KEP P20 User Manual
P20 Printer
User's Manual
990382 08/24/16
KESSLER-ELLIS PRODUCTS
10 Industrial Way East
Eatontown, NJ 07724
800-631-2165 • 732-935-1320
Fax: 732-935-9344
Page 1
Important Safety Information
This section presents important information intended to ensure safe and effective use of this product. Read this section carefully and store it in an accessible
location.
Key to Symbols
The symbols in this manual are identied by their level of importance, as dened
below. Read the following carefully before handling the product.
WARNING:
Warnings must be followed carefully to avoid serious bodily injury.
CAUTION:
Cautions must be observed to avoid minor injury to yourself damage to your
equipment, or loss of data.
Note:
Notes have important information and useful tips on the operation of your
equipment.
Safety Precautions
WARNING:
Shut down your equipment immediately if it produces smoke, a strange odor, or
unusual noise. Continued use may lead to re or shock. Immediately unplug the
equipment and contact your dealer or a service center for advice. Never attempt
to repair this product yourself. Improper repair work can be dangerous.
Never disassemble or modify this product. Tampering with this product may result
in injury, re, or shock.
Be sure to use the specied power source. Connection to an improper power
source may cause re.
Never insert or disconnect the power plug with wet hands. Doing so may result in
severe shock.
Do not place multiple loads on the power outlet (wall outlet). Always supply power
directly from a standard power outlet. Overloading the outlet may lead to re.
Be sure your power cord meets the relevant safety standards and includes a
power-system ground terminal (PE terminal). Otherwise shock may result. Han-
dle the cables with care. Improper handling may lead to re or shock.
Do not use the cables if it they are damaged.
Do not modify or attempt to repair the cables.
Do not place any object on top of the cables.
Avoid excessive bending, twisting, and pulling of the cables.
Do not place cables near heating equipment.
Check that the plug is clean before plugging it in.
Check that the AC inlet is clean before plugging the power connector in it.
Be sure to push the prongs and power connector all the way in.
Use the provided power cable only. Do not use the provided power cable with
any other devices than the specied one. Doing so may lead to re or shock.
Never glue the AC inlet and the power cable together.
Page 2
Regularly remove the power plug from the outlet and clean the base of the
prongs and between the prongs, If you leave the power plug in the outlet for a
long time, dust may collect on the base of the prongs, causing a short and re,
Regularly conrm that the plug and AC inlet are not wet with liquid such as water,
Do not allow foreign matter to fall into the equipment, Penetration by foreign ob-
jects may lead to re,
If water or other liquid spills into this equipment, unplug the power cord immediately, and then contact your dealer or a service center for advice, Continued
usage may lead to re,
Do not use aerosol sprayers containing ammable gas inside or around this
product, Doing so may cause re,
Do not connect a telephone line to the drawer kick-out connector: otherwise the
printer and the telephone line may be damaged,
CAUTION:
Do not connect cables in ways other than those mentioned in this manual,
Different connections may cause equipment damage and burning, Be sure to set
this equipment on a rm, stable, horizontal surface, The product may break or
cause injury if it falls,
Do not use in locations subject to high humidity or dust levels, Excessive humidity
and dust may cause equipment damage or re,
Do not place heavy objects on top of this product, Never stand or lean on this
product, Equipment may fall or collapse, causing breakage and possible injury,
Take care not to injure your ngers on the manual cutter
When you remove printed paper
When you perform other operations such as loading/replacing roll
paper
To ensure safety, unplug this product before leaving it unused for an extended
period,
Caution Labels
The caution labels on the product indicate the following precautions.
CAUTION:
Do not touch the thermal head because it can be very hot after printing,
Restriction of Use
When this product is used for applications requiring high reliability /safety, such as
transportation devices related to aviation, rail, marine, automotive, etc.; disaster
prevention devices; various safety devices, etc.; or functional/precision devices, etc.; you should use this product only after giving consideration to including
fail-safes and redundancies into your design to maintain safety and total system
reliability. Because this product was not intended for use in applications requiring
extremely high reliability /safety, such as aerospace equipment, main communication equipment, nuclear power control equipment, or medical equipment related
to direct medical care, etc., please make your own judgment on this product's
suitability after a full evaluation.
Page 3
Unpacking
The following items are included with the standard specication printer.
If any item is damaged, contact your dealer.
Page 4
Part Names
Page 5
Connecting the Cables
CAUTION:
For a serial interface, use a null modem cable.
For a USB interface, do not turn on the printer before installing the
printer driver. Do not connect to electrical outlets close to devices
that generate voltage uctuations or electrical noise. In particular,
stay clear of devices that use large electric motors.
Never attempt to stretch the cables to enable a connection. The power
cable must have adequate slack at all times during use.
