Keri Systems Keri USB-A User Manual

Keri USB-A Connection and Configuration

Step 1 - Connect the KPC-1 cable to the K-USB.

Step 2 – Plug the USB Connector of the K-USB to any available USB port on the
PC.

Step 3 – Plug the one end of the KPC-1 into the K-USB and the other end into the
black RJ-45 connector (J2) on the NXT controller.

NOTE: The form of the

USB converter may
vary, so the unit you
receive may not be
identical to the one
displayed here.

01576-011 1 of 7

Keri USB-A Connection and Configuration

Step 4 – Connecting the Access Control Hardware

Use the Diagram below and the appropriate hardware Installation Guides to hook up the
remaining hardware.

01576-011 2 of 7

Keri USB-A Connection and Configuration

Step 5 – Software Installation
Driver Installation - Insert the Installation CD, packaged with the K-USB device, into your

computer’s CD-ROM drive. The computer’s operating system automatically detects the Adapter
and asks you how to begin the driver installation. For Windows XP, select Install the software

automatically. For Windows Vista or 7, select Locate and install driver software.
NOTE: If the operating system does not auto detect the USB to Ethernet adapter and

install its driver, you must manually install the driver using the CD provided with the
device.

Doors.NET installation

NOTE: Doors.NET utilizes the latest Microsoft .NET framework and service patches.

Depending on the computer, Windows Update may need to be run multiple times before
installing Doors.NET. The installer will install the required .NET patches if needed.
Computers that are not up to date will require additional time for the install.

o Close all running applications.
o Select a Typical Installation to install the Doors.NET Application Server, NXT

Gateway, Administrative Client and the Global Linkage Service.

o Use the Custom installation Option if different components need to be installed.

Step 6 – Software Configuration

 After installation, run the Eclipse License Manger. (Start

Manager)

o In the Installed Components section, select Application Server under Services



Programs  Door. NET  License

o Enter the License Keys for the Application Server if one has been provided and click

on Activate.

01576-011 3 of 7
