measurement range with output disconnect relays. Only on Models N6761A, N6762A. J01 Tracking overvoltage protection function. Only available on Models N6752A, N6754A, and N6762A when
Output disconnect/polarity reversal. Disconnects the + and – output and sense terminals. Switches the
+ and – output and sense polarities. Not available on N6741B, N6751A, N6752A, N676xA, or N678xA.SMU.
NOTE 1
Output disconnect. Disconnects + and – output and sense terminals. Available for all power modules.
installed in an N6700B, N6701A, or N6702A mainframe.
1
A small AC network is always present across the output terminals.
Installation 2
Keysight N6700 User’s Guide 25

Items Supplied

Mainframe Items
Description
Part Number
Power Module Items

Inspecting the Unit

Power Cord A power cord suitable for your location. Call Keysight Sales & Support Office Ferrite Core for N6700B Installs on power cord to reduce common mode currents. Keysight 9170-2131 Digital Connector plug 8-pin connector for connecting signal lines to the digital port. Keysight 1253-6408
Phoenix Contact MC 1,5/8-ST-3,5 Product Reference CD-ROM Includes drivers and documentation. Keysight 5969-2914 Automation-Ready CD-ROM Contains Keysight IO Libraries Suite. Keysight E2094N Quick Reference Guide Contains quick reference information. Keysight 5969-2950 T-10 Torx tool Torx tool for installing or removing power modules. Keysight 8710-2416
8 A Output Connector plug One 8 A, 8-pin connector plug for connecting power and sense
leads. Only used in N678xA SMU.
12 A Output Connector plug One 12 A, 4-pin connector plug for connecting power and sense
leads. Used in all except N6731B, N6741B, N6753A-N6756A, N6763A-N6766A, N6773A, N678xA SMU.
20 A Output Connector plug One 20 A, 4-pin connector plug for connecting power and sense
leads. Only used in N6731B, N6741B, N6754A, N6756A, N6764A, N6766A, N6773A.
50 A Output Connector plug One 50 A, 2-pin connector plug for connecting power leads. Only
used in N6753A, N6755A, N6763A, N6765A.
AUX Measurement connector plug
Small Sense Jumpers Two small jumpers for local sensing at the output connector.
Large Sense Jumpers Two large jumpers for local sensing at the output connector. Only
Sense Connector A 4-pin connector for connecting sense leads. Wires (p/n 5185-
Module Cal. Certificate A certificate of calibration referenced to the serial number. N/A
A 2-pin connector plug for connecting the auxiliary measurement inputs. Only used in N6781A and N6785A.
Used in all except N6731B, N6741B, N6753A-N6756A, N6763A­N6766A, N6773A, N678xA SMU.
used in N6731B, N6741B, N6754A, N6756A, N6764A, N6766A, N6773A.
8847) are used for local sensing. Only used in N6753A, N6755A, N6763A, N6765A.
Keysight 1253-6408
Phoenix Contact MC 1,5/8-ST-3,5
Keysight 1253-5826
Phoenix Contact MSTB 2,5/4-STF
Keysight 1253-6211
Phoenix Contact PC 4/4-ST-7,62
Keysight 1253-7187
Molex 39422-0002
Keysight 1253-8485
Phoenix Contact FMC 1,5/2-ST-3,5
Keysight 8120-8821
Phoenix Contact EPB 2-5(1733169)
Keysight 0360-2935
Phoenix Contact 3118151
Keysight 1253-5830
Phoenix Contact MC 1,5/4-ST-3,5
When you receive your power system, inspect it for any obvious damage that may have occurred during shipment. If there is damage, notify the shipping carrier and nearest Keysight Sales and Support Office immediately. Refer to www.keysight.com/find/assist
.
Until you have checked out the power system, save the shipping carton and packing materials in case the unit has to be returned. Check the list under “Items Supplied” and verify that you have received these items with your instrument. If anything is missing, please contact your nearest Keysight Sales and Support Office.
2 Installation
26 Keysight N6700 User’s Guide

Installing the Unit

Safety Considerations

Environment

WARNING
Do not operate the instrument in the presence of flammable gasses or fumes

Cleaning

WARNING
SHOCK HAZARD To prevent electric shock, unplug the unit before cleaning.

Power Module Channel Assignment

lowest
lowest
This power system is a Safety Class 1 instrument, which means it has a protective earth terminal. That terminal must be connected to earth ground through a power source equipped with a ground receptacle.
Refer to the Safety Summary page at the beginning of this guide for general safety information. Before installation or operation, check the power system and review this guide for safety warnings and instructions. Safety warnings for specific procedures are located at appropriate places throughout this Guide.
The environmental conditions of the instrument are documented in Appendix A. Basically, the instrument should only be operated indoors in a controlled environment.
The dimensions of your instrument as well as an outline diagram are given in Appendix A. A fan cools the power system by drawing air through the sides and exhausting it out the side and back. The instrument must be installed in a location that allows sufficient space at the sides and back of the unit for adequate air circulation.
Use a dry cloth or one slightly dampened with water to clean the external case parts. Do not use detergent or chemical solvents. Do not attempt to clean internally.
The slot location of a power module in the mainframe determines the channel assignment of the module. When viewed from the rear, the module next to the GPIB connector is always output channel one. Numbering continues sequentially to the left, from 1 up to 4.
Double-wide power modules are assigned the number of the numbered slot in which is installed. For example, if a double-wide module is installed in slots 3 and 4, it is assigned channel number 3.
Grouped power modules, those that are connected in parallel and have been configured or grouped to act as a single higher-power channel, are assigned the channel number of the
numbered slot of the group.
Installation 2
Keysight N6700 User’s Guide 27

Power Module Installation

NOTE
CAUTION
Tools required:
Firmware Note:
Step 1.
Step 2.
The information in this section applies if you have purchased an N6700 mainframe without the power modules installed, or if you are adding a power module to the mainframe.
Turn the mainframe off and disconnect the power cord before installing or removing power modules. Observe all standard electrostatic discharge precautions before handling electronic components.
Modules must be installed next to one another, starting with slot 1. Do not leave any empty slots between modules, otherwise the power system will not operate. Any remaining unused slots must have a filler module installed to ensure proper cooling. Do not install filler modules between power modules.
T10 Torx driver;
Small flat-blade screwdriver
Newer power modules can only be installed in N6700 mainframes with the latest firmware. Refer to the “Updates” section in the front of this manual for more information. If your mainframe has the latest firmware version, install the power module. If not, download and install the latest version firmware from the web.
Remove the blower cover. Remove the screws from the top and sides of the blower cover. Tilt the cover up and slide it out.
To install a power module, align the module over the pins and push it down onto the mainframe connector.
2 Installation
28 Keysight N6700 User’s Guide
Step 3.
Step 4.

Rack Installation

CAUTION
You cannot use support rails for rack mounting your instrument.
Tools required:
Step 1.
2a
3
4
5
6
1
2b
2c
2d
1
Use a T10 Torx driver and install the screws at each end of the power module. Because the RFI strips apply upward pressure, continue pushing down on the module until the screws are tight.
Replace the blower cover when finished. Carefully fit the spring clips under the lip of the power modules.
Support rails would block the airflow needed for cooling. Use Rack Mount kit (Option 908) to rack mount your instrument. The Rack Mount Kit is also available by ordering part number N6709A.
Keysight N6700 MPS mainframes can be mounted in a 19-inch EIA rack cabinet. They are designed to fit in one rack-unit (1U) of space. Do not block the air intake and exhaust at the sides of the unit, or the exhaust at the rear of the unit.
Phillips driver, T22 Torx driver, T10 Torx driver
Install eight clip-nuts on the rack frame (2 in each corner) where your instrument will be located.
Installation 2
Keysight N6700 User’s Guide 29
Step 2.
Step 3.
Step 4.
Step 5.
Step 6.

Bench Installation

CAUTION
Do not block the air intake and exhaust at the sides, or the exhaust at the rear of the unit. Refer to the outline diagram in Appendix A.

400 Hz Operation

Redundant Ground Requirement
Power Factor
Install the two front ears and the two rear extender supports on the instrument as shown in the figure. Use six M3 x 8mm screws (a) for the front ears and four M3 x 6mm screws (b) for the extender supports. If the standard extender supports are either too short or too long, use the longer supports (c). Cut the supports if required (d).
Install the two rear ears on the back of the instrument rack as shown in the figure. Use four plain 10-32 screws to install the rear ears.
Slide the instrument into the rack, making sure that the rear extender supports are aligned inside the rear ears.
Attach the front ears to the front of the instrument rack using the four dress 10-32 screws provided.
This is optional. Insert a plain 10-32 screw through the slot of the rear ear and extender support. Attach it with a clip-nut. Note that this will prevent the unit from being slid out of the front of the rack.
Minimum clearances for bench operation are 2 inches (51 mm) along the sides and back.
At 400 Hz AC input operation, the leakage current of the unit exceeds
3.5 mA. This requires the installation of a permanent, redundant ground from the instrument chassis to earth ground. This ensures that ground will always be connected and that any leakage current will be diverted to ground. Refer to the Service Guide for installation instructions.
Refer to Appendix A for power factor statistics at 400 Hz operation.
2 Installation
30 Keysight N6700 User’s Guide

Connecting the Line Cord

WARNING
FIRE HAZARD Use only the power cord that was supplied with your instrument. Using other types of power cords may cause overheating of the power cord, resulting in fire.
SHOCK HAZARD The power cord provides a chassis ground through a third conductor. Be certain that your power outlet is of the three­conductor type with the correct pin connected to earth ground.
Keysight N6702A Mainframe Note:
NOTE
Connect the power cord to the IEC 320 connector on the rear of the unit. If the wrong power cord was shipped with your unit, contact your nearest Keysight Sales and Support Office.
The AC input on the back of your unit is a universal AC input. It accepts nominal line voltages in the range of 100 VAC to 240 VAC. The frequency can be 50 Hz, 60 Hz, or 400 Hz.
nominal 100-120 VAC cannot supply enough current to power the N6702A mainframe when it is operated at its full rated power. Nevertheless, the N6702A can be connected to an AC mains circuit rated at nominal 100-120 VAC. In this case, internal circuits will limit the power available to modules to 600 W. As a result of this power limiting, the current drawn from the AC mains will be < 15 A, so that standard 100-120 VAC mains circuits will not be overloaded.
The detachable power cord may be used as an emergency disconnecting device. Removing the power cord will disconnect AC input power to the unit.
Standard AC mains circuits rated at
Loading...
+ 98 hidden pages
