Page 1
KeHmor&
OWNER'S MANUAL FOR
KENPORE HEPA AIR CLEANER
MODEL 152.85244
' » I
..................
..
c\^/ys
tNFO - LINE:
After reading this manual, if you have any questions or comments on your
Kenmore Air Cleaner, call 1-888-277-2810
* •
• Safety
• Operation
To order replacement filters by phone,
call toll free: 1 (800) 366-7278
7 AM to 7 PM 7 days a week
Sears, Roebuck and Co., Hoffman Estates, !L 60179 U.S.A.
> Warranty
> Parts
Page 2
IMPORTANT SAFETY INSTRUCTIONS
Please read all instructions before using this product. Save these
instructions for easy reference. When using electrical appliances,
basic precautions should always be followed to reduce breakage,
risk of fire, electric shock and injury to persons including the following;
• Read all instructions before operating the air cleaner.
• Place the air cleaner where it is not easily knocked over by persons
in the household.
• ALWAYS unplug air cleaner when not in use.
• DO NOT use any product with a damaged cord or plug, or if product
malfunctions, is dropped or damaged in any manner.
■ Keep the power cord away from heated surfaces.
• DO NOT use air cleaner outdoors.
• NEVER use the air cleaner unless it is fully assembled.
• DO NOT run power cord under carpets and DO NOT cover with
throw rugs. Arrange cord so it will not be tripped over.
• DO NOT use air cleaner where combustible gases or vapors
are present.
• DO NOT expose the air cleaner to rain, or use near water,
in a bathroom, laundry area or other damp locations.
■ To disconnect air cleaner, first turn speed dial to OFF position and
remove plug from outlet.
• DO NOT allow foreign objects to enter
as this may cause electric shock or damage to the air cleaner.
DO NOT block air outlets or intakes.
• Place air cleaner near a power outlet, and avoid using an
extension cord.
»The air cleaner has a polarized plug (one blade is wider than
the other). To reduce the risk of shock, this plug is intended to fit
in a
polarized
outlet, reverse the plug. If it still
to
install
' A loose fit between the plug and the AC outlet (receptacle)
may cause overheating and distortion of the plug. Contact a
qualified electrician to replace loose or worn receptacles.
' DO NOT sit, stand or place heavy objects on the air cleaner.
• ALWAYS disconnect power supply before servicing.
outlet only one way. If
does
the proper outlet. DO NOT try to alter the plug in any way.
ventilation
the
plug does not fit fully in the
not fit, contact qualified personnel
or exhaust opening,
A WARNING; To reduce the risk of fire or electric shock,
DO NOT use this product with any solid-state speed control device.
Page 3
ONE YEAR FULL WARRANTY ON KENMORE AIR CLEANER
If this air cleaner fails due to a defect in material or workmanship within
one year from the date of purchase, return it to your nearest Sears Parts
& Repair Center to have it repaired free of charge. Free repair does not
include replacing the pre-filter or HERA filter, which are expendable
parts that can wear out from normal use before one year expires.
If repair is not possible, at your option Sears will replace this product or
refund its full purchase price.
This warranty is void if this product is used for commercial or rental
purposes.
This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL 60179
INTRODUCTION_______________________________________________
Congratulations on your choice of the Kenmore HEPA Air Cleaner.
We highly recommend that you operate the Air Cleaner 24 hours
a day, because indoor air can be quickly contaminated by activity
or objects in a room and infiltration of outside air. Portable air cleaners
are much more effective in rooms where all doors and windows
are closed.
Page 4
HOW IT WORKS
This Air Cleaner is equipped with a HERA (High Efficiency Particulate
Arrestor) filter. Room air is drawn into the Air Cleaner through the Air
Intake Grille and passes through the HERA filter. The filtered air is
released from the top of the unit and is dispersed upwards into the room.
The Air Cleaner has three operating speeds: HI, MED and LO.
The indicator light is “ON” when the Air Cleaner is operating.
Your Air Cleaner has an ionizer with a red light indicating when
it is turned “ON”.
Use of ionizer boosts cleaning efficiency and revitalizes stale air.
SET UP
______________________________________________________
Your Air Cleaner was thoroughly inspected and tested at the
factory prior to packaging. Visually inspect it upon removal
from its box. Remove and discard any packaging material.
Return the unit if it shows any signs of damage or mishandling.
Adjust the filter change wheel to properly indicate when the
next filter change is necessary.
ELECTRICAL HOOKUP
Plug the Air Cleaner into a polarized 120-Volt AC wall outlet.
AwARNING: To avoid the risk of fire or electric shock hazard, the
Air
Cleaner
should ONLY be plugged into a polarized 120-Volt AC outlet.
OPERATION
A.CAUTION! NEVER operate the Air Cleaner without the HEPA filter
properly
Each time you start the Air Cleaner, it is a good idea to run it
at HI speed for a few seconds for fast, initial cleaning. Then
set to MED or LO as desired.
installed. Permanent
motor
damage could result.
Page 5
OPERATION coni.
•HI
•MED
• LO Nighttime
• On/Off Ionizer Use for fast initial cleaning
Operation
• When the ionizer is activated it
freshen the air by removing smail airborne particies. When
using ionizer, be sure to piace air cleaner about one foot
away from the walls. This will help keep airborne dust
particles from depositing on walls.
FILTER CHANGE SCHEDULE
• HEPA Filter: The usable lifetime of the HEPA filter is 1 - 2 years,
depending upon the level of the room's air contaminants and the
frequency of use. The FiEPA filter will turn medium brown and air
volume will begin to decrease dramatically when the filter needs to
be changed. You should have a spare filter available for later
replacement.
FILTER REPLACEMENT
This HEPA filter is specially designed for easy replacement to
provide maximum performance. THE HEPA FILTER IS NOT
WASHABLE.
Use
helps
_______________________________
to further
Fast Initial Cleaning
Normal Cleaning
Quieter Operation
dean
and
1. Turn the air cleaner OFF and unplug it from the power outlet.
2. Carefully lay the unit down on a flat surface with the Front
Grille facing up.
3. Gently push in on Release Buttons on both sides of the unit,
pull Front Grille out and away.
4. Remove and discard used HEPA filter.
5. Remove any plastic protective wrapping and
packaging from the new HEPA filter.
6. Set new HEPA filter into the air cleaner.
7. Install the Front Grille by engaging its tabs into the bottom
slots on the unit. Then swing grille up and gently push in top
to snap into place.
8. Turn the Air Cleaner upright and plug it into an outlet for
operation.
Page 6
FILTER REPLACEMENT cont
Iviodel 32-85244
HEPA
Filter
Release Tabs on
Both Sides of Top
Front of Grille Filter
CLEANING THE UNIT
AwARNING: To avoid serious injury from electric shock ALWAYS
turn the Air Cleaner OFF and disconnect the plug from the outlet
BEFORE cleaning.
1. Turn Air Cleaner OFF and unplug from outlet.
2. Clean unit with a moistened soft cloth only. DO NOT pour
or splash water on the unit or use any abrasive-type cleaner
on it. Clean all external surfaces, especially the air intake
grilles and air outlet.
3. DO NOT attempt to clean the FIEPA filter; it IS NOT washable and
washing will damage it.
4. Reposition Air Cleaner plug into power outlet and turn ON.
STORAGE____________________________________________________
If you store your Air Cleaner for more than 30 days you should:
1. Remove the HEPA filter from the unit.
2. Wrap the HEPA filter in an air-tight plastic bag or plastic wrap. Be sure
that the filter is totally sealed to protect it from its storage environment.
3. DO NOT put the plastic-wrapped HEPA filter back into the Air Cleaner.
4. To restore the Air Cleaner to service:
• Unwrap the HEPA filter.
• Install filter assembly in the air cleaner. See “Filter
Replacement” section for proper installation.
Page 7
TECHNICAL SPECIFICATIONS
liJiR/tODiLiS
Length
Width
Height
Weight 7.2 lbs. (3.3kg)
Input Voltage
REPLACEMENT PARTS
CUSTOMER ASSISTANCE LINE
If you experience a problem, please see the warranty for information.
DO NOT attempt to repair this unit yourself. Doing so will void your
warranty, and could cause serious personal injury to yourself,
or damage the Air Cleaner.
If you have any questions concerning this appliance, please
call toll free: 1-888-277-2810
Monday - Friday 8;30 A.M. to 5:00 P.M. GST
12 in. (30.5cm)
6.5 in. (16.5cm)
14 in. (36.5cm)
120 volts AC, 60 Hz
HOWTO ORDER REPLACEMENT PARTS
To order replacement parts by phone, call toll
free 1-800-366-7278
7 A.M.-7 P.M.
7 days a week
______________________
