* All Models Discontinued - Availability through 1Q 2007
Land-Mobile Price List
TK-280/380
VHF / UHF Trunking / Conventional Portable Radios
Model Description List
VHF Spring Action Belt Clip included; Antenna, Battery & Charger not included
TK-280K
TK-280K3
TK-280K2
TK-280K4
UHF Spring Action Belt Clip included; Antenna, Battery & Charger not included
TK-380K2
TK-380K3
TK-380K6
GENERAL FEATURES
5W VHF / 4W UHF Transmit Power
Wide Band Frequency Ranges
12.5 / 25 kHz Channel Spacing
Programmable Power Per Channel
Companded Audio Per Channel (wide &
narrow*)
500 mW Audio Power
Lighted Front Panel Dot Matrix LCD
10 Character Alphanumeric Display
3 Numeric Character Sub-Display
Dot Matrix Lighted LCD
LCD Operational Icons
Two Color Tri-State LED
5 Programmable Function Keys (lighted)
DTMF Keypad Models
Shift Key Function (keypad models)
Optional Speaker Mic (w/ 2 PF Keys)
Recessed Orange Emergency/AUX Key
Encryption/Scrambler Board Control
ANI Board Control
PTT ID Side-Tone (ANI Boards)*
PTT ID TA Inhibit*
Emergency Type (FS, DTMF, ANI Brd.)*
Emergency Calling Feature
Key Lock Feature
DTMF Decode Selective Call
DTMF Deadbeat Disable
DTMF PTT ID & DTMF Emergency ID*
Alert with Transpond (2-Tone, DTMF)*
Call Alert Tone: Mom or Continuous
(2-Tone, DTMF & FleetSync®)*
Auto-Dial Memory (32 numbers)
Key Lock Feature
Low Battery Alert
Weather-Sealed Accessory Connector
PTT Release Tone
146-174 MHz 5W, LTR-32 Systems, CONV-250 CH.
146-174 MHz 5W, LTR-32 Systems, CONV-250 CH., w/DTMF
136-162 MHz 5W, LTR-32 Systems, CONV-250 CH.
136-162 MHz 5W, LTR-32 Systems, CONV-250 CH., w/DTMF
470-512 MHz 4W, LTR-32 Systems, CONV-250 CH.
400-430 MHz 4W, LTR-32 Systems, CONV-250 CH.
400-430 MHz 4W, LTR-32 Systems, CONV-250 CH., w/DTMF
TK-280/380 FEATURES:
Minimum Volume
Control Tones On/Off
Embedded Message (64 Char.)
Data Password (“Anti-piracy”)
Radio Password (Radio Lock)
Clone Capability (enable/disable)
Front Panel Field Programming & Tuning
Windows® PC Programming/ Tune Software
Flash ROM Firmware
MIL810 C, D & E (11 categories)
CONVENTIONAL MODE
250 CH (aggregate max.)
Single Priority Scan
Single/Multi-Group Scan
Scan Revert Channel Display
Scan Delete/Add
Nuisance Delete
QT/DQT Encode & Decode
Operator Selectable Tone (16 OST)
2-Tone Decode (A, B, C, A-B, A-C, C-B; 2 decode pairs)*
BCL, BCL Override, TOT & TA
TRUNKED MODE
32 Systems (max.)
Trunked LTR & Conventional Systems
250 Group IDs (aggregate max.)
Single Priority Scan (within any Conv. System only)
LTR Talk Around / Scan Revert Group Display
System Scan & Group Scan / Auto System Search
FLEETSYNC®
PTT ID (Digital ANI; 100 ID List capacity*)
- Caller ID Display (per CH; BOT only)*
- Caller ID Stack (last 3 calls)*
Status Messaging (50 Msg. List capacity*)
- 70 Custom Dispatch Messages
- 9 Reserved Special Use Messages
ST# 99- Emergency Status
ST# 88- Emergency Mode Off*
ST# 89- Horn Alert Request* (mobiles)
$517.00
550.00
517.00
550.00
517.00
517.00
567.00
FLEETSYNC® CONT.....
ST# 90- Stun radio (No TX)
ST# 91- Stun radio (No TX / No RX audio)
ST# 92- Turn off Stun
ST# 93- ACK stun is ON
ST# 94- ACK stun is OFF
ST# 80-87, 95-97 (Reserved for future use)
Selective Call
Short Text Messages** (stored/display)
--------------------------------------------* Features added in Ver. 2 radios
** Fleetsync® Enhanced Option required (included
as of 10/1/02)
---------------------------------------------------
INCLUDED ITEMS
Spring Action Belt Clip, Instruction Manual
Page 1 of 5 TK-280_380
Page 2
Nov-06
Accessories for the TK-280/380 Series Radios
Model Description List
ANTENNAS
KRA-14M
KRA-14M2
KRA-14M3
KRA-15AM
KRA-15AM2
KRA-15AM3
KRA-16M
KRA-16M2
KRA-16M3
KRA-17M
KRA-17M2
KRA-17M3
KRA-25
BATTERIES AND CHARGERS
3
KBP-4
KNB-16A
KNB-17A
KNB-17BK
KNB-21N
KNB-22N
KNB-22NC
KMB-16
KMB-23
KSC-19
KSC-19M
KSC-24
KSC-24E
KVC-3
KVC-4
VHF helical antenna 148-162 MHz
VHF helical antenna 162-174 MHz
VHF helical antenna 136-150 MHz
UHF whip antenna 450-490 MHz
UHF whip antenna 470-512 MHz
UHF whip antenna 403-430 MHz
VHF stubby antenna 148-162 MHz
VHF stubby antenna 162-174 MHz
VHF stubby antenna 136-150 MHz
UHF stubby antenna 450-490 MHz
UHF stubby antenna 470-512 MHz
UHF stubby antenna 403-430 MHz
High Gain VHF Helically Loaded ¼ Wave Whip Antenna 148-162 MHz (9.75 inches); SMA-F connector
Note: The KRA-25 is 9.75 inches long. This is 3.75 inches longer than a normal VHF helical antenna!
Stocked in limited quantities. Allow up to 8 weeks for delivery.
AA Alkaline Refillable Battery Pack for TK-290/390/280/380 (12 AA Alkaline 9V) Batteries Not Incl.
1100 mAh/8 Hour, 7.2 VDC Ni-Cd battery
1500 mAh/10 Hour, 7.2 VDC Ni-Cd battery
1, 2
Intrinsically Safe Battery 1500 mAh, 7.2 VDC (4/5W), NiCd battery [I.S. Certified]
7
1600 mAh NiMH (more than 10 hours life @ 5-5-90) - requires KSC-24 charger
Note: Not compatible with Kenwood NiCd chargers or earlier model leather cases.
7
2100 mAh NiMH (more than 13 hours life @ 5-5-90) - requires KSC-24 charger
Note: Not compatible with Kenwood NiCd chargers or earlier model leather cases.
8
2100 mAh NiMH (approx. 13 hrs. life @ 5-5-90); requires KSC-24 charger, [I.S. Certified] Must order L-
980 Note: Not compatible with Kenwood NiCd chargers or earlier model leather cases.
Six Unit Charger Adapter for the KSC-20/24/25 rapid rate (chargers not included)
Six Unit Charger Adapter for the KSC-20/24/25 rapid rate chargers (chargers not included)
Small footprint (13"Wx7.8"Hx11.7"D); 2 tiered rows hold 3 KSC-units each
Regular rate single unit desk charger for NiCd batteries only: KNB-16/17A/17B
220 volt regular rate single unit desk charger for NiCd batteries only: KNB-16/17A/17B
110 volt Rapid rate single unit dual-chemistry charger for KNB-14/15/16/17A/17B/20N/21N/22N
220 volt Rapid rate single unit dual-chemistry charger for KNB-14/15/16/17A/17B/20N/21N/22N
Regular rate DC vehicular charger adapter for the KSC-15,19,30 (chargers not included; includes KSC-
mobile bracket & cigarette lighter cable DC adapter)
Note: NOT compatible with NiMH batteries (KNB-20N/21N/22N); Compatible w/NiCd batteries
Rapid rate DC vehicular charger adapter for the KSC-16,24,25 (chargers not included; includes KSCmobile bracket & cigarette lighter cable DC adapter)
Note: Compatible with NiMH batteries (KNB-20N/21N/22N) & NiCd batteries when used with the KSC-24
$17.00
17.00
17.00
17.00
17.00
17.00
13.00
13.00
13.00
13.00
13.00
13.00
32.50
41.00
57.00
67.00
100.00
60.00
70.00
117.00
165.00
182.00
35.00
35.00
59.00
59.00
60.00
80.00
4
KVC-5A
Drop-in Vehicular D.C. Charger for 80/90 Series Portables
Note: Compatible with KNB-16/17A/17B/21N/22N
340.00
CARRYING ACCESSORIES
KBH-10
KBH-8DS
KLH-58BC
KLH-6SW
KLH-75B
KLH-76B
KLH-85
KLH-86
KLH-92
KLH-137ST
KWR-1
Spring action belt clip
5
Swivel belt loop with D-Ring
Bungi-cord for KLH-58/60/71/75/76
Leather swivel belt loop / detachable swivel D-Ring back for a leather case
Heavy duty leather carrying case for TK-280/380/480/481 - compatible w/NiCd & NiMH batteries
Heavy duty leather carrying case for TK-280/285/380/480/481 DTMF keypad models - compatible w/NiCd
& NiMH batteries
Cordura Nylon carrying case for TK-280/380/480/481 DTMF keypad models (Black)
Cordura Nylon carrying case for TK-280/285/380/480/481 (Black)
Heavy duty leather carrying case for TK-280/380/480/481 DTMF keypad models w/ KBP-4
Firemen's Heavy-Duty Leather Shoulder Strap for KLH-75B/76B/92
Water resistant bag
8.00
25.00
3.50
21.00
42.00
42.00
25.00
25.00
42.00
35.00
29.00
Accessories for the TK-280/380 Series Radios Cont'd…
Model Description List
MICROPHONES AND SPEAKERS
1
KEP-1
KCT-30
1
KEP-3
1
KEP-4
KMC-25
KHS-11BE
KHS-11BL
KHS-12BE
KHS-12BL
KHS-14
KHS-15-BH
KHS-15-OH
3.5mm earphone kit for KMC-25/26 Speaker mics (black only) [I.S. Certified]
1
2.5mm Audio Accessory Adapter for KEP-3/4 [I.S. Certified]
Earphone kit w/ 2.5mm plug for KCT-30, 30" Cable (black) [I.S. Certified]
Earphone kit w/ 2.5mm plug for KCT-30, 48" Cable (black) [I.S. Certified]
1
MIL-SPEC, Noise canceling Speaker mic [I.S. Certified]
2-wire palm mic w/earphone, universal connector. ("Beige-colored" 2-wire & 3-wire mic models; Allow
1
min. 4 weeks delivery time). [I.S. Certified]
1
2-wire palm mic w/earphone, universal connector (Black) [I.S. Certified]
3-wire mini lapel mic w/earphone, universal connector. ("Beige-colored" 2-wire & 3-wire mic models;
1
Allow min. 4 weeks delivery time). [I.S. Certified]
1
3-wire mini lapel mic w/earphone, universal connector (Black) [I.S. Certified]
1
Lt. Wt. Single muff headset w/boom mic & In-line PTT, universal connector (Blk) [I.S. Certified]
1
Hvy-duty noise reduction behind-the-headset w/noise cancelling boom mic & in-line PTT (black); NRR24
db; (Heavy-duty headsets; Allow min. 4 weeks delivery time). [I.S. Certified]
1
Hvy-duty noise reduction over-the-headset w/noise cancelling boom mic & in-line PTT (black); NRR24
db. (Heavy-duty headsets; Allow min. 4 weeks delivery time). [I.S. Certified]
Page 2 of 5 TK-280_380
50.00
61.00
49.00
52.00
92.00
149.00
149.00
175.00
175.00
120.00
400.00
350.00
Page 3
Nov-06
QE-2 G-Star®/ MDC1200 DIGITAL ANI MODULES by Cimarron Technologies
How to Order: Please see QE-2 Information and Order Sheet available from LMR Order Desk
1. Select the proper model/ quantity of radios, desired MDC-1200 (L-901) or G-Star (L-902) ANI format labor code.
2. Refer to the "QE-2 MDC-1200 Information/Order Sheet" available from the LMR Order Desk; select the ID format, ID codes and other feature options
3. Fax the Order Sheet with your radio order to your authorized Kenwood Rep or LMR Order Desk
All order sheet items must be filled out even if the feature option is "disabled" (incomplete Order Sheets will not be processed).
a. QE-2's are Kenwood installed only; these are not available as "shipped loose" (pre-programmed or not).
b. Allow a min. 1 week delivery ARO for 1- 25 units (allow min. 3 weeks for 25 units and up).
Dealers can purchase a QE-2 programmer , Model QPF-2, direct from Cimarrron Technologies Call 800-487-7184 www.cimtechcorp.com
QE-2
Transcrypt Secure Technologies Encryption
The following Transcrypt Secure Technologies encryption accessories (available from Transcrypt) and TK-280/380/480/481 combination when installed according to
Transcrypt instructions meet Intrinsically Safe Classes I, II & III, Div.1, Groups C, D,E, F & G hazardous locations and Non-Incendive Class I, Div. 2, Groups C, D
hazardous locations:
· SC20-400 · SC20-430-12
· SC20-416-12 · SC20-460-12
For more information on Transrcypt encryption please visit their website at www.transcryptsecure.com or contact them at:
Transcrypt Secure Technologies
4800 NW 1st Street, Suite 100
Lincoln, NE 68521
Phone: 402-474-4800
Fax: 402-479-8472
G-Star® or MDC1200 ANI Board : PTT ANI, emergency & man-down
Important Factory Install Only – Order L-901 or L-902
128.00
SERVICE RELATED ACCESSORIES
KPG-36
KPG-49DK
Programming interface Cable
P.C. Programming Software for TK-280/380/480/481/780/880/980/981
N/A
N/A
Page 3 of 5 TK-280_380
Page 4
Nov-06
Installation/Tuning Charges for the TK-280/380 Series Radios
Model Description List
L-836
L-961
L-855
L-856
L-980
L-901
L-902
Assemble KMB-16 with six KSC-24's (Rapid Rate, 120 Volt version only)
Assemble KMB-23 with six KSC-24/25/32 (Rapid Rate, 120 Volt versions only)
TK-280/380 Programming (with basic TX/RX check)
Configure TK-280/380 for Intrinsically Safe (Must Order KNB-17BK)
Configure TK-280/380/480/481/385 (KNB-22NC for Intrisically Safe (Must Order KNB-22NC)
Program and install QE-2 MDC1200 Encoder
Program and install QE-2 G-Star® Encoder
15.00
17.00
25.00
70.00
70.00
75.00
75.00
PassPort® Options (Kenwood-installed)
FOR NEW RADIO ORDERS ONLY
Ordering Instructions
For VHF/UHF models TK-280/780/380/880 new radio orders, the Kenwood-installed PassPort® ESN / firmware option is no charge:
Order the PassPort® ESN/Firmware option L-938 for each PassPort® radio.
Other required items:
a. KPG-63D Radio Programming Software: the KPG-63D is required to program all PassPort® parameters for all PassPort® enabled
radios, the KPG-63D will not program LTR or conventional parameters.
b. KPG-49D is required only if LTR or conventional systems are to also be programmed in the PassPort® radio.
Model Description List
L-938
PassPort® Radio Programming Software
KPG-63DK
Install PassPort® ESN options and firmware; NO CHARGE for new TK-280/380/780/880 orders
Note: Only current 80-Series Version 2.0 production radios (“Ver. 2.0” appears on FCC ID label)
PassPort® Radio Programming Software V2.00 or higher
0.00
65.00
PassPort® Options (Field-installation kits)
FOR DEALER / OPERATOR FIELD CONVERSIONS
Ordering Instructions
1. Order the ESN key/firmware Labor Code options: L-892, L-893 or L-894; specify model radio(s).
Pre-loaded ESN hardware key(s) with the ordered quantities of ESN's and a PassPort® radio firmware diskette will be shipped (100 ESN’s
maximum per hardware key). Important: Any depleted key previously registered to a technicians computer must be retained to
register any new purchased key to the computer; please retain the old key until the new one is received.
2. Other required items:
a. KPG-64D: PassPort® ESN Install Program: the KPG-64D only needs to be ordered one time. It is re-usable for subsequent ESN orders
(unless an upgrade is recommended).
b. KPG-63D Radio Programming Software: required to program all PassPort® parameters for all PassPort® enabled radios, the KPG-63D will
not program LTR or conventional parameters.
c. KPG-49D Radio Programming Software: required only if LTR or conventional systems are also tbe programmed in the PassPort® radio.
3. The KPG-49D radio programming software is required for LTR & conventional site programming
2
.
Page 4 of 5 TK-280_380
Page 5
Nov-06
Model Description List
L-892
L-893
L-894
Note: Sales of L-892, 893, 894 are NOT refundable. Purchaser has a 72 hour limit after receipt to report suspected hardware key defects or ESN shortages to
Kenwood engineering, Suwanee office 678-474-4700
SRB08698
NOTES:
· Requires purchase of L-892, 893 or 894
· Sales of L-892, 893, 894 are NOT refundable
· Maximum 100 ESNs per hardware key
· Requires KPG-64D to download PassPort TM ESN options into an 80-Series radio.
· Important: The hardware key is registered to the computer that it is first used on; it cannot be used on other computers.
· Empty hardware keys can be returned for 50% credit; call the LMR order desk for RMA #.
· Important: Retain depleted keys until a new one is received. It will be required to register the new key to the same computer.
KPG-64D
KPG-63D
PassPort® ESN Options & PassPort® firmware disk (SPECIFY RADIO MODEL)
· 1-24 qty. lot price; Price is per ESN
PassPort® ESN Options & PassPort® firmware disk (SPECIFY RADIO MODEL)
· 25-99 qty. lot price; Price is per ESN
PassPort® ESN Options & PassPort® firmware disk (SPECIFY RADIO MODEL)
· 100 qty lot price; Price is per ESN
· Maximum 100 ESN options per hardware key
Hardware Key (Sentinel Super Pro)
PassPort® ESN Field Installation Software V1.12
· V1.12: supercedes V1.11; upgrade to V1.12 recommended for improved ESN file database features
PassPort® Radio Programming Software V2.00 or higher
IMPORTANT NOTES:
1
For intrinsically safe models TK-190/280/380/290/390/480/481: Meets Intrinsically Safe Classes I, II & III, Div. 1, Groups C, D, E, F, G hazardous locations
and Non-Incendive Class I, Div. 2, Groups C, D hazardous locations.
2
Important Note Regarding Intrisically Safe Certification: Using an Intrinsically Safe battery on a radio does not constitute an Intrinsically Safe (I.S.) radio.
All Kenwood I.S. radios must be certified at Kenwood by inspection, logging & proper labeling. The appropriate I.S. labor code must be specified on all I.S.
radio orders and the proper model I.S. battery must be used with the radio. Kenwood I.S. batteries can be purchased separately for existing Kenwood
certified I.S. radios. Intentionally or inadvertently representing a Kenwood radio as I.S. without proper Kenwood certification can result in serious safety and/or
legal liability issues for your company.
3
AA refillable packs DO NOT meet any of the MIL-STD environmental standards, nor are they water-resistant or Intrinsically Safe approved.
Actual battery life is dependent on battery condition, type, quality, temperature, and use habits. Alkalines exhibit non-linear voltage vs. current drain
characteristics, therefore radio transmit power will lower and decrease during transmit and as the battery is drained. Nominal Life (hrs.) 5-5-90 duty cycle,
battery save off, scan off. See chart below:
Transmit Power 1W 2W 4/5W
Nominal Battery Life (hrs.) 18 11.5 4
4
KVC-5 & KVC-6 has the following features: Accommodates Speaker/Microphones of KMC-25/26 (for KVC-5), and KMC-17/21 (for KVC-6), with retainer
brackets; Rapid Charge LED (red) -- "on" when portable radio is properly seated and battery is in rapid charge mode, Trickle Charge LED (green) -- "on"
when the battery is fully charged and the charger is in the trickly charge mode, repeat enable LED (yellow) -- "on" when the Automatic Enable switch is on
and the portable is removed (it goes "off" when portable is inserted), and Automatic Repeat Enable Switch (activates the vehicular repeater units, e.g.
Pyramid Communications brand SVR units). Note: These units are ONLY charger units. They are NOT vehicular adapters with RF, P.A., AF P.A., antenna
connector, speaker & mobile hand mic. (a.k.a.; "console", "vehicular console", "convert-a-com", "jerk & run").
5
Retain the screws included with the metal belt clip (included with radio). These are required to attach the KBH-8 or KBH-8DS. Screws also available from
Parts Dept.: Part # N99-2004-05.
6
Required to program both normal radio parameters and all FleetSyncTM feature parameters.
7 Important Note regarding KNB-21N/22N/22NC:
- NiMH batteries will exhibit reduced capacity while exposed to temperatures below 14°F(-10°C) and become virtually unusable below -4°F or
(-20°C). NiMH batteries are commonly used in extreme low temperature environments (ex: northern latitudes, refrigerated warehousing, etc.) by
keeping the portable next to the body under the users coats. Prolonged exposure to extreme cold should be avoided for proper radio operation.
- NiMH batteries capacity life is slightly lower than NiCd: NiCd : 70% at 500 cycles vs. NiMH (1600 mAh): 60% at 500 cycles
8
Meets Intrinsically Safe requirements of Classes I, II, III, Division 1, Groups C, D, E, F, G, & Non-Incendive Class I, Division 2, Gropus C, D hazardous
locations.
The KNB-22NC is labeled "KNB-22NC is an authorized alternate to KNB-17B" and therefore the KNB-22NC can be sold into existing portable fleets using
KNB-17BK and not compromise the portables I.S. certification.
The KNB-22NC does NOT require re-adjustment of the Low Battery Warning settings. Portables previously inspected & readjusted by Kenwood Tuning
Dept. or
the dealership for KNB-17B Low Battery Warning should be re-adjusted for the Low Battery Warning factory default setting (per the service manual).
$68.00
68.00
68.00
83.33
10.00
65.00
Page 5 of 5 TK-280_380
Loading...
