Operating instruction
Counting scales
KERN CXB/CXP
Version 1.7
10/2014
GB
D-72336 Balingen
Fax: +49-[0]7433-9933-149
CXB/CXP-BA-e-1417
KERN CXB/CXP
Counting scales
GB
Version 1.7 10/2014
Operating instruction
Table of Contents
1 Technical data ................................................................................................ 4
2 Declaration of conformity ............................................................................. 7
3 Appliance overview ....................................................................................... 8
3.1 Overview of display ................................................................................................................ 10
3.1.1 Display weight ........................................................................................................................... 11
3.1.2 Display reference weight .......................................................................................................... 11
3.1.3 Display quantity ......................................................................................................................... 11
3.1.4 Battery charge status display .................................................................................................... 11
3.2 Keyboard overview ................................................................................................................. 12
4 Basic Information (General) ........................................................................ 14
4.1 Proper use ............................................................................................................................... 14
4.2 Improper Use........................................................................................................................... 14
4.3 Warranty .................................................................................................................................. 14
4.4 Monitoring of Test Resources ............................................................................................... 15
5 Basic Safety Precautions ............................................................................ 15
5.1 Pay attention to the instructions in the Operation Manual ................................................ 15
5.2 Personnel training .................................................................................................................. 15
6 Transport and storage ................................................................................. 15
6.1 Testing upon acceptance ...................................................................................................... 15
6.2 Packaging ................................................................................................................................ 15
7 Unpacking, Setup and Commissioning ..................................................... 16
7.1 Installation Site, Location of Use .......................................................................................... 16
7.2 Unpacking ............................................................................................................................... 16
7.2.1 Setup ........................................................................................................................................ 17
7.2.2 Scope of delivery ...................................................................................................................... 18
7.3 Mains connection ................................................................................................................... 18
7.4 Battery power supply ............................................................................................................. 18
7.5 Initial Commissioning ............................................................................................................ 18
7.5.1 Start-up ..................................................................................................................................... 19
7.5.2 Turn off – CXB models ............................................................................................................. 19
7.5.3 Turn off/standby mode – CXP models ..................................................................................... 19
7.5.4 Balance zero display ................................................................................................................. 19
7.5.5 Stability display ......................................................................................................................... 19
7.6 Adjustment with external weight .......................................................................................... 20
7.6.1 Adjustment of models CXP ...................................................................................................... 20
7.6.2 Adjustment of models CXB ...................................................................................................... 21
7.6.3 Adjustment of models CXB_M ................................................................................................. 23
8 Verification ................................................................................................... 24
8.1 Adjustment key and seals ...................................................................................................... 25
9 Parts counting .............................................................................................. 26
9.1 Determination of the reference weight by weighing ........................................................... 26
9.2 Numeric entering of the reference weight ........................................................................... 27
CXB/CXP-BA-e-1417 2
USER
9.3 Automatic reference optimization ......................................................................................... 27
9.4 Store/call reference weight .................................................................................................... 28
9.4.1 Save .......................................................................................................................................... 28
9.4.2 Call-up ...................................................................................................................................... 29
9.5 Count with tolerance control - Fill to target ......................................................................... 29
9.5.1 Set tolerance value for target number of pieces ....................................................................... 29
9.5.2 Set tolerance value for target weight ........................................................................................ 30
10 Taring ............................................................................................................ 31
10.1 Determination of the tare weight by weighing ..................................................................... 31
10.2 Numerical input of tare (PRE-TARE) ..................................................................................... 32
10.3 Numerical input of tare (PRE-TARE) ..................................................................................... 35
11 Add up........................................................................................................... 37
11.1 Add up “number parts" .......................................................................................................... 37
11.2 Add up “weight" ..................................................................................................................... 38
11.3 Delete stored values ............................................................................................................... 39
12 Application menu ......................................................................................... 39
12.1 Navigation in the menu .......................................................................................................... 39
12.2 Menu overview [
] ........................................................................................................... 40
13 Configurations menu ................................................................................... 41
13.1.1 Display background illumination ........................................................................................... 41
13.1.2 Setting the display speed ..................................................................................................... 42
14 Data output ................................................................................................... 43
14.1 RS 232C interface ................................................................................................................... 43
14.2 Description of interface ......................................................................................................... 44
14.2.1 Example: Setting an output format ....................................................................................... 48
15 Service, maintenance, disposal .................................................................. 49
15.1 Cleaning................................................................................................................................... 49
15.2 Service, maintenance ............................................................................................................. 49
15.3 Disposal ................................................................................................................................... 49
16 Instant help ................................................................................................... 50
17 Appendix ASCII CODE table ....................................................................... 51
CXB/CXP-BA-e-1417 3
1 Technical data
Weighing plate, stainless
CXB models:
KERN CXB 3K0.2 CXB 6K0.5 CXB 15K1 CXB 30 K2
Readability (d) 0.2 g 0.5 g 1 g 2 g
Weighing range (max) 3 kg 6 kg 15 kg 30 kg
Reproducibility 0.2 g 0.5 g 1 g 2 g
Linearity ± 0.4 g ± 1.0 g ± 2 g ± 4 g
Stabilization time 2 sec. 2 sec. 2 sec. 2 sec.
Recommended adjustment
weight, not added (class)
Weighing unit g g g g
Minimum piece weight 0.1 g 0.2 g 0.5 g 1 g
Warming up time (operat-
ing temperature)
Reference quantity freely selectable
Net weight (kg) 4 kg
Permissible ambient
condition
Humidity of air 15% - 85% (non-condensing)
steel
Dimensions of the housing
(B x D x H)
Mains connection Mains adapter 230 V, 50/60 Hz ; 9 V DC balance, 800 mA
3 kg (M1) 5 kg (M1) 15 kg (M1) 30 kg (M1)
30 min
-10° C to 40° C
300 x 225 mm
300 x 330 x 110 mm
Rechargeable battery Without backlight display:
Service life c. 200 hours / loading time ca. 8 hrs.
With backlight display:
Operating time ca. 60h. / loading time ca. 8 hrs.
CXB/CXP-BA-e-1417 4
KERN
CXB
3K1NM
CXB
6K2NM
CXB
15K5NM
CXB
30K10NM
Weighing plate, stainless
Readability (d) 1 g 2 g 5 g 10 g
Weighing range (Max) 3 kg 6 kg 15 kg 30 kg
Minimum load (Min) 20 g 40 g 100 g 200 g
Verification value (e) 1 g 2 g 5 g 10 g
Reproducibility 1 g 2 g 5 g 10 g
Linearity 2 g 4 g 10 g 20 g
Verification class III III III III
Stabilization time 2 sec. 2 sec. 2 sec. 2 sec.
Recommended adjustment
weight, not added (class)
Weighing unit kg kg kg kg
Minimum piece weight 100 mg 200 mg 500 mg 1 g
Warming up time (operat-
ing temperature)
Reference quantity freely selectable
Net weight (kg) 4 kg
Permissible ambient
condition
Allowable air humidity 15% - 85% (non-condensing)
steel
Dimensions of the housing
plastic material (B x D x H)
Voltage 220-240 V, 50/60 Hz;
3 kg (M1) 6 kg (M1) 15 kg (M1) 30 kg (M1)
10 min
-10° C bis 40° C
300 x 225 mm
300 x 330 x 110
Rechargeable battery Without backlight display:
CXB/CXP-BA-e-1417 5
Service life ca. 200Std. / loading time ca. 8 Std.
with back light:
Operating time ca. 60Std. / loading time ca. 8 Std.
CXP models:
Weighing plate, stainless
KERN CXP 30K2 CXP 75K5 CXP 150K10
Readability (d) 2 g 5 g 10 g
Weighing range (max) 30 kg 75 kg 150 kg
Reproducibility 2 g 5 g 10 g
Linearity ± 4 g ± 10 g ± 20 g
Stabilization time 2 sec. 2 sec. 2 sec.
Recommended adjustment
weight, not added (class)
Weighing unit g g g
Minimum piece weight 0.5 g 1 g 2.5 g
Warming up time (operat-
ing temperature)
Reference quantity freely selectable
Net weight (kg) 8.9 kg
Permissible ambient
condition
Allowable air humidity 15 % - 85 % (non-condensing)
steel
Dimensions of the housing
plastic material (B x D x H)
Voltage 230 V (AC)
20 kg (M1) 50 kg (M1) 100 kg (M1)
30 min
-10° C to 40° C
400 x 300 mm
400 x 300 x 100 mm (platform)
290 x 140 mm (terminal)
Rechargeable battery Without backlight display:
Service life c. 200 hours / loading t ime ca. 16 hrs.
With backlight display:
Operating time ca. 60h. / loading time ca. 16 hrs.
with backlight + RS 232:
Operating time ca. 56h. / loading time ca. 16 hrs.
Data interface RS 232C
