Operating instruction
Analytical balance
KERN ABT
Version 1.2
03/2013
#
GB
D-72336 Balingen
Fax: +49-[0]7433-9933-149
ABT-BA-e-1312
2
KERN ABT
Analytical balance
Table of Contents
1 Technical data ................................................................................................ 4
2 Declaration of conformity ............................................................................. 7
3 Keyboard and display overview ................................................................... 8
3.1 Keyboard overview .................................................................................................. 8
3.2 Overview of display ................................................................................................10
4 Basic Information (General) ........................................................................ 11
4.1 Proper use ...............................................................................................................11
4.2 Improper Use ..........................................................................................................11
4.3 Warranty ..................................................................................................................11
4.4 Monitoring of Test Resources ...............................................................................12
5 Basic Safety Precautions ............................................................................ 12
5.1 Pay attention to the instructions in the O per at i on M anual ..................................12
5.2 Personnel training ..................................................................................................12
6 Transport and storage ................................................................................. 12
6.1 Testing upon acceptance .......................................................................................12
6.2 Packaging / return transport ..................................................................................13
7 Unpacking, Setup and Commissioning ..................................................... 15
7.1 Installation Site, Locat ion of Use ..........................................................................15
7.2 Unpacking ...............................................................................................................15
7.2.1 Scope of delivery ...................................................................................................................... 16
7.2.2 Installation ................................................................................................................................. 17
7.3 Mains connection ...................................................................................................18
7.4 Connection of peripheral devices .........................................................................18
7.5 Initial Commissioning ............................................................................................19
7.5.1 Turning On the Power............................................................................................................... 19
8 Adjustment ................................................................................................... 20
8.1 Automatic adjustment via PSC ..............................................................................20
8.1.1 PCS function ON/OFF .............................................................................................................. 21
8.2 Automatic adjustment via Clock-CAL ...................................................................22
8.2.1 Setting the time for Clock-CAL ................................................................................................. 23
8.3 Adjustment via preset process ..............................................................................24
8.3.1 Selecting default adjustment method ....................................................................................... 24
8.3.2 Default setting: Adjustment with internal weight ....................................................................... 25
8.3.3 Default setting: Adjustment test with internal weight ................................................................ 25
8.3.4 Default setting: Adjustment test with external weight ............................................................... 26
8.4 Carrying out alternative adjustment methods ......................................................27
8.4.1 Adjustment with internal weight ................................................................................................ 27
8.4.2 Adjustment test with internal weight ......................................................................................... 28
8.4.3 Adjustment test with external weight ........................................................................................ 29
9 Verification ................................................................................................... 30
10 ISO/GLP log .................................................................................................. 31
10.1 Set t ing the log printout of your adjustment data .................................................31
10.2 Bal ance ID Number Setting ....................................................................................32
10.3 Set t ing the date printout ........................................................................................33
GB
Version 1.2 03/2013
Operating instruction
ABT-BA-e-1312
3
10.3.1 Printout Date and Time, without weight value ...................................................................... 33
11 Basic Operation ........................................................................................... 34
11.1 Weighing .................................................................................................................34
11.2 Taring ......................................................................................................................34
11.3 Changi ng t he display ..............................................................................................35
11.4 Changi ng r eadabi lity ..............................................................................................36
11.5 Under f l oor weighing ...............................................................................................37
12 The menu ...................................................................................................... 38
12.1 Changi ng set tings ..................................................................................................38
12.2 How to change settings .........................................................................................38
12.3 Cal l up menu ...........................................................................................................39
12.4 Sel ecting the menu .................................................................................................40
12.5 Menu overview ........................................................................................................41
12.6 Menu Lock ...............................................................................................................44
12.7 Reset t ing the menu ................................................................................................44
12.8 Set t ings control display .........................................................................................45
13 Description of individual functions ............................................................ 46
13.1 Stability filter ...........................................................................................................46
13.1.1 Standard mode ..................................................................................................................... 46
13.1.2 Anti-convection mode ........................................................................................................... 47
13.1.3 High-stability Mode ............................................................................................................... 47
13.1.4 Apportioning mode ............................................................................................................... 48
13.2 St andst ill display ....................................................................................................49
13.3 Auto Zero .................................................................................................................50
13.4 Setting date .............................................................................................................51
13.
5 Sett i ng time .............................................................................................................52
13.6 Capaci t y display .....................................................................................................53
14 Application Functions ................................................................................. 54
14.1 Par t s count ing ........................................................................................................54
14.2 Per cent det er m i nat ion ............................................................................................55
14.3 Densi t y determination ............................................................................................56
14.3.1 Density determination of solids ............................................................................................ 56
14.3.2 Determining density of liquids .............................................................................................. 57
14.4 Auto Print ................................................................................................................59
14.5 Add up mode ...........................................................................................................60
14.6 Reci pe m ode ...........................................................................................................62
15 Data output ................................................................................................... 64
15.1 RS 232C int er f ace ...................................................................................................64
15.2 Dat a For m at s ...........................................................................................................64
15.3 Rem ot e cont r ol instructions ..................................................................................65
15.4 St andar d Set t i ngs ...................................................................................................66
15.5 User Settings ..........................................................................................................67
15.5.1 Communication speed settings ............................................................................................ 68
15.5.2 Delimiter settings .................................................................................................................. 68
15.5.3 Parity settings ....................................................................................................................... 68
15.5.4 Stop bit settings .................................................................................................................... 69
15.5.5 Input-output data format settings ......................................................................................... 69
15.5.6 Handshake settings .............................................................................................................. 69
16 Service, maintenance, disposal .................................................................. 70
16.1 Cleaning ..................................................................................................................70
2 Service, m ai nt enance .............................................................................................70
16.
16.3 Disposal...................................................................................................................70
17 Instant help ................................................................................................... 71
ABT-BA-e-1312
4
1 Technical data
Weighing plate, stainless
KERN ABT 100-5M ABT 120-4M
Readability (d) 0.01 mg 0.1 mg
Weighing range (max) 101 g 120 g
Minimum load (Min) 1 mg 10 mg
Verification value (e) 1 mg 1 mg
Verification class I I
Reproducibility 0.05 mg 0.1 mg
Linearity ± 0.15 mg ± 0.2 mg
Stabilization time 10 sec 3 sec
Adjustment weight internal
Weighing units
(calibrated appliances)
Smallest part weight for piece
counting
Reference quantities at
piece counting
steel
Dimensions of the housing (B
x D x H)
Dimensions
Glass wind screen [mm]
1 mg 1 mg
10, 20, 50,100
217 x 356 x 338
Weighing room 168 x172 x223
g, ct
ø 80mm
Net weight (kg) 7
Permitted environmental
condition
+10° C to +30° C
Humidity of air max. 80 % relative (not condensing)
AC adapter (Primary) AC 100 -240 V, 400 mA 50/60Hz
Rated electric power supply DC 12 V, 1 A
Pollution Degree 2
Overvoltage Category Category II
Altitude Up to 2000 m
Installation Site device may only be used indoors
ABT-BA-e-1312
5
Weighing plate, stainless
KERN ABT 220-4M ABT 320-4M
Readability (d) 0.1 mg 0.1 mg
Weighing range (max) 220 g 320 g
Minimum load (Min) 10 mg 10 mg
Verification value (e) 1 mg 1 mg
Verification class I I
Reproducibility 0.1 mg 0.1 mg
Linearity ± 0.2 mg ± 0.2 mg
Stabilization time 3 sec
Adjustment weight internal
Weighing units
(calibrated appliances)
Smallest part weight for
piece counting
Reference quantities at
piece counting
steel
Dimensions of the housing
(B x D x H)
Dimensions
Glass wind screen [mm]
1 mg 0,1 mg
10, 20, 50,100
217 x 356 x 338
Weighing room 168 x172 x223
g, ct
ø 80mm
Net weight (kg) 7
Permitted environmental
condition
+10° C to +30° C
Humidity of air max. 80 % relative (not condensing)
AC adapter (Primary) AC 100 -240 V, 400 mA 50/60Hz
Rated electric power supply DC 12 V, 1 A
Pollution Degree 2
Overvoltage Category Category II
Altitude Up to 2000 m
Installation Site device may only be used indoors
ABT-BA-e-1312
6
Weighing plate, stainless
KERN ABT 120-5DM ABT 220-5DM
Readability (d) 0.01/0.1 mg 0.01/0.1 mg
Weighing range (max) 42 g/120 g 82 g/220 g
Minimum load (Min) 1 mg 1 mg
Verification value (e) 1 mg 1 mg
Verification class I I
Reproducibility ±0.02/ 0.1 mg ±0.05/ 0.1 mg
Linearity ± 0.05/0.2 mg ± 0.1/0.2 mg
Stabilization time 3sec./10 sec.
Adjustment weight internal
Weighing units
(calibrated appliances)
Smallest part weight for piece
counting
Reference quantities at
piece counting
steel
Dimensions of the housing (B
x D x H)
Dimensions
Glass wind screen [mm]
10, 20, 50,100
217 x 356 x 338
Weighing room 168 x172 x223
g, ct
1 mg
ø 80mm
Net weight (kg) 7
Permitted environmental
condition
+10° C to +30° C
Humidity of air max. 80 % relative (not condensing)
AC adapter (Primary) AC 100 -240 V, 400 mA 50/60Hz
Rated electric power supply DC 12 V, 1 A
Pollution Degree 2
Overvoltage Category Category II
Altitude Up to 2000 m
Installation Site device may only be used indoors
ABT-BA-e-1312
7
2 Declaration of conformity
KERN & Sohn GmbH
D-72322 Balingen-Frommern
E-Mail: info@kern-sohn.de
Tel: 0049-[0]7433- 9933-0
Internet: www.kern-sohn.de
D
Konformitätserklärung
Wir erklären hiermit, dass das Produkt, auf das sich diese Erklärung bezieht,
mit den nachstehenden Normen übereinstimmt.
GB
Declaration of
conformity
We hereby declare that the product to which this declaration refers conforms
with the following standards.
CZ
Prohlášení o
shode
Tímto prohlašujeme, že výrobek, kterého se toto prohlášení týká, je v souladu
s níže uvedenými normami.
E
Declaración de
conformidad
Manifestamos en la presente que el producto al que se refiere esta
declaración está de acuerdo con las normas siguientes
F
Déclaration de
conformité
Nous déclarons avec cela responsabilité que le produit, auquel se rapporte la
présente déclaration, est conforme aux normes citées ci-après.
I
Dichiarazione di
conformitá
Dichiariamo con ciò che il prodotto al quale la presente dichiarazione si riferisce è conforme alle norme di seguito citate.
NL
Conformiteitverklaring
Wij verklaren hiermede dat het product, waarop deze verklaring betrekking
heeft, met de hierna vermelde normen overeenstemt.
P
Declaração de
conformidade
Declaramos por meio da presente que o produto no qual se refere esta
declaração, corresponde às normas seguintes.
PL
Deklaracja
zgodności
Niniejszym oświadczamy, że produkt, którego niniejsze oświadczenie dotyczy,
jest zgodny z poniższymi normami.
RUS
Заявление о
соответствии
Мы заявляем, что продукт, к которому относится данная декларация,
соответствует перечисленным ниже нормам.
Signature
Datum
27.03.2013
Ort der Ausstellung
Place of issue
72336 Balingen
Albert Sauter
KERN & Sohn GmbH
Geschäftsführer
Managing director
KERN & Sohn GmbH, Ziegelei 1, D-72336 Balingen, Tel. +49-[0]7433/9933-0
Fax +49-[0]7433/9933-149, E-Mail: info@kern-sohn.com, Internet: www.kern-sohn.com
Postfach 4052
Fax: 0049-[0]7433-9933-149
Declaration of conformity
EC-Konformitätserklärung EC-Declaration of -Conformity
Déclaration de conformité EC-Declaración de Conformidad
ECEC-Dichiarazione di conformit à EC-Conformiteitverklaring
EC- Declaração de conformidade EC- Prohlášení o shode
EC-Deklaracja zgodności EC-Заявление о соответствии
Electronic Balan ce: KERN ABT
2004/108/EC EN 61326-1:2006
2006/95/EC EN 61010-1: 2010
Date
ABT-BA-e-1312
Signatur
8
3 Keyboard and display overview
Designa-
tion
Pressed once and released
PC)
ABT 320-4M
digit is only possible for models with a
ABT 100-5M
ABT 220-5DM
3.1 Keyboard overview
In weighing mode:
Key
[ON/OFF]
Switches between the operation and standby modes.
[CAL]
[TARE] Tare or set weight display to zero
Invokes adjustment or menu
selection.
[UNIT] Changing the display
Issue of weighing value to
[PRINT]
external appliances (printer,
ABT 120-4M
ABT 220-4M
[1d/10d]
ABT 120-5DM
Keep pressed for abo u t 3 seconds
Switches the key notification buzzer on/off.
Invokes adjustment or menu selection.
Issue of date and time to external appliances.
For verified applications cutting off the last
readout of 0,01 mg.
For all other models the button 1/10d is inoperable.
ABT-BA-e-1312
9
In menu:
Designa-
tion
Keep pressed for abo u t 3 se-
conds
Key
Pressed once and released
[ON/OFF]
Back to menu Return to weighing mode
[CAL]
Menu selection
[TARE]
[UNIT] Entering numeric values Increases the numeric value of flashing digit by 1.
Parameter selection
Storing settings
[PRINT] Entering numeric values. Shifts flashing digit.
[1d/10d]
No effect.
ABT-BA-e-1312
10
3.2 Overview of display
Display
Designation
Description
ting during menu item selection
Appears during adjustment. Flashes prior to start of automatic
vise necessity of adjustment.
Number symbol
Indicates numeric value entry.
locked.
Asterisk
Indicates that the displayed numeric value is not a mass value.
Add-on symbol
Indicates set-up of Add-on mode.
Communication
symbol
Is lit up during communication with external appliances via RS232C cable. Shown when communication functions are ON.
Indicates a low battery voltage when using the balance with the
optional battery pack.
Auto Print symbol
Indicates set-up of the Auto Print function.
Standby mark
Appears during standby status of balance.
bol
play.
Capacity display
Units display
Standstill display
Weight symbol
Menu symbol
Battery symbol
▼
Inverse triangle sym-
Indicates that the weighed value is stable. Highlights current set-
adjustment.
Appears during parameter selection for adjustment. Blinks to ad-
Appears during menu selection. Always shown when the menu is
Illuminates as part of the solid specific gravity measurement dis-
ABT-BA-e-1312
11
4 Basic Information (General)
4.1 Proper use
The balance you purchased is intended to determine the weighing value of material
to be weighed. It is intended to be used as a “non-automatic“ balance, i.e. the material to be weighed is manually and carefully placed in the centre of the weighing
plate. As soon as a stable weighing value is reached the weighing value can be read.
4.2 Improper Use
Do not use balance for dynamic add-on weighing procedures, if small amounts of
goods to be weighed are removed or added. The “stability compensation“ installed in
the balance may result in displaying an incorrect measuring value! (Example: Slowly
draining fluids from a container on the balance.)
Do not leave permanent load on the weighing plate. This may damage the measuring system.
Impacts and overloading exceeding the stated maximum load (max) of the balance,
minus a possibly existing tare load, must be strictly avoided. Balance may be damage by this.
Never operate balance in explosive environment. The serial version is not explosion
protected.
The structure of the balance may not be modified. This may lead to incorrect weighing results, safety-related faults and destruction of the balance.
The balance may only be used according to the described conditions. Other areas of
use must be released by KERN in writing.
4.3 Warranty
Warranty claims shall be voided in case
• Our conditions in the operation manual are ignored
• The appliance is used outside the described uses
• The appliance is modified or opened
• Mechanical damage or damage by media, liquids, natural wear and tear
• The appliance is improperly set up or incorrectly electrically connected
• The measuring system is overloaded
ABT-BA-e-1312
12
4.4 Monitoring of Test Resources
In the framework of quality assurance the measuring-related properties of the balance and, if applicable, the testing weight, must be checked regularly. The responsible user must define a suitable interval as well as type and scope of this test. Information is available on KERN’s home page (www.kern-sohn.com with regard to the
monitoring of balance test substances and the test weights required for this. In
KERN’s accredited DKD calibration laboratory test weights and balances may be
calibrated (return to the national standard) fast and at moderate cost.
5 Basic Safety Precautions
5.1 Pay attention to the instructions in the Operation Manual
Carefully read this operation manual before setup and commissioning, even if you
are already familiar with KERN balances.
5.2 Personnel training
The appliance may only be operated and maintained by trained personnel.
6 Transport and stora ge
6.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the appliance itself when unpacking for possible visible damage.
ABT-BA-e-1312
13
6.2 Packaging / return transport
Keep all parts of the original packaging for a possibly re-
quired return.
Only use original packaging for returning.
Prior to dispatch disconnect all cables and remove
loose/mobile parts.
Reattach possibly supplied transport securing devices.
Secure all parts such as the glass wind screen, the weighing
platform, power unit etc. against shifting and damage.
ABT-BA-e-1312
14
ABT-BA-e-1312
15
7 Unpacking, Setup and Commissioning
7.1 Installation Site, Location of Use
The balances are designed in a way that reliable weighing results are achieved in
common conditions of use.
You will work accurately and fast, if you select the right location for your balance.
Therefore, observe the following for the installation site:
• Operate the device only indoors.
• Place the balance on a firm, level surface;
• Avoid extreme heat as well as temperature fluctuation caused by installing
next to a radiator or in the direct sunlight;
• Protect the balance against direct draughts due to open windows and doors;
• Avoid jarring during weighing;
• Protect the balance against high humidity, vapours and dust;
• Do not expose the device to extreme dampness for longer periods of time.
Non-permitted condensation (condensation of air humidity on the appliance)
may occur if a cold appliance is taken to a considerably warmer environment.
In this case, acclimatize the disconnected appliance for ca. 2 hours at room
temperature.
• Avoid static charge of goods to be weighed or weighing container.
If electro-magnetic fields or static charge occur, or if the power supply is unstable
major deviations on the display (incorrect weighing results) are possible. In that case,
the location must be changed.
7.2 Unpacking
Carefully remove the balance from the packaging, remove plastic cover and setup
balance at the intended workstation.
ABT-BA-e-1312
16
7.2.1 Scope of delivery
Serial accessories:
Balance
Weighing plate
Carrier of weighing plate
Screening ring
Mains adapter
Adapter cable holder
Protective cover
Operating Manual
ABT-BA-e-1312
17
7.2.2 Installation
• Attach the adapter cable holder. Peel
• Carrier of weighing plate, attach
• Level balance with foot screws until
• When the key panel and the display
place the cover over the key panel.
the protective sheet of adhesive of
the adapter cable holder, and stick it
on the back of the balance as shown
in the figure.
weighing plate and circular screen in
order.
the air bubble of the water balance is
in the prescribed circle.
must be protected from dirt and wear,
ABT-BA-e-1312
18
1
7.3 Mains connection
3
4
Power is supplied via the external mains power supply. The stated voltage value
must be the same as the local voltage. Only use original KERN mains power supplies. Using other makes requires consent by KERN.
7.4 Connection of peripheral devices
Before connecting or disconnecting of additional devices (printer, PC) to the data
interface, always disconnect the balance from the power supply.
With your balance, only use accessories and peripheral devices by KERN, as they
are ideally tuned to your balance.
Terminal for external devices:
1 RS -232 interface
2 Mains connector
3 Anti-theft safety device (for chains or other fastenings)
4 Connection earthing terminal
ABT-BA-e-1312
19
7.5 Initial Commissioning
1. Supply power to balance via mains
be used.
2. Actuate the [ON/OFF] key. After all dis-
pears.
3. Pressing the [ON/OFF] key again turns
A warming up time of 4 hours after switching on stabilizes the measuring values.
The accuracy of the balance depends on the local acceleration of gravity.
Strictly observe hints in chapter Adjustment.
7.5.1 Turning On the Power
adapter. After the balance performs a
self check, calibration will be automatically executed. During this process, the
display will change as follows. “CHE 5”,
“CHE 4”...... “CHE 0”, “CHE 2”, “CHE 1”
, “CAL 2 – CAL 0” , “CAL-End”, “oFF”.
This adjustment can be interrupted immediately after switching-on the power
supply by actuating the [ON/OFF]-key.
However, at least one adjustment must
be carried out before the balance can
plays appear, the gram (g) symbol ap-
on the standby symbol and puts the
balance in standby (warm up) status.
Current time (see ch. 13.5) will be displayed.
ABT-BA-e-1312
20
8 Adjustment
As the acceleration value due to gravity is not the same at every location on earth,
each balance must be coordinated - in compliance with the underlying physical
weighing principle - to the existing acceleration due to gravity at its place of location
(only if the balance has not already been adjusted to the location in the factory). This
adjustment process must be carried out for the first commissioning, after each
change of location as well as in case of fluctuating environment temperature. To receive accurate measuring values it is also recommended to adjust the balance periodically in weighing operation.
Observe stable environmental conditions. Stabilisation requires a warm-up period of
1 or 4 hours (for models d = 0.01 mg). Ensure that there are no objects on the
weighing plate.
8.1 Automatic adjustment via PSC
The default setting for balances of the series ABT ("PSC ON") prompts automatic
adjustment via the PSC function.
The moment a change in temperature is detected this function uses the internal tare
weight to carry out fully-automatic adjustment with the help of a temperature sensor.
If PSC is left ON, when there is a temperature change that would influence sensitivity, span calibration executes automatically to maintain the sensitivity of the balance.
Adjustment in weighing mode is carried out automatically under the following conditions:
(1) If a change in environmental temperature (0.5 °C) occurs;
(2) When about four hours has passed since the previous calibration.
(3) When the balance is switched from standby status to weighing mode
and condition (1) or (2) has been met.
(4) When balance was disconnected from the mains.
If one of the above conditions was met in weighing mode, the weight symbol flashes
for about two minutes in order to notify the pending adjustment; afterwards the display will show "PSC run". During operation, the display will automatically change and
the motor sound of the weight loading system is heard. In order to ensure proper
PSC operation, prevent vibrations and air flow. As soon as the display in grams reappears after completing adjustment via PSC, the balance returns to weighing mode.
The sensitivity before and after adjustment is slightly different. Also, no measurements can be made during adjustment. To prevent a start-up of adjustment during a
measuring process you have to actuate the [ON/OFF] key as soon as the weight
symbol starts flashing. This will interrupt automatic adjustment.
ABT-BA-e-1312
21
8.1.1 PCS function ON/OFF
Press the [CAL] key repeatedly until "SettinG" appears.
Press the [TARE] key. The display shows “CAL dEF”.
Actuate the [CAL] key repeatedly until the current "PSC:∗∗" set-
ting appears:
To change the setting, actuate the [TARE] key as soon as
"PSC:∗∗" appears.
You can use the [CAL] key to select between the following set-
tings:
PSC and Clock-CAL may be turned on and off separately. The setting control display
(see ch. 12.6) shows the weight symbol ( ), when PSC or Clock-CAL or both func-
tions are activated.
“PSC-on” Function activated
“PSC-oF” Function deactivated
The current setting is indicated by the standstill display ( ).
Confirm your selection by pressing the [TARE] key
To exit the function, press the [ON/OFF] key.
Brief actuation of ON/OFF key:
Back to previous menu.
Long actuation of ON/OFF key:
Back to weighing mode.
ABT-BA-e-1312
22
8.2 Automatic adjustment via Clock-CAL
(only models ABT 100-5M, ABT 120-5DM, ABT 220-5DM)
With the help of its internal adjusting weight and integrated clock the balance can be
set to carry out automatic adjustment at set times (up to three times daily). ClockCAL is a very convenient function, when calibration reports are desired to be made
for regular calibrations, or when wishing span calibrations during break times to avoid
interruption of measurement work.
The weight symbol blinks for about two minutes as notification of span calibration
before it begins. Automatic adjustment can be stopped by actuating the [ON/OFF]
key during this message.
Clock-CAL function ON/OFF:
Press the [CAL] key repeatedly until "SettinG" appears.
Press the [TARE] key. The display shows “CAL dEF”.
Actuate the [CAL] key repeatedly until the current "tCal:∗∗" setting
appears:
To change the setting, actuate the [TARE] key as soon as
"tCal:∗∗" appears.
You can use the [CAL] key to select between the following set-
tings:
“tCAL-on” Function activated
“tCAL-oF” Function deactivated
The current setting is indicated by the standstill display ( ).
Confirm your selection by pressing the [TARE] key
To exit the function, press the [ON/OFF] key.
Brief actuation of ON/OFF key:
Back to previous menu.
Long actuation of ON/OFF key:
Back to weighing mode.
ABT-BA-e-1312
Loading...
