Keurig SS-700BK, SS-700, B66 User Manual

INSTRUCTION BOOKLET
Single Serve Brewing System
For your safety and continued enjoyment of this product, always read the instruction book carefully before using.
SS-700
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock and/or injury to persons, including the following:
1. READ ALL INSTRUCTIONS.
2. Do not touch hot surfaces. Use handles and knobs.
3. To protect against electric shock, do not place cord, plug, or base unit in water or other liquids.
4. Close supervision is necessary when any appliance is used by or near children.
5. Always unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been dropped or damaged in any manner. Return appliance to the nearest Cuisinart repair, or electrical or mechanical adjustment.
7. The use of accessory attachments not recommended by Cuisinart may cause injuries, fire, electric shock or injury to persons.
8. Do not use outdoors.
9. Do not let cord hang over edge of table or counter, or touch hot surfaces.
Repair Center for examination,
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. Always fill water reservoir first, then plug cord into the wall outlet. To disconnect, turn controls to Off, then remove plug from wall outlet.
12. Do not use appliance for other than intended use.
13. Do not lift handle to open the lid of the brewer while brewing is in progress.
14. Do not overfill the water reservoir with water. Use ONLY WATER in this appliance! Do not put any other liquids or foods in the water reservoir except as instructed in the cleaning instructions in this guide.
15. Do not clean drip tray with cleansers, steel wool pads, or other abrasive materials.
16. WARNING: TO REDUCE THE RISK OF
FIRE OR ELECTRIC SHOCK, DO NOT REMOVE THE BASE PANEL. NO USER-SERVICEABLE PARTS ARE INSIDE. REPAIR SHOULD BE DONE ONLY BY AUTHORIZED PERSONNEL.
SAVE THESE INSTRUCTIONS.
FOR HOUSEHOLD USE ONLY
WARNING: RISK OF FIRE OR ELECTRIC SHOCK
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of fire or electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
2
SPECIAL CORD SET INSTRUCTIONS
A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
Longer extension cords are available and may be used if care is exercised in their use.
If a long extension cord is used, the marked electrical rating of the extension cord must be at least as great as the electrical rating of the appliance. The extension cord should be a grounding-type 3-wire cord, and the longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.
If a grounding-type outlet is not available, an adapter, shown in Figure B, may be obtained so that a 2-slot wall outlet can be used with a 3-prong plug. As shown in Figure C, the adapter must be grounded by attaching its grounding lug under the screw of the outlet cover plate.
NOTE: Do not remove the grounding prong.
CAUTION: Before using an adapter, it must be determined that the outlet cover plate screw is properly grounded. If in doubt, consult a licensed electrician. Never use an adapter unless you are sure it is properly grounded.
Note: Use of an adapter is not permitted in Canada.
NOTICE
If you have a diecast metal unit, for your protection, it is equipped with a 3-conductor cord set that has a molded 3-prong grounding-type plug, and should be used in combi­nation with a prop­erly connected grounding-type outlet as shown in Figure A.
Circuit Grounding Conductor Connected Properly
Grounding Prong
Grounding Lug
Cover Mounting Screw
Cover of Grounded Outlet Box
A.
B.
Adapter
C.
WARNING
RISK OF FIRE OR ELECTRIC SHOCK
IMPORTANT UNPACKING INSTRUCTIONS
1. Place the box on a large, sturdy, flat surface.
2. Remove the instruction book and any other literature.
3. Turn the box so that the backside of the Brewer is down and slide the coffeemaker from the box.
4. After the Brewer has been removed, place the box out of the way and take the pcaking materials away.
5. Remove the polybag covering the Brewer.
We suggest you save all packing materials in the event that future shipping of the machine is needed. Keep all plastic bags away from children.
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY
3
Contents
Important Safeguards . . . . . . . . . . . . . . . . . . . . . 2
Important Unpacking Instructions . . . . . . . . . . . . 3
The Quest for the Perfect Cup . . . . . . . . . . . . . . 5
Features and Benefits. . . . . . . . . . . . . . . . . . . . . 6
Set-Up & First Brew . . . . . . . . . . . . . . . . . . . . . . 8
Setting Up Your Brewer . . . . . . . . . . . . . . . . . . . 8
Charcoal Water Filter . . . . . . . . . . . . . . . . . . . . . 9
Brewing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Hot Water/Rinse . . . . . . . . . . . . . . . . . . . . . . . . 12
Brewing with the My K-Cup
®
Accessory. . . . . . 13
Stopping the Brew Process . . . . . . . . . . . . . . . 14
Adding Water . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Purging the Brewer . . . . . . . . . . . . . . . . . . . . . . 14
Programming . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting the Clock . . . . . . . . . . . . . . . . . . . . . 15
Programming On/Off Features . . . . . . . . . . 15
Programming Brew Temperature . . . . . . . . 17
Programming Your Brew Size . . . . . . . . . . . 18
Cleaning & Maintenance . . . . . . . . . . . . . . . . . . 18
Cleaning External Parts . . . . . . . . . . . . . . . . 18
®
Cleaning the My K-Cup
Cleaning the K-Cup
Filter . . . . . . . . . . . 18
®
Holder . . . . . . . . . . . . 19
Cleaning the Water Reservoir and Lid. . . . . 19
De-Scaling Your Brewer . . . . . . . . . . . . . . . 20
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 21
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4
The Quest
for the Perfect
Cup of Coffee
Element 1:
WATER
Any hot beverage is made up primarily of water. Often overlooked, the quality of the water is as important as the quality of the coffee, tea or cocoa. A good rule of thumb is that if your water doesn’t taste good from the tap, it won’t taste any better in your beverage. That’s why the Cuisinart Serve Brewing System has added a charcoal water filter that removes chlorine, bad tastes and odors, for the purest cup every time.
®
Single
Element 2:
COFFEE
While the bulk of the liquid is water, all of the flavor should be from the coffee, tea or cocoa. To achieve the same great quality you receive at coffee bars, you need to use the same quality ingredients. By using the K-Cup most premium brands on the market, you can be assured that you’re getting the finest, freshest gourmet product with every cup you brew. If you choose to use your own coffee in the included My K-Cup at their freshest.
®
, brought to you by some of the
®
, make sure all your ingredients are
Element 3:
GRIND
The grind of coffee and cocoa, or the refinement of your tea leaves, is critical for proper flavor extraction. With the pre-measured, pre-ground ingredients found in every K-Cup that it’ll brew perfectly each and every time, locking in maximum flavor and freshness.
®
, you can rest easy knowing
Element 4:
PROPORTION
No matter which cup size you choose, the Cuisinart® Single Serve Brewing System, working in conjunction with K-Cup time. When grinding your own coffee and using it in the included My K-Cup amount of ground coffee that corresponds to the number of ounces being brewed.
®
, always produces the perfect cup every
®
, remember to add the
5
Features and Benefits
2
1
7
3
4
1a
1. Charcoal Filter Holder
1a. Charcoal Water Filter
2. Water Reservoir Lid
Removes for easy filling.
3. Removable 80-oz. Water Reservoir
Offers extra-large capacity, eliminating the need for frequent refills.
4. Removable Drip Tray Plate
Allows extra space for travel mugs.
6
5. Drip Tray
6. Drip Tray Base
7. Removable K-Cup
®
Holder
8. Handle
Easy grip prevents slips.
9. Brewing Head
10. Brewing Chamber
Holds My K-Cup
®
or the K-Cup® Holder.
11. Housing
5
8
9
10
11
6
12
13
14
15
16
17
18
19
20
22
23
12. Control Panel
13. Menu Button
14. Up Button (
15. Down Button (
)
)
16. Brew Button
17. Rinse Button
18. Hot Water Button
19. My K-Cup
®
Compartment
Conveniently stores My K-Cup
20. My K-Cup
®
Reusable
Coffee Filter
21. Power Cord
(not shown)
22. Power Switch
(located rear side of Brewer)
23. Coffee Scoop
®
.
7
Set-Up & First Brew
IMPORTANT: Do not attempt to use
your Cuisinart System until it has been set up for its first use as outlined below.
®
Single Serve Brewing
NOTE: If Brewer has been exposed to temperatures below freezing, wait at least two hours for Brewer to reach room temperature before brewing. An extremely cold Brewer will not operate.
Setting Up Your Brewer
6. The Brewer will automatically fill the
1. Unwrap cord and plug the Brewer into
a grounded outlet. Make sure to remove packing tape, clear plastic sticker from control panel, and sticker from water reservoir. Also be sure to remove the polybag from the My
®
K-Cup
located in the compartment
on the right side of the brewer.
2. Place a large cup or mug (10 oz.
minimum) on the drip tray.
3. Remove lid from reservoir, then lift
reservoir straight up and away from the Brewer. Wash the reservoir with warm soapy water.
4. Fill reservoir with water to the max fill line
and return with lid to unit (see figure 1).
Note: It is normal to see small amounts
Water Reservoir Lid
Water Reservoir
Once the water is heated, OPEN HEAD
7. When the control panel displays
internal tank with water and heating will begin. This will take approximately 4 minutes. During the heating period, NOT READY will be displayed on the control panel (see figure 2).
Heating Mode
figure 2
of water dripping into the water reservoir during this and subsequent heatings.
will be displayed.
OPEN HEAD (see figure 3), open and close the brewing chamber. READY and brew size icons will be displayed with the default size shown as a solid mug (see figure 4).
Idle Mode
Ready Mode
figure 1
5. Press the power switch located on the
rear right side of the Brewer. The switch is spring-loaded and will return to original position automatically.
8
figure 3
figure 4
8. Making sure your mug is in place, press
the Brew button to start a cleansing cycle (unit will dispense approximately 8 oz. of water). The control panel will display BREWING, as well as the factory default brew size (see figure 5). When cycle is complete, dispose of the hot water.
Note: Do not use a K-Cup
®
for this
cycle.
The one-time set-up
process is complete.
Charcoal Water Filter
Your coffeemaker comes with a charcoal water filter that eliminates chlorine, bad tastes and odors from tap water.
Upper Filter Holder
figure 5
5. Flush filter by running fresh water through lower portion of the filter holder.
6. Allow the filter to drain completely.
7. Place the assembled water filter holder into the water reservoir, pushing it down to fit into place (see figure 7).
Water Reservoir Lid
Charcoal Water Filter
PRESS TABS
Lower Filter Holder
figure 6
Inserting the Water Filter
1. Remove the filter and filter holder from the polybags.
2. Soak the filter, fully immersed in cold tap water, for 15 minutes.
3. Remove lower portion of filter holder by pressing the tabs on the sides and pulling apart. Rinse with fresh water.
4. Insert the charcoal filter into the upper filter holder, then attach the lower portion by pressing on tabs and pushing until it locks into place (see figure 6).
assembled Charcoal Water Filter
Water Reservoir
figure 7
Note:
We recommend changing the water filter every 60 days or after 60 uses, and more often if you have hard water. Replacement filters can be purchased in stores, by calling Cuisinart Customer Service, or at www.cuisinart.com.
9
Brewing
1. The control panel will display OPEN HEAD while in idle mode.
2. Place a cup or mug on the drip tray. The drip tray can be removed to accommodate travel mugs.
3. Lift the handle. The brewing chamber will open toward you.
4. Select a K-Cup
Note: Do not remove the foil lid or
puncture the K-Cup
5. Place a K-Cup (see figure 8).
K-Cup Portion Pack
®
Portion Pack®.
®
.
®
in the brewing chamber
6. Lower the handle to close the brewing chamber. When closed completely, the control panel will indicate READY (see figure 9).
Note: If not used within 60 seconds,
the unit will return to Idle mode and OPEN HEAD will be displayed on the control panel. To restart the process, open and close the handle and control panel will display READY again.
Ready Mode
figure 9
figure 8
Caution: There are two sharp
needles that puncture the K-Cup
®
, one above and one below. To avoid risk of injury, do not put your fingers in the K-Cup
®
brewing chamber.
7. All brew size icons will be displayed with the default size shown as a solid mug. To choose a different size, use the or
buttons. Choose from 4-oz. (iced beverage), 6-oz., 8-oz., 10-oz., and 12-oz. brew sizes.
Note: The 8-oz. serving is the factory-
set default brew size. To program your favorite brew size, see Programming Your Brew Size on page 18.
a. Once a size is chosen, press Brew.
Only the Brew button will be lit. The control panel will now display BREWING, as well as the serving size you selected (see figure 10).
10
figure 10
b. To use the iced beverage setting,
place a tall glass filled with ice on the drip tray. Use your favorite K-Cup
®
, select the iced beverage brew size (4 oz.) and press the Brew button. Once brewing is complete, add more ice; add cream and sugar if desired.
Note: There may be a short pause
before the brewing process begins. The entire brew process lasts approximately 1 minute and ends with a burst of air to remove all liquid from the K-Cup
®
.
Caution: There is very hot water in the K-Cup
®
chamber during the brew process. To avoid risk of injury, do not lift the handle or open the K-Cup
®
chamber during the brew
process.
8. Lift the handle, then remove and
dispose of the used K-Cup
®
. Close the
brewing head.
Caution: K-Cup
®
will be hot.
Following the brew, your Brewer will automatically fill and heat in preparation for the next brew. Your Brewer will display NOT READY. When water reaches default temperature, OPEN HEAD will be displayed on the control panel and your unit will return to Idle mode, and will be ready for your next brew.
Enjoy your cup of gourmet
coffee, tea, or hot cocoa!
11
Hot Water/Rinse
Your Brewer is equipped to dispense hot water to make hot chocolate, tea, soup, and more. Your Brewer is also equipped with a Rinse cycle to flush out residual flavors. The Rinse cycle will dispense about 4 oz. of hot water.
Note: We suggest to running the Rinse cycle before using hot water to flush out any residual coffee, tea or hot cocoa flavor.
To Rinse:
1. Place a cup or mug on the drip tray. If you’ve just completed a Rinse or Hot Water cycle, proceed to step 4.
2. Lift the handle. The brewing chamber will open towards you; check to make sure there is no K-Cup
®
inserted.
3. Lower the handle to close the brewing chamber. When closed completely, the control panel will indicated READY.
4. Press Rinse. During the Rinse cycle, only the Rinse button will be lit. The control panel will display the word RINSE (see figure 11).
To make Hot Water:
1. Place a cup or mug on the drip tray.
2. Lift the handle. The brewing chamber
3. Lower the handle to close the brewing
4. All brew-size icons will be displayed with
5. Press Hot Water. While the Hot Water
If you’ve just completed a Rinse or Hot Water cycle proceed to step 4.
will open towards you; check to make sure there is no K-Cup
®
inserted.
chamber. When closed completely, the control panel will indicated READY.
your default size shown as a solid mug. To choose a different size, use the
or
buttons.
cycle is in progress, only the Hot Water button will be lit. The control panel will display the words HOT WATER, as well as the serving size you selected (see figure 12).
figure 11
Following the Rinse cycle, your Brewer
will automatically fill and heat in preparation for the next cycle. Once the heat cycle is completed, the RINSE and HOT WATER buttons will remain lit for one minute. While buttons are lit, you can perform another Rinse cycle or dispense Hot Water without opening the brew chamber.
Note: To BREW directly after a Rinse
cycle open the brewing head, insert a K-Cup and brew as normal.
12
figure 12
Following the cycle, your Brewer will
automatically fill and heat in preparation for the next cycle. After the heating cycle is completed, you can perform a Rinse or another Hot Water cycle immediately for up to one minute. The RINSE and HOT WATER buttons will be lit. After this time the unit will return to Idle mode and OPEN HEAD will be displayed.
Note: To BREW directly after a Hot
Water cycle open the brewing head, insert a K-Cup and brew as normal.
Brewing with the My K-Cup® Reusable Coffee Filter
The Cuisinart® Single Serve Brewing System comes with a My K-Cup filter, which allows you to use your own ground coffee. The dishwasher-safe, My
®
K-Cup
conveniently stores in the easy-
open compartment.
1. Open the storage compartment located on the right side of the Brewer by pressing the finger indent. Remove the My K-Cup
®
(see figure 13).
®
reusable coffee
7. Remove the K-Cup
®
holder from the brewing chamber by pulling toward you. (If you would like, store the K-Cup holder in the My K-Cup
®
storage
®
compartment.)
8. Drop the assembled My K-Cup
®
into the brewing chamber. (No need to snap it into place). See figure 15.
®
figure 13
My K-Cup
Lid
Filter
Basket
Holder
figure 14
2. Disassemble the My K-Cup® by turning the lid from the holder in a counter­clockwise direction. Remove the filter basket from the holder (see figure 14).
3. Wash the My K-Cup
®
lid, filter basket and holder in warm soapy water prior to use, making sure to rinse and dry thoroughly. All My K-Cup
®
parts are
dishwasher safe.
4. Insert the filter basket into the holder.
5. Fill the filter basket with ground coffee making sure not to fill past the top of the mesh. Adjust the amount to your personal preference. Do not tamp the grinds. Ensure there are no grinds remaining on the upper rim of the filter basket. Turn the lid clockwise to seal.
6. Raise the handle and the brew chamber will open toward you.
figure 15
CAUTION: There are two sharp
needles that puncture the K-Cup
®
, one above and one below. To avoid risk of injury, do not put your fingers in the K-Cup
®
brewing chamber.
9. Follow Brewing instructions on page 10.
10. Following brewing raise the handle and remove the My K-Cup
as the My K-Cup
11. Disassemble the My K-Cup
®
. Use caution
®
will be hot.
®
by turning the lid from the holder in a counter­clockwise direction. Remove the filter basket from the holder, discard the grounds and rinse out the filter basket and holder.
12. Replace the K-Cup
®
holder, ensuring the arrow on K-Cup
®
rim aligns with the arrow on the brewing chamber. Gently push the K-Cup holder to snap into place (see figure 16).
figure 16
13
Stopping the Brew Process
If for any reason you need to stop brewing after the process has started, press the power switch on the rear right side of the Brewer to turn the Brewer off. The flow of coffee, tea or hot cocoa will stop, the heater will shut off, and the blue lights illuminating the control panel and reservoir will turn off.
Note: You may get less coffee, tea or hot cocoa in your cup during your next brew. In order for your next brew to be the volume you have selected, we recommend that you perform a rinse cycle after a terminated brew.
Adding Water
The Control Panel will indicate when the water level in your reservoir is low or if the Reservoir has been removed by displaying the words “ADD WATER”. The blue light in the Reservoir will also blink when water needs to be added. When “ADD WATER” is displayed, the Brewer will not allow you to brew.
Purging the Brewer
If your Brewer has not been used for more than one week, we suggest purging the water from the inner tank.
1. If there is water in the reservoir, discard
2. Be sure the Brewer is turned on. Raise
3. When the control panel displays READY,
4. Repeat this process two more times to
the water, then rinse and refill with fresh water. Place the reservoir back on the Brewer and replace the lid. (If there is no water in the reservoir, simply fill.)
and lower the handle on the Brewer without inserting a K-Cup
dispense 12 oz. of hot water by selecting the 12-oz. cup size and hot water.
completely replace the water in the inner tank.
®
.
The Water Reservoir can be filled in two ways:
1. Lift off the Reservoir Lid and pour water directly into the Reservoir while it is still attached to the Brewer, then replace the Lid.
2. Remove the Reservoir from Brewer by first removing the Lid from the Reservoir then lifting the Reservoir straight up and away from Brewer. Fill with water, place the Reservoir back on the Brewer, and replace the Lid.
IMPORTANT: Do not remove the Water Reservoir during the brewing process.
14
Programming
Setting the Clock
Setting the clock is optional. When the clock is set, the time will appear on the control panel. Note: You must set the clock if you plan on using the ONOFF TIME SET programming feature.
1. Press the Menu button. Programming options will appear on the control panel with CLOCK flashing. The word OFF will appear at the top of the control panel to indicate that the clock is not set (see figure 17).
Set Hours Set Minutes
figure 17
2. Press or hold the through the hours until you have reached the appropriate hour. Be sure the PM indicator is on if a PM time is desired.
3. Press or hold the through the minutes until you have reached the desired minutes.
4. When you have reached the correct time, press the Menu button to set the time. Continue pressing Menu to scroll through the remaining programming functions to exit the programming mode.
5. The correct time should now be displayed on top of the control panel (see figure 18).
button to scroll
button to scroll
Clock set in READY Mode
figure 18
Note: Depending upon the Brewer’s
current mode, other icons will be displayed as well.
Note: If power is interrupted to the Brewer, the clock will need to be reset. Follow the procedure above to reset the clock.
Programming On/Off Features
The Brewer provides three ways for you to enjoy gourmet coffee, tea or hot cocoa on your own schedule. It will take the Brewer approximately 3½ minutes to warm up from room temperature.
1. Leave it on all the time.
The Brewer can be left on all the time so
that it is always ready to brew a fresh cup of gourmet coffee, tea or hot cocoa.
To turn the Brewer off at any time,
simply press the power switch located on the right side of the Brewer.
Note: Although the clock remains on, if
set, you cannot brew a cup of coffee, tea or hot cocoa if the brewer is off. Press the power switch to restore power to the Brewer. You will have to wait for the water to heat up before the Brewer is ready to brew.
15
2. Set the Brewer to AUTO OFF.
This will automatically shut the Brewer
off after a specified period of time from the last brew.
a. Press the Menu button until AUTO
OFF SET flashes (see figure 19).
Set Hours
figure 19
e. To turn off the AUTO OFF feature,
press the Menu button until AUTO OFF SET flashes. Press the
button to advance one hour at a time until OFF appears. Press the Menu button to scroll through the remaining programming functions to exit the programming mode.
3. Program your Brewer for a specific ON and/or OFF TIME.
By programming your Brewer to turn on
each morning, you will never have to wait for the Brewer to warm up in order to brew a gourmet cup of coffee.
Note: To use this feature, the clock
must be set to the correct time.
Also Note: the brewer must be turned
off for the On Time to function.
b. Press or hold the
button to advance one hour at a time, up to 9 hours.
c. After setting the desired AUTO OFF
TIME, press the Menu button to set the AUTO OFF TIME. Continue pressing Menu to scroll through the remaining programming functions to exit the programming mode.
d. AUTO OFF SET will be displayed on
the control panel, indicating that it has been successfully set (see figure 20).
AUTO OFF Set in Ready Mode
figure 20
Set Hours Set Minutes
figure 21
a. Press the Menu button until ON
TIME SET flashes (see figure 21).
b. Press or hold the
or button to scroll through the hours and minutes to your desired ON TIME. The button is used for hours and the button is used for minutes.
c. After setting the desired ON TIME,
press the Menu button once to save your selected ON TIME. You will now be in the OFF TIME SET MODE (see figure 22).
Note: Depending upon the
Brewer’s current mode, other icons will be displayed as well.
16
g. To turn off the ONOFF TIME SET
feature, press the Menu button until ONOFF TIME SET flashes. Use the button to scroll through. The control panel will display OFF after 11 pm.
Note:
The AUTO OFF timer and the OFF TIME programming options operate independently. If both are set, the unit will turn off at whichever time comes first.
Set Hours Set Minutes
figure 22
d. If you want to set an OFF TIME,
Use the or buttons as above. If not, continue to Step e.
e. To complete the process, press the
Menu button to set the OFF TIME. Continue pressing to scroll through the remaining programming options to exit the programming mode.
f. The ON TIME and OFF TIME
functions operate independently from one another. The control panel will display ON TIME SET if the ON TIME has been set. The control panel will display OFF TIME SET if the OFF TIME has been set and the control panel will display ONOFF TIME SET if both the On and Off times have been set (see figure 23).
ON OFF TIME SET
in Ready Mode
figure 23
Note: Depending upon the
Brewer’s current mode, other icons will be displayed as well.
Programming Brew Temperature
The Brewer brews at a pre-set temperature of 192°F. If you prefer a cooler cup of coffee, hot water, tea, or cocoa, you may adjust this temperature down by 5 degrees. Simply follow the instructions below.
1. Press the Menu button until BREW TEMP flashes on the control panel (see figure 24).
Decrease Temp
Increase
Temp
figure 24
2. The initial set temperature of 192°F will be displayed at the top of the control panel. Use the the temperature one degree at a time.
Note: If at maximum temperature (192°F), only the
button will work, and if at
minimum (187°F) temperature, only the
arrow will work.
3. Once you have reached your optimal brew temperature, press the Menu button to set your default brew temperature. Continue pressing Menu to scroll through the remaining
to lower or to raise
17
programming options to exit the programming mode.
Note: At high altitudes (over 5,000 feet) use the temperature adjustment to lower the temperature.
Programming Your Brew Size
The Brewer’s default brew size preset
is 8 oz. The default brew size lets you choose the brew size most often used.
To change the default brew size to your
desired brew size:
1. Press the Menu button until BREW SIZE flashes (see figure 25).
2. Use
3. Once the desired default brew
The control panel will display your
selected default brew size.
Note: You can always select another
size prior to brewing.
or buttons to select your
default brew size.
size is selected, press the Menu button to set your default brew size and exit the programming mode.
Cleaning & Maintenance
Cleaning External Parts
We recommend regular cleaning of the Brewer’s external components.
1. Never immerse the Brewer in water or other liquids. The housing and other external components may be cleaned with a soapy, damp, non-abrasive cloth.
2. To remove the drip tray, simply slide it toward you, keeping it level at all times in order to prevent spills. The drip tray and drip tray plate are dishwasher safe.
Cleaning the My K-Cup® Reusable Coffee Filter
1. Open the storage compartment located on the right side of the Brewer by pressing the finger indent. Remove the My K-Cup
2. Disassemble the My K-Cup the lid from the holder in a counter­clockwise direction. Remove the filter basket from the holder (see figure 26).
3. Wash the My K-Cup and holder in warm soapy water making sure to rinse and dry thoroughly. All My K-Cup
®
.
®
by turning
®
lid, filter basket
®
parts are dishwasher safe.
18
Set Smaller
Brew Size
Set Larger Brew Size
figure 25
figure 26
Cleaning the K-Cup® Holder
1. The K-Cup® holder is top-shelf dishwasher safe (use low temperature cycles in the dishwasher). To remove, lift the handle to open the brewing chamber. Grasp the top of the K-Cup holder and pull towards you. After cleaning, replace the K-Cup
®
holder,
being sure to align the arrow on the
®
K-Cup
holder rim with the arrow on the
brewing chamber.
2. Cleaning the Funnel – The Funnel can be removed from the K-Cup Holder by pulling on it until it pops off (see figure
27). The Funnel is top-rack dishwasher safe. To replace it, just snap it back onto the K-Cup Holder Assembly.
®
Cleaning the Water Reservoir & Lid
Neither the reservoir lid nor the reservoir should be put into the dishwasher. Clean them with a damp, soapy, non-abrasive cloth and rinse thoroughly. Do not dry the inside of the water reservoir with a cloth, as lint may remain.
Caution: Rinse the water reservoir thoroughly after cleaning to ensure that no cleaners or cleaning solutions remain in this area, as they may contaminate the Brewer’s water supply.
figure 28
figure 27
3.
Cleaning the Exit Needle – The Exit Needle is located on the inside bottom of the K-Cup Holder Assembly. Should a clog arise due to coffee grinds, it can be cleaned using a paper clip or similar tool. Remove K-Cup Holder (as shown in figure 27). Insert the paper clip (see figure
28) to loosen the clog and push it out.
CAUTION: There are sharp needles
that puncture the K-Cup above and below. To avoid risk of injury, do not put your fingers in the K-Cup Assembly Housing.
figure 29
19
De-Scaling your Brewer
Mineral content in water varies from place to place. Depending on the mineral content of the water in your area, calcium deposits or scale may build up in your Brewer. Though scale is non-toxic, it can hinder Brewer performance. De-scaling your Brewer will help maintain the heating element and other Brewer parts that come in contact with water.
For optimal performance, de-scale your Brewer every 3 to 6 months. It is possible for calcium deposits to build up faster, making it necessary to de-scale more often.
This Brewer is equipped with sensors to detect when scale buildup is interfering with the performance of the Brewer. When this is detected, DE-SCALE will be displayed on the control panel (see figure 30), at which point you should promptly de-scale. However, even if DE-SCALE is not displayed, it is still advisable that you de-scale your Brewer regularly.
Follow these steps to de-scale your unit:
1. Empty the reservoir.
2. Disable the AUTO OFF and OFF TIME
3. Making sure there is no K-Cup in the
4. Place a large mug on the drip tray and
5. Repeat the hot water process until ADD
6. Let the Brewer stand for at least four
7. Rinse the water reservoir thoroughly
8. Run another Hot Water cycle. Discard
9. Repeat hot water process until ADD
10. You may need to perform additional
Note: If DE-SCALE is still displayed on
features.
brewing chamber, fill the reservoir with 60 oz. of undiluted white vinegar.
run a Hot Water cycle. Select the 12 oz. brew size. Discard contents of mug.
WATER is displayed on the control panel and the reservoir lights will flash.
hours while still on.
and fill with fresh water.
contents of large mug.
WATER is displayed on the control panel and the reservoir lights will flash.
Hot Water cycles if you detect any residual vinegar taste.
the control panel after completing the procedure, repeat the de-scaling procedure above.
figure 30
Note: Though the Brewer will continue to function even when DE-SCALE is displayed, not de-scaling at that point could damage the Brewer. If this occurs, DE-SCALE will begin to flash on the control panel to alert you to potential damage if you do not de-scale immediately.
20
Troubleshooting
Problem: Solution:
Brewer does not have power.
Brewer will not brew. Every once in a while an air bubble may get trapped in the water path. Lift off the
Chlorine or mineral taste in coffee.
Doesn’t brew a full cup. Every once in a while an air bubble may get trapped in the water path. Lift off the
The time is not displayed on the LCD control panel.
Brewer shuts off, or turns on, automatically.
The blue light in the water reservoir is flashing.
Coffee is too weak or watery.
Plug Brewer into an independent outlet.
Make sure the Brewer is securely plugged in.
Plug into a different outlet.
Reset your home’s circuit breaker.
Confirm the power has been turned on and the LCD is illuminated.
reservoir, then put it back into place.
Turn off and unplug the brewer for 30 seconds or more. When you plug the brewer back in, be sure to turn the power back on.
Make sure the water reservoir is properly in place, and perform a Rinse cycle.
After placing the K-Cup® in the K-Cup® Holder, make sure the handle is pushed down securely and the LCD control panel reads READY. The Brew, Hot Water, and Rinse buttons will be illuminated. Then press any of the lit buttons.
If the LCD control panel indicates ADD WATER, check to make sure the water reservoir is properly filled. If not, add water. If so, make sure the water reservoir is properly seated in its base.
If the LCD control panel indicates ADD WATER even after refilling and checking the base, contact Customer Service at 1-800-726-0190.
The exit needle may be clogged (refer to page 19).
Consider using bottled water, filtered water or the Cuisinart Charcoal Water Filter.
reservoir, then put it back into place.
Turn off and unplug the brewer for 30 seconds or more. When you plug the brewer back in, be sure to turn the power back on.
The exit needle may be clogged (refer to “Cleaning & Maintenance” page 18).
Clean the K-Cup® holder brewing chamber (refer to “Cleaning & Maintenance” page 18).
Make sure the water reservoir is properly in place, and perform a Rinse cycle.
De-scale the Brewer (refer to page 20).
If you have repeated the de-scale procedure two times and it is still only brewing a partial cup, contact Customer Service at 1-800-726-0190.
You must set the clock (refer to page 15) in order for the time to be displayed on the LCD.
If power is interrupted to the Brewer, you will need to re-set the clock (refer to page 15).
Make sure the Auto Off and the On/Off time features have not been set. To do this, press the Menu button and scroll through the programming options. OFF should be displayed for Auto Off timer and On/Off. If OFF is not displayed, you must reset (refer to page 15).
This indicates the water level in the reservoir is low and water must be added (refer to page 14) in order to brew a full cup.
Reduce the brew size for a stronger-tasting cup of coffee (refer to “Programming Your Brew Size” on page 18). Try an Extra Bold K-Cup®. It has 30% more ground coffee in each portion pack.
and buttons,
21
WARRANTY
LIMITED THREE-YEAR WARRANTY
This warranty is available to consumers only. You are a consumer if you own a Cuisinart® Single Serve Brewing System that was purchased at retail for personal, family or household use. Except as otherwise required under applicable law, this warranty is not available to retailers or other commercial purchasers or owners.
We warrant that your Cuisinart® Single Serve Brewing System will be free of defects in materials and workmanship under normal home use for 3 years from the date of original purchase.
We recommend that you visit our website, www.cuisinart.com for a fast, efficient way to complete your product registration. However, product registration does not eliminate the need for the consumer to maintain the original proof of purchase in order to obtain the warranty benefits. In the event that you do not have proof of purchase date, the purchase date for purposes of this warranty will be the date of manufacture.
If your Cuisinart® Single Serve Brewing System should prove to be defective within the warranty period, we will repair it, or if we think necessary, replace it. To obtain warranty service, simply call our toll-free number, 1-800-726-0190, for additional information from our Customer Service Representatives, or send the defective product to Customer Service at Cuisinart, 150 Milford Road, East Windsor, NJ 08520.
To facilitate the speed and accuracy of your return, please enclose $10.00 for shipping and handling of the product.
Please pay by check or money order (California residents need only supply proof of purchase and should call 1-800-726-0190 for shipping instructions).
NOTE: For added protection and secure handling of any Cuisinart product that is being returned, we recommend you use a traceable, insured delivery service. Cuisinart cannot be held responsible for in-transit damage or for packages that are not delivered to us. Lost and/or damaged products are not covered under warranty. Please be sure to include your return address, daytime phone number, description of the product defect, product model number (located on bottom of product), original date of purchase, and any other information pertinent to the product’s return.
Your Cuisinart® Single Serve Brewing System has been manufactured to the strictest specifications and has been designed for use with the authorized accessories and replacement parts.
This warranty expressly excludes any defects or damages caused by accessories, replacement parts, or repair service other than those that have been authorized by Cuisinart.
This warranty does not cover any damage caused by accident, misuse, shipment or other ordinary household use.
This warranty excludes all incidental or consequential damages. Some states do not allow the exclusion or limitation of these damages, so these exclusions may not apply to you.
CALIFORNIA RESIDENTS ONLY:
California law provides that for In-Warranty Service, California residents have the option of returning a nonconforming product (A) to the store where it was purchased or (B) to another retail store that sells Cuisinart products of the same type.
The retail store shall then, at its discretion, either repair the product, refer the consumer to an inde­pendent repair facility, replace the product, or refund the purchase price less the amount directly attributable to the consumer’s prior usage of the product. If the above two options do not result in the appropriate relief to the consumer, the con­sumer may then take the product to an indepen­dent repair facility if service or repair can be eco­nomically accomplished. Cuisinart and not the consumer will be responsible for the reasonable cost of such service, repair, replacement, or refund for nonconforming products under warranty.
California residents may also, according to their preference, return nonconforming products directly to Cuisinart for repair, or if necessary, replacement, by calling our Consumer Service Center toll-free at 1-800-726-0190.
Cuisinart will be responsible for the cost of the repair, replacement, and shipping and handling for such products under warranty.
BEFORE RETURNING YOUR CUISINART PRODUCT
If you are experiencing problems with your Cuisinart product, we suggest that you call our Customer Service Center at 1-800-726-0190 before returning the product to be serviced. If servicing is needed, a representative can confirm whether the product is under warranty and direct you to the nearest service location.
Important: If the nonconforming product is to be serviced by someone other than Cuisinart’s Authorized Service Center, please remind the servicer to call our Customer Service Center at 1-800-726-0190 to ensure that the problem is properly diagnosed, the product serviced with the correct parts, and the product is still under warranty.
22
23
Coffeemakers
Food
Processors
Toasters
Blenders
Cookware
Ice Cream
Makers
Cuisinart offers an extensive assortment of top quality products to make life in the
kitchen easier than ever. Try some of our other countertop appliances and
cookware, and Savor the Good Life
®
.
www.cuisinart.com
trademark of the Conair Corporation
Any trademarks or service marks of third parties used herein are the trademarks or service marks of their respective owners.
Keurig, the Cup and Star logo, Keurig Brewed, Quiet-Brew Technology, and K-Cup are trademarks or registered trademarks of Keurig, Incorporated. Covered by U.S. patents numbered 7,165,488; 7,398,726; 7,347,138; 7,377,162 and 7,360,418; and other U.S. and foreign patents and patents pending.
©2010 Conair Corporation
Cuisinart
®
is a registered
Cuisinart
150 Milford Road
East Windsor, NJ 08520
Printed in China
10CE13186
G IB-9178B
Version no :
IB-9178B
Fold Size:
Material:
Coating:
Color (Front):
(Back):
228MMX152MM Saddle Stitiched 24PP
Cover: 157gsm matt art Paper
Inside: 120gsm gloss art Paper Gloss Varinishing In Cover
Cover: 4C(CMYK)+1C(BK)
Inside: 1C(BK)+1C(BK)
Date: APR-12-2010
Hugo Description
PDF version :
Hugo Code :
Color Series:
Remark: Quality request(1)
SS700 IB-9178B(0,1) BOOK
SMT0022IB-1B1
Non
Co-ordinator : Scias Liu
Operator : Kin
Loading...
